Printed in Japan©October 2017 Sony Corp.

Main specifications of Interchangeable-lens

digital camera

Specifications and features are subject to change without notice.

*1 Phase-detection AF may not work with certain lenses or may require software update. See Sony support page for details. *2 With compatible Sony external flash. *3 With compatible external flash. *4 Varies according to shooting conditions or memory card used. *5 Images shot in Pixel Shit Multi Shooting mode

can be processed using a dedicated imaging software by Sony. Maximum flash-sync speed is limited to 1/13 second. *6 Supports Micro USB compatible device. *7 (Configuration method/Access method) WPS or manually /infrastructure mode. When connecting to smartphones, the camera can always work as a base

without a wireless access point. (Security: WEP/WPA-PSK/WPA2-PSK) *8 Sony accessories for the Accessory Shoe can be attached. *9 The LCD screen is turned on, shot once every 30 seconds, operate zoom alternately between W and T ends, flash strobe once every two times, turn power off and on once every ten

times. *10 Continuous movie recording is possible for approximately 29 minutes (limited by product specifications). *11 Indication recording time, which is defined by repeating the cycle: Power on, start recording, zoom , stand-by and power off. *12 The total movie recording time. When the limit of the continuous

movie recording time (29 minutes) is reached, let the camera continue movie recording by pressing the MOVIE button again. No other operation such as zoom is performed.

Trademarks & Remarks

• " ", "Exmor", "Exmor R", "BIONZ X", "BRAVIA", "SteadyShot", "InfoLithium", "Translucent Mirror Technology", "Tru-Finder", "Memory Stick", "Memory Stick PRO Duo", "Memory Stick PRO-HG Duo", "PlayMemories Home", "PlayMemories Mobile", "PlayMemories Camera Apps", "x.v.Color", "TRILUMINOS", "TRILUMINOS

Color", "TRILUMINOS Display" and "XAVC S" are trademarks or registered trademarks of Sony Corporation. • "Xperia" is a trademark or registered trademark of Sony Mobile Communications AB. • "AVCHD" and "AVCHD Progressive" are trademarks of Panasonic Corporation and Sony Corporation. • The SD Logo, SDHC

Logo and SDXC Logo are trademarks of SD-3C, LLC. • The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries. • The Wi-Fi Protected Setup Identifier Mark is a mark of the Wi-Fi Alliance.

• N-Mark is a registered trademark of the NFC Forum. • Dolby is a trademark of Dolby Laboratories. • WhiteMagic is a trademark of Japan Display Inc. • App Store is a service mark of Apple Inc. • Android, Google Play and Google Play logo are trademarks or registered trademarks of Google Inc. • iPad is a trademark

of Apple Inc., registered in the U.S. and other countries. • All other company and product names mentioned herein are used for identification purposes only and may be the trademarks or registered trademarks of their respective owners. • "InfoLithium" is a lithium battery pack which can exchange data with

compatible electronic equipment about its energy consumption. • Sony recommends that you use the battery pack with electronic equipment bearing the "InfoLithium" mark. • Screen displays and effects used to illustrate some functions are simulated. • For use of other companies’ services and software, 1) other

conditions for use may be applied. 2) updating of services and software may be stopped/terminated without prior notice. 3) the contents of services and software may be changed without prior notice. 4) other registrations or payments of other fees may be required.

General Camera Type Interchangeable-lens digital camera

Lens mount E-mount

Image sensor Type 35mm full frame (35.9×24.0mm), Exmor R CMOS sensor

Number of Pixels Approx. 42.4 megapixels (effective), Approx. 43.6 (Total)

Image sensor Aspect Ratio 3:2

Anti-Dust System Charge protection coating on optical filter and image sensor shift mechanism

Recording System

(still image)

Recording Format JPEG (DCF Ver. 2.0, Exif Ver.2.31, MPF Baseline compliant), RAW (Sony ARW 2.3 format)

Image Size (pixels) [3:2] [35mm full frame] L: 7952 x 5304 (42M), M: 5168 x 3448 (18M), S: 3984 x 2656 (11M)

[APS-C] L: 5168 x 3448 (18M), M: 3984 x 2656 (11M), S: 2592 x 1728 (4.5M)

Image Size (pixels) [16:9] [35mm full frame] L: 7952 x 4472 (36M), M: 5168 x 2912 (15M), S: 3984 x 2240 (8.9M)

[APS-C] L: 5168 x 2912 (15M), M: 3984 x 2240 (8.9M), S: 2592 x 1456 (3.8M)

Image Quality modes RAW, RAW & JPEG (Extra fine, Fine, Standard), JPEG (Extra fine, Fine, Standard)

Picture Effect 8 types: Posterization (Color), Posterization (B/W), Pop Color, Retro Photo, Partial Color (R/

G/B/Y), High Contrast Monochrome, Toy Camera(Normal/Cool/Warm/Green/Magenta),

Soft High-key, Rich-tone Monochrome

Creative Style Standard, Vivid, Neutral, Clear, Deep, Light, Portrait, Landscape, Sunset, Night Scene, Autumn

leaves, Black & White, Sepia, Style Box (1-6), (Contrast (-3 to +3 steps), Saturation (-3 to +3

steps), Sharpness (-3 to +3 steps))

Picture Profile Yes (Off / PP1-PP10) Parameters: Black level, Gamma (Movie, Still, Cine1-4, ITU709, ITU709

[800%], S-Log2, S-Log3, HLG, HLG1-3), Black Gamma, Knee, Color Mode, Saturation, Color

Phase, Color Depth, Detail, Copy, Reset

Dynamic Range Functions Off, Dynamic Range Optimizer (Auto/Level (1-5)), Auto High Dynamic Range (Auto Exposure

Difference, Exposure Difference Level (1-6 EV, 1.0 EV step))

Color Space

sRGB standard (with sYCC gamut) and Adobe RGB standard compatible with TRILUMINOS Color

14bit RAW Yes

Uncompressed RAW Yes

Recording System

(movie)

Recording Format XAVC S, AVCHD format Ver. 2.0 compliant

Video Compression XAVC S: MPEG-4 AVC/H.264, AVCHD: MPEG-4 AVC/H.264

Audio Recording Format XAVC S: LPCM 2ch, AVCHD: Dolby Digital (AC-3) 2ch, Dolby Digital Stereo Creator

Color Space xvYCC standard (x.v.Color when connected via HDMI cable) compatible with TRILUMINOS

Color

Picture Effect

Posterization (Color), Posterization (B/W), Pop Color, Retro Photo, Partial Color (R/G/B/Y), High

Contrast Monochrome, Toy Camera(Normal/Cool/Warm/Green/Magenta), Soft High-key

Creative Style Standard, Vivid, Neutral, Clear, Deep, Light, Portrait, Landscape, Sunset, Night Scene, Autumn

leaves, Black & White, Sepia,Style Box(1-6) (Contrast (-3 to +3 steps), Saturation (-3 to +3

steps), Sharpness (-3 to +3 steps))

Picture Profile Yes (Off / PP1-PP10) Parameters: Black level, Gamma (Movie, Still, Cine1-4, ITU709, ITU709

[800%], S-Log2, S-Log3, HLG, HLG1-3), Black Gamma, Knee, Color Mode, Saturation, Color

Phase, Color Depth, Detail, Copy, Reset

Image Size (Pixels), NTSC XAVC S 4K: 3840 x 2160 (30p, 100M), 3840 x 2160 (24p, 100M), 3840 x 2160 (30p, 60M), 3840

x 2160 (24p, 60M)

XAVC S HD: 1920 x 1080 (120p, 100M), 1920 x 1080 (120p, 60M), 1920 x 1080 (60p, 50M), 1920

x 1080 (30p, 50M), 1920 x 1080 (24p, 50M), 1920 x 1080 (60p, 25M), 1920 x 1080 (30p, 16M)

AVCHD: 1920 x 1080 (60i, 24M, FX), 1920 x 1080(60i, 17M, FH)

Image Size (pixels), PAL XAVC S 4K: 3840 x 2160 (25p, 100M), 3840 x 2160 (25p, 60M)

XAVC S HD: 1920 x 1080 (100p, 100M), 1920 x 1080 (100p, 60M), 1920 x 1080 (50p, 50M), 1920

x 1080 (25p, 50M), 1920 x 1080 (50p, 25M), 1920 x 1080 (25p, 16M)

AVCHD: 1920 x 1080 (50i, 24M, FX), 1920 x 1080 (50i, 17M, FH)

Slow & Quick Motion (S&Q) /

Image size

NTSC mode: 1920x1080 (60p, 30p, 24p)

PAL mode: 1920x1080 (50p, 25p)

Slow & Quick Motion (S&Q) /

Image frame rate

NTSC mode: 1fps, 2fps, 4fps, 8fps, 15fps, 30fps, 60fps, 120fps

PAL mode: 1fps, 2fps, 3fps, 6fps, 12fps, 25fps ,50fps,100fps

Movie Functions Audio Level Display, Audio Rec Level, PAL/NTSC Selector, Proxy Recording (1280 x 720,

9Mbps), TC/UB (TC Preset/UB Preset/TC Format/TC Run/TC Make/UB Time Rec), Auto Slow

Shutter, REC Control, Clean HDMI Info.(ON/OFF selectable), Gamma Disp. Assist

HDMI Output 3840 x 2160 (25p), 1920 x 1080 (50p), 1920 x 1080 (50i), 1920 x 1080 (24p), 1920 x 1080 (60p),

1920 x 1080 (60i), 3840 x 2160 (30p), 3840 x 2160 (24p), YCbCr 4:2:2 8bit / RGB 8bit

Recording System Location Information Link From

Smartphone

Yes

Media Memory Stick PRO Duo, Memory Stick PRO-HG Duo, Memory Stick Micro (M2), SD memory

card, SDHC memory card (UHS-I/II compliant), SDXC memory card (UHS-I/II compliant),

microSD memory card, microSDHC memory card, microSDXC memory card

Memory Card Slot SLOT1: Slot for SD (UHS-I/II compliant) memory card

SLOT2: Multi slot for Memory Stick Duo/SD (UHS-I compliant) memory card

Recording mode on 2 memory

cards

Simult. Rec (Still), Simult. Rec (Movie), Simult. Rec (Still/Movie), Sort (JPEG/RAW), Sort (Still/

Movie), Auto Switch Media (On/Off), Copy

Noise reduction Noise Reduction Long exposure NR: On/Off, available at shutter speeds longer than 1 sec.

High ISO NR: Normal/Low/Off

Multi Frame NR -

White Balance Modes Auto / Daylight / Shade / Cloudy / Incandescent / Fluorescent <;Warm White / Cool White

/ Day White / Daylight> / Flash /Underwater/ Color Temperature <2500 to 9900K> & color

filter <G7 to M7(57-step), A7 to B7(29-step)> / Custom

AWB Micro Adjustment Yes <G7 to M7,57-step><A7 to B7,29-step>

Priority Set in AWB Yes

Bracketing 3 frames, H/L selectable

Focus Focus Type*1 Fast Hybrid AF (phase-detection AF/contrast-detection AF)

Focus Sensor Exmor R CMOS sensor

Focus Point 35mm full frame: 399 points (phase-detection AF), APS-C mode with FE lens: 323 points

(phase-detection AF), with APS-C lens: 255 points (phase-detection AF) / 425 points

(contrast-detection AF)

Focus Sensitivity Range EV-3 to EV20 (ISO100 equivalent with F2.0 lens attached)

Focus Mode AF-A (Automatic AF), AF-S (Single-shot AF), AF-C (Continuous AF), DMF (Direct Manual Focus),

Manual Focus

Focus Area Wide (399 points (phase-detection AF), 425 points(contrast-detection AF)) / Zone / Center

/ Flexible Spot (S/M/L) /Expanded Flexible Spot/ Lock-on AF ( Wide / Zone / Center /

Flexible Spot (S/M/L)/Expanded Flexible Spot)

Other Features Eye-start AF (only with separately sold LA-EA2 or LA-EA4 attached), Lock-on AF, Eye AF, AF

micro adjustment (only with separately sold LA-EA2 or LA-EA4 attached), Predictive control,

Focus lock, AF Track Sensitivity, Swt.V/H AF Area, AF Area Registration

AF Illuminator Yes (with Built-in LED type)

AF Illuminator Range Approx. 0.3m - approx. 3.0m (with FE 28-70mm F3.5-5.6 OSS attached)

Focus Type With LA-EA3

(Sold separately)

Selectable (phase-detection, contrast-detection)

Exposure Metering Type 1200-zone evaluative metering

Metering Sensor Exmor R CMOS sensor

Metering Sensitivity EV-3 to EV20 (at ISO100 equivalent with F2.0 lens attached)

Metering Mode Multi-segment, Center-weighted, Spot, Spot Standard/Large, Entire Screen Avg., Highlight

Exposure Compensation +/- 5.0EV(1/3 EV, 1/2 EV steps selectable) (with exposure compensation dial : +/- 3EV (1/3

EV steps))

Exposure Bracketing Bracket: Cont., Bracket: Single, 3/5/9 frames selectable. With 3 or 5 frames, in 1/3, 1/2, 2/3,

1.0, 2.0, or 3.0 EV increments, with 9 frames, in 1/3, 1/2, 2/3, or 1.0 EV increments.

AE Lock

Locked when shutter button is pressed halfway. Available with AE lock button. (On/Off/Auto)

Exposure Modes AUTO (iAuto), Programmed AE (P), Aperture priority (A), Shutter-speed priority (S), Manual

(M), Movie (Programmed AE (P) / Aperture priority (A) / Shutter-speed priority (S) / Manual

(M) ), Slow & Quick Motion (Programmed AE (P) / Aperture priority (A) / Shutter-speed

priority (S) / Manual (M) )

ISO sensitivity

(Recommended Exposure

Index)

Still images: ISO 100-32000 (ISO numbers up from ISO 50 to ISO 102400 can be set as

expanded ISO range.),

AUTO (ISO 100-12800, selectable lower limit and upper limit)

Movies: ISO 100-32000 equivalent, AUTO (ISO 100-12800, selectable lower limit and upper limit)

Anti-flicker Shoot. Yes

Viewfinder Viewfinder Type 1.3 cm (0.5-type) electronic viewfinder (color), Quad-VGA OLED Tru-Finder

Number of Dots 3,686,400 dots

Brightness Control (Viewfinder) Auto/Manual (5 steps between -2 and +2)

Color Temperature Control Manual (5 steps)

Viewfinder (Cont.) Field Coverage 100%

Magnification Aapprox. 0.78 x (with 50mm lens at infinity, -1m-1)

Dioptre Adjustment -4.0 to +3.0m-1

Eye Point Approx. 23mm from the eyepiece lens, 18.5mm from the eyepiece frame at -1m-1 (CIPA

standard)

Finder Frame Rate Selection NTSC mode: STD 60fps / HI 120fps

PAL mode: STD 50fps / HI 100fps

Display Content Graphic Display, Display All Info., No Disp. Info., Digital Level Gauge, Histogram

LCD Screen Type 7.5cm (3.0-type) type TFT

Number of Dots 1,440,000 dots

Touch Panel Yes

Brightness Control Manual (5 steps between -2 and +2), Sunny Weather mode

Adjustable Angle Up by approx. 107 degrees, Down by approx. 41 degrees

Display Selecter (Finder/LCD) Yes (Auto/Manual)

Real-time Image Adjustment

Display (LCD)

On/Off

Quick Navi Yes

Focus Magnifier Yes (35mm full frame: 6.2x, 12.4x APS-C: 4.0x, 8.0x)

Zebra Yes (Selectable level + range or lower limit as custom setting)

Peaking MF Yes (Level setting: High/Mid/Low/Off, Color: White/Red/Yellow)

Others WhiteMagic™, Grid Line (Rule of 3rds Grid/Square Grid/Diag. + Square Grid/Off), Movie

Marker (Center/Aspect/Safety Zone/Guideframe)

Display Contents

Graphic Display, Display All Info, No Disp. Info, Digital Level Gauge, Histgram, For viewfinder, Monitor Off

Other Features PlayMemories Camera Apps™ -

Clear Image Zoom Still images:Approx. 2x

Movies:Approx. 1.5x (4K), Approx. 2x (HD)

Digital Zoom Smart zoom (Still images) [35mm full frame] M: approx 1.5x, S: approx 2x [APS-C] M: approx

1.3x, S: approx 2x

Digital zoom (Still images) [35mm full frame] L: approx 4x, M: approx 6.2x, S: approx 8x

[APS-C] L: approx 4x, M: approx 5.2x, S: approx 8x

Digital zoom (Movie) [35mm full frame] approx 4x [APS-C] approx 4x

Face Detection [Modes] Face Priority inAF (On/Off), Face Priority in Multi Metering (On/Off), Regist. Faces

Priority (On/Off)

[Face registration] Max. number of detectable: 8

Others Touch Focus (Available with LCD monitor or Viewfinder operation), ISO AUTO Min. SS, Bright

Monitoring, Copyright Info, Set File Name, FTP Transfer Func., Help guide, Area Setting, Shop

Front Mode, Video Light Mode, Zoom Ring Rotate

Eye-Fi ready -

Shutter Type Electronically-controlled, vertical-traverse, focal-plane type

Shutter Speed [Still images] 1/8000 to 30 sec, Bulb, [Movies] 1/8000 to 1/4 (1/3 steps) up to 1/60 in AUTO

mode (up to 1/30 in Auto slow shutter mode);

Flash Sync. Speed *2 1/250 sec.

Electronic Front Curtain Shutter Yes (ON/OFF)

Silent Shooting Yes (ON/OFF)

Image Stabilization Type Image Sensor-Shift mechanism with 5-axis compensation (Compensation depends on lens

specifications)

Compensation Effect 5.5 stops (based on CIPA standard. Pitch/yaw shake only. With Planar T* FE 50mm F1.4 ZA

lens mounted. Long exposure NR off.)

Flash Control Control Pre-flash TTL

Flash Compensation +/- 3.0 EV (switchable between 1/3 and 1/2 EV steps)

Flash Bracketing 3/5/9 frames selectable. With 3 or 5 frames, in 1/3, 1/2, 2/3, 1.0, 2.0, 3.0 EV increments, with

9 frames, in 1/3, 1/2, 2/3, 1.0 EV increments.

Flash Modes Flash off, Autoflash, Fill-flash, Slow Sync., Rear Sync., Red-eye reduction (on/off selectable),

Wireless*3, Hi-speed sync.*3

External Flash Compatibility Sony α System Flash compatible with Multi Interface Shoe, attach the shoe adaptor for flash

compatible with Auto-lock accessory shoe

FE Level Lock Yes

Wireless Control Yes (Light signal: Available with Fill-flash, Slow Sync., Hi-speed sync. /Radio signal: Available

with Fill-flash, Rear Sync., Slow Sync., Hi-speed sync.)

Drive Drive Modes Single Shooting, Continuous shooting (Hi+/Hi/Mid/Lo selectable), Self-timer, Self-timer

(Cont.), Bracket: Single, Bracket: Cont., White Balance bracket, DRO bracket

Continuous Drive Speed

(approx. max.) *4

Continuous shooting: Hi+: max. 10 fps, Hi: max. 8 fps, Mid: max. 6fps, Lo: max. 3 fps

No. of Recordable Frames

(approx.) *4

JPEG Extra fine L: 76 frames, JPEG Fine L: 76 frames, JPEG Standard L: 76 frames, RAW: 76

frames, RAW&JPG: 76 frames, RAW (Uncompressed): 28 frames, RAW (Uncompressed)&JPG:

28 frames

Self-Timer 10 sec. delay/5 sec. delay/2 sec. delay/Continuous self-timer (3 frames after 10 sec. delay/5

frames after 10 sec. delay/3 frames after 5 sec. delay/5 frames after 5 sec. delay/3 frames

after 2 sec. delay/5 frames after 2 sec. delay)/Bracketing self-timer

Pixel Shift Multi Shooting Yes*5

Playback Photo Capture Yes

Modes Single (with or without shooting information Y RGB histogram & highlight/shadow

warning), 9/25-frame index view, Enlarged display mode (L: 19.9x, M: 12.9x, S: 10.0x), Auto

Review (10/5/2 sec,Off), Image orientation (Auto/Manual/Off selectable), Slideshow, Folder

selection (Date/ Still/ AVCHD/XAVC S HD/XAVC S 4K), Forward/Rewind (movie), Delete,

Protect, Rating, Disp Cont Shoot Grp

Interface PC Interface Mass-storage, MTP, PC remote

Multi / Micro USB Terminal *6 Yes

USB Type-C™ Terminal Yes (SuperSpeed USB (USB 3.1 Gen 1) compatible)

NFC™ Yes (NFC forum Type 3 Tag compatible), One-touch remote, One-touch sharing

Wireless LAN (Built-In) Wi-Fi Compatible, IEEE 802.11b/g/n (2.4GHz band), View on Smartphone, Send to Computer,

View on TV*7

Bluetooth Yes (Bluetooth Standard Ver. 4.1 (2.4GHz band))

HD Output HDMI micro connector (Type-D), BRAVIA Sync(Control for HDMI), PhotoTV HD, 4K movie

output/4K still image PB

Multi Interface Shoe *8 Yes

Mic Terminal Yes (3.5 mm Stereo minijack)

Sync Terminal Yes

Headphone Terminal Yes (3.5 mm Stereo minijack)

Vertical Grip Connector Yes

PC Remote Yes

LAN Terminal -

Audio Microphone Built-in stereo microphone or XLR-K2M/XLR-K1M/ECM-XYST1M (sold separately)

Speaker Built-in, monaural

Print Compatible Standards Exif Print, Print Image Matching III, DPOF setting

Custom function Type Custom key settings, Programmable Setting (Body 3 sets /memory card 4 sets), My Menu,

Reg Cust Shoot Set

Lens Compensation Setting Peripheral Shading, Chromatic Aberration, Distortion

Power Supplied Battery One rechargeable battery pack NP-FZ100

Battery Life

(Still Images)

*9 Approx. 530 shots (Viewfinder) / approx. 650 shots (LCD monitor) (CIPA standard)

Battery Life

(Movie, actual recording)

*10 *11 Approx. 100 min (Viewfinder) / Approx. 115 min (LCD monitor) (CIPA standard)

Battery Life

(Movie, continuous recording)

*10 *12 Approx. 180 min (Viewfinder) / Approx. 190 min (LCD monitor) (CIPA standard)

Internal Battery Charge Yes (Available via Multi/Micro USB Terminal or USB Type-C™ Terminal)

Power Consumption With

Viewfinder

Still images: approx. 3.7W (with FE 28-70mm F3.5-5.6 OSS lens attached),

Movies: approx. 5.5W (with FE 28-70mm F3.5-5.6 OSS lens attached)

Power Consumption With LCD

Screen

Still images: approx. 3.0W(with FE 28-70mm F3.5-5.6 OSS lens attached),

Movies: approx. 5.2W (with FE 28-70mm F3.5-5.6 OSS lens attached)

USB Power Supply Yes (Available via Multi/Micro USB Terminal or USB Type-C™ Terminal)

Others Operating Temperature 32 - 104 degrees F / 0 - 40 degrees C

Size & Weight Dimensions (W x H x D) Approx. 126.9mm x 95.6mm x 73.7mm, Approx. 126.9mm x 95.6mm x 62.7mm (from grip to

monitor) /Approx. 5 x 3 7/8 x 3 inches, Approx. 5 x 3 7/8 x 2 1/2 inches (from grip to monitor)

Weight Approx. 657 g / approx. 1lb 7.2 oz (with battery and memory card included)

What's In The Box Power cord, Rechargeable Battery NP-FZ100, Cable Protector, Battery Charger BC-QZ1,

Shoulder strap, Body cap, Accessory shoe cap, Eyepiece cup, USB Type-C™ cable

No.1 image sensor manufac-

turer for digital cameras and

video recorders. Based on

Sony research – April 2016 to

March 2017

(over 50% market share).

NEW in this guide marks an advancement over the 7R II .

Reality realized. New worlds.

The art of bringing the world to life in photographic form hinges on a sublime blend of technical

capability and creative vision. With a new system that achieves outstanding resolution, sensitivity,

dynamic range, and speed, the 7R III provides the technical capability you need to let your

imagination soar and fulfill your vision with breathtaking reality. All of this comes in a compact,

mobile package that is easy and intuitive to use while seamlessly supporting professional workflows.

The 7R III offers the potential you need to realize concepts and explore worlds that have previously been beyond reach.

* Connect to an HDR (HLG) compatible Sony TV via a USB cable when displaying HDR (HLG) movies.

** Up to 10 fps in continuous “Hi+” mode, and up to 8 fps in continuous “Hi” mode. Maximum fps will depend on camera settings.

FE 85mm F1.4 GM (SEL85F14GM), 1/250sec., F8, ISO 100

FE 24-70mm F2.8 GM (SEL2470GM), 1/640sec., F8, ISO 200

FE 100-400mm F4.5-5.6 GM OSS (SEL100400GM), 1/4000 sec., F5.6, ISO 400

FE 12-24mm F4 G (SEL1224G), 2 sec., F8, ISO 100, Pixel Shift Multi Shooting mode, composited using dedicated software

Planar T* FE 50mm F1.4 ZA (SEL50F14Z), 1/250 sec., F1.4, ISO 100

1514

16-bit image processing

JPEG

RAW

Image Sensor Newly developed

high-speed front-end LSI

14bits 14bits

8bits

3.69 million dot Quad-VGA OLED Tru-Finder™42.4* effective megapixel full-frame Exmor R™ CMOS sensor

Faster, more detailed image processing

Standard 100 ~ 32000 ISO expandable up to 102400*

Lightweight, durable magnesium body

Versatile viewingSpectacular Rendering

Compact, lightweight, and durable

16-bit processing and

14-bit RAW output

High quality mode

Increased mount and grip rigidity

AF in Focus Magnifier

Durable low-vibration shutter

Improved peaking

Dust and moisture resistant*

The standard ISO range has been ex-

tended to ISO 100 ~ 32000, expand-

able* to ISO 50 at the low end and ISO

This high-resolution Quad-VGA OLED

Tru-Finder has approximately 3.69

million dots for fine detail and high

contrast for accurate black reproduc-

tion. High luminance brings view-

finder brightness closer to that of the

actual scene. The high quality of the

viewfinder image and features like

focus magnification make it easier to

achieve perfect focus with just about

any subject in any situation.

Back illumination for high sensitiv-

ity, gapless on-chip lenses, anti-

reflective seal glass coating, no

optical low-pass filter, and other

advanced features contribute to un-

The latest high-speed front-end

LSI and updated BIONZ X™ image-

processing engine provide a dramatic

increase in system speed, plus an

impressive 15-stop dynamic range*

at low-sensitivity settings. Advances

have also been made in Sony’s Detail

Reproduction Technology and Area-

specific Noise Reduction features,

precedented imaging performance.

High resolution, high sensitivity with

low noise, and wide dynamic range

add up to vastly expanded shooting

potential.

reducing noise by as much as a full

stop** in the mid sensitivity range.

A sublime blend of high resolution

and low noise is ensured over a wide

sensitivity range, for outstanding

image quality and color accuracy that

are ideal for portraits and landscape

photography.

To ensure maximum reliability in

harsh conditions, body durability

has been enhanced by the use of a

102400 at the high end for wide cover-

age that can capture low-light scenes

with high quality and low noise.

lightweight, high-rigidity magne-

sium alloy for the top cover, front

cover, internal frame, and rear cover.

The digital output from the image

sensor’s AD converter is processed

in 16-bit form by the front-end LSI

and BIONZ X processor before being

output as compressed or uncom-

pressed 14-bit RAW files. The result

is smoother, more natural gradations

that contribute to higher overall im-

age quality. The enhanced image

processing system makes 14-bit RAW

output available even when shooting

in silent or continuous mode.*

“Standard” and “High” quality settings

are available for the viewfinder and

monitor. “High” takes advantage of the

large amount of data read from the

42.4 effective megapixel sensor to pro-

vide extra fine viewfinder and monitor

displays for a more natural view.

Increased lens mount rigidity maxi-

mizes durability when using heavy

optics, and the grip has been rede-

signed and unified with the front

cover using magnesium alloy for

higher overall rigidity.

A new shutter unit features a fast-

response coreless motor and brake

system that effectively subdues me-

chanical vibration. The shutter has

been tested for durability in excess

of 500,000 shutter cycles.*

Sealing is provided at critical loca-

tions to minimize dust and moisture

ingress, ensuring reliable operation

in challenging environments.

By magnifying the selected focus

area while using autofocus to shoot

stills this function makes it easier to

achieve perfect focus, especially for

macro photography and other criti-

cal applications.

The evolved BIONZ X processing

engine improves the accuracy of

“peaking” display that highlights

in-focus areas when focusing manu-

ally, making it easier to achieve

precise focus.

Conventional XGA Finder

* Expanded ISO available

for still images only.

* Limited to 12 bits during compressed RAW continuous

shooting, BULB exposure, or when Long Exposure NR

is ON.

* Sony internal tests with electronic front curtain shutter.

* Not guaranteed to be 100% dust and moisture proof.

NEW

NEWNEW

NEW NEW

NEW

A portal to unseen worlds

Technology both frees and confines art. As it evolves restraints

diminish and art comes to the fore. The 7R III makes

an evolutionary leap, freeing the user to explore previously

unseen worlds of detail, color, dimension, and time.

* Approximately.

* Sony test conditions for stills ** Compared to the 7R II .

NEW

Quad-VGA Finder (High quality mode)

FE 24-70mm

F2.8 GM (SEL2470GM),

1/320sec., F11, ISO 3200

1716

10 fps continuos shooting captures the decisive moment

Fast:

Up to 2x* AF speed

Steadfast: Subject tracking performance

approximately doubled

Reliable AF down to

EV-3 brightness

Focal plane phase-detection AF

with A-mount lenses*

Advanced AF algorithms contribute

to high AF precision down to light

levels as low as EV-3 (ISO 100 equiv-

alent, F2.0 lens) in the AF-S mode.

AF is more precise and reliable in

dark scenes.

Focal plane phase-detection AF also

functions with A-mount lenses* mount-

ed via the LA-EA3 adaptor, providing

wide-area coverage, fast response, and

high tracking performance. Eye AF is

now supported with A-mount lenses*.

Enhanced Fast Hybrid AF System

performance achieves low-light AF

response that is up to twice as fast*

as the 7R II. Focus is fast and reli-

able even in dim lighting.

Tracking performance during continu-

ous shooting has been improved by

approximately 2x.* Complex, unpre-

dictable motion is reliably tracked with

greater precision than ever before.

399 focal plane phase-detection AF

points cover approximately 68% of

the image area in the horizontal and

vertical directions, complementing

425 contrast AF points for consis-

tently reliable focus.

Updated algorithms enhance AF response

Unprecedented AF performance

Evolved image processing plus AF algorithms from the 9

refined and optimized for the 7R III provide significant im-

provements in AF speed, precision, and tracking performance.

Even the wildest motion can be tracked reliably.

Speed and precision capture perfect moments

Breakthroughs in continuous shooting and autofocus performance

make it easier than ever to capture those elusive natural moments

that define the photographer’s art. Enhanced operability and

reliability further ensure that not a moment is lost.

High-speed continuous shooting

10fps

42.4

megapixels

Silent continuous shooting**

Up to 10 fps* continuous shooting with AF/AE tracking

Silent, vibration-free shooting at up

to 10 fps** with AF/AE tracking and no

cropping is also available when shoot-

ing in silent mode. Silent shooting

is critical for wildlife photography

where even the slightest shutter

noise can mean missing the mo-

ment.

Continuous shooting at up to 10 fps*

with accurate AF/AE tracking makes it

possible to capture moving subjects

in their most photogenic moments

while taking full advantage of the

camera’s 42.4 megapixel resolution

and 14-bit output. The image files

produced contain ample data for

flexible trimming and retouching

without losing image quality. It is

also possible to shoot continuously

at up to 8 fps* in live view mode,

with minimal viewfinder/monitor

display lag.

42.4 megapixel resolution provides plenty of margin

for cropping.

* Up to 10 fps in continuous “Hi+” mode, and up to 8 fps in continuous “Hi” mode. Maximum fps will depend on camera settings.

** Some distortion may occur with fast-moving subjects or if the camera is moved sideways rapidly while shooting.

* Compared to the 7R II. Sony test conditions.

* With SSM or SAM lenses only. With the LA-EA3 mount adapter. Focal plane phase-detection AF not supported for

movie recording. AF-C can only be used when the “Phase detection” AF system is selected, but focus is fixed at the

first frame during continuous shooting in any mode other than “Continuous: Lo” (Hi+, Hi, Mid).

NEW

NEWNEWNEW

NEWNEW

NEW

Wide: 399 phase-detection +

425 contrast AF points

1918

More continuous shooting support

Professional staminaCustomizable Functions for Smooth Focus Operation

Up to 76* images per burst Dual media slots, UHS-II support

A larger buffer memory, increased

overall system speed, UHS-II sup-

port, and other refinements allow

up to 76* JPEG or compressed RAW

images, or up to 28* uncompressed

RAW images to be captured in one

continuous burst.

The Fn menu can be accessed and

edited immediately after continuous

shooting while data writing is in prog-

ress*, as can the menus and parame-

ters. It is also possible to immediately

access the playback display, with the

number of still images remaining to

be written shown during playback.

A new NP-FZ100 battery provides

approximately 2.2 times the capac-

ity of the NP-FW50. The optional

VG-C3EM Vertical Grip holds two

batteries, or an optional Multi Bat-

tery Adaptor (NPA-MQZ1K) can hold

up to four Z batteries for even fur-

ther extended recording time.

Ratings of from 1 to 5 stars can be

applied to still images right from

the camera controls. The rating and

protect functions can be set via as-

signed custom buttons while view-

ing the review playback display on

location or while traveling to save

time.

Images shot in continuous mode

can be reviewed as groups, and the

play index display has been signifi-

cantly improved. Continuous groups

can be deleted or protected in one

quick operation to save time on

location.

Separate media slots for SD card

(UHS-II compatible) and SD/MS card

allow data to be simultaneously or se-

quentially recorded to two cards (Auto

Switch Media), or separate cards can

be assigned to save RAW and JPEG

files, or stills and movies. Data can

also be copied between media cards.

USB Type-C™ and Multi/Micro USB

connectors allow external mobile bat-

teries to power the camera for extend-

ed recording time. The Multi/Micro USB

connector can be used with a remote

control unit or other accessory while

the USB Type-C™ connector is used

for power supply or PC tethering.

Display continuous shooting

group

Rating and protect functions

facilitate on-location sorting

Improved operability while

writing to memory card

3.0 type 1.44 million dot

tilting LCD monitor

Battery capacity increased by

approximately 2.2 times

USB power

Efficient focus control

AF tracking sensitivity

AF-ON button

Multi-selector

Switch Vertical and Horizontal AF Area

Touch focus Touchpad focus point control

AF Area Registration Recall Custom Setting During Hold

The sensitivity with which autofocus

will follow subjects that move outside

the focus area can be adjusted in 5

steps when shooting stills. Higher

sensitivity is best for subjects at vary-

ing distances, while lower sensitivi-

ties can keep focus on a subject that

is briefly obscured by other objects.

Press the AF-ON button to activate

autofocus when shooting stills or mov-

ies. This makes it possible to release

the shutter instantly to capture fleeting

moments without having to go through

the normal half-press focus sequence.

The multi-selector provides a fast,

efficient way to shift focus points.

Simply press the up, down, left, or

right button when using the Zone,

Flexible Spot, or Expand Flexible

Spot focus area mode.

Simply touch the monitor screen to

specify the desired focus point for

stills or movies. Even subjects near

the frame edges can be instantly

selected without having to reframe

or manually shift the focus point.

Double-tap any point for a magni-

fied view of that area when focusing

manually.

The monitor touchpad function al-

lows the focus frame to be dragged

to any desired point with a fingertip

while viewing through the view-

finder. Relative and absolute modes

are available, and nine area patterns

provide easy operation when view-

ing with either eye, and when posi-

tioning with either hand.

It is possible to use separate or

identical focus areas and points

for horizontal and vertical camera

orientations, reducing the need to

readjust focus when shooting sub-

jects that requires frequent camera

orientation changes.

Frequently used focus point settings

can be memorized and instantly

recalled via custom button assign-

ments. Focus area mode settings

can also be memorized and recalled

as required for fast, convenient

operation.

Memorized settings (exposure,

focus settings, drive mode, etc.) can

be assigned to custom buttons for

temporary recall while the button

is held, providing a convenient way

to quickly make temporary setting

changes.

This 3.0 type LCD monitor with 1.44

million dots features high resolution

for detailed viewing. WhiteMagic™

technology is included to ensure that

LCD viewing is bright and clear even

in outdoor conditions. The monitor

tilts upwards by a maximum of 107°,

and downwards by a maximum of 41°

for flexible hold and framing.

AF-ON Multi-selector

Touchpad Function

Touch Focus

* “Hi+” continuous mode with UHS-II compatible SDXC

memory card. Sony test conditions.

* Not all menu parameters can be edited while data is

being written to the memory card.

NEW

NEW NEW NEW

NEW

NEW NEW

NEW

2120

5-axis optical in-body image stabilization for a 5.5-step* exposure advantage

Doubled Eye AF performance*

A new precision stabilization unit and

gyro sensors work with optimized

image stabilization algorithms to

achieve a 5.5-step* shutter speed

advantage. Camera shake is effec-

tively compensated for in 5 axes, and

stabilization is effective for movies as

Eye AF automatically detects and

focuses on the subject’s eye. Notable

improvements in detection preci-

sion and speed in the 7R III result

in approximately doubled* tracking

performance when shooting moving

well as stills. The viewfinder image

is stabilized too, making it easier to

frame and focus. Effective stabiliza-

tion is achieved with a wide range

of lenses, including non-stabilized

E-mount lenses, and A-mount

lenses mounted via an adaptor.

portrait subjects. Eye focus is fast

and accurate even if the subject

is distant, looking away from the

camera, backlit, or in other situa-

tions that would challenge previous

systems. Eye AF is also supported

for A-mount lenses mounted via an

adaptor.**

Compensation for commonly experienced pitch and

yaw shake at long focal lengths.

Compensation for X and Y-axis shift shake at high mag-

nification (during macrophotography, etc.).

Compensation for roll shake on the Z-axis during long

exposures. Most in-lens systems for interchangeable-

lens cameras cannot compensate for roll shake.

Pitch and yaw compensation Horizontal and vertical shift compensation Roll compensation

Automatic, instant eye focus

In-body image stabilization enhances shooting freedom

Subject looking down

Eye AF can lock

on even while the

subject is turning

around

Indoor shots when the face is dimly lit Obstacles obscure part of the face (glasses, hands, etc.)

New portraiture potential

Innovations in Eye AF technology make the delicate task of

photographing people smoother and easier, while 5-axis

image stabilization boosts mobility and flexibility for sig-

nificantly enhanced portraiture potential.

* Compared to the 7R II, approx.

** With SSM or SAM lenses only. With the LA-EA3 mount adapter. Eye AF not supported for movie recording. AF-C can

only be used when the “Phase detection” AF system is selected, but focus is fixed at the first frame during continuous

shooting in any mode other than “Continuous: Lo” (Hi+, Hi, Mid).

* Eye AF may not function as expected in some situations.

* CIPA standards. Pitch/yaw shake only. Planar T* FE 50mm F1.4 ZA lens. Long exposure NR off.

NEW

New portraiture potential

Innovations in Eye AF technology make the delicate task of

photographing people smoother and easier, while 5-axis

image stabilization boosts mobility and flexibility for sig-

nificantly enhanced portraiture potential.

FE 70-200mm F2.8 GM OSS (SEL70200GM), 1/1000 sec., F5.6, ISO 800

Speed and flexibility for tethered shooting Professional lighting capability

Powerful software support

USB 3.1 Gen 1 compatible USB Type-CTM connector for fast transfer Improved flash compatibility

Image storage selection for PC remote

Capture One (for Sony)*

New Sony imaging software suite*

A USB Type-

C™

connector that sup-

ports fast USB 3.1 Gen 1 data trans-

fer makes high-speed PC Remote

data transfer available for smooth

A standard sync terminal is provided

for convenient synchronization with

studio flash units and other external

lighting equipment. Release time

lag has been minimized for smooth,

responsive flash photography. Con-

When the camera is tethered to a

computer, still images can be stored

in the camera as well as on the com-

puter so they can be reviewed without

having to leave the camera position.

Capture One Express (for Sony)

is free software for precise, high-

quality finishing of RAW data.

handling of large RAW image files.

Quickly review images on a PC, and

continue shooting without having to

wait for slow file transfers.

tinuous flash shooting at up to 10 fps*

offers advanced capture capability.

Slow sync and rear curtain sync** can

be selected when shooting with wire-

less off-camera flash for even further

enhanced versatility.

And when shooting RAW & JPEG it

is possible to transfer only the JPEG

files to the computer to reduce data

volume and allow transferred im-

ages to be reviewed immediately.

Capture One Pro (for Sony) can be

purchased for local adjustment and

PC Remote compatibility.

A new suite of imaging apps from

Sony provides top-quality RAW

development, convenient PC tether-

ing, and efficient viewing/manage-

ment. Live viewing on the computer

screen with semi-transparent refer-

ence overlay capability is available

during tethered shooting. Focus

points can also be set from the

computer. The new Pixel Shift Multi

Shooting feature can also be used

while tethered, and the pixel-shifted

images can be immediately com-

posited and viewed.

* Refer to the download page for details: http://www.sony.net/disoft/d/

* Please contact Phase One regarding all inquiries as to usage and support including functional compatibility of Capture

One Express (for Sony) and Capture One Pro (for Sony).

* Maximum continuous shooting speed will depend on the flash and shooting settings used.

** Rear curtain sync is not available with optical wireless flash units.

FE 85mm F1.4 GM (SEL85F14GM), 1/250 sec., F8, ISO 100, Profoto Pro-10 flash units

Smooth studio workflow

Features and operation related to PC remote shooting and

flash lighting have been updated in many important ways,

complementing improved response and higher efficiency

for professional studio applications.

NEW

2524

Pixel Shift Multi Shooting : Superior resolution from 42.4 megapixel RGB information

The Pixel Shift Multi Shooting principle

Normal single shot

Pixel Shift Multi Shooting

This new feature takes advantage

of the advanced in-body image

stabilization system control capabil-

ity available in the 7R III, precisely

shifting the sensor in 1-pixel incre-

ments to capture four pixel-shifted

images containing a total of approx-

Even the atmosphere of the subject

and surroundings are reproduced

with breathtaking fidelity, making

Pixel Shift Multi Shooting an ideal

technology for archival images of

art, architecture, and more.

imately 169.6 million pixels* that are

later composited using a computer

to achieve overwhelming subjec-

tive resolution in a single image. Still

images are captured with true-to-

life details, texture, and color, with

minimal moiré and color artifacts.

Notes A dedicated software application is required for compositing. Image compositing

may not be successful if camera or subject movement causes blur. The use of a tri-

pod is recommended, as is the use of PC tethered control or a remote commander

(when PC tethered control is not being used) where possible. Uncompressed RAW

and silent mode are automatically selected for Pixel Shift Multi shooting. Some

restrictions apply to flash and other devices. Refer to the Sony support site for

details.

http://www.sony.net/psms/

* Image size after compositing is approx. 42.4 million (7952 x 5304) pixels.

Normal single shot

Pixel Shift Multi Shooting after compositing

Tripod provided by Manfrotto

Lifelike detail, texture, color, and atmosphere

NEW

In a “normal” digital capture each pixel represents just

one color: red, green, or blue. The surrounding pixels

are used to supply the necessary extra information

required to interpolate and reproduce the remaining

two primary colors. Pixel Shift Multi Shooting, however,

composites four pixel-shifted images so that each of the

sensor’s 42.4 million effective pixels can represent red,

green, and blue values simultaneously. Extra interpola-

tion becomes unnecessary so the data from the sensor

can be directly synthesized to recreate the final colors.

The result is unprecedented reproduction accuracy and

detail for true-to-life textures. Images shot using this

feature can be processed using the dedicated PC soft-

ware from Sony running on a personal computer.

1) RGB color information

acquired at a 1:2:1 ratio.

1) The image sensor is moved in 1-pixel increments while shooting four sequential frames.

2) Each pixel represents

R, G, and B information.

2) Demosaicing provides the

remaining color information.

R : 10.5M

G : 21M

B : 10.5M

R : 10.5M X 4

G : 21M X 4

B : 10.5M X 4

A new dimension of

subjective resolution

Still images of art and architecture take on a new dimension of

reality with unprecedented subjective resolution.

Breathtaking movie reality

5K (15-megapixel) oversampling results in 4K movies with an

overwhelming sense of depth and detail, while a new HLG picture

profile supports high-quality HDR content creation. High resolution

and wide dynamic range come together with stunning realism.

2726

4K movies** from 5K (15-megapixel) data

Broad support for HDR content creation

HLG (Hybrid Log-Gamma) support for instant HDR workflow

Full pixel readout in the Super 35

mode, without the need for pixel bin-

ning, makes it possible to condense

5K (15-megapixel) data into high-

resolution, extraordinarily beautiful

4K movies with minimal moiré and

jaggies. Advanced image process-

ing also allows full-frame 4K movie

recording with dramatically improved

image quality at mid to high sensitivi-

ties. Super 35mm or full-frame re-

cording can be selected as required.

Sony’s S-Log gamma curve provides

extra flexibility to achieve a “look”

that best serves your artistic vision

during post-production color grad-

ing, while a newly added HLG (Hy-

brid Log-Gamma)* picture profile

supports instant HDR production

without the need for color grading.

Extra care has been taken to ensure

that a wide range of HDR content

creation requirements are fully sup-

ported.

Movies recorded using the HLG

profile will appear true-to-life with

no blocked shadows or blown high-

lights when played back on an HDR

(HLG) compatible TV, without the

need for color grading. The BT.2020

color space is supported, providing

a wider color gamut.

SDR HDR (HLG)

Improved Fast Hybrid AF for movies

Photo Capture

Proxy recording

Auto Power Off Temperature* Other movie features

Enhanced Zebra function Slow and quick motion

S-Log3 for wide 14-stop dynamic range

Fast Hybrid AF performance during

movie recording has been refined,

providing a wide AF area that is

similar to that provided for still im-

ages. AF now accurately locks onto

movie subjects over a wider area.

High-quality stills can be extracted

from movies and stored separately:

8 megapixel stills from 4K movies,

and 2 megapixel stills from full-HD

movies.

4K movies and lower-resolution

proxy movies can be recorded

simultaneously. The smaller proxy

files are ideal for quick previewing

or pre-editing that can reduce the

time required for final 4K editing.

This function sets the temperature

at which the camera will automati-

cally shut off. “High” allows longer

movie recording times when the

camera is mounted on a tripod.

Picture profiles, Clean HDMI, Time

Code/User Bit, REC control, Gamma

Display Assist, and other details

provide comprehensive support for

advanced video workflows.

This function simplifies exposure

monitoring, especially when shoot-

ing with Log gamma. A new mini-

mum brightness level setting helps

to avoid blown out highlights.

Frame rates from 1 fps to 120 fps

can be selected in eight steps for

up to 60x quick motion and 5x slow

motion while recording with full-HD

quality.

In addition to S-Log2, S-Log3 is

available for better gradation from

shadows to mid-tones (18% gray)

and a wide dynamic range of up to

14 stops for movies. A new color S-

Gamut3 color space that is a refined

version of S-Gamut is also provided.

S&Q Record Setting

NTSC 24p 30p 60p

PAL 25p 50p

S&Q Frame Rate

NTSC 1fps 2fps 4fps 8fps 15fps 30fps 60fps 120fps

PAL 1fps 2fps 3fps 6fps 12fps 25fps 50fps 100fps

Comprehensive moviemaking controlWide dynamic range

High-resolution, wide-dynamic-range 4K

* Sound not recorded. Class 10 or higher SDHC/SDXC

card required.

* Set to “Standard” for handheld shooting. Use a tripod or other support when “High” is selected. Shooting time may

vary according to environmental conditions and camera temperature when set to “High.”

* Connect to an HDR (HLG) compatible Sony TV via a USB cable when displaying HDR (HLG) movies.

** A Class 10 or higher SDHC/SDXC card is required for XAVC S format movie recording. UHS speed class 3 or higher is

required for 100 Mbps recording. S-Gamut3.Cine/S-Log3 Color Grading

NEW NEW

NEW NEW NEW

NEW

Tripod provided by Manfrotto

NEW

Other features that enhance

the 7R III experience

A well thought out selection of customizable functions, detailed AE

and AWB settings, plus image management and sharing features

provide handy solutions to a wide range of professional needs.

2928

My Menu & new menu interface

Fast parameter editing via Fn menu

Custom button assignments Anti-flicker shooting

Priority Set in AWB

Exposure standard adjustment

Location Information Link via Bluetooth

Wi-Fi / NFCTM / QR code FTP file transfer via Wi-Fi

File Names and Copyright

Instant mode dial recall of memorized camera setups

Flicker from fluorescent lights and

other artificial lighting can ruin still

images if it and the shutter timing

are out of sync. The 7R III auto-

matically detects flicker and adjusts

shutter timing to eliminate its effects.

A new M y Me nu f eature all ow s up to 3 0

items to be registered for instant recall.

Registered items can be arranged in

any convenient order, and unused items

can be erased as required. The primary

menus have also been reorganized for

smoother search and operation.

The first three characters of still im-

age file names can now be edited for

easier identification, and copyright

information can be automatically em-

Camera setups, including modes and cam-

era settings, can be registered in memory

for instant recall via the mode dial: up to

three in the camera, and four on a mem-

ory card. Memory card setups can also be

loaded into a separate 7R III body.

bedded in still image files. Record-

ing the photographer’s name and

author’s name along with images

provides basic copyright protection.

After the camera has been paired

to the PlayMemories Mobile™ app

installed on a compatible mobile

phone or tablet device, it can ac-

quire location data from the mobile

device and record that data with still

images or movies. The PlayMemo-

ries Home™ application can then

be used on a personal computer to

organize images imported into the

computer on a map.

When incandescent lamps or simi-

lar are the primary light source and

white balance is set to Auto, the color

tone priority can be set to Standard,

Ambience, or White. Ambience pri-

ority produces a warm tone, while

white priority is designed to provide

accurate white reproduction.

The Fn button can be used to quick-

ly display and select from up to 12

freely assignable functions while

shooting. Assign functions you use

frequently for fast, efficient selec-

tion and operation.

With one-touch remote, a smart-

phone or tablet functions as a view-

finder/remote control. One-touch

sharing transfers photos/videos to the

device. Install the PlayMemories Mo-

bile app on an NFC-enabled Android

device via Wi-Fi, then touch the device

to the camera to connect. The camera

now features QR code compatibility

This function allows convenient Wi-Fi

transfer of still image files selected

via the menu display to a specified

remote FTP server. FTPS (File Transfer

Protocol over SSL/TLS) is supported,

allowing SSL or TLS encrypted data

transfer for maximum security.

The standard exposure value can

be adjusted from -1 to +1 stop in 1/6

stop increments. This setting can be

made separately for each metering

mode.

Custom button assignments allow the

camera interface to be customized

for individual shooting preferences.

Eleven buttons can be reassigned to

select functions you choose, and sep-

arate functions can be assigned for

the still, movie, and playback modes.

ISO AUTO Min. shutter speed

This function sets the shutter speed

above which ISO sensitivity will begin

to change when the camera mode

is set to “P” or “A” and “ISO AUTO” is

selected. It can be used to minimize

subject blur when shooting moving

subjects.

Customizable functions

Flexible Auto Exposure and Auto White Balance

Data management and sharing

Normal

Shooting

Flickering

light source

Anti-ﬂicker

Shooting

Flicker

detected and

timing adjusted

1/100sec.(100Hz), 1/120sec.(120Hz)

The live view image is divided into

1,200 segments for detailed analysis

of subject color and lighting. The

use of focus information to ensure

consistent AE control is another

innovation that can reduce varia-

tions in image brightness in varying

situations.

The control direction of the front

and rear dials can be set via the

menus. It is also possible to assign

the large, accessible shutter button

to start and stop movie recording,

rather than using the MOVIE button.

A new Highlight mode detects the

brightest area in the frame to avoid

blown highlights, and an Entire

Screen Average mode can provide

stable auto exposure through com-

position changes.

When the Focus Area parameter is

set to Flexible Spot or Expand Flexible

Spot the metering spot location can

be linked to the focus area so that the

optimum metering point is maintained

automatically. Two spot sizes are avail-

able to match a wide range of subjects.

1200-segment live view exposure

analysis enhances stability

Customizable front/rear dials

and release button

Additional modes expand

metering versatility Versatile spot metering

* Only 100 Hz and 120 Hz flicker is detected. Continuous

shooting speed may decrease. Anti-flicker shooting is

not available during silent shooting, BULB exposure, or

movie recording.

* Bluetooth connectivity available with the following

terminal devices (at the date of release):

- Android (Android 5.0 or later, Bluetooth 4.0 or later)

- iPhone/iPad (iPhone 4S or later, 3rd generation iPad

or later)

Please refer to http://www.sony.net/pmm/btg/ for

more information.

* Use the latest version of PlayMemories Mobile.

* PlayMemories Mobile must be installed on the smartphone or tablet device.

NEW

NEW NEW

NEW

NEW NEW NEW

NEW

NEW NEW NEW

NEW

3130

Essential apps

• Recommended memory cards for movie recording in AVCHD/MP4 formats:

Memory Stick PRO Duo (Mark2), Memory Stick PRO-HG Duo, SD memory

card/SDHC memory card/SDXC memory card(Class 4 or more)

• Recommended memory card for movie recording in XAVC S format: SDHC/

SDXC memory card of Class 10 or higher

• The numbers in the table show approximate maximum recordable time

obtained by totaling all movie files.

• AVCHD movies are automatically divided into separate files up to a maxi-

mum of 2GB each.

Number of recordable frames for single media

(Image size L 42M, aspect ratio 3:2)

8GB 32GB 64GB 256GB

Standard 770 3,100 6,200 24,500

Fine 520 2,100 4,200 16,500

Extra fine 270 1,050 2,150 8,700

RAW & JPEG

(Compressed RAW) 130 520 1,050 4,200

RAW

(Compressed RAW) 170 700 1,400 5,600

RAW & JPEG

(Uncompressed RAW) 75 300 600 2,400

RAW

(Uncompressed RAW) 88 355 710 2,850

8GB 32GB 64GB 256GB

XAVC S 4K 30p 100M/ 25p 100M 0:08:00 0:35:00 1: 1 5:00 5:1 5:00

30p 60M/ 25p 60M 0:1 0:00 1:00:00 2: 05:00 8:35:00

24p 100M 0:08:00 0:35:00 1:1 5:00 5:1 5:00

24p 60M 0:1 0:00 1:00:00 2:05:00 8:35:00

XAVC S HD 120p 100M/ 100p 100M 0:08:00 0:35:00 1:1 5:00 5:1 5:00

120p 60M/ 100p 60M 0:1 0:00 1:00:00 2:0 5:00 8:35:00

60p 50M/ 50p 50M 0:1 5:00 1: 1 5:00 2:3 0:00 10:25:00

60p 25M/ 50p 25M 0:30:00 2:25:00 5:00:00 20: 15:00

30p 50M/ 25p 50M 0:1 5:00 1: 1 5:00 2:30:00 10:25:00

30p 16M/ 25p 16M 0:50:00 3:50:00 7:45:00 31:25:00

24p 50M 0:1 5:00 1: 1 5:00 2:30:00 10:25:00

AVCHD 60i 24M (FX)/ 50i 24M (FX) 0:40:00 2: 55:00 6:00:00 24: 15:00

60i 17M (FH)/ 50i 17M (FH) 0: 55:00 4:05:00 8: 1 5:00 33: 15:00

Movie recording time for single media

(Hours:Minutes:Seconds)

1 Hook for shoulder strap

2 Microphone jack

3 Flash sync terminal

4 Headphones jack

5 HDMI micro jack jack

6 USB Type-CTM terminal

7 Charge lamp

8 Multi/Micro USB terminal

9 Mode dial

10 Mode dial lock release button

11 Microphone

12 Image sensor position mark

13 Speaker

14 Multi Interface Shoe

15 Front dial

16 Power switch

17 Shutter button

18 C1 (Custom 1) button

19 C2 (Custom 2) button

20 Exposure compensation dial

21 AF illuminator/Self-timer lamp

22 Remote sensor

23 Lens release button

24 Mount index

25 Mount

26 Image sensor

27 Lens contacts

28 Battery insertion slot

29 Tripod socket hole

30 Eye sensor

31 Viewfinder

32 Eyepiece cup

33 C3 button (Custom button 3)

34 MENU button

35 Monitor

36 Playback button

37 MOVIE button

38 Rear dial

39 For shooting: AEL button

For viewing: Image index button

40 For shooting: AF-ON button

For viewing: Enlarge button

41 Multi-selector

42 For shooting: Fn (Function) button

For viewing: Send to Smartphone button

43 Control wheel

44 Access lamp

45 For shooting: C4 button (Custom button 4)

For viewing: Delete button

46 Diopter-adjustment dial

47 Media slot cover switch

48 Hook for shoulder strap

49 N mark

PlayMemories Home™

PlayMemories Mobile™

Controls

It’s easy to install this image man-

agement software onto a Windows

or Mac computer, then use it for

The PlayMemories Mobile app can

be installed on a compatible smart-

phone or tablet to provide remote

camera control and easy image

transfer. The new PlayMemories

easy viewing, editing and printing.

You can also upload and share con-

tent via network services.

Mobile version provides updated

remote camera control, with the

same operability as available on the

camera itself.

Library

Enter the exciting world of Sony α products through α Library,

the new photography-themed application for tablets.

Go to Google Play for Android Tablet. For iPad, go to App Store.Then search for “sony α library“.

“sony α library“

3332

Fast, expressive lenses

FE 70-200mm F2.8 GM OSS

(SEL70200GM)

FE 100mm F2.8 STF OSS GM

(SEL100F28GM)

FE 100-400mm F4.5-5.6 GM OSS

(SEL100400GM)

1.4x Teleconverter Lens

(SEL14TC)

for SEL70200GM and SEL100400GM

2x Teleconverter Lens

(SEL20TC)

for SEL70200GM and SEL100400GM

NEW

FE 24-70mm F2.8 GM

(SEL2470GM)

FE 16-35mm F2.8 GM

(SEL1635GM)

FE 85mm F1.4 GM

(SEL85F14GM)

E-mount G MasterTM

FE 70-300 F4.5-5.6 G OSS

(SEL70300G)

FE 90mm F2.8 Macro G OSS

(SEL90M28G)

FE 12- 24mm F4 G

(SEL1224G)

FE 24-105mm F4 G OSS

(SEL24105G)

FE PZ 28-135mm F4 G OSS

(SELP28135G)

FE 70-200mm F4 G OSS

(SEL70200G)

E-mount G LensTM

Vario-Tessar T*

FE 16-35mm F4 ZA OSS

(SEL1635Z)

Vario-Tessar T*

FE 24-70mm F4 ZA OSS

(SEL2470Z)

Distagon T*

FE 35mm F1.4 ZA

(SEL35F14Z)

Sonnar T*

FE 35mm F2.8 ZA

(SEL35F28Z)

Planar T*

FE 50mm F1.4 ZA

(SEL50F14Z)

Sonnar T*

FE 55mm F1.8 ZA

(SEL55F18Z)

E-mount ZEISS®

A-mount Explore higher perspectives

See the world from more creative perspectives with the full range of

premium Sony A-mount lenses. Fisheye, wide-angle, super telepho-

to, macro, and legendary ZEISS® lenses offer the ultimate in imaging

expression. An optional LA-EA3 or LA-EA4 Mount Adaptor is required

to mount A-mount lenses on the 7R III.

Image quality Standard ISO up to ISO 25600 up to ISO 32000 + 1/3 stop

Low noise Up to 1 stop improvement for mid sensitivity.

Gradation Up to 15 stops low-sensitivity dynamic range. 14-bit

RAW* support for continuous and silent shooting.

Sharpness, color Large improvement.

Pixel Shift Multi Shooting New

Speed Continuous shooting 5 fps (approx.) 10 fps (approx.) Speed doubled (approx.)

Continuous shooting (Silent) Single only 10 fps (approx.) Continuous supported

No. of recordable frames 23 compressed

RAW images

76 compressed

RAW images

3.3x improvement

Basic AF performance

Up to 2x** faster in low light, approx. 2x** faster tracking

Lower AF detection brightness limit

EV-2 EV-3 1 stop increase.

Eye AF Large improvement in detection precision, speed.

Approx. 2x** faster tracking. A-mount lens support.

Operability &

Reliability

5-axis image stabilization 4.5 steps 5.5 steps + 1 stop

EVF XGA OLED

Tru-Finder

Quad-VGA OLED

Tru-Finder

1.5x resolution, 2x luminance

(approx.). 120 fps*** finder

frame rate support, 30% faster

startup. High quality mode.

Battery NP-FW50 NP-FZ100 2.2x capacity

Media Single slot

(UHS-I)

Dual slot

(UHS-II support)

Higher write speed,

simultaneous write, sequential

write (Auto Switch Media).

USB connector for PC

tethering

USB 2.0

(Multi/ Micro USB)

USB 3.1 Gen 1

(USB Type-CTM)

Faster transfer speed

Controls AF-on, Multi Selector, Touch Panel.

Movies Improved quality in full-frame 4K high-sensitivity

movies, improved movie AF, Hybrid Log-Gamma,

S-Log3, Slow&Quick motion, Photo Capture, Proxy

Recording.

Others Sync terminal, Anti-flicker shooting, improved

peaking, Focus magnification with AF support, My

Menu, Rating, Display continuous shooting group,

FTP over Wi-Fi, and more.

Improvement

7R II / 7R III comparison

* Limited to 12 bits during compressed RAW continuous shooting, BULB exposure, or when Long Exposure NR is ON.

** Sony test conditions.

*** in NTSC mode. 100fps in PAL mode.

Sony Photo Galley:

http://www.sony.net/Products/di_photo_gallery/

Sony Camera Channel:

https://www.youtube.com/c/ImagingbySony

3534

System chart

Flash Light

Tripod / Commander

Microphone / Monitor

Cace

Vertical Grip

Strap/Grip Belt

Power / Other

Flash

HVL-F45RM

Flash

HVL-F43M

Wireless Radio

Receiver

FA-WRR1

Flash

HVL-F60M

Wireless Radio

Comander

FA-WRC1M

Flash

HVL-F20M

Flash

HVL-F32M Battery Video Light

HVL-LE1

Battery Video Light

HVL-LBPC

Battery Video IR Light

HVL-LEIR1

Ring Light

HVL-RL1

VG-C3EM

Stereo

Microphone

ECM-XYST1M

Shotgun

Microphone

ECM-CG60

Wireless

Microphone

ECM-AW4

Wireless

Microphone

ECM-W1M

XLR Adaptor Kit

XLR-K2M

Electret Condenser

Microphone

ECM-MS2

UWP-D Package

UWP-D11/D12

Clip-on LCD Monitor

CLM-V55

Clip-on LCD Monitor

CLM-FHD5

Soft

Carrying

Case

LCS-SL20

Sling Bag

LCS-SB1

Soft Carrying Case

LCS-SC21

Soft

Carrying

Case

LCS-SC8

Soft

Carrying

Case

LCS-PSC7

Back Pack

LCS-BP2

Back Pack

LCS-BP3

Remote Commander

and IR Receiver Kit

RMT-VP1K

Remote

Control

Tripod

VCT-VPR1

Remote Control Tripod

VCT-VPR10

Remote

Commander

RM-SPR1

XLR Adaptor Kit

XLR-K1M

Electret Condenser

Microphone

ECM-680S

Multi Interface

Shoe Adaptor

SMAD-P3

Battery Charger

BC-QZ1

Multipod

VCT-MP1

Tripod

VCT-P300

Eyepiece Cup

FDA-EP18

Rechargeable

battery Pack

NP-FZ100

Multi Battery

Adaptor Kit

NPA-MQZ1K

LCD Protect

Semi Hard Sheet

PCK-LG1

Grip Extension

GP-X1EM

Body Cap

ALC-B1EM

Circular PL Filters

VF-49CPAM/

55CPAM/

62CPAM/

67CPAM/

72CPAM/

77CPAM/

82CPAM

MC Protectors

VF-49MPAM/

55MPAM/

62MPAM/

67MPAM/

72MPAM/

77MPAM/

82MPA/

M405MP

HDMI Cable

(Micro)

DLC-HEU15/30

Multi Terminal

Connecting Cable

VMC-MM1

Bracket

VCT-55LH

Shoe Cap

FA-SHC1M

Remote

Commander

RMT-DSLR2

Shoulder

Strap

STP-SS5

Shoulder

Strap

STP-XH1

Shoulder

Strap

STP-XH70

Shoulder

Strap

STP-SB2AM

Remote Commander

RM-VPR1

Options for expanded photographic capability

Vertical Grip

VG-C3EM

• Optimum hold*1 and control comfort when shooting in

vertical orientation

•

Houses two NP-FZ100 batteries for longer operation, and sup-

ports USB charging via the camera

Multi Battery Adaptor Kit

NPA-MQZ1K

• Allows sequential use of up to four NP-FZ100 batteries

• Also functions as a four-battery rapid charger*1

• Compact and lightweight clip-on flash with high GN45*1

output

• Functions as a wireless radio commander or receiver in

multi-flash setups

Radio Wireless Flash

HVL-F45RM

This Multi Battery Adaptor Kit houses up to four NP-FZ100

rechargeable battery packs and connects to the camera via

a plug-in plate, providing dramatically extended operat-

ing time for sessions that can’t be interrupted by battery

changes. The NPA-MQZ1K also supports power supply from

NP-FW50*2. It includes two USB ports so that power can be

delivered to the camera and a USB device simultaneously.

LED indicators show the remaining power for each battery.

Three tripod mount sockets on the upper surface and three

on the lower surface provide flexible mounting options.

The VG-C3EM Vertical Grip makes shooting in vertical

orientation just as efficient and comfortable as horizontal

orientation with a full complement of essential controls, in-

cluding a duplicate Multi-Selector. The grip shape is identi-

cal to the grip on the camera body, so no hold adjustment is

required. The VG-C3EM features a magnesium alloy exterior

for high rigidity and durability, and the design is dust and

moisture resistant*2 for maximum reliability.

The HVL-F45RM is compact and convenient for use in the

field or studio, delivering up to Guide Number 45*1 power

with less than a 2.5-second*2 recycle time. It can be used as

a wireless radio commander or receiver, and when used as

a commander can control up to 15 compatible off-camera

flash units or receivers in up to 5 groups*3. Radio wireless

works at distances up to 30 meters*4, providing reliable

operation without pairing errors.

In addition to supplying power, the NPA-MQZ1K also

functions as rapid charger, Four NP-FZ100 batteries can be

charged to 90% level in approximately 480 minutes.

The VG-C3EM not only provides space for two NP-FZ100

rechargeable battery packs, significantly extending operat-

ing time, but it also allows the batteries to be charged via

the camera USB connector so the batteries don’t have to be

removed from the grip.

The HVL-F45RM also provides high-visibility tabbed menus

and a Quick Navi interface for easy, intuitive operation.

Customizable keys give you direct access to the functions

you use the most. The flash bounce head rotates and tilts for

flexible lighting in a wide range of situations, and the overall

design is dust and moisture resistant*5 for high reliability.

*1 With the supplied AC adaptor. NP-FW50 charging not supported.

*2 NP-FW50 compatible cameras: 7/7 II/7R/7R II/7S/7S II/6500/

6300/6000/5100/5000/3500/3000/DSC-RX10/RX10 II/RX10 III/

RX10 IV.

*1 Simultaneous use with LE-EA2 or LA-EA4 mount adaptor not

supported due to narrow clearance between mount adapter and

vertical grip.

*2 Not guaranteed to be 100% dust and moisture proof.

*1 105mm at ISO 100 in meters.

*2 1/1 manual flash emission, alkaline batteries.

Up to 5 groups in GROUP mode, and up to 3 groups in TTL or MANUAL mode.

*4 Internal Sony tests.

*5 Not guaranteed to be 100% dust and moisture proof.

SD Cards (UHS-II)

SF-G Series (32/64/128 GB)

Eyepiece Cup

FDA-EP18

Battery Charger

BC-QZ1

Grip Extension

GP-X1EM

Screen Protect Glass Sheet

PCK-LG1

Rechargeable Battery Pack

NP-FZ100

• Ultra-fast write speed

up to 299MB/s, read

speed up to 300MB/s

• Ideal for high-speed

continuous shooting

and 4K video recording

• Supplied Sony File Res-

cue software recovers

accidentally deleted

photos and video

• Slides easily into place

with a secure locking

mechanism

• Soft material for

optimum eye fit and

comfort

• Fully charges one

NP-FZ100 battery in

approx. 150 min.

• LED indicator shows

charge status

• Slim, 33-millimeter

portable design

• Provides an ideal rest-

ing spot for a finger,

improving hold comfort

and stability

• Hard (hardness rating

9H), shatterproof

glass provides reliable

screen protection

• Compatible with

touch-sensitive and

tilting LCDs

• AS coating resists

staining and finger-

prints

• Twice the capacity

of the NP-FW50 for

long life

• I nfoLITHIUM® support

enables remaining

battery charge display

on the camera LCD

screen

Sony ILCE 7RM3 User Manual Brochure And Main Specifications ILCE7RM3

Navigation menu

Versions of this User Manual:

Views

Navigation
