KDL-
23S2010
BRAVIA®
S
-
Series Digital LCD Television
Key Features
ATSC Digital Tuner
BRAVIA Engine
™
full digital video processor
Digital audio amplifier
Light sensor backlighting control
SRS
®
TruSurround XT audio enhancement
ATSC Digital Tuner
BRAVIA Engine
™
full digital video processor
Digital audio amplifier
Light sensor backlighting control
Picture Freeze function
Key Technologies
BRAVIA Engine
™ Full Digital Video Processor
BRAVIA
®
S
-
Series Digital LCD televisions use Sony's
BRAVIA Engine™ full digital video processor for crisp and clear images. Several special picture
enhancement technologies are integrated into the processor to create better gradations and
details, enhance contrast, dynamically improve color, and reduce image flicker.
HDMI™
and PC Connectivity
Designed for maximum versatility, Sony’s S
-
Series Digital LCD TV line is
equipped with a comprehensive range of input interfaces. The HDMI (High
-
Definition Multimedia
Interface) is the first industry
-
supported, uncompressed, all
-
digital audio/video interface. HDMI
technology supports enhanced or High Definition video, together with multi
-
channel digital audio to
provide matchless image and sound reproduction. The PC input (HD
-
15
-
pin) offers easy connection
to your PC, allowing you to use your high resolution BRAVIA S
-
Series Digital TV as a computer monitor.
Light Sensor
Intelligently adjusts the screen brightness to match the ambient light in a room,
ensuring a comfortable viewing experience. In a dim room for example the screen automatically
reduces brightness making it much more comfortable for viewing.
SRS
®
TruSurround
® XT Building on the success of TruSurround technology, TruSurround XT audio
adds three new audio enhancement technologies to produce an amazingly immersive sound
experience. Dialog Clarity
-
brings movie dialog into “focus” during the playback of any surround
-
encoded material to make speech much clearer and crisper. TruBass creates incredible deep rich
bass allowing a person to perceive significantly deeper, richer low bass tones that are far beyond
the physical low frequency capabilities of the speaker itself. And WOW (comprised of SRS, TruBass
and Focus technologies) widens the soundstage by processing standard two
-
channel stereo
material as well as multi
-
channel encoded material for a dramatic improvement in the playback of
any stereo audio over a two
-
speaker system.
Freeze Function
Sony’s Freeze Function is a useful function that allows you to temporarily freeze the
picture in a separate screen while the programming continues to display. This comes in handy when
you want to copy a recipe, phone number, etc. that flashes too quickly across your screen. Simply
touch the “Freeze” button on the remote control and copy the details down at your convenience.
Last Updated: 05/23/2008
KDL-
23S2010
BRAVIA®
S
-
Series Digital LCD Television
Please visit the Dealer Network for current
information at www.sony.com/dn
Features
General
Video Label: Yes
Closed Captions (CC): Yes
Video
Video Processing: Yes (BRAVIA Engine™
System)
Noise Reduction: Yes
Picture Modes:
Vivid, Standard, Custom
Display Technology: LCD (178
°
wide
viewing angle LCD display panels)
High Definition: Yes (720p)
3D Comb Filter: Yes
Audio
MTS Stereo Decoder: Yes
A/V Synch:
Off/1/2/3
Digital Amplifier: Yes
SRS
®
TruSurround
®
XT Audio Effect: Yes
Auto SAP: Yes
Steady Sound
®
Automatic Volume
Control:
Yes (with BBE
®
Technology)
Dolby
®
:
Dolby
®
Digital (AC3/ATSC only)
SRS
®
:
SRS
®
TruSurround
®
XT Audio Effect
Convenience
Channel Label: Yes
Channel Skip/Add: Yes
Favorite Channel: Yes
Parental Control (V
-
Chip): Yes
Programmable Timer: Yes
Sleep Timer: 15, 30, 45, 60, 90, Off
Timer Events: Timer 1, Timer 2
Clock:
Yes
Power Save Mode:
Standard, Reduced,
Picture Off
Picture Freeze: Yes
Input Skip: Yes
Remote Control: Yes
ID
-
1 Detection: Yes
LightSensor™
:
Yes
Specifications
General
Aspect Ratio: 16:9
Television Type: Flat Panel LCD HDTV
Video
Panel Response Time: 8ms (gray to gray)
Advanced Video Processor:
CineMotion
®
/
Film Mode/Cinema Drive,
Contrast enhancer circuit, Green and
blue enhancer, Motion and edge
adaptive I/P converter, MPEG Noise
Reduction
Audio
Audio Power Output: 10W (5W x2)
Sound Enhancer:
Dynamic, Standard,
Custom
Convenience
Timer Clock: Yes
Inputs and Outputs
Component Video (Y/Pb/Pr ) Input(s): 2
(Rear)
Composite Video Input(s): 3 (2 Rear/1
Side)
Digital Audio Output(s): 1 (Rear)
RF Connection Input(s): 1 (Rear)
S-
Video Input(s): 2 (1 Rear/1 Side)
Headphone Output(s): 1 (Side)
PC Audio Input(s): 1 (Rear)
PC Video Input(s): 1 (Rear)
Analog Audio Input(s) (Total): 5 (4 Rear/1
Side)
Audio Out: 1 (Rear)
HDMI™ Connection(s) (Total): 1 (Rear)
HDMI™ Connection(s) (w/ Analog Audio
In): 1 with L/R RCA audio connections
Power
Power Consumption (in Operation): 105W
Power Consumption (in Standby): Less
than 0.01W
Power Requirements (voltage): AC 120
-
240V, 50/60Hz
Regulation and Standard
Compliance
Energy Star
®
Compliant: Yes
VESA
®
Hole Spacing Compatible: Yes
VESA
®
Hole Pitch: 200 x 200 hole pattern /
M6 thread size / 14mm hole depth
Service and Warranty Information
Limited Warranty: 1 Year Parts / 1 Year
Labor
Dimensions
Weight: 22.50lbs. (10.2kg) with pedestal;
16.40bs (7.4kg) without pedestal
Supplied Accessories
Tabletop Stand
RM
-
YD005 Remote Control
AA x 2 Batteries
Coaxial Cable (x1)
HD
-
15 to HD15 Cable (x1)
Support belt and screws
Operation Manual
Optional Accessories
SU
-
WL31 Wall Mount Bracket
Color:
Black
UPC Code:
027242704015
1. Screen Size measured diagonally.
2. Limited to resolutions supported by both the PC and the Sony TV. See
Sony TV users manual and PC documentation for supported
resolutions
3. Black white range seen over a period of time.
2
2
Lamp in this product contains mercury. Disposal of these materials may
be regulated due to environmental considerations. For disposal or
recycling information, please contact your local authorities or the
Electronic Industries Alliance (www.eiae.org)
©2006 Sony Electronics Inc. All rights reserved.
Sony, BRAVIA, BRAVIA Engine, and CineMotion are trademarks of Sony.
SRS and the SRS symbol, TruSurround are trademarks of SRS Labs, Inc.
Dolby Digital is a registered trademark of Dolby Laboratories. This TV
incorporates High
-
Definition Multimedia Interface (HDMI™
)
technology.
HDMI, the HMDI logo and High
-
Definition Multimedia Interface are
trademarks or registered trademarks of HDMI Licensing LLC. All other
trademarks are property of their respective owners.
VESA is a trademark of Video Electronics Standards Association Inc.
Features and specifications are subject to change without notice. Non
-
metric weights and measures are approximate.
