Contents

PY7-PM0944_user manual_0416

Device basics
2
6
5
4
7
3
1
1 NFC
2 Charging/Notification light
3 Nano SIM/Memory card slot
4 Power key/Fingerprint sensor
5 Volume/Zoom key
6 Camera key
7 Charger/USB cable port
In addition to using a single SIM card, the combined
SIM/Memory card holder allows you to use either an
additional SIM card or an additional memory card. It is
not possible to use two SIM cards and a memory card at
the same time.
To insert one or two nano SIM cards
12
1Using your fingernail, drag out the SIM/Memory card
holder.
2Firmly place the primary SIM card (SIM 1) in the correct
horizontal orientation in position (1) as shown in the
illustration.
3Firmly place the additional SIM card (SIM 2) in the
correct horizontal orientation in position (2) as shown in
the illustration.
4Gently push the holder into the slot until it fits into place.
To insert one nano SIM card and one
memory card
12
1Using your fingernail, drag out the SIM/Memory card
holder.
2Firmly place the SIM card in the correct horizontal
orientation in position (1) as shown in the illustration.
3Firmly place the memory card in the correct horizontal
orientation in position (2) as shown in the illustration.
4Gently push the holder into the slot until it fits into place.
To turn on the device
Make sure that the battery is charged for at least 30
minutes before you turn on the device for the first time.
1Press and hold down the power key until the device
vibrates.
2Wait a moment for the device to start.
To activate the screen
Briefly press the power key .
Screen protection
Before using your device, remove the protection film by
pulling up on the protruding tab.
It is recommended to protect your device with a Sony
branded screen cover or a protector intended for your
Xperia™ model. The use of third party screen protection
accessories may prevent your device from working correctly
by covering sensors, lenses, speakers, or microphones and
can invalidate the warranty.
Support for you
Access our support website directly on your device or visit
support.sonymobile.com
with any supported browser.
Support options include User guides, downloadable content,
troubleshooting tips and contact information.
Even if you don’t have a network connection, you can
access support contact information on your device.
Depending on the country or region where you purchased
your device, you can find this information directly in the
Support application.
To access the Support application
1From your Home screen, tap .
2Find and tap .
For the best support available, we recommend connecting
to the Internet when using the Support application.
Warranty, SAR and usage guidelines
For information about warranty, SAR (Specific Absorption
Rate) and safety guidelines, please read the Important
information provided under Settings > About phone > Legal
information on your device.
Dust and water protection
Your device is waterproof and protected against dust; all
ports and attached covers should be firmly closed. You
should not put the device completely under water or expose
it to sea water; salt water; chlorinated water; or liquids such
as drinks. Improper use will invalidate the warranty. Your
device has the Ingress Protection ratings IP65 and IP68. For
more information about IP ratings, visit
www.sonymobile.com/waterproof
.
Your capless USB port must be completely dry before a
cable can be connected. If your USB port gets wet, wipe it
dry with a microfibre cloth and shake it several times with
the USB port facing downwards. Repeat until no moisture
is visible in the USB port.
Transferring contacts and content
If you need help to transfer contacts, messages, photos or
other data from an old device to your new device, we
recommend that you use the Xperia™ Transfer application.
Visit
www.sonymobile.com/xperiatransfer
for more
information.
To view the CE mark
1Using your fingernail, drag out the nano SIM/Memory card
holder.
2Drag out the label tray in the same way.
The CE mark and FCC ID are displayed on the label tray.
To view the regulatory compliance mark
Open the phone dialer, then enter *#07#.
Legal information
Publication number: 1301-1424.1
This Startup guide is published by Sony Mobile Communications Inc. or its local affiliated company, without
any warranty. Improvements and changes to this Startup guide necessitated by typographical errors,
inaccuracies of current information, or improvements to programs and/or equipment, may be made by
Sony Mobile Communications Inc. at any time and without notice. Such changes will, however, be
incorporated into new editions of this Startup guide. All illustrations are for illustration only and may not
accurately depict the actual device.
See regulatory information such as the device CE mark in the relevant label tray in the device.
All product and company names mentioned herein are the trademarks or registered trademarks of their
respective owners. Any rights not expressly granted herein are reserved. Visit
www.sonymobile.com/global-
en/legal/
for more information.
Product compliance: This product has been manufactured by or on behalf of Sony Mobile Communications
Inc., 4-12-3 Higashi-Shinagawa, Shinagawa-ku, Tokyo, 140-0002 Japan. Inquiries related to product
compliance based on national legislation shall be addressed to Sony Mobile Quality Office, Sony Mobile
Communications Inc., 4-12-3 Higashi-Shinagawa, Shinagawa-ku, Tokyo, 140-0002 Japan. Should your
device need warranty service, please return it to the dealer from whom it was purchased or visit
support.sonymobile.com/contact
to contact your local Sony Mobile repair partner (national rates may
apply).
© 2016 Sony Mobile Communications Inc. All rights reserved.
Supported frequency bands
Some frequency bands might be turned off in certain markets or by certain operators.
F8132
UMTS HSPA+ 800 (Band VI), 800 (Band XIX), 850 (Band V), 900 (Band VIII), 1700 (Band IV), 1900 (Band II),
2100 (Band I) MHz GSM GPRS/EDGE 850, 900, 1800, 1900 MHz LTE (Bands 1, 2, 3, 4, 5, 7, 8, 12, 13,
17,19, 20, 26, 28, 29, 38, 39, 40, 41)
Startup guide
Xperia X Performance
F8132
Sony Mobile Communications Inc.
4-12-3 Higashi-Shinagawa, Shinagawa-ku, Tokyo, 140-0002 Japan
1301-1424.1
