Audio/Video Receiver
• 7 Channel Power Rating: 110W Per Channel x 7 (8 ohms 1 kHz, THD 0.7%)
100W x 7 (8 ohms 20Hz-20kHz, THD 0.09%)
• Dolby® Digital, Dolby® Digital EX, dts®, dts ES®, dts:Neo6®, Dolby® Pro Logic® II Decoding
• S-Video Up-Conversion from Composite Video
• Multi-Room Audio Output with Independant Source Selection
• Preprogrammed/Learning/Macro Remote Control
• Front Composite A/V and Optical Input
• 5.1 and 7.1 Multi-Channel Analog Inputs
• 2 Component Video Inputs: HD Pass (80 MHz)
Auto Channel Grouping Enjoy DVD movies that have the 5.1/6.1 audio converted to 7.1 channels. When a 5.1 channel mix is present,
auto channel grouping will route the discrete information for surround left/right directly to surround left/right outputs while adding a new
surround back left/right channel. When 6.1 channel mix is detected, auto channel grouping will route the discrete information for surround
left/right directly to surround left/right output while the 6th channel is duplicated by both surround back channels (left/right).
Dolby® Pro Logic® II Decoding Creating surround sound requires only a stereo source. Listening to the radio, a CD, or an old VCR tape
in full surround sound. Anything stereo can be converted to digital signal and distributed to your front, surround, subwoofer, and center
speakers.
Component Video Pass-Through In order to benefit from a progressive or satellite signal, you must use the component video inputs and
outputs. This utilizes 3 cables (red, green and blue) to assure proper color separation while more information passes to the display source.
Passing these signals through your receiver enables the user to simply switch the “function” on their receiver, and not worry about
changing any settings on the TV.
STR-DE897/B
Audio/Video Receiver
For more information:
http://www.sony.com/dn
STR-DE897/B
Features
Amplifier Section
• Black Finish A/V Receiver (Also
Available in Silver)
• A & B/A or B Speaker Switch
• 32-bit Dolby® Digital, Dolby Pro®
Logic and dts® Decoder
• 32-bit DSP with 13 Acoustic
Environments
• Digital Cinema Sound™ system
with Cinema Studio EX modes
• Sound Field Modes (Movie, Music,
AFD, 2 Channel) Movie: 3 Modes;
Music: 3 Modes; AFD: 6 Modes; 2
Channel: 1 Mode
• Station Presets 30 Total
• Analog Direct
• Circuit Device (Discrete)
• Sound Field Link
Inputs and Outputs
• Assignable Digital Inputs
• 2 Component Video Inputs HD
Pass 80 MHz
• Screw Terminals for A and B
Speaker Connections
• Front Composite A/V with Optical
• Multi-Channel In (Analog) 5.1
Channel & 7.1 Channel Input
• Headphone Jack 1/4" Jack Gold
Plated
• Phono (mm)
• Control A 1 II
• Analog Audio Input x 3
• Digital Input x 6 (4 Optical, 2
Coaxial)
• Analog Audio Output x 1
• Digital Output x 1 (Optical)
• 2nd Zone Audio Ouput
• Pre-Out x 1 (Subwoofer)
• Composite Video Input x 5
• Composite Video Output x 2
• S-Video Input x 3
• S-Video Output x 1
• Component Video Input x 2 (HD
Pass 80 MHz)
• Component Video Output x 1 (HD
Pass 80 MHz)
• Monitor Out x 2 (1 Composite, 1
S-Video)
• AC Outlet (switched) x 2
Convenience
• Remote Commander® Remote
Control Pre-Programmed + Learn
+ Limited Macro
• Easy Setup Expandable Menu
System for Simplicity
Specifications
General
• Power Requirements 120V AC, 60
Hz
• Power Consumption n/a
• Power Consumption (Standby) n/a
Video
• S-Video (Y)/(C) Input Sensitivity
Impedance (Y) 1 Vp-p/75 ohm;
(C) .286 Vp-p/75 ohm
• Component Video (Y/Pb/Pr) Input
Sensitivity Impedance (Y) 1
Vp-p/75 ohm;
(Pb) .7 Vp-p/75 ohm;
(Pr) .7 Vp-p/75 ohm
• Composite Video Output
Sensitivity Impedance 1 Vp-p/75
ohm
• S-Video (Y)/(C) Output Sensitivity
Impedance (Y) 1 Vp-p/75 ohm;
(C) .286 Vp-p/75 ohm
• Component Video (Y/Pb/Pr)
Output Sensitivity Impedance (Y) 1
Vp-p/75 ohm
(Pb) .7 Vp-p/75 ohm;
(Pr) .7 Vp-p/75 ohm
Amplifier Section
• Stereo Power Rating 100 Watts
Per Channel x 2 (8 ohms 20 Hz-20
kHz, THD .09%)
• Phono Input S/N Ratio 86 dB
• Line Input S/N Ratio 96 dB
• Frequency Response Line (CD) 10
Hz - 100kHz ±3 dB
• Phono Input Sensitivity Impedance
8mV/50 kohm
• Line (CD) Input Sensitivity
Impedance 500mV/50 k ohm
• Subwoofer Pre-Out Level
Impedance 2V/1 kohm
Supplied Accessories
• Instruction Manual
• Remote Model: RM-PG413
Weights & Measures
• TBD
• TBD
UPC Codes
• 0272426441820
