Sony DSX A415BT User Manual Marketing Specifications Docget
User Manual: Sony DSX-A415BT Marketing Specifications
Open the PDF directly: View PDF .
Page Count: 4

Keep in touch on the road with Dual Bluetooth connectivity from the DSX-
A415BT. Wirelessly connect your rst phone to play music, get directions
and communicate with contacts. Add a second phone to make hands-
free calls on the move from either one.1
DSX-A415BT
Media Receiver with BLUETOOTH® Technology
• Bluetooth media receiver lets you connect two
smartphones simultaneously1
• Voice control with Siri Eyes Free2 and Android
• USB input lets you play music from your iPhone and iPod7
• 55Wx4 for powerful sound reproduction
• Sound-synchronized illumination pulses to the music if
desired
Bullets
Tap to connect wirelessly
NFC technology lets you connect your Bluetooth® phone instantly, just by tapping it on the receiver’s volume knob.1
Enjoy powerful sound
Built-in 55Wx4 amplication delivers clear audio playback and plenty of volume.
Connect two smartphones with Dual Bluetooth®1
Pair your rst phone using Bluetooth® for full access to navigation, music playback and communication features. A second
phone can be connected simultaneously for making and receiving hands-free calls.1
Bring Siri on the road
Hook up your iOS device to control the music in it, navigation, messaging and more, using Siri Eyes Free.2
Voice control for Android
Use voice control to get directions, send messages, and play tracks on your Android smartphone.
Plug in with AOA 2.0 compatible USB ports4
AOA 2.0 compatible front USB port give you even more options for connecting various mobile devices.4
EXTRA BASS™ boosts the beat
Bring out the dynamics in your music, with enhanced low frequencies from EXTRA BASS™.
Take control with the Music Center app3
Available for both Android™ and compatible iOS devices. The Music Center™ app lets you use your smartphone or tablet
as a convenient system remote. It can even access, select, and playback the music les stored on your compatible
device. Got an Android phone? Use Music Center to manage music playback, read messages and control apps, by
voice.3
10-band digital equalizer customizes your sound
With 10 adjustable EQ sliders, you can easily ne-tune the sound to your personal tastes. The new karaoke mode lowers
vocal tracks for those times when you just can't help singing along.
USB input lets you play music from iPhone or iPod
With the handy USB input, you can easily play music from your iOS device. Just plug in with a USB cable (not supplied),
and you can control basic playback functions while seeing track information on the display. 7
Lights that move to the music
When music starts playing, multicolor LEDs light up your car interior, pulsing to the beat of the track if desired.
Play FLAC les
FLAC compatibility lets you play lossless audio les, so you can enjoy every detail of the music.
Read easily with high-contrast LCD
Features

Feature & Device / Amp & General Feature
Aux-In Yes (Front)
Balance Yes
EQ Yes (EQ10)
Fader Yes
High Pass Filter Yes(80/100/120)
Low Pass Filter Yes(80/100/120)
Output Power
(4ohm, 1kHz,16V) 55W
Pre Out x 2 (Rear + Sub)
Sirius/XM
Connector Yes
Sub Out Yes
Sub Woofer adjust
(LEVEL) Yes
Subwoofer Direct
Connection Yes (Easy)
Sub Woofer Phase Yes
USB Yes (Front)
Feature & Device / AUX in Feature
Level Adjustment -8dB / +18dB
Bluetooth Feature
# of records
connected 9 (HFP+Audio)
Built-in
microphone Yes
Call history (# of) Yes (20 numbers via PBAP)
Call history browse
with PBAP Yes (Combined call)
Call Volume Level
Control Yes
Connection Status
(maximum #) [2HFP+1Audio]
Echo/Noise
Canceler Yes (mode1/mode2)
Internal ringtone 2016 Sony Mobile Ringtone
Last dialed call Yes
MIC GAIN
Adjustment Yes (Low/Mid/Hi)
Phonebook
Access via PBAP Yes
RF ON/OFF Yes
Ring alert select Yes (Internal/Cellular)
Ring volume level
control Yes
Voice Control Yes
Bluetooth Audio Feature
Audio Codec SBC, AAC
Audio Level
Adjustment Yes (-6dB - +6dB)
CUE/REV Yes
Meta Data
Indication Yes
PAUSE Yes
TRACK +/- Yes
BT Spec.
Secure Simple
Pairing Yes
Version Version 3.0
Feature & Device / Display Panel
Auto o mode Yes
Dimmer Adjust Yes(On/O/Clock)
Sound and Color
Synchronization Yes
Feature & Device / Panel Design
Display color
(Color Variation/
Nega or Posi)
Black color/Negative
Display Device
(LCD/FL/OEL/TFT) LCD (with Acryl)
Key Illumination Blue
USB Shutter Yes
Other features
Ant connector JASO
Specications
With ve times the contrast of conventional screens, plus an optimized viewing angle, the screen is always easy to read.
Sirius XM Radio ready5
Connect your Sirius XM Radio satellite tuner (not supplied) to enjoy commercial-free music, sports, news, and
entertainment.5
2-Volt rear and sub RCA preamp outputs
When you’re ready to expand your system, the receiver delivers 2 volt RCA pre-amp outputs for external rear and
subwoofer ampliers. The adjustable subwoofer level control also lets you dial in the bass when you’re ready to pump it
up.
Switch volume and tracks from the wheel6
Easily set up basic audio controls from your steering wheel without a signal converter, on compatible vehicles.6
Steering wheel control ready input6
This receiver is compatible with aermarket remote control adapters designed to utilize the vehicles existing, primary radio
controls directly from the steering wheel. The 1/8” rear panel mounted remote input jack allows for simple connectivity.6

USB Mass Strage Device Control Feature
CODEC (for USB) MP3, WMA, FLAC
Jump Mode Yes
List Browsing
(Folders/Files) Yes
Pause Yes
Repeat ALL/TRACK/ALBUM
Resume Play Yes
Shue OFF/ALBUM/DEVICE
Specications chart / General
Maximum output
power (4ohm,
1kHz, 16V)(W)
55
Preout impedance
(ohms) 680
Preout output
level (V) 2
iPod Control Feature
CODEC (for iPod) Depend on iPod
Pause Yes
Repeat All / Track
Resume Play Yes
Shue O / Track
USB-capable
USB Android
Open Accessory
Protocol
Yes (2.0)
USB Mass Storage
Device Yes
Others / Instruction Manual Language
English Yes
French Yes
Bluetooth Feature & Device / Other features
Auto-paring for
iOS devices Yes
Device Name DSX-A415BT
Network Carrier
Information Yes
Pandora Link (BT) Yes
Siri Eyes Free Mode Yes
SongPal (Android) Yes (Music Center)
SongPal (iOS) Yes (Music Center)
Feature & Device / Other features
Card Remote ( ):
Option RM-X231
Clock 12H
Detachable Panel Detachable
Steering Wheel
Remote Input Ye s
Bluetooth Feature & Device / Prole
A2DP Version 1.3
AVRCP Version 1.6
HFP Version 1.3
PBAP Yes
SPP Yes
Others / Safety Standard
FCC Yes
Specications chart / Tuner
FM: Channel
separation (dB) 50
FM: Frequency
response (Hz) 20 - 15k
FM: S/N ratio
(mono) (dB) 73
FM: Selectivity (400
kHz) (dB) 75
FM: Tuning range
(MHz) 87.5-107.9
FM: Usable
sensitivity (75 ohm)
(dBf)
7
MW: Tuning
range(kHz) 530-1710
Feature & Device / Tuner Feature
Preset FM18/AM12
RDS / EON Yes (RBDS)
Others / Cosmetic Print
**Wx4 55
Bluetooth logo Yes
Cosmetic Sticker Sticker (iPod, USB AOA2), 5 months
IR Yes
Other logos NFC logo
Phone mark icon
(Green/Red) Yes on "CALL" Key
Product name Yes
Sirius/XM Ready
Logo Yes
USB jack logo
(Trident) Yes
**Wx4 55
Bluetooth logo Yes
Cosmetic Sticker Sticker (iPod, USB AOA2), 5 months
IR Yes
Other logos NFC logo
Phone mark icon
(Green/Red) Yes on "CALL" Key
Product name Yes
Sirius/XM Ready
Logo Yes
USB jack logo
(Trident) Yes
USB Mass Strage Device Control Feature
Maximum Current 1A
USB Feature & Device / USB Capability
USB Media Transfer
Protocol Yes
Weights and Measurements

1. Interoperability and compatibility among Bluetooth® devices may vary.
2. Siri is available on iPhone 4s or later, iPad Pro, iPad Air or later, iPad (3rd generation) or later, iPad mini or later and iPod touch (5th generation or later), and requires Internet access. Siri
may not be available in all languages or areas, and features may vary by area. Cellular data charges may apply.
3. Requires download of Sony Music Center app for iPhone from the App Store or for Android from Google Play. User must link compatible devices in order to control operation. Subject
to app terms and conditions.
4. Full functionality with compatible Android devices only.
5. Sirius XM Radio requires tuner and subscription, sold separately.
6. Compatibility varies as not all vehicles are compatible; please consult with each interface manufacturer for details.
7. Not all USB devices are compatible. Consult www.esupport.sony.com for complete details.
© 2017 Sony Electronics, Inc. All rights reserved. Reproduction in whole or in part without written permission is prohibited. Sony, EXTRA BASS and the Sony logos are trademarks of
Sony Corporation. iPhone is a trademark of Apple Inc. Android is a trademark of Google Inc. Bluetooth and the Bluetooth logo are trademarks of Bluetooth SIG, Inc. The N Mark
is a registered trademark of NFC Forum, Inc. All other trademarks are trademarks of their respective owners. Features and specications are subject to change without notice.
Updated: January 25, 2018
Dimensions
(Approx.)
178 x 50 x 119 mm
Mounting dimensions: 182 x 53 x 102 mm
Weight (Approx.) 0.7 kg
Accessories
Supplied
Accessories
Warranty card (NA)
Trim Ring (Collar), Black(Not Painted)
