KP-65WV600
KP-57WV600
Hi-Scan 1080i™ 16:9 Projection Television
• Hi-Scan 1080i™ Display
• HD MICROFOCUS™ CRT And Lens System
• DRC™ MultiFunction V1 Circuitry
• CineMotion™ Reverse 3-2 Pulldown Technology
• MID™-X (Multi Image Driver-X) Technology
• HD Detailer™ Wideband Video Amplifier
• ClearEdge VM™ Wideband Velocity Modulation
• 720p Input Capable (Converted To 1080i)
• MemoryStick® Media Playback (JPEG)*
• DVI-HDTV Interface
General Features
• DVI-HDTV Interface
• Auto SAP
• Auto Mute (Tuner)
• DAC Speaker System
(20w x 2
• Simulated Surround Sound
• TruSurround™ SRS 3D
Audio Effect
• Steady Sound® Auto
Volume
Control With BBE
• Fixed/Variable Audio Out
• Speakers On/Off
• Auto Channel Program
• Caption Vision (CC)
• Channel Fix
• Channel Label
• Channel Skip/Add
• Clock/Timer (Two Event)
• Demo Mode
• Energy Star® Compliant
• Favorite Channel With
Preview
• Twin-View™ Two Tuner
Picture And Picture
• Picture Freeze
• Channel Jump
• On Screen Display
English/Spanish/French
• Program Palette™ Presets
• Scrolling Channel Index™
• Sleep Timer
• Speed Surf™ Channel
Selection
• V Chip Parental Control
• Video Label
• Auto Wide/Widescreen
Modes
• XDS Banner
• Flash Focus® Digital
Convergence (Automatic)
• Manual Convergence
Adjustment
• First Surface Mirror
• BrightView™ Dual
Component Screen
• High Contrast Lenticular
Screen
• Fine Pitch Fresnal Screen
With Signal A/R Coating
• Built-In High Contrast
Protective Screen
• Auto Pedestal Clam
• Auto White Balance
• Dynamic Focus™ Circuitry
• Dynamic Picture™
Processor Circuitry
• Trinitone® Color
Temperature
• Vertical Aperture
Compensation
• Vertical Center Adjustment
• S Video Detection
KEY FEATURES
ADDITIONAL FEATURES
Product Information
KP-65WV600
KP-57WV600
Hi-Scan 1080i™ 16:9 Projection Television
Hi-Scan 1080i™ Display Sony’s Hi-Scan 1080i™ TV’s accept
the full 1080 interlaced scanning lines (1080i) or 720 progressive
scan (720p) from an external HDTV receiver or a compatible high
definition digital satellite receiver. It also accepts 480 progressive
(480p) scanning lines from compatible DVD video sources.
HD MicroFocus™ CRT’s By using an impregnated cathode
and a denser phospher layer, this CRT produces a 30% tighter
beam spot compare to previous models
Digital Reality Creation™ MultiFunction V1 The latest
version of DRC™ circuitry minimizes the visibility of scanning lines
to create an impressively smoother and more beautiful picture,
while also offering user control over detail and smoothness levels,
to allow for a custimized picture that is optimized for signal quality,
viewing conditions and personal preference.
CineMotion™ Reverse 3-2 Pulldown Technology Is a
fixed algorithm irrespective of source which preserves the integrity
of movie film frames to create the best possible image.
Specifications
Inputs and Outputs
• Component Video Input
(Y, Pb, Pr): 2 Rear
• Composite Input: 3
Rear/1Front
• RF Input: 2 Rear
• Control S In/Out
• DVI-HDTV Interface
• S Video: 2 Rear
• Monitor Out: 1 Rear
General
• Power Requirements:
AC120V, 60Hz
Accessories
Supplied Accessories
• Instruction Manual
• Remote Control
(RM-Y188)
• AA Battery x 2
Weights & Measures
(Approx)
• Dimensions (W x H x D):
KP-65WV600 -
60 3/4 x 59 5/8 x 28 7/8
(1542x1516x735mm)
KP-57WV600
53 5/8 x 54 7/8 x 27 1/8
(1361x1394x689mm)
• Weight (Approx.):
KP-65WV600 - 299lbs
13oz (136kg)
KP-57WV600 - 216lbs 1oz
(98kg)
ADDITIONAL FEATURES
KEY TECHNOLOGY
Product Information
©2002 Sony Electronics Inc. All rights reserved. Reproduction in whole or in part without written permission is prohibited. Sony, CineMotion, Hi-Scan, Jog Dial, Precision Drive, Memory Stick, Hi-Scan, 1080i, DRC, Digital Reality
Creation, Trinitron, DynaBlack, HD Detailer, Uniform Brightness Screen, MicroFocus, ClearEdge and WEGA are trademarks of Sony. Dolby Digital is a registered trademark of Dolby Laboratories Licensing Corporation. dts is a
registered trademark of Digital Theater Systems, Inc. All other trademarks and logos are property of their respective owners.
*All Sony digital still cameras and camcorders except models DSCD-700, DSCD-770, DCR-TRV900, and DSR-PD100A store images on a Memory Stick in the DCF file format, which is required for playback on these televi-
sions. If the image file is re-named or manipulated, the DCF file format must be restored before playback is possible. Images captured on all other digital still cameras and camcorders will need to be formatted on a PC to the
DCF file format (with third party software not supplied with the television) before they can be viewed.
Component Video Inputs (Y/Pb/Pr) Delivers optimum picture
quality by supplying sperate connections from luminance (Y), blue
color difference (Pb) and red color difference (Pr). Ideal for DVD
players and digital television (DTV) set top receiver/decoders.
DVI-HDTV Interface (Digital Visual Interface) Has been
added for the latest generation in high definition television connec-
tivity. A single wire delivers a full digital uncompressed HD signal
that can be received from any DVI set top box.
