08 user guide
User guide
English
Language
Language
Language
1
2
Microphone
Microphone
Call handling
key
Call handling
key
Earspeaker
Earspeaker
Volume keys
Volume keys
Power key
Power key
Indicator light
Indicator light
First time charging: about 8 hours
Normal charging: about 2 hours
First time charging: about 8 hours
Normal charging: about 2 hours
Battery needs charging
Battery needs charging
Charging
Charging
Fully charged
Fully charged
3
4
5
1
3
2
1
34
2
xxx xxx xx
Regulatory information
Regulatory information
6
FCC Statement
This device complies with Part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) This device must accept any interference
received, including interference that may cause undesired operation.
Any change or modification not expressly approved by Sony Ericsson
may void the user's authority to operate the equipment.
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Industry Canada Statement
This device complies with RSS-210 of Industry Canada.
Operation is subject to the following two conditions: (1) this device
may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired
operation of the device.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-
003 du Canada.
Declaration of conformity for HBH-PV720
We, Sony Ericsson Mobile Communications AB of
Nya Vattentornet
SE-221 88 Lund, Sweden
declare under our sole responsibility that our product
Sony Ericsson type DDA-0002018
to which this declaration relates is in conformity with the appropriate
standards EN 300 328:V1.7.1, EN 301 489-7:V1.3.1, EN 301 489-
17:V1.2.1 and EN 60950-1:2006 following the provisions of Radio
Equipment and Telecommunication Equipment directive 1999/5/EC.
Lund, May 2008
Jacob Sten, Head of Product Business Unit Accessories
We fulfil the R&TTE Directive.
We fulfil the R&TTE Directive.
We fulfil the R&TTE Directive.
We fulfil the R&TTE Directive.
English
The Bluetooth™ headset HBH-PV720 can be
connected to any device with Bluetooth wireless
technology that supports the handsfree or headset
profile. This User guide focuses on use with a Sony
Ericsson mobile phone.
Charging the headset
Before using the HBH-PV720 for the first time, charge
it with, for example, the supplied charger or your
phone charger, see figure 2. For compatible chargers,
see figure 3.
Turning on and off the headset
To turn on the headset
•Press the power key (see figure 1). The indicator light
shows a steady green light (if the light is red, the
headset needs charging). After 3 seconds, the light
turns off and the headset stays on.
To turn off the headset
•Press and hold down the power key until the
indicator light shows a steady green light (if the light
is red, the headset needs charging). After 2 seconds,
the light fades and the headset turns off.
Pairing the headset
Before you can use the headset it has to be paired
once with your phone. After a successful pairing, the
headset automatically connects to the phone when it
is turned on and within range.
Note: When you put the headset in pairing mode, do not
press the call handling key together with the power key.
To pair the headset with your phone
1. Turn on the Bluetooth function in the phone. For
instructions, see the phone User guide.
2. Place the phone within 20 cm (8 inches) of the
headset.
3. Turn on the headset. The first time you do so, the
headset automatically enters pairing mode and tries
to pair with your phone (auto pairing).
Note: If auto pairing is not supported by your phone, or
not successful, follow the two first steps above and turn
on the headset. Then add the headset to your phone as
described in your phone User guide. The passcode is
0000.
To pair the headset with another phone
1. Turn on the Bluetooth function in the phone. For
instructions, see the phone User guide.
2. Place the phone within 20 cm (8 inches) of the
headset.
3. Turn off the headset if it is turned on. Press and hold
down the power key until the indicator light flashes
red and green alternately.
4. Press Yes when Add device? appears in the phone.
If required, the passcode is 0000. The headset
beeps and flashes green when successfully paired.
Putting on the headset
Slide the ear hook behind your ear and point the
microphone toward your mouth. For left ear use,
change the position of the ear hook as instructed in
figure 4.
Calling
When you have paired the headset with your phone,
you can make and receive calls as long as the headset
is turned on.
Solid objects, walls and a greater distance than 5
metres (16.5 feet) can affect the sound quality
negatively. For best performance, wear the headset
and the phone on the same side of your body.
To make a call
•Use the phone keys to dial the number as normal.
The call is automatically activated in the headset.
To end a call
•Press the call handling key briefly.
To answer a call
•Press the call handling key briefly.
To reject a call
•Press and hold down the call handling key until you
hear a short beep (after 2 seconds).
To redial the last number
•Double-click the call handling key.
To answer a second call
•Press the call handling key. The ongoing call is put
on hold.
To switch between two calls
•Press and hold down the call handling key until you
hear a beep.
To turn off the microphone (mute)
•Press both volume keys simultaneously. Mute is
indicated with a beeping sound. Repeat to turn on
the microphone again.
Adjusting volume
To adjust the ring volume
•When you are not making a call, or when the phone
is ringing, press a volume key.
To adjust the speaker volume
•During a call, press a volume key.
Calling using voice commands
Voice commands can be useful when you are using
the headset and the phone is not close to you. For
more information on voice commands, see your
phone User guide.
To make a call using voice commands
•Press the call handling key briefly, wait for a beep
and say your command.
Note: Make sure voice commands are enabled and
recorded in your phone before you use them.
Transferring sound
To transfer sound from the phone to the
headset
•During a call, press the call handling key briefly. The
sound is transferred to the headset.
To transfer sound from the headset to the
phone
•See the phone User guide.
Battery
A new, or infrequently used, battery could have
reduced capacity. It may need to be recharged a
number of times.
When the battery needs charging, the indicator
light flashes red and you hear a low beep. If you do not
charge the headset, it automatically turns off.
To check the battery status
•Press the power key briefly:
•steady green light plus one green flash – the
battery needs charging soon
•steady green light plus two green flashes – the
battery is half full
•steady green light plus three green flashes – the
battery is fully charged
Resetting the headset
To reset the headset
1. Turn off the headset.
2. Press and hold down the power key until the
indicator light flashes red and green alternately.
3. Press and hold down the power key and the call
handling key simultaneously until the headset turns
off.
4. Pair the headset with the phone in the same way as
you paired it the first time.
Language 2
HBH-PV720
Lyra_UG.book Page 1 Wednesday, May 21, 2008 2:59 PM
Sony Ericsson Mobile Communications AB
SE-221 88 Lund, Sweden
1211-9294.1
Printed in XXXXX
1
Microphone
Microphone
Call handling
key
Call handling
key
Earspeaker
Earspeaker
Volume keys
Volume keys
Power key
Power key
Indicator light
Indicator light
2
3
4
First time charging: about 8 hours
Normal charging: about 2 hours
First time charging: about 8 hours
Normal charging: about 2 hours
Battery needs charging
Battery needs charging
Charging
Charging
Fully charged
Fully charged
1
3
2
5
6
1
34
2
xxx xxx xx
Regulatory information
Regulatory information
Language 3
The Bluetooth™ headset HBH-PV720 can be
connected to any device with Bluetooth wireless
technology that supports the handsfree or headset
profile. This User guide focuses on use with a Sony
Ericsson mobile phone.
Charging the headset
Before using the HBH-PV720 for the first time, charge
it with, for example, the supplied charger or your
phone charger, see figure 2. For compatible chargers,
see figure 3.
Turning on and off the headset
To turn on the headset
•Press the power key (see figure 1). The indicator light
shows a steady green light (if the light is red, the
headset needs charging). After 3 seconds, the light
turns off and the headset stays on.
To turn off the headset
•Press and hold down the power key until the
indicator light shows a steady green light (if the light
is red, the headset needs charging). After 2 seconds,
the light fades and the headset turns off.
Pairing the headset
Before you can use the headset it has to be paired
once with your phone. After a successful pairing, the
headset automatically connects to the phone when it
is turned on and within range.
Note: When you put the headset in pairing mode, do not
press the call handling key together with the power key.
To pair the headset with your phone
1. Turn on the Bluetooth function in the phone. For
instructions, see the phone User guide.
2. Place the phone within 20 cm (8 inches) of the
headset.
3. Turn on the headset. The first time you do so, the
headset automatically enters pairing mode and tries
to pair with your phone (auto pairing).
Note: If auto pairing is not supported by your phone, or
not successful, follow the two first steps above and turn
on the headset. Then add the headset to your phone as
described in your phone User guide. The passcode is
0000.
To pair the headset with another phone
1. Turn on the Bluetooth function in the phone. For
instructions, see the phone User guide.
2. Place the phone within 20 cm (8 inches) of the
headset.
3. Turn off the headset if it is turned on. Press and hold
down the power key until the indicator light flashes
red and green alternately.
4. Press Yes when Add device? appears in the phone.
If required, the passcode is 0000. The headset
beeps and flashes green when successfully paired.
Putting on the headset
Slide the ear hook behind your ear and point the
microphone toward your mouth. For left ear use,
change the position of the ear hook as instructed in
figure 4.
Calling
When you have paired the headset with your phone,
you can make and receive calls as long as the headset
is turned on.
Solid objects, walls and a greater distance than 5
metres (16.5 feet) can affect the sound quality
negatively. For best performance, wear the headset
and the phone on the same side of your body.
To make a call
•Use the phone keys to dial the number as normal.
The call is automatically activated in the headset.
To end a call
•Press the call handling key briefly.
To answer a call
•Press the call handling key briefly.
To reject a call
•Press and hold down the call handling key until you
hear a short beep (after 2 seconds).
To redial the last number
•Double-click the call handling key.
To answer a second call
•Press the call handling key. The ongoing call is put
on hold.
To switch between two calls
•Press and hold down the call handling key until you
hear a beep.
To turn off the microphone (mute)
•Press both volume keys simultaneously. Mute is
indicated with a beeping sound. Repeat to turn on
the microphone again.
Adjusting volume
To adjust the ring volume
•When you are not making a call, or when the phone
is ringing, press a volume key.
To adjust the speaker volume
•During a call, press a volume key.
Calling using voice commands
Voice commands can be useful when you are using
the headset and the phone is not close to you. For
more information on voice commands, see your
phone User guide.
To make a call using voice commands
•Press the call handling key briefly, wait for a beep
and say your command.
Note: Make sure voice commands are enabled and
recorded in your phone before you use them.
Transferring sound
To transfer sound from the phone to the
headset
•During a call, press the call handling key briefly. The
sound is transferred to the headset.
To transfer sound from the headset to the
phone
•See the phone User guide.
Battery
A new, or infrequently used, battery could have
reduced capacity. It may need to be recharged a
number of times.
When the battery needs charging, the indicator
light flashes red and you hear a low beep. If you do not
charge the headset, it automatically turns off.
To check the battery status
•Press the power key briefly:
•steady green light plus one green flash – the
battery needs charging soon
•steady green light plus two green flashes – the
battery is half full
•steady green light plus three green flashes – the
battery is fully charged
Resetting the headset
To reset the headset
1. Turn off the headset.
2. Press and hold down the power key until the
indicator light flashes red and green alternately.
3. Press and hold down the power key and the call
handling key simultaneously until the headset turns
off.
4. Pair the headset with the phone in the same way as
you paired it the first time.
Language 4Bluetooth™ Headset HBH-PV720
User guide
User guide
User guide
User guide
Sony Ericsson HBH-PV720
This User guide is published by Sony Ericsson Mobile
Communications AB, without any warranty. Improvements and
changes to this User guide necessitated by typographical errors,
inaccuracies of current information, or improvements to programs
and/or equipment, may be made by Sony Ericsson Mobile
Communications AB at any time and without notice. Such changes
will, however, be incorporated into new editions of this User guide. All
rights reserved.
©Sony Ericsson Mobile Communications AB, 2008
Publication number: 1211-9294.1
Some of the services in this User guide are not supported by all
networks. This also applies to the GSM International Emergency
Number 112. Contact your network operator or service provider if you
are in doubt whether you can use a particular service.
The Bluetooth word mark and logos are owned by the Bluetooth SIG,
Inc. and any use of such marks by Sony Ericsson is under license.
Sony and WALKMAN are trademarks or registered trademarks of
Sony Corporation.
Ericsson is a trademark or registered trademark of
Telefonaktiebolaget LM Ericsson.
This product is leadfree and halogenfree.
Lyra_UG.book Page 1 Wednesday, May 21, 2008 2:59 PM
