ICD-

U60

Voice Plus All

-In-

One DVR Solution

NEW

Step

-

up

New

512MB

Built In Flash Memory

3

5

Up to 8 Hours of MP3 Playback

4

Up to 251 Hours

of Recording Time (LP Mode)

2

Built

-

in USB

1

5 Message Folders

HQ Recording Mode - 16kHz (19.2Kbps): Up to 57 Hours

Recording

Time

3

Function Toggle Button Makes the Unit Easy to Use

Digital VOR (Voice Operated Recording)

Easy-

to

-Read LCD Display

35mW Speaker Output

Includes; 1 "AAA" Battery, Neck Strap and Stereo Headphones

Digital Pitch Control

HQ/SP/LP Recording Modes

Sony Electronics Inc.

•

16530 Via Esprillo

•

San Diego, CA 92127

•

1-800-222-7669

•

www.sony.com

Last Updated: 10/08/2007

ICD-

U60

Voice Plus All

-In-

One DVR Solution

Please visit the Dealer Network for current information at

www.sony.com/dn

Features

512MB Flash Memory

uses a high capacity IC chip, which

may be recorded over and used again and again, with

distortion

-

free clarity.

3

5

MP3 Playback

provides easy playback of unsecured MP3 files

by dragging and dropping files into the MP3 folder on the

device

4

HQ/SP/LP Recording Modes Provide clearer recording of

meetings, interviews or dictation. HQ: 57hr 30min, SP: 153hr

25min, LP: 251hr 5min.

Built

-

In USB

allows the device to be plugged directly into a USB

port on a computer or hub, eliminating the need for cables

1

Digital VOR (Voice Operated Recording) Stops the recording

during silent pauses, saving valuable recording time, then

begins recording again without missing a single syllable

thanks to the digital buffer.

Digital Pitch Control allows recordings to be heard at slower

than normal speeds without distortion to facilitate transcribing

or editing, or faster than normal to move quickly to a desired

portion.

Slim Style Design main controls are easy to use

Specifications

General

Type of Use: All

-

In

-

One Ultra Portable DVR

Recording Media: Built

-

In Flash Memory 512MB

Recording and Playback Times: HQ: 57 Hr 30 Min.; SP: 153 Hr 25

Min.; LP: 251 Hr 5 Min.

Audio

Recording System: Monaural Recording

Microphone: Built

-

in

Format(s) Supported:

MP3 Playback

Audio Features

Microphone Sensitivity Feature: Yes (SENS Settings)

Recording Features: Digital Voice Operated Recording (VOR),

Overwrite, Move, Divide

Convenience

Erase/Protect: 2 Erase Options

Convenience Features

Safety Lock: Yes (Hold Function)

Search Features:

Cue and Review, Easy Search

Message Folder(s): Yes (5 Folders)

Clock:

Yes

Hardware

Display: Full function, high color 16 bit or more and 800x480 dots

or more

Power

Output Power: 35mW

Power Requirements: AAA Battery (1)

Battery Life (Approx.): Up to 16.5 Hours Recording, Up to 19

Hours

Playback in LP Mode.

Battery Type: "AAA" x 1

Speaker

Type: Built

-

in

2

4

Speaker Dimensions: 17/27" (10mm); Built

-

in

Software

Supplied Software: Player Tool/Player Plug

-

in for Windows

®

Media

Player (2

-

892

-

303

-

1)

Operating System Compatibility: Microsoft Windows

®

XP Media

Center Edition 2005/Windowos

®

CP Media Center Edition

2004/Windows

®

XP Media Center Edition/Windows

®

XP

Professional/Windows

®

XP Home Edition/Windows

®

2000

Professional/Windows

®

Millenium Edition/Windows

®

98 Second

Edition

Inputs and Outputs

Headphone Output(s): 1 (Mini)

USB Port(s): 1

Dimensions

Weight: 2.26 oz. (64 g) with battery

Measurements: 1.18" x 3.92" x 0.78 (30.0 x 99.7 x 20.0mm)

Supplied Accessories

1 "AAA" Battery

Neck Strap

Stereo Headphones

Player Tool/Player Plug

-

in for Windows

®

Media Player

Color:

White

UPC Code:

027242690875

1. Not all products with USB connectors may communicate with each other due to chipset variations.

2. Approximate recording times. Battery life will vary based upon usage conditions.

3. User available memory= 502,530,048 bytes, a portion of which is used for data management functions, with

default 5 folders setting. Total available space will be reduced as the number of folders increases.

4. Playback is based on MP3 at 128kbps. Calculated on 4 minutes per song.

5. Actual user available memory is approximate. A portion is used for data management.

©2006 Sony Electronics Inc.

Reproduction in whole or in part without written permission is prohibited. All rights reserved. Sony, Voice Up,

and like.no.other are trademarks of Sony. Dragon, NaturallySpeaking, and the Dragon logo are registered

trademarks or trademarks of Nuance Communications, Inc. or its affiliates in the United States and/or other

countries. Microsoft and Windows are trademarks or registered trademarks of Microsoft Corporation in the

United States and/or other countries.

Features and specifications are subject to change without notice. Non

-

metric weights and measures are

approximate.
