DAV
-
DX375
Integrated Home Theater System
Key Features
5 Disc DVD/CD/SACD Player with HDMI
™ Output
1000 Watts-143WattsX5 (1kHz,<10%THD)
+285Watt Subwoofer
Portable Audio Enhancer with Front Audio Input
Digital Cinema Auto Calibration w/ Mic (auto
speaker setup)
Music/Movie Mode
Multi-Speaker Formation Feature
Front Speaker Stands Included
S
-
Master
®
Digital Amplifier
Key Technologies
HDMI
™ Output with 720P/1080i upscaling of DVD Media --- Reads the data on a standard DVD at
480P and maximizes the video resolution to best fit your HDMI compatible TV. This allows for you to enjoy the
best in video performance while delivering digital Video and Audio over one simple cable.
Portable Audio Enhancer Simplified front audio and video connections are part of what makes the STR-
DG800 ideal for today’s portables. Beyond the simplified connection a powerful Digital Signal Processor is
used to expand the quality from any device that is connected.
Digital Cinema Auto Calibration Now the optimal speaker for your living room is only a press of button
away. Simply place the included microphone in your listening position and allow the strength of Sony’s Digital
Signal Processing to take over. Speaker placement, distance, and delays are all adjusted automatically to
ensure a worry free listening experience.
Music/Movie Mode System automatically adjusts sound characteristics to match the source (movie vs.
music).
Multi Speaker Formation Select from the on screen display to configure the system for different speaker
layout.
DAV
-
DX375
Integrated Home Theater System
Last Updated: 04/03/2006
Please visit the Dealer Network for current
information at www.sony.com/dn
Specifications
DVD, VCD, CD Player
Video
Play Mode:
Shuffle, Program, Repeat
Digital
-
to
-
Analog Converter:
108MHz/12bit
Amplifier
General
Function:
CD, DVD, Audio
Audio
Digital Amplifier: Yes (S-Master
®
Digital
Amplifier)
Equalizer:
Bass Boost function (Dynamic Bass on
RM)
Audio Power Output:
Amplifier: 1000W Total,
Center Speaker: 143W (1KHz 10%THD), Front
Speaker: 143W x 2 (1KHz 10%THD), Subwoofer
Speaker: 285W (1KHz 10%THD), Surround
Speaker: 143W x 2 (1KHz 10%THD)
Tuner Type: AM, FM
Speaker Type:
DAV Connector
Digital
-
to
-
Analog Converter:
48kHz/24bit
Convenience
Timer Clock: Yes (Sleep)
Inputs and Outputs
Analog Audio Input(s): 2 (Rear)
Component Video (Y/Pb/Pr) Output(s):
1
(Rear)
Composite Video Output(s): 1 (Rear)
Headphone Input(s): 3.5mm
HDMI
™ Connection Output(s): 1 (Rear)
S
-
Video Input(s): 1 (Rear)
Power
Power Requirements:
AC120V, 60Hz
Power Consumption (in Operation):
160W
Power Consumption (in Standby):
Less than
0.3W
Tuner
Audio
Station Preset(s):
10 AM, 20 FM
Tuner Type: AM/FM
Inputs and Outputs
Antenna Terminal(s):
Yes (FM: 75 ohm)
Front Speaker
Speaker
Woofer(s):
6.5cm
Speaker System:
1 way (Full Range)
Audio
Impedance:
3 ohm
Weights and Measurements
Cord Length (Approx.):
5m x 2
Dimensions (Approx.):
3 5/8 x 8 2/3 x 3 2/13" (92
x 220 x 80mm)
Weight (Approx.):
1 lbs, 9 oz (0.7 kg)
Center Speaker
Speaker
Satellite: Yes
Speaker System:
1 way (Full Range)
Audio
Impedance:
3 ohm
Weights and Measurements
Cord Length (Approx.):
1 x 5m
Dimensions (Approx.):
10 3/13 x 3 5/7 x 3
5/13" (260 x 94.5 x 86mm)
Weight (Approx.):
1 lbs, 9 oz (0.7 kg)
Surround Speaker
Speaker
Speaker System:
1 way (Full Range)
Speaker Dimensions:
6.5cm
Audio
Impedance:
3 ohm
Weights and Measurements
Cord Length (Approx.):
15 m x 2
Dimensions (Approx.):
3 5/8 x 5 15/16 x 3
3/13" (92 x 151 x 82mm)
Weight (Approx.):
1 lb, 5 oz (0.6 kg)
Subwoofer Speaker
Speaker
Speaker System:
DDTD
Speaker Type: Bass Reflex (Ported)
Audio
Impedance:
1.5 ohm
Weights and Measurements
Dimensions (Approx.):
9 4/9 x 14 8/11 x 15
5/14" (240 x 374 x 390mm)
Weight (Approx.):
14 lbs, 12 oz (6.7 Kg)
Dimensions
Weight:
Amplifier: 11 lbs, 0 oz (5 Kg) Center
Speaker: 1 lb, 9 oz (0.7 kg) Front Speaker: 9 lbs,
15 oz (4.5 Kg) Subwoofer: 14 lbs, 12 oz (6.7 Kg)
Surround Speaker: 1 lb, 5 oz (0.6 kg)
Measurements:
Amplifier: 1 2/11 x 3 5/14 x 16
8/15" (30 x 85 x 420mm) Center Speaker:2 4/11
x 3 5/7 x 3 5/13" (60 x 94.5 x 86mm) Front
Speaker: 3 5/8 x 8 2/3 x 3 2/13" (92 x 220 x
80mm) Subwoofer: 9 4/9 x 14 8/11 x 15
5/14" (240 x 374 x 390mm) Surround Speaker:
3 5/8 x 5 15/16 x 3 3/13" (92 x 151 x 82mm)
1.Playback depends on recording conditions
©2006 Sony Electronics Inc. All Rights Reserved.
Reproduction in whole or in part without written permission is prohibited. All
rights reserved. Sony and S-Master are trademarks of Sony. Dolby is a
registered trademark of Dolby Laboratories. dts is a trademark of Digital
Theater Systems, L.P. HDMI is a trademark of HDMI Licensing LLC. All other
trademarks are property of their respective owners.
Features and specifications are subject to change without notice. All Weights
and measures are approximate.
