STR-DH510

5.1 ch. High-

Definition AV Receiver

Key Features

5.1 Channel A/V Receiver (100W x 5; 8 ohms

1kHz 1% THD)

5 HD Inputs (3 HDMI, 2 Component)

HDMI™ Repeater for simplified audio and video

signal management

Blu

-ray Disc™

Audio Decoding (Linear PCM

Only)

Audio Return Channel uses just one cable for

TV audio

Standby pass-

through of Audio & Video

Assignable digital audio inputs allows for use of

all digital audio connections

BRAVIA®

Sync

™

for multi

device control w/ one

remote

Deep color output and x.v.Color

™ support

Digital Media Port for iPod®

(

iPod cradle sold

separately)

24p True Cinema™ pass-

through

Key Technologies

5 HD Inputs Get versatile HD connection options with five HD inputs. Three HDMI™ inputs (up to 1080/24p capable)

let you connect a Sony

PlayStation

3 entertainment system, Blu

ray Disc™ player, any 2 other HDMI

capable

devices, for high definition video and audio. Two component inputs (1080/60i capable) provide added HD

capable

connectivity and versatility.

HDMI™ Repeater Connect multiple devices via HDMI™ to your A/V receiver, easily switch between them, and then

connect everything to your HDTV with just one HDMI cable.

Blu

ray Disc™ Audio Decoding Experience sound closer to the way it was captured with LPCM.

Audio Return Channel Eliminate the need for extra cables connected to your TV. This feature allows audio to be

sent from your compatible TV to your receiver through the same HDMI™

cable already being used to send audio and

video to your TV.

Standby pass

through of Audio & Video Conveniently access all your HDMI connected devices without having

to power on the receiver

Assignable digital audio inputs Get the most out of each audio input with the ability to reassign digital audio

inputs to support connected devices.

BRAVIA

Sync™

Capable

Conveniently operate and control all your HDMI™ connected BRAVIA

Sync devices

with one remote including: Blu

ray Disc™ Players, BRAVIA

HDTVs, home theater products, Handycam

Camcorders

and Cyber

shot

Digital Cameras.

x.v. Color™ Experience close to twice as many (1.8 x's) viewable colors as the existing RGB color standard with

x.v.Color technology.

Digital Media Port Connect a Digital Media Port (DMP) adapter (sold separately) to your A/V receiver and access

music from your iPod

Walkman

Bluetooth

or PC device.

24p True Cinema™ Mode Watch movies at their native frame rate 24p format (24 frames per second) when

paired with a 24p playback device like a Blu

ray Disc™ Player or PlayStation

3 gaming console.

Sony Electronics Inc.

•

16530 Via Esprillo

•

San Diego, CA 92127

•

1.800.222.7669

•

www.sony.com

Last Updated: 05/13/2010

STR-DH510

5.1 ch. High-

Definition AV Receiver

Please visit the Dealer Source for current

information at www.sony.com/dealersource

Features

General

Power Consumption: 230W

Power Stand By: 0.3W

Auto Standby: Yes

Display: 8 Seg. FL

Panel: Mold, Black (New)

Pin Jack: Nickel

Power Requirement: 120V 60Hz

Remote Commander: U

RM; RM

AAU071

Sleep Timer: Yes

Video

A/V SYNC:

Yes(fixed)

A/V Sync Sampling Frequency: 48kHz

A/V Sync Time (msec): 60ms

BRAVIA

SYNC

™ (

CEC Control):

Yes

HDMI Pass Through: Yes

Theater Mode Selector: Yes

Audio Return Channel: Yes

HDMI™ Video Output Capability: 1080p;

1080/24p; Deep Color; x.v.Color (xvYCC)

Convenience

Auto Tuning: Yes

Amplifier

(8Ohms 1kHz) THD RMS: 1%

(8Ohms 20

20kHz) THD: 0.09%

8Ohms 1kHz RMS: 100W + 100W

8Ohms 20

20kHz: 90W + 90W

Headphone Out: Yes(Gold)

Night Mode: Yes

Number of Amp channels: 5ch

Portable Audio Enhancer: Yes

Sound Field Program (2ch): 2

Sound Field Program (A.F.D.): 2

Sound Field Program (Headphone): 2

Sound Field Program (Movie): 5

Sound Field Program (Music): 7

Speaker Selector: A

Speaker Terminal: Front(Screw)/Others

(Push)

4 Ohm/8 Ohm Switching: No(8 Ohm only)

Analog Direct: Yes

Cinema Studio EX. A/B/C mode: Yes

DSP:

Sharc

Equalizer(F/C/Sur/Sur B) Bass,Mid,Treble:

B,T/

Sound Field Link (w Lock): Yes(

)

Sub Woofer X' Over:

17 points (40

200Hz)

Type:

Analog

Specifications

Inputs and Outputs

A/V In/Out (S

Video I/O): Including Front

AV: 2/1 (0/0) + V1/0

Analog Audio In (Inc TV CEC)/Out (excl.

tuner)/TV(CEC): 2/0/Yes

Coaxial: 1/0

Component Video In/Out (Pass through):

2/1

DMPORT: 1

Digital Input Assign: Yes

HDMI In/Out: (Front input): 3/1

Monitor Out (S

Video Out): 1(0)

Opt. In/Out/TV(CEC): incl Front input & TV

(CEC):

2/0/Yes

Pre Out: SW x1

Tuner

Auto Tuning: Yes

Direct Tuning: Yes(RM)

Preset Channel: TTL60 (

/30/30)

Station Name: Yes

Decoding Format(S)

96k/24Bit PCM: Yes

Dolby Digital/DTS: Yes/Yes

Dolby Dual Mono:

Yes

Dolby Prologic:

Yes

Dolby Prologic II:

Yes

LPCM (2CH/5.1CH/7.1CH) thru HDMI:

Yes/Yes/

Color:

Black

UPC Code:

027242780002

1. Requires HDMI

™

cable and source device with HDMI output and

LPCM capabilities (both sold separately).

2. Requires sources connected with HDMI

™

cables (sold separately) and

compatible HDTV. Sound quality will vary depending on source.

3. HDMI™

Cables sold separately

4. Works with other BRAVIA® Sync or Theatre Sync™

labeled home

audio/video products when connected via HDMI

™

interface.

5. Deep Color and x.v. Color

™

technology are supported only when

source product, HDMI

™

cable, media and HDTV all support those

features.

6. iPod

support is limited to the following players with the optional dock:

iPod

touch, iPod

classic, iPod

Nano 1st, 2nd & 3rd generation,

iPod

® 4th& 5th generation &iPod®

Mini. The optional TDM

IP50 dock

will support iPhones as well.

7. 24p playback capable device required, sold separately.

in part without written permission is prohibited. Sony, BRAVIA, BRAVIA

Sync and their respective logos are trademarks of Sony. Blu

ray Disc is a

trademark. Dolby is a registered trademark of Dolby Laboratories. dts is a

trademark of dts Inc. All other trademarks are trademarks of their

respective owners. Features and specifications are subject to change

without notice. Non

metric weights and measures are approximate.
