KDF
-E50A10
50" 3LCD Rear Projection Television
Shown with optional SU-RG11M A/V stand
Key Features
3LCD Technology
WEGA Engine
™ System
Cinema Black Pro
ATSC Integrated Tuner with CableCARD™ Slot
WEGA GATE
™ - Easy Operation Guide
Slim, Stylish Design
PC Input
HDMI™ (High Definition Multimedia Interface) Connector
Key Technologies
3LCD Panels
The 3LCD technology at the heart of Sony’s Grand WEGA™ televisions provide a bright picture, with
high detail and natural color. These three key benefits are immediately apparent when viewing a Grand WEGA™
TV. You can expect to see an incredibly detailed picture with eye
-
popping colors.
Sony uses three tiny LCD panels (0.73” or 0.87” depending on model) with a combined resolution of over 2.76
million pixels on the smallest panel and over 3 million pixels on the larger one. The light from a high output UHP
lamp shines into a filtering system that splits the beam into red, green, and blue light streams. Each color goes
through its own LCD panel, which passes or blocks the light. The three beams are then recombined and sent to the
projection lens.
Cinema Black Pro
Cinema Black Pro is an exclusive Sony function designed to improve contrast expression
especially in darker scenes. The Cinema Black Pro function is enabled by using either one or both of two features
-
Iris Control and Advanced Iris. The Iris Control function sets the maximum size of the iris opening and sets the
overall level of brightness. There are six settings that allow the user to adjust the iris opening to best match the
room lighting conditions.
The Advanced Iris function is a dynamic adjustment that automatically opens and closes the iris according to the
gamma level of the picture on the screen. There are four different adjustments. The “High” setting is ideal for
movies and music video content. And the “
Off
”
setting works great for sports and news content.
HDMI™ and PC Connectivity
Designed for maximum versatility, Sony’s Grand WEGAT™
XBR
® line is equipped
with a comprehensive range of input interfaces. The HDMI (High
-
Definition Multimedia Interface) is the first
industry
-
supported, uncompressed, all
-
digital audio/video interface. HDMI technology supports enhanced or High
Definition video, together with multi
-
channel digital audio to provide matchless image and sound reproduction.
The PCD input (HD
-
15
-
pin) offers easy connection to your PC, allowing you to use your high resolution Grand WEGA
XBR TV as a computer monitor.
Sony Electronics Inc.
•
16530 Via Esprillo Drive
•
San Diego, CA 92127
•
1-800-222-7669
•
www.sony.com
KDF
-E50A10
50" 3LCD Rear Projection Television
Shown with optional SU-RG11M A/V stand
Please visit the Dealer Network for current
information at www.sony.com/dn
Features
General
Auto SAP: Yes
Channel Fix: Yes
Closed Caption (CC): Yes
ID1 Detection:
Yes
Video Label: Yes
Video
Screen or Display Technology: 3LCD
Tuner: 8 VBS, ATSC, NTSC, Clear QAM
Video Processing:
Yes (WEGA Engine
™
Technology)
Color Temperature: Cool, Neutral, Warm 1,
Warm 2
Noise Reduction: Yes
Black Corrector: High, Medium, Low, Off
Cinema Black Pro: Yes
Clear White:
High, Low, Off
Color Space: Wide, Normal
Gamma Compensation: Max, High, Medium,
Low, Off
Live Color: High, Medium, Low, Off
CineMotion® Reverse 3:2 Pulldown
Technology: Yes
Direct Digital II Circuitry:
Yes
Advanced Iris: High, Medium, Low, Off
Wide Mode (16:9): Wide Zoom, Full, Zoom
Wide Mode (4:3): Wide Zoom, Normal, Full,
Zoom
Wide Mode (PC): Normal, Full 1, Full 2, Zoom
Display Mode for PC Input: Video, Text
Comb Filter: 3D Digital Comb Filter
DRC® MultiFunction Circuitry: Yes
DRC® Mode: High Density, Progressive, Off
DRC®
Palette Presets:
Custom 1
Game Mode: On/Off
Game Picture: +5 to -5
Auto Adjustment (PC): Yes
Image Shift:
Auto, Level 1, 2, 3, 4
Phase (PC Only): Yes
Pitch (PC Only): Yes
Advanced Video Menu: Yes
Picture Modes: Vivid, Standard, Custom
Color System: ATSC, NTSC
Audio
Tone Control(s): Treble, Bass
Sound Mode: Dynamic, Standard, Custom
MTS Stereo Decoder:
Yes
A/V Synch: Off/1/2/3
Digital Amplifier:
Yes
Audio Mute: Yes
Speaker On/Off:
Yes
Simulated Surround: Yes
SRS
® TruSurround® XT Audio Effect: Yes
Dolby®
Digital:
Yes
Convenience
Channel Label: Yes
Channel Skip/Add: Yes
Channel Jump: Yes
Favorite Channel: Yes
Speed Surf
™
Channel Selection: Yes
WEGA GATE
™
Technology: Yes
Program Guide Access: Yes
Auto Channel Programming: Yes
Menu Color: Yes
Multiple Language Display:
English; Español;
Français
Parental Control (V-Chip): Yes
Info Banner: Yes
Programmable Timer: 2 Event
Sleep Timer:
15, 30, 45, 60, 90, Off
Timer Events:
Timer 1, Timer 2
Caption Vision: On, Off, Program
Clock: Yes
Power Save Mode: Standard, Reduced, Picture
Off
Built
-in AC Adaptor: Yes
Picture Freeze:
Yes (with side-by-side viewing)
Specifications
General
Aspect Ratio: 16:9
Screen Size:
50"
Video
Native Resolution: 720p
Display Resolution: 1280 x 720
Viewing Angle:
Right/Left: 170
°
, Up/Down: 170
°
Vertical Size:
Yes
Vertical Center:
+50 to -50
Horizontal Center: +50 to -50
Audio
Speakers (Total):
2
Audio Power Output: 24W Total (12W x 2)
Inputs and Outputs
Analog Audio Input(s): 5 (4 Rear/1 Side)
Audio Out (Variable/Fixed):
1 (Rear)
CableCARD
™
Slot:
1 (Rear)
Component Video (Y/Pb/Pr ) Input(s): 1 (Rear)
Composite Video Input(s): 1 (Rear)
Digital Audio Output(s):
1 (Rear)
RF Connection Input(s): 2 (Rear)
S
-Video Input(s): 2 (Rear)
PC Video Input(s): 1 (Rear) D-sub 15
HDMI
™
Connection(s): 1 (Rear) with Audio
Input
Power
Internal Power Supply: Yes
Power Consumption (in Operation): 210W
2
Power Consumption (in Standby): Less than
17W
Power Requirements: AC 120V, 60Hz
Power Management: Yes
Regulation and Standard Compliance
Energy Star
® Compliant: Yes
Service and Warranty Information
Limited Warranty:
1 Year Parts / 1 Year Labor
Dimensions
Weight:
72lb. 13oz (33kg)
Measurements: 46 5/8"×32 5/8"×16
1/8" (1184×827×408mm)
Optional Accessories
SU
-RG11M (Optional AV Stand)
XL-2400 (Replacement Lamp)
UPC Code: 027242675315
Confidential Sony Information. For Internal Use Only.
1. "Standby" LED for "Power Management" mode.
2. Screen Sive measured diagonally.
©2006 Sony Electronics Inc. All rights reserved.
Sony, WEGA Engine, WEGA GATE, Steady Sound, DRC and MID are
trademarks of Sony. Dolby and Dolby Digital are trademarks of Dolby
Laboratories. SRS and TruSurround are trademarks of SRS Labs, Inc. HDMI is
a trademark of HDMI Licensing, LLC. CableCARD is a trademark of Cable
Television Laboratories, Inc. All other trademarks are property of their
respective owners.
Features and specifications are subject to change without notice. Non
-
metric weights and measures are approximate.
