4-129-231-11 (1)

P/N7525000004A

Digital Photo

Frame

DPF-D82/D92

© 2009 Sony Corporation

Before operation

Basic operations

Advanced operations

Using an external device

(with Bluetooth)

Using an external device

(with a computer)

Error messages

Troubleshooting

Additional information

Operating Instructions

Before operating this unit, please read this manual thoroughly and

retain it for future reference.

Owner’s Record

The model and serial numbers are located at the rear.

Record the serial number in the space provided below. Refer to

these numbers whenever you call upon your Sony dealer

regarding this product.

Model No. DPF-D82/D92

Serial No. ________________________

2 GB

To reduce fire or shock hazard, do not

expose the unit to rain or moisture.

Do not expose the batteries to

excessive heat such as sunshine, fire

or the like.

CAUTION

Replace the battery with the specified

type only. Otherwise, fire or injury

may result. Dispose of used batteries

according to the instructions.

For the customers in the U.S.A.

CAUTION

You are cautioned that any changes or modifications

not expressly approved in this manual could void

your authority to operate this equipment.

If you have any questions about this product, you may

call:

Sony Customer Information Services Center

1-800-222-SONY (7669)

The number below is for the FCC related matters

only.

Regulatory Information

Note:

This equipment has been tested and found to comply

with the limits for a Class B digital device, pursuant

to Part 15 of the FCC Rules.

These limits are designed to provide reasonable

protection against harmful interference in a

residential installation. This equipment generates,

uses, and can radiate radio frequency energy and, if

not installed and used in accordance with the

instructions, may cause harmful interference to radio

communications. However, there is no guarantee that

interference will not occur in a particular installation.

If this equipment does cause harmful interference to

radio or television reception, which can be

determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by

one or more of the following measures:

– Reorient or relocate the receiving antenna.

– Increase the separation between the equipment and

receiver.

– Connect the equipment into an outlet on a circuit

different from that to which the receiver is

connected.

– Consult the dealer or an experienced radio/TV

technician for help.

WARNING

Declaration of Conformity

Trade Name: SONY

Model No.: DPF-D92

Responsible Party: Sony Electronics Inc.

Address: 16530 Via Esprillo, San Diego,

CA 92127 U.S.A.

Telephone No.: 858-942-2230

This device complies with part 15 of the FCC

Rules. Operation is subject to the following two

conditions:

(1) This device may not cause harmful

interference, and (2) this device must accept any

interference received, including interference that

may cause undesired operation.

Declaration of Conformity

Trade Name: SONY

Model No.: DPF-D82

Responsible Party: Sony Electronics Inc.

Address: 16530 Via Esprillo, San Diego,

CA 92127 U.S.A.

Telephone No.: 858-942-2230

This device complies with part 15 of the FCC

Rules. Operation is subject to the following two

conditions:

(1) This device may not cause harmful

interference, and (2) this device must accept any

interference received, including interference that

may cause undesired operation.

3 GB

For the State of California, USA

only

Perchlorate Material - special handling may apply,

See

www.dtsc.ca.gov/hazardouswaste/perchlorate

Perchlorate Material: Lithium battery contains

perchlorate.

For the Customer in Europe

This product has been tested and found compliant

with the limits set out in the EMC Directive for using

connection cables shorter than 3 meters (9.8 feet).

Attention

The electromagnetic fields at the specific frequencies

may influence the picture of this digital photo frame.

Notice

If static electricity or electromagnetism causes data

transfer to discontinue midway (fail), restart the

application or disconnect and connect the

communication cable (USB, etc) again.

Disposal of Old Electrical &

Electronic Equipment (Applicable in

the European Union and other

European countries with separate

collection systems)

This symbol on the product

or on its packaging indicates

that this product shall not be

treated as household waste.

Instead it shall be handed

over to the applicable

collection point for the

recycling of electrical and

electronic equipment. By

ensuring this product is

disposed of correctly, you

will help prevent potential

negative consequences for

the environment and human health, which could

otherwise be caused by inappropriate waste handling

of this product. The recycling of materials will help to

conserve natural resources. For more detailed

information about recycling of this product, please

contact your local Civic Office, your household waste

disposal service or the shop where you purchased the

product.

Disposal of waste batteries

(applicable in the European Union

and other European countries with

separate collection systems)

This symbol on the battery or on the

packaging indicates that the battery

provided with this product shall not

be treated as household waste. By

ensuring these batteries are disposed

of correctly, you will help prevent

potentially negative consequences for

the environment and human health which could

otherwise be caused by inappropriate waste handling

of the battery. The recycling of the materials will help

to conserve natural resources. In case of products that

for safety, performance or data integrity reasons

require a permanent connection with an incorporated

battery, this battery should be replaced by qualified

service staff only. To ensure that the battery will be

treated properly, hand over the product at end-of-life

to the applicable collection point for the recycling of

electrical and electronic equipment. For all other

batteries, please view the section on how to remove

the battery from the product safely. Hand the battery

over to the applicable collection point for the

recycling of waste batteries.

For more detailed information about recycling of this

product or battery, please contact your local Civic

Office, your household waste disposal service or the

shop where you purchased the product.

Notice for the customers in the

countries applying EU Directives

The manufacturer of this product is Sony

Corporation, 1-7-1 Konan Minato-ku Tokyo, 108-

0075 Japan. The Authorized Representative for EMC

and product safety is Sony Deutschland GmbH,

Hedelfinger Strasse 61, 70327 Stuttgart, Germany.

For any service or guarantee matters please refer to

the addresses given in separate service or guarantee

documents.

Continued

4 GB

Notes on LCD screen

• Do not press against the LCD screen. The screen

may be discolored and that may cause a

malfunction.

• Exposing the LCD screen to direct sunlight for long

periods may cause malfunctions.

• The LCD screen is manufactured using extremely

high-precision technology, so over 99.99% of the

pixels are operational for effective use. However,

there may be some tiny black points and/or bright

points (white, red, blue or green in color) that

constantly appear on the LCD screen. These points

are normal in the manufacturing process and do not

affect the viewing in any way.

• Images may trail across on the LCD screen in a cold

location. This is not a malfunction.

On trademarks and copyrights

• , BRAVIA, BRAVIA Sync, ,

“PhotoTV HD”, , Cyber-shot, , “Memory

Stick”, , “Memory Stick Duo”,

, “MagicGate Memory

Stick”, “Memory Stick PRO”,

, “Memory Stick PRO Duo”,

, “Memory Stick PRO-HG

Duo”, , “Memory Stick

Micro”, , , “Memory Stick-

ROM”, , “MagicGate”, and

are trademarks or registered

trademarks of Sony Corporation.

• Microsoft, Windows, and Windows Vista are either

registered trademarks or trademarks of Microsoft

Corporation in the United States and/or other

countries.

• Macintosh and Mac OS are registered trademarks of

Apple Inc. in the United States and/or other

countries.

• CompactFlash is a trademark of SanDisk

Corporation in the U.S.A.

• or xD-Picture Card™ is a trademark of

FUJIFILM Corporation.

• The Bluetooth word mark and logos are owned by

the Bluetooth SIG, Inc. and any use of such marks

by Sony Corpration is under licence. Other

trademarks and trade names are those of their

resective owners.

• Contains iTypeTM and fonts from Monotype

Imaging Inc.

iTypeTM is a trademark of Monotype Imaging Inc.

• All other companies and product names mentioned

herein may be the trademarks or registered

trademarks of their respective companies.

Furthermore, “™” and “®” are not mentioned in

each case in this manual.

• This unit is equipped with face recognition feature.

Sony Face Recognition technology developed by

Sony is used.

Duplication, edition, or printing of a CD, TV

programs, copyrighted materials such as pictures or

publications, or any other materials except for your

own recording or creation is limited to private or

domestic use only. Unless you hold copyright or

have permission of copyright holders for the

materials to be duplicated, use of those materials

beyond this limit may infringe the provisions of the

copyright law and be subject to the copyright

holders claim for damages.

When using photo images with this digital photo

frame, pay special attention not to infringe the

provisions of the copyright law. Any unauthorized

use or modification of there’s portrait may also

infringe their rights.

For some demonstrations, performances, or

exhibits, photography may be forbidden.

Backup recommendations

To avoid potential risk of data loss caused by

accidental operation or malfunction of the digital

photo frame, we recommend that you save a

backup copy of your data.

Information

IN NO EVENT SHALL SELLER BE LIABLE

FOR ANY DIRECT, INCIDENTAL OR

CONSEQUENTIAL DAMAGES OF ANY

NATURE, OR LOSSES OR EXPENSES

RESULTING FROM ANY DEFECTIVE

PRODUCT OR THE USE OF ANY PRODUCT.

Sony shall assume no responsibility for any

accidental or consequential damages or loss of the

recording contents which may be caused by use or

malfunction of the digital photo frame or memory

card.

5 GB

Notice for users

Program © 2009 Sony Corporation

Documentation © 2009 Sony Corporation

All rights reserved. This manual or the software

described herein, in whole or in part, may not be

reproduced, translated or reduced to any machine

readable form without prior written approval from

Sony Corporation.

IN NO EVENT SHALL SONY CORPORATION BE

LIABLE FOR ANY INCIDENTAL,

CONSEQUENTIAL OR SPECIAL DAMAGES,

WHETHER BASED ON TORT, CONTACT, OR

OTHERWISE, ARISING OUT OF OR IN

CONNECTION WITH THIS MANUAL, THE

SOFTWARE OR OTHER INFORMATION

CONTAINED HEREIN OR THE USE THEREOF.

Sony Corporation reserves the right to make any

modification to this manual or the information

contained herein at any time without notice.

The software described herein may also be governed

by the terms of a separate user license agreement.

Any design data such as sample pictures provided in

this software cannot be modified or duplicated except

for the purpose of personal use. Any unauthorized

duplication of this software is prohibited under

copyright law.

Please note that unauthorized duplication or

modification of portraits or copyrighted work could

infringe the rights reserved by rights holders.

On the illustrations and screen

shots used in this manual

The illustrations and screen shots used in this

manual are of the DPF-D92 unless noted

otherwise.

6 GB

Table of Contents

Before operation

Enjoying your photo frame in various

ways ...............................................8

Features ..........................................9

Checking included items ...............11

Identifying the parts .....................11

Basic operations

Preparing the remote control ........15

Setting the stand ..........................16

To display the photo frame on

the wall .........................................17

Connecting to the AC power

source ..........................................18

Turning the photo frame on ..........19

Setting the current time ................20

Inserting a memory card ..............21

Changing the display ....................23

Slideshow display .........................24

Clock and calendar display ...........25

Single view mode .........................26

Index image display ......................27

Advanced operations

Enjoying a slideshow ....................29

Changing the settings of

the slideshow ................................. 29

Refresh mode ...............................32

Adding images to the internal

memory ........................................32

Exporting an image .......................34

Deleting an image .........................36

Registering a mark .......................37

Searching for an image

(Filtering) ......................................39

Specifying the playback device .....40

Adjusting the image size and

position ...................................40

Enlarging/reducing an image ..........40

Rotating an image ...........................41

Changing the settings of the auto

power on/off function ...................42

Using the alarm function ..............43

Setting the alarm ............................43

Setting the time to be alarmed ........44

Changing the settings ...................44

Setting procedure ...........................44

Items to set .....................................46

Operating an external device

connected to the photo frame .......48

Using an external device

(with Bluetooth)

Connecting to a Bluetooth

device ...........................................49

Using an external device

(with a computer)

Connecting to a computer ............51

System requirements ......................51

7 GB

Connecting to a computer to exchange

images ...........................................51

Disconnecting your computer ........52

Error messages

If an error message appears .........53

Troubleshooting

If trouble occurs ...........................55

Additional information

Precautions ..................................60

Safety .............................................60

Installation .....................................60

Cleaning .........................................60

Restrictions on duplication .............61

About memory cards ....................61

“Memory Stick” ..............................61

SD memory card ............................62

xD-Picture Card .............................62

CompactFlash card ........................62

Notes on using a memory card .......63

Specifications ...............................64

Index ............................................66

8 GB

Before operation

Enjoying your photo frame in various ways

The Sony DPF-D82/D92 is a digital photo frame for easily displaying images taken with a digital

camera or other device, without using a computer.

9 GB

Before operation

Features

xSupport for various memory cards*

Supports various memory cards and other

devices, such as a “Memory Stick”,

CompactFlash card, SD memory card, xD-

Picture Card, and USB memory. Just insert a

memory card removed from a digital camera

or other device, and you will be able to view

the images immediately. (.page 21, 48)

xVarious display functions

You can enjoy various viewing modes, such

as the slideshow display, Clock and calendar

display, Single view mode, and Index image

display. (.page 23)

xVarious modes

The displayed image can be switched

automatically as though you are turning the

pages of an album yourself. You can select

from various modes, including just images, a

clock, or calendar view. You can also change

playback settings such as the playback order.

(.page 29)

xAdding images to internal memory

The images you add to the album are saved

in internal memory. (.page 32)

xExporting images

You can export images in the album to your

memory card. (.page 34)

Continued

10 GB

xSearch function

You can search for images by the date,

folder, image direction, and mark.

(.page 39)

xAlarm function

The photo frame announces the specified

time on the image and using sound.

(.page 43)

xAutomatic rotation of images

The photo frame automatically rotates

images to their proper orientation. Images

are also automatically rotated when the

photo frame is set in either the portrait or

landscape position. (.page 16)

xEasy transfer of images taken with a

Bluetooth compatible mobile phone

or other device*

You can transfer images to the photo frame's

internal memory from a Bluetooth

compatible device via a Bluetooth adaptor

(optional). (.page 49)

xDisplaying images on a wall

You can hang the photo frame on the wall.

(.page 17)

* We do not guarantee proper operations for all types

of devices.

11 GB

Before operation

Checking included

items

Make sure that the following items are

included.

• Digital photo frame (1)

• Stand (1)

• Remote control (1)

• AC adaptor (1)

• Operating Instructions (this manual) (1)

• Read This First (1)

• Warranty (1)

(In some regions, the warranty is not

supplied.)

Identifying the parts

For details, see the pages indicated in the

parentheses.

The illustrations are of the DPF-D92. The

locations and names of buttons and connectors

of the DPF-D82 are identical to those of the

DPF-D92, although the LCD screen size and

shape is different.

Front

ALCD screen

BRemote sensor

When using the supplied remote control, point

it at this sensor.

Continued

12 GB

Rear

AConnector for USB A/Bluetooth

adaptor (.page 49)

You can transfer images wirelessly from a

BLUETOOTH™ compatible mobile phone or

digital camera by connecting a Bluetooth

adaptor (optional: DPPA-BT1).

You can also connect a digital camera, USB

memory, or photo storage compatible with

USB mass storage.

BUSB B connector (.page 51)

Connect a USB cable when you want to use

the photo frame with a computer.

CStand (.page 16)

DDC IN 12 V jack (.page 18)

Insert the plug of the supplied AC adaptor to

this jack, and connect to the wall outlet.

EPower Switch (.page 19)

F“Memory Stick PRO” (Standard/

Duo) slot (.page 21)

GAccess lamp

HStandby indicator

I1 (on/standby) button

JMENU button

Displays the menu.

From the menu, you can operate the same

functions as those of the buttons on the

remote control, such as [Slideshow Settings],

[Rotate], [Add to album] and [Date/time

settings].

KDirection (B/b/v/V) buttons,

Press B/b/v/V to select the menu items. Then

press to enter the selection.

LBACK button

Returns to the previous screen.

MReset switch (.page 58)

The date/time setting, alarm settings, and the

auto power on/off settings return to their

factory default setting. Use a long, thin object,

such as a pin, to push the switch.

NCompactFlash card/Microdrive

slot (.page 21)

OSD memory card/MMC/xD-Picture

Card slot (.page 21)

13 GB

Before operation

PBuzzer

QVIEW MODE button (.page 23)

RAlarm switch (.page 43)

SHoles for hanging unit on the wall

(.page 17)

TSpace for storing the stand

Continued

14 GB

Remote control AVIEW MODE button (.page 23)

BSLIDE-SHOW ( ) button

(.page 23)

CINDEX ( ) button (.page 23)

This button switches from the single view

mode to the index image display.

DSINGLE ( ) button

(.page 23)

EMENU button

FBACK button

G1 (on/standby) button

HCLOCK ( ) button (.page 23)

IZoom in ( )/Zoom out ( ) buttons

(.page 40)

JALBUM ( ) button (.page 32)

KDirection (B/b/v/V) buttons

L (enter) button

MROTATE ( ) button

(.page 40)

15 GB

Basic operations

Basic operations

Preparing the remote

control

The supplied lithium battery (CR2025) has

already been inserted into the remote control.

Pull out the protective sheet before use as

shown in the figure.

Using the remote control

Point the top end of the remote control towards

the remote sensor on the photo frame.

Note

The photo frame may fall if you use the buttons on the

photo frame when it is hanging on the wall. Operate

the photo frame using the remote control.

Replacing the battery of the

remote control

If the remote control stops working, replace the

battery (CR2025 lithium battery) with a new

one.

1Pull out the battery holder.

While pressing in the tab of the battery

holder, pull out the battery holder.

2Remove the old battery from the

battery holder and then insert a new

battery.

Insert the battery so that “+” is facing

upwards.

3Reinsert the battery holder into the

remote control.

Notes

• When the lithium battery becomes weak, the

operating distance of the Remote control may

shorten, or the Remote control may not function

properly. In this case, replace the battery with a

Sony CR2025 lithium battery. Use of another

battery may present a risk of fire or explosion.

Protective sheet

Remote

sensor

WARNING

Battery may explode if mistreated. Do not

recharge, disassemble or dispose of in fire.

Continued

16 GB

• Using a battery other than the specified one may

result in the battery rupturing.

• Dispose of used batteries as specified by the local

authorities.

• Do not leave the remote control in a very hot and

humid place.

• Take care that no foreign objects get inside the

remote control when you, for example, replace the

battery.

• Incorrect use of the battery may cause leaking and

corrosion.

– Do not recharge the battery.

– When the remote control will not be used for a

long period of time, remove the battery from the

remote control to prevent leaking and corrosion.

– Incorrectly inserting, shorting, dismantling, or

heating the battery, or throwing it into a fire

may cause the battery to rupture or leak.

About descriptions in this

manual

The operations described in this manual are

based on remote control operation. When an

operation is performed differently, for example,

with the remote control and the buttons on the

photo frame, it will be explained in a tip.

Setting the stand

1Hold the photo frame tightly and

insert the stand straight into the

screw hole on the rear panel.

2Screw the stand into the screw hole

firmly until the stand stops turning.

Setting to portrait or landscape

orientation

You can set the photo frame to portrait or

landscape orientation by rotating it without

moving the stand.

17 GB

Basic operations

When the photo frame is placed in the portrait

orientation, the image is also automatically

rotated to its proper orientation.

The directions indicated on the direction button

on the rear panel depend on the orientation of

the photo frame.

Notes

• Check whether the stand is stable. If the stand is not

set properly, the photo frame may fall over.

• When the photo frame is placed in the portrait

orientation, the Sony logo doesn't light up.

• The photo frame does not detect and rotate the

orientation of images when [Auto display

orientation] on the (Settings) tab is set to

[OFF].

• A magnet is contained in the storage portion of the

stand. Do not keep anything that is easily affected

by magnetism, such as a cash card or credit card,

near the photo frame.

Tip

It is easier to turn the stand if you wind or wrap a

rubber band tightly around the stand when you

remove the stand from the photo frame.

To display the photo

frame on the wall

You can hang the photo frame on the wall

using the following procedure.

1Prepare screws (not supplied)

suitable for the screw holes on the

rear panel.

2Screw the screws (not supplied) into

the wall.

Be sure the screws (not supplied) protrude

between 2.5 to 3mm (1/8 inch) from the

surface of the wall.

3Hang the photo frame on the wall by

fitting the hole on the rear panel to

the screws on the wall.

Notes

• Use screws suitable for the quality of the material of

the wall. The screws may be damaged, depending

on the type of material used in the wall. Set the

screws in a pillar or stud in the wall.

4mm (3/16 inch)

More than 25mm (1 inch)

4.2mm

(3/16 inch)

8.6mm

(11/32 inch)

Holes for hanging

the unit on the wall

Between

2.5mm to 3mm

(1/8 inch)

Continued

18 GB

• When you want to re-insert the memory card,

remove the photo frame from the wall, then eject

and re-insert the memory card while the photo

frame is placed on a stable surface.

• Store the stand in the place provided when you hang

the photo frame on the wall.

• Connect the plug of the supplied AC adaptor to the

photo frame and set the power switch to ON. And

then connect the AC adaptor to the wall outlet after

hanging the photo frame on the wall.

• We take no responsibility for any accidents or

damage caused by defects of attachment, misuse, or

natural disasters, etc.

Connecting to the AC

power source

1Insert the plug of the AC adaptor

into the DC IN 12 V jack on the rear

of the photo frame.

2Connect the AC adaptor to the wall

outlet.

Notes

• The socket outlet should be as close as possible to

the unit, and easily accessible.

• Do not place the photo frame in an unsteady

location such as on an unsteady table or tilted

surface.

• Connect the AC adaptor to an easily accessible wall

outlet close by. If trouble occurs while using the

adaptor, immediately shut off the power by

disconnecting the plug from the wall outlet.

• Do not short the plug of the AC adaptor with a

metal object. Doing so may cause a malfunction.

• Do not use the AC Adaptor placed in a narrow

space, such as between a wall and furniture.

AC adaptor

To wall outlet

To the DC IN 12 V jack

19 GB

Basic operations

• Insert the plug of the AC adaptor firmly, if the

connection is loose, the photo frame may turn off

when it is moved.

• After use, remove the AC adaptor from the

DC IN 12 V jack of the photo frame, and remove

the AC adaptor from the outlet.

• Even if your photo frame is turned off, AC power

(house current) is still supplied to it while connected

to the wall outlet via the AC adaptor.

• Do not turn the photo frame off or disconnect the

AC adaptor from the photo frame before the

standby indicator turns red. Doing so may damage

the photo frame.

Turning the photo frame

on

When the power switch is set to

off

When the power switch is set to on, the standby

indicator turns green and the Sony logo on the

front panel lights up.

When the power switch is set to

on

Press 1 (on/standby) on the photo frame or

remote control to turn on the power. The

standby indicator turns to green from red. The

Sony logo on the front panel lights up.

Continued

20 GB

Turning off the power

Hold 1 (on/standby) on the photo frame or

remote control until the power turns off. The

standby indicator turns to red from green.

Note

Do not turn the photo frame off or disconnect the AC

adaptor from the photo frame before the standby

indicator turns red. Doing so may damage the photo

frame.

Operations in an initial state

When the photo frame is turned on without a

memory card connected, the initial display

below appears on the screen.

If the photo frame is not operated for 10

seconds, the demo mode is displayed. If any

other button than the power button is pressed,

the screen returns to the initial display.

First, press MENU during the initial display,

and then set the date and time.

Setting the current time

The clock of the photo frame needs to be

adjusted in order to display an accurate time in

the clock and calendar view modes.

1Press MENU.

The menu screen is displayed.

2Press B/b to select the

(Settings) tab.

The settings screen is displayed.

Tip

You can use the B/b button only when a

memory card is inserted in the photo frame, an

external device is connected, or anything other

than the clock and calender settings item

(page 25) are selected.

3Press

v

/V

to select [Date/time

settings] and then press .

The Date/time settings screen is displayed.

4

Adjust the date.

1Press v/V to select [Date] and then

press .

2Press B/b to select year, month, and

day, and then press v/V to select a

value, then press .

5

Adjust the time.

1Press v/V to select [Time] and then

press .

2Press B/b to select hour, minute, and

second, and then press v/V to select a

value, then press .

21 GB

Basic operations

6Select the format of the date.

1Press

v

/V

to select [Date Display Order]

and then press

.

2Press v/V

to select a format and then

press

.

•Y-M-D

•M-D-Y

•D-M-Y

7Set the day to start the week for the

calendar.

You can set the day that appears on the

very left when the calendar is displayed.

1Press v/V to select [First Weekday] and

then press .

2Press v/V to select

[Sunday] or

[Monday]

and then press .

8

Select the time display.

1Press

v

/V to select [12hr/24hr display]

and then press .

2Press

v

/V to select [12 hours] or

[24 hours] and then press .

9Press MENU.

The menu screen is closed.

Inserting a memory card

Insert the memory card firmly into the

corresponding slot with its label side

facing toward you (when you are facing

the back side of the photo frame).

The access lamp flashes when the memory card

is inserted correctly. Reinsert the memory card

after checking the label side of the memory

card if the access lamp does not flash.

For details on the memory cards you can use

with this photo frame, see pages 61 to 63.

Insert the memory card firmly into the

corresponding slot with its label side facing

toward you. The slot order from the top is

“Memory Stick” (“Memory Stick Duo”),

CompactFlash card, SD memory card and xD-

Picture Card.

Access lamp

Continued

22 GB

To remove a memory card

Remove the memory card from its slot in the

opposite direction from which it was inserted.

Notes

• When inserting the memory card, it will only insert

part of the way, so do not try to force it as this could

damage the memory card and/or photo frame.

• This photo frame has a slot that is both a “Memory

Stick” standard and Duo size compatible slot, so

you do not need a “Memory Stick” adaptor.

• The SD memory card/xD-Picture Card dual-

purpose slot automatically detects the card type.

• Before using a memory card, see “About memory

cards” on page 61.

Display priority of images

If a memory card is inserted or an external device is

connected, the images of the inserted memory card or

connected device are displayed automatically.

To manually change the memory card or external

device to be displayed, specify it in (Select

device) menu (page 40).

The photo frame displays the images of the

memory card in the following priorities.

• Memory card t The device connected to the

USB A/Bluetooth connector t internal memory

•If multiple memory cards are inserted when the

photo frame is turned on, the images of the first

memory card you inserted take priority and are

displayed.

•If multiple devices are inserted while the photo

frame is turned off, the priority order for display is

as follows.

“Memory Stick” b CompactFlash card

b SD memory card/xD-Picture Card b internal

memory

However, priority is given to the device which was

displayed on the screen when you turned the photo

frame to OFF.

•If no memory card is inserted and no device is

connected, the images saved in the album in the

internal memory are displayed.

Notes

• Due to one of the characteristics of the internal

memory device, images stored for long time or read

many times may be subject to data error when read

too often.

• The photo frame can display JPEG image files

compatible with DCF format or RAW files taken by

a Sony digital camera. Any other file (such as files

made or edited using a computer or RAW files

taken by digital cameras other than a Sony digital

camera, etc.) may not be displayed.

23 GB

Basic operations

Changing the display

1Press VIEW MODE.

The view mode screen is displayed.

2Select the group you want.

Tip

Select the group you want using B/b after

moving the cursor to the group area using B/b/

v/V, when you operate the photo frame using

the buttons on the photo frame.

3Press B/b/v/V or VIEW MODE to

select the style you want and then

press .

Note

You cannot select a group other than the Clock and

calendar display when there is no image stored in the

internal memory.

Group Explanation

Slideshow

Displays a slideshow display

style.

Clock and

calendar

Displays a clock or calendar

style.

Displays a single image

style.

Index

Displays a thumbnail list

style.

24 GB

Slideshow display

Tips

• If the power is on, and no memory card is inserted,

and no device is connected, the images stored in

internal memory are displayed. If no images are

saved in internal memory, demonstration mode

starts automatically. Demonstration mode ends if a

button other than 1 (on/standby) is pressed.

• For details on the playback order in a slideshow

display, see page 46.

• You can set the interval, effect, listing order, or

color effect when you select the slideshow display.

Refer to “Slideshow Settings” (page 31).

• You can select the single view mode when you

press on the photo frame when the image you

want appears in the slideshow display.

• You can use the VIEW MODE button on the photo

frame.

Group Image Style Explanation

Slideshow

ASingle view Images are displayed on a single screen, one

after another, with the effect selected in the

[Slideshow Settings] menu.

BMulti image view Displays multiple images at the same time.

CClock view Displays images with the present date and time.

DCalendar view Displays images, one after another, while

showing a calendar. The present date and time

is displayed.

ETime Machine Displays images with the shooting date and

time. The present date and time cannot be

displayed.

FRandom view Displays images while randomly switching

between a number of different slideshow styles

and effects.

ABCD

EF

25 GB

Basic operations

Clock and calendar display

Note

You can select only the (Settings) tab when the

Clock and calendar display is displayed.

Tip

You can use the VIEW MODE button on the photo

frame.

Clock1 Clock2 Clock3 Clock4 Clock5

Clock6 Clock7 Clock8 Clock9 Clock10

Clock11

Calendar1 Calendar2 Calendar3

Lunar Calendar

(when you select

[Simplified

Chinese] in

[Language setting])

Arabic Calendar

(when you select

[Arabic] in

[Language setting])

Farsi Calendar

(when you select

[Persian] in

[Language setting])

26 GB

Single view mode

Tips

• If the power is on, and no memory card is inserted,

and no device is connected, the images stored in

internal memory are displayed. If no images are

saved in internal memory, demonstration mode

starts automatically. Demonstration mode ends if a

button other than 1 (on/standby) is pressed.

• You can set the image display mode by pressing

VIEW MODE and pressing B/b to select either

entire image or fit to screen mode. Not all images

are able to use the fit to screen mode.

• You can use the VIEW MODE button on the photo

frame.

Group Image Style Explanation

AEntire image Displays an entire image in the screen. You can

switch the images to be displayed by pressing

B/b.

BFit to screen Displays an image over the whole screen. You

can switch the images to be displayed by

pressing B/b.

CEntire image (with

Exif)

Displays image information, such as the image

number, file name, and shooting date while

displaying the entire image. You can switch the

images to be displayed by pressing B/b.

Refer to “About the information display”

(page 28) for details on the image information.

DFit to screen (with

Exif)

Displays image information, such as the image

number, file name, and shooting date in fit to

screen mode. You can switch the images to be

displayed by pressing B/b.

Refer to “About the information display”

(page 28) for details on the image information.

ABCD

27 GB

Basic operations

Index image display

Tips

• A thumbnail is a small-sized image for index use

that is recorded in the pictures taken by a digital

camera.

• If the power is on, and no memory card is inserted,

and no device is connected, the images in internal

memory are displayed. If no images are saved in

internal memory, demonstration mode starts

automatically. Demonstration mode ends if a button

other than 1 (on/standby) is pressed.

• You can select the single view mode when you

press on the photo frame when the image you

want appears in the index image display.

• You can use the VIEW MODE button on the photo

frame.

Group Image Style Explanation

Index

AIndex 1 Displays a list of large thumbnails. You can

select an image by pressing B/b/v/V.

BIndex 2 Displays a list of thumbnails. You can select an

image by pressing B/b/v/V.

CIndex 3 Displays a list of small thumbnails. You can

select an image by pressing B/b/v/V.

ABC

Continued

28 GB

About the information display

The following information is displayed.

1Display type

– Entire image

– Fit to screen

– Entire image (with Exif)

– Fit to screen (with Exif)

2Image display order/Total number of images

Input indications for an image are displayed.

3Image details

– File format (JPEG(4:4:4), JPEG(4:2:2),

JPEG(4:2:0), BMP, TIFF, RAW)

– Number of pixels (width × height)

– Manufacturer name of image input device

– Model name of image input device

– Shutter speed (e.g.: 1/8)

– Aperture value (e.g.: F2.8)

– Exposure value (e.g.: +0.0EV)

– Rotation information

4Setting information

5Image number (folder-file number)

This is displayed if the image is DCF

compliant.

6Shooting date/time

Icons Meaning

“Memory Stick” input

SD Memory Card input

CompactFlash input

xD-Picture Card input

External Device input

Internal memory input

Icons Meaning

Protect indication

Associated file indication

(Displayed when there is an

associated file such as a motion

file or a miniature e-mail image

file.)

Displays when you have

registered a mark.

29 GB

Advanced operations

Advanced operations

Enjoying a slideshow

You can display images stored in the internal

memory or on a memory card, one after

another, automatically.

The slideshow starts from the last image that

was displayed the previous time, if you set the

power switch to OFF in the standby mode, or

turn the photo frame to ON from the standby

mode.

1Press VIEW MODE.

The view mode screen is displayed.

2Select (slideshow).

Tip

Select (slideshow) using B/b after moving

the cursor to the group area using B/b/v/V

when you operate the photo frame using the

buttons on the photo frame.

3Press B/b/v/V to select the style you

want, then press .

Refer to “Slideshow display” (page 24)

for details on the slideshow styles.

1Press MENU.

The menu is displayed.

2Press B/b to select the

(Settings) tab.

The settings screen is displayed.

3Press v/V to select [Slideshow

Settings] and then press .

The slideshow settings screen is

displayed.

4Press v/V to select the item and

then press .

Refer to the tables on the next page for

details on the setting items.

Notes

• Note the following when you select a slideshow

using the image stored on the memory card.

– Due to one of the characteristics of the memory

card devices, images may be subject to data

error when read too often.

– Do not run a slideshow for a long time with a

small number images. This may cause data

error.

– We recommend you back up images on the

memory card often.

• When the photo frame is, for instance, displaying a

slideshow, changes to the settings of some items are

unavailable. These items are displayed in gray and

cannot be selected.

• The slideshow starts from the first image if you set

the power switch to OFF before entering the

standby mode, if you reset the photo frame.

Changing the settings of the

slideshow

Continued

30 GB

• When the screen is too bright, it may make you feel

nauseous. Be careful that you do not make the

brightness settings too bright when you use the

photo frame.

Tip

You can also use the VIEW MODE button on the

photo frame.

31 GB

Advanced operations

*: Factory default settings

Item Setting Description

Slideshow

Settings

Interval Set a value from 3 sec., 7 sec.*, 20 sec., 1 min., 5 min., 30 min., 1 hour,

3 hours, 12 hours, 24 hours for the interval between images.

Note

An image may not switch at the intervals you set on the menu, depending

on the style of the slideshow.

Effect Center cross Transitions to the next image as though the previous

image is being pushed from the center to the four

corners.

Vert. blinds Transitions to the next image as though blinds are

being lowered vertically.

Horiz. blinds Transitions to the next image as though blinds are

being pulled horizontally.

Fade* Transitions to the next image by fading out the current

image and fading in the next image.

Wipe Transitions to the next image as though the current

image is being wiped off the screen to reveal the next

image.

Random Uses the above five effects randomly.

Shuffle ON Displays images randomly.

OFF* Cancels shuffle playback.

Color effect Color* Displays an image in color.

Sepia Displays an image in a sepia color.

Monochrome Displays an image in monochrome.

Display Mode You can select the view mode for the single image display.

Note

The original image data will not change.

Entire image* Displays an entire image enlarged to proper size. (An

image may be displayed with margins on the top,

bottom, left and right.)

Fit to screen Zooms in at the center of the image enough to fill the

whole screen.

Note

An image may not display with the display size you set

on the menu, depending on the style of the slideshow.

32 GB

Refresh mode

Due to one of the characteristics of the device,

images stored for a long time or read many

times may be subject to data error when read

too often.

This photo frame refreshes the internal memory

automatically to prevent these errors,

depending on the status of the internal memory.

The confirmation screen used for refreshing the

internal memory is displayed automatically

when the refresh is needed.

The refresh starts when you select [OK]. The

Refresh also starts automatically when no

operation is attempted for 30 seconds. If you

select [Cancel], the confirmation screen used

for refreshing the internal memory is displayed

the next time.

Do not turn the photo frame to OFF while the

internal memory is being refreshed. It may

cause a malfunction.

It may take approximately 5 minutes to refresh

the internal memory.

Notes

• We recommend that you perform a backup of your

data periodically to avoid losing it.

• Do not run a slideshow with less than 10 images

continuously if you have set the interval time for the

slideshow to 3 seconds. You may not be able to

protect some images in the internal memory.

Adding images to the

internal memory

You can use the photo frame as a digital album,

saving important images in the internal

memory.

Tip

In [Image file size] of the menu, you can preset

whether to optimize the size of images or save images

as is, without compressing them, when you save them

to the internal memory (page 46).

When [Image file size] is set to [Album], up to

approx. 2,000 images can be added to the album.

When set to [Original], the number of images that can

be saved may vary, depending on the original image

file size.

1Press (Album) when an image

stored on the memory card or the

external device is displayed on the

screen.

Tip

Select [Add to album] using v/V after pressing

the MENU button and then select

(Editing) using B/b.

Single image display

33 GB

Advanced operations

Slideshow display

Index image display

2Press v/V to select [Add this image],

[Selected images] or [Add all

images] and then press .

If you select [Add this image], the image

currently displayed is added to the album.

Go to step 4. (This item cannot be selected

on the slideshow display.)

If you select [Selected images], you can

select the image you want to add from the

image list. Go to step 3.

If you select [Add all images], the image

list is displayed. A check mark is attached

to the check box of all the images. Go to

step 4.

3Specify the image to add from the

image list.

About the image list

During a search: Displays all the images

applicable to the criteria used for the

search.

Other than during a search: Displays all

images in the device displayed on the

screen.

Refer to “Searching for an image

(Filtering)” (page 39).

1Press B/b/v/V to select the image to

add to the album and then press . A

check mark will be attached to the

check box of each selected image.

Repeat this operation to add multiple

images at the same time.

To cancel the selection, select images to

cancel and then press to delete the

check mark in the check box.

2Press MENU.

The confirmation screen used for

selecting a folder is displayed.

4Press v/V to select the folder you

want and press .

The confirmation screen used to decide

whether to add an image or not to the

internal memory is displayed.

Tip

A new folder is created automatically when you

select [New folder].

5Press v/V to select [Yes] and then

press .

The image is saved in the specified folder

in internal memory.

Continued

34 GB

6Press when the confirmation

screen is displayed.

Notes

• Images in the internal memory cannot be added to

the album.

• Do not turn off the power, remove the memory card,

or disconnect the external device while an image is

being added. Doing so may damage the photo frame

or memory card, or damage the data.

Tips

• To perform this operation using the remote control,

press the MENU button on the remote control and

then press v/V to select [Add to album] from

(Editing) and then press .

• You can also use the MENU button on the photo

frame.

• You can change the thumbnail size using [ /] in

the image list.

• Due to one of the characteristics of the internal

memory device, images stored for long time or read

many times may be subject to data error when read

too often. We recommend that you perform a

backup of your data periodically to avoid losing it.

Exporting an image

You can export the images in the internal

memory to a memory card or external device.

1Press MENU when an image stored

on the internal device is displayed

on the screen.

The menu is displayed.

2Press B/b to select the (Editing)

tab.

The screen used for editing is displayed.

3Press v/V to select [Export] and

then press .

The Export menu is displayed.

Single image display

4Press v/V to select [Export this

image], [Selected images] or [Export

all images] and then press .

If you select [Export this image], the

image currently displayed is exported to

the device. Go to step 6. (This item cannot

be selected on the slideshow display.)

If you select [Selected images], you can

select the image you want to export from

the image list. Go to step 5.

If you select [Export all images], the

image list is displayed. A check mark is

attached to the check box of all the

images. Go to step 6.

35 GB

Advanced operations

5Specify the image to export from the

image list.

About the image list

During a search: Displays all the images

applicable to the criteria used for the

search.

Other than during a search: Displays the

image list of the album on the screen.

Refer to “Searching for an image

(Filtering)” (page 39).

1Press B/b/v/V to select the image you

want to export and then press . A

check mark will be attached to the

check box of each selected image.

Repeat this operation to export multiple

images at the same time.

To cancel the selection, select images to

cancel and then press to delete the

check mark in the check box.

2Press MENU.

The screen used for selecting the device

to which to export is displayed.

6Press v/V to select the device to

which to export the image and then

press .

7Press v/V to select the folder you

want to save to and press .

The confirmation screen used to decide

whether to export or not is displayed.

Tip

A new folder is created automatically when you

select [New folder].

8Press v/V to select [Yes] and then

press .

The exporting is finished.

9Press when the confirmation

screen is displayed.

The image is copied to the specified

device.

Note

Do not turn off the power, remove the memory card,

or disconnect the external device during exporting.

Doing so may damage the photo frame or memory

card, or damage the data.

Tips

• You can also use the MENU button on the photo

frame.

• You can enlarge or reduce the image to export when

you select the index image display.

• Any device that is not recognized by the photo

frame is displayed in gray and you cannot select it.

36 GB

Deleting an image

1Press MENU when an image is

displayed on the screen.

The menu is displayed.

2Press B/b to select the (Editing)

tab.

The screen used for editing is displayed.

3Press v/V to select [Delete] and

then press .

4Press v/V to select [Delete this

image], [Selected images] or [Delete

all images] and then press .

If you select [Delete this image], the

image currently displayed is deleted. Go

to step 6. (This item cannot be selected on

the slideshow display.)

If you select [Selected images], you can

select the image you want to delete from

the image list. Go to step 5.

If you select [Delete all images], the

image list is displayed. A check mark is

attached to the check box of all the

images. Go to step 6.

5Specify the image to delete from the

image list.

About the image list

During a search: Displays all the images

applicable to the criteria used for the

search.

Other than during a search: Displays all

images in the device displayed on the

screen.

Refer to “Searching for an image

(Filtering)” (page 39).

1Press B/b/v/V to select the image to

delete and then press . A check mark

will be attached to the check box of

each selected image.

Repeat this operation to delete multiple

images at the same time.

To cancel the selection, select images to

cancel and then press to delete the

check mark in the check box.

2Press MENU.

The delete confirmation screen is

displayed.

6Press v/V to select [Yes] and then

press .

The image is deleted.

7Press when the confirmation

screen is displayed.

To format the internal memory

1Press MENU.

The menu is displayed.

2Press B/b to select the (Settings) tab.

The settings screen is displayed.

3Press v/V to select [Initialize] and then

press .

4Press v/V to select [Format internal

memory] and then press .

The confirmation screen used for

initializing the internal memory is

displayed.

5Press v/V to select [Yes], then press .

Notes

• When the message [Cannot delete a protected

image.] appears on the screen, the image file was set

to Read Only on a computer. In this case, connect

the photo frame to a computer, and delete this file

using the computer.

• The total capacity of the internal memory is not

equal to the remaining capacity, even immediately

after initialization.

• If deletion has started, the deleted image cannot be

recovered even if you stop deletion. Delete images

only after confirming you actually want to delete

them.

37 GB

Advanced operations

Tips

• You can also use the MENU button on the photo

frame.

• You can enlarge or reduce the image when you

select the index image display.

Registering a mark

You can produce a slideshow only with images

which have been selected beforehand and have

been marked. You can easily check for images

with marks using the index image display or

single view mode.

1Press MENU when an image is

displayed on the screen.

The menu is displayed.

2Press B/b to select the (Editing)

tab.

The screen used for editing is displayed.

3Press v/V to select [Marking] and

then press .

4Press v/V to select the mark you

want and then press .

5Press v/V to select [Mark this

image], [Selected images] or [Mark

all images] and then press .

If you select [Mark this image], the image

currently displayed will be marked and

showed in the future. Go to step 7. (This

item cannot be selected on the slideshow

display.)

If you select [Selected images], you can

select the image to which you want to

attach a mark from the image list. Go to

step 6.

If you select [Mark all images], the image

list is displayed. A check mark is attached

Continued

38 GB

to the check box of all the images. Go to

step 7.

6Specify the image to which you want

to attach a mark from the image list.

About the image list

During a search: Displays all the images

applicable to the criteria used for the

search.

Other than during a search: Displays all

images in the device.

Refer to “Searching for an image

(Filtering)” (page 39).

1Press B/b/v/V to select the image to

which to attach and then press . A

check mark will be attached to the

image. Repeat this operation to attach a

mark to multiple images at the same

time.

To cancel the selection, select an

imeges you want to cancel and then

press to remove the check mark

from the check box.

2A mark will be attached to the image

for which a check mark has been placed

in the check box.

If a check mark is removed from the

check box of an image, the mark will be

removed from the image.

7Press v/V to select [Yes] and then

press .

The mark is attached to the selected

image.

To delete the registration of a

mark

Select [Unmark this image] or [Unmark all

images] and then press in step 5. You can

also cancel the selection when you remove the

check mark from the check box.

[Unmark this image]: Removes a mark from

the image currently displayed. (This item

cannot be selected on the slideshow display.)

[Unmark all images]

During a search: Removes a marks from all the

images applicable to the criteria specified in the

search.

Other than during a search: Removes all marks

from all images stored on the device displayed.

Note

A mark is removed when the power is turned off, or if

you remove the memory card or the external device if

you have attached a mark to an image stored on a

memory card or the external device.

Tips

• You can select a mark from among 3 types.

• You can also use the MENU button on the photo

frame.

• You can enlarge or reduce the image when you

select the index image display.

39 GB

Advanced operations

Searching for an image

(Filtering)

You can search for an image which is stored in

internal memory or on a memory card. You can

filter an image using various criteria, such as

the date, the folder in which the image is saved,

the orientation of the image or mark, etc.

1Press MENU when an image is

displayed on the screen.

The menu is displayed.

2Press B/b to select the (Editing)

tab.

The screen used for editing is displayed.

Note

You cannot select the (Editing) tab when

the clock and calendar are displayed.

3Press v/V to select [Search] and

then press .

4Press v/V to select the criteria you

want and then press .

• [Search by date]: Filters by the date.

• [Search by folder]: Filters by the folder.

• [Search by vertical/horizontal]: Filters

by the image orientation.

• [Search by mark]: Filters by the mark.

5Press v/V to select the item you

want and then press .

To cancel the search for an


Press the MENU button when an image is

displayed on the screen and then select [Exit

search (show all photo)].

To change the criteria for a

search

Press the BACK button when an image you

searched for is displayed on the screen.

Notes

• Do not turn off the power, remove the memory card,

or disconnect the external device during a

searching. Doing so may damage the photo frame or

memory card, or damage the data.

• The search is cancelled automatically in the

following cases.

– When you change the playback device

– When you search for an image which is stored

on a memory card or external device and then

remove that memory card or external device

Tip

You can also use the MENU button on the photo

frame.

40 GB

Specifying the playback

device

You can specify the memory card or external

device to be displayed.

1Press MENU.

The menu is displayed.

2Press B/b to select the (Select

device) tab.

The screen used for selecting a device is

displayed.

Tip

Insert the device at this point during the

procedure if the device you want to use cannot

be selected.

3Press v/V to select the device you

want to display and then press .

The images of the selected device are

displayed.

Tips

• You can also use the MENU button on the photo

frame.

• The search is cancelled automatically when you

change the playback device during a search.

Adjusting the image size

and position

You can enlarge or reduce an image in single

view mode.

1To enlarge an image, press

(zoom in) on the remote control. To

reduce an enlarged image, press

(zoom out).

Each press of the button enlarges the

image further. You can enlarge an image

to a maximum of 5 times the original

scale. You can move an enlarged image

up, down, left, and right.

About crop and save

• The screen currently displayed is saved as it

was trimmed after you press B/b/v/V to

move the enlarged image and then press the

MENU button.

• You can select [Save as new image] or

[Overwrite] by pressing the MENU button

when the image is enlarged or reduced. Press

v/V to select the method used to save the

image.

• If you select [Save as new image], the image

is saved as a new image.

• If you select [Overwrite], the image is

overwritten. A confirmation screen is

displayed when you select [Overwrite]. Press

v/V to select [Yes] and then press to

save the image. Press again when the

confirmation screen is displayed after saving

is finished.

Notes

• Enlarging an image may reduce the quality

depending on the image size.

• It is not possible to enlarge an image using the

buttons on the photo frame.

Enlarging/reducing an image

41 GB

Advanced operations

Press ROTATE ( ) on the remote

control.

Each press of the button rotates the image 90

degrees counter-clockwise.

Operate from the menu of the

photo frame

1Press MENU in single display mode.

The menu is displayed.

2Press B/b to select the (Editing)

tab.

The screen used for editing is displayed.

3Press v/V to select [Rotate] and

then press .

The Rotate menu is displayed.

4Press v/V to select the direction to

rotate and then press .

•:

Rotates the image 90 degrees

clockwise.

•:

Rotates the image 90 degrees counter-

clockwise.

5Press v/V to select [OK] and then

press .

Note

An enlarged image cannot be rotated.

Tips

• The information used to rotate the image is retained

even after the power is turned off.

• You can rotate the image of the index image

display.

Rotating an image

42 GB

Changing the settings of

the auto power on/off

function

The timer function to turn the photo frame on/

off automatically can be set. Main power needs

to be switched ON for this function.

1Press MENU.

The menu is displayed.

2Press B/b to select the

(Settings) tab.

The settings screen is displayed.

3Press v/V to select [Auto power ON/

OFF] and press .

The screen used for setting a value for

[Auto power ON/OFF] is displayed.

4Press v/V to select [Simple] or

[Advanced] and then press .

[Simple]: Sets the auto power ON/OFF

function finely in one minute increments.

[Advanced]: Sets the auto power ON/OFF

function according to a day of the week by

one hour units.

5Set the time setting.

[Simple]

1Press v/V to select [Auto power ON/

OFF] and then press .

2Press v/V to select [Enable] and then

press .

3Set the auto on/off timer.

Press v/V to set the time you want.

AM or PM is displayed on the right of

the screen when you select [12 hours]

on the time display setting.

4Set the auto ON/OFF day.

Press v/V to select the day you want to

use this function and then press to

check. Press v/V to select [OK] and

then press .

[Advanced]

1Press B/b/v/V to select the time you

want to use the auto power on/off

function.

You can set this function according to a

day of the week by one hour units.

The color of the selected time zone

changes to blue after you press . The

power supply of the photo frame will be

turned on when the blue time zone time

occurs. The color of the selected time

43 GB

Advanced operations

zone changes to gray, after you select

the blue time zone and then press .

The power supply of the photo frame is

turned off while it is in the gray time

zone.

Tip

The power is turned off automatically at the

time you set for [Auto power OFF] when

you are using the photo frame.

The power is turned on automatically at the

time you set for [Auto power ON] during the

standby mode.

2Press B/b/v/V to select [OK].

Using the alarm function

You can use the photo frame as an alarm clock.

Set to the alarm switch on the rear panel

to ON.

Under condition of main power switch set to

“On”, the alarm sound and alarm mode screen

will appear at the scheduled alarm time.

To turn off the alarm

Set the alarm switch on the rear panel to OFF.

The alarm is stopped although an alarm screen

continues to be displayed.

The normal screen is displayed after you press

any button on the photo frame other than 1

(on/standby).

Setting the alarm

Continued

44 GB

1Press MENU.

The menu is displayed.

2Press B/b to select the

(Settings) tab.

The settings screen is displayed.

3Press v/V to select [Alarm Setting]

and press .

4Press v/V to set the time you want.

Tips

• To set the clock, refer to “Setting the current time”

(page 20).

• Auto power on/off will not function during alarm is

set off.

• When alarm sets off at scheduled time, power will

also turn on regardless of auto off settings. Main

power needs to be set at ON for alarm to operate.

Changing the settings

You can change the following settings.

• Slideshow Settings

• Alarm Setting

• Auto power ON/OFF

• Date/time settings

• General Settings (Listing Order, Sony logo

ON/OFF etc,.)

• Language setting

• Initialize

Note

Only internal memory can be formatted.

1Press MENU.

The menu is displayed.

2Press B/b to select the

(Settings) tab.

The settings screen is displayed.

Setting the time to be alarmed

Setting procedure

45 GB

Advanced operations

3Press v/V to select the item you

want to change and then press .

The setting screen of the selected item is

displayed.

For example, when [Slideshow Settings]

is selected.

4Press v/V to select the item you

want to change and then press .

This enables you to set each of the items

(page 46).

Note

When the photo frame is, for instance,

displaying a slideshow, some settings of some

items cannot be changed. They are displayed in

gray and cannot be selected.

5Press v/V to select a setting value

and then press .

Each time you press v/V (v/V from the

photo frame), the setting value changes. In

the case of a numerical value, press V to

increase the value and press v to decrease

the value.

If you press , the setting is confirmed.

6Press MENU.

The menu closes.

To reset to factory default

settings

1Press MENU and then select (Settings) -

[Initialize] by pressing B/b/v/V.

2Press v/V to select [Reset] and then press

.

All adjusted values, except for the clock

settings, are reset to the default settings.

Tip

You can also use the MENU button on the photo

frame.

Continued

46 GB

Items to set

*: Factory default settings

Item Setting Description

Slideshow

Settings

Refer to “Enjoying a slideshow” (page 29).

Alarm Setting Sets the specific time for an alarm. (.page 43)

Auto power

ON/OFF

Sets the timer function which turns the power supply of the photo frame on or off,

automatically. You can use this function with the following settings. (.page 42)

Simple Power-ON

timer

You can set [Power-ON timer] ([Enable] or [Disable]),

[Auto ON time] and [Auto ON day].

You can set the timer (hour/minute) for the power to

turn on automatically.

Power-OFF

timer

You can set [Power-OFF timer] ([Enable] or

[Disable]), [Auto OFF time] and [Auto OFF day].

You can set the timer (hour/minute) for the power to

turn off automatically.

Advanced* OK Returns to the previous screen after confirming the

operation.

Cancel Returns to the previous screen after cancelling the

operation.

Reset all Deletes all the selected times.

Setup method Advanced* Sets the auto power ON/OFF function according to a

day of the week by one hour units.

Simple Sets the auto power ON/OFF function finely in one

minute increments.

Date/time

settings

Sets the date, time, first day of a week, etc. (.page 20)

General

Settings

Listing Order Sets the display order of images. This setting affects the order in

[Slideshow Settings].

Number Order* Displays images in order of file name.

Shoot. Date Displays images in order of shooting date.

Auto display

orientation

ON*/OFF: You can set the photo frame to automatically detect and rotate

the orientation of images.

LCD backlight Allows you to set the brightness of the backlight of the LCD screen to a

level from 1 to 10*.

Beep ON*/OFF: Sets the beep sound on/off.

Image file size Album* Compresses images and saves them to the internal

memory.

Original Saves images to the internal memory without

compressing them. There is no deterioration, but you

can save fewer images.

Sony logo ON/

OFF

ON*/OFF: You can set whether the photo frame's Sony logo lights or not.

47 GB

Advanced operations

System

Information

Version Displays the version of the firmware of the photo frame.

Internal

memory

Memory

capacity

Indicates the maximum amount of space available in

internal memory in the initial state.

Remaining

capacity

Indicates the amount of free space currently available

in internal memory.

Bluetooth

Address

Displays when the Bluetooth adapter is connected to the photo frame.

Language

setting

Sets the display language on the LCD screen.

Japanese, English*, French, Spanish, German, Italian, Russian, Korean, Simplified Chinese,

Traditional Chinese, Dutch, Portuguese, Arabic, Persian, Hungarian, Polish, Czech, Thai,

Greek, Turkish, Malay, Swedish, Norwegian, Danish, Finnish

Note

Default language setting may vary in some regions.

Initialize Format internal

memory

You can format the internal memory.

Notes

• All the images added to the internal memory will be deleted.

• Do not format the internal memory by using a connection to a PC or

other external device.

Reset Returns all settings to their factory defaults except for the current date and

time setting of the [Date/time settings].

*: Factory default settings

Item Setting Description

48 GB

Operating an external

device connected to the

photo frame

You can connect a mass-storage-complaint

digital camera, a USB memory device, a photo

storage device, or other external device to the

photo frame and display an image directly from

the external device.

Notes

• We cannot guarantee connection with all types of

mass storage devices.

• The playback device will be switched to the

external device if you connect the external device to

the USB A/Bluetooth jack during playback the

internal memory.

1Connect the photo frame to the AC

power source. (.page 18)

2Set the digital camera or external

device to mass storage connection

mode.

The setting and operation method used

before connecting differ depending on the

digital camera or external device. Refer to

the operating instructions supplied with

the digital camera or external device. (If

you are using a Cyber-shot, set “USB

Connect” to [Normal] or [Mass Storage].)

3Turn the photo frame to ON.

(.page 19)

4Connect the digital camera or

external device to the USB A/

Bluetooth connector.

Use the USB cable supplied with the

digital camera or external device to

connect to the photo frame.

5Select the playback device.

(.page 40)

An image on the device is displayed on

the screen.

For details on the slideshow, refer to

page 29. For details on adding images to

the internal memory, refer to page 32.

Notes

• When using a commercially available USB cable,

use an A-Type USB cable that is less than 3 meters

long.

• Do not disconnect the USB cable or turn the photo

frame and external device off while the access lamp

on the external device is flashing. Doing so may

damage the data stored on the external device. Sony

assumes no responsibility for any damage or loss of

data.

• A USB hub or USB device with a built-in USB hub

may not work properly.

• The photo frame cannot use data that has been

encrypted or compressed using, for instance,

fingerprint authentication or a password.

External

memory or

other external

device

49 GB

Using an external device (with Bluetooth)

Using an external device (with Bluetooth)

Connecting to a

Bluetooth device

You can connect a Bluetooth adaptor (optional)

to the USB A/Bluetooth connector of the photo

frame and transfer images from a Bluetooth

compatible mobile phone or other device. The

transferred images are saved in internal

memory.

Note

You cannot send a file to other Bluetooth compatible

devices from the photo frame.

Compatible profiles for Bluetooth

communication

The DPF-D82/D92 supports the following

profiles:

• BIP (Basic Imaging Profile)

Image Push Responder

• OPP (Object Push Profile)

Object Push Server

For the profiles that your Bluetooth device

supports, please refer to its manual.

What is a “Profile”?

A profile consists of the standards that enable

Bluetooth wireless communication. There are

several profiles available, depending on the

purposes and product to be used. To make

Bluetooth communication possible, the devices

used in the communicated should support the

same profile.

Compatible image file formats that can

be displayed

See page 64.

Maximum number of pixels that can be

handled

See page 64.

1Connect the photo frame to the AC

power source. (.page 18)

2Turn the photo frame to ON.

(.page 19)

3Connect the Bluetooth adaptor

(optional) to the USB A/Bluetooth

connector.

is displayed on the upper portion of

the screen when the guide is displayed.

Note

If any device, other than the Bluetooth adaptor,

such as a memory card, camera, PC, or other

USB memory device or a USB cable is

connected to any of the memory card slots, or

the USB A/Bluetooth connector, disconnect it

from the photo frame and then connect the

Bluetooth adaptor.

4Check the Bluetooth address.

You can display the address from [System

Information]. (page 46)

Tip

The address is displayed only when the

Bluetooth adaptor is connected.

5Transfer an image from the

Bluetooth-compliant mobile phone,

or other device to the photo frame.

The image transferred is saved on the

internal memory.

Note

You cannot transfer an image to the memory

card of a digital photo frame.

Continued

50 GB

To select the photo frame from a

Bluetooth-compliant device, select “Sony

DPF-D92 ##,” “Sony DPF-D82 ##.”

(“##” stands for the two figures from the

right of the address displayed in [System

Information].)

When input of Passkey* is required

Input “0000.” You cannot change the

Passkey with the photo frame.

* A Passkey is often referred to as a “pass

code” or “PIN code.”

Notes

• We cannot guarantee that this product works with

all devices enabled with Bluetooth wireless

technology.

• Do not use the DPPA-BT1 outside the area you

purchased it. Depending on the area, the use of this

product may violate the local radio wave

regulations and may be subject to penalty.

• The communication distance of the product may

vary depending on the obstacles between the

product (a human body, metal objects, or a wall)

and the mobile phone or other device.

• The sensitivity of the Bluetooth communication

may be affected under the following conditions:

– When there is an obstacle between the product

and the mobile phone or other product such as a

human body, metal objects, or a wall.

– Where a wireless LAN is established or a

microwave oven is being used near-by, or other

electromagnetic waves are emitted.

• We cannot guarantee that this product works with

all devices enabled with Bluetooth wireless

technology.

• Sony cannot assume any responsibility for any

information leakage that may be caused by the use

of Bluetooth communications.

• Sony cannot accept responsibilities for any failure

to satisfy the protection requirements resulting from

a non-recommended modification or use of the

product.

For customer support information, please refer to

the operating instructions of the photo frame.

P Caution

• Radio waves from a Bluetooth device may

adversely affect the operation of electrical and

medical devices, and could lead to accidents due to

malfunctions. Make sure to turn off the product and

mobile phone and do not use this product in the

following places:

– Inside medical facilities, trains, airplanes, gas

stations or other places that may emit flammable

gas.

– near automatic doors or fire alarms or other

automatically controlled devices.

• Keep this product at least 22 cm away from cardiac

pacemakers. Radio waves from this product may

adversely affect the operation of cardiac

pacemakers.

Bluetooth

compatible mobile

phone

51 GB

Using an external device (with a computer)

Using an external device (with a computer)

Connecting to a

computer

You can connect to a computer to view and

copy images from the internal memory of the

photo frame to the computer, and copy images

from the computer to the photo frame.

To connect a computer to the picture frame,

your computer must satisfy the following

recommended system requirements.

xWindows

Recommended OS: Microsoft Windows Vista

SP1/Windows XP SP3/Windows 2000

Professional SP4

Port: USB port

xMacintosh

Recommended OS: Mac OS X (10.4 or later)

Port: USB port

Notes

• If multiple USB devices are connected to a

computer or if a hub is used, a problem may occur.

In such a case, simplify the connections.

• You cannot operate the photo frame from another

USB device being used simultaneously.

• Do not disconnect the USB cable during data

communication.

• Operation with all computers that satisfy the

recommended system requirements is not

guaranteed.

• The photo frame has been demonstrated as operable

when connected to PC or Sony digital photo printer.

When other devices are connected to the photo

frame, these devices may not recognize the internal

memory of the photo frame.

1Connect the photo frame to the AC

power source. (.page 18)

2Connect the computer and photo

frame with a commercially available

USB cable (optional: VMC-

14UMB2)*.

* This cable may not be available in all

countries.

Note

Use a B-Type USB cable that is less than 3

meters long.

3Turn the photo frame to ON.

(.page 19)

4When the [AutoPlay] window

appears on the computer display,

click [Open folder to view files].

If the [AutoPlay] window does not appear,

click [Computer (My Computer)] in the

System requirements

Connecting to a computer to

exchange images

To USB B

connector

To USB connectorComputer

Continued

52 GB

Start menu, and then open the removable

disc.

5Move the cursor in this window and

right click, and then click [New] -

[Folder].

Name this new folder. In this manual, the

folder name “sony” is used as an example.

6Double click to open this “sony”

folder.

7Open the folder that contains the

image files you want to copy, and

then copy the image files by using

drag-and-drop.

Notes

• When saving images from a computer in the

internal memory, make a folder in the internal

memory and save the images in this folder. If you

do not make a folder, you can only save up to 512

images. In addition, the number of images may be

reduced depending on the file name length or

character type.

• A paticular image may not be displayed in order of

the shooting date on the index image display, etc as

the information on the shooting date may have been

changed or lost when you edited or saved that image

file on a computer.

• When images from the computer are saved in the

internal memory of the photo frame, the image files

are saved without being compressed. As a result,

fewer images may be able to be saved to the internal

memory of the photo frame.

• Image files made or edited on a computer may not

be displayed. Image files set to “Read Only” on a

computer cannot be deleted on the photo frame.

Cancel “Read Only” before saving image files from

a computer on the photo frame.

Disconnect the USB cable or turn the photo

frame to OFF after disconnecting it from your

computer.

1Double-click on the Task Tray.

2Click (USB Mass Storage

Device) t [Stop].

3Click [OK] after checking the drive

you want to remove.

Disconnecting your computer

53 GB

Error messages

Error messages

If an error message appears

If an error occurs, one of the following error messages may be displayed on the LCD screen of the

photo frame. Follow the corresponding solution below to solve the problem.

Error message Meaning/Solutions

No Memory Stick. / No

CompactFlash card. / No SD

Memory Card. / No xD-Picture

Card. / No External Device.

• A memory card is not inserted in a slot. Or, an external

device is not connected to the USB A/Bluetooth connector.

Insert a memory card in the corresponding slot. Or, connect

an external device. (.pages 21, 48)

An incompatible Memory Stick is

inserted. / An incompatible

CompactFlash card is inserted. / An

incompatible SD Memory Card is

inserted. / An incompatible xD-

Picture Card is inserted. / An

incompatible External Device is

inserted.

• An unsupported memory card is inserted. Or, an

unsupported external device is connected to the

USB A/Bluetooth connector. Use a memory card or

external device that is supported by the photo frame.

No images on file. • There is no image file that can be displayed on the screen

of the photo frame on the memory card or the external

device. Use a memory card or on external device

containing image files that can be displayed with the photo

frame.

Cannot delete a protected image. • To delete a protected file, cancel the protection on your

digital camera.

Media is protected. Remove

protection then try again.

• The memory card is write-protected. Slide the write-

protect switch to the enable position. (.page 62)

The Memory Stick is full. / The

CompactFlash card is full. / The SD

Memory Card is full. / The xD-

Picture Card is full. / The External

Device is full.

• No more data can be saved because the memory card, the

internal memory, or the external device is full. Delete

images, or use a memory card or external device with free

space available.

Error reading the Memory Stick. /

Error reading the CompactFlash

card. / Error reading the SD

Memory Card. / Error reading the

xD-Picture Card. / Error reading

the External Device.

• An error has occurred. If this error message is displayed

frequently, check the status of the memory card or external

device with a device other than the photo frame.

• In the case of an external device:

The external device may be write-protected. Cancel the

write-protection setting for the device you are using. The

internal memory of a digital camera may be write-

protected.

Format the internal memory.

Write error in the Memory Stick. /

Write error in the CompactFlash

card. / Write error in the SD

Memory Card. / Write error in the

xD-Picture Card. / Write error in

the External Device.

Continued

54 GB

The Memory Stick is read only. • A “Memory Stick-ROM” is inserted. To save the images,

use the “Memory Stick” recommended.

The Memory Stick is protected. • A protected “Memory Stick” is inserted. To edit and save

the images, use an external device to remove protection.

Media format not supported. • The images cannot be displayed if the image file is not

supported by the photo frame.

Cannot open the image.

No more USB hubs can be

connected.

• Connect the device directly to the photo frame, or use a

device without a built-in USB hub.

Incompatible USB device. Check

device’s USB settings.

• Connect a device with support for mass storage. If the USB

setting of your device is incorrect, set the mass storage

mode in the USB setting.

Error message Meaning/Solutions

55 GB

Troubleshooting

Troubleshooting

If trouble occurs

Before submitting the photo frame for repair, try using the following guidance to solve the problem.

If the problem persists, consult with your Sony dealer or Sony service facilities.

Power supply

Displaying images

If the power is turned on but images are not displayed or the settings of the operation screen cannot

be configured, confirm the following check items.

Symptom Check item Cause/Solutions

The power cannot

be turned on.

• Is the power plug inserted

properly?

cInsert the power plug properly.

Symptom Check item Cause/Solutions

No images are

displayed on the

screen.

• Is a memory card inserted or

an external device connected

properly?

cInsert a memory card or connect an

external device properly. (.pages 21,

49)

• Does the memory card

contain images saved with a

digital camera or other

device?

• Are images stored on the

external device?

cInsert a memory card containing images

or connect an external device containing

images.

cCheck the file formats that can be

displayed. (.page 64)

• Is the file format compatible

with DCF?

cA file that is not compatible with DCF

may not be able to be displayed with the

photo frame, even if it can be displayed

with a computer.

Images are not

played back in the

order of shooting

date.

• Were these images saved

from a computer?

• Were these images edited on

a computer?

cThe information on the shooting date may

be changed or lost when you edit or save

an image file on a computer.

Continued

56 GB

Some images are

not displayed.

• Are the images displayed in

the index view?

cIf the image is displayed in the index view

but cannot be displayed as single image,

the image file may be damaged even

though its thumbnail preview data is fine.

cA file that is not compatible with DCF

may not be able to be displayed with the

photo frame, even if it can be displayed

with a computer.

• Does the mark displayed

below appear in the index

view?

• Were the images created

with an application on a

computer?

cIf the mark shown on the left is displayed,

the image file may not be supported by the

photo frame because, for example, it is a

JPEG file that was created with your

computer. Also, the image file may be

supported, but not contain thumbnail data.

Select the mark and press to change

the screen to the single image display. If

the mark on the left is displayed again, the

image cannot be displayed because the

image file is not supported by the photo

frame.

• Does the mark displayed

below appear in the index

view?

cIf the mark shown on the left is displayed,

the image file is supported by the photo

frame, but the thumbnail data or image

itself cannot be opened. Select the mark

and press . If the mark shown on the

left is displayed again, the image cannot

be displayed.

• Are there more than 9,999

images in the memory card

or external device?

cThe photo frame can play, save, delete, or

otherwise handle up to 9,999 image files.

• Did you rename the file with

a computer or other device?

cIf you named or renamed the file on your

computer and the file name includes

characters other than alphanumeric

characters, the image may not be able to

be displayed on the photo frame.

• Are there eight or more

levels in the folder hierarchy

of the memory card or

external device?

cThe photo frame cannot display images

saved in a folder that is more than eight

levels deep.

Symptom Check item Cause/Solutions

57 GB

Troubleshooting

Saving and deleting images

The file name is

not displayed

properly.

• Did you rename the file with

a computer or other device?

cIf you named or renamed the file on your

computer and the file name includes

characters other than alphanumeric

characters, the file name may not be able

to be displayed properly on the photo

frame. Also, for a file created on a

computer or other device, a maximum of

ten characters from the beginning of the

file name can be displayed.

Note

Only alphanumeric characters can be displayed.

Blank areas appear

at the top and

bottom.

• Is the image extremely tall or

wide?

cIf an image is extremely tall or wide,

blank areas may appear because of the

ratio between the height and width.

Symptom Check item Cause/Solutions

Cannot save an

image.

• Is the memory card write-

protected?

cCancel write-protection and try saving

again.

• Is the write-protect switch of

the memory card in the

[LOCK] position?

cSlide the write-protect switch to the

enable position.

• Is the memory card full? cReplace the memory card with one with

sufficient free space. Or, delete any

unwanted images. (.page 36)

• Is the internal memory full? cDelete any unwanted images.

(.page 36)

• Did you save images from a

computer to the internal

memory without making a

folder in the internal

memory?

cIf you do not make a folder, you can only

save up to 512 images. In addition, the

number of images may be reduced

depending on the file name length or

character type. When you save images in

the internal memory from a computer, be

sure to make a folder in the internal

memory and save the images in this

folder.

Symptom Check item Cause/Solutions

Continued

58 GB

Connecting a digital camera or other external device

Photo frame

Cannot delete an

image.

• Is the memory card write-

protected?

cUse the device you are using to cancel

write-protection and try deleting again.

• Is the write-protect switch of

the memory card in the

[LOCK] position?

cSlide the write-protect switch to the

enable position.

• Are you using a “Memory

Stick-ROM”?

cIt is not possible to delete an image from

or format a “Memory Stick-ROM”.

• Is this image protected? cCheck the image information from the

single view mode. (.page 28)

cAn image with a mark is set to Read

Only. You cannot delete it on the photo

frame.

An image was

deleted

accidentally.

—

cAn image cannot be recovered once it is

deleted.

Symptom Check item Cause/Solutions

The camera is

connected but

nothing is

displayed.

• Is the cable connected

properly?

cConnect the cable properly.

• Is the photo frame turned

on?

cTurn both the photo frame and the camera

to ON.

Nothing happens

even if the USB

cable is

disconnected and

then re-connected.

—

cAn over current error may have occurred

with the photo frame. To recover from the

error, turn the power of the photo frame

off and then back on.

Symptom Check item Cause/Solutions

Nothing happens

even if you operate

the photo frame. —

cPush the reset switch on the back of the

photo frame using a long, thin object such

as a pin, etc. (.page 12)

cSet the power switch to off, and then set it

to on again. (.page 12)

Symptom Check item Cause/Solutions

59 GB

Troubleshooting

Remote control

Symptom Check item Cause/Solutions

Nothing happens

even if you operate

the remote control.

• Is the battery inserted in the

remote control properly?

cReplace the battery. (.page 15)

cInsert a battery. (.page 15)

cInsert a battery in the proper orientation.

(.page 15)

—

cPoint the top end of the remote control

towards the remote sensor on the photo

frame. (.page 15)

cRemove any obstruction between the

remote control and the remote sensor.

60 GB

Additional information

Precautions

• Be careful not to set or drop any heavy

objects on the power cord, or to damage the

power cord in any way. Never operate this

photo frame with a damaged power cord.

• Should any solid object or liquid fall into the

cabinet, unplug the photo frame and have it

checked by qualified personnel before

operating it any further.

• Never disassemble the photo frame.

• To disconnect the power cord, pull it out by

the plug. Never pull the power cord itself.

• When the photo frame is not going to be

used for an extended period of time,

disconnect the power cord from the wall

outlet.

• Do not handle the photo frame roughly.

• To reduce the risk of electrical shock, always

unplug the photo frame from the electrical

outlet before cleaning and servicing the

photo frame.

• Avoid placing the photo frame in a location

subject to:

– vibration

–humidity

– excessive dust

– direct sunlight

– extremely high or low temperatures

• Do not use electrical equipment near the

photo frame. The photo frame will not work

properly in electromagnetic fields.

• Do not place heavy objects on the photo

frame.

On the AC adaptor

• Even if your photo frame is turned off, AC

power (house current) is still supplied to it

while it is connected to the wall outlet via the

AC adaptor.

• Be sure to use the AC adaptor supplied with

the photo frame. Do not use other AC

adaptors, as this may cause a malfunction.

• Do not use the supplied AC adaptor for other

devices.

• Do not use an electrical transformer (travel

converter), as this may cause overheating or

a malfunction.

• In case the cord of the AC adaptor is

damaged, do not use it any longer, as this

may be dangerous.

On moisture condensation

If the photo frame is brought directly from a

cold location to a warm location or placed in an

extremely warm or humid room, moisture may

condense inside the unit. In such cases the

photo frame will probably not work properly

and may even develop a fault if you persist in

using it. If moisture condensation occurs,

unplug the AC adaptor of the photo frame and

do not use the photo frame for at least one hour.

On transport

When you transport the photo frame, remove

the memory card, external devices, AC adaptor,

and connected cables from the photo frame and

put the photo frame and its peripherals in the

original box with the protective packaging.

If you no longer have the original box and

packing parts, use similar packing material so

that the photo frame will not be damaged while

being transported.

Clean the photo frame with a soft dry cloth, or a

soft cloth lightly moistened with a mild

detergent solution. Do not use any type of

solvent, such as alcohol or benzine, which may

damage the finish.

Safety

Installation

Cleaning

61 GB

Additional information

TV programs, films, video tapes, portraits of

other people, or other materials may be

copyrighted. Unauthorized use of such

materials may infringe the provisions of the

copyright law.

About memory cards

Types of “Memory Stick” that

the photo frame can use

With the photo frame, you can use the

following types of “Memory Stick”*1:

*1 The photo frame supports FAT32. The photo

frame has been demonstrated as operable with a

“Memory Stick” with a capacity of 16 GB or less

manufactured by Sony Corporation. However, we

do not guarantee the operations of all the “Memory

Stick” media.

*2 The photo frame is equipped with a slot compatible

with both standard-size and Duo-size media.

Without a “Memory Stick Duo” adaptor, you can

use both a standard-size “Memory Stick” and the

compact-size “Memory Stick Duo”.

*3 When using a “Memory Stick Micro” with the

photo frame, always insert it into an M2 adaptor.

*4 “M2” is an abbreviation for “Memory Stick

Micro”. In this section, “M2” is used to describe a

“Memory Stick Micro”.

*5 Data reading/recording that requires “MagicGate”

copyright protection cannot be performed.

“MagicGate” is the general name of a copyright

Restrictions on duplication

“Memory Stick”

Type of “Memory

Stick”

Displaying Deleting/

Saving

“Memory Stick”*2

(Not compatible

with

“MagicGate”)

OK OK

“Memory Stick”*2

(Compatible with

“MagicGate”)

OK*5 OK*5

“MagicGate

Memory Stick”*2 OK*5 OK*5

“Memory Stick

PRO”*2 OK*5 OK*5

“Memory Stick

PRO-HG”*2 OK*5*6 OK*5*6

“Memory Stick

Micro”*3 (“M2”*4)OK*5 OK*5

Continued

62 GB

protection technology developed by Sony using

authentication and encryption.

*6 The photo frame does not support 8 bit parallel

data transfer.

Notes on use

• For the latest information on the “Memory

Stick” types that the photo frame supports,

see the “Memory Stick” compatibility

information on the Sony web site:

http://www.memorystick.com/en/support/

support.html

(Select the area where you use your photo

frame, and then select “Digital Photo Frame”

from each area page.)

• Do not insert more than one “Memory Stick”

at the same time, or this may cause trouble

with the photo frame.

• If you use a “Memory Stick Micro” with the

photo frame, the “Memory Stick Micro”

needs to be inserted into an “M2” adaptor.

• If you insert a “Memory Stick Micro” into

the photo frame without an “M2” adaptor,

you may be unable to remove the “Memory

Stick Micro”.

• If you insert a “Memory Stick Micro” into an

“M2”adaptor, and insert the “M2” adaptor

into a “Memory Stick Duo” adaptor, the

photo frame may not operate properly.

• When you format a “Memory Stick”, use the

format function of your digital camera. If

you format a “Memory Stick” with your

computer, images may not be displayed

properly.

• When you format a “Memory Stick”, all the

data including protected image files will be

erased. To avoid erasing important data by

accident, make sure to check the contents of

the “Memory Stick” before formatting.

• You cannot record, edit, or delete data if you

slide the write-protect switch to LOCK.

• Do not attach any other material than the

supplied label on the labelling position.

When you attach the supplied label, be sure

to attach it to the labelling position. Be

careful that the label does not stick out.

The SD memory card slot of the photo frame

allows you to use the following:

• SD memory card*1

• miniSD card, microSD card

(An adaptor is necessary.)*2

• SDHC memory card*3

• MMC standard memory card*4

We do not guarantee proper operations for all

types of SD memory cards and MMC standard

memory cards.

*1 The photo frame has been demonstrated as

operable with an SD memory card with a capacity

of 2 GB or smaller.

*2 Some commercially available card adaptors have

projected terminals on the back. This type of

adaptor may not work properly with the photo

frame.

*3 The photo frame has been demonstrated as

operable with an SDHC memory card with a

capacity of 32 GB or less.

*4 The photo frame has been demonstrated as

operable with an MMC standard memory card with

a capacity of 2 GB or less.

Notes on use

Data reading/recording that requires copyright

protection cannot be performed.

With the xD-Picture Card slot of the photo

frame, you can use an xD-Picture Card*5. Not

all the memory card operations are supported

and we do not guarantee proper operations for

all types of xD-Picture Card.

*5 The photo frame has been demonstrated as

operable with an xD-Picture Card with a

capacity of 2 GB or less.

The CompactFlash card slot of the photo frame

allows you to use the following:

SD memory card

xD-Picture Card

CompactFlash card

63 GB

Additional information

• CompactFlash Memory Card (Type I/

Type II) and CF+Card (Type I/Type II)-

compatible CompactFlash Card*6

• Microdrive

You can also use the Smart Media card by

using a commercially available CompactFlash

card adaptor*7.

However, we do not guarantee proper

operations for all types of CompactFlash cards.

*6 Use a CompactFlash card with a power

specification of 3.3V or 3.3V/5V. You cannot use

a type for 3V or 5V only. Do not insert other types

of CompactFlash card into the photo frame’s

insertion slot. The photo frame may be damaged.

The photo frame has been demonstrated as

operable with a CompactFlash with a capacity of

32 GB or smaller.

*7 When using a commercially available

CompactFlash card adaptor, refer to the operating

instructions of the adaptor you use for how to

install the card and adaptor. When using a

CompactFlash card adaptor, a write-protected card

may not work properly.

• When using a card, make sure to check the

correct insertion direction of the card and the

correct insertion slot.

• When inserting the memory card, it will only

insert part of the way, so do not try to force

it, as this could damage the memory card

and/or photo frame.

• Do not remove a card or turn off the photo

frame while the photo frame is reading or

writing data, or the access indicator is

flashing. Otherwise, data may be rendered

unreadable or be erased.

• We recommend that you save a backup of

important data.

• Data processed with the computer may not

be displayed with the photo frame.

• When you carry or store a card, put it in the

case supplied with it.

• Do not touch the terminal of a card with your

hand or a metal object.

• Do not strike, bend or drop a card.

• Do not disassemble or modify a card.

• Do not expose a card to water.

• Do not use or store a card under the

following conditions:

– Locations beyond the required operational

conditions including locations such as the

hot interior of a car parked in the sun and/

or in the summer, the outdoors exposed to

direct sunlight, or a place near a heater.

– Humid locations or locations with

corrosive substances present

– Locations subject to static electricity or

electrical noise

Notes on using a memory card

64 GB

Specifications

x Photo frame

LCD screen

LCD panel:

DPF-D92: 9.0 inches, TFT active

matrix

DPF-D82: 8.0 inches, TFT active

matrix

Total number of dots:

DPF-D92: 1,152,000

(800 × 3(RGB) × 640) dots

DPF-D82: 1,080,000

(1024 × 3(RGB) × 600) dots

Display aspect ratio

15:9

Effective display area

DPF-D92: 8.6 inches

DPF-D82: 7.6 inches

LCD backlight life

DPF-D92: 20,000 hours

DPF-D82: 30,000 hours

(before brightness of the backlight is

reduced to half)

Input/Output connectors

USB connector (TypeB, Hi-Speed USB)

USB A/Bluetooth connector

(TypeA, Hi-Speed USB)

Slots

“Memory Stick PRO” slot

SD memory card/MMC/

xD-Picture Card slot

CompactFlash card/Microdrive slot

Compatible image file formats

JPEG: DCF 2.0 compatible, Exif 2.21

compatible, JFIF*1

TIFF: Exif 2.21 compatible

BMP: 1, 4, 8, 16, 24, 32 bit Windows

format

RAW (preview only*2): SRF, SR2, ARW

(2.0 or lower version)

(Some image file formats are not

compatible.)

Maximum number of pixels that can be

displayed

8,000 (H) × 6,000 (V) pixels

File system

FAT12/16/32,

sector size of 2,048 bytes or smaller

Image file name

DCF format, 256 characters, within 8th

hierarchy

Maximum number of files that can be

handled

9,999 files for a memory card/an external

device

Internal memory capacity*3

DPF-D92/D82: 1 GB

(Approx. 2,000 images*4 can be saved.)

When measuring media capacity, 1 GB

equals 1 billion bytes, a portion of

which is used for data management.

Power requirements

DC IN jack, DC 12V

Power consumption

Operating temperature

5 °C to 35 °C (41 °F to 95 °F)

Dimensions

[With the stand spread out]

DPF-D92:

Approx. 276 × 189 × 144.1 mm

(10 7/8 × 7 1/2 × 5 3/4 inches)

(width/height/depth)

DPF-D82:

Approx. 243 × 162 × 126.6 mm

(9 5/8 × 6 1/2 × 5 inches)

[When the photo frame is hanging on the

wall]

Model in operation mode including the

AC adaptor

DPF-D92/

D82

at the maximum load 11.6W

normal mode* 5.5W

* The definition of the normal mode is a status

which allows the performance of a slideshow using

images stored in the internal memory with the

default settings without inserting a memory card or

connecting an external device.

65 GB

Additional information

DPF-D92:

Approx. 276 × 189 × 39.5 mm

(10 7/8 × 7 1/2 × 1 9/16 inches)

(width/height/depth)

DPF-D82:

Approx. 243 × 162 × 39.5 mm

(9 5/8 × 6 1/2 × 1 9/16 inches)

Mass

DPF-D92: Approx. 810 g (1 lb 12 5/8 oz)

DPF-D82: Approx. 720 g (1 lb 9 3/8 oz)

(excluding the AC adaptor)

Included accessories

See “Checking included items” on

page 11.

x AC adaptor

The following are common specifications of

DPF-D92/D82.

Power requirements

- 100 V to 240 V, 50/60 Hz

0.48 A

Rated output voltage

12 V 1.2 A

Dimensions

Approx. 34 × 72 × 69 mm

(1 3/8 × 2 7/8 × 2 3/4 inches)

(width/height/depth)

(excluding the protruding parts)

Mass

Approx. 110 g (4 oz)

See the label of AC adaptor for more details.

Design and specifications are subject to change

without notice.

*1: Baseline JPEG with 4:4:4, 4:2:2, or 4:2:0 format

*2: RAW files are displayed as thumbnail preview.

*3: The capacity is calculated as 1 MB is equivalent to

1 000 000 bytes. The actual capacity is reduced as

files for management and applications are

included. Approximately 900 MB on DPF-D92/

D82 can be used for your actual operation.

*4: Approximate number is shown when the images

taken by 2 000 000 pixels equivalent camera are

saved. The value may vary depending on the

shooting condition.

Customer support home page

The latest support information is available at the

following home page address:

http://www.sony.net/

66 GB

Index

A

AC adaptor 18

Accessories 11

Adding to the internal

memory 32

Alarm 43, 46

Associated file 28

Auto power ON/OFF 46

Auto power on/off 42

B

Bluetooth 49

C

Calendar 21

Changing the settings 44

Cleaning 60

Connecting

Computer 51

External device 48

Connecting to the AC power

source 18

D

Date/time settings 20, 46

DC IN 8.4 V 18

Deleting an image 36

Display priority 22

E

Error messages 53

Exporting an image 34

F

Features 9

Format internal memory 47

G

General Settings 46

I

Image file size 46

Index image display 27

Initialize 47

L

Language setting 47

M

Mass storage compatible

devices 48

Memory cards 61

“Memory Stick” 61

CompactFlash card 62

Notes on use 63

SD memory card 62

xD-Picture Card 62

P

Placing in portrait or

landscape orientation 16

Playback device 40

Precautions 60

R

Remote control 15

Replacing the battery of the

remote control 15

Reset 47

Rotating an image 41

S

Searching for an image 39

Setting the stand 16

Single view mode 26

Slideshow display 24

Slideshow Settings 31

Color effect 31

Display Mode 31

Effect 31

Interval 31

Shuffle 31

Specifications 64

System Information 47

System requirements

Macintosh 51

Windows 51

T

Troubleshooting 55

U

USB cable 48

W

Write-protect switch 62

Z

Zooming an image in/out 40

Sony Corporation Printed in China

Printed using VOC (Volatile

Organic Compound)-free

vegetable oil based ink.
