WARNING
About These Operating Instructions
About the S-AIR function
Playable Discs
Getting Started
Disc
Tuner
Control for HDMI/External Audio Device
Other Operations
Additional Information

(DAV-DZ880W only)

4-122-233-11(1)

DVD Home Theatre

System

Operating Instructions

DAV-DZ380W / DZ680W / DZ880W

2GB

Caution – The use of optical instruments

with this product will increase eye

hazard.

Do not install the appliance in a confined space, such

as a bookcase or built-in cabinet.

To reduce the risk of fire, do not cover the ventilation

opening of the apparatus with newspapers, tablecloths,

curtains, etc. Do not place the naked flame sources

such as lighted candles on the apparatus.

To reduce the risk of fire or electric shock, do not

expose this apparatus to dripping or splashing, and do

not place objects filled with liquids, such as vases, on

the apparatus.

Do not expose batteries or apparatus with battery-

installed to excessive heat such as sunshine, fire or the

like.

To prevent injury, this apparatus must be securely

attached to the floor/wall in accordance with the

installation instructions.

Excessive sound pressure from earphones and

headphones can cause hearing loss.

Indoor use only.

This appliance is

classified as a CLASS 1

LASER product. This

marking is located on the

rear exterior.

Disposal of Old

Electrical & Electronic

Equipment (Applicable

in the European Union

and other European

countries with separate

collection systems)

This symbol on the product or

on its packaging indicates that

this product shall not be treated as household waste.

Instead it shall be handed over to the applicable

collection point for the recycling of electrical and

electronic equipment. By ensuring this product is

disposed of correctly, you will help prevent potential

negative consequences for the environment and human

health, which could otherwise be caused by

inappropriate waste handling of this product. The

recycling of materials will help to conserve natural

resources. For more detailed information about

recycling of this product, please contact your local

Civic Office, your household waste disposal service or

the shop where you purchased the product.

Disposal of waste

batteries (applicable in

the European Union and

other European

countries with separate

collection systems)

This symbol on the battery or on the packaging

indicates that the battery provided with this product

shall not be treated as household waste. By ensuring

these batteries are disposed of correctly, you will help

prevent potentially negative consequences for the

environment and human health which could otherwise

be caused by inappropriate waste handling of the

battery. The recycling of the materials will help to

conserve natural resources. In case of products that for

safety, performance or data integrity reasons require a

permanent connection with an incorporated battery,

this battery should be replaced by qualified service

staff only. To ensure that the battery will be treated

properly, hand over the product at end-of-life to the

applicable collection point for the recycling of

electrical and electronic equipment. For all other

batteries, please view the section on how to remove the

battery from the product safely. Hand the battery over

to the applicable collection point for the recycling of

waste batteries. For more detailed information about

recycling of this product or battery, please contact your

local Civic Office, your household waste disposal

service or the shop where you purchased the product.

Notice for customers: the following information is

only applicable to equipment sold in countries

applying EU directives.

The manufacturer of this product is Sony Corporation,

1-7-1 Konan Minato-ku Tokyo, 108-0075 Japan. The

Authorized Representative for EMC and product

safety is Sony Deutschland GmbH, Hedelfinger

Strasse 61, 70327 Stuttgart, Germany. For any service

or guarantee matters please refer to the addresses given

in separate service or guarantee documents.

For the wireless transceiver

(EZW-RT10/EZW-RT10A)

See “Wireless Product Safety Information” (supplied).

About the surround amplifier

• The nameplate is located on the side exterior.

WARNING

3GB

Precautions

On power sources

• The unit is not disconnected from the mains as long

as it is connected to the AC outlet, even if the unit

itself has been turned off.

• As the main plug is used to disconnect the unit from

the mains, connect the unit to an easily accessible AC

outlet. Should you notice an abnormality in the unit,

disconnect the main plug from the AC outlet

immediately.

About These Operating

Instructions

• The instructions in these Operating

Instructions describe the controls on the

remote. You can also use the controls on the

unit if they have the same or similar names as

those on the remote.

• The Control Menu items may vary depending

on the area.

• “DVD” may be used as a general term for a

DVD VIDEO, DVD+RW/DVD+R, and DVD-

RW/DVD-R.

• Measurements are expressed in feet (ft) for

North American models.

• The default setting is underlined.

Copyrights

This product incorporates copyright protection

technology that is protected by U.S. patents and

other intellectual property rights. Use of this

authorized by Macrovision, and is intended for

home and other limited viewing uses only unless

otherwise authorized by Macrovision. Reverse

engineering or disassembly is prohibited.

This system incorporates with Dolby* Digital

and Dolby Pro Logic (II) adaptive matrix

surround decoder and the DTS** Digital

Surround System.

* Manufactured under license from Dolby

Laboratories.

Dolby, Pro Logic, and the double-D symbol are

trademarks of Dolby Laboratories.

** Manufactured under license under U.S. Patent #’s:

5,451,942; 5,956,674; 5,974,380; 5,978,762;

6,487,535 & other U.S. and worldwide patents

issued & pending. DTS and DTS Digital Surround

are registered trademarks and the DTS logos and

This system incorporates High-Definition

Multimedia Interface (HDMITM) technology.

HDMI, the HDMI logo and High-Definition

Multimedia Interface are trademarks or

registered trademarks of HDMI Licensing LLC.

4GB

“DVD-RW,” “DVD-R,” “DVD+RW,”

“DVD+R,” “DVD VIDEO,” and the “CD”

logos are trademarks.

“BRAVIA” is a trademark of Sony Corporation.

“PLAYSTATION” is a trademark of Sony

Computer Entertainment Inc.

“WALKMAN” and “WALKMAN” logo are

registered trademarks of Sony Corporation.

DivX® is a video file compression technology,

developed by DivX, Inc.

DivX, DivX Certified, and associated logos are

trademarks of DivX, Inc. and are used under

license.

“S-AIR” and its logo are trademarks of Sony

Corporation.

MPEG Layer-3 audio coding technology and

patents licensed from Fraunhofer IIS and

Thomson.

About MPEG-4 Visual

THIS PRODUCT IS LICENSED UNDER THE

MPEG-4 VISUAL PATENT PORTFOLIO

LICENSE FOR THE PERSONAL AND NON-

COMMERCIAL USE OF A CONSUMER FOR

DECODING VIDEO IN COMPLIANCE

WITH THE MPEG-4 VISUAL STANDARD

(“MPEG-4 VIDEO”) THAT WAS ENCODED

BY A CONSUMER ENGAGED IN A

PERSONAL AND NON-COMMERCIAL

ACTIVITY AND/OR WAS OBTAINED

FROM A VIDEO PROVIDER LICENSED BY

MPEG LA TO PROVIDE MPEG-4 VIDEO.

NO LICENSE IS GRANTED OR SHALL BE

IMPLIED FOR ANY OTHER USE.

ADDITIONAL INFORMATION INCLUDING

THAT RELATING TO PROMOTIONAL,

INTERNAL AND COMMERCIAL USES

AND LICENSING MAY BE OBTAINED

FROM MPEG LA, LLC. SEE HTTP://

WWW.MPEGLA.COM

About the S-AIR function

The system is compatible with the S-AIR

function, which allows transmission of sound

between S-AIR products wirelessly.

The following S-AIR products can be used with

the system:

• Surround amplifier (supplied): You can enjoy

surround speaker sound wirelessly.

• S-AIR receiver (optional): You can enjoy

system sound in another room.

The S-AIR receiver can be purchased as an

option (the S-AIR product lineup differs

depending on the area).

Notes or instructions for the surround amplifier

or S-AIR receiver in these Operating

Instructions refer only to when the surround

amplifier or S-AIR receiver is used.

For details on the S-AIR function, see “Using an

S-AIR Product” (page 89).

5GB

Table of Contents

About These Operating Instructions ....... 3

About the S-AIR function.......................4

Playable Discs.........................................6

Getting Started

Step 1: Installing the System....... 13

Step 2: Connecting the System... 23

Step 3: Setting up the Wireless

System ..................................... 35

Step 4: Performing the Quick

Setup........................................ 36

Step 5: Selecting the Source....... 39

Step 6: Enjoying Surround

Sound....................................... 41

Disc

Playing a Disc .......................................44

Using Play Mode...................................49

Searching/Selecting Disc Contents .......52

Playing MP3 Files/JPEG Image Files... 54

Enjoying Video Files ............................58

Adjusting the Delay Between the Picture

and Sound .......................................60

Restricting Playback of the Disc...........60

Changing the System Settings by Using

the Setup Display............................62

Tuner

Presetting Radio Stations ......................70

Listening to the Radio...........................71

Using the Radio Data System (RDS).... 72

Control for HDMI/External

Audio Device

Using the Control for HDMI Function for

“BRAVIA” Sync ............................73

Playing Back Files of a USB Device .... 76

Transferring Songs onto a USB

Device.............................................84

Using a Sony Ericsson Mobile

Phone ..............................................87

Using the DIGITAL MEDIA PORT

Adapter ...........................................88

Using an S-AIR Product .......................89

Other Operations

Getting Optimal Surround Sound for a

Room .............................................. 94

Calibrating the Appropriate Settings

Automatically ................................. 95

Controlling the TV with the Supplied

Remote ........................................... 96

Using the Sound Effect......................... 97

Selecting the Effect to Suit

the Source....................................... 98

Enjoying Multiplex Broadcast

Sound.............................................. 98

Changing the Input Level of the Sound

from Connected Components......... 99

Using the Sleep Timer .......................... 99

Changing the Brightness of the Front

Panel Display................................ 100

Viewing Information About

the Disc......................................... 100

Returning to the Default Settings ....... 103

Additional Information

Precautions.......................................... 104

Notes about the Discs ......................... 105

Troubleshooting.................................. 106

Self-diagnosis Function ...................... 116

Specifications...................................... 117

Glossary .............................................. 119

Playback priority of file types ............ 122

Language Code List............................ 123

Index to Parts and Control .................. 124

Guide to the Control Menu Display ... 129

Index ................................................... 133

6GB

Playable Discs

1)MP3 (MPEG1 Audio Layer 3) is a standard format defined by ISO/MPEG for compresses audio data. MP3 files

must be in MPEG1 Audio Layer 3 format.

2)JPEG image files must conform to the DCF image file format. (DCF “Design rule for Camera File system”: Image

standards for digital cameras regulated by Japan Electronics and Information Technology Industries Association

(JEITA).)

Type Disc logo Characteristics Icon

DVD VIDEO • DVD VIDEO

• DVD-R/DVD-RW in DVD VIDEO

format or video mode

• DVD+R/DVD+RW in DVD VIDEO

format

VR (Video

Recording) mode

• DVD-R/DVD-RW in VR (Video

Recording) mode (except for DVD-R

DL)

VIDEO CD • VIDEO CD (Ver. 1.1 and 2.0 discs)

• Super VCD

• CD-R/CD-RW/CD-ROM in video CD

format or Super VCD format

Super Audio CD • Super Audio CD

CD • Audio CD

• CD-R/CD-RW in audio CD format

DATA CD – • CD-R/CD-RW/CD-ROM in DATA CD

format, containing MP3 files1), JPEG

image files2), DivX video files, and

MPEG4 video files, and conforming to

ISO 96603) Level 1/Level 2, or Joliet

(extended format)

DATA DVD – • DVD-ROM/DVD-R/DVD-RW/

DVD+R/DVD+RW in DATA DVD

format, containing MP3 files1), JPEG

image files2), DivX video files, and

MPEG4 video files, and conforming to

UDF (Universal Disk Format)

7GB

3)A logical format of files and folders on CD-ROMs, defined by ISO (International Organization for

Standardization).

Notes on discs

This product is designed to playback discs that conform to the Compact Disc (CD) standard.

DualDiscs and some of the music discs encoded with copyright protection technologies do not conform

to the Compact Disc (CD) standard, therefore, these discs may not be playable by this product.

The system cannot play the following discs:

• CD-ROM/CD-R/CD-RW other than those recorded in the formats listed on page 6

• CD-ROM recorded in PHOTO CD format

• Data part of CD-Extra

• CD Graphics disc

• DVD Audio

• DATA CD/DATA DVD that does not contain MP3 files, JPEG image files, DivX video files, or

MPEG4 video files

• DVD-RAM

•Blu-ray Disc

Also, the system cannot play the following discs:

• A DVD VIDEO with a different region code (page 8)

• A disc that has a non-standard shape (e.g., card, heart)

• A disc with paper or stickers on it

• A disc that has the adhesive of cellophane tape or a sticker still left on it

In some cases, CD-R/CD-RW/DVD-R/DVD-RW/DVD+R/DVD+RW cannot be played on this system

due to the recording quality or physical condition of the disc, or the characteristics of the recording

device and authoring software.

The disc will not play if it has not been correctly finalized. For more information, refer to the operating

instructions for the recording device.

Note that some playback functions may not work with some DVD+RWs/DVD+Rs, even if they have

been correctly finalized. In this case, view the disc by normal playback. Also some DATA CDs/DATA

DVDs created in Packet Write format cannot be played.

• This system can play a Multi Session CD when an MP3 file is contained in the first session. Any

subsequent MP3 files recorded in later sessions can also be played back.

• This system can play a Multi Session CD when a JPEG image file is contained in the first session.

Any subsequent JPEG image files recorded in later sessions can also be played back.

• If MP3 files and JPEG image files in music CD format or video CD format are recorded in the first

session, only the first session will be played back.

Example of discs that the system cannot play

Note about CD-R/CD-RW/DVD-R/DVD-RW/DVD+R/DVD+RW

About Multi Session CD

8GB

Your system has a region code printed on the rear of the unit and will only play a DVD labeled with

the same region code.

A DVD VIDEO labeled will also play on this system.

If you try to play any other DVD VIDEO, the message [Playback prohibited by area limitations.] will

appear on the TV screen. Depending on the DVD VIDEO, no region code indication may be given even

though playing the DVD VIDEO is prohibited by area restrictions.

Some playback operations on a DVD or VIDEO CD may be intentionally set by software producers.

Since this system will play a DVD or VIDEO CD according to the disc contents the software producers

designed, some playback features may not be available. Be sure to read the operating instructions

supplied with the DVD or VIDEO CD.

Region code

Note about playback operations of a DVD or VIDEO CD

ALL

9GB

Getting Started

DAV-DZ380W

Getting Started

Unpacking

• Front speakers (2)

• Center speaker (1)

• Surround speakers (2)

• Subwoofer (1)

• FM wire antenna (aerial) (1)

• Speaker cords (6, red/white/

green/gray/blue/purple)

• Remote commander

(remote) (1)

• R6 (size AA) batteries (2)

• Calibration mic (1)

• Foot pads (1 set)

• Surround amplifier (1)

• Speaker cord cover (1)

• Speaker cord holder (1)

• Wireless transceivers (2)

• Operating Instructions

• Quick Setup Guide

• Wireless Product Safety

Information

For United Kingdom models

• DIGITAL MEDIA PORT

adapter (TDM-iP20) (1)

• Operating Instructions for

the DIGITAL MEDIA

PORT adapter (TDM-iP20)

10GB

Getting Started

DAV-DZ680W

• Front speakers (2)

• Center speaker (1)

• Surround speakers (2)

• Subwoofer (1)

• FM wire antenna (aerial) (1)

• Speaker cords (4, green/

gray/blue/purple)

• Remote commander

(remote) (1)

• R6 (size AA) batteries (2)

• Calibration mic (1)

• Foot pads (1 set)

• Bases (2)

• Screws (with washer) (6)

• Surround amplifier (1)

• Speaker cord cover (1)

• Speaker cord holder (1)

• Wireless transceivers (2)

• Operating Instructions

• Quick Setup Guide

• Wireless Product Safety

Information

For United Kingdom models

• DIGITAL MEDIA PORT

adapter (TDM-iP20) (1)

• Operating Instructions for

the DIGITAL MEDIA

PORT adapter (TDM-iP20)

11GB

Getting Started

DAV-DZ880W

• Front speakers (2)

• Center speaker (1)

• Surround speakers (2)

• Subwoofer (1)

• FM wire antenna (aerial) (1)

• Speaker cords (2, green/

purple)

• Remote commander

(remote) (1)

• R6 (size AA) batteries (2)

• Calibration mic (1)

• Foot pads (1 set)

• Bases (4)

• Screws (with washer) (12)

• Surround amplifier (1)

• Speaker cord cover (1)

• Speaker cord holder (1)

• Wireless transceivers (2)

• Operating Instructions

• Quick Setup Guide

• Wireless Product Safety

Information

For United Kingdom models

• DIGITAL MEDIA PORT

adapter (TDM-iP20) (1)

• Operating Instructions for

the DIGITAL MEDIA

PORT adapter (TDM-iP20)

12GB

Getting Started

Inserting batteries into the remote

Insert two R6 (size AA) batteries (supplied) by matching the 3 and # ends on the batteries to the

markings inside the compartment. To use the remote, point it at the remote sensor on the unit.

Note

• Do not leave the remote in an extremely hot or humid place.

• Do not use a new battery with an old one.

• Do not drop any foreign object into the remote casing, particularly when replacing the batteries.

• Do not expose the remote sensor to direct sunlight or lighting apparatus. Doing so may cause a malfunction.

• If you do not intend to use the remote for an extended period of time, remove the batteries to avoid possible damage

from battery leakage and corrosion.

13GB

Getting Started

Step 1: Installing the System

For the best possible surround sound, place all speakers at the same distance from the listening position

(A). The distance can be between 1.0 to 7.0 meters.

If you cannot place the center speaker and surround speakers at the same distance as (A), you can move

the center speaker up to 1.6 meters closer to the listening position (B), and the surround speakers up

to 5.0 meters closer to the listening position (C).

The subwoofer can be placed anywhere in the room.

Note

• Use caution when placing the speakers and/or speaker stands attached to the speakers on a specially treated (waxed,

oiled, polished, etc.) floor, as staining or discoloration may result.

• Do not lean or hang on a speaker, as it may fall down.

Positioning the system

AACC

Front left speaker (L) Front right speaker (R)

Center speaker

Subwoofer

Surround left speaker (L) Surround right speaker (R)

14GB

Getting Started

Attaching the foot pads to the subwoofer

Attach the foot pads (supplied) to the bottom of the subwoofer to stabilize the subwoofer and prevent

it from slipping.

Remove the foot pads from

the protective cover.

15GB

Getting Started

(DAV-DZ680W/DAV-DZ880W only)

Before connecting the speakers, attach the speaker stand to the speaker.

(For the front speakers of DAV-DZ680W, and the front and surround speakers of DAV-DZ880W)

Use the parts as follows:

DAV-DZ680W

• Front speakers (2)

• Bases (2)

• Screws (with washer) (6)

DAV-DZ880W

• Front and surround speakers (4)

• Bases (4)

• Screws (with washer) (12)

For details of how to connect the speaker cords to the SPEAKER jacks, see page 23.

Note

• Spread a cloth on the floor to avoid damaging the floor when you assemble the speakers.

• You can use the speaker without the speaker stand by installing it on the wall (page 18).

1Thread the speaker cord through the top hole in the base.

Assembling the speakers

Speaker cord

Top of the base

Speaker

16GB

Getting Started

2Turn the speaker upside down.

3Place the base on the bottom of the speaker, then secure the base with three screws

(with washer).

Speaker

Speaker cord

Speaker

Bottom of the

base

Screws (with washer)

17GB

Getting Started

Fully-assembled illustration

DAV-DZ680W

DAV-DZ880W

White Red

Front left speaker (L):

White label

Front right speaker (R):

Red label

Surround left speaker (L):

Blue label

White Red

Surround right speaker (R)

Gray label

Front left speaker (L):

White label

Front right speaker (R):

Red label

Blue Gray

18GB

Getting Started

Caution

• Contact a screw shop or installer for information regarding the wall material or screws to be used.

• Use screws that are suitable for the wall material and strength. As a plaster board wall is especially fragile, attach

the screws securely to a beam. Install the speakers on a vertical and flat wall where reinforcement is applied.

• Sony is not responsible for accidents or damage caused by improper installation, insufficient wall strength or

improper screw installation, natural calamity, etc.

Before installing the front speakers of DAV-DZ680W or the front and surround speakers of DAV-

DZ880W on a wall, you need to disassemble the speakers. You can install the upper part of a speaker

on a wall.

To disassemble the speaker

(Front speakers of DAV-DZ680W or front and surround speakers of DAV-DZ880W only)

1Pull out the speaker cord from the slot of the rear of the speaker.

2Disconnect the speaker cords from the speaker.

Installing the speakers on a wall

Rear of the speaker

Speaker cord

Rear of the speaker

19GB

Getting Started

3Remove the screw (pre-installed) at the rear of the speaker.

This screw is used when reassembling the speaker. Be sure not to lose the screw.

4Disassemble the speaker by lifting the upper part of the speaker.

Rear of the speaker

Screw

Upper part

Lower part

Rear of the speaker

20GB

Getting Started

5Pull out the speaker cord from the bottom of the lower part of the speaker.

The removed speaker cord is used when installing the speaker on a wall.

Fully-disassembled illustration

To install the speakers on a wall

Before installing the speakers on a wall, connect the speaker cord to the speaker.

Be sure to match the speaker cords to the appropriate terminals on the speakers: the speaker cord with

the color tube to 3, and the speaker cord without the color tube to #.

Lower part of the speaker

Speaker cord

Upper part of

the speaker

Lower part of

the speaker

Speaker cord

Screw

Color tube

Front left speaker (L): White

Front right speaker (R): Red

Center speaker: Green

Surround left speaker (L): Blue

Surround right speaker (R): Gray

21GB

Getting Started

1Prepare screws (not supplied) that are suitable for the hole on the back of each speaker.

See the illustrations below.

2Fasten the screws to the wall.

DAV-DZ380W

DAV-DZ680W

30 mm (1 3/16 inches)

4 mm (5/32 inch)

Hole on the back of

the speaker

5 mm

(7/32 inch)

10 mm

(13/32 inch)

8 to 10 mm

(

inch

)

145 mm

(5 3/4 inches)

For the center speaker For the other speakers

8 to 10 mm

(

inch

)

8 to 10 mm

(

inch

)

145 mm

(5 3/4 inches)

For the center speaker

210 mm

(8 3/8

inches

)

For the front speakers

8 to 10 mm

(

inch

)

For the surround speakers

8 to 10 mm

(

inch

)

22GB

Getting Started

DAV-DZ880W

3Hang the speakers on the screws.

8 to 10 mm

(

inch

)

145 mm

(5 3/4 inches)

For the center speaker

210 mm

(8 3/8

inches

)

For the other speakers

8 to 10 mm

(

inch

)

5 mm

(7/32 inch)

10 mm

(13/32 inch)

Hole on the back of

the speaker

Rear of the speaker

23GB

Getting Started

Step 2: Connecting the System

For connecting the system, read the information on the following pages.

Do not connect the AC power cord (mains lead) of the unit to a wall outlet (mains) until all the other

connections are made.

Note

• When you connect another component with a volume control, turn down the volume of the other components to a

level where sound is not distorted.

The connector of the speaker cords and the color tube are color-coded depending on the type of speaker.

Connect the speaker cords to match the color of the SPEAKER jacks of the unit.

Be sure to match the speaker cords to the appropriate terminals on the speakers: the speaker cord with

the color tube to 3, and the speaker cord without the color tube to #. Do not catch the speaker cord

insulation (rubber covering) in the speaker terminals.

To connect speaker cords to the unit

When connecting to the unit, insert the connector until it clicks.

Connecting the speakers

24GB

Getting Started

DAV-DZ380W/DAV-DZ680W

SURROUND SELECTOR

S-AIR ID

EZW-RT

SPEAKER

SURROUND

PAI RING

SURROUND

BACK

CENTER

SUBWOOFER

HDMI OUT

SPEAKER

COAXIAL 75

ANTENNA

DMPORT

DC5V

0.7A MAX

DIGITAL IN

COAXIAL

OPTICAL

TVEURO AV

OUTPUT(TO TV)

EZW-RT10

FRONT R FRONT L

SPEAKER

Green

(Center speaker)

Purple

(Subwoofer)

White

(Front left speaker (L))

Red

(Front right speaker (R))

Gray

(Surround right speaker (R))

Blue

(Surround left speaker (L))

Rear panel of the unit

Rear panel of the surround amplifier

25GB

Getting Started

DAV-DZ880W

To connect speaker cords to the speaker

SURROUND SELECTOR

S-AIR ID

EZW-RT

SPEAKER

SURROUND

PAI RING

SURROUND

BACK

CENTER

SUBWOOFER

HDMI OUT

SPEAKER

COAXIAL 75

ANTENNA

DMPORT

DC5V

0.7A MAX

DIGITAL IN

COAXIAL

OPTICAL

TVEURO AV

OUTPUT(TO TV)

EZW-RT10

AUDIO IN L

LINE

FRONT R FRONT L

SPEAKER

Green

(Center speaker)

Purple

(Subwoofer)

White

(Front left speaker (L))

Red

(Front right speaker (R))

Gray

(Surround right speaker (R))

Blue

(Surround left speaker (L))

Rear panel of the unit

Rear panel of the surround amplifier

Color tube (+)

(–)

Connector

Rear of the speaker

26GB

Getting Started

Depending on the jacks on your TV, select the connection method.

DAV-DZ380W/DAV-DZ680W

DAV-DZ880W

Connecting the TV

CENTER

SUBWOOFER

HDMI OUT

SPEAKER

COAXIAL 75

ANTENNA

DMPORT

DC5V

0.7A MAX

DIGITAL IN

COAXIAL

OPTICAL

TVEURO AV

OUTPUT(TO TV)

EZW-RT10

FRONT R FRONT L

SPEAKER

To the HDMI IN jack of the TV.

To the SCART (EURO AV)

jack of the TV.

A SCART (EURO AV) cable

(not supplied)

B HDMI cable (not

supplied)

C Digital optical cord (not

supplied)

To the digital optical

out jack of the TV. To the digital coaxial

out jack of the TV.

D Digital coaxial cord (not

supplied)

CENTER

SUBWOOFER

HDMI OUT

SPEAKER

COAXIAL 75

ANTENNA

DMPORT

DC5V

0.7A MAX

DIGITAL IN

COAXIAL

OPTICAL

TVEURO AV

OUTPUT(TO TV)

EZW-RT10

AUDIO IN LR

LINE

FRONT R FRONT L

SPEAKER

To the HDMI IN jack of the TV.

To the SCART (EURO AV)

jack of the TV.

A SCART (EURO AV) cable

(not supplied)

B HDMI cable (not

supplied)

C Digital optical cord (not

supplied)

To the digital optical

out jack of the TV. To the digital coaxial

out jack of the TV.

D Digital coaxial cord (not

supplied)

27GB

Getting Started

Method 1: SCART (EURO AV) cable (A) connection

This connection sends both video and audio signals.

Method 2: HDMI* cable (B) and SCART (EURO AV) cable (A) connection

If your TV has an HDMI jack, connect to the TV both with an HDMI cable and SCART (EURO AV)

cable. Picture quality will be improved compared to using only the SCART (EURO AV) connection.

When connecting with the HDMI cable, you need to select the type of output signal (page 38).

To view images from the DIGITAL MEDIA PORT adapter, you need to connect to the TV with the

SCART (EURO AV) cable. Video signals from the DIGITAL MEDIA PORT adapter are not output

via the HDMI OUT jack.

* HDMI (High-Definition Multimedia Interface)

Digital optical cord (C) or digital coaxial cord (D) connection

When the TV has a digital optical or coaxial output jack, you can improve sound quality by connecting

with a digital optical or coaxial cord in addition to the SCART (EURO AV) connection.

Note

• The system can accept both digital and analog signals. Digital signals have priority over analog signals. (COAXIAL

has priority over OPTICAL.) If the digital signal ceases, the analog signal will be processed after 2 seconds.

• When you connect the system and a TV with the “BRAVIA” Sync function via an HDMI cable, the “BRAVIA”

Sync function is enabled. In this case, set [CONTROL FOR HDMI] in [HDMI SETUP] to [ON] (page 64).

28GB

Getting Started

You can enjoy connected components via the system’s speakers.

DAV-DZ380W/DAV-DZ680W

Portable audio source (not supplied): E

USB device (not supplied): F

DIGITAL MEDIA PORT adapter: G (TDM-iP20 is supplied with United Kingdom models. You can

also use other DIGITAL MEDIA PORT adapters.)

Connecting the other components

CENTER

SUBWOOFER

HDMI OUT

SPEAKER

COAXIAL 75

ANTENNA

DMPORT

DC5V

0.7A MAX

DIGITAL IN

COAXIAL

OPTICAL

TVEURO AV

OUTPUT(TO TV)

EZW-RT10

FRONT R FRONT L

SPEAKER

G DIGITAL MEDIA PORT adapter

(page 88)

To a portable audio source

E Stereo mini-plug cord

(not supplied)

F Connect a USB

device (page 76).

Note

• Connect the DIGITAL MEDIA PORT

adapter so that the V marks are aligned.

When disconnecting, pull out while

pressing .

29GB

Getting Started

DAV-DZ880W

Portable audio source (not supplied): E

USB device (not supplied): F

DIGITAL MEDIA PORT adapter: G (TDM-iP20 is supplied with United Kingdom models. You can

also use other DIGITAL MEDIA PORT adapters.)

VCR, digital satellite receiver, or PlayStation, etc. (not supplied): H

CENTER

SUBWOOFER

HDMI OUT

SPEAKER

COAXIAL 75

ANTENNA

DMPORT

DC5V

0.7A MAX

DIGITAL IN

COAXIAL

OPTICAL

TVEURO AV

OUTPUT(TO TV)

EZW-RT10

AUDIO IN L

LINE

FRONT R FRONT L

SPEAKER

G DIGITAL MEDIA PORT

adapter (page 88)

To a portable audio source

E Stereo mini-plug cord

(not supplied)

F Connect a USB

device (page 76).

Note

• Connect the DIGITAL MEDIA PORT

adapter so that the V marks are aligned.

When disconnecting, pull out while

pressing . To the audio out jacks of the VCR, digital satellite

receiver, or PlayStation, etc.

H Audio cord (not

supplied)

30GB

Getting Started

If your TV has multiple audio/video inputs

You can enjoy sound with the speakers of the system through the connected TV. Connect the

components as follows.

Select the component on the TV. For details, refer to the operating instructions of the TV.

If the TV does not have multiple audio/video inputs, a switcher will be necessary to receive sound from

more than one component.

System

:Signal flow

VCR, digital satellite receiver,

PlayStation, etc.

VCR, digital satellite receiver,

PlayStation, etc.

31GB

Getting Started

Note

• Be sure to fully extend the FM wire antenna (aerial).

• After connecting the FM wire antenna (aerial), keep it as horizontal as possible.

• If you have poor FM reception, use a 75-ohm coaxial cable (not supplied) to connect the unit to an outdoor FM

antenna (aerial) as shown below.

Connecting the antenna (aerial)

COAXIAL 75

ANTENNA

FM wire antenna (aerial)

(supplied)

COAXIAL 75

ANTENNA

Outdoor FM antenna (aerial) Unit

32GB

Getting Started

You can transmit sound from the unit to an S-AIR product, such as a surround amplifier or S-AIR

receiver.

To transmit sound from the unit, you need to insert the wireless transceivers into the unit, surround

amplifier, and S-AIR receiver.

For details of S-AIR products, see “Using an S-AIR Product” (page 89).

DAV-DZ380W/DAV-DZ680W

DAV-DZ880W

Note

• When you insert the wireless transceiver, make sure that the AC power cord (mains lead) is not connected to a wall

outlet (mains).

• Do not touch the terminals of the wireless transceiver.

• Insert the wireless transceiver so that the V marks are aligned.

• Do not insert anything other than the wireless transceiver into the EZW-RT10 slot.

Inserting the wireless transceiver

SURROUND SELECTOR

S-AIR ID

EZW-RT

SPEAKER

SURROUND

PAI R I N G

SURROUND

BACK

HDMI OUT

COAXIAL 75

ANTENNA

DMPORT

DC5V

0.7A MAX

EURO AV

OUTPUT(TO TV)

EZW-RT10

FRONT R FRONT L

SPEAKER

Rear panel of the unit Rear panel of the surround

amplifier

Wireless

transceiver

Wireless

transceiver

SURROUND SELECTOR

S-AIR ID

EZW-RT

SPEAKER

SURROUND

PAI R I N G

SURROUND

BACK

HDMI OUT

COAXIAL 75

ANTENNA

DMPORT

DC5V

0.7A MAX

EURO AV

OUTPUT(TO TV)

EZW-RT10

AUDIO IN LR

LINE

FRONT R FRONT L

SPEAKER

Rear panel of the unit Rear panel of the surround

amplifier

Wireless

transceiver

Wireless

transceiver

33GB

Getting Started

Before connecting the AC power cords (mains leads) of the unit and the surround amplifier to a wall

outlet (mains), connect the front, center speakers and subwoofer to the unit and surround speakers to

the surround amplifier.

After connecting the AC power cord (mains lead), the demonstration appears in the front panel display.

Setting the demonstration mode to on/off

1Press [/1 on the unit.

The system turns on.

2Press SYSTEM MENU.

3Press X/x repeatedly until “DEMO” appears in the front panel display, then press or

4Press X/x to select a setting.

•“DEMO ON”: On.

• “DEMO OFF”: Off.

5Press .

The setting is made.

Connecting the AC power cords (mains leads)

About the demonstration

SURROUND SELECTOR

S-AIR ID

EZW-RT

SPEAKER

SURROUND

PAI RING

SURROUND

BACK

Wall outlet (mains): The shape of

the wall outlet (mains) differs

depending on the area.

Rear panel of the unit

Rear panel of the

surround amplifier

34GB

Getting Started

6Press SYSTEM MENU.

The system menu turns off.

• When you purchase the system new, or if the system is at its factory default settings (ex., after performing “COLD

RESET” (page 103)), you can turn off the demonstration simply by pressing [/1 on the remote.

35GB

Getting Started

Step 3: Setting up the

Wireless System

To use the wireless system, you need to set up

the surround amplifier. Before setting, make

sure that the wireless transceivers are inserted

into the unit and the surround amplifier correctly

(page 32).

This wireless system is called “S-AIR.” For

details of the S-AIR function, see “Using an

S-AIR Product” (page 89).

The unit transmits sound to the surround

amplifier that is connected to the surround

speakers. To establish sound transmission,

perform the following Steps.

1Press "/1 on the unit.

The system turns on.

2Set the SURROUND SELECTOR switch

of the surround amplifier to

SURROUND.

3Set the S-AIR ID switch of the surround

amplifier to A.

4Press POWER on the surround

amplifier.

The POWER / ON LINE indicator turns

green. If it doesn’t, check the transmission

status as follows.

To check the transmission status

You can check the status of sound transmission

between the unit and surround amplifier by

observing the POWER / ON LINE indicator of

the surround amplifier.

For details of the surround amplifier, see

“Surround amplifier operation” (page 114).

To enjoy sound by using

headphones

You can enjoy the system’s sound by connecting

the headphones to the PHONES jack on the

surround amplifier.

Note

• The volume of the unit may become minimum if you

turn off the surround amplifier while the headphones

are connected to the surround amplifier, or radio

reception is poor. In this case, “HP NO LINK” and

“VOLUME MIN” appear alternately in the front

panel display. Check radio reception, and set the

volume again.

When you use multiple S-AIR

products

See “Establishing sound transmission between

the unit and S-AIR sub unit (ID setting)”

(page 89).

"/1

POWER

POWER/ON LINE

PHONES

SURROUND SELECTOR

S-AIR ID

EZW-RT

SPEAKER

SURROUND

PAI R I N G

SURROUND

BACK

POWER

POWER / ON LINE

Indicator

SURROUND

SELECTOR switch

S-AIR ID switch

PHONES jack

POWER / ON LINE

indicator

Status

Turns green. Sound transmission is

established.

Flashes green. Sound transmission is not

established.

Turns red. The surround amplifier does

not output sound.

Turns off. The surround amplifier turns

off or its protection is active.

36GB

Getting Started

To attach the cover to the

surround amplifier

After connecting and setting, you can attach the

cover to the surround amplifier for organizing

and storing excess speaker cords.

1Attach the speaker cord cover by

sliding it down along the grooves at the

edges of the surround amplifier.

Push the speaker cord cover down until you

hear a click. Turn the surround amplifier

upside down, then store the cords in the

speaker cord cover.

2Insert the tabs of the speaker cord

holder in the slots of the speaker cord

cover, and press it into place.

Step 4: Performing the

Quick Setup

Follow the Steps below to make the basic

adjustments for using the system.

Displayed items vary depending on the area.

1Turn on the TV.

2Press [/1 on the unit, and POWER on

the surround amplifier.

Note

• Make sure that the function is set to “DVD”

(page 39).

3Switch the input selector on your TV so

that the signal from the system

appears on the TV screen.

[Press [ENTER] to run QUICK SETUP.]

appears at the bottom of the TV screen. If

this message does not appear, recall the

Quick Setup display (page 38).

4Press without inserting a disc.

The Setup Display for selecting the

language used in the on-screen display

appears.

Speaker cord cover

Surround amplifier

Grooves

Speaker cord holder

Surround amplifier

"/1

DISPLAY

C/X/x/c,

LANGUAGE SETUP

MENU:

OSD:

AUDIO:

SUBTITLE:

ENGLISH

FRENCH

SPANISH

PORTUGUESE

37GB

Getting Started

5Press X/x to select a language, then

press .

The Setup Display for selecting the aspect

ratio of the TV to be connected appears.

6Press X/x to select the setting that

matches your TV type, then press .

•[16:9]: For a wide-screen TV or a 4:3

standard TV with a wide-screen mode

(page 64)

• [4:3 LETTER BOX] or [4:3 PAN SCAN]:

For a 4:3 standard TV (page 64)

The Setup Display for selecting the output

method for video signals from the EURO

AV T OUTPUT (TO TV) jack on the rear

panel of the unit appears.

7Press X/x to select the output method

for video signals, then press .

• [VIDEO]: Outputs video signals.

• [RGB]: Outputs RGB signals.

Note

• If your TV does not accept RGB signals, no

picture appears on the TV screen even if you

select [RGB]. Refer to the operating instructions

supplied with your TV.

The Setup Display for the Control for

HDMI function appears.

8Press X/x to select the setting, then

press .

•[OFF]: The Control for HDMI function is

set to off.

• [ON]: The Control for HDMI function

(page 73) is set to on.

The Setup Display for selecting the speaker

formation appears.

9Press C/c to select the speaker

formation image as the speakers are

actually positioned, then press .

For details, see “Getting Optimal Surround

Sound for a Room” (page 94).

10Connect the calibration mic (supplied)

to the A.CAL MIC jack on the front

panel.

Set up the calibration mic at ear level using

a tripod, etc. (not supplied).

The front of each speaker should face the

calibration mic, and there should be no

obstruction between the speakers and the

calibration mic.

VIDEO SETUP

LINE:

TV TYPE:

PAUSE MODE:

16:9

4:3 LETTER BOX

4:3 PAN SCAN

VIDEO SETUP

LINE:

TV TYPE:

PAUSE MODE:

16:9

VIDEO

RGB

HDMI SETUP

HDMI RESOLUTION:

VOLUME LIMIT:

AUTO

(1920x1080p)

OFF

YCBCR/RGB(HDMI):

JPEG RESOLUTION:

AUDIO(HDMI):

CONTROL FOR HDMI: OFF

OFF

SPEAKER FORMATION

STANDARD

38GB

Getting Started

11 Press C/c to select [YES], then press

[AUTO CALIBRATION] starts.

Be quiet during the measurement.

Note

• Loud test sounds are output when [AUTO

CALIBRATION] starts. You cannot turn the

volume down. Give consideration to children

and neighbors.

• Before [AUTO CALIBRATION], install the

surround amplifier in the appropriate location. If

you install the surround amplifier in an improper

location, such as another room, proper

measurement will not be obtained.

• The environment of the room in which the

system is installed may affect measurements.

When the measurements differ considerably

from the status of the speaker installation,

perform the speaker settings manually by

following “Settings for the speakers” (page 67).

12 Unplug the calibration mic, press C/c

to select [YES], then press .

Quick Setup is finished. All connections

and setup operations are complete.

To quit the Quick Setup

Press DISPLAY in any Step.

To recall the Quick Setup display

1Press FUNCTION +/– repeatedly until

“DVD” appears in the front panel

display.

2Press DISPLAY while the system is

in stop mode.

The Control Menu display appears on the

TV screen.

3Press X/x to select [SETUP],

then press .

The options for [SETUP] appear.

4Press X/x to select [QUICK], then press

The Quick Setup display appears.

Depending on the connection of the TV

(page 26), select the type of video output of the

system.

To select the type of video signal

output from the HDMI OUT jack

When you connect the unit and the TV with an

HDMI cable, select the type of video signals

output from the HDMI OUT jack.

For details, refer also to the operating

instructions supplied with the TV/projector, etc.

1Press FUNCTION +/– repeatedly until

“DVD” appears in the front panel

display.

2Press DISPLAY while the system is

in stop mode.

The Control Menu display appears on the

TV screen.

Calibration mic

Setting the type of video

output to match your TV

94( 99)

CUSTOM

DVD VIDEO

T 0: 01: 08

1( 1)

QUICK

39GB

Getting Started

3Press X/x to select [SETUP],

then press .

The options for [SETUP] appear.

4Press X/x to select [CUSTOM], then

press .

The Setup Display appears.

5Press X/x to select [HDMI SETUP], then

press .

The options for [HDMI SETUP] appear.

6Press X/x to select [HDMI

RESOLUTION], then press .

7Press X/x to select the desired setting,

then press .

• [AUTO (1920

× 1080p)]: The system

outputs the optimal video signal for the

connected TV.

• [1920 × 1080i]: The system outputs 1920

× 1080i* video signals.

• [1280 × 720p]: The system outputs 1280 ×

720p* video signals.

•[720 × 480p]**: The system outputs 720 ×

480p* video signals.

* i: interlace, p: progressive

** Depending on the area, [720 × 480/576p] may

appear.

Step 5: Selecting the

Source

You can select the playback source.

Press FUNCTION +/– repeatedly until the

desired function appears in the front panel

display.

Each time you press FUNCTION +/–, the

function changes as follows.

xDAV-DZ380W/DAV-DZ680W

“DVD” y “TUNER FM” y “USB” y

“TV” y “DMPORT” y “AUDIO” y …

Function Source

“DVD” Disc that is played by the

system

“TUNER FM” FM radio (page 70)

“USB” USB device (page 76)

“TV” TV

“DMPORT” DIGITAL MEDIA PORT

adapter (page 88)

“AUDIO” Portable audio source that

is connected to the AUDIO

IN jack on the front panel

FUNCTION

+/–

40GB

Getting Started

xDAV-DZ880W

“DVD” y “TUNER FM” y “USB” y

“TV” y “LINE” y “DMPORT” y

“AUDIO” y …

Function Source

“DVD” Disc that is played by the

system

“TUNER FM” FM radio (page 70)

“USB” USB device (page 76)

“TV” TV

“LINE” Component that is

connected to the LINE

jacks on the rear panel

“DMPORT” DIGITAL MEDIA PORT

adapter (page 88)

“AUDIO” Portable audio source that

is connected to the AUDIO

IN jack on the front panel

41GB

Getting Started

Step 6: Enjoying Surround Sound

You can enjoy surround sound simply by selecting one of the system’s pre-programmed decoding

modes. They bring the exciting and powerful sound of movie theaters into your home.

1Press SYSTEM MENU.

2Press X/x repeatedly until “DEC. MODE” appears in the front panel display, then press

or c.

3Press X/x repeatedly until “PRO LOGIC” appears in the front panel display.

4Press .

The setting is made.

5Press SYSTEM MENU.

The system menu turns off.

Note

• When TV program sound is monaural, sound is output only from the center speaker.

1Press SYSTEM MENU.

2Press X/x repeatedly until “DEC. MODE” appears in the front panel display, then press

or c.

3Press X/x repeatedly until the surround sound effect you want appears in the front panel

display.

See the table below for surround sound effect descriptions.

Enjoying TV sound with the 5.1 channel surround sound effect

Selecting surround sound effects based on your listening preference

SYSTEM MENU

X/x/c,

42GB

Getting Started

4Press .

The setting is made.

5Press SYSTEM MENU.

The system menu turns off.

About speaker output

The table below describes the options when you connect all the speakers to the unit and you set

[SPEAKER FORMATION] to [STANDARD] (page 94).

The default setting is “A.F.D. STD” (when connecting the headphones to the unit or surround

amplifier, the default setting is “HP 2CH”).

Sound from Surround effect Effect

Depending on the source. “A.F.D. STD”

(AUTO FORMAT

DIRECT STANDARD)

The system discriminates the sound format of the source and

presents sound as it was recorded/encoded.

“A.F.D. MULTI”

(AUTO FORMAT

DIRECT MULTI)

• 2 channel source: The system outputs 2 channel sound from

the front and surround speakers by assigning the 2 channel

sound to the surround left and right channels.

• Multi-channel source: The system outputs sound from the

speakers depending on the number of channels of the

source.

“PRO LOGIC”

“PLII MOVIE”

“PLII MUSIC”

• 2 channel source: The system simulates surround sound

from 2 channel sources and outputs sound from all the

speakers.

– “PRO LOGIC” performs Dolby Pro Logic decoding.

– “PLII MOVIE” performs Dolby Pro Logic II movie

mode decoding.

– “PLII MUSIC” performs Dolby Pro Logic II music mode

decoding.

• Multi-channel source: The system outputs sound from the

speakers depending on the number of channels of the

source.

“2CH STEREO” The system outputs the sound from the front speakers and

subwoofer regardless of sound format or number of channels.

Multi-channel surround formats are downmixed to 2

channels.

“HP 2CH”

(HEADPHONE 2

CHANNEL STEREO)

The system outputs the sound from the headphones

regardless of sound format or number of channels. Multi-

channel surround formats are downmixed to 2 channels.

43GB

Getting Started

To turn the surround effect off

Select “A.F.D. STD,” “2CH STEREO,” or “HP 2CH” for “DEC. MODE.”

Note

• When the bilingual broadcast sound is input, “PRO LOGIC,” “PLII MOVIE,” and “PLII MUSIC” are not effective.

• You cannot select the decoding mode while the system is loading a disc.

• You cannot select the decoding mode when the unit is reading the files in a USB device or transferring songs.

• Depending on the input stream, the decoding mode may not be effective.

• When you select “A.F.D. MULTI,” the surround or stereo effect may not be effective. In this case, select “A.F.D.

STD,” “PRO LOGIC,” “PLII MOVIE,” or “PLII MUSIC.”

• When changing the decoding mode while using the S-AIR receiver, sound from the S-AIR receiver may skip.

“HP VIRTUAL”

(HEADPHONE

VIRTUAL)

The system outputs the sound from the headphones by

adding a surround effect regardless of sound format or

number of channels.

Sound from Surround effect Effect

44GB

Playing a Disc

Depending on the DVD VIDEO or VIDEO CD,

some operations may be different or restricted.

Refer to the operating instructions supplied with

your disc.

1Turn on your TV.

2Switch the input selector on the TV to

this system.

3Press "/1.

The system turns on.

Unless the system is set to “DVD,” press

FUNCTION +/– to select “DVD.”

4Press Z on the unit to open the disc

tray, and place a disc on the tray.

Place one disc on the tray, and then press Z.

Note

• When you play an 8 cm disc, place it on the

inner circle of the tray. Be careful that the disc is

not skewed on the inner circle of the tray.

• Do not place more than one disc on the tray.

5Press H.

The system starts playback (continuous

play).

6Adjust the volume by using VOLUME +/

– on the remote or the VOLUME control

on the unit.

The volume level appears on the TV screen

and in the front panel display.

Note

• When you set the Control for HDMI function to on,

the TV that is connected to the system with an HDMI

cable can be sync-operated with the system. For

details, see “Using the Control for HDMI Function

for “BRAVIA” Sync” (page 73).

To turn the system off

Press "/1 while the system is on. The system

enters standby mode.

To save power in standby mode

Press "/1 while the system is on.

To enter power saving mode, make sure that the

system is in the following status.

– “DEMO” is set to “OFF” (page 33).

– [CONTROL FOR HDMI] is set to [OFF]

(page 73).

– “S-AIR STBY” is set to “STBY OFF”

(page 91).

Disc

"/1

Disc tray

FUNCTION

Adjust the volume

PHONES jack

OPERATION DIAL

"/1

FUNCTION

+/–

./>

MUTING

VOLUME +/–

/m/

STEP

With the label side up.

Disc

45GB

To use the headphones

Connect the headphones to the PHONES jack on

the unit. The sound of the system is muted.

You can also connect the headphones to the

PHONES jack on the surround amplifier. (The

sound of the system is muted.)

See “To enjoy sound by using headphones”

(page 35).

Other operations

1)Except for JPEG image files.

2)DVD VIDEO/DVD-R/DVD-RW/VIDEO CD only.

3)Except for VIDEO CDs.

4)You cannot search for a still picture on a DVD-VR.

5)For a DATA CD/DATA DVD, this function works

only for video files.

6)DVD VIDEO/DVD-RW/DVD-R only. The button

can be used except for DivX/MPEG4 video files.

7)DVD VIDEO/DVD-RW/DVD-R/DVD+RW/

DVD+R only. The button can be used except for

DivX/MPEG4 video files.

To change the angles

If various angles (multi-angles) for a scene are

recorded on a DVD VIDEO, you can change the

viewing angle.

To Press

Stop x

Pause X

Resume play after pause X or H

Go to the next chapter,

track, or scene1)

Go back to the

preceding chapter,

track, or scene1)

. twice in a second.

When you press . once,

you can go to the beginning

of the current chapter,

track, or scene.

Find the desired chapter,

track, or scene using

OPERATION DIAL on

the unit1)

Turning OPERATION

DIAL clockwise is the

same operation as pressing

Turning OPERATION

DIAL counterclockwise is

the same operation as

pressing ..

Turn off the sound

temporarily

MUTING.

To cancel, press it again or

press VOLUME + to adjust

the sound volume.

Stop play and remove

the disc

Z on the unit.

Locate a point quickly

by playing a disc in fast

forward or fast reverse

(Scan)1)

M/ or /m while

playing a disc. Each time

you press M/ or /

m during scan, the

playback speed changes.

To return to normal speed,

press H. Actual speeds

may differ with some discs.

Watch frame by frame

(Slow-motion Play)2)

M/ or /m3)

while the system is in pause

mode. Each time you press

M/ or /m3)

during Slow-motion Play,

the playback speed

changes. Two speeds are

available. To return to

normal playback speed,

press H.

Play one frame at a time

(Freeze Frame)2)4)5)

STEP to go to the next

frame while the system is in

pause mode. Press STEP

to go to the preceding

frame while the system is in

pause mode (DVD VIDEO/

DVD-R/DVD-RW only).

To return to normal

playback, press H.

Replay the previous

scene (10 seconds

before)6)

(instant replay) during

playback.

Briefly fast forward the

current scene (30

seconds ahead)7)

(instant advance)

during playback.

Displaying multi-angles and

subtitles

To Press

46GB

Press ANGLE during playback to select the

desired angle.

To display the subtitles

If subtitles are recorded on a disc, you can turn

the subtitles on/off during playback. If

multilingual subtitles are recorded on the disc,

you can change the subtitle language during

playback, or turn the subtitles on/off whenever

you want.

Press SUBTITLE during playback to select

the desired subtitle language.

Note

• You can select the subtitles if the DivX video file has

an “.avi” or “.divx” extension and contains subtitle

information within the same file.

When the system is playing a DVD VIDEO or

DATA CD/DATA DVD (DivX video files)

recorded in multiple audio formats (PCM,

Dolby Digital, MPEG audio, or DTS), you can

change the audio format. If the DVD VIDEO is

recorded with multilingual tracks, you can also

change the language.

With a VIDEO CD, CD, DATA CD, or DATA

DVD, you can select the sound from the right or

left channel and listen to the sound of the

selected channel through both the right and left

speakers.

You cannot change the sound for a Super Audio

CD.

Press AUDIO repeatedly during playback to

select the desired audio signal.

xDVD VIDEO

Depending on the DVD VIDEO, the choice of

language varies.

When 4 digits are displayed, they indicate a

language code. See “Language Code List”

(page 123) to confirm which language the code

represents. When the same language is

displayed two or more times, the DVD VIDEO

is recorded in multiple audio formats.

xDVD-VR

The types of sound tracks recorded on a disc are

displayed.

Example:

• [1: MAIN] (main sound)

• [1: SUB] (sub sound)

• [1: MAIN+SUB] (main and sub sound)

• [2: MAIN]

•[2: SUB]

• [2: MAIN+SUB]

xVIDEO CD/CD/DATA CD (MP3 file)/DATA

DVD (MP3 file)

•[STEREO]: The standard stereo sound.

• [1/L]: The sound of the left channel

(monaural).

• [2/R]: The sound of the right channel

(monaural).

xDATA CD (DivX video file)/DATA DVD

(DivX video file)

The choice of DATA CD or DATA DVD audio

signal formats differs, depending on the DivX

video file contained on the disc. The format

appears on the TV screen.

xSuper VCD

• [1:STEREO]: The stereo sound of audio track

• [1:1/L]: The sound of the left channel of audio

track 1 (monaural).

• [1:2/R]: The sound of the right channel of

audio track 1 (monaural).

• [2:STEREO]: The stereo sound of audio track

• [2:1/L]: The sound of the left channel of audio

track 2 (monaural).

• [2:2/R]: The sound of the right channel of

audio track 2 (monaural).

If you press AUDIO repeatedly during

playback, the format of the current audio signal

(PCM, Dolby Digital, DTS, etc.) appears as

shown below.

Changing the sound

Checking the audio signal

format

Disc

47GB

xDVD

Example:

Dolby Digital 5.1 channel

Example:

Dolby Digital 3 channel

xDATA CD (video file)/DATA DVD (video

file)

Example:

MP3 audio

Some Super Audio CDs consist of a 2 channel

playback area and a multi-channel playback

area. You can select the playback area you want

to listen to.

1Press DISPLAY while the system is

in stop mode.

The Control Menu display appears on the

TV screen.

2Press X/x to select [MULTI/

2CH], then press .

The options for [MULTI/2CH] appear.

3Press X/x to select the desired setting

and press .

• [MULTI]: You can play the multi-channel

playback area.

• [2CH]: You can play the 2 channel

playback area.

Note

• When the Super Audio CD does not have a multi-

channel playback area, you cannot select the

playback area.

Some Super Audio CDs consist of a Super

Audio CD layer and a CD layer. You can change

the playback layer you want to listen to.

1Press DISPLAY while the system is

in stop mode.

The Control Menu display appears on the

TV screen.

2Press X/x to select [SUPER

AUDIO CD/CD LAYER], then press .

xWhen the current layer is the CD

layer

[SUPER AUDIO CD] appears.

xWhen the current layer is the Super

Audio CD layer

[CD] appears.

3Press to change the layer.

• [SUPER AUDIO CD]: You can play the

Super Audio CD layer.

When the system is playing a Super Audio

CD layer, “SA-CD” lights up in the front

panel display.

Selecting a playback area for a

Super Audio CD

1: ENGLISH

DOLBY DIGITAL 3 / 2 .1

LFE

CL R

LS RS

Surround (L/R)

Front (L/R) +

Center

LFE (Low

Frequency Effect)

Currently playing program format

1:SPANISH

DOLBY DIGITAL 2 / 1

L R

Front (L/R)

Surround

(Monaural)

Currently playing program format

1:MP3 128k

Bit rate

Changing a playback layer for

a hybrid Super Audio CD

48GB

• [CD]: You can play the CD layer.

When the system is playing a CD layer,

“CD” lights up in the front panel display.

Note

• Each play mode function works only within the

selected layer or playback area.

• When you select a CD layer, you cannot change

playback areas.

• Super Audio CD audio signals are not output from the

HDMI OUT jack.

With PBC (Playback Control) functions, you

can enjoy simple interactive operations, search

functions, and other such operations.

PBC playback allows you to play a VIDEO CD

interactively by following the menu on the TV

screen.

1Start playing a VIDEO CD with PBC

functions.

The menu for your selection appears.

2Select the item number you want using

the number buttons.

If you make a mistake, press CLEAR to

cancel the number.

3Press .

4Follow the instructions in the menu for

interactive operations.

Refer to the operating instructions supplied

with the disc, as the operating procedure

may differ depending on the VIDEO CD.

To go back to the menu

Press O RETURN.

Note

• Depending on the VIDEO CD, [Press ENTER] in

Step 3 may appear as [Press SELECT] in the

operating instructions supplied with the disc. In this

case, press H.

• To play without using the PBC function, press ./

> or the number buttons while the system is in stop

mode to select a track, then press H or . The

system starts playback. You cannot play still pictures

such as a menu. To return to PBC playback, press x

twice, then press H.

When you stop the disc, the system remembers

the point where you pressed x and “RESUME”

appears in the front panel display. As long as

you do not remove the disc, Resume Play will

work even if the system is set to standby mode

by pressing "/1.

1While playing a disc, press x to stop

playback.

“RESUME” appears in the front panel

display.

2Press H.

The system starts playback from the point

where you stopped the disc in Step 1.

Note

• Depending on where you stop the disc, the system

may not resume playback from exactly the same

point.

• The point where you stopped playing may be cleared

when:

– you eject the disc.

– the system enters standby mode (DATA CD/

DATA DVD only).

– you change or reset the settings on the Setup

Display.

– you change the parental control level.

– you change the function by pressing FUNCTION

+/–.

– you disconnect the AC power cord (mains lead).

• For a DVD-VR, VIDEO CD, Super Audio CD, CD,

DATA CD, or DATA DVD, the system remembers

the resume playback point for the current disc.

• Resume Play does not work during Program Play and

Shuffle Play.

• This function may not work properly with some

discs.

Playing a VIDEO CD with PBC

functions (Ver. 2.0)

(PBC Playback)

Resuming playback from the

point where you stopped the

disc

(Resume Play)

Disc

49GB

• To play from the beginning of the disc, press x twice,

then press H.

To enjoy a disc that you played

before with resume playback

(Multi-disc Resume)

This system recalls the point where you stopped

the disc the last time it was played and resumes

playback from that point the next time you insert

the same disc. When the resume playback

memory is full, the resume playback point for

the earliest disc is deleted.

To activate this function, set [MULTI-DISC

RESUME] in [SYSTEM SETUP] to [ON]. For

details, see “[MULTI-DISC RESUME] (DVD

VIDEO/VIDEO CD only)” (page 67).

Note

• This system stores the resume points in memory for

up to 10 discs.

• To play from the beginning of the disc, press x twice,

then press H.

Using Play Mode

You can play the contents of a disc in the order

you want by arranging the order of the tracks on

the disc to create your own program. You can

program up to 99 tracks.

1Press DISPLAY.

The Control Menu display appears on the

TV screen.

2Press X/x to select [PROGRAM],

then press .

The options for [PROGRAM] appear.

3Press X/x to select [SET t], then

press .

4Press c.

The cursor moves to the track row [T] (in

this case, [01]).

Creating your own program

(Program Play)

PROGRAM 0: 00:00

1. TRACK – – – –

– –

ALL CLEAR

2. TRACK

3. TRACK

7. TRACK

6. TRACK

5. TRACK

4. TRACK

Tracks recorded on a disc

Total time of the programmed tracks

PROGRAM 0: 00:00

2. TRACK

1. TRACK – – – –

– –

ALL CLEAR

3. TRACK

7. TRACK

6. TRACK

5. TRACK

4. TRACK

50GB

5Select the track you want to program.

For example, select track [02].

Press X/x to select [02] under [T], then

press .

6To program other tracks, repeat Steps

4 to 5.

The programmed tracks are displayed in the

selected order.

7Press H to start Program Play.

Program Play starts.

When the program ends, you can restart the

same program again by pressing H.

To return to normal play

Press CLEAR while the display for the program

setting is not displayed on the TV screen, or

select [OFF] in Step 3. To play the same

program again, select [ON] in Step 3 and press

To turn off the Control Menu

display

Press DISPLAY repeatedly until the Control

Menu display is turned off.

To change or cancel a program

1Follow Steps 1 to 3 of “Creating your

own program.”

2Press X/x to select the program

number of the track you want to

change or cancel.

If you want to delete the track from the

program, press CLEAR.

3Follow Step 5 for new programming.

To cancel a program, select [--] under [T],

then press .

To cancel all of the tracks in the

programmed order

1Follow Steps 1 to 3 of “Creating your

own program.”

2Press X and select [ALL CLEAR].

3Press .

Note

• When you press CLEAR to return to normal play,

Shuffle Play and Repeat Play are also canceled.

You can play the contents on a disc in random

order. Subsequent Shuffle Play may produce a

different playing order.

Note

• The same song may be played repeatedly when you

are playing MP3 files.

1Press DISPLAY during playback.

The Control Menu display appears on the

TV screen.

2Press X/x to select [SHUFFLE],

then press .

The options for [SHUFFLE] appear.

3Press X/x to select the item to be

shuffled.

xVIDEO CD/Super Audio CD/CD

• [OFF]: Off.

• [TRACK]: You can shuffle tracks on the

disc.

xDuring Program Play

• [OFF]: Off.

• [ON]: You can shuffle tracks selected in

Program Play.

xDATA CD (except for video files)/

DATA DVD (except for video files)

• [OFF]: Off.

• [ON (MUSIC)]: You can shuffle MP3

files in the folder on the current disc.

When no folder is selected, the first folder

will play in random order.

PROGRAM 0: 03:51

1. TRACK 02 – –

– –

ALL CLEAR

2. TRACK

3. TRACK

7. TRACK

6. TRACK

5. TRACK

4. TRACK

Selected track

Total time of the programmed tracks

Playing in random order

(Shuffle Play)

Disc

51GB

4Press .

Shuffle Play starts.

To return to normal play

Press CLEAR, or select [OFF] in Step 3.

To turn off the Control Menu

display

Press DISPLAY repeatedly until the Control

Menu display is turned off.

Note

• You cannot use Shuffle Play with a VIDEO CD or

Super VCD with PBC playback.

• When you press CLEAR to return to normal play,

Program Play and Repeat Play are also canceled.

You can play the contents on a disc repeatedly.

You can use a combination of Shuffle Play or

Program Play modes.

1Press DISPLAY during playback.

The Control Menu display appears on the

TV screen.

2Press X/x to select [REPEAT],

then press .

The options for [REPEAT] appear.

3Press X/x to select the item to be

repeated.

xDVD VIDEO/DVD-VR

•[OFF]: Off.

• [DISC]: You can repeat all of the titles on

the disc.

• [TITLE]: You can repeat the current title

on a disc.

• [CHAPTER]: You can repeat the current

chapter on a disc.

xVIDEO CD/Super Audio CD/CD

•[OFF]: Off.

• [DISC]: You can repeat all of the tracks

on the disc.

• [TRACK]: You can repeat the current

track.

xDATA CD/DATA DVD

•[OFF]: Off.

• [DISC]: You can repeat all of the folders

on the disc.

• [FOLDER]: You can repeat the current

folder.

• [TRACK] (MP3 files only): You can

repeat the current file.

• [FILE] (video files only): You can repeat

the current file.

4Press .

The item is selected.

To return to normal play

Press CLEAR, or select [OFF] in Step 3.

To turn off the Control Menu

display

Press DISPLAY repeatedly until the Control

Menu display is turned off.

Note

• You cannot use Repeat Play with a VIDEO CD or

Super VCD with PBC playback.

• When the system is playing a DATA CD/DATA

DVD which contains MP3 files and JPEG image

files, and their playing time is not the same, the audio

sound will not match the image.

• When you press CLEAR to return to normal play,

Program Play and Shuffle Play are also canceled.

Playing repeatedly

(Repeat Play)

52GB

Searching/Selecting

Disc Contents

A DVD is divided into many sections, which

make up a picture or music feature. These

sections are called “titles.” When you play a

DVD which contains several titles, you can

select the title you want using DVD TOP

MENU.

When you play a DVD that allows you to select

items such as the language for the subtitles and

the language for the sound, select these items

using DVD MENU.

1Press DVD TOP MENU or DVD MENU.

The disc’s menu appears on the TV screen.

The contents of the menu vary depending

on the disc.

2Press C/X/x/c or the number buttons to

select the item you want to play or

change.

3Press .

To display the DVD’s menu on the

Control Menu display

1Press DISPLAY during playback.

The Control Menu display appears on the

TV screen.

2Press X/x to select [DISC

MENU], then press .

The options for [DISC MENU] appear.

3Press X/x to select [MENU] or [TOP

MENU].

4Press .

To turn off the Control Menu

display

Press DISPLAY repeatedly until the Control

Menu display is turned off.

This function is only available for DVD-VRs

with a playlist created.

1Press DISPLAY while the system is

in stop mode.

The Control Menu display appears on the

TV screen.

2Press X/x to select [ORIGINAL/

PLAY LIST], then press .

The options for [ORIGINAL/PLAY LIST]

appear.

3Press X/x to select a setting.

• [PLAY LIST]: You can play the titles in

the order of the existing playlist.

• [ORIGINAL]: You can play the titles

originally recorded.

4Press .

You can search a DVD VIDEO/DVD-VR by

title or chapter, and you can search a VIDEO

CD/Super Audio CD/CD/DATA CD/DATA

DVD by track, index, or scene. For a DATA CD/

DATA DVD, you can search by folder or file.

As titles and tracks are assigned unique numbers

on the disc, you can select the desired title or

track by entering its number. Or, you can search

for a scene using the time code.

1Press DISPLAY. (If [MEDIA] is set to

[MUSIC/PHOTO], press DISPLAY

twice.)

The Control Menu display appears on the

TV screen.

Using the DVD’s menu

Selecting an original title or

edited title on a DVD-VR

Searching for a title/chapter/

track/scene, etc.

Disc

53GB

2Press X/x to select the search method.

Example: [CHAPTER]

[** (**)] is selected (** refers to a number).

The number in parentheses indicates the

total number of titles, chapters, tracks,

indexes, scenes, folders, or files.

3Press .

[** (**)] changes to [– – (**)].

4Press X/x or the number buttons to

select the desired number of the title,

chapter, track, index, scene, etc.

If you make a mistake, press CLEAR to

cancel the number.

5Press .

The system starts playback from the

selected number.

• When the Control Menu display is turned off, you can

search for a chapter (DVD VIDEO/DVD-R/DVD-

RW), track (VIDEO CD/Super Audio CD/CD), or

file (DATA CD/DATA DVD (video file)) by

pressing the number buttons and .

To search for a scene using the

time code

1In Step 2, select [TIME].

[T **:**:**] (playing time of the current

title) is selected.

2Press .

[T **:**:**] changes to [T --:--:--].

3Input the time code using the number

buttons.

For example, to find a scene at 2 hours, 10

minutes, and 20 seconds after the

beginning: press 2, 1, 0, 2, 0 ([2:10:20]).

4Press .

Note

• You cannot search for a scene on a DVD+RW using

the time code.

DVD VIDEO

13( 99)

98( 99)

T 0: 03: 17

Selected row

DVD VIDEO

13( 99)

98( 99)

T 0: 03: 17

54GB

Playing MP3 Files/JPEG

Image Files

You can play MP3 files or JPEG image files:

– which have the extension “.mp3” (MP3 file)

or “.jpg”/“.jpeg” (JPEG image file).

– which conform to the DCF* image file

format.

* “Design rule for Camera File system”: Image

standards for digital cameras regulated by Japan

Electronics and Information Technology Industries

Association (JEITA).

Note

• The system will play any files with the extension

“.mp3,” “.jpg,” or “.jpeg” even if they are not in MP3

or JPEG format. Playing these files may generate a

loud noise which could damage your speaker system.

• The system does not play back audio in MP3PRO

format.

• The system can recognize up to 200 folders, and will

not play any folders beyond the 200th. (Depending on

the folder configuration, the number of folders that

can be recognized by the system may decrease.)

• The system can recognize up to 150 MP3 files/JPEG

image files in a folder.

• The system may take a longer time to play files when

progressing to the following folder or jumping to

other folders.

• The system may not play certain types of JPEG image

files (ex. a JPEG image file that is less than 8 (width)

× 8 (height)).

1Press FUNCTION +/– repeatedly until

“DVD” appears in the front panel

display.

2Load a DATA CD or DATA DVD.

After loading the disc, the list of folders

appears on the TV screen.

3Press DISPLAY.

The Control Menu display appears on the

TV screen.

4Press X/x to select [MEDIA],

then press .

The options for [MEDIA] appear.

5When [MUSIC] is selected, press DVD

MENU. When other than [MUSIC] is

selected, press X/x to select [MUSIC],

then press .

A list of folders that contain MP3 files

appears.

The selected folder is highlighted in yellow.

6Press X/x to select a folder.

xTo play MP3 files in a folder

Press H to start playing the selected

folder.

xTo select an MP3 file

Press .

The list of files contained in the folder

appears.

Press X/x to select a file and press .

The system starts playing the selected file.

You can turn the file list off by pressing

DVD MENU. Pressing DVD MENU again

will display the folder list.

To go to the next or previous

page

Press / .

To stop playback

Press x.

Selecting an MP3 file or folder

FOLDER LIST

02 1st Album (1986)

03 In the Middle of Nowhere (1986)

04 Ready for Romance (1986)

05 In the Garden of Venus (1987)

06 Romantic Warriors (1987)

07 Back for Good (1988)

08 Alone (1999)

01 Let's Talk About Love (1985)

TRACK LIST

03 In the Middle of Nowher...

02_Riding_On_A_White_Swan

03_Give_Me_Peace_On_Earth

04_Sweet_Little_Shella

05_Ten_Thousand_Lonely_Drums

06_Lonely_Tears_In_Chinatown

07_In_Shaire

01_Geronimo_s_Cadillac

Disc

55GB

To play the next or previous MP3

file

Press > to play the next MP3 file. Press .

twice to play the previous MP3 file.

When you press . once, you can go to the

beginning of the current MP3 file.

Note that you can select the next folder by

continuing to press > after the last file on the

current folder, but that you cannot return to the

previous folder by pressing .. To return to

the previous folder, select the folder from the

folder list.

To return to the previous display

Press O RETURN.

To turn on/off the display

Press DVD MENU.

To select the folder via the

remote

During playback or pause, you can select the

desired folder quickly by pressing +/–.

Other operations

See “Other operations” (page 45).

1Press FUNCTION +/– repeatedly until

“DVD” appears in the front panel

display.

2Load a DATA CD or DATA DVD.

After loading the disc, the list of folders

appears on the TV screen.

3Press DISPLAY.

The Control Menu display appears on the

TV screen.

4Press X/x to select [MEDIA],

then press .

The options for [MEDIA] appear.

5When [PHOTO] is selected, press DVD

MENU. When other than [PHOTO] is

selected, press X/x to select [PHOTO],

then press .

A list of folders that contain JPEG files

appears.

The selected folder is highlighted in yellow.

6Press X/x to select a folder.

xTo go to the next or previous page

Press / .

xTo play JPEG image files in a folder

Press H to start playing the selected

folder.

The JPEG images are played as a slide

show. You can change the interval of the

slide show (page 56), and add effects to the

slide show (page 57).

xTo select a JPEG image file by

displaying the image browser

Press PICTURE NAVI.

Previews of JPEG image files in the folder

appear in 16 subscreens.

Press C/X/x/c to select the JPEG image

file you want to view, then press .

To return to the previous screen, press O

RETURN.

To play the next or previous JPEG

image file

Press c/C when the Control Menu display is not

displayed. Note that you can select the next

folder by continuing to press c after the last

image on the current folder, but that you cannot

return to the previous folder by pressing C. To

Selecting a JPEG image file or

folder

FOLDER LIST

02 Travelling 01

03 2003.08.20

04 Flowers

05 Travelling 02

06 Animals

07 2003.11.16

08 2003.12.03

01 Happy birthday

1234

5678

13 14 15 16

9101112

56GB

return to the previous folder, select the folder

from the folder list.

To rotate a JPEG image file

When a JPEG image file is displayed on the TV

screen, you can rotate the JPEG image file in 90

degree increments.

Press X/x while viewing a JPEG image file.

Press CLEAR to return to normal view.

Note

• You cannot rotate the JPEG image file when you set

[JPEG RESOLUTION] in [HDMI SETUP] to [(1920

× 1080i) HD ] or [(1920 × 1080i) HD] (page 65).

To stop playback

Press x.

To turn on/off the display

Press DVD MENU.

To select the folder via the

remote

During playback or pause, you can select the

desired folder quickly by pressing +/–.

Other operations

See “Other operations” (page 45).

You can play a slide show with sound by first

placing both MP3 files and JPEG image files in

the same folder on a DATA CD or DATA DVD.

1Press FUNCTION +/– repeatedly until

“DVD” appears in the front panel

display.

2Load a DATA CD or DATA DVD.

After loading the disc, the list of folders

appears on the TV screen.

3Press DISPLAY.

The Control Menu display appears on the

TV screen.

4Press X/x to select [MEDIA],

then press .

The options for [MEDIA] appear.

5When [MUSIC/PHOTO] is selected,

press DVD MENU. When other than

[MUSIC/PHOTO] is selected, press X/x

to select [MUSIC/PHOTO], then press

The list of folders appears.

6Press X/x to select the desired folder

and press H.

The system starts playing the selected

folder.

You can turn the folder list on/off by

pressing DVD MENU repeatedly.

Note

• If you play a large MP3 file and JPEG image file at

the same time, the sound may skip. Sony

recommends that you set the MP3 bit rate to 128 kbps

or lower when creating the file. If the sound still

skips, reduce the size of the JPEG image file.

1Press DISPLAY. (If [MEDIA] is set to

[MUSIC/PHOTO], press DISPLAY

twice.)

The Control Menu display appears on the

TV screen.

2Press X/x to select [INTERVAL],

then press .

The options for [INTERVAL] appear.

3Press X/x to select a setting.

• [NORMAL]: You can set to the standard

duration.

• [FAST]: You can set the duration shorter

than [NORMAL].

• [SLOW 1]: You can set the duration

longer than [NORMAL].

• [SLOW 2]: You can set the duration

longer than [SLOW 1].

4Press .

Note

• Some JPEG image files may take longer to display

than the option you selected. Especially progressive

JPEG image files or JPEG image files of 3,000,000

pixels or more.

Playing a slide show with

sound

Selecting the slide show

duration of JPEG image files

Disc

57GB

1Press DISPLAY. (If [MEDIA] is set to

[MUSIC/PHOTO], press DISPLAY

twice.)

The Control Menu display appears on the

TV screen.

2Press X/x to select [EFFECT],

then press .

The options for [EFFECT] appear.

3Press X/x to select a setting.

•[MODE 1]: The JPEG image file sweeps

in from top to bottom.

• [MODE 2]: The JPEG image file stretches

out from left to right of the TV screen.

• [MODE 3]: The JPEG image file stretches

out from the center of the TV screen.

• [MODE 4]: The JPEG image files

randomly cycle through the effects.

• [MODE 5]: The next JPEG image file

slides over the previous image.

• [OFF]: Off.

4Press .

Note

• The [EFFECT] setting is not effective when you set

[JPEG RESOLUTION] in [HDMI SETUP] to [(1920

× 1080i) HD ] or [(1920 × 1080i) HD] (page 65).

You can select playback priority when mixed

media (MP3 files, JPEG image files, or video

files) are in the disc.

1Press FUNCTION +/– repeatedly until

“DVD” appears in the front panel

display.

2Load a DATA CD or DATA DVD.

After loading the disc, the list of folders

appears on the TV screen.

3Press DISPLAY.

The Control Menu display appears on the

TV screen.

4Press X/x to select [MEDIA],

then press .

The options for [MEDIA] appear.

5Press X/x to select a setting.

• [MUSIC/PHOTO]: You can play both

JPEG image files and MP3 files in the

same folder as a slide show.

• [MUSIC]: MP3 file playback has priority.

• [VIDEO]: Video file playback has

priority.

• [PHOTO]: JPEG image file playback has

priority. You can play JPEG image files as

a slide show.

6Press .

For details of the playback priority of file

types under the [MEDIA] setting, see

“Playback priority of file types” (page 122).

1Press DISPLAY during playback.

The Control Menu display appears on the

TV screen.

2Press X/x to select

[BROWSING], then press .

The options for [BROWSING] appear.

3Press X/x to select the desired list,

then press .

• [FOLDER LIST]: The list of folders

appears. Follow Step 6 of “Selecting an

MP3 file or folder” (page 54) or

“Selecting a JPEG image file or folder”

(page 55).

• [PICTURE LIST] (JPEG image files

only): Previews of JPEG image files in the

folder appear in 16 subscreens. Follow

Step 6 of “Selecting a JPEG image file or

folder” (page 55).

Selecting an effect for JPEG

image files in the slide show

Selecting playback priority of

the file type

Displaying a list of MP3 files/

JPEG image files

58GB

Enjoying Video Files

You can play DivX video files and MPEG4

video files.

DivX® is a video file compression technology,

developed by DivX, Inc. This product is an

official DivX® Certified product.

You can play a DATA CD or DATA DVD that

contains DivX® video files.

A DATA CD or DATA DVD that the

system can play

The system only plays a DATA CD of format

ISO 9660 Level 1/Level 2 or Joliet, and a DATA

DVD of Universal Disk Format (UDF).

Refer to the operating instructions supplied with

the disc drives and the recording software (not

supplied) for details on the recording format.

About playback order of data on a

DATA CD or DATA DVD

Note that the playback order may not be

applicable, depending on the software used for

creating the video file, or if there are more than

200 folders and 150 video files in each folder.

Note

• The system may not be able to play some DATA

CDs/DATA DVDs created in the Packet Write

format.

DivX video files that the system

can play

The system can play data that is recorded in

DivX format, and which has the extension “.avi”

or “.divx.” The system will not play files with

the extension “.avi” or “.divx” if they do not

contain a DivX video.

Note

• The system may not play a DivX video file when the

file has been combined from two or more DivX video

files.

• The system cannot play a DivX video file of size

more than 720 (width) × 576 (height) or 2GB.

• Depending on the DivX video file, sound may skip or

not match the pictures on the TV screen.

• The system cannot play some DivX video files that

are longer than 3 hours.

• Depending on the DivX video file, the picture may

pause or be unclear, in which case it is recommended

that you create the file at a lower bit rate. If the sound

is still noisy, MP3 is the recommended audio format.

Note, however, this system does not conform to

WMA (Windows Media Audio) format for playing

DivX files.

• Because of the compression technology used for

DivX video files, it may take some time after you

press H for the picture to appear.

MPEG4 video files that the

system can play

The system can play data that is recorded in

MP4 file format, and which has the extension

“.mp4” or “.m4v.” The system will not play files

with the extension “.mp4” or “.m4v” if they do

not contain a MPEG4 video.

Note

• Compatibility with all MPEG4 video encoding/

writing software, recording devices, and recording

media cannot be guaranteed.

1Press FUNCTION +/– repeatedly until

“DVD” appears in the front panel

display.

2Load a DATA CD or DATA DVD.

After loading the disc, the list of folders

appears on the TV screen.

3Press DISPLAY.

The Control Menu display appears on the

TV screen.

4Press X/x to select [MEDIA],

then press .

The options for [MEDIA] appear.

5When [VIDEO] is selected, press DVD

MENU. When other than [VIDEO] is

selected, press X/x to select [VIDEO],

then press .

A list of folders that contain video files

appears.

The selected folder is highlighted in yellow.

About video files

Selecting a folder

Disc

59GB

6Press X/x to select the folder you want

to play.

7Press H.

The system starts playing the selected

folder.

To select video files, see “Selecting a video

file” (page 59).

To go to the next or previous

page

Press / .

To stop playback

Press x.

To turn on/off the display

Press DVD MENU.

To select the folder via the

remote

During playback or pause, you can select the

desired folder quickly by pressing +/–.

Other operations

See “Other operations” (page 45).

1After Step 6 of “Selecting a folder,”

press .

The list of files in the folder appears.

2Press X/x to select a file and press .

The selected file starts playing.

To go to the next or previous

page

Press / .

To return to the previous display

Press O RETURN.

To stop playback

Press x.

To play the next or previous video

file without turning on the above

file list

You can select the next or previous video file in

the same folder by pressing >/..

You can also select the first file of the next

folder by pressing > during playback of the

last file of the current folder. Note that you

cannot return to the previous folder by pressing

.. To return to the previous folder, select it

from the folder list.

• If the number of viewing times is preset, you can play

a DivX video file as many times as the preset number.

The following occurrences are counted:

– when the system is turned off.

– when another file is played.

– when the disc tray is opened.

1Press DISPLAY during playback.

The Control Menu display appears on the

TV screen.

2Press X/x to select

[BROWSING], then press .

The options for [BROWSING] appear.

3Press X/x to select [FOLDER LIST],

then press .

The list of folders appears. Follow Step 6 of

“Selecting a folder” (page 58).

Selecting a video file

FOLDER LIST

NEW YEAR'S DAY

MY FAVOURITES

SUMMER 2003

FILE LIST

MY FAVOURITES

VENUS

HAWAII 2004

Displaying a list of video files

60GB

Adjusting the Delay

Between the Picture and

Sound

[A/V SYNC]

When the sound does not match the pictures on

the TV screen, you can adjust the delay between

the picture and sound.

1Press DISPLAY.

The Control Menu display appears on the

TV screen.

2Press X/x to select [A/V SYNC],

then press .

The options for [A/V SYNC] appear.

3Press X/x to select a setting.

•[OFF]: Off.

• [ON]: You can adjust the delay between

picture and sound.

4Press .

Note

• Depending on the input stream, [A/V SYNC] may not

be effective.

Restricting Playback of

the Disc

[PARENTAL CONTROL]

The [PARENTAL CONTROL] function allows

you to restrict playback of DVDs that have

ratings. Scenes may be blocked or replaced with

different scenes.

You can set the playback restriction by

registering a password. When you set the

[PARENTAL CONTROL] function to on, you

need to enter the password to play restricted

discs.

1Press FUNCTION +/– repeatedly until

“DVD” appears in the front panel

display.

2Press DISPLAY while the system is

in stop mode.

The Control Menu display appears on the

TV screen.

3Press X/x to select [SETUP],

then press .

The options for [SETUP] appear.

4Press X/x to select [CUSTOM], then

press .

The Setup Display appears.

5Press X/x to select [SYSTEM SETUP],

then press .

The options for [SYSTEM SETUP] appear.

6Press X/x to select [PARENTAL

CONTROL t], then press .

xIf you have not entered a password

The display for registering a new password

appears.

PARENTAL CONTROL

Enter a new 4-digit password,

then press .

ENTER

Disc

61GB

Enter a 4-digit password using the number

buttons, then press .

The display for confirming the password

appears.

xWhen you have already registered a

password

The display for entering the password

appears.

7Enter or re-enter your 4-digit password

using the number buttons, then press

The display for setting the playback

limitation level appears.

8Press X/x to select [STANDARD], then

press .

The selection items for [STANDARD] are

displayed.

9Press X/x to select a geographic area

as the playback limitation level, then

press .

The area is selected.

When you select [OTHERS t], select and

enter a standard code from “Parental

Control Area Code List” (page 123) using

the number buttons.

10 Press X/x to select [LEVEL], then press

The selection items for [LEVEL] are

displayed.

11 Press X/x to select the desired level,

then press .

[PARENTAL CONTROL] setting is

complete.

The lower the value, the stricter the

limitation.

To turn off the [PARENTAL

CONTROL] function

Set [LEVEL] to [OFF] in Step 11.

To play a disc for which

[PARENTAL CONTROL] is set

1Load the disc and press H.

The display for entering your password

appears.

2Enter your 4-digit password using the

number buttons, then press .

The system starts playback.

• If you forget your password, remove the disc and

repeat Steps 1 to 6 of “Restricting Playback of the

Disc” (page 60). When you are asked to enter your

password, enter “199703” using the number buttons,

then press . The display will ask you to enter a new

4-digit password. After you enter a new 4-digit

password, replace the disc in the unit and press H.

When the display for entering your password appears,

enter your new password.

1Press FUNCTION +/– repeatedly until

“DVD” appears in the front panel

display.

2Press DISPLAY while the system is

in stop mode.

The Control Menu display appears on the

TV screen.

3Press X/x to select [SETUP],

then press .

The options for [SETUP] appear.

4Press X/x to select [CUSTOM], then

press .

The Setup Display appears.

5Press X/x to select [SYSTEM SETUP],

then press .

The options for [SYSTEM SETUP] appear.

6Press X/x to select [PARENTAL

CONTROL t], then press .

The display for entering the password

appears.

LEVEL:

STANDARD:

CHANGE PASSWORD:

OFF

USA

PARENTAL CONTROL

Changing the password

62GB

7Enter your 4-digit password using the

number buttons, then press .

8Press X/x to select [CHANGE

PASSWORD t], then press .

9Enter a new 4-digit password using the

number buttons, then press .

10 To confirm your password, re-enter it

using the number buttons, then press

If you make a mistake entering

your password

Press C before you press , then input the

correct number.

Changing the System

Settings by Using the

Setup Display

You can make various adjustments to items such

as picture and sound.

Displayed items vary depending on the area.

Note

• Playback settings stored in the disc take priority over

the Setup Display settings and not all the functions

described may work.

1Press FUNCTION +/– repeatedly until

“DVD” appears in the front panel

display.

2Press DISPLAY while the system is

in stop mode.

The Control Menu display appears on the

TV screen.

3Press X/x to select [SETUP],

then press .

The options for [SETUP] appear.

4Press X/x to select [CUSTOM], then

press .

The Setup Display appears.

5Press X/x to select the setup item, then

press .

• [LANGUAGE SETUP] (page 63)

• [VIDEO SETUP] (page 63)

• [HDMI SETUP] (page 64)

• [AUDIO SETUP] (page 66)

• [SYSTEM SETUP] (page 66)

• [SPEAKER SETUP] (page 67)

Example: [VIDEO SETUP]

VIDEO SETUP

LINE:

TV TYPE:

PAUSE MODE:

16:9

VIDEO

AUTO

Selected item

Setup items

Disc

63GB

6Press X/x to select an item, then press

The options for the selected item appear.

Example: [TV TYPE]

7Press X/x to select a setting, then

press .

The setting is selected and setup is

complete.

Example: [4:3 LETTER BOX]

To reset all of the [SETUP]

settings

To reset all of the [SETUP] settings, see

“Returning the [SETUP] settings to the default”

(page 103).

Set various languages for the on-screen display

or sound track.

x[OSD] (On-Screen Display)

You can switch the display language on the TV

screen.

x[MENU] (DVD VIDEO only)

You can switch the language for the disc’s

menu.

x[AUDIO] (DVD VIDEO only)

You can switch the language of the sound track.

When you select [ORIGINAL], the language

given priority on the disc is selected.

x[SUBTITLE] (DVD VIDEO only)

You can switch the language of the subtitles

recorded on the DVD VIDEO.

When you select [AUDIO FOLLOW], the

language for the subtitles changes according to

the language you selected for the sound track.

Note

• When you select a language in [MENU], [AUDIO],

or [SUBTITLE] that is not recorded on the DVD

VIDEO, one of the recorded languages will be

automatically selected (depending on the disc, the

language may not be selected automatically).

• If you select [OTHERS t] in [MENU], [AUDIO],

and [SUBTITLE], select and enter a language code

from “Language Code List” (page 123) using the

number buttons.

Select settings according to the TV to be

connected.

Setting the display or sound

track language

[LANGUAGE SETUP]

VIDEO SETUP

LINE:

TV TYPE:

PAUSE MODE:

16:9

OFF

FULL

AUTO

16:9

4:3 LETTER BOX

4:3 PAN SCAN

Options

VIDEO SETUP

LINE:

TV TYPE:

PAUSE MODE:

4:3 LETTER BOX

VIDEO

AUTO

Selected setting

LANGUAGE SETUP

MENU:

OSD:

AUDIO:

ENGLISH

ORIGINAL

AUDIO FOLLOW

SUBTITLE:

Settings for the display

[VIDEO SETUP]

VIDEO SETUP

LINE:

TV TYPE:

PAUSE MODE:

16:9

VIDEO

AUTO

64GB

x[TV TYPE]

You can select the aspect ratio of the connected

TV.

[16:9]: Select this when you connect a wide-

screen TV or a TV with a wide mode function.

[4:3 LETTER BOX]: Select this when you

connect a 4:3 standard TV. The system displays

a wide picture with bands on the upper and

lower portions of the TV screen.

[4:3 PAN SCAN]: Select this when you connect

a 4:3 standard TV. The system automatically

displays a wide picture on the entire screen and

cuts off the portions that do not fit.

Note

• Depending on the DVD, [4:3 LETTER BOX] may be

selected automatically instead of [4:3 PAN SCAN] or

vice versa.

x[LINE]

You can select the output method for video

signals from the EURO AV T OUTPUT (TO

TV) jack on the rear panel of the unit.

[VIDEO]: The system outputs video signals.

[RGB]: The system outputs RGB signals.

Note

• If your TV does not accept RGB signals, no picture

appears on the TV screen even if you select [RGB].

Refer to the operating instructions supplied with your

TV.

• You cannot select [RGB] while “HDMI” is lit. [RGB]

automatically switches to [VIDEO] when you turn on

any connected HDMI equipment.

x[PAUSE MODE] (DVD VIDEO/DVD-R/

DVD-RW only)

You can select the picture in pause mode.

[AUTO]: The picture, including subjects that

move dynamically, is output with no jitter. This

setting is for normal usage.

[FRAME]: The picture, including subjects that

do not move dynamically, is output in high

resolution.

x[HDMI RESOLUTION]

You can select the type of video signal that is

output from the HDMI OUT jack. For details,

see “To select the type of video signal output

from the HDMI OUT jack” (page 38).

[AUTO (1920

× 1080p)]: The system outputs

the optimal video signal for the connected TV.

[1920

× 1080i]: The system outputs 1920 ×

1080i* video signals.

[1280 × 720p]: The system outputs 1280 ×

720p* video signals.

[720 × 480p]**: The system outputs 720 ×

480p* video signals.

* i: interlace, p: progressive

** Depending on the area, [720 × 480/576p] may

appear.

x[CONTROL FOR HDMI]

You can set the [CONTROL FOR HDMI]

function to on/off. This function is available

when you connect the system and TV with an

HDMI cable. For details, see “Using the Control

Settings for HDMI

[HDMI SETUP]

HDMI SETUP

CONTROL FOR HDMI:

HDMI RESOLUTION:

VOLUME LIMIT:

AUTO

(1920x1080p)

OFF

LEVEL2

YCBCR

OFF

YCBCR/RGB(HDMI):

JPEG RESOLUTION:

AUDIO(HDMI):

Disc

65GB

for HDMI Function for “BRAVIA” Sync”

(page 73).

[OFF]: Off.

[ON]: On. You can operate mutually between

components that are connected with an HDMI

cable.

x[VOLUME LIMIT]

If you change the output method of the TV to the

system speakers via the TV menu (or by

pressing THEATRE), the System Audio Control

(page 74) is activated and loud sound may be

output depending on the volume level of the

system. You can prevent this by limiting the

maximum level of the volume.

[LEVEL3]: Maximum volume level is set to 10.

[LEVEL2]: Maximum volume level is set to 15.

[LEVEL1]: Maximum volume level is set to 20.

[OFF]: Off.

Note

• This function is available only when [CONTROL

FOR HDMI] is set to [ON].

x[YCBCR/RGB (HDMI)]

You can select the type of HDMI signal output

from the HDMI OUT jack.

[YCBCR]: The system outputs YCBCR signals.

[RGB]: The system outputs RGB signals.

Note

• If the playback picture becomes distorted, set

[YCBCR] to [RGB].

• If the HDMI OUT jack is connected to a component

with a DVI jack, [RGB] signals will be automatically

output even when you select [YCBCR].

x[AUDIO (HDMI)]

You can select the audio output status from the

HDMI OUT jack.

[OFF]: The system does not output sound from

the HDMI OUT jack.

[ON]: The system outputs audio signals by

converting Dolby Digital, DTS, or 96 kHz/24-

bit PCM signals to 48 kHz/16-bit PCM.

Note

• When you connect the unit and TV with an HDMI

cable and [ON] is selected, [AUDIO DRC], [A/V

SYNC], DYNAMIC BASS, “DEC. MODE,” and

sound mode are not applied to the sound that is output

from the TV.

• When you set the function to other than “DVD” or

“USB,” the system does not output the sound from

the HDMI OUT jack even if you set [AUDIO

(HDMI)] to [ON].

x[JPEG RESOLUTION]

You can select the resolution of JPEG image

files output from the HDMI OUT jack.

[SD ]: The system outputs standard

resolution with a black frame.

[HD ]: The system outputs HD resolution

with a black frame.

[HD]: The system outputs the HD resolution

without a black frame.

[(1920 × 1080i) HD ]: The system outputs

full size HD resolution with a black frame.

[(1920 × 1080i) HD]: The system outputs full

size HD resolution without a black frame.

Note

• [JPEG RESOLUTION] is effective only when you

set [TV TYPE] in [VIDEO SETUP] to [16:9], and

you set [HDMI RESOLUTION] in [HDMI SETUP]

to other than [720 × 480p] or [720 × 480/576p].

• You can select [(1920 × 1080i) HD ] or [(1920 ×

1080i) HD] only when you set [HDMI

RESOLUTION] in [HDMI SETUP] to [1920 ×

1080i].

• The HDMI signal will stop momentarily when:

– the system is loading or unloading a DATA CD or

DATA DVD.

– you connect or remove a USB device.

66GB

x[SPEAKER FORMATION]

You can select the position of the speakers for

better surround sound. For details, see “Getting

Optimal Surround Sound for a Room”

(page 94).

x[AUTO CALIBRATION]

You can calibrate the appropriate settings

automatically. For details, see “Calibrating the

Appropriate Settings Automatically” (page 95).

x[AUDIO DRC] (DVD VIDEO only)

You can compress the dynamic range of the

sound track. [AUDIO DRC] is useful for

watching movies at low volume late at night.

[OFF]: No compression of dynamic range.

[STANDARD]: The system reproduces the

sound track with the kind of dynamic range that

the recording engineer intended.

[MAX]: The system compresses dynamic range

fully.

Note

• [AUDIO DRC] works only for Dolby Digital.

x[TRACK SELECTION] (DVD VIDEO only)

You can give the sound track which contains the

highest number of channels priority when you

play a DVD VIDEO on which multiple audio

formats (PCM, DTS, Dolby Digital, or MPEG

audio) are recorded.

[OFF]: Off.

[AUTO]: The system selects the sound track

automatically according to the priority.

Note

• When you set the item to [AUTO], the language may

change. The [TRACK SELECTION] setting has

higher priority than the [AUDIO] settings in

[LANGUAGE SETUP] (page 63). (Depending on

the disc, this function may not work.)

• If PCM, DTS, Dolby Digital sound, and MPEG audio

have the same number of channels, the system selects

PCM, DTS, Dolby Digital sound, and MPEG audio in

this order.

x[SCREEN SAVER]

You can reduce the

damage to the display device

(ghosting). Press any button (e.g.,

) to cancel

the screen saver.

[ON]: The screen saver image appears if you do

not operate the system for about 15 minutes.

[OFF]: Off.

x[BACKGROUND]

You can select the background color or picture

on the TV screen.

[JACKET PICTURE]: The jacket picture (still

picture) appears, but only when the jacket

picture is already recorded on the disc (CD-

EXTRA, etc.). If the disc does not contain a

jacket picture, the [GRAPHICS] picture

appears.

[GRAPHICS]: A preset picture stored in the

system appears.

[BLUE]: The background is blue.

[BLACK]: The background is black.

Settings for the audio

[AUDIO SETUP]

AUDIO SETUP

AUTO CALIBRATION:

SPEAKER FORMATION:

AUDIO DRC: OFF

OFF

TRACK SELECTION:

Other Settings

[SYSTEM SETUP]

SYSTEM SETUP

BACKGROUND:

SCREEN SAVER:

PARENTAL CONTROL:

JACKET PICTURE

Registration Code

DivX:

MULTI-DISC RESUME: ON

RESET:

Disc

67GB

x[PARENTAL CONTROL]

You can set the playback restrictions. For

details, see “Restricting Playback of the Disc”

(page 60).

x[DivX]

You can display the registration code for this

system.

For more information, go to

http://www.divx.com on the Internet.

x[MULTI-DISC RESUME] (DVD VIDEO/

VIDEO CD only)

You can set the [MULTI-DISC RESUME]

function to on/off.

[ON]: The system stores the resume points in

memory for up to 10 discs.

[OFF]: The system does not store the resume

points in memory. Playback restarts at the

resume point only for the current disc in the unit.

x[RESET]

You can return the [SET UP] settings other than

[PARENTAL CONTROL] to the default

settings. For details, see “Returning the

[SETUP] settings to the default” (page 103).

To obtain the best possible surround sound, set

connection of the speakers and their distance

from your listening position. Then use the test

tone to adjust the level and the balance of the

speakers to the same level.

x[CONNECTION]

If you do not connect center or surround

speakers, set the parameters for [CENTER] and

[SURROUND]. Since the front speaker and

subwoofer settings are fixed, you cannot change

them.

[FRONT]

[YES]

[CENTER]

[YES]: Normally select this.

[NONE]: Select this if no center speaker is used.

[SURROUND]

[YES]: Normally select this.

[NONE]: Select this if no surround speakers are

used.

[SUBWOOFER]

[YES]

Note

• When you change the [CONNECTION] setting, the

[STANDARD] of [SPEAKER FORMATION]

setting remains the same, but the other settings of

[SPEAKER FORMATION] return to

[STANDARD].

x[DISTANCE (FRONT)]

When you move the front speakers and center

speaker, be sure to set the parameters of the

distance (A) from the listening position to the

speakers.

You can set the parameters from 1.0 to 7.0

meters1) (3 to 23 ft) for the front speakers, from

0.0 to 7.0 meters2) (0 to 23 ft) for the center

speaker.

Settings for the speakers

[SPEAKER SETUP]

SPEAKER SETUP

DISTANCE(FRONT)

CONNECTION:

DISTANCE(SURROUND):

LEVEL(FRONT):

LEVEL(SURROUND):

TEST TONE

FRONT:

CENTER:

SURROUND:

SUBWOOFER:

YES

68GB

[L/R] 3.0 m/10 ft3): Set the front speaker

distance.

[CENTER] 3.0 m/10 ft3)4): Set the center speaker

distance (up to 1.6 meters (5 ft) closer to the

front speakers).

1)0.9 to 6.9 meters for North American models.

2)0.0 to 6.9 meters for North American models.

3)When you perform the Quick Setup (page 36), the

default settings are changed.

4)This item appears when you set [CENTER] to [YES]

in the [CONNECTION] setting.

x[DISTANCE (SURROUND)]

When you move the surround speakers, be sure

to set the parameters of the distance (B) from

the listening position to the speakers.

You can set the parameters from 0.0 to 7.0

meters1) (0 to 23 ft).

[L/R] 3.0 m/10 ft2)3): Set the surround speaker

distance (up to 5.0 meters (16 ft) closer to the

front speakers).

1)0.0 to 6.9 meters for North American models.

2)When you perform the Quick Setup (page 36), the

default settings are changed.

3)This item appears when you set [SURROUND] to

[YES] in the [CONNECTION] setting.

Note

• If all front and surround speakers are not placed at an

equal distance from your listening position, set the

distance according to the closest speaker.

• Do not place the surround speakers farther away from

your listening position than the front speakers.

• Depending on the input stream, the [DISTANCE]

setting may not be effective.

x[LEVEL (FRONT)]

You can adjust the sound level of the front

speakers, center speaker, and subwoofer. You

can set the parameters from –6.0 dB to 0 dB for

[L/R], and from –6.0 dB to +6.0 dB for

[CENTER] and [SUBWOOFER]. Be sure to set

[TEST TONE] to [ON] for easy adjustment.

[L/R] 0.0 dB: Set the front speaker level.

[CENTER] 0.0 dB*: Set the center speaker

level.

[SUBWOOFER] +2.0 dB: Set the subwoofer

level.

* This item appears when you set [CENTER] to

[YES] in the [CONNECTION] setting.

x[LEVEL (SURROUND)]

You can adjust the sound level of the surround

speakers. You can set the parameter from –6.0

dB to +6.0 dB. Be sure to set [TEST TONE] to

[ON] for easy adjustment.

[L/R] 0.0 dB*: Set the surround speaker level.

* This item appears when you set [SURROUND] to

[YES] in the [CONNECTION] setting.

x[TEST TONE]

The speakers will emit a test tone to adjust

[LEVEL (FRONT)] and [LEVEL

(SURROUND)].

[OFF]: The test tone is not emitted from the

speakers.

[ON]: The test tone is emitted from each speaker

in sequence while adjusting the level. When you

select one of the [SPEAKER SETUP] items, the

test tone is emitted from each speaker in

sequence.

Adjust the sound level as follows.

1Set the [TEST TONE] to [ON].

2Press C/X/x/c repeatedly to select the

desired speaker and the level.

3Press .

4Repeat Steps 1 to 3.

5Press C/X/x/c repeatedly to set [TEST

TONE] to [OFF] after adjusting the

speaker level.

Disc

69GB

• To adjust the volume of all the speakers at one time,

turn the VOLUME control on the unit, or press

VOLUME +/– on the remote.

• To return to the default setting when changing a

setting, select the item, then press CLEAR. Note that

only the [CONNECTION] setting does not return to

the default setting.

70GB

Presetting Radio

Stations

You can preset 20 FM stations. Before tuning,

make sure to turn down the volume to minimum.

1Press FUNCTION +/– repeatedly until

“TUNER FM” appears in the front panel

display.

2Press and hold TUNING +/– until the

auto scanning starts.

Scanning stops when the system tunes in a

station. “TUNED” and “ST” (stereo

program) appear in the front panel display.

3Press SYSTEM MENU.

4Press X/x repeatedly until “MEMORY”

appears in the front panel display.

5Press or c.

A preset number appears in the front panel

display.

6Press X/x to select the preset number

you want.

• You can select the preset number directly by

pressing the number buttons.

7Press .

“COMPLETE” appears in the front panel

display, and the station is stored.

8Repeat Steps 2 to 7 to store other

stations.

9Press SYSTEM MENU.

The system menu turns off.

To change the preset number

Select the desired preset number by pressing

PRESET +/– (page 71), then perform the

procedure from Step 3.

Tuner

FM 10 : 88.00 MHz

SONY RADIO

Station name

Current band and preset number

Current station

Tuner

71GB

Listening to the Radio

Preset radio stations in the system’s memory

first (see “Presetting Radio Stations” (page 70)).

1Press FUNCTION +/– repeatedly until

“TUNER FM” appears in the front panel

display.

The last received station is tuned in.

2Press PRESET +/– repeatedly to select

the preset station.

Each time you press the button, the system

tunes in one preset station.

• You can select the preset station number directly

by pressing the number buttons.

3Adjust the volume by pressing

VOLUME +/–.

To turn off the radio

Press "/1.

To listen to non-preset radio

stations

Use manual or automatic tuning in Step 2.

For manual tuning, press TUNING +/–

repeatedly.

For automatic tuning, press and hold TUNING

+/–. The automatic tuning stops automatically

when the system receives the radio station. To

stop the automatic tuning manually, press

TUNING +/– or x.

To listen to radio stations when

you know the frequencies

Press D.TUNING in Step 2, press the number

buttons to select the frequencies, then press .

• To improve reception, reorient the connected

antennas (aerials).

If an FM program is noisy

If an FM program is noisy, you can select

monaural reception. There will be no stereo

effect, but reception will improve.

1Press SYSTEM MENU.

2Press X/x repeatedly until “FM MODE”

appears in the front panel display.

3Press or c.

4Press X/x to select “MONO.”

• “STEREO”: Stereo reception.

• “MONO”: Monaural reception.

5Press .

The setting is made.

6Press SYSTEM MENU.

The system menu turns off.

You can enter a name for preset stations. These

names (for example, “ABC”) appear in the front

panel display when a station is selected.

Only one name can be entered for each preset

station.

Note

• You cannot enter a name for preset stations of the

Radio Data System (RDS) (page 72).

1Press FUNCTION +/– repeatedly until

“TUNER FM” appears in the front panel

display.

The last received station is tuned in.

2Press PRESET +/– repeatedly to select

the preset station you want to create an

index name for.

3Press SYSTEM MENU.

4Press X/x repeatedly until “NAME IN”

appears in the front panel display.

5Press or c.

6Create a name by using C/X/x/c.

Press X/x to select a character, then press c

to move the cursor to the next position.

Naming preset stations

72GB

You can input letters, numbers, and other

symbols for a radio station.

If you make a mistake

Press C/c repeatedly until the character to

be changed flashes, then press X/x to select

the desired character.

To erase the character, press C/c

repeatedly until the character to be erased

flashes, then press CLEAR.

7Press .

“COMPLETE” appears in the front panel

display, and the station name is stored.

8Press SYSTEM MENU.

The system menu turns off.

When the system is set to “TUNER FM,” you

can check the frequency using the front panel

display.

Press DISPLAY.

Each time you press DISPLAY, the display

changes:

1 t 2 t .... t 1 t ....

When the station name is set

1 Station name

Ex. “SONY RADIO”

2 Frequency

Ex. “FM1 87.50”

3 The “FM MODE” setting

Ex. “STEREO”

When the station name is not set

1 Frequency

Ex. “FM1 87.50”

2 The “FM MODE” setting

Ex. “STEREO”

Using the Radio Data

System (RDS)

The Radio Data System (RDS) is a broadcasting

service that allows radio stations to send

additional information along with the regular

program signal. This tuner offers convenient

RDS features, such as station name display.

RDS is available only for FM stations.*

Note

• RDS may not work properly if the station you are

tuned to is not transmitting the RDS signal properly,

or if the signal strength is weak.

* Not all FM stations provide RDS service, nor do

they provide the same type of services. If you are not

familiar with the RDS system, check with your local

radio stations for details on RDS services in your

area.

Simply select a station from the FM band.

When you tune in a station that provides RDS

services, the station name* appears in the front

panel display.

* If an RDS broadcast is not received, the station

name may not appear in the front panel display.

Viewing the station name or

frequency in the front panel

display

What is the Radio Data

System?

Receiving RDS broadcasts

Control for HDMI/External Audio Device

73GB

Using the Control for

HDMI Function for

“BRAVIA” Sync

This function is available on TVs with the

“BRAVIA” Sync function only.

By connecting Sony components that are

compatible with the Control for HDMI function

with an HDMI cable, operation is simplified as

below:

– Theatre Mode (page 74)

– One-Touch Play (page 74)

– System Power Off (page 74)

– System Audio Control (page 74)

– Volume Limit (page 75)

– Language Follow (page 75)

Control for HDMI is a mutual control function

standard used by CEC (Consumer Electronics

Control) for HDMI (High-Definition

Multimedia Interface).

The Control for HDMI function will not work in

the following cases:

– When you connect this system to a

component which is not compatible with the

Control for HDMI function.

– A component does not have an HDMI jack.

There are convenient buttons on the system’s

remote for operating the TV, such as

THEATRE, ONE-TOUCH PLAY, TV [/1. For

details, see “Controlling the TV with the

Supplied Remote” (page 96) and refer to the

operating instructions of the TV.

Note

• Depending on the connected component, the Control

for HDMI function may not work. Refer to the

operating instructions supplied with the component.

• The Control for HDMI function may not work if you

connect a component other than a Sony component,

even if the component is compatible with the Control

for HDMI function.

(Control for HDMI - Easy Setting)

The system is compatible with the Control for

HDMI - Easy Setting function. If the TV is

compatible with the Control for HDMI - Easy

Setting function, you can set the system’s

[CONTROL FOR HDMI] function

automatically by setting the TV. For details,

refer to the operating instructions of the TV.

If the TV is not compatible with the Control for

HDMI - Easy Setting function, set the Control

for HDMI function of the system and TV

manually.

1Make sure that the system and the TV

are connected with an HDMI cable.

2Turn on the TV and press [/1 to turn on

the system.

3Switch the input selector on your TV so

that the signal from the system through

the HDMI input appears on the TV

screen.

4Set the Control for HDMI function of the

system and TV.

For details of the system settings, see the

following Steps. For details of the setting of

the TV, refer to the operating instructions of

the TV (depending on the TV, the default

setting of the Control for HDMI function

may be set to off).

To set the [CONTROL FOR HDMI]

function to on/off

1Press FUNCTION +/– repeatedly until

“DVD” appears in the front panel

display.

Control for HDMI/External Audio

Device

THEATRE

BRAVIA Sync

ONE-TOUCH

PLAY

Preparing the Control for HDMI

function

74GB

2Press DISPLAY while the system is

in stop mode.

The Control Menu display appears on the

TV screen.

3Press X/x to select [SETUP],

then press .

The options for [SETUP] appear.

4Press X/x to select [CUSTOM], then

press .

The Setup Display appears.

5Press X/x to select [HDMI SETUP], then

press .

The options for [HDMI SETUP] appear.

6Press X/x to select [CONTROL FOR

HDMI], then press .

7Press X/x to select the setting, then

press .

•[OFF]: Off.

• [ON]: On.

(Theatre Mode)

If your TV is compatible with the Theatre Mode,

you can enjoy optimal image and sound quality

suited for movies, and sound is output from the

system’s speakers automatically by pressing

THEATRE.

(One-Touch Play)

By only pressing ONE-TOUCH PLAY, the TV

turns on, the TV is set for DVD input mode, and

the system starts playing a disc automatically.

Note

• One-Touch Play does not work when you press H.

The system and TV work as follows (e.g.):

(System Power Off)

When you turn the TV off by using the POWER

button on the TV’s remote or TV [/1 on the

system’s remote, the system turns off

automatically.

Note

• Before using the System Power Off function, set the

function for TV power. For details, refer to the

operating instructions of the TV.

• Depending on the status of the system (ex. while

using other than “DVD,” “TV,” or “USB” functions,

or playing a CD), the system may not turn off

automatically.

(System Audio Control)

You can enjoy TV sound via this system easily.

To use this function, connect the system and the

TV with a SCART (EURO AV) cable and an

HDMI cable (page 26).

Depending on the TV, when you set the system

to the “TV” function, the System Audio Control

function is activated. TV sound is output from

the system speakers, and the volume of the TV

speakers is minimized automatically.

You can use the System Audio Control function

as follows:

• While you are watching the TV and the

function of the system is switched to “TV,” TV

Using the Theatre Mode

Watching a DVD by a single

button press

This system TV

Turns on. (If not already

turned on.)

Switches to “DVD”

function.

Starts playing the disc and

outputs the sound.

Turns on. (If not already

turned on.)

Switches to HDMI input.

Minimizes sound level.

(System Audio Control)

Turning the system off in sync

with the TV

Enjoying TV sound from the

speakers by this system

Control for HDMI/External Audio Device

75GB

sound is output from the system speakers

automatically.

• While you are watching the TV and the

function of the system is switched to “DVD”

or “USB,” sound of the selected system

function is output from the system speakers;

TV sound is not output via the TV speakers.

• You can control the system’s volume by the

remote of the TV.

• If you turn the system off or set the function of

the system to other than “TV,” “DVD,” or

“USB,” TV sound is output from the TV

speakers.

You can also operate the System Audio Control

function via the TV menu. For details, refer to

the operating instructions of the TV.

Note

• While the TV is in PAP (picture and picture) mode,

the System Audio Control function will not work.

When the TV exits PAP mode, the output method of

the TV returns to the one before PAP mode.

• While transferring songs on an audio CD onto a USB

device, the System Audio Control function will not

work.

• You can connect the system and the TV audio

digitally. For details, see page 26.

(Volume Limit)

If you change the output method of the TV to the

system speakers via the TV menu (or by

pressing THEATRE), loud sound may be output

depending on the volume level of the system.

You can prevent this by limiting the maximum

level of the volume. For details, see “[VOLUME

LIMIT]” (page 65).

(Language Follow)

When you change the language for the on-screen

display of the TV, the system’s on-screen

display language is also changed. However,

when the system’s on-screen display is

displayed, this function does not work.

Setting the Maximum Volume

Level of the System

Changing the language for the

on-screen display of the TV

76GB

Playing Back Files of a

USB Device

You can play audio files (MP3/WMA/AAC

files)/JPEG image files/video files (DivX/

MPEG4 video files) stored in a USB device such

as the digital music player or USB storage media

(not supplied) by connecting the USB device to

the unit.

For a list of USB devices that can be connected

to the unit, see “Playable USB Devices”

(supplement).

The audio formats that can be played back by the

system are MP3/WMA/AAC files* only.

* Files with copyright protection (Digital Rights

Management) cannot be played by the system.

Note

• The system cannot play WMA/AAC files on a DATA

CD/DATA DVD.

About playable USB devices

• Do not use USB devices other than these USB

devices. Operation of models not listed here is

not guaranteed.

• Operation may not always be ensured even

when using these USB devices.

• Some of these USB devices may not be

available for purchase in certain areas.

• During playback or transferring of files, there

is a small possibility that these operations may

be stopped due to excess static buildup in the

system or the USB device. In this case, remove

the USB device and reconnect it, then retry the

operation from the beginning.

• When formatting a USB device, be sure to do

so using the device itself, or dedicated

formatting software for the device. Otherwise,

you may be unable to properly transfer from

the USB device to this system.

• Some files supported by the Walkman® are not

supported by this system.

• When connecting a Walkman® to the system,

be sure to connect after the display “Creating

Library” or “Creating Database” on the

Walkman® has disappeared.

• When transferring music to a Walkman® using

“Media Manager for WALKMAN,” be sure to

transfer in MP3 format. For details, refer to the

operating manual supplied with the

Walkman®.

1Press FUNCTION +/– repeatedly until

“USB” appears in the front panel

display.

2Connect a USB device (digital music

player or USB storage media) to the

(USB) port.

When you connect the USB device,

“READING” appears in the front panel

display until the system reads all data of the

USB device.

Note

• Do not forcibly insert the USB device, as this may

cause the device to be damaged.

• Do not connect any devices or objects other than a

USB device.

• It may take about 10 seconds before “READING”

appears in the front panel display depending on the

type of the USB device.

To remove the USB device

1Press x to stop playback.

2Press [/1 to turn off the system.

3Remove the USB device.

Notes on the USB device

• The system can play back up to 200 folders,

including albums (folders) that do not contain

audio files and JPEG image files. When more

than 200 folders are in the USB device, folders

that are recognized by the system differ

depending on the folder configuration.

Connecting the USB device

USB device

Control for HDMI/External Audio Device

77GB

• The system can play back the following files.

The system will play back any data with the

extension above, even if it is not MP3/WMA/

AAC/JPEG/DivX/MPEG4 format. Playing

this data may generate a loud noise which

could damage your speaker system.

• The following USB devices/situations can

increase the time it takes to start playback:

– a USB device recorded with a complicated

tree structure.

– when the audio files, JPEG image files, or

video files in another folder have just been

played back.

• Some USB devices cannot be played back on

the system depending on the file format.

• The system can play back to a depth of 8

folders only.

• The system may not be able to play an audio

file, JPEG image file, or video file depending

on the file type.

• When the USB device is inserted, the system

reads all the files on the USB device. If there

are many folders or files on the USB device, it

may take a long time to finish reading the USB

device.

• Do not connect the system and the USB device

through a USB hub.

• With some connected USB devices, after an

operation is performed, there may be a delay

before it is performed by this system.

• This system does not necessarily support all

the functions provided in a connected USB

device.

• Files recorded by a device such as a computer

may not be played back in the order in which

they were recorded.

• The playback order for the system may differ

from the playback order of the connected USB

device.

• Always turn off the system before removing

the USB device. Removing the USB device

while the system is on may corrupt the data on

the USB device.

• Do not save other types of files or unnecessary

folders on a USB device that has audio files,

JPEG image files, or video files.

• Folders that have no audio files, JPEG image

files, or video files are skipped.

• Compatibility with all MP3/WMA/AAC

encoding/writing software, recording devices,

and recording media cannot be guaranteed. An

incompatible USB device may produce noise

or interrupted audio or may not play at all.

• Compatibility with all MPEG4 video

encoding/writing software, recording devices,

and recording media cannot be guaranteed.

• Before using the USB device, make sure that

no virus-ridden files are on the USB device.

1Press FUNCTION +/– repeatedly until

“USB” appears in the front panel

display.

2Connect a USB device to the (USB)

port.

After reading all data of the USB device,

the list of folders appears on the TV screen.

3Press DISPLAY.

The Control Menu display appears on the

TV screen.

4Press X/x to select [MEDIA],

then press .

The options for [MEDIA] appear.

5When [MUSIC] is selected, press DVD

MENU. When other than [MUSIC] is

selected, press X/x to select [MUSIC],

then press .

A list of folders that contain audio files

appears.

The selected folder is highlighted in yellow.

File Extension of the file

MP3 file “.mp3”

WMA file “.wma”

AAC file “.m4a”

JPEG image file “.jpg” or “.jpeg”

DivX video file “.avi” or “.divx”

MPEG4 video file “.mp4” or “.m4v”

Selecting an audio file or

folder

78GB

6Press X/x to select a folder.

xTo play audio files in a folder

Press H to start playing the selected

folder.

xTo select an audio file

Press .

The list of files contained in the folder

appears.

Press X/x to select a file and press .

The system starts playing the selected file.

You can turn the file list off by pressing

DVD MENU. Pressing DVD MENU again

will display the folder list.

• The system can recognize up to 150 audio files in a

single folder.

To go to the next or previous

page

Press / .

To stop playback

Press x.

To play the next or previous

audio file

Press > to play the next audio file. Press .

twice to play the previous audio file.

When you press . once, you can go to the

beginning of the current audio file.

Note that you can select the next folder by

continuing to press > after the last file on the

current folder, but that you cannot return to the

previous folder by pressing .. To return to

the previous folder, select the folder from the

folder list.

To return to the previous display

Press O RETURN.

To turn on/off the display

Press DVD MENU.

To select the folder via the

remote

During playback or pause, you can select the

desired folder quickly by pressing +/–.

Other operations

See “Other operations” (page 45).

1Press FUNCTION +/– repeatedly until

“USB” appears in the front panel

display.

2Connect a USB device to the (USB)

port.

After reading all data of the USB device,

the list of folders appears on the TV screen.

3Press DISPLAY.

The Control Menu display appears on the

TV screen.

4Press X/x to select [MEDIA],

then press .

The options for [MEDIA] appear.

5When [PHOTO] is selected, press DVD

MENU. When other than [PHOTO] is

selected, press X/x to select [PHOTO],

then press .

A list of folders that contain JPEG files

appears.

The selected folder is highlighted in yellow.

FOLDER LIST

02 1st Album (1986)

03 In the Middle of Nowhere (1986)

04 Ready for Romance (1986)

05 In the Garden of Venus (1987)

06 Romantic Warriors (1987)

07 Back for Good (1988)

08 Alone (1999)

01 Let's Talk About Love (1985)

TRACK LIST

03 In the Middle of Nowher...

02_Riding_On_A_White_Swan

03_Give_Me_Peace_On_Earth

04_Sweet_Little_Shella

05_Ten_Thousand_Lonely_Drums

06_Lonely_Tears_In_Chinatown

07_In_Shaire

01_Geronimo_s_Cadillac Selecting a JPEG image file or

folder

Control for HDMI/External Audio Device

79GB

6Press X/x to select a folder.

xTo go to the next or previous page

Press / .

xTo play JPEG image files in a folder

as a slide show

Press H to start playing the selected

folder.

The JPEG images are played as a slide

show. You can change the interval of the

slide show (page 79), and add effects to the

slide show (page 80).

xTo select a JPEG image file by

displaying the image browser

Press PICTURE NAVI.

Previews of JPEG image files in the folder

appear in 16 subscreens.

Press C/X/x/c to select the JPEG image

file you want to view, then press .

To return to previous screen, press O

RETURN.

• The system can recognize up to 150 JPEG

image files in a single folder.

To play the next or previous JPEG

image file

Press c/C when the Control Menu display is not

displayed. Note that you can select the next

folder by continuing to press c after the last

image on the current folder, but that you cannot

return to the previous folder by pressing C. To

return to the previous folder, select the folder

from the folder list.

To rotate a JPEG image file

When a JPEG image file is displayed on the TV

screen, you can rotate the JPEG image file in 90

degree increments.

Press X/x while viewing a JPEG image file.

Press CLEAR to return to normal view.

Note

• You cannot rotate the JPEG image file when you set

[JPEG RESOLUTION] in [HDMI SETUP] to [(1920

× 1080i) HD ] or [(1920 × 1080i) HD].

To stop playback

Press x.

To turn on/off the display

Press DVD MENU.

To select the folder via the

remote

During playback or pause, you can select the

desired folder quickly by pressing +/–.

Other operations

See “Other operations” (page 45).

To select the slide show duration

of JPEG image files

1Press DISPLAY.

The Control Menu display appears on the

TV screen.

2Press X/x to select [INTERVAL],

then press .

The options for [INTERVAL] appear.

3Press X/x to select a setting.

• [NORMAL]: You can set to the standard

duration.

• [FAST]: You can set the duration shorter

than [NORMAL].

• [SLOW 1]: You can set the duration

longer than [NORMAL].

• [SLOW 2]: You can set the duration

longer than [SLOW 1].

4Press .

FOLDER LIST

02 Travelling 01

03 2003.08.20

04 Flowers

05 Travelling 02

06 Animals

07 2003.11.16

08 2003.12.03

01 Happy birthday

1234

5678

13 14 15 16

9101112

80GB

Note

• Some JPEG image files may take longer to display

than the option you selected. Especially progressive

JPEG image files or JPEG image files of 3,000,000

pixels or more.

To select an effect for JPEG

image files in the slide show

1Press DISPLAY.

The Control Menu display appears on the

TV screen.

2Press X/x to select [EFFECT],

then press .

The options for [EFFECT] appear.

3Press X/x to select a setting.

• [MODE 1]: The JPEG image file sweeps

in from top to bottom.

• [MODE 2]: The JPEG image file stretches

out from left to right of the TV screen.

• [MODE 3]: The JPEG image file stretches

out from the center of the TV screen.

• [MODE 4]: The JPEG image files

randomly cycle through the effects.

• [MODE 5]: The next JPEG image file

slides over the previous image.

• [OFF]: Off.

4Press .

Note

• The [EFFECT] setting is not effective when you set

[JPEG RESOLUTION] in [HDMI SETUP] to [(1920

× 1080i) HD ] or [(1920 × 1080i) HD] (page 65).

1Press FUNCTION +/– repeatedly until

“USB” appears in the front panel

display.

2Connect a USB device to the (USB)

port.

After reading all data of the USB device,

the list of folders appears on the TV screen.

3Press DISPLAY.

The Control Menu display appears on the

TV screen.

4Press X/x to select [MEDIA],

then press .

The options for [MEDIA] appear.

5When [VIDEO] is selected, press DVD

MENU. When other than [VIDEO] is

selected, press X/x to select [VIDEO],

then press .

A list of folders that contain video files

appears.

The selected folder is highlighted in yellow.

6Press X/x to select a folder.

xTo play video files in a folder

Press H to start playing the selected

folder.

xTo select a video file

Press .

The list of files contained in the folder

appears.

Press X/x to select a file and press .

The system starts playing the selected file.

You can turn the file list off by pressing

DVD MENU. Pressing DVD MENU again

will display the folder list.

To go to the next or previous

page

Press / .

To stop playback

Press x.

Selecting a video file or folder

FOLDER LIST

NEW YEAR'S DAY

MY FAVOURITES

SUMMER 2003

FILE LIST

MY FAVOURITES

VENUS

HAWAII 2004

Control for HDMI/External Audio Device

81GB

To play the next or previous video

file

Press > to play the next video file. Press .

twice to play the previous video file.

When you press . once, you can go to the

beginning of the current video file.

Note that you can select the next folder by

continuing to press > after the last file on the

current folder, but that you cannot return to the

previous folder by pressing .. To return to

the previous folder, select the folder from the

folder list.

To return to the previous display

Press O RETURN.

To turn on/off the display

Press DVD MENU.

To select the folder via the

remote

During playback or pause, you can select the

desired folder quickly by pressing +/–.

Other operations

See “Other operations” (page 45).

Note

• For details on video files, see “Enjoying Video Files”

(page 58).

You can select playback priority when mixed

media (audio files, JPEG image files, or video

files) are in the USB device.

1Press FUNCTION +/– repeatedly until

“USB” appears in the front panel

display.

2Connect a USB device to the (USB)

port.

After reading all data of the USB device,

the list of folders appears on the TV screen.

3Press DISPLAY.

The Control Menu display appears on the

TV screen.

4Press X/x to select [MEDIA],

then press .

The options for [MEDIA] appear.

5Press X/x to select a setting.

•[MUSIC]: Audio file playback has

priority.

• [VIDEO]: Video file playback has

priority.

• [PHOTO]: JPEG image file playback has

priority. You can play JPEG image files as

a slide show.

6Press .

For details of the playback priority of file

types under the [MEDIA] setting, see

“Playback priority of file types” (page 122).

1Press DISPLAY during playback.

The Control Menu display appears on the

TV screen.

2Press X/x to select

[BROWSING], then press .

The options for [BROWSING] appear.

3Press X/x to select the desired list,

then press .

• [FOLDER LIST]: The list of folders

appears. Follow Step 6 of “Selecting an

audio file or folder” (page 77), “Selecting

a JPEG image file or folder” (page 78), or

“Selecting a video file or folder”

(page 80).

• [PICTURE LIST] (JPEG image files

only): Previews of JPEG image files in the

folder appear in 16 subscreens. Follow

Step 2 of “Selecting a JPEG image file or

folder” (page 78).

Selecting playback priority of

the file type

Displaying the list of audio

files/JPEG image files/video

files

82GB

You can play the audio files/JPEG image files/

video files on the USB device repeatedly.

1Press DISPLAY during playback.

The Control Menu display appears on the

TV screen.

2Press X/x to select [REPEAT],

then press .

The options for [REPEAT] appear.

3Press X/x to select the item to be

repeated.

•[OFF]: Off.

• [MEMORY]: You can repeat all of the

folders on the USB device.

• [FOLDER]: You can repeat the current

folder.

• [TRACK] (audio files only): You can

repeat the current file.

• [FILE] (video files only): You can repeat

the current file.

4Press .

The item is selected.

To return to normal play

Press CLEAR, or select [OFF] in Step 3.

To turn off the Control Menu

display

Press DISPLAY repeatedly until the Control

Menu display is turned off.

You can search a USB device by audio file,

JPEG image file, video file, or folder. As audio

files, JPEG image files, and video files are

assigned unique numbers on the USB device,

you can select the desired audio file, JPEG

image file, or video file by entering its number.

1Press DISPLAY.

The Control Menu display appears on the

TV screen.

2Press X/x to select the search method.

• [FOLDER]: Folders.

• [TRACK]: Audio files.

• [FILE]: JPEG image files/video files.

[** (**)] is selected (** refers to a number).

The number in parentheses indicates the

total number of audio files, JPEG image

files, video files, or folders.

3Press .

[** (**)] changes to [– – (**)].

4Press X/x or the number buttons to

select the desired number.

If you make a mistake, press CLEAR to

cancel the number.

5Press .

The system starts playback from the

selected number.

Press DISPLAY repeatedly.

Each time you press DISPLAY while playing

the USB device, the display changes:

1 y 2

1 Playing time and current track number

2 Track (file) name*

Playing repeatedly

(Repeat Play)

Searching for a file or folder Viewing the information of an

audio file in the front panel

display

USB

1( 144)

1( 1)

T 0: 23

Selected row

USB

1( 144)

1( 1)

T 1: 31

Control for HDMI/External Audio Device

83GB

* If an MP3 file has the ID3 tag, the system will

display a folder name/track (file) name from the ID3

tag information.

The system can support ID3 ver 1.0/1.1/2.2/2.3.

ID3 ver 2.2/2.3 tag information display has priority

when both ID3 ver 1.0/1.1 and ver 2.2/2.3 tags are

used for a single MP3 file.

Note

• If a file name of the audio file cannot be displayed,

“*” will appear in the front panel display instead.

• The file name may not be displayed depending on the

text.

• Playing time of audio files may not be displayed

correctly.

You can display the information of an audio file/

video file such as time information, name of the

folder/audio file/video file, and the audio bit rate

(the amount of data per second of the current

audio) on the TV screen.

Press DISPLAY during playback.

The information of an audio file appears on the

TV screen.

Example for playback of an audio file

* Appears when playing an audio file.

** If an MP3 file has an ID3 tag, the system will

display a folder name/track (file) name from the ID3

tag information.

The system can support ID3 ver 1.0/1.1/2.2/2.3.

ID3 ver 2.2/2.3 tag information display has priority

when both ID3 ver 1.0/1.1 and ver 2.2/2.3 tags are

used for a single MP3 file.

Note

• Characters/marks may not be displayed in some

languages.

• Depending on the type of file being played, the

system can only display a limited number of

characters. Also, depending on the file, not all text

characters will be displayed.

You can check the date information during

playback when the Exif* tag is recorded in the

JPEG image file.

Press DISPLAY during playback.

The Control Menu display appears on the TV

screen.

* “Exchangeable Image File Format” is a digital

camera image format defined by the Japan

Electronics and Information Technology Industries

Association (JEITA).

Viewing the information of an

audio file/video file on the TV

screen

T 0: 13 192k MP3

2002_Remixes

Soul_Survivor_rap_version

Bit rate*

Folder name** Audio file**/video file

name

Checking the date information

of a JPEG image file

USB

6( 30)

2( 2)

16/9/2002

Date information

84GB

Transferring Songs onto

a USB Device

You can transfer songs on an audio CD onto a

USB device by encoding to MP3 format. You

can also transfer MP3 files on a DATA CD/

DATA DVD onto a USB device.

For connecting the USB device, see

“Connecting the USB device” (page 76).

The transferred music is limited to private use

only. Use of the music beyond this limit requires

permission of the copyright holders.

Notes on USB transferring

• Do not connect the unit and the USB device

through a USB hub.

• Make sure there is enough space in the USB

device for transferring.

• Do not remove the USB device during

transferring.

• When you are transferring tracks from a CD,

the tracks are recorded as 128 kbps MP3 files.

• When you are transferring MP3 files from a

DATA CD/DATA DVD, the MP3 files are

transferred with the same bit rate as the

original MP3 files.

• CD text information is not transferred in the

created MP3 files.

• If you stop a transfer halfway, the MP3 file that

was being created is deleted.

• Transferring stops automatically if:

– The USB device runs out of space during

transfer.

– The number of MP3 files on the USB

device reaches the limit for the number that

the system can recognize.

• You can store up to 150 files in a folder.

• You can store up to 199 folders in a single

USB device.

• If a folder or file that you are trying to transfer

already exists on the USB device with the

same name, a sequential number is added after

the name without overwriting the original

folder or file.

1Load an audio CD.

2Press DISPLAY while the system is

in stop mode.

The Control Menu display appears on the

TV screen.

3Press X/x to select [USB

TRANSFER], then press .

4Press .

“READING” appears in the front panel

display until the tracks recorded on the

audio CD appear on the TV screen.

Note

• It takes several minutes to display the tracks

depending on the number of tracks.

5Select a track that you want to transfer.

xTo select the desired track

Press X/x to select the track, then press .

The tracks are marked in the order that you

select.

xTo select all tracks on the audio CD

Press C/X/x/c to select [x ALL], then

press .

xTo cancel the track

Press X/x to select the track, then press .

The mark on the track is removed.

xTo cancel all the tracks

Press C/X/x/c to select [s ALL], then

press .

Transferring tracks on an

audio CD onto a USB device

USB TRANSFER

TRACK 01

1START

ALL

TRACK 02

TRACK 03

TRACK 04

TRACK 05

TRACK 06

TRACK 07

TRACK 08

ALL

Remaining space of the USB device

Tracks to be transferred.

Control for HDMI/External Audio Device

85GB

6Press C/X/x/c to select [START], then

press .

The system starts transferring and the status

of transferring appears.

To cancel transferring, press x.

1Load a DATA CD/DATA DVD.

2Press DISPLAY while the system is

in stop mode.

The Control Menu display appears on the

TV screen.

3Press X/x to select [USB

TRANSFER], then press .

4Press X/x to select [TRACK] or

[FOLDER], then press .

• [TRACK]: The tracks recorded on the

DATA CD/DATA DVD appear. You can

transfer the desired MP3 files.

• [FOLDER]: The folders recorded on the

DATA CD/DATA DVD appear. You can

transfer all MP3 files in the folder. Go to

Step 6.

“READING” appears in the front panel

display until the tracks/folders appear on

the TV screen.

Note

• It takes several minutes to display the tracks/

folders depending on the number of tracks/

folders.

5Press X/x to select the desired folder,

then press .

The MP3 files in the selected folder appear.

6Select an MP3 file/folder that you want

to transfer.

xTo select the desired MP3 file/folder

Press X/x to select the MP3 file/folder, then

press .

The MP3 files/folders are marked.

xTo select all MP3 files/folders

Press C/X/x/c to select [ ALL], then

press .

xTo cancel the MP3 file/folder

Press X/x to select the MP3 file/folder, then

press . The mark on the MP3 file/folder

is removed.

xTo cancel all MP3 files/folders

Press C/X/x/c to select [ ALL], then

press .

7Press C/X/x/c to select [START], then

press .

The system starts transferring and the

transferring status appears.

To cancel transferring, press x.

You can transfer tracks/MP3 files simply onto a

USB device by using REC TO USB.

To transfer all tracks on an audio

CD or all MP3 files onto a USB

device

Tracks on an audio CD are transferred onto a

USB device by encoding to MP3 format.

1Load an audio CD/DATA CD/DATA

DVD.

Transferring MP3 files on a

DATA CD/DATA DVD onto a USB

device

Transferring by single button

press

USB TRANSFER

START

ALL

01_Back_Seat_O...

02_One_Nights_...

03_Are_You_Ma...

04_I_Can_Lose_...

05_Soul_Survivo...

06_Strangers_B...

07_Stay_maxi_ve...

ALL

2002_Remixes

Remaining space of the USB device

MP3 files/folders to be transferred.

86GB

2Press x.

3Press REC TO USB on the unit.

REC TO USB lights up and “READING”

appears in the front panel display. Then,

“PUSH PLAY” and the remaining space of

the USB device appear alternately in the

front panel display.

4Press H.

Transferring starts.

When transferring is completed,

“COMPLETE” appears in the front panel

display and the disc and the USB device

stop automatically.

To cancel transferring, press x.

To transfer a single track on an

audio CD or a single MP3 file onto

a USB device

You can transfer the track/MP3 file that is

currently playing back. A track on an audio CD

is transferred onto a USB device by encoding to

MP3 format.

1Load an audio CD/DATA CD/DATA

DVD.

2Select the desired track/MP3 file, then

press H.

Playback of the selected track/MP3 file

starts.

3Press REC TO USB on the unit.

REC TO USB lights up and “READING”

appears in the front panel display. Then,

“PUSH PLAY” and the remaining space of

the USB device appear alternately in the

front panel display.

4Press H.

Transferring of the selected track/MP3 file

starts.

When transferring is completed,

“COMPLETE” appears in the front panel

display and the disc and the USB device

stop automatically.

To cancel transferring, press x.

When transferring onto a USB device, a

“MUSIC” folder is created directly below the

“ROOT”. Folders and files are generated within

this “MUSIC” folder as follows according to the

transferring method and source.

• When transferring all tracks on an audio CD or

all MP3 files on a DATA CD/DATA DVD

• When transferring a single track on an audio

CD or a single MP3 file on a DATA CD/

DATA DVD

1)Up to 64 characters of the name are assigned

(including the extension).

2)Folders are assigned in numeric order thereafter.

3)Files are assigned in numeric order thereafter.

4)A new file is transferred in the “REC1-MP3” or

“REC1-CD” folder each time REC1 transferring is

performed.

You can erase audio files (“.mp3,” “.wma,” or

“.m4a”) on the USB device.

1Press FUNCTION +/– repeatedly until

“USB” appears in the front panel

display.

2Press X/x to select a folder.

xTo erase all audio files in a folder

Press CLEAR.

xTo erase an audio file

Press .

Folder and file generation

rules

Source Folder name File name

MP3 Same as the transferring source1)

Audio CD “FLDR001”2) “TRACK001”3)

Source Folder name File name

MP3 “REC1-MP3”4) Same as the

transferring

source1)

Audio CD “REC1-CD”4) “TRACK001”3)

Erasing audio files on a USB

device

Control for HDMI/External Audio Device

87GB

The list of files contained in the folder

appears.

Press X/x to select the desired audio file,

then press CLEAR.

3Press C/c to select [YES], then press

To cancel, select [NO], then press .

Note

• Do not remove the USB device while erasing.

• If the folder to be erased contains non-audio format

files or sub folders, these are erased from the list on

the TV screen, but are not erased from the USB

device.

Using a Sony Ericsson

Mobile Phone

You can connect a Sony Ericsson mobile phone

to the system and enjoy music from it via this

system, or transfer music from this system to the

mobile phone.

1Connect the mobile phone to the

(USB) port.

2Set the data transfer mode of your

mobile phone to File Transfer (Mass

Storage).

For details, refer to the operating

instructions supplied with the mobile

phone.

3Perform playback or transfer via the

system.

• Playback: See “Playing Back Files of a

USB Device” (page 76).

• Transferring: See “Transferring Songs

onto a USB Device” (page 84)

Note

• Connect to this system with the mobile phone turned

on.

• Use the USB cable supplied with the mobile phone

when connecting to the system.

• While the mobile phone is connected to this system,

do not insert or detach the memory card.

• Some files supported by the mobile phone may not be

supported by the system.

• When a song is registered in a music playlist on your

mobile phone and you erase the song via this system,

the playlist entry is not modified.

88GB

Using the DIGITAL MEDIA

PORT Adapter

The DIGITAL MEDIA PORT (DMPORT)

adapter is for enjoying sound from a portable

audio source or computer. By connecting a

DIGITAL MEDIA PORT adapter, you can

enjoy sound from the connected component on

the system.

Available DIGITAL MEDIA PORT adapters

vary in each area.

For details on connecting the DIGITAL MEDIA

PORT adapter, see page 28.

Note

• Do not connect an adapter other than the DIGITAL

MEDIA PORT adapter.

• Do not connect or disconnect the DIGITAL MEDIA

PORT adapter to/from the unit while the system is

turned on.

• When you use the system and the Bluetooth Wireless

Audio Adapter (such as TDM-BT1, not supplied) at

the same time, transmission distance between the

Bluetooth transmitter and Bluetooth Wireless Audio

Adapter may be reduced. In this case, place the

Bluetooth transmitter as far as possible from the

system, or move the Bluetooth Wireless Audio

Adapter closer to the Bluetooth transmitter.

• When you use the system and the Wireless Network

Audio Adapter (such as TDM-NC1, not supplied) at

the same time, place the Wireless Network Audio

Adapter as far as possible from the system.

1Press FUNCTION +/– repeatedly until

“DMPORT” appears in the front panel

display.

2Start playback of the connected

component.

The sound and images from the connected

component are played on the system or

connected TV.

For operation details, refer to the operating

instructions of the DIGITAL MEDIA

PORT adapter.

Note

• Depending on the type of DIGITAL MEDIA PORT

adapter, images are also output. In this case, the

system outputs the EURO AV T OUTPUT (TO

TV) signal only regardless of the type of video signal

• Depending on the type of DIGITAL MEDIA PORT

adapter, you may be able to operate a connected

component using either the buttons on the remote or

the unit. The following illustration shows an example

of buttons that can be used in this case.

Playing the connected

component on the system

./>

Control for HDMI/External Audio Device

89GB

Using an S-AIR Product

The unit is compatible with the S-AIR function

(page 120), which allows sound transmission

between S-AIR products.

About S-AIR products

There are two types of S-AIR products.

• S-AIR main unit (this unit): This is for

transmitting sound. You can use up to three

S-AIR main units. (The number of usable

S-AIR main units depends on the use

environment.)

• S-AIR sub unit: This is for receiving sound.

–Surround amplifier: You can enjoy

surround speaker sound wirelessly.

–S-AIR receiver: You can enjoy system

sound in another room.

Note

• You cannot operate this function if you do not insert

the wireless transceiver into the unit correctly

(page 32).

Simply by matching the ID of the unit and the

S-AIR sub unit, you can establish sound

transmission.

To set the ID of the unit

1Press "/1 on the unit.

The system turns on.

2Press SYSTEM MENU.

3Press X/x repeatedly until “S-AIR ID”

appears in the front panel display, then

press or c.

4Press X/x to select the desired ID.

You can select any ID (A, B, or C).

5Press .

The setting is made.

6Press SYSTEM MENU.

The system menu turns off.

7Set the S-AIR sub unit to the same ID.

Sound transmission is established as

follows (example):

• To confirm the current ID, perform Steps 1 to 3

above. When you pair the unit with the S-AIR sub

S-AIR sub unit

(surround amplifier)

S-AIR main unit

S-AIR sub unit

(S-AIR receiver)

Room A

Room B

Establishing sound

transmission between the unit

and S-AIR sub unit

(ID setting)

For the surround amplifier

For the S-AIR receiver

ID A

S-AIR main unit

(This unit)

ID A

S-AIR sub unit

ID A

S-AIR sub unit

90GB

unit (page 91), “(PAIRING)” appears beside ID in

the front panel display.

To set the ID of the surround

amplifier

1Make sure that the SURROUND

SELECTOR switch of the surround

amplifier is set to SURROUND.

2Set the S-AIR ID switch of the surround

amplifier to match the ID (A, B, or C) of

the unit.

3Press POWER on the surround

amplifier.

When sound transmission is established,

the POWER / ON LINE indicator of the

surround amplifier turns green.

For details of the POWER / ON LINE

indicator, see “To check the transmission

status” (page 35).

To set the ID of the S-AIR

receiver

Refer to the operating instructions of the S-AIR

receiver.

To use multiple S-AIR main units

You can use multiple S-AIR main units by

setting a different ID for each component.

You can enjoy the system’s sound by using the

S-AIR receiver. The S-AIR receiver can be

placed in another room for enjoying the

system’s sound there.

For details of the S-AIR receiver, refer to the

operating instructions of the S-AIR receiver.

1Press SYSTEM MENU.

2Press X/x repeatedly until “S-AIR

MODE” appears in the front panel

display, then press or c.

3Press X/x to select the desired setting.

•“PARTY”: The S-AIR receiver outputs

sound according to functions set on the

unit.

• “SEPARATE”: You can set the desired

function for the S-AIR receiver while unit

functions do not change.

4Press .

The setting is made.

5Press SYSTEM MENU.

The system menu turns off.

6Select the desired function on the

S-AIR receiver.

xWhen “PARTY” is set

The S-AIR receiver’s function changes

sequentially as you press FUNCTION +/–

of the main unit (page 39) or S-AIR CH of

the S-AIR receiver.

xWhen “SEPARATE” is set

The S-AIR receiver’s function changes

by pressing S-AIR CH of the S-AIR

receiver as follows.

“MAIN UNIT” t “TUNER FM” t

“DMPORT” t “AUDIO” t …

To enjoy the same function as the unit,

select “MAIN UNIT.”

Other S-AIR

main unit

S-AIR main unit

(This unit)

ID A

S-AIR sub unit

ID A

S-AIR

sub unit

ID B

S-AIR sub unit

ID A ID B

Enjoying the system’s sound in

another room

For the S-AIR receiver

Control for HDMI/External Audio Device

91GB

7Adjust the volume on the S-AIR

receiver.

Note

• When the sound is other than 2 channel stereo, multi-

channel sound is downmixed to 2 channel.

To set “S-AIR MODE” via the

remote

Press S-AIR MODE.

The S-AIR mode appears in the front panel

display. Each time you press S-AIR MODE, the

S-AIR mode changes.

To control the system from the

S-AIR receiver

You can control the system from the S-AIR

receiver by using the following buttons.

For details, refer to the operating instructions of

the S-AIR receiver.

You can enjoy the S-AIR receiver while the unit

is in standby mode by setting “S-AIR STBY” to

“STBY ON.”

1Press SYSTEM MENU.

2Press X/x repeatedly until “S-AIR

STBY” appears in the front panel

display, then press or c.

3Press X/x to select the desired setting.

• “STBY ON”: You can enjoy the S-AIR

receiver while the unit is in standby mode

or turned on. The power consumption

during the standby mode increases.

• “STBY OFF”: You cannot enjoy the

S-AIR receiver while the unit is in

standby mode.

The default setting differs depending on the

area.

4Press .

The setting is made.

5Press SYSTEM MENU.

The system menu turns off.

Note

• When you turn the system off while “S-AIR STBY”

is set to “STBY ON,” “S-AIR” flashes (when sound

transmission between the unit and S-AIR receiver is

not established), or lights up (when sound

transmission between the unit and S-AIR receiver is

established) in the front panel display.

It is easy to set the same ID for the unit and an

S-AIR sub unit, such as a surround amplifier or

S-AIR receiver, to establish sound transmission.

However, neighbors may also receive your

system’s sound if IDs are the same, or you may

receive sound from neighbors. To prevent this,

you can identify the unit with a specific S-AIR

sub unit by performing the pairing operation.

Press Operation

H, X, x,

./>

Share the same operations on the

remote and unit.

S-AIR CH Change the function of the system.

Enjoying the S-AIR receiver

while the unit is in standby

mode

For the S-AIR receiver

Identifying the unit with a

specific S-AIR sub unit

(Pairing operation)

For the surround amplifier

For the S-AIR receiver

92GB

xBefore pairing

Sound transmission is established by ID

(example).

xAfter pairing

Sound transmission is established between the

paired unit and S-AIR sub unit(s) only.

To perform pairing

1Place the S-AIR sub unit that you want

to pair near the unit.

Note

• Remove headphones from the surround

amplifier (if connected).

2Match the IDs of the unit and the S-AIR

sub unit.

• To set the ID of the unit, see “To set the ID

of the unit” (page 89).

• To set the ID of the surround amplifier,

see “To set the ID of the surround

amplifier” (page 90).

• To set the ID of the S-AIR receiver, refer

to the operating instructions of the S-AIR

receiver.

3Press SYSTEM MENU.

4Press X/x repeatedly until “PAIRING”

appears in the front panel display, then

press or c.

5After “START” appears in the front

panel display, press .

The unit starts pairing and “SEARCH”

flashes in the front panel display.

To cancel pairing, press SYSTEM MENU.

6Start pairing of the S-AIR sub unit.

xFor the surround amplifier

Press POWER on the surround amplifier to

turn on the surround amplifier and press

PAIRING on the rear panel of the surround

amplifier.

The PAIRING indicator of the surround

amplifier flashes red when pairing starts.

When sound transmission is established,

the PAIRING indicator of the surround

amplifier turns red and “PAIRING” and

“COMPLETE” appear alternately in the

front panel display.

• To press PAIRING on the rear panel of the

surround amplifier, a slim instrument, such as a

paper clip, can be used.

xFor the S-AIR receiver

Refer to the operating instructions of the

S-AIR receiver.

When sound transmission is established,

“PAIRING” and “COMPLETE” appear

alternately in the front panel display.

Note

• Perform pairing within several minutes of Step

5. If you do not, “PAIRING” and

“INCOMPLETE” appear alternately in the front

panel display. To continue pairing, press and

start again from Step 5. To cancel pairing, press

SYSTEM MENU.

7Press SYSTEM MENU.

The system menu turns off.

This unit

ID A

S-AIR sub unit

ID A

S-AIR sub unit

Your room Neighbor

This unit

ID A

S-AIR sub unit

ID A ID A

S-AIR sub unit

Your room Neighbor

Pairing

No transmission

Control for HDMI/External Audio Device

93GB

To cancel pairing

Perform the ID setting of the unit according to

the procedure of “To set the ID of the unit.” If

you select a new ID, pairing is canceled.

If you use multiple wireless systems which share

the 2.4 GHz band, such as wireless LAN or

Bluetooth, the transmission of S-AIR products

or other wireless systems may be unstable. In

this case, the transmission may be improved by

changing the following “RF CHANGE” setting.

1Press SYSTEM MENU.

2Press X/x repeatedly until “RF

CHANGE” appears in the front panel

display, then press or c.

3Press X/x to select the desired setting.

•“AUTO”: Normally select this. The

system changes “RF CHANGE” to “ON”

or “OFF” automatically.

• “ON”: The system transmits sound by

searching for the better channel for

transmitting.

• “OFF”: The system transmits sound by

fixing the channel for transmitting.

4Press .

The setting is made.

5Press SYSTEM MENU.

The system menu turns off.

6When you set “RF CHANGE” to “OFF,”

select the ID so that sound

transmission is most stable (page 89).

Note

• In most cases, you will not need to change this

setting.

– If “RF CHANGE” is set to “OFF,” transmission

between the unit and S-AIR sub unit can be

performed using one of the following channels.

– S-AIR ID A: equivalent channel for IEEE

802.11b/g channel 1

– S-AIR ID B: equivalent channel for IEEE

802.11b/g channel 6

– S-AIR ID C: equivalent channel for IEEE

802.11b/g channel 11

• The transmission may be improved by changing the

transmission channel (frequency) of the other

wireless system(s). For details, refer to the operating

instructions of the other wireless system(s).

If sound transmission is

unstable

For the surround amplifier

For the S-AIR receiver

94GB

Getting Optimal

Surround Sound for a

Room

[SPEAKER FORMATION]

Depending on the shape of the room, you cannot

install some speakers. For better surround

sound, Sony recommends that first you decide

the position of the speakers.

1Press FUNCTION +/– repeatedly until

“DVD” appears in the front panel

display.

2Press DISPLAY while the system is

in stop mode.

The Control Menu display appears on the

TV screen.

3Press X/x to select [SETUP],

then press .

The options for [SETUP] appear.

4Press X/x to select [CUSTOM], then

press .

The Setup Display appears.

5Press X/x to select [AUDIO SETUP],

then press .

The options for [AUDIO SETUP] appear.

6Press X/x to select [SPEAKER

FORMATION], then press .

The options for [SPEAKER

FORMATION] appear.

7Press C/c to select a setting.

• [STANDARD]: Select this when you

install all the speakers normally.

• [NO CENTER]: Select this when you

install the front and surround speakers

only.

• [NO SURROUND]: Select this when you

install the center and front speakers only.

• [FRONT ONLY]: Select this when you

install the front speakers only.

• [ALL FRONT]: Select this when you

install all the speakers in front of the

listening position.

• [ALL FRONT - NO CENTER]: Select

this when you install the front and

surround speakers in front of the listening

position.

8Press .

The setting is made and the confirmation

display appears.

9Press C/c to select [YES] or [NO], then

press .

• [YES]: Continue with [AUTO

CALIBRATION]. Follow the procedure

from Step 7 of “Calibrating the

Appropriate Settings Automatically”

(page 95).

• [NO]: Exit [SPEAKER FORMATION].

Other Operations

SPEAKER FORMATION

STANDARD

Other Operations

95GB

Calibrating the

Appropriate Settings

Automatically

[AUTO CALIBRATION]

D. C. A. C. (Digital Cinema Auto Calibration)

can set the appropriate surround sound

automatically.

Note

• The system outputs a loud test sound when [AUTO

CALIBRATION] starts. You cannot turn the volume

down. Give consideration to children and neighbors.

1Press FUNCTION +/– repeatedly until

“DVD” appears in the front panel

display.

2Press DISPLAY while the system is

in stop mode.

The Control Menu display appears on the

TV screen.

3Press X/x to select [SETUP],

then press .

The options for [SETUP] appear.

4Press X/x to select [CUSTOM], then

press .

The Setup Display appears.

5Press X/x to select [AUDIO SETUP],

then press .

The options for [AUDIO SETUP] appear.

6Press X/x to select [AUTO

CALIBRATION], then press .

The options for [AUTO CALIBRATION]

appear.

7Connect the calibration mic (supplied)

to the A.CAL MIC jack on the front

panel.

Set up the calibration mic at ear level using

a tripod, etc. (not supplied).

The front of each speaker should face the

calibration mic, and there should be no

obstruction between the speakers and the

calibration mic.

8Press C/c to select [YES].

9Press .

[AUTO CALIBRATION] starts.

Be quiet during the measurement.

Note

• Before [AUTO CALIBRATION], make sure

that the surround amplifier turns on and you

install the surround amplifier in the appropriate

location. If you install the surround amplifier in

an improper location, such as another room,

proper measurement will not be obtained.

• The environment of the room in which the

system is installed may affect measurements.

When the measurements differ considerably

from the status of the speaker installation,

perform the speaker settings manually by

following “Settings for the speakers” (page 67).

10Press C/c to select [YES] or [NO], then

press .

xThe measurement is OK.

Disconnect the calibration mic, then select

[YES]. The result is implemented.

When you want to cancel the measurement

and retry [AUTO CALIBRATION], select

[NO].

Calibration mic

96GB

xThe measurement is not OK.

Follow the message, then select [YES] to

retry.

Note

• While the Auto Calibration function is working, do

not operate the system.

• The measurement for [SUBWOOFER] is always

[YES] since the system does not perform subwoofer

calibration, but the [SUBWOOFER] level in

[SPEAKER SETUP] returns to the default setting

when you perform [AUTO CALIBRATION].

Controlling the TV with

the Supplied Remote

You can control the TV (Sony only) by using the

following buttons. Use these buttons (other than

TV [/1, THEATRE, and TV INPUT) while

pressing the TV button.

Note

• Depending on the TV, you may not be able to control

your TV or to use some of the buttons.

* Use these buttons while pressing the TV button.

By pressing You can

TV [/1Turn the TV on/off.

THEATRE Enjoy optimal image quality

suited for movies.

TV INPUT Switch the TV’s input source

between the TV and other input

sources.

VOLUME +/–* Adjust the TV volume.

PROG +/–* Select the TV channel.

Number

buttons*, -*

ENTER*

Select the TV channel.

TOOLS* Displays the operation menu for

the current display.

RETURN* Return to the previous channel or

layer on the menu of the TV.

MENU* Display the menu of the TV.

MUTING* Turn off the TV sound

temporarily.

C/X/x/c*, * Select the item on the menu.

Other Operations

97GB

Using the Sound Effect

You can reinforce bass frequencies.

Press DYNAMIC BASS.

“D. BASS ON” appears in the front panel

display and bass frequencies are effectively

reinforced.

To turn off the sound effect

Press DYNAMIC BASS again.

You can enjoy sound effects or dialogue, as you

would in a movie theater, even at low volume. It

is useful for watching movies at night.

Press NIGHT.

“NIGHT ON” appears in the front panel display

and the sound effect is activated.

Note

• This effect does not work for a Super Audio CD.

When you load a Super Audio CD during “NIGHT

ON,” the sound effect turns off automatically.

• When sound is output from the center speaker, this

effect is more pronounced, as speech (movie dialog,

etc.) is easy to hear. When sound is not output from

the center speaker, or you are using the headphones,

the system optimally adjusts the volume.

To turn off the sound effect

Press NIGHT again.

You can enhance compressed sound such as an

MP3 audio file.

This effect is activated automatically when all

the following conditions are satisfied:

– The function is set to “DMPORT,”

“AUDIO,” or “USB”.

– “DEC. MODE” is set to “A.F.D. STD” or

“A.F.D. MULTI.”

– Headphones are not connected.

To turn off the sound effect

Select other than “A.F.D. STD” or “A.F.D.

MULTI” for “DEC. MODE” (page 41).

Reinforcing bass frequencies

Enjoying the sound at low

volume

Enhancing compressed sound

98GB

Selecting the Effect to

Suit the Source

You can select a suitable sound mode for movies

or music.

Press SOUND MODE repeatedly during

playback until the desired mode appears in

the front panel display.

• “AUTO”: The system automatically selects

“MOVIE” (the MOVIE indicator lights up) or

“MUSIC” (the MUSIC indicator lights up) to

produce the sound effect depending on the

source.

• “MOVIE”: The system provides the sound for

movies. The MOVIE indicator lights up.

• “MUSIC”: The system provides the sound for

music. The MUSIC indicator lights up.

Note

• When you play a Super Audio CD, this function does

not work.

• You cannot operate these setup items when you

connect headphones to the unit or surround amplifier.

• When changing the sound mode while using the

S-AIR receiver, sound from the S-AIR receiver may

skip.

Enjoying Multiplex

Broadcast Sound

(DUAL MONO)

You can enjoy multiplex broadcast sound when

the system receives or plays a Dolby Digital

multiplex broadcast signal.

Note

• To receive a Dolby Digital signal, you need to

connect a TV or other component to the unit with an

optical or coaxial digital cord (page 26) and set the

digital output mode of the TV or other component to

Dolby Digital.

Press AUDIO repeatedly until the desired

signal appears in the front panel display.

•“MAIN”: Sound of the main language will be

output.

• “SUB”: Sound of the sub language will be

output.

• “MAIN+SUB”: Mixed sound of both the main

and sub languages will be output.

Other Operations

99GB

Changing the Input Level

of the Sound from

Connected Components

Distortion may occur when you listen to a

component connected to the EURO AV T

OUTPUT (TO TV) or LINE* jacks on the rear

panel, or to the AUDIO IN jack on the front

panel. Distortion is not a malfunction and will

depend on the component connected.

To prevent distortion, reduce the input level on

the unit.

1Press FUNCTION +/– repeatedly until

“TV,” “LINE*,” or “AUDIO” appears in

the front panel display.

2Press SYSTEM MENU.

3Press X/x repeatedly until

“ATTENUATE” appears in the front

panel display, then press or c.

4Press X/x to select a setting.

• “ATT ON”: You can attenuate the input

level. The output level is changed.

• “ATT OFF”: Normal input level.

5Press .

The setting is made.

6Press SYSTEM MENU.

The system menu turns off.

* DAV-DZ880W only.

Using the Sleep Timer

You can set the system to turn off at a preset

time, so you can fall asleep listening to music.

You can preset the time in 1 or 10-minute

increments.

Press SLEEP.

Each time you press SLEEP, the minutes display

(the remaining time) changes by 10 minutes.

When you set the sleep timer, “SLEEP” flashes

in the front panel display.

To check the remaining time

Press SLEEP once.

To change the remaining time

Press SLEEP repeatedly to select the desired

time.

To cancel the sleep timer

function

Press SLEEP repeatedly until “SLEEP OFF”

appears in the front panel display.

To set the sleep timer using the

system menu

1Press SYSTEM MENU.

2Press X/x repeatedly until “SLEEP”

appears in the front panel display, then

press or c.

3Press X/x to select a setting.

The minutes display (the remaining time)

changes by 10 minutes.

• You can select the remaining time by pressing

the number buttons. In this case, you can preset

the time in 1-minute increments.

4Press .

The setting is made and “SLEEP” flashes in

the front panel display.

5Press SYSTEM MENU.

The system menu turns off.

100GB

Changing the Brightness

of the Front Panel

Display

You can set the brightness of the front panel

display to either of 2 levels.

Press DIMMER.

Each time you press DIMMER, the brightness of

the front panel display changes.

To set the brightness of the front

panel display using the system

1Press SYSTEM MENU.

2Press X/x repeatedly until “DIMMER”

appears in the front panel display, then

press or c.

3Press X/x to select the brightness of

the front panel display.

• “DIMMER OFF”: The front panel display

is bright.

• “DIMMER ON”: The front panel display

is dark.

4Press .

The setting is made.

5Press SYSTEM MENU.

The system menu turns off.

Viewing Information

About the Disc

Press DISPLAY repeatedly.

Each time you press DISPLAY while playing

the disc, the display changes:

1 t 2 t ... t 1 t ...

Some displayed items may disappear after a few

seconds.

xDVD VIDEO/DVD-VR

1 Playing time of the current title

2 Remaining time of the current title

3 Playing time of the current chapter

4 Remaining time of the current chapter

5 Disc name

6 Title and chapter

xVIDEO CD (without PBC functions)/

Super Audio CD/CD

1 Playing time of the current track

2 Remaining time of the current track

3 Playing time of the disc

4 Remaining time of the disc

5 Track name

6 Track and index*

* VIDEO CD/Super Audio CD only.

xSuper VCD

1 Playing time of the current track

2 Track text

3 Track and index number

xDATA CD (MP3 file)/DATA DVD (MP3 file)

1 Playing time and current track number

2 Track (file) name*

* If an MP3 file has an ID3 tag, the system will

display an album name or title name from the ID3

tag information.

The system can support ID3 ver 1.0/1.1/2.2/2.3.

ID3 ver 2.2/2.3 tag information display has priority

when both ID3 ver 1.0/1.1 and ver 2.2/2.3 tags are

used for a single MP3 file.

Viewing the playing time and

remaining time in the front

panel display

Other Operations

101GB

xDATA CD (video file)/DATA DVD (video

file)

1 Playing time of the current file

2 Current file name

3 Current album and file number

Note

• The system can only display the first level of the

DVD/CD text, such as the disc name or title.

• If a file name of the MP3 file cannot be displayed, “*”

will appear in the front panel display instead.

• The disc name or track name may not be displayed

depending on the text.

• Playing time of MP3 files and video files may not be

displayed correctly.

• When the system is playing a VIDEO CD with PBC

functions, the playing time is displayed.

1Press DISPLAY during playback.

The following display appears on the TV

screen.

2Press DISPLAY repeatedly to change

the time information.

The display and the kinds of time that you

can check depend on the disc you are

playing.

xDVD VIDEO/DVD-VR

• T **:**:**

Playing time of the current title

• T-**:**:**

Remaining time of the current title

• C **:**:**

Playing time of the current chapter

• C-**:**:**

Remaining time of the current chapter

xVIDEO CD (with PBC functions)

•**:**

Playing time of the current scene

xVIDEO CD (without PBC functions)/

Super Audio CD/CD

• T **:**

Playing time of the current track

• T-**:**

Remaining time of the current track

• D **:**

Playing time of the current disc

• D-**:**

Remaining time of the current disc

xDATA CD (MP3 file)/DATA DVD (MP3

file)

• T **:**

Playing time of the current track

xDATA CD (video file)/DATA DVD

(video file)

• **:**:**

Playing time of the current file

Note

• Characters/marks may not be displayed in some

languages.

• Depending on the type of disc being played, the

system can only display a limited number of

characters. Also, depending on the disc, not all text

characters will be displayed.

To check DVD/Super Audio CD/CD

text

Press DISPLAY repeatedly during playback to

display text recorded in the DVD/Super Audio

CD/CD.

The DVD/Super Audio CD/CD text appears

only when text is recorded in the disc. You

cannot change the text. If the disc does not

contain text, “NO TEXT” appears.

Viewing the playing time and

remaining time on the TV

screen

T 1: 01: 40

Time information

Checking the play information

of the disc

Dvorak/Tchaikovsky /NedPho/Kreizberg

Adagio - Allegro molto

102GB

To check DATA CD/DATA DVD

(MP3 file/video file) text

By pressing DISPLAY while playing MP3 files

or video files on a DATA CD/DATA DVD, you

can display the name of the folder/MP3 file/

video file, and the audio bit rate (the amount of

data per second of the current audio) on the TV

screen.

Example for playback of an audio file

* Appears when playing an MP3 file on a DATA CD/

DATA DVD.

** If an MP3 file has the ID3 tag, the system will

display an album name or title name from the ID3

tag information.

The system can support ID3 ver 1.0/1.1/2.2/2.3.

ID3 ver 2.2/2.3 tag information display has priority

when both ID3 ver 1.0/1.1 and ver 2.2/2.3 tags are

used for a single MP3 file.

You can check the date information during

playback when the Exif* tag is recorded in the

JPEG image file.

Press DISPLAY during playback.

The Control Menu display appears on the TV

screen.

* “Exchangeable Image File Format” is a digital

camera image format defined by the Japan

Electronics and Information Technology Industries

Association (JEITA).

Checking the date information

of a JPEG image file

T 0: 13 192k MP3

2002_Remixes

Soul_Survivor_rap_version

Bit rate*

Folder name** MP3 file**/video file name

DATA CD

10( 15)

5( 8)

18/9/2002

Date information

Other Operations

103GB

Returning to the Default

Settings

1Press "/1 to turn on the system.

2Press x, N, and "/1 on the unit at the

same time.

“COLD RESET” appears in the front panel

display and the system returns to default

settings.

You can return the [SETUP] settings (page 62)

other than [PARENTAL CONTROL] to the

default settings.

1Press FUNCTION +/– repeatedly until

“DVD” appears in the front panel

display.

2Press DISPLAY while the system is

in stop mode.

The Control Menu display appears on the

TV screen.

3Press X/x to select [SETUP],

then press .

The options for [SETUP] appear.

4Press X/x to select [CUSTOM], then

press .

The Setup Display appears.

5Press X/x to select [SYSTEM SETUP],

then press .

The options for [SYSTEM SETUP] appear.

6Press X/x to select [RESET] and press

7Press C/c to select [YES].

You can also quit the process and return to

the Control Menu display by selecting [NO]

here.

8Press .

Do not press [/1 while resetting the system

as it takes a few seconds to complete.

Note

• The [MEDIA], [INTERVAL], [EFFECT], and

[MULTI/2CH] settings also return to the default

settings.

Returning the system

parameters, such as preset

stations, to the default

settings

Returning the [SETUP] settings

to the default

"/1x

104GB

Precautions

On power sources

• Unplug the unit from the wall outlet (mains) if you do

not intend to use it for an extended period of time. To

disconnect the cord, pull it out by the plug, never by

the cord.

On placement

• Place the system in a location with adequate

ventilation to prevent heat build-up in the system.

• At high volume, over long periods of time, the cabinet

becomes hot to the touch. This is not a malfunction.

However, touching the cabinet should be avoided. Do

not place the system in a confined space where

ventilation is poor as this may cause overheating.

• Do not block the ventilation slots by putting anything

on the system. The system is equipped with a high

power amplifier. If the ventilation slots are blocked,

the system can overheat and malfunction.

• Do not place the system on surfaces (rugs, blankets,

etc.) or near materials (curtains, draperies) that may

block the ventilation slots.

• Do not install the system near heat sources such as

radiators, or air ducts, or in a place subject to direct

sunlight, excessive dust, mechanical vibration, or

shock.

• Do not install the system in an inclined position. It is

designed to be operated in a horizontal position only.

• Keep the system and discs away from components

with strong magnets, such as microwave ovens, or

large loudspeakers.

• Do not place heavy objects on the system.

On operation

• If the system is brought directly from a cold to a warm

location, or is placed in a very damp room, moisture

may condense on the lenses inside the unit. Should

this occur, the system may not operate properly. In

this case, remove the disc and leave the system turned

on for about half an hour until the moisture

evaporates.

• When you move the system, take out any disc. If you

don’t, the disc may be damaged.

• If anything falls into the cabinet, unplug the unit and

have it checked by qualified personnel before

operating it any further.

On adjusting volume

• Do not turn up the volume while listening to a section

with very low level inputs or no audio signals. If you

do, the speakers may be damaged when a peak level

section is suddenly played.

On cleaning

• Clean the cabinet, panel, and controls with a soft cloth

slightly moistened with a mild detergent solution. Do

not use any type of abrasive pad, scouring powder or

solvent such as alcohol or benzine.

If you have any questions or problems concerning

your system, please consult your nearest Sony dealer.

On cleaning discs, disc/lens

cleaners

• Do not use cleaning discs or disc/lens cleaners

(including wet or spray types). These may cause

the apparatus to malfunction.

On your TV’s color

• If the speakers should cause the TV screen to have

color irregularity, turn off the TV then turn it on after

15 to 30 minutes. If color irregularity should persist,

place the speakers further away from the TV set.

On moving the system

Before moving the system, make sure that there is no

disc inserted, and remove the AC power cord (mains

lead) from the wall outlet (mains).

About S-AIR function

• As the S-AIR product(s) transmits sound by radio

waves, sound may skip when radio waves are

obstructed. This is a characteristic of radio waves and

is not malfunction.

• As the S-AIR product(s) transmits sound by radio

waves, equipment that generates electromagnetic

energy, such as a microwave oven, may prevent

sound transmission.

• As the S-AIR product(s) uses the radio waves that

share the same frequency as other wireless systems,

such as wireless LAN or Bluetooth devices it may

occur interference or poor transmission as a result. In

Additional Information

IMPORTANT NOTICE

Caution: This system is capable of holding a still

video image or on-screen display image on your

television screen indefinitely. If you leave the still

video image or on-screen display image displayed

on your TV for an extended period of time you risk

permanent damage to your television screen.

Projection televisions are especially susceptible to

this.

Additional Information

105GB

this case, take the following steps to enhance the

transmission of signals:

– Avoid placing the S-AIR product(s) near other

wireless systems.

– Avoid using the S-AIR product(s) and the other

wireless systems spontaneously.

– The transmission may be improved by changing

the transmission channel (frequency) of the other

wireless system(s). For details, refer to the

operating instructions of the other wireless

system(s).

• The transmission distance differs depending on the

usage of environment. Find a location where

transmission between the S-AIR main unit and sub

unit is most effective, and install the S-AIR main unit

and sub unit there.

• Place the S-AIR product(s) on the stable surface off

the floor.

• Poor transmission may occur and the transmission

distance may be too short if the following conditions

exist:

– There is a wall/floor made of reinforced concrete

or stone between the S-AIR product(s).

– There is an iron divider/door or furniture/electric

product made of fireproof glass, metal, etc.,

between the S-AIR product(s).

Notes about the Discs

On handling discs

• To keep the disc clean, handle the disc by its

edge. Do not touch the surface.

• Do not stick paper or tape on the disc.

• Do not expose the disc to direct sunlight or

heat sources such as hot air ducts, or leave it in

a car parked in direct sunlight as the

temperature may rise considerably inside the

car.

• After playing, store the disc in its case.

On cleaning

• Before playing, clean the disc with a cleaning

cloth.

Wipe the disc from the center out.

• Do not use solvents such as benzine, thinner,

commercially available cleaners, or anti-static

spray intended for vinyl LPs.

This system can only play back a standard

circular disc. Using neither standard nor circular

discs (e.g., card, heart, or star shape) may cause

a malfunction.

Do not use a disc that has a commercially

available accessory attached, such as a label or

ring.

106GB

Troubleshooting

If you experience any of the following difficulties while using the system, use this troubleshooting

guide to help remedy the problem before requesting repairs. Should any problem persist, consult your

nearest Sony dealer.

Note that if service personnel changes some parts during repair, these parts may be retained.

In the event of a problem with the S-AIR function, have a Sony dealer check the entire system together

(main unit and S-AIR sub unit).

Power


Symptom Remedy

The power is not turned on. • Check that the AC power cord (mains lead) is connected securely.

•Press "/1 after “STANDBY” disappears from the front panel display.

If “PROTECTOR” and “PUSH

POWER” appear alternately in

the front panel display.

Press "/1 to turn off the system, and check the following items after

“STANDBY” disappears.

• Are the + and – speaker cords short-circuited?

• Are you using only the specified speakers?

• Is anything blocking the ventilation holes of the system?

• After checking the above items and fixing any problems, turn on the system. If

the cause of the problem cannot be found even after checking all the above

items, consult your nearest Sony dealer.

Symptom Remedy

There is no picture. • The SCART (EURO AV) cable is not connected securely.

• The SCART (EURO AV) cable is damaged.

• The unit is not connected to the correct EURO AV T OUTPUT (TO TV) jack

(page 26).

• The video input on the TV is not set so that you can view pictures from the

system.

• Check the output method on your system (page 26).

• Re-connect the connecting cord securely.

• The unit is connected to an input device that is not HDCP (High-bandwidth

Digital Content Protection) compliant (“HDMI” on the front panel does not

light up) (page 26).

• If the HDMI OUT jack is used for video output, change the type of video signal

output from the HDMI OUT jack. It may solve the problem (page 38).

Connect the TV and the unit using a video jack other than the HDMI OUT, and

switch the TV’s input to the connected video input so that you can see the on-

screen displays. Change the type of video signal output from the HDMI OUT

jack, and switch the TV’s input back to HDMI. If the picture still does not

appear, repeat the Steps and try other options.

• If you are using the “DMPORT” function, the video signal is output from the

EURO AV T OUTPUT (TO TV) jack only.

Picture noise appears. • The disc is dirty or flawed.

• If the signal from the EURO AV T OUTPUT (TO TV) jack is distorted,

change the type of video signal output from the HDMI OUT jack by setting

[HDMI RESOLUTION] in [HDMI SETUP] to [720 × 480p]* (page 38).

* Depending on the area, [720 × 480/576p] may appear.

Additional Information

107GB

Sound

Even though you set the aspect

ratio in [TV TYPE] of [VIDEO

SETUP], the picture does not fill

the TV screen.

• The aspect ratio on the disc is fixed.

Color irregularity occurs on the

TV screen.

The system’s speakers contain magnet parts, so magnetic distortion may occur.

When color irregularity occurs on the TV screen, check the following items.

• If the speakers are used with a CRT-based TV or projector, install the speakers

at least 0.3 meters (1.0 ft) from the TV set.

• If the color irregularity persists, turn off the TV set once, then turn it on after 15

to 30 minutes.

• If howling occurs, reposition the speakers farther away from the TV set.

• Make sure that no magnetic object (magnetic latch on a TV stand, health care

device, toy, etc.) is placed near the speakers.

Symptom Remedy

There is no sound. • The speaker cord is not connected securely.

• Press MUTING on the remote if “MUTING ON” is displayed in the front panel

display.

• The system is in pause mode or in Slow-motion Play mode. Press H to return

to normal play mode.

• Fast forward or fast reverse is being performed. Press H to return to normal

play mode.

• Check the speaker settings (page 67).

• The component connected to the HDMI OUT jack does not conform to the

audio signal format, in this case set [AUDIO (HDMI)] in [HDMI SETUP] to

[ON] (page 65).

No sound is output from the

HDMI OUT jack.

• Set [AUDIO (HDMI)] in [HDMI SETUP] to [ON] (page 65).

• The HDMI OUT jack is connected to a DVI (Digital Visual Interface) device

(DVI (Digital Visual Interface) jacks do not accept audio signals).

• The HDMI OUT jack does not output Super Audio CD sound.

• Try the following: 1 Turn the system off and on again. 2 Turn the connected

component off and on again. 3 Disconnect and then connect the HDMI cable

again.

The left and right sounds are

unbalanced or reversed.

• Check that the speakers and components are connected correctly and securely.

There is no sound from the

subwoofer.

• Check the speaker connections and settings (pages 23, 67).

Severe hum or noise is heard. • Check that the speakers and components are connected securely.

• Check that the connecting cords are away from a transformer or motor, and at

least 3 meters (10 ft) away from your TV set or a fluorescent light.

• Move your TV away from the audio components.

• The plugs and jacks are dirty. Wipe them with a cloth slightly moistened with

alcohol.

• Clean the disc.

The sound loses stereo effect

when you play a VIDEO CD, a

CD, or an MP3 file.

• Select stereo sound by pressing AUDIO (page 46).

• Make sure the unit is connected properly.

108GB

Operation

The surround effect is difficult to

hear when you are playing a

sound track of Dolby Digital,

DTS, or MPEG audio.

• Check the “DEC. MODE” setting (page 41).

• Check the speaker connections and settings (pages 23, 67).

• Depending on the DVD, the output signal may not be the entire 5.1 channel. It

may be monaural or stereo even if the sound track is recorded in Dolby Digital

or MPEG audio format.

The sound comes from the center

speaker only.

• Depending on the disc, the sound may come from the center speaker only.

No sound is heard from the

center speaker.

• Check the speaker connections and settings (pages 23, 67).

• Check the “DEC. MODE” setting (page 41).

• Depending on the source, the effect of the center speaker may be less

noticeable.

• A 2 channel source is being played.

No sound or only a very low-

level sound is heard from the

surround speakers.

• Check the speaker connections and settings (pages 23, 67).

• Check the “DEC. MODE” setting (page 41).

• Depending on the source, the effect of the surround speakers may be less

noticeable.

• Check the wireless setting (page 35).

• A 2 channel source is being played.

There is no sound from the

DIGITAL IN COAXIAL/

OPTICAL jack.

• The sampling frequency of the input stream is more than 48 kHz.

Symptom Remedy

Radio stations cannot be tuned

in.

• Check that the antenna (aerial) is connected securely. Adjust the antenna

(aerial) or connect an external antenna (aerial) if necessary.

• The signal strength of the stations is too weak (when tuning in with automatic

tuning). Use direct tuning.

• No stations have been preset or the preset stations have been cleared (when

tuning by scanning preset stations). Preset the stations (page 70).

The remote does not function. • There are obstacles between the remote and the unit.

• The distance between the remote and the unit is too far.

• The remote is not pointed at the remote sensor on the unit.

• The batteries in the remote are weak.

The disc does not play. • There is no disc inserted.

• The disc is upside down.

Insert the disc with the playback side facing down.

• The disc is skewed on the disc tray.

• The system cannot play CD-ROMs, etc. (page 6).

• The region code on the DVD does not match the system.

• Moisture has condensed inside the unit and may cause damage to the lenses.

Remove the disc and leave the unit turned on for about half an hour.

The MP3 file cannot be played. • The DATA CD is not recorded in ISO 9660 Level 1/Level 2, or Joliet.

• The DATA DVD is not recorded in UDF (Universal Disk Format).

• The MP3 file does not have the extension “.mp3.”

• The data is not formatted in MP3 even though it has the extension “.mp3.”

• The data is not MPEG1 Audio Layer 3 data.

• The system cannot play audio tracks in MP3PRO format.

• Check the [MEDIA] setting (page 57).

Symptom Remedy

Additional Information

109GB

The JPEG image file cannot be

played.

• The DATA CD is not recorded in ISO 9660 Level 1/Level 2, or Joliet.

• The DATA DVD is not recorded in UDF (Universal Disk Format).

• It has an extension other than “.jpeg” or “.jpg.”

• It is larger than 3,072 (width) × 2,048 (height) in normal mode, or more than

2,000,000 pixels in progressive JPEG image file which is mainly used on

Internet Web sites.

• It does not fit the TV screen (those images are reduced).

• Check the [MEDIA] setting (page 57).

The video file cannot be played. • The file is not created in DivX format or MP4 file format.

• The file has an extension other than “.avi,” “.divx,” “.mp4,” or “.m4v.”

• The DATA CD is not recorded in ISO 9660 Level 1/Level 2, or Joliet.

• The DATA DVD is not recorded in UDF (Universal Disk Format).

• The video file is larger than 720 (width) × 576 (height).

• Check the [MEDIA] setting (page 57).

The titles of folder/file/file name

are not displayed correctly.

• The system can only display numbers and letters of the alphabet. Other

characters are displayed as [*].

A disc does not start playing

from the beginning.

• Program Play, Shuffle Play, or Repeat Play has been selected.

Press CLEAR to cancel these functions before playing a disc.

• Resume Play has been selected.

During stop, press x on the unit or the remote and then start playback

(page 48).

• The title, DVD or PBC menu automatically appears on the TV screen.

The system starts playing the

disc automatically.

• The DVD features an auto playback function.

Playback stops automatically. • Some discs may contain an auto pause signal. While playing such a disc, the

system stops playback at the auto pause signal.

You cannot perform some

functions such as stop, search,

Slow-motion Play, or Repeat

Play.

• Depending on the disc, you may not be able to perform some of these

operations. Refer to the operating instructions supplied with the disc.

Messages do not appear on the

TV screen in the language you

want.

• In the Setup Display, select the desired language for the on-screen display in

[OSD] under [LANGUAGE SETUP] (page 63).

The language for the sound track

cannot be changed.

• Multilingual tracks are not recorded on the DVD being played.

• The DVD prohibits changing the language for the sound track.

The subtitle language cannot be

changed.

• Multilingual subtitles are not recorded on the DVD being played.

• The DVD prohibits changing the subtitles.

The subtitle cannot be turned off. • The DVD prohibits turning off subtitles.

The angles cannot be changed. • Multi-angles are not recorded on the DVD being played (page 45).

• The DVD prohibits changing the angles.

A disc cannot be ejected and

“LOCKED” appears in the front

panel display.

• Contact your Sony dealer or local authorized Sony service facility.

Symptom Remedy

110GB

USB device

[Data error] appears on the TV

screen when playing a DATA

CD or DATA DVD.

• The MP3 file/JPEG image file/video file you want to play is broken.

• The data is not MPEG1 Audio Layer 3 data.

• The JPEG image file format does not conform to DCF.

• The file has the extension “.jpg” or “.jpeg,” but is not in JPEG format.

• The file you want to play has the extension “.avi” or “.divx” but is not in DivX

format, or is in DivX format but does not conform to DivX Certified profiles.

• The file you want to play has the extension “.mp4” or “.m4v” but is not in MP4

format, or is in MP4 format but does not conform to MPEG4 Simple Profiles.

The system does not work

normally.

• Disconnect the AC power cord (mains lead) from the wall outlet (mains), then

reconnect after several minutes.

The Control for HDMI function

does not work.

• When “HDMI” does not light up in the front panel display, check the HDMI

connection (page 26).

• Set [CONTROL FOR HDMI] in [HDMI SETUP] to [ON] (page 64).

• Make sure that the connected component is compatible with the [CONTROL

FOR HDMI] function.

• Check that the AC power cord (mains lead) of the connected component is

connected securely.

• Check the connected component’s setting for the Control for HDMI function.

Refer to the operating instructions supplied with the component.

• If you change the HDMI connection, connect and disconnect the AC power

cord (mains lead), or have a power failure, set [CONTROL FOR HDMI] in

[HDMI SETUP] to [OFF], then set [CONTROL FOR HDMI] in [HDMI

SETUP] to [ON] (page 64).

• For details, see “Using the Control for HDMI Function for “BRAVIA” Sync”

(page 73).

No sound is output from the

system and TV while using the

System Audio Control function.

• Set [AUDIO (HDMI)] in [HDMI SETUP] to [ON] (page 65).

• Make sure that the connected TV is compatible with the System Audio Control

function.

• For details, see “Using the Control for HDMI Function for “BRAVIA” Sync”

(page 73).

The TV input select does not

change automatically when you

connect the system and TV with

a SCART (EURO AV) cable.

• Set [CONTROL FOR HDMI] in [HDMI SETUP] to [OFF] (page 64).

Symptom Remedy

“OVERLOAD,” “REMOVE

USB,” then “PUSH POWER”

appear in the front panel display.

• A problem has been detected with the level of electrical current from the

(USB) port. Turn off the system and remove the USB device from the

(USB) port. Make sure there is no problem with the USB device. If this display

pattern persists, contact your nearest Sony dealer.

Are you using a supported USB

device?

• If you connect an unsupported USB device, the following problems may occur.

See “Playable USB Devices” (supplement) for the supported device types.

– The USB device is not recognized.

– File or folder names are not displayed on this system.

– Playback is not possible.

– The sound skips.

– There is noise.

– A distorted sound is output.

– Transferring stops before it is finished.

Symptom Remedy

Additional Information

111GB

There is no sound. • The USB device is not connected correctly. Turn off the system, then reconnect

the USB device.

The sound is distorted. • The bit rate used when encoding the audio files was low. Transfer audio files

encoded with higher bit rates onto the USB device.

There is noise or the sound skips. • Turn off the system, then reconnect the USB device.

• Noise may have entered during the transferring process. Delete the file, and try

transferring again.

• Copy the files to your computer, format the USB device in FAT12, FAT16, or

FAT32 format, and transfer the files to the USB device again.*

* This system supports FAT12, FAT16, and FAT32, but some USB devices

may not support all of these. For details, refer to the operating instructions of

each USB device or contact the manufacturer.

The USB device cannot be

connected into the (USB)

port.

• The USB device is being connected backwards. Connect the USB device in the

correct orientation.

The USB device which has been

used on another device does not

work.

• It may be recorded in an unsupported format. If so, first take the precaution of

backing up important files on the USB device by copying them to your

computer hard disk. Next, format the USB device in FAT12, FAT16, or FAT32

format, and transfer the files to the USB device again.*

* This system supports FAT12, FAT16, and FAT32, but some USB devices

may not support all of these. For details, refer to the operating instructions of

each USB device or contact the manufacturer.

“READING” is displayed for a

long time.

• The reading process can take a long time in the following cases.

– There are many folders or files on the USB device.

– The file structure is extremely complex.

– The memory capacity is excessive.

– The internal memory is fragmented.

• Sony recommends following these guidelines.

– Total folders on the USB device: 200 or less

– Total files per folder: 150 or less

File names are not displayed

properly.

• Transfer the music data onto the USB device again, as the data stored in the

USB device may have been corrupted.

• The character codes that can be displayed by this system are numbers and letters

of the alphabet only. Other characters are not displayed correctly.

“DATA ERROR” appears in the

front panel display during

playback of a USB device.

• The audio file/JPEG image file/video file you want to play is broken.

• The data is not MPEG1 Audio Layer 3 data.

• The JPEG image file format does not conform to DCF.

• The file has the extension “.jpg” or “.jpeg,” but is not in JPEG format.

• The file you want to play has the extension “.avi” or “.divx” but is not in DivX

format, or is in DivX format but does not conform to DivX Certified profiles.

• The file you want to play has the extension “.mp4” or “.m4v” but is not in MP4

format, or is in MP4 format but does not conform to MPEG4 Simple Profiles.

Playback does not start. • Turn off the system, then reconnect the USB device.

• Connect the USB device that this system can play. See “Playable USB Devices”

(supplement).

•Press H to start play.

Playback does not start from the

first track.

• Program Play, Shuffle Play, or Repeat Play has been selected.

Press CLEAR to cancel these functions before playing a USB device.

• Resume Play has been selected.

During stop, press x on the unit or the remote and then start playback.

Symptom Remedy

112GB

It takes time until playback

starts.

• The system is playing an audio file in AAC format.

The USB device (audio file/

JPEG image file/video file)

cannot be played back.

• USB devices formatted with file systems other than FAT12, FAT16, or FAT32

are unsupported.*

• Files that are encrypted or protected by passwords, etc. cannot be played back.

• The MP3 file does not have the extension “.mp3.”

• The WMA file does not have the extension “.wma.”

• The AAC file does not have the extension “.m4a.”

• The DivX video file does not have the extension “.avi” or “.divx.”

• The MPEG4 video file does not have the extension “.mp4” or “.m4v.”

• The data is not stored in the desired format.

• The MP3 files in formats other than MPEG 1 Audio Layer 3 cannot be played

back.

• If you use a partitioned USB device, only audio files on the first partition can

be played.

• The system can playback to a depth of 8 folders only.

• Check the [MEDIA] setting (page 81).

• The number of folders has exceeded 200.

• For audio files/JPEG image files, the folder contains more than 150 files.

• The JPEG image file does not have the extension “.jpg” or “.jpeg.”

• The JPEG image file is larger than 3,072 (width) × 2,048 (height) in normal

mode, or more than 2,000,000 pixels in progressive JPEG mode which is

mainly used on Internet Web sites.

• JPEG image files with a high width to length ratio cannot be played back.

• The system cannot play audio tracks in MP3PRO format.

• A WMA file that is in WMA DRM, WMA Lossless, or WMA PRO format

cannot be played back.

• An AAC file that is in AAC DRM or AAC Lossless format cannot be played

back.

* This system supports FAT12, FAT16, and FAT32, but some USB devices

may not support all of these. For details, refer to the operating instructions of

each USB device or contact the manufacturer.

Audio files or JPEG image files

take longer to play back than

others.

• After the system reads all files on the USB device, playback may take more

time than usual if:

– the number of folders or files is very large.

– the folder or file organization structure is very complex.

– the memory capacity is very large.

– the file size is extremely large.

– the physical structure within the memory is fragmented.

• Sony recommends following these guidelines.

– Total folders on the USB device: 200 or less

– Total files per folder: 150 or less

You cannot start transferring

onto a USB device.

• The following problems may have occurred.

– The USB device is full.

– The number of audio files and folders on the USB device has reached the

upper limit.

– The USB device is write-protected.

Symptom Remedy

Additional Information

113GB

The S-AIR function

Transferring stops before it is

finished.

• The communication speed of the USB device is extremely slow. Connect a

USB device that this system can play.

• If the transferring and erasing operations are repeated multiple times, the file

structure within the USB device becomes complex. Follow the procedure in the

operating instructions of the USB device to format the USB device. If the

problem persists, contact your nearest Sony dealer.

Transferring to a USB device

results in an error.

• You are using an unsupported USB device. See “Playable USB Devices”

(supplement).

• The USB device was disconnected or the power was turned off during

transferring. The USB device may be broken. Follow the procedure in the

operating instructions of the USB device to format the USB device. If the

problem persists, contact your nearest Sony dealer.

Audio files or folders on the

USB device cannot be erased.

• Check if the USB device is write-protected.

• The USB device was disconnected or the power was turned off during erasing.

Delete the partially-erased file. If this does not fix the problem, the USB device

may be broken. Follow the procedure in the operating instructions of the USB

device to format the USB device. If the problem persists, contact your nearest

Sony dealer.

Symptom Remedy

S-AIR connection is not

established (sound transmission

is not established), e.g., the

indicator of the S-AIR sub unit

does the following:

• Turns off.

•Flashes.

• Turns red.

• If you use another S-AIR main unit, place it more than 8 m (about 25 feet) away

from the S-AIR main unit you are using.

• Confirm the S-AIR IDs of the unit and S-AIR sub unit (page 89).

• Another S-AIR sub unit is paired to the S-AIR main unit. Pair the desired S-AIR

sub unit with the S-AIR main unit (page 91).

• Place so that the S-AIR main unit and S-AIR sub unit are separated from other

wireless devices.

• Avoid using any other wireless devices.

• The S-AIR sub unit is turned off. Make sure the AC power cord (mains lead) is

connected and turn on the S-AIR sub unit.

No sound is heard from the

S-AIR sub unit.

• If you use another S-AIR main unit, place it more than 8 m (about 25 feet) away

from the S-AIR main unit you are using.

• Confirm the S-AIR IDs of the unit and S-AIR sub unit (page 89).

• Confirm the pairing setting (page 91).

• Place so that the S-AIR main unit and S-AIR sub unit closer together.

• Avoid use of equipment that generates electromagnetic energy, such as a

microwave oven.

• Place so that the S-AIR main unit and S-AIR sub unit are separated from other

wireless devices.

• Avoid using any other wireless devices.

• Change the “RF CHANGE” setting (page 93).

• Change the S-AIR ID settings of the S-AIR main unit and S-AIR sub unit.

• Turn off the system and S-AIR sub unit, then turn on them.

Symptom Remedy

114GB

Surround amplifier operation

If no sound is output from the surround speakers, check the status of the POWER / ON LINE indicator

on the surround amplifier. For details of the POWER / ON LINE indicator, see “Step 3: Setting up the

Wireless System” (page 35).

There is noise or the sound skips. • If you use another S-AIR main unit, place it more than 8 m (about 25 feet) away

from the S-AIR main unit you are using.

• Place so that the S-AIR main unit and S-AIR sub unit closer together.

• Avoid use of equipment that generates electromagnetic energy, such as a

microwave oven.

• Place so that the S-AIR main unit and S-AIR sub unit are separated from other

wireless devices.

• Avoid using any other wireless devices.

• Change the “RF CHANGE” setting (page 93).

• Change the S-AIR ID settings of the S-AIR main unit and S-AIR sub unit.

Symptom Remedy

The power is not turned on. • Check that the AC power cord (mains lead) is connected securely.

The POWER / ON LINE

indicator does not turn on.

Turn off the surround amplifier and remove the AC power cord (mains lead) of

the surround amplifier, then check the following items.

• Are the + and – speaker cords short-circuited?

• Is anything blocking the ventilation holes of the surround amplifier?

• After checking the above items and fixing any problems, connect the AC power

cord (mains lead) of the surround amplifier and turn on the surround amplifier.

If the cause of the problem cannot be found even after checking all the above

items, consult your nearest Sony dealer.

Symptom Remedy

Additional Information

115GB

There is no sound. Check the status of the POWER / ON LINE indicator on the surround amplifier.

• turns green

– The speaker cord is not connected securely.

– Check the speaker connections and settings.

– The volume of the S-AIR main unit is set to minimum.

– The S-AIR main unit is in mute status.

– Depending on the source or the settings of the S-AIR main unit, the effect of

the speakers may be less noticeable.

– Headphones are connected.

• flashes green

– The S-AIR main unit is not turned on.

– Pair the S-AIR main unit with another S-AIR sub unit.

– The surround amplifier is paired to another S-AIR main unit.

– Confirm the S-AIR IDs of the S-AIR main unit and surround amplifier being

the same ID (page 89).

– Pairing operation is not completed.

– Sound transmission is poor.

Move the surround amplifier so that the POWER / ON LINE indicator turns

green.

– Move the system away from another wireless devices.

– Avoid using any other wireless devices.

– The wireless transceiver(s) is/are not inserted correctly.

• turns red

– Set the SURROUND SELECTOR switch of the surround amplifier to

SURROUND.

“HP NO LINK” and “VOLUME

MIN” appear alternately in the

front panel display, and the

volume of the unit becomes

minimum.

• Volume becomes minimum when you turn off the surround amplifier with

headphones connected before you turn off the unit or if radio reception is poor.

In these cases, check radio reception, and set the volume again.

Symptom Remedy

116GB

Self-diagnosis Function

(When letters/numbers appear in the

display)

When the self-diagnosis function is activated to

prevent the system from malfunctioning, a 5-

character service number (e.g., C 13 50) with a

combination of a letter and 4 digits appears on

the TV screen or front panel display. In this case,

check the following table.

When the version number

appears on the TV screen

When you turn on the system, the version

number [VER.X.XX] (X is a number) may

appear on the TV screen. Although this is not a

malfunction and for Sony service use only,

normal system operation will not be possible.

Turn off the system, and then turn on the system

again to operate.

First 3

characters of

the service

number

Cause and/or corrective action

C 13 The disc is dirty.

,Clean the disc with a soft cloth

(page 105).

C 31 The disc is not inserted correctly.

,Restart the system, then re-insert

the disc correctly.

E XX

(XX is a

number)

To prevent a malfunction, the

system has performed the self-

diagnosis function.

,Contact your nearest Sony

dealer or local authorized Sony

service facility and give the 5-

character service number.

Example: E 61 10

C:13:50

VER.X.XX

Additional Information

117GB

Specifications

Amplifier Section

DAV-DZ380W/DAV-DZ680W

Stereo mode (rated) 108 W + 108 W (at 3 ohms,

1 kHz, 1% THD)

Surround mode (reference) RMS output power

FL/FR/C*: 142 watts (per

channel at 3 ohms, 1 kHz,

10% THD)

Subwoofer*: 140 watts (at

3 ohms, 80 Hz, 10% THD)

DAV-DZ880W

Stereo mode (rated) 108 W + 108 W (at 3 ohms,

1 kHz, 1% THD)

Surround mode (reference) RMS output power

FL/FR/C*: 144 watts (per

channel at 3 ohms, 1 kHz,

10% THD)

Subwoofer*: 280 watts (at

1.5 ohms, 80 Hz, 10%

THD)

* Depending on the decoding mode settings and the

source, there may be no sound output.

Inputs (Analog)

TV (AUDIO IN) Sensitivity: 450/250 mV

LINE (AUDIO IN) (DAV-DZ880W only)

Sensitivity: 450/250 mV

AUDIO IN Sensitivity: 250/125 mV

Inputs (Digital)

TV (COAXIAL IN/OPTICAL IN)

Impedance: 75 ohms/-

Input Stream: Dolby

Digital 5.1ch/DTS 5.1ch/

Linear PCM 2ch

(Sampling Frequency: less

than 48 kHz)

Outputs (Analog)

Phones Accepts low- and high-

impedance headphones.

Super Audio CD/DVD System

Laser Diode Properties Emission Duration:

Continuous

Laser Output: Less than

44.6μW

* This output is the value measurement at a distance

of 200mm from the objective lens surface on the

Optical Pick-up Block with 7mm aperture.

Signal format system PAL/NTSC

USB Section

(USB) port:

Maximum current: 500 mA

Tuner Section

System PLL quartz-locked digital

synthesizer

FM Tuner section

Tuning range

North American models: 87.5 MHz - 108.0 MHz

(100 kHz step)

Other models: 87.5 MHz - 108.0 MHz (50

kHz step)

Antenna (aerial) FM wire antenna (aerial)

Antenna (aerial) terminals 75 ohms, unbalanced

Intermediate frequency 10.7 MHz

Video Section

Outputs VIDEO: 1 Vp-p 75 ohms

R/G/B: 0.7 Vp-p 75 ohms

HDMI OUT: Type A (19

pin)

Speakers

Front

DAV-DZ380W (SS-TS92)

Speaker system Full range Bass reflex

Speaker unit 65 mm cone type

Rated impedance 3 ohms

Dimensions (approx.) 103 mm × 164 mm × 94

mm (w/h/d)

Mass (approx.) 0.5 kg

DAV-DZ680W/DAV-DZ880W (SS-TS98)

Speaker system Full range Bass reflex

Speaker unit 65 mm cone type

Rated impedance 3 ohms

Dimensions (approx.) 295 mm × 1,185 mm × 295

mm (113 mm × 640 mm ×

87 mm speaker only for

reference) (w/h/d)

Mass (approx.) 3.3 kg

Center (SS-CT91)

Speaker system Full range Bass reflex,

Magnetically Shielded

Speaker unit 65 mm cone type

Rated impedance 3 ohms

Dimensions (approx.) 265 mm × 94 mm × 77 mm

(w/h/d)

Mass (approx.) 0.7 kg

Surround

DAV-DZ380W/DAV-DZ680W (SS-TS92)

Speaker system Full range Bass reflex

Speaker unit 65 mm cone type

Rated impedance 3 ohms

Dimensions (approx.) 103 mm × 164 mm × 94

mm (w/h/d)

Mass (approx.) 0.5 kg

118GB

DAV-DZ880W (SS-TS98)

Speaker system Full range Bass reflex

Speaker unit 65 mm cone type

Rated impedance 3 ohms

Dimensions (approx.) 295 mm × 1,185 mm × 295

mm (113 mm × 640 mm ×

87 mm speaker only for

reference) (w/h/d)

Mass (approx.) 3.3 kg

Subwoofer

DAV-DZ380W/DAV-DZ680W (SS-WS91)

Speaker system Subwoofer Bass reflex

Speaker unit 160 mm cone type

Rated impedance 3 ohms

Dimensions (approx.) 168 mm × 300 mm × 325

mm (w/h/d)

Mass (approx.) 5.3 kg

DAV-DZ880W (SS-WS97)

Speaker system Subwoofer Bass reflex

Speaker unit 160 mm cone type

Rated impedance 1.5 ohms

Dimensions (approx.) 168 mm × 300 mm × 325

mm (w/h/d)

Mass (approx.) 5.3 kg

General

Power requirements 220 V - 240 V AC,

50/60 Hz

Power consumption On: 110 W

Standby: 0.3 W (at the

Power Saving mode)

Output voltage (DIGITAL MEDIA PORT)

DC 5 V

Output current (DIGITAL MEDIA PORT)

700 mA

Dimensions (approx.) 430 mm × 66 mm × 395

mm (w/h/d) incl.

projecting parts

430 mm × 66 mm × 425

mm (w/h/d) with the

wireless transceiver

inserted

Mass (approx.) 4.3 kg

Surround amplifier (TA-SA100WR)

Amplifier Section (bundled with DAV-DZ380W/

DAV-DZ680W)

Stereo mode (rated)

80 W + 80 W (at 3 ohms, 1

kHz, 1 % THD)

Surround mode (reference) RMS output power

142 W (per channel at 3

ohms, 1 kHz, 10 % THD)*

Amplifier Section (bundled with DAV-DZ880W)

Stereo mode (rated)

80 W + 80 W (at 3 ohms, 1

kHz, 1 % THD)

Surround mode (reference) RMS output power

144 W (per channel at 3

ohms, 1 kHz, 10 % THD)*

* Depending on the source, there may be no sound

output.

Rated impedance: 3 - 16 Ω

General

Power requirements 220 V - 240 V AC,

50/60 Hz

Power consumption On: 50 W

Dimensions (approx.) 85 mm × 100 mm × 330

mm (w/h/d) (incl. Wireless

transceiver)

85 mm × 100 mm × 345

mm (w/h/d) incl. speaker

cord cover and speaker

cord holder

Mass (approx.) 1.7 kg incl. speaker cord

cover and speaker cord

holder

Wireless transceiver (EZW-RT10/EZW-

RT10A)

Communication system S-AIR Specification

version 1.0

Frequency band 2.4000 GHz - 2.4835 GHz

Modulation method DSSS

Power requirements DC 3.3 V, 350 mA

Dimensions (approx.) 50 mm × 13 mm × 60 mm

(w/h/d)

Mass (approx.) 24 g

Supported file format

MP3 (MPEG 1 Audio Layer-3)

File Extension: mp3

Bitrate: 32 kbps - 320 kbps

Sampling frequencies: 32/44.1/48 kHz

WMA (USB device only)

File Extension: wma

Bitrate: 48 kbps - 192 kbps

Sampling frequencies: 44.1 kHz

AAC (USB device only)

File Extension: m4a

Bitrate: 48 kbps - 320 kbps

Sampling frequencies: 44.1 kHz

DivX

File Extension: avi/divx

Video codec: DivX video

Bitrate: 8 Mbps (MAX)

Frame rate: 30 fps

Resolution: 720 × 576

Audio codec: MP3

Additional Information

119GB

MPEG4

File format: MP4 File Format

File Extension: mp4/m4v

Video codec: MPEG4 Simple Profile

(AVC is not compatible.)

Bitrate: 4 Mbps

Frame rate: 30 fps

Resolution: 720 × 576

Audio codec: AAC-LC (HE-AAC is not

compatible.)

DRM: Not compatible

Design and specifications are subject to change

without notice.

Glossary

Digital Cinema Auto Calibration

Digital Cinema Auto Calibration was developed

by Sony to automatically measure and adjust the

speaker settings to your listening environment in

a short period of time.

Digital Direct Twin Drive Subwoofer

(DAV-DZ880W only)

Utilizing Sony proprietary S-master technology,

the Digital Direct Twin Drive Subwoofer

features two S-master Digital Amplifiers that

provide dedicated power to a strategically

located subwoofer for astounding sound

performance. Easy to set up, Digital Direct Twin

Drive Subwoofer provides a stable sound field

over a much larger listening area without having

to adjust frequency levels.

Dolby Digital

This movie theater sound format is more

advanced than Dolby Surround Pro Logic. In

this format, the surround speakers output stereo

sound with an expanded frequency range, and a

subwoofer channel for deep bass is

independently provided. This format is also

called “5.1” with the subwoofer channel

designed as the 0.1 channel (since it functions

only when a deep bass effect is needed). All six

channels in this format are recorded separately

for superior channel separation. Furthermore,

since all the signals are processed digitally, less

signal degradation occurs.

Dolby Pro Logic II

Dolby Pro Logic II creates five full-bandwidth

output channels from 2 channel sources. This is

done using an advanced, high-purity matrix

surround decoder that extracts the spatial

properties of the original recording without

adding any new sounds or tonal colorations.

xMovie mode

The Movie mode is for use with stereo television

shows and all programs encoded in Dolby

Surround. The result is enhanced sound field

directionality that approaches the quality of

discrete 5.1-channel sound.

120GB

xMusic mode

The Music mode is for use with any stereo music

recordings, and provides a wide and deep sound

space.

Dolby Surround Pro Logic

As one method of decoding Dolby Surround,

Dolby Surround Pro Logic produces four

channels from 2 channel sound. Compared with

the former Dolby Surround system, Dolby

Surround Pro Logic reproduces left-to-right

panning more naturally and localizes sounds

more precisely. To take full advantage of Dolby

Surround Pro Logic, you should have one pair of

surround speakers and a center speaker. The

surround speakers output monaural sound.

DTS

Digital audio compression technology

developed by DTS, Inc. This technology

conforms to 5.1-channel surround. This format

is comprised of a stereo rear channel and a

discrete subwoofer channel. DTS provides the

same 5.1 discrete channels of high quality digital

audio. The good channel separation is realized

due to the all channel data being recorded

discretely and processed digitally.

HDMI (High-Definition Multimedia

Interface)

HDMI is an interface that supports both video

and audio on a single digital connection,

allowing you to enjoy high quality digital

picture and sound. The HDMI specification

supports HDCP (High-bandwidth Digital

Content Protection), a copy protection

technology that incorporates coding technology

for digital video signals.

Parental Control

A function of the DVD to limit playback of the

disc by the age of users according to the

limitation level in each country. The limitation

varies from disc to disc; when it is activated,

playback is completely prohibited, violent

scenes are skipped or replaced with other scenes

and so on.

S-AIR

(Sony Audio Interactive Radio

frequency)

Recent times have seen the rapid spread of DVD

media, Digital Broadcasting, and other high-

quality media.

To ensure that the subtle nuances of these high-

quality media are transmitted with no

deterioration, Sony has developed a technology

called “S-AIR” for the radio transmission of

digital audio signals with no compression, and

has incorporated this technology into the EZW-

RT10/EZW-RT10A/EZW-T100.

This technology transfers digital audio signals

with no compression using the 2.4 GHz band

range of ISM band (Industrial, Scientific, and

Medical band), also used by wireless LANs and

Bluetooth applications.

Super Audio CD

Super Audio CD is a new high-quality audio

disc standard where music is recorded in the

DSD (Direct Stream Digital) format

(conventional CD is recorded in the PCM

format). The DSD format, using a sampling

frequency 64 times higher than that of a

conventional CD, and with 1-bit quantization,

achieves both a wide frequency range and a wide

dynamic range across the audible frequency

range, and so provides music reproduction

extremely faithful to the original sound.

xSuper Audio CD types

There are two types of discs, depending on the

Super Audio CD layer and CD layer

combination.

• Super Audio CD layer: A high-density

signal layer for Super Audio CD

•CD layer

1): A layer that is readable by a

conventional CD player

Additional Information

121GB

A Super Audio CD layer consists of the 2

channel area or the multi-channel area.

• 2 channel area: An area in which 2 channel

stereo tracks are recorded

• Multi-channel area: An area in which multi-

channel (up to 5.1 channels) tracks are

recorded

1)You can play the CD layer on a conventional CD

player.

2)Since both layers are on one side, it is not necessary

to turn the disc over.

3)To select a layer, see “Changing a playback layer for

a hybrid Super Audio CD” (page 47).

4)To select an area, see “Selecting a playback area for

a Super Audio CD” (page 47).

Single layer disc

(a disc with a single Super Audio CD layer)

Super Audio CD

layer

Hybrid disc2)

(a disc with a Super Audio CD layer and a CD layer)

Super Audio CD

layer3)

CD layer3)

Super Audio CD

layer

Multi-channel area4)

2 channel area4)

122GB

Playback priority of file types

The table below describes the playback priority of file types under the [MEDIA] setting.

* When using a disc, you can play MP3 files only.

File type on a disc or USB

device

[MEDIA] setting

[VIDEO] [MUSIC/

PHOTO]

[PHOTO] [MUSIC]

Disc USB device Disc Disc/USB

device

Disc/USB

device

Video files only Video files Video files Video files Video files Video files

JPEG image files only JPEG image

files

JPEG image

files

JPEG image

files

JPEG image

files

JPEG image

files

Audio files only MP3 files Audio files MP3 files Audio files* Audio files*

Video files and JPEG image

files

Video files Video files JPEG image

files

JPEG image

files

Video files

Video files and audio files Video files Video files MP3 files Audio files* Audio files*

Audio files and JPEG image

files

MP3 files and

JPEG image

files with slide

show

Audio files MP3 files and

JPEG image

files with slide

show

JPEG image

files

Audio files*

Video files, audio files, and

JPEG image files

Video files Video files MP3 files and

JPEG image

files with slide

show

JPEG image

files

Audio files*

Additional Information

123GB

Language Code List

The language spellings conform to the ISO 639: 1988 (E/F) standard.

Code Language Code Language Code Language Code Language

1027 Afar

1028 Abkhazian

1032 Afrikaans

1039 Amharic

1044 Arabic

1045 Assamese

1051 Aymara

1052 Azerbaijani

1053 Bashkir

1057 Byelorussian

1059 Bulgarian

1060 Bihari

1061 Bislama

1066 Bengali;

Bangla

1067 Tibetan

1070 Breton

1079 Catalan

1093 Corsican

1097 Czech

1103 Welsh

1105 Danish

1109 German

1130 Bhutani

1142 Greek

1144 English

1145 Esperanto

1149 Spanish

1150 Estonian

1151 Basque

1157 Persian

1165 Finnish

1166 Fiji

1171 Faroese

1174 French

1181 Frisian

1183 Irish

1186 Scots Gaelic

1194 Galician

1196 Guarani

1203 Gujarati

1209 Hausa

1217 Hindi

1226 Croatian

1229 Hungarian

1233 Armenian

1235 Interlingua

1239 Interlingue

1245 Inupiak

1248 Indonesian

1253 Icelandic

1254 Italian

1257 Hebrew

1261 Japanese

1269 Yiddish

1283 Javanese

1287 Georgian

1297 Kazakh

1298 Greenlandic

1299 Cambodian

1300 Kannada

1301 Korean

1305 Kashmiri

1307 Kurdish

1311 Kirghiz

1313 Latin

1326 Lingala

1327 Laothian

1332 Lithuanian

1334 Latvian;

Lettish

1345 Malagasy

1347 Maori

1349 Macedonian

1350 Malayalam

1352 Mongolian

1353 Moldavian

1356 Marathi

1357 Malay

1358 Maltese

1363 Burmese

1365 Nauru

1369 Nepali

1376 Dutch

1379 Norwegian

1393 Occitan

1403 (Afan)Oromo

1408 Oriya

1417 Punjabi

1428 Polish

1435 Pashto;

Pushto

1436 Portuguese

1463 Quechua

1481 Rhaeto-

Romance

1482 Kirundi

1483 Romanian

1489 Russian

1491 Kinyarwanda

1495 Sanskrit

1498 Sindhi

1501 Sangho

1502 Serbo-

Croatian

1503 Singhalese

1505 Slovak

1506 Slovenian

1507 Samoan

1508 Shona

1509 Somali

1511 Albanian

1512 Serbian

1513 Siswati

1514 Sesotho

1515 Sundanese

1516 Swedish

1517 Swahili

1521 Tamil

1525 Telugu

1527 Tajik

1528 Thai

1529 Tigrinya

1531 Turkmen

1532 Tagalog

1534 Setswana

1535 Tonga

1538 Turkish

1539 Tsonga

1540 Tatar

1543 Twi

1557 Ukrainian

1564 Urdu

1572 Uzbek

1581 Vietnamese

1587 Volapük

1613 Wolof

1632 Xhosa

1665 Yoruba

1684 Chinese

1697 Zulu

1703 Not specified

Parental Control Area Code List

Code Area Code Area Code Area Code Area

2044 Argentina

2047 Australia

2046 Austria

2057 Belgium

2070 Brazil

2079 Canada

2090 Chile

2092 China

2115 Denmark

2165 Finland

2174 France

2109 Germany

2248 India

2238 Indonesia

2254 Italy

2276 Japan

2304 Korea

2363 Malaysia

2362 Mexico

2376 Netherlands

2390 New Zealand

2379 Norway

2427 Pakistan

2424 Philippines

2436 Portugal

2489 Russia

2501 Singapore

2149 Spain

2499 Sweden

2086 Switzerland

2528 Thailand

2184 United

Kingdom

124GB

Index to Parts and Control

For more information, refer to the pages indicated in parentheses.

A"/1 (on/standby) (36, 103)

BZ (open/close) (44)

CFront panel display (126)

DFUNCTION (39)

E (remote sensor) (12)

FMOVIE/MUSIC indicator (98)

GVOLUME control (44)

HREC TO USB (85)

I (USB) port (76)

JOPERATION DIAL (44)

KPHONES jack (44)

LAUDIO IN/A.CAL MIC jack (28, 36, 95)

MPlay operation buttons (44)

NDisc tray (44)

Front panel

Additional Information

125GB

DAV-DZ380W/DAV-DZ680W

ASPEAKER jacks (23)

BEZW-RT10 slot (32)

CCOAXIAL 75Ω FM jack (31)

DEURO AV T OUTPUT (TO TV) jack (26)

EDMPORT (DIGITAL MEDIA PORT) jack

(28, 88)

FHDMI OUT jack (26)

GTV (DIGITAL IN COAXIAL/OPTICAL)

jacks (26)

DAV-DZ880W

ASPEAKER jacks (23)

BEZW-RT10 slot (32)

CCOAXIAL 75Ω FM jack (31)

DEURO AV T OUTPUT (TO TV) jack (26)

ELINE (AUDIO IN R/L) jacks (29)

FDMPORT (DIGITAL MEDIA PORT) jack

(28, 88)

GHDMI OUT jack (26)

HTV (DIGITAL IN COAXIAL/OPTICAL)

jacks (26)

Rear panel

CENTER

SUBWOOFER

HDMI OUT

SPEAKER EURO AV

OUTPUT(TO TV)

COAXIAL 75

ANTENNA

DMPORT

DC5V

0.7A MAX

EZW-RT10

DIGITAL IN

COAXIALOPTICAL

FRONT R FRONT L

SPEAKER

CENTER

SUBWOOFER

HDMI OUT

SPEAKER EURO AV

OUTPUT(TO TV)

COAXIAL 75

ANTENNA

DMPORT

DC5V

0.7A MAX

EZW-RT10

DIGITAL IN

COAXIALOPTICAL

FRONT R FRONT L

SPEAKER

AUDIO IN LR

LINE

126GB

About the indications in the front panel display

APlaying status

BFlashes when the sleep timer is set.

(99)

CDisplays the system’s status such as

chapter, title, or track number, time

information, radio frequency, playing

status, decoding mode, etc.

DLights up when a station is received.

(Radio only) (70)

EStereo/Monaural effect (Radio only)

(71)

FLights up when the S-AIR transceiver is

inserted in the unit and the system

transmits the sound. (89)

GLights up when the HDMI OUT jack is

correctly connected to HDCP (High-

bandwidth Digital Content Protection)

compliant device with HDMI or DVI

(Digital Visual Interface) input. (26)

HCurrent surround format (Except for

JPEG image file)

ILights up when an NTSC disc is

loaded.

JLights up when a Super Audio CD/CD

is loaded. (47)

Front panel display

Additional Information

127GB

APHONES jack (35)

BPOWER (ON/OFF) (35, 89)

CPOWER / ON LINE indicator (35, 89)

DPAIRING indicator (91)

EPAIRING (91)

FWireless transceiver (EZW-RT10) slot

(32)

GS-AIR ID switch (35, 89)

HSPEAKER L jack (23)

ISPEAKER R jack (23)

JSURROUND SELECTOR switch (35, 89)

Surround amplifier

PHONES

POWER

POWER/ON LINE

Front panel Rear panel

SURROUND SELECTOR

S-AIR ID

EZW-RT10

SPEAKER

SURROUND

PA I R I N G

SURROUND

BACK

128GB

Remote control

ALPHABETICAL ORDER BUTTON DESCRIPTIONS

A – O P – Z

ANGLE ws (45)

AUDIO qg (46)

CLEAR es (49, 71)

D.TUNING qh (71)

DIMMER ed (100)

DISPLAY wa (72, 82, 100)

DVD MENU wg (52)

DVD TOP MENU qd (52)

DYNAMIC BASS 4 (97)

ENTER wf (96)

FUNCTION +/– 2 (39, 44)

MEMORY SELECT1) ws

MENU wg (96)

MUTING 7 (44)

NIGHT wd (97)

ONE-TOUCH PLAY eh (74)

PICTURE NAVI ef (55, 78)

PRESET +/– wj (71)

PROG +/– wj (96)

S-AIR MODE eg

SLEEP qj (99)

SOUND MODE 3 (98)

SUBTITLE qh (46)

SYSTEM MENU 5 (33, 41, 70,

99)

THEATRE qk (73)

TOOLS wh (96)

TUNING +/– 0 (70)

TV wl (96)

TV INPUT w; (96)

VOLUME +/– 8 (44)

Number buttons qf (48, 70, 96)

[/1 (on/standby) 1 (33, 36, 44)

TV [/1 (on/standby) ql (96)

C/X/x/c/ qs (33, 36, 47, 49,

70, 94)

+/– 6 (54, 76)

REPLAY/ADVANCE

9 (44)

./> wj (44)

m/M 0 (44)

STEP / 9 (44)

SLOW / 0 (44)

H (play) e; (44)

x (stop) wk (44)

X (pause) qa (44)

DISPLAY2) wh (36, 47, 49, 62,

94, 129)

O RETURN ea (48, 96)

-/-- es (96)

1)See the included supplement.

2)This button is available for

the “DVD,” “USB,” or

“DMPORT” function.

Depending on the DIGITAL

MEDIA PORT adapter, this

button may not work.

Additional Information

129GB

Guide to the Control Menu Display

You can use the Control Menu display to select a function and to view related information.

Press DISPLAY repeatedly.

Each time you press DISPLAY, the Control Menu display changes:

1 t 2 t ... t 1 t ...

1 Control Menu display 1

2 Control Menu display 2 (appears when available)

3 Control Menu display off

Note

• The Control Menu Display appears during the “DVD” or “USB” function.

The Control Menu display 1 and 2 will show different items depending on the disc type. For details,

see the pages in parentheses.

Control Menu display

DISPLAY

130GB

Example: Control Menu display 1 when playing a DVD VIDEO.

To turn off the display

Press DISPLAY.

List of Control Menu items

Item Item Name, Function, Relevant Disc Type

[TITLE] (page 52)/[SCENE] (page 52)/[TRACK] (page 52)

You can select the title, scene, or track to be played.

[CHAPTER] (page 52)/[INDEX] (page 52)

You can select the chapter or index to be played.

[INDEX] (page 52)

You can display the index and select the index to be played.

[TRACK] (page 52)

You can select the track to be played.

[ORIGINAL/PLAY LIST] (page 52)

You can select the type of titles (DVD-RW/DVD-R) to be played, the [ORIGINAL] one, or

an edited [PLAY LIST].

[TIME] (page 53)

You can check the elapsed time and the remaining playback time.

You can play from a desired point by inputting the time code (DVD VIDEO/DVD-VR only).

[MULTI/2CH] (page 47)

You can select the playback area on a Super Audio CD when available.

[SUPER AUDIO CD/CD LAYER] (page 47)

You can select the playback layer on a Super Audio CD when available.

[PROGRAM] (page 49)

You can select the track to play in the order you want.

98( 99)

OFF

DVD VIDEO

REPEAT

Quit:

ENTER DISPLAY

T 0: 04: 17

13( 99)

DISC

TITLE

CHAPTER

OFF

Currently playing title number

Playing time

Total number of chapters

Options

Current setting

Total number of titles

Playback status

(N Playback,

X Pause,

x Stop, etc.)

Function name of selected

Control Menu item

Operation message

Selected item

Control Menu items

Type of disc being

played

Currently playing chapter number

Additional Information

131GB

* These items are not displayed when playing a DATA CD/DATA DVD with video files.

List of Control Menu Items for USB device

[SHUFFLE] (page 50)

You can play the tracks/files in random order.

[REPEAT] (page 51)

You can play the entire disc (all titles/all tracks/all folders/all files) repeatedly or one title/

chapter/track/folder/file repeatedly.

[A/V SYNC] (page 60)

You can adjust the delay between the picture and sound.

[DISC MENU] (page 52)

You can display the DVD’s menu.

[BROWSING] (page 57)

You can display the list of folders/JPEG image files.

[SETUP] (page 62)

[CUSTOM]

In addition to the Quick Setup setting, you can adjust various other settings.

[QUICK] (page 36)

You can make the basic adjustments. Use Quick Setup to select the desired language of the

on-screen display, the aspect ratio of the TV, and select yes or no to start the Auto Calibration.

[FOLDER] (page 52)

You can select the folder to be played.

[FILE] (page 52)

You can select the JPEG image file or video file to be played.

*[DATE] (page 102)

You can display the date the picture was taken by a digital camera.

*[INTERVAL] (page 56)

You can select the duration for which the slides are displayed on the TV screen.

*[EFFECT] (page 57)

You can select the effects to be used for changing slides during a slide show.

[MEDIA] (page 57)

You can select the data type (MP3 file, JPEG image file, video file, or both MP3 file and JPEG

image file) to be played on a DATA CD/DATA DVD.

Item Item Name, Function, Relevant Disc Type

[REPEAT] (page 82)

You can play the entire USB device (all folders/all files) repeatedly or one folder/file

repeatedly.

[BROWSING] (page 81)

You can display the list of folders/JPEG image files.

[DATE] (page 83)

You can display the date the picture was taken by a digital camera.

[INTERVAL] (page 79)

You can select the duration for which the slides are displayed on the TV screen.

132GB

• The Control Menu icon indicator lights up in yellow t when you select any item except [OFF]

([PROGRAM], [SHUFFLE], [REPEAT], and [A/V SYNC] only). The [ORIGINAL/PLAY LIST] indicator lights

up in yellow when you select [PLAY LIST] (default setting). The [MULTI/2CH] indicator lights up in yellow when

you select the multi-channel playback area on a Super Audio CD.

[EFFECT] (page 80)

You can select the effects to be used for changing slides during a slide show.

[MEDIA] (page 81)

You can select the data type (MP3/AAC/WMA file, JPEG image file, or video file) on a USB

device.

[USB TRANSFER] (page 84)

You can transfer tracks on an audio CD or MP3 files on a CD/DATA CD/DATA DVD onto

a USB device.

[SHUFFLE]

You can play files in random order.

[TRACK]

You can select the track to be played.

[FOLDER]

You can select the folder to be played.

[FILE]

You can select the JPEG image file to be played.

[TIME]

You can check the elapsed time and the remaining playback time.

[A/V SYNC]

You can adjust the delay between the picture and sound.

133GB

Index

Numerics

5.1 Channel Surround 46

A/V SYNC 60

AAC file 76

ANGLE 46

ATTE N UAT E 9 9

AUDIO 63

AUDIO (HDMI) 65

AUDIO DRC 66

Audio file 76

AUDIO SETUP 66

AUTO CALIBRATION 66, 95,

119

BACKGROUND 66

COLD RESET 103

CONTROL FOR HDMI 64

Control for HDMI 73

Control Menu Display 129

CUSTOM 62, 103

D. C. A. C. (Digital Cinema

Auto Calibration) 95, 119

DATA CD 58

DATA DVD 58

DEMO 33

Digital Direct Twin Drive

Subwoofer 119

DIGITAL MEDIA PORT 88

DIMMER 100

DISPLAY 72

DivX 76

DivX® 58, 67

Dolby Digital 46, 119

Dolby Pro Logic II 119

Dolby Surround Pro Logic 120

DTS 46, 120

DUAL MONO 98

DVD’s menu 52

DYNAMIC BASS 97

EFFECT 57, 80

FM MODE 71

Front panel 124

Front panel display 100, 126

HDMI

YCBCR/RGB (HDMI) 65

HDMI (High-Definition

Multimedia Interface) 120

HDMI RESOLUTION 64

HDMI SETUP 64

Instant Advance 45

Instant Replay 45

INTERVAL 56, 79

JPEG image file 54, 76

JPEG RESOLUTION 65

Language Code List 123

LANGUAGE SETUP 63

LINE 64

MEDIA 54, 55, 56, 57, 58, 77,

78, 80, 81

MENU 63

MP3 file 54, 76

MPEG4 58, 76

Multi Session CD 7

MULTI-DISC RESUME 67

Multiplex broadcast sound 98

Naming preset stations 71

NIGHT 97

OSD 63

PAIRING 92

PARENTAL CONTROL 60,

67, 120

PAUSE MODE 64

PBC Playback 48

PICTURE NAVI 55, 79

Playable discs 6

Program Play 49

Quick Setup 36

RDS 72

Rear panel 125

Region Code 8

Remote 12

Repeat Play 51

RESET 67, 103

Resume Play 48

RF CHANGE 93

S-AIR 120

S-AIR ID 89

S-AIR MODE 90

S-AIR receiver 89

S-AIR STBY 91

SCREEN SAVER 66

SETUP 62, 103

Shuffle Play 50

SLEEP 99

Slide Show 56

SPEAKER FORMATION 66,

SPEAKER SETUP 67

CONNECTION 67

DISTANCE 67, 68

LEVEL 68

SUBTITLE 46, 63

Super Audio CD 47, 120

Surround amplifier 89, 127

SYSTEM MENU 33, 41, 71,

89, 90, 91, 92, 93, 99, 100

SYSTEM SETUP 66

TEST TONE 68

TIME 53

TRACK SELECTION 66

TV TYPE 64

USB device 76

VIDEO SETUP 63

VOLUME LIMIT 65

WMA file 76
