User Guide
Startup guide
Xperia™ T
LT30p
Sony Mobile Communications AB
SE-221 88 Lund, Sweden
www.sonymobile.com
1263-5432.1
To view the CE mark
1
2
3
4
1Open the memory card and the micro SIM
card cover.
2Insert the tip of a pen or a similar object into
the hole, then drag out the tray.
3Open the peel & read label to view the CE
mark.
Phone basics
Phone overview
2 34
567
8
9
10
11
12
1
13
14
15
16
17
18
19
20
1. Notification LED
2. Light sensor
3. Proximity sensor 1
4. Proximity sensor 2
5. Ear speaker
6. Front camera lens
7. Headset connector
8. Power key
9. Volume/Zoom key
10. Camera key
11. Main microphone
12. Touchscreen
13. Second microphone
14. Camera lens
15. Camera LED light
16. Connector for
charger/USB cable
17. Speaker
18. SIM card slot
19. microSD™ card slot
20. SIM card/microSD™
card cover
Use the accessories provided with your phone,
or other compatible accessories, for optimal
performance.
Turning on the phone
To turn on the phone
Make sure that the battery is charged for at
least 30 minutes before you turn on the
phone for the first time.
1Press and hold down the power key on the
right side of the phone until the phone
vibrates.
2Wait a while for the phone to start.
Waking up the screen
To activate the screen
•Briefly press the power key .
To unlock the screen
•Drag to the right across the screen.
Using the keys
Back
•Go back to the previous screen
•Close the on-screen keypad, a dialog
box, an options menu, or the
Notification panel
Home
•Go to the Home screen
Task
•Tap to open a window showing your
most recently used applications and a
small apps bar
Set up your phone
What is Android™?
Android is your phone's operating system. Since
it's developed by Google™, your phone is
preloaded with several Google™ services, such as
Google Maps™ and Google™ web search. To use
some of the services provided by Google™, you
need a Google account.
What is different about Android?
Android™ is an open system, which means that
you're not limited to using applications and
services from only one provider.
Google™ account
With a Google™ account, you can use Gmail™ to
send emails, Google Talk™ to chat with friends,
and Google Play™ to download applications and
games, music, movies and books.
To set up a Google™ account in your phone
1From your Home screen, tap .
2Find and tap Settings > Accounts & sync > Add
account > Google.
3Follow the registration wizard to create a
Google™ account, or sign in if you already have
an account. Your phone is now ready to use with
Gmail™ , Google Talk™ and Google Calendar™.
You can also sign in or create a Google™
account from the setup guide the first time you
start your phone. Or you can go online and
create an account at
www.google.com/accounts.
Basic settings
The first time you start your phone, a setup guide
explains basic phone functions and helps you enter
essential settings. You can also access the setup
guide later.
To access the setup guide manually
1From the Home screen, tap .
2Find and tap Setup guide.
Transferring contacts
to your new phone
Transferring contacts to your new phone can
sometimes be complicated, but help is available.
You can transfer contacts from several phone
brands, including iPhone, Samsung, HTC and
Nokia.
You need:
•An Internet-connected PC running Windows®
•A USB cable for your old phone
•A USB cable for your new Android™ phone
•Your old phone
•Your new Android™ phone
If you don't have access to all of the items listed
above, go to www.sonymobile.com to find out
about other ways to transfer your contacts.
Get started transferring your
contacts
Use the PC Companion program to transfer your
contacts. It's free, and the installation files are
already saved on your new phone. PC Companion
also offers a range of other features, including help
to update your phone software.
To install PC Companion
1New phone: Turn on your new Android™ phone
and connect it to a PC using a USB cable.
2New phone: Tap Install to install PC Companion
on the PC.
3Computer: If a popup window appears, select
Run Startme.exe. In the new popup window that
appears, click Install to start the installation and
then follow the instructions to complete the
installation.
To transfer contacts to your new phone
using PC Companion
1Make sure that PC Companion is installed on
your PC.
2Open the PC Companion program on the PC,
then click Contacts Setup and follow the
instructions to transfer your contacts.
Welcome
Important information
Please read the Important information leaflet
before you use your mobile phone.
Assembly
To insert the memory card and the micro
SIM card
The memory card may not be included at
purchase in all markets.
July 5, 2012 13:49:00
LT30p__Booklet_EN_1263-5432.1.pdf 1 of 2
Finding your way
Home screen
Your phone Home screen is the equivalent of the
desktop on a computer. You can customise your
Home screen with widgets, shortcuts, folders,
themes, wallpaper and other items.
The Home screen extends beyond the regular
screen display width, so you need to flick left or
right to view content in one of the screen's four
extensions.
The items in the bar at the bottom of the screen are
always available for quick access.
To go to the Home screen
•Press .
To browse the Home screen
•Flick right or left.
To change your Home screen wallpaper
1Tap an empty area on your Home screen, then
tap .
2Tap Wallpaper and select an option.
Widgets
Widgets are small applications that you can use
directly on your Home screen. For example, the
Music player widget allows you to start playing
music directly.
Some widgets are resizable, so you can expand
them to view more content or shrink them to save
space on your Home screen.
Application screen
The Application screen, which you open from your
Home screen, contains the applications that come
installed with your phone as well as the
applications you download.
The Application screen extends beyond the regular
screen width, so you need to flick left and right to
view all content.
To open the Notification panel
•Drag the status bar downwards.
Phone settings menu
View and change your phone settings from the
Settings menu.
To access the phone settings
1From your Home screen, tap .
2Tap Settings.
You can also drag the status bar downwards
on the Home screen and tap to access
the phone settings.
More basics
Calling
To make a call by dialling
1From your Home screen, tap .
2Find and tap Phone.
3Enter the number of the recipient and tap Call. To
delete a number, tap .
To end a call
•Tap .
To answer a call
•Drag to the right across the screen.
Multimedia and text
messaging
To create and send a message
1From your Home screen, tap , then find and
tap .
2Tap .
3Tap , then select the desired recipients from
the Contacts list. If the recipient is not listed as a
contact, enter the contact's number manually
and tap .
4When you are finished adding recipients, tap
Done.
5Tap Write message and enter your message text.
6If you want to add a media file, tap and select
an option.
7To send the message, tap Send.
Troubleshooting
My phone is not responding
If your phone hangs, or if you cannot restart it
normally, you can force restart the phone.
To force the phone to restart
1Press and hold down both the volume up key
and the power key for five seconds.
2After your phone vibrates once, release the keys.
The phone restarts automatically.
Legal information
Sony LT30p
Google Play™ is not available in all countries. Some of the services
and features described in this Startup guide are not supported in all
countries/regions or by all networks and/or service providers in all
areas. Without limitation, this applies to the GSM International
Emergency Number 112. Please contact your network operator or
service provider to determine availability of any specific service or
feature and whether additional access or usage fees apply.
This Startup guide is published by Sony Mobile Communications AB
or its local affiliated company, without any warranty. Improvements
and changes to this Startup guide necessitated by typographical
errors, inaccuracies of current information, or improvements to
programs and/or equipment, may be made by Sony Mobile
Communications AB at any time and without notice. Such changes
will, however, be incorporated into new editions of this Startup
guide.
© 2012 Sony Mobile Communications AB. All rights reserved.
Publication number: 1263-5432.1
Your mobile phone has the capability to download, store and
forward additional content, e.g. ringtones. The use of such content
may be restricted or prohibited by rights of third parties, including
but not limited to restriction under applicable copyright laws. You,
and not Sony, are entirely responsible for additional content that you
download to or forward from your mobile phone. Prior to your use of
any additional content, please verify that your intended use is
properly licensed or is otherwise authorized. Sony does not
guarantee the accuracy, integrity or quality of any additional content
or any other third party content. Under no circumstances will Sony
be liable in any way for your improper use of additional content or
other third party content.
This Startup guide may reference services or applications provided
by third parties. Use of such programming or services may require
separate registration with the third party provider and may be
subject to additional terms of use. For applications accessed on or
through a third-party website, please review such websites’ terms of
use and applicable privacy policy in advance. Sony does not warrant
or guarantee the availability or performance of any third-party
websites or offered services.
See regulatory information such as the CE mark on the back of the
phone.
All product and company names mentioned herein are the
trademarks or registered trademarks of their respective owners. Any
rights not expressly granted herein are reserved. All other
trademarks are property of their respective owners.
Visit www.sonymobile.com for more information.
All illustrations are for illustration only and may not accurately depict
the actual phone.
This product is protected by certain intellectual property rights of
Microsoft. Use or distribution of such technology outside of this
product is prohibited without a license from Microsoft.
Get support
User guide
A User guide is available in the Help application in
your phone and at www.sonymobile.com.
Support in the phone
Get user support directly in your phone using the
Help application.
To access the Help application
1From your Application screen, find and tap .
2Find and tap the required support item.
Support on the web
Visit www.sonymobile.com to access a range of
support and get the most from your phone.
Customer support
Customer support – if all else fails. Access the
relevant support number at www.sonymobile.com
by clicking the Contact us link at the bottom of the
page. You can also find the relevant support
number in the supplied Important information
leaflet.
www.sonymobile.com
To open the Application screen
•From your Home screen, tap .
To open an application
•From your Home screen or the Application
screen, tap the application.
Applications
An application is a phone program that helps
you perform a task. For example, there are
applications to make calls, take photos and
download more applications.
Status and notifications
The status bar at the top of your screen shows
what's going on in your phone. For example,
new message and calendar notifications appear
here.
A notification light also gives you battery status
information and some notifications. For
example, a flashing blue light means there is a
new message or a missed call. The notification
light may not work when the battery level is low.
Checking notifications and
ongoing activities
You can drag down the status bar to open the
Notification panel and get more information. For
example, you can use the panel to open a new
message or view a calendar event. You can also
open some applications that run in the
background, such as the music player.
July 5, 2012 13:49:01
LT30p__Booklet_EN_1263-5432.1.pdf 2 of 2
FCC Statement
Declaration of Conformity
Sony LT30p
UMTS HSPA Band 1 2 4 5 8 GSM GPRS/EDGE
850/900/1800/1900
Important Information
United States & Canada
THIS PHONE MODEL HAS BEEN CERTIFIED IN
COMPLIANCE WITH THE GOVERNMENT’S REQUIREMENTS
FOR EXPOSURE TO RADIO WAVES.
The LT30p Series mobile phones have been designed to
comply with applicable safety requirements for exposure to
radio waves. Your wireless phone is a radio transmitter and
receiver. It is designed to not exceed the limits* of exposure to
radio frequency (RF) energy set by governmental authorities.
These limits establish permitted levels of RF energy for the
general population. The guidelines are based on standards
that were developed by international scientific organizations
through periodic and thorough evaluation of scientific studies.
The standards include a safety margin designed to assure the
safety of all individuals, regardless of age and health.
The radio wave exposure guidelines employ a unit of
measurement known as the Specific Absorption Rate (SAR).
Tests for SAR are conducted using standardized methods with
the phone transmitting at its highest certified power level in all
used frequency bands. While there may be differences
between the SAR levels of various phone models, they are all
designed to meet the relevant guidelines for exposure to radio
waves. For more information on SAR, please refer to the safe
and efficient use chapter in the User Guide.
The highest SAR value as reported to the authorities for this
phone model when tested for use by the ear is 1.07 W/kg*,
and when worn on the body is 0.88 W/kg* for speech and
1.12 W/kg* for data calls. For body-worn operation, the phone
has been tested when positioned a minimum of 15 mm from
the body without any metal parts in the vicinity of the phone or
when properly used with an appropriate Sony accessory and
worn on the body. For devices which include “WiFi hotspot”
functionality, SAR measurements for the device operating in
WiFi hotspot mode were taken using a separation distance of
2
10mm. Use of third-party accessories may result in different
SAR levels than those reported.
**Before a phone model is available for sale to the public in
the US, it must be tested and certified by the Federal
Communications Commission (FCC) that it does not exceed
the limit established by the government-adopted requirement
for safe exposure*. The tests are performed in positions and
locations (i.e., by the ear and worn on the body) as required by
the FCC for each model. The FCC has granted an Equipment
Authorization for this phone model with all reported SAR levels
evaluated as in compliance with the FCC RF exposure
guidelines. While there may be differences between the SAR
levels of various phones, all mobile phones granted an FCC
equipment authorization meet the government requirement for
safe exposure. SAR information on this phone model is on file
at the FCC and can be found under the Display Grant section
of http://www.fcc.gov/oet/fccid after searching on FCC
ID PY7PM-0030. Additional information on SAR can be found
on the Cellular Telecommunications & Internet Association
(CTIA) website at http://www.phonefacts.net.
* In the United States and Canada, the SAR limit for mobile
phones used by the public is 1.6 watts/kilogram (W/kg)
averaged over one gram of tissue. The standard incorporates a
margin of safety to give additional protection for the public and
to account for any variations in measurements.
**This paragraph is only applicable to authorities and
customers in the United States.
3
Renseignements importants
États-Unis et Canada
CE MODÈLE DE TÉLÉPHONE A ÉTÉ CERTIFIÉ CONFORME
AUX EXIGENCES GOUVERNEMENTALES RELATIVES À
L'EXPOSITION AUX ONDES RADIOÉLECTRIQUES.
Les téléphones mobiles de la LT30p ont été conçus pour
répondre aux normes de sécurité en vigueur en matière
d'exposition aux ondes radioélectriques. Votre téléphone sans fil
est un émetteur et un récepteur radio. Il est conçu de manière à
ne pas dépasser les limites* d'exposition à l'énergie des
fréquences radio (RF) établies par les autorités
gouvernementales. Ces limites fixent les niveaux maximaux
d'énergie RF auxquels peut être soumis le grand public. Ces
lignes directrices sont basées sur des normes qui ont été
élaborées par des organisations scientifiques internationales par
le biais d'évaluations périodiques et approfondies des études
scientifiques. Ces normes prévoient une marge de sécurité visant
à assurer la protection de tous les individus, peu importe leur
âge et leur état de santé.
Les lignes directrices relatives à l'exposition aux ondes
radioélectriques utilisent une unité de mesure appelée « Taux
d'absorption spécifique » (TAS). Les tests de TAS sont effectués
selon des méthodes standardisées dans lesquelles le téléphone
émet dans toutes les bandes de fréquences utilisées, à la plus
forte puissance pour laquelle il a été homologué. Bien que le
TAS puisse être différent d'un modèle de téléphone à un autre,
tous les appareils sont conçus pour respecter les lignes
directrices relatives aux ondes radioélectriques. Pour en savoir
plus sur le TAS, reportez-vous au chapitre sur l'utilisation
efficace et sans danger du guide de l'utilisateur.
Le TAS le plus élevé relevé par les autorités pour ce modèle de
téléphone est de 1.07 W/kg* lorsqu'il est testé en utilisation près
de l'oreille, et de 0.88 W/kg* pour les appels vocaux et de
1.12 W/kg* pour les transmissions de données lorsqu'il est porté
sur le corps. En mode d’utilisation porté sur le corps, le
téléphone a été testé lorsqu’il est à au moins 15 mm du corps et
4
à l’écart de toute pièce en métal, ou lorsqu’il est utilisé de façon
adéquate avec un accessoire Sony et porté sur le corps. Pour
les appareils munis de la fonctionnalité « point d'accès WiFi »,
les mesures du TAS de l'appareil en mode WiFi ont été prises à
une distance de sécurité de 10 mm. L'utilisation d'accessoires
tiers peut produire des niveaux de TAS différents de ceux
relevés.
**Avant qu'un modèle de téléphone ne soit mis en vente
auprès du public aux États-Unis, la Commission fédérale des
communications (CFC) doit le tester et certifier qu'il respecte les
limites fixées dans les exigences gouvernementales d'exposition
sans danger*. Pour chaque modèle, les tests sont effectués en
position et aux endroits d'usage (c.-à-d. près de l'oreille et porté
sur le corps), tel que requis par la CFC. La CFC a accordé une
autorisation d'équipement pour ce modèle de téléphone, après
que tous les niveaux de TAS indiqués aient été évalués et
considérés conformes aux lignes directrices de la CFC en
matière d'exposition aux radiofréquences. Même s'il peut y avoir
des différences entre les niveaux de TAS des différents
téléphones, tous les téléphones mobiles auxquels la CFC a
accordé une autorisation d'équipement répondent aux normes
gouvernementales en matière d'exposition sans danger. La CFC
conserve dans ses dossiers l'information relative aux TAS relevés
pour ce modèle de téléphone. Vous pouvez la consulter au
http://www.fcc.gov/oet/fccid sous la rubrique « Display Grant »,
après avoir effectué une recherche sur CFC ID PY7PM-0030.
Vous trouverez des renseignements supplémentaires concernant
le TAS sur le site Web de la Cellular Telecommunications &
Internet Association (CTIA) au http://www.phonefacts.net.
* Aux États-Unis et au Canada, la limite de TAS des
téléphones mobiles utilisés par le public est de 1,6 watt/kg
(W/kg) en moyenne sur un gramme de tissus. Cette norme
comporte une marge importante de sécurité afin d'assurer une
protection supplémentaire et de tenir compte de toute variation
dans les mesures.
**Ce paragraphe ne concerne que les autorités et les clients
des États-Unis.
5
Información importante
Estados Unidos y Canadá
ESTE MODELO DE TELÉFONO HA SIDO CERTIFICADO
CONFORME A LOS REQUISITOS GUBERNAMENTALES PARA
LA EXPOSICIÓN A ONDAS DE RADIO.
Los teléfonos móviles de la Serie LT30p han sido diseñados
según los requisitos de seguridad aplicables para la exposición a
ondas de radio. Su teléfono inalámbrico es un transmisor y
receptor de radio. Está diseñado para no superar los límites* de
exposición a energía de radiofrecuencia (RF) fijados por las
autoridades gubernamentales. Estos límites establecen los
niveles permitidos de energía de RF para la población general.
Las especificaciones se basan en los estándares desarrollados
por organizaciones científicas internacionales mediante
evaluaciones periódicas y minuciosas de estudios científicos.
Los estándares incluyen un margen de seguridad destinado a
garantizar la seguridad de todas las personas,
independientemente de la edad y de la salud.
Las especificaciones de la exposición a ondas de radio
emplean una unidad de medida conocida como la Tasa
específica de absorción (SAR, por su sigla en inglés). Las
pruebas de SAR se llevan a cabo mediante el uso de métodos
estandarizados con la transmisión telefónica al más alto nivel de
energía registrado en todas las bandas de frecuencia utilizadas.
Aunque es posible que haya diferencias entre los niveles de SAR
de los diferentes modelos de teléfonos, todos están diseñados
para cumplir con las especificaciones correspondientes de la
exposición a ondas de radio. Para obtener más información
sobre SAR, consulte el capítulo sobre uso seguro y eficaz que se
encuentra en la Guía del usuario.
Según se reportó a las autoridades, el valor más alto de SAR
de este modelo de teléfono cuando se probó usándolo cerca del
oído es de 1.07 W/kg* y al usarlo en el cuerpo es de 0.88 W/kg*
para hablar y 1.12 W/kg* para llamadas de datos. Para su uso
cerca del cuerpo, el teléfono ha sido probado para su
funcionamiento a una distancia mínima de 15 mm (0,59 pulg.)
6
del cuerpo, sin que haya piezas metálicas cerca del teléfono o
cuando se utiliza correctamente con el accesorio adecuado
Sony. En lo que respecta a los dispositivos que cuentan con la
funcionalidad “Zona activa WiFi”, las medidas SAR del
dispositivo que funciona, en modo de zona activa WiFi, se
tomaron mediante el uso de una distancia de separación de 10
mm. El uso de accesorios de terceros puede resultar en niveles
de SAR diferentes a aquellos que se reportaron.
**Antes de que un modelo de teléfono se encuentre disponible
para la venta al público en los Estados Unidos, la Comisión
federal de telecomunicaciones (FCC) debe aprobarlo y certificar
que no supera el límite establecido por el requisito adoptado por
el gobierno para una exposición segura*. Las pruebas se llevan a
cabo en posiciones y ubicaciones (es decir, cerca del oído y
cerca del cuerpo) según lo requiere la FCC para cada modelo.
La FCC ha otorgado una Autorización de equipo para este
modelo de teléfono con todos los niveles de SAR reportados, los
cuales fueron evaluados conforme a las especificaciones de
exposición a RF de la FCC. Aunque es posible que haya
diferencias entre los niveles de SAR de los diferentes teléfonos,
todos los teléfonos móviles que cuentan con una autorización de
equipo de la FCC cumplen con los requisitos gubernamentales
para la exposición segura. La información sobre SAR de este
modelo de teléfono está archivada en la FCC y puede
encontrarla en la sección Display Grant (Mostrar subvención) en
http://www.fcc.gov/oet/fccid después de buscar la
ID PY7PM-0030 de la FCC. Puede encontrar información
adicional sobre SAR en el sitio Web de la Asociación de
Telecomunicaciones Celulares e Internet (CTIA) en
http://www.phonefacts.net.
* En los Estados Unidos y Canadá, el límite de SAR de los
teléfonos móviles utilizados por el público es de 1.6
watts/kilogramo (W/kg) promediados sobre un gramo de tejido.
El estándar incluye un margen de seguridad para proporcionarle
una protección adicional al público y para tomar en cuenta
cualquier variación en las medidas.
7
**Este párrafo se aplica únicamente a autoridades y clientes de
los Estados Unidos.
8
Important Information
Latin & South America
Radio wave exposure and Specific Absorption Rate (SAR)
information
The LT30p Series mobile phones have been designed to
comply with applicable safety requirements for exposure to
radio waves. These requirements are based on scientific
guidelines that include safety margins designed to assure the
safety of all persons, regardless of age and health.
The radio wave exposure guidelines employ a unit of
measurement known as the Specific Absorption Rate, or SAR.
Tests for SAR are conducted using standardised methods with
the phone transmitting at its highest certified power level in all
used frequency bands.
While there may be differences between the SAR levels of
various phone models, they are all designed to meet the
relevant guidelines for exposure to radio waves.
For more information on SAR, please refer to the safety
chapter in the User Guide.
SAR data information for residents in countries that have
adopted the SAR limit recommended by the International
Commission on Non-Ionizing Radiation Protection (ICNIRP),
which is 2 W/kg averaged over ten (10) gram of tissue (for
example European Union, Japan, Brazil and New Zealand):
The highest SAR value for this model phone when tested by
Sony for use at the ear is 0.85 W/kg (10g).
9
Información importante
Latinoamérica y América del Sur
Información acerca de la exposición a ondas de radio y la
Tasa específica de absorción (SAR)
El teléfono móvil LT30p ha sido diseñado para cumplir con los
requisitos de seguridad aplicables de exposición a las ondas de
radio. Dichos requisitos se basan en directrices científicas que
establecen márgenes de seguridad con el fin de evitar perjuicos
a todas las personas, independientemente de su edad o estado
de salud.
Las directrices de exposición a ondas de radio utilizan una
unidad de medida denominada coeficiente de absorción
específica o SAR. Las pruebas de SAR se líevan a cabo
utilizando métodos normalizados, con el teléfono transmitiendo
en el nivel más elevado de potencia autoridado en todas las
bandas de frecuencia utilizadas.
Aunque puede existir diferencias entre los niveles de SAR de
diferentes modelos de teléfono, todos han sido diseñados para
cumplir las directrices pertinentes sobre exposición a ondas de
radio.
Para obtener más información sobre el SAR, consulte el
capítulo sobre seguridad en la guía del usuario.
Información sobre datos de SAR para residentes de países en
los que se haya adoptado el limite de SAR recomendado por la
International Commission on Non-Ionizing Radiation Protection
(ICNIRP, Comisión internacional de protección contra la
radiación no ionizantes (ICNIRP, International Commission on
Non-Ionizing Radiation Protection), es 2 W/kg promedio por
cada diez (10) gramos de tejido (por ejemplo, la Unión Europea,
Japón, Brasil y Nueva Zelanda):
El valor de SAR más elevado para este modelo de teléfono
cuando Sony realizó la prueba para su uso en la oreja era de
0,85 W/kg (10g).
10
Informação importante
América do Sul e Latina
Informações sobre SAR (Taxa de Absorção Específica) e
exposição à radiofreqüência
O celular LT30p foi projetado para cumprir os requisitos de
segurança aplicáveis para exposição à radiofreqüência. Esses
requisitos têm como base diretrizes científicas que incluem as
margens de segurança para garantir a segurança de todas as
pessoas, independentemente da idade e da saúde.
As diretrizes de exposição à radiofreqüência usam uma
unidade de medida conhecida como SAR ou Taxa de Absorção
Específica. Os testes de SAR são conduzidos por métodos
padronizados com a transmissão telefônica em seu nível
certificado de energia mais alto em todas as faixas de freqüência
usadas.
Embora possa haver diferenças entre os níveis de SAR de
vários modelos de telefone, todos foram projetados para atender
as diretrizes relevantes de exposição à radiofreqüência.
Para obter mais informações sobre SAR, consulte o capítulo
de segurança do Guia do Usuário.
Informações sobre os dados de SAR para moradores de
países que adotaram o limite SAR recomendado pelo ICNIRP
(International Commission on Non-Ionizing Radiation Protection)
que é o limite médio de 2 W/kg em dez (10) gramas de tecido
(por exemplo, União Européia, Japão, Brasil e Nova Zelândia).
Quando testado pela Sony, o valor de SAR mais alto para este
modelo de telefone para uso junto ao ouvido foi de
0,85 W/kg (10g).
11
FCC Statement
This device complies with Part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) This device must accept any interference received,
including interference that may cause undesired operation.
Any change or modification not expressly approved by Sony
may void the user's authority to operate the equipment.
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and
receiver.
•Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for
help.
12
Industry Canada Statement
This device complies with RSS-210 of Industry Canada.
Operation is subject to the following two conditions: (1) this
device may not cause interference, and (2) this device must
accept any interference, including interference that may cause
undesired operation of the device.
This Class B digital apparatus complies with Canadian
ICES-003.
Cet appareil numérique de la classe B est conforme à la
norme NMB-003 du Canada.
Avis d’industrie Canada
Le présent appareil est conforme aux CNR d'Industrie Canada
applicables aux appareils radio exempts de licence.
L'exploitation est autorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et, and (2)
l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible
d'en compromettre le fonctionnement.
13
Declaration of Conformity for LT30p
We, Sony Mobile Communications AB of
Nya Vattentornet
SE-221 88 Lund, Sweden
declare under our sole responsibility that our product
Sony type PM-0030-BV
and in combination with our accessories, to which this
declaration relates is in conformity with the appropriate
standards EN 301 511:V9.0.2, EN 301 908-1:V5.2.1,
EN 301 908-2:V5.2.1, EN 300 328:V1.7.1, EN 300 440-2:V1.4.1,
EN 301 489-3:V1.4.1, EN 301 489-7:V1.3.1, EN 301 489-17:V2.1.1,
EN 301 489-24:V1.5.1, EN 301 893: V1.6.1,
EN 302 291-2:V1.1.1, EN 62 209-1:2006 and
EN 60 950-1:2006+A11:2009+A1:2010+A12:2011 following the
provisions of, Radio Equipment and Telecommunication
Terminal Equipment directive 1999/5/EC.
Lund, August 2012
Pär Thuresson,
Quality Officer, Head of Quality & Validation
We fulfil the requirements of the R&TTE Directive (1999/5/EC).
Ce produit est conforme aux directives de R&TTE (1999/5/EC).
Cumplimos con los requisitos de la Directiva R&TTE – Normas
sobre equipos de terminales de radio y telecomunicaciones
(1999/5/EC).
14
Atendemos aos requisitos da Diretriz R&TTE (1999/5/EC).
15
www.sonymobile.com
Sony Mobile Communications AB
SE-221 88 Lund, Sweden
1263-8011.1
Important information
Sony Consumer Web site
At www.sonymobile.com/support there is a support
section where help and tips are only a few clicks away.
Here you will find the latest computer software updates
and tips on how to use your product more efficiently.
Service and support
You have access to a portfolio of exclusive service
advantages such as:
•Global and local Web sites providing support.
•A global network of Contact Centers.
•An extensive network of Sony service partners.
•A warranty period. Learn more about the warranty
conditions in theLimited warrantysection.
At www.sonymobile.com/support, you can find the
latest support tools and information. For operator-
specific services and features, please contact your
network operator.
You can also contact our Contact Centers. If your
country/region is not represented in the list below,
please contact your local dealer. (Calls are charged
according to national rates, including local taxes,
unless the phone number is a toll-free number.)
If your product needs service, please contact the
dealer from whom it was purchased, or one of our
service partners. For warranty claims, save proof of
purchase.
Guidelines for Safe and Efficient Use
Please follow these guidelines. Failure to do so
might entail a potential health risk or product
malfunction. If in doubt as to its proper function, have
2
the product checked by a certified service partner
before charging or using it.
Recommendations for care and safe use of our
products
•Handle with care and keep in a clean and dust-free
place.
•Warning! May explode if disposed of in fire.
•Do not expose to liquid or moisture or excess
humidity.
•For optimum performance, the product should
not be operated in temperatures below
-10°C(+14°F) or above +45°C(+113°F). Do not expose
the battery to temperatures above +60°C(+140°F).
•Do not expose to flames or lit tobacco
products.
•Do not drop, throw or try to bend the product.
•Do not paint or attempt to disassemble or
modify the product. Only Sony authorised
personnel should perform service.
•Consult with authorised medical staff and the
instructions of the medical device manufacturer
before using the product near pacemakers or other
medical devices or equipment.
•Discontinue use of electronic devices, or disable the
radio transmitting functionality of the device, where
required or requested to do so.
•Do not use where a potentially explosive atmosphere
exists.
•Do not place the product, or install wireless
equipment, in the area above an air bag in a car.
3
www.sonymobile.com
Sony Mobile Communications AB
SE-221 88 Lund, Sweden
•Caution: Cracked or broken displays may create
sharp edges or splinters that could be harmful upon
contact.
•Do not use the Bluetooth Headset in positions where
it is uncomfortable or will be subject to pressure.
Children
Warning! Keep out of the reach of children. Do
not allow children to play with mobile phones or
accessories. They could hurt themselves or others.
Products may contain small parts that could become
detached and create a choking hazard.
Power supply (Charger)
Connect the charger to power sources as marked on
the product. Do not use outdoors or in damp areas. Do
not alter or subject the cord to damage or stress.
Unplug the unit before cleaning it. Never alter the plug.
If it does not fit into the outlet, have a proper outlet
installed by an electrician. When a power supply is
connected there is a small drain of power. To avoid
this small energy waste, disconnect the power supply
when the product is fully charged. Use of charging
devices that are not Sony branded may pose increased
safety risks.
Battery
New or idle batteries can have short-term reduced
capacity. Fully charge the battery before initial use.
Use for the intended purpose only. Charge the battery
in temperatures between +5°C(+41°F) and
+45°C(+113°F). Do not put the battery into your mouth.
Do not let the battery contacts touch another metal
4
object. Turn off the product before removing the
battery. Performance depends on temperatures, signal
strength, usage patterns, features selected and voice
or data transmissions. Only Sony service partners
should remove or replace built-in batteries. Use of
batteries that are not Sony branded may pose
increased safety risks. Replace the battery only with
another Sony battery that has been qualified with the
product per the standard IEEE-1725. Use of an
unqualified battery may present a risk of fire,
explosion, leakage or other hazard.
Personal medical devices
Mobile phones may affect implanted medical
equipment. Reduce risk of interference by keeping a
minimum distance of 15 cm(6 inches) between the
phone and the device. Use the phone at your right ear.
Do not carry the phone in your breast pocket. Turn off
the phone if you suspect interference. For use in
proximity to personal medical devices, please consult
a physician and the device manufacturer.
Driving
Some vehicle manufacturers forbid the use of phones
in their vehicles unless a handsfree kit with an external
antenna supports the installation. Check with the
vehicle manufacturer's representative to be sure that
the mobile phone or Bluetooth handsfree will not affect
the electronic systems in the vehicle. Full attention
should be given to driving at all times and local laws
and regulations restricting the use of wireless devices
while driving must be observed.
5
GPS/Location based functions
Some products provide GPS/Location based
functions. Location determining functionality is
provided “As is” and “With all faults”. Sony does not
make any representation or warranty as to the
accuracy of such location information.
Use of location-based information by the device may
not be uninterrupted or error free and may additionally
be dependent on network service availability. Please
note that functionality may be reduced or prevented in
certain environments such as building interiors or areas
adjacent to buildings.
Caution: Do not use GPS functionality in a manner
which causes distraction from driving.
Emergency calls
Calls cannot be guaranteed under all conditions. Never
rely solely upon mobile phones for essential
communication. Calls may not be possible in all areas,
on all networks, or when certain network services
and/or phone features are used.
Antenna
Use of antenna devices not marketed by Sony could
damage the phone, reduce performance, and produce
SAR levels above the established limits. Do not cover
the antenna with your hand as this affects call quality,
power levels and can shorten talk and standby times.
Radio Frequency (RF) exposure and Specific
Absorption Rate (SAR)
When the phone or Bluetooth handsfree is turned on, it
emits low levels of radio frequency energy.
International safety guidelines have been developed
6
through periodic and thorough evaluation of scientific
studies. These guidelines establish permitted levels of
radio wave exposure. The guidelines include a safety
margin designed to assure the safety of all persons
and to account for any variations in measurements.
Specific Absorption Rate (SAR) is used to measure
radio frequency energy absorbed by the body when
using a mobile phone. The SAR value is determined at
the highest certified power level in laboratory
conditions, but because the phone is designed to use
the minimum power necessary to access the chosen
network, the actual SAR level can be well below this
value. There is no proof of difference in safety based
on difference in SAR value.
Products with radio transmitters sold in the US must
be certified by the Federal Communications
Commission (FCC). When required, tests are
performed when the phone is placed at the ear and
when worn on the body. For body-worn operation, the
phone has been tested when positioned a minimum of
15 mm from the body without any metal parts in the
vicinity of the phone or when properly used with an
appropriate Sony accessory and worn on the body.
When operating with “Hotspot” functionality engaged,
a separation distance of 10mm was used.
For more information about SAR and radio frequency
exposure, go to: www.sonymobile.com/health.
Flight mode
Bluetooth and WLAN functionality, if available in the
device, can be enabled in Flight mode but may be
prohibited onboard aircraft or in other areas where
radio transmissions are prohibited. In such
7
environments, please seek proper authorisation before
enabling Bluetooth or WLAN functionality even in Flight
mode.
Malware
Malware (short for malicious software) is software that
can harm the mobile phone or other computers.
Malware or harmful applications can include viruses,
worms, spyware, and other unwanted programs. While
the device does employ security measures to resist
such efforts, Sony does not warrant or represent that
the device will be impervious to the introduction of
malware. You can however reduce the risk of malware
attacks by using care when downloading content or
accepting applications, refraining from opening or
responding to messages from unknown sources, using
trustworthy services to access the Internet, and only
downloading content to the mobile phone from known,
reliable sources.
Accessories
Use only Sony branded original accessories and
certified service partners. Sony does not test third-
party accessories. Accessories may influence RF
exposure, radio performance, loudness, electric safety
and other areas. Third-party accessories and parts
may pose a risk to your health or safety or decrease
performance.
Accessible Solutions/Special Needs
In the US, compatible Sony Xperia phones may offer
compatibility with TTY terminals (with use of necessary
accessory). For more information call the Sony Special
8
Needs Center on 877 878 1996 (TTY) or 877 207 2056
(voice), or go to www.sonyericsson-snc.com.
Disposal of old electrical and electronic
equipment and battery
This symbols on the electronic product or on its
packaging indicates that the electronic product
inclusive the battery should not be treated as
household waste. Instead it should be handed over to
the applicable collection point for the recycling of
electrical and electronic equipment. Do not attempt to
remove internal batteries. Internal batteries shall be
removed only by a waste treatment facility or trained
service professional.
By ensuring this product is disposed of correctly, you
will help prevent potential negative consequences for
the environment and human health, which could
otherwise be caused by inappropriate waste handling
of this product. The recycling of materials will help to
conserve natural resources. For more detailed
information about recycling of this product, please
contact your local city office, your household waste
disposal service or the shop where you purchased the
product, by calling a Sony Contact Center or at
www.sonymobile .com/recycling.
Memory card
If the product comes complete with a removable
memory card, it is generally compatible with the
handset purchased but may not be compatible with
other devices or the capabilities of their memory cards.
Check other devices for compatibility before purchase
or use. If the product is equipped with a memory card
9
reader, check memory card compatibility before
purchase or use.
Memory cards are generally formatted prior to
shipping. To reformat the memory card, use a
compatible device. Do not use the standard operating
system format when formatting the memory card on a
PC. For details, refer to the operating instructions of
the device or contact customer support.
SIM card
If your phone is equipped with a standard-sized SIM
card slot, inserting an incompatible SIM card (for
example, a micro SIM card, a micro SIM card with a
non-Sony adapter, or a standard SIM card cut into a
micro SIM card size) in the SIM card slot may damage
your SIM card or your phone permanently. Sony does
not warrant and will not be responsible for any damage
caused by use of incompatible or modified SIM cards.
For Devices Supporting 3D Viewing capabilities
In viewing 3D images shot with this phone on a 3D-
compatible monitor, you may experience discomfort in
the form of eye strain, fatigue, or nausea. To prevent
these symptoms, we recommend that you take regular
breaks. However, you need to determine for yourself
the length and frequency of breaks you require, as they
vary according to the individual. If you experience any
type of discomfort, stop viewing the 3D images until
you feel better, and consult a physician as necessary.
Also refer to the operating instructions supplied with
the device or software you have connected or are
using with this phone. Note that a child’s eyesight is
still at the development stage (particularly children
10
below the age of 6). Consult a pediatrician or
ophthalmologist before letting your child view 3D
images, and make sure he/she observes the above
precautions when viewing such images.
Warning!
If the device requires an adapter for insertion into the
handset or another device, do not insert the card
directly without the required adapter.
Precautions on memory card use
•Do not expose the memory card to moisture.
•Do not touch terminal connections with your hand or
any metal object.
•Do not strike, bend, or drop the memory card.
•Do not attempt to disassemble or modify the memory
card.
•Do not use or store the memory card in humid or
corrosive locations or in excessive heat such as a
closed car in summer, in direct sunlight or near a
heater, etc.
•Do not press or bend the end of the memory card
adapter with excessive force.
•Do not let dirt, dust, or foreign objects get into the
insert port of any memory card adapter.
•Check you have inserted the memory card correctly.
•Insert the memory card as far as it will go into any
memory card adapter needed. The memory card may
not operate properly unless fully inserted.
•We recommend that you make a backup copy of
important data. We are not responsible for any loss or
damage to content you store on the memory card.
11
•Recorded data may be damaged or lost when you
remove the memory card or memory card adapter,
turn off the power while formatting, reading or writing
data, or use the memory card in locations subject to
static electricity or high electrical field emissions.
Protection of personal information
Erase personal data before disposing of the product.
To delete data, perform a master reset. Deleting data
from the phone memory does not ensure that it cannot
be recovered. Sony does not warrant against recovery
of information and does not assume responsibility for
disclosure of any information even after a master reset.
Loudness warning!
Avoid volume levels that may be harmful to your
hearing.
End User Licence Agreement
Software delivered with this device and its media is
owned by Sony Mobile Communications AB, and/or its
affiliated companies and its suppliers and licensors.
Sony grants you a non-exclusive limited licence to
use the Software solely in conjunction with the Device
on which it is installed or delivered. Ownership of the
Software is not sold, transferred or otherwise
conveyed.
Do not use any means to discover the source code
or any component of the Software, reproduce and
distribute the Software, or modify the Software. You
are entitled to transfer rights and obligations to the
Software to a third party, solely together with the
Device with which you received the Software, provided
12
the third party agrees in writing to be bound by the
terms of this Licence.
This licence exists throughout the useful life of this
Device. It can be terminated by transferring your rights
to the Device to a third party in writing.
Failure to comply with any of these terms and
conditions will terminate the licence immediately.
Sony and its third party suppliers and licensors retain
all rights, title and interest in and to the Software. To
the extent that the Software contains material or code
of a third party, such third parties shall be beneficiaries
of these terms.
This licence is governed by the laws of Sweden.
When applicable, the foregoing applies to statutory
consumer rights.
In the event Software accompanying or provided in
conjunction with your device is provided with
additional terms and conditions, such provisions shall
also govern your possession and usage of the
Software.
Export regulations
Export regulations: Goods delivered under this
Agreement may be the subject to import and export
regulations of the European Union, the United States
and other countries. Purchaser will comply with these
applicable laws and regulations and will obtain and
maintain any export and import license required for the
delivery of goods to Purchaser under this Agreement.
Without limiting the foregoing, and as an example,
Purchaser will not knowingly export or re-export goods
to destinations identified pursuant to Articles in
13
Chapter II of European Council Regulation (EC)
428/2009 and specifically, and without limitation,
Purchaser will also comply with U.S. government
Export Administration Regulations (“EAR”, 15 C.F.R.
§§ 730-774, http://www.bis.doc.gov/) administered by
Department of Commerce, Bureau of Industry and
Security and economic sanctions regulations (30
C.F.R. §§ 500 et. seq., http://www.treas.gov/offices/
enforcement/ofac/) administered by the U.S.
Department of Treasury, Office of Foreign Assets
Control.
Limited Warranty
Sony Mobile Communications AB, SE-221 88 Lund,
Sweden, (Sony) or its local affiliated company,
provides this Limited Warranty for your mobile phone,
original accessory delivered with your mobile phone,
and/or your mobile computing product (hereinafter
referred to as “Product”).
Should your Product need warranty service, please
return it to the dealer from whom it was purchased, or
contact your local Sony Contact Center (national rates
may apply) or visit www.sonymobile.com to get further
information.
Our warranty
Subject to the conditions of this Limited Warranty,
Sony warrants this Product to be free from defects in
design, material and workmanship at the time of its
original purchase by a consumer. This Limited
Warranty will last for a period of one (1) year as from
the original date of purchase of the Product.
14
What we will do
If, during the warranty period, this Product fails to
operate under normal use and service, due to defects
in design, materials or workmanship, Sony authorised
distributors or service partners, in the country/region*
where you purchased the Product, will, at their option,
either repair or replace the Product in accordance with
the terms and conditions stipulated herein.
Sony and its service partners reserve the right to
charge a handling fee if a returned Product is found not
to be under warranty according to the conditions
below.
Please note that some of your personal settings,
downloads and other information may be lost when
your Sony Product is repaired or replaced. At present,
Sony may be prevented by applicable law, other
regulation or technical restrictions from making a
backup copy of certain downloads. Sony does not take
any responsibility for any lost information of any kind
and will not reimburse you for any such loss. You
should always make backup copies of all the
information stored on your Sony Product such as
downloads, calendar and contacts before handing in
your Sony Product for repair or replacement.
Conditions
1. This Limited Warranty is valid only if the original proof
of purchase for this Product issued by a Sony
authorised dealer specifying the date of purchase and
serial number**, is presented with the Product to be
repaired or replaced. Sony reserves the right to refuse
warranty service if this information has been removed
15
June 28, 2012 13:17:46
Legal-Leaflets---Generic_EN_1222-9266.9.pdf 1 of 2
1222-9266.10
or changed after the original purchase of the Product
from the dealer.
2. If Sony repairs or replaces the Product, the repair for
the defect concerned, or the replaced Product shall
be warranted for the remaining time of the original
warranty period or for ninety (90) days from the date
of repair, whichever is longer. Repair or replacement
may involve the use of functionally equivalent
reconditioned units. Replaced parts or components
will become the property of Sony.
3. This warranty does not cover any failure of the
Product due to normal wear and tear, or due to
misuse, including but not limited to use in other than
the normal and customary manner, in accordance
with the Sony instructions for use and maintenance of
the Product. Nor does this warranty cover any failure
of the Product due to accident, software or hardware
modification or adjustment, acts of God or damage
resulting from liquid.
A rechargeable battery can be charged and
discharged more than a hundred times. However, it
will eventually wear out – this is not a defect and
corresponds to normal wear and tear. When the talk-
time or standby time is noticeably shorter, it is time to
replace the battery. Sony recommends that you use
only batteries and chargers approved by Sony.
Minor variations in display brightness and colour
may occur between phones. There may be tiny bright
or dark dots on the display. It occurs when individual
dots have malfunctioned and can not be adjusted.
Two defective pixels are deemed acceptable.
16
Minor variations in camera image appearance may
occur between phones. This is nothing uncommon
and is not regarded as a defective camera module.
4. Since the cellular system on which the Product is to
operate is provided by a carrier independent from
Sony, Sony will not be responsible for the operation,
availability, coverage, services or range of that
system.
5. This warranty does not cover Product failures caused
by installations, modifications, or repair or opening of
the Product performed by a non-Sony authorised
person.
6. The warranty does not cover Product failures which
have been caused by use of accessories or other
peripheral devices which are not Sony branded
original accessories intended for use with the
Product.
7. Tampering with any of the seals on the Product will
void the warranty.
8. THERE ARE NO EXPRESS WARRANTIES, WHETHER
WRITTEN OR ORAL, OTHER THAN THIS PRINTED
LIMITED WARRANTY. ALL IMPLIED WARRANTIES,
INCLUDING WITHOUT LIMITATION THE IMPLIED
WARRANTIES OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE, ARE LIMITED TO
THE DURATION OF THIS LIMITED WARRANTY. IN
NO EVENT SHALL SONY OR ITS LICENSORS BE
LIABLE FOR INCIDENTAL OR CONSEQUENTIAL
DAMAGES OF ANY NATURE WHATSOEVER,
INCLUDING BUT NOT LIMITED TO LOST PROFITS
OR COMMERCIAL LOSS TO THE FULL EXTENT
THOSE DAMAGES CAN BE DISCLAIMED BY LAW.
17
Some countries/states do not allow the exclusion or
limitation of incidental or consequential damages, or
limitation of the duration of implied warranties, so the
preceding limitations or exclusions may not apply to
you.
The warranty provided does not affect the
consumer’s statutory rights under applicable
legislation in force, nor the consumer’s rights against
the dealer arising from their sales / purchase contract.
*Geographical scope of the warranty
If you have purchased your Product in a country
member of the European Economic Area (EEA) or in
Switzerland or the Republic of Turkey, and such
Product was intended for sale in the EEA or in
Switzerland or in Turkey, you can have your Product
serviced in any EEA country or in Switzerland or in
Turkey, under the warranty conditions prevailing in the
country in which you require servicing, provided that
an identical Product is sold in such country by an
authorised Sony distributor. To find out if your Product
is sold in the country you are in, please call the local
Sony Contact Center. Please observe that certain
services may not be available outside the country of
original purchase, for example, due to the fact that
your Product may have an interior or exterior which is
different from equivalent models sold in other
countries. Please note in addition that it may
sometimes not be possible to repair SIM-locked
Products.
Our goods come with guarantees that cannot be
excluded under the Australian Consumer Law. If you
purchased your product in Australia, you are entitled to
18
a replacement or refund for a major failure and
compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the
goods repaired or replaced if the goods fail to be of
acceptable quality and the failure does not amount to a
major failure. For warranty service in Australia, please
contact 1300 650 050 or Sony Service Centre, 320
Princes Hwy, ROCKDALE NSW 2216.
** In some countries/regions additional information
(such as a valid warranty card) may be requested.
Trademarks and acknowledgements
The Liquid Identity logo and Xperia are trademarks or
registered trademarks of Sony Mobile Communications
AB.
Sony is a trademark or a registered trademark of Sony
Corporation.
Ericsson is a trademark or registered trademark of
Telefonaktiebolaget LM Ericsson.
Bluetooth is a trademark or a registered trademark of
Bluetooth SIG Inc. and any use of such mark by Sony
is under license.
Other product and company names mentioned herein
may be the trademarks of their respective owners.
Any rights not expressly granted herein are reserved.
19
Anguilla 1-800-080-95
18 (Toll Free)
questions.CO@support.sonymo
bile.com
Antigua
and
Barbuda
1-800-081-95
18 (Toll Free)
questions.CO@support.sonymo
bile.com
Argentina 0800-333-74
27 (número
gratuito)
questions.CO@support.sonymo
bile.com
Australia 1300 650-050
(Toll Free)
questions.AU@support.sonymo
bile.com
The
Bahamas 1-800-205-60
62 (Toll Free)
questions.CO@support.sonymo
bile.com
Barbados 1-800-082-95
18 (Toll Free)
questions.CO@support.sonymo
bile.com
Belgique/
België 02-0745 1611 questions.BE@support.sonymo
bile.com
Belize AN 815, PIN
5597 (Toll
Free)
questions.CO@support.sonymo
bile.com
Bermuda 1-800-083-95
18 (Toll Free)
questions.CO@support.sonymo
bile.com
Bolivia 800-100-542
(número
gratuito)
questions.CO@support.sonymo
bile.com
Brasil 4001-0444
(Capitais e
regiões
questions.BR@support.sonymo
bile.com
20
metropolitana
s)
0800 884
0444 (Demais
regiões)
Canada 1 866 766
9374 (Toll
Free / sans
frais)
questions.CA@support.sonymo
bile.com
Cayman
Islands 1-800-084-95
18 (Toll Free)
questions.CO@support.sonymo
bile.com
Central
and
Southern
Africa
+27 11 506
0123
questions.CF@support.sonymo
bile.com
Česká
republika 844 550 055 questions.CZ@support.sonymo
bile.com
Chile 800-646-425
(número
gratuito)
questions.CO@support.sonymo
bile.com
Colombia 01800-0966-
080 (número
gratuito)
questions.CO@support.sonymo
bile.com
Costa
Rica 0 800 011
0400 (número
gratuito)
questions.CO@support.sonymo
bile.com
Danmark 3331 2828 questions.DK@support.sonymo
bile.com
Deutschla
nd 0180 534
2020
questions.DE@support.sonymo
bile.com
21
(ortsübliche
Gebühren)
Dominica 1-800-085-95
18 (Toll Free)
questions.CO@support.sonymo
bile.com
Ecuador 1-800-0102-5
0 (número
gratuito)
questions.CO@support.sonymo
bile.com
Eesti 06 032 032 questions.EE@support.sonymo
bile.com
Egypt/
رصم 16727 questions.EG@support.sonymo
bile.com
Ελλάδα 801 11 810 810
+30 210 899 19 19
(από κινητό
τηλέφωνο)
questions.GR@support.sonymo
bile.com
El
Salvador 800-6323
(número
gratuito)
questions.CO@support.sonymo
bile.com
España 902 180 576
(tarifa local)
questions.ES@support.sonymo
bile.com
France 09 69 32 21
21
09 69 32 21
22 (Xperia™
uniquement)
questions.FR@support.sonymo
bile.com
Guatemal
a1-800-300-00
57 (número
gratuito)
questions.CO@support.sonymo
bile.com
Haïti/Ayiti AN 193, PIN
5598 (numéro
gratuit /
questions.CO@support.sonymo
bile.com
22
nimewo
gratis)
Honduras AN 8000122,
PIN 5599
(número
gratuito)
questions.CO@support.sonymo
bile.com
Hong
Kong/香
港
+852 8203
8863
questions.HK@support.sonymo
bile.com
Hrvatska 062 000 000 questions.HR@support.sonymo
bile.com
India/भारत 1800 11 1800
(Toll Free)
+91 (011)
39011111
questions.IN@support.sonymob
ile.com
Indonesia +62 21 2935
7669
questions.ID@support.sonymob
ile.com
Ireland 1850 545 888
(Local rate)
questions.IE@support.sonymob
ile.com
Italia 06 48895206
(tariffa locale)
questions.IT@support.sonymob
ile.com
Jamaica 1-800-442-34
71 (Toll Free)
questions.CO@support.sonymo
bile.com
Κύπρος/
Kıbrıs
0800 90 909 questions.CY@support.sonymo
bile.com
Latvija 67 21 43 01 questions.LV@support.sonymo
bile.com
Lietuva 8 700 55030 questions.LT@support.sonymo
bile.com
23
Magyaror
szág 01 880 47 47 questions.HU@support.sonymo
bile.com
Malaysia 1
800-88-7666
questions.MY@support.sonymo
bile.com
Maroc/
+212 2 2958
344
questions.MA@support.sonymo
bile.com
México 0 1800 000
4722 (número
gratuito)
questions.MX@support.sonymo
bile.com
Nederland 0900
8998318
questions.NL@support.sonymo
bile.com
Nederland
se Antillen 001-866-509-
8660 (gratis
nummer)
questions.CO@support.sonymo
bile.com
New
Zealand 0800-100-15
0 (Toll Free)
questions.NZ@support.sonymo
bile.com
Nicaragua AN
1800-0166,
PIN 5600
(número
gratuito)
questions.CO@support.sonymo
bile.com
Norge 815 00 840
(lokaltakst)
questions.NO@support.sonymo
bile.com
Österreich 0810 200 245 questions.AT@support.sonymo
bile.com
Pakistan/
021 - 111 22
55 73
questions.PK@support.sonymo
bile.com
Panamá 00800-787-0
009 (número
gratuito)
questions.CO@support.sonymo
bile.com
24
Paraguay 009 800 54
20032
(número
gratuito)
questions.CO@support.sonymo
bile.com
Perú 0800-532-38
(número
gratuito)
questions.CO@support.sonymo
bile.com
Philippine
s/Pilipinas +632 479
9777 or 1800
1 853 7669
questions.PH@support.sonymo
bile.com
Polska +48 22 22 77
444
questions.PL@support.sonymo
bile.com
Portugal 808 204 466
(chamada
local)
questions.PT@support.sonymo
bile.com
República
Dominica
na
1-800-751-33
70 (número
gratuito)
questions.CO@support.sonymo
bile.com
România +40 21 401
0401
questions.RO@support.sonymo
bile.com
Saint Kitts
and Nevis 1-800-087-95
18 (Toll Free)
questions.CO@support.sonymo
bile.com
Saint
Vincent
and the
Grenadine
s
1-800-088-95
18 (Toll Free)
questions.CO@support.sonymo
bile.com
Schweiz/
Suisse/
Svizzera
0848 824 040 questions.CH@support.sonymo
bile .com
25
Singapore +65 6744
0733
questions.SG@support.sonymo
bile.com
Slovenia 0800 81291 questions.si@support.sonymobi
le.com
Slovensko 02 5443 6443 questions.SK@support.sonymo
bile.com
South
Africa 0861 632222 questions.ZA@support.sonymo
bile.com
South
Κorea/대
한민국
(+82) 1588
4170
questions.KO@support.sonymo
bile.com
Suomi 09 299 2000 questions.FI@support.sonymob
ile.com
Sverige 013 24 45 00
(lokal taxa)
questions.SE@support.sonymo
bile.com
Thailand 001 800 852
7663 or
02401 3030
questions.CO@support.sonymo
bile.com
Trinidad
and
Tobago
1-800-080-95
21 (Toll Free)
questions.CO@support.sonymo
bile.com
Türkiye +90 212 473
77 77
questions.TR@support.sonymo
bile.com
United
Kingdom 08705 237
237 (Local
rate)
questions.GB@support.sonymo
bile.com
United
States 1 866 766
9374
questions.US@support.sonymo
bile.com
26
Uruguay 000-401-787-
013 (número
gratuito)
questions.CO@support.sonymo
bile.com
Venezuela 0-800-1-00-2
250 (número
gratuito)
questions.CO@support.sonymo
bile.com
Việt Nam 1900 1525
(miễn phí)
questions.VN@support.sonymo
bile .com
България 0800 1 8778 questions.BG@support.sonymo
bile.com
Россия 8-800-10080
22
questions.RU@support.sonymo
bile.com
Україна +38 044 590
1515
questions.UA@support.sonymo
bile.com
+971 4 3919
880
questions.JO@support.sonymo
bile.com
+971 4 3919
880 (UAE)
questions.AE@support.sonymo
bile.com
+971 4 3919
880
questions.KW@support.sonymo
bile.com
800-8200-72
7
questions.SA@support.sonymo
bile.com
27
中国 +86 400 810
0000
questions.CN@sonymobile.com
台灣 +886 2
25625511
questions.TW@support.sonymo
bile.com
ไทย 02 2483 030 questions.TH@support.sonymo
bile.com
28
June 28, 2012 13:17:47
Legal-Leaflets---Generic_EN_1222-9266.9.pdf 2 of 2
