DVP-FX700

Operating Instructions

Portable

CD/DVD Player

3-088-314-12(1)

WARNING

To prevent fire or shock hazard, do not expose the unit to rain or moisture.

To avoid electrical shock, do not open the cabinet. Refer servicing to qualified personnel only.

CAUTION

The use of optical instruments with this product will increase eye hazard. As the laser beam used in this

CD/DVD player is harmful to eyes, do not attempt to disassemble the cabinet.

Refer servicing to qualified personnel only.

This CD/DVD player is CLASS 1 LASER PRODUCT.

This symbol is intended to alert the user to the presence of uninsulated

“dangerous voltage” within the product’s enclosure that may be of suffi-

cient magnitude to constitute a risk of electric shock to persons.

This symbol is intended to alert the user to the presence of important

operating and maintenance (servicing) instructions in the literature

accompanying the appliance.

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

ATTENTION: POUR ÉVITER LES CHOCS ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE

DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.

Welcome!

Thank you for purchasing this CD/DVD Player. Before operating this player, please read this manual thorough-

ly and retain it for future reference.

This label is located on the bottom of the unit.

Important Safety Instructions

Introductions

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in

accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as

radiators, heat registers, stoves, or other appara-

tus (including amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized

or grounding-type plug. A polarized plug has two

blades with one wider than the other. A grounding

type plug has two blades and a third grounding

prong. The wide blade or the third prong are pro-

vided for your safety. If the provided plug does

not fit into your outlet, consult an electrician for

replacement of the obsolete outlet.

10. Protect the power cord from being walked on or

pinched particularly at plugs, convenience recep-

tacles, and the point where they exit from the

apparatus.

11. Only use attachments/accessories specified by

the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or

table specified by the manufacturer, or sold with

the apparatus. When a cart is used, use caution

when moving the cart/apparatus combination to

avoid injury from tip-over.

13. Unplug this apparatus during lightning storms or

when unused for long periods of time.

14. Refer all servicing to qualified service personnel.

Servicing is required when the apparatus has

been damaged in any way, such as power-supply

cord or plug is damaged, liquid has been spilled

or objects have fallen into the apparatus, the

apparatus has been exposed to rain or moisture,

does not operate normally, or has been dropped.

Precautions

For customers in the U.S.A

Owner’s Record

The model and serial numbers are located on the bottom of the unit. Record the serial number in the space provided below.

Refer to them whenever you call upon your Sony dealer regarding this product.

Model No. DVP-FX700

Serial No.______________

For Customers in Canada

If this product is not working properly, please call 1-877-602-2008 for

Peace of Mind Warranty Replacement service.

For other product related questions please contact our Customer

Information Service Centre at 1-877-899-7669 or write to us at: Customer Information Service 115 Gordon Baker Road,

Toronto, Ontario, M2H 3R6

CAUTION

You are cautioned that any change or modifications not expressly approved in this manual could void your authority to oper-

ate this equipment.

NOTE

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the

FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installa-

tion. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance

with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interfer-

ence will not occur in a particular installation. If this equipment does cause harmful interference to radio or television recep-

tion, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference

by one or more of the following measures:

– Reorient or relocate the receiving antenna.

– Increase the separation between the equipment and receiver.

– Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

– Consult the dealer or an experienced radio/TV technician for help.

Introductions

Precautions (continued)

• The power requirements and power consumption of this

are indicated on the AC power adaptor. Check that the

unit’s operating voltage is identical with your total power

supply.

On safety

• Caution – The use of optical instruments with this product

will increase eye hazard.

• To prevent fire or shock hazard, do not place objects filled

with liquids, such as vases, on the apparatus.

• Should any solid object or liquid fall into the cabinet,

unplug the player and have it checked by qualified per-

sonnel before operating it any further.

• Do not put any foreign objects in the DC IN 9.8V (external

power input) jack.

On temperature increases

• Heat may build up while charging or during extented use.

This is not a malfunction.

• If the surrounding temperature is very high the protective

function will turn off the player automatically.

Leave the player cool location for about 30 minutes before

using it again.

• Use only the supplied AC power adaptor. Do not use any

other AC power adaptor. It may cause a malfunction.

• If the AC power adaptor causes interference to radio

reception, move it away from the radio.

• Do not touch the AC power adaptor with wet hands.

• The player is not disconnected from the AC power source

(mains) as long as it is connected to the wall outlet, even

if the player itself has been turned off.

• If you are not going to use the player for a long time, be

sure to disconnect the player from the wall outlet. To dis-

connect the AC power cord (mains lead), grasp the plug

itself; never pull the cord.

• Should the AC power cord need to be changed, have it

done at a qualified service shop only.

• Use a commercially available AC plug adaptor, if neces-

sary, depending on the design of the wall outlet.

Polarity of the plug

Wall outlet

AC plug adaptor

AC-FX100

Precautions (continued)

On the rechargeable battery

• Charge the rechargeable battery before you start using it.

• Do not allow dust to come into contact with the battery

terminals of the player and rechargeable battery.

• Do not short the terminals.

• Do not open the terminal covers of the player.

• Keep the battery dry.

•

Use only the rechargeable battery(NP-FX100) supplied

with this player(DVP-FX700). Other rechargeable batteries

supplied with other models cannot be used with this player.

• Do not disassemble.

• Do not incinerate.

• Dispose of use battery promptly.

To dispose of the rechargeable battery

• Certain countries may regulate disposal of the battery

used to power this product. Please consult with your local

authority.

To store the rechargeable battery

The rechargeable battery is consumed gradually as time

elapses even if is not used. In order to prevent the battery

from deteriorating, store the rechargeable battery as fol-

lows:

• Remove the rechargeable battery from the player after

use.

• Use up the battery completely on the player before stor-

ing it.

• Keep the rechargeable battery in a cool location to pre-

vent it from deteriorating.

• Charge and use the rechargeable battery at least once in

6 months.

On charging the rechargeable battery

• Heat may build up the rechargeable battery while

charging. This is not a malfunction.

• When the battery life of a fully charged rechargeable bat-

tery becomes about half the normal life, you may need to

replace the battery with a new one.

• Disconnect the rechargeable battery from the player as

soon as the battery has been charged. Leaving it con-

nected may result in reduced battery performance.

Introductions

Precautions (continued)

On handing the player

• Keep the lens on the player clean and do not touch it. If

you do so, the lens may be damaged and the player will

not operate properly.

• Place the player in a location with adequate ventilation to

prevent heat build-up in the player.

• Do not put any heavy object on top of the player. The

player and the discs may be damaged.

• Do not leave the player in a location near heat sources, or

in a place subject to direct sunlight, excessive dust or

sand, moisture, rain, mechanical shock, on an unlevel sur-

face, or in a car with its windows closed.

• Do not wrap the player in a cloth or blanket during use as

it may cause malfunction or serious accidents.

• If the player causes interface to radio or television recep-

tion, turn off the player or move it away from the radio or

television.

• Keep the player and discs away from equipment with

strong magnets, such as microwave ovens, or lager loud-

speakers.

• If the player is brought directly from a cold to warm loca-

tion, or is placed in a very damp place, moisture may con-

dense on the lenses of the player. Should this occur, the

player may not operate properly. In this case, remove the

disc and leave the player for about half an hour until the

moisture evaporates.

• Discs with non-standard shapes (e.g, heart, square, star)

cannot be player on this player. Do not use discs.

• While operating, do not move,shake or otherwise allow

any shock to the player. It may cause a malfunction.

• Use this player in a stable, horizontal position where it is

not subject to vibration.

• Do not touch the disc if it is still spinning when you open

the lid.

• When you move the player, take out any, you don’t, the

disc may be damaged.

It’s too

warm!

On handing the LCD screen

• The LCD is manufactured using high precision technology.

You may , however, see tiny black points and/or bright

points(red,blue,green) that continuously appear on the

LCD. This is a normal result of the manufacturing process

and does not indicate a malfunction.

• Do not scratch the LCD or exert pressure on it. This could

cause a malfunction.

• Using the player in low temperature conditions may pro-

duce a residual image on the screen. This is not a mal-

function. When the player returns to normal temperature,

the screen returns to normal.

• A residual image may appear on the screen if the same

image is displayed for a lengthy period of time. The resid-

ual image disappears in a while.

If you are going to leave from the player for a long time,

turn off power.

• The screen becomes warm during operation. This is nor-

mal and does not indicate a malfunction.

On headphones

Preventing hearing damaged

Avoid using headphones at high volume. Hearing experts

advise against continuous, loud and extended play. If you

experience a ringing in your ears, reduce volume or discon-

tinue use.

Caring for others

Keep the volume at a moderate level. This will allow you to

hear outside sounds and to be considerate to the people

around you.

On adjusting volume

Do not turn up the volume while listening to a section with

very low level inputs or no audio signals. If you do, the

speakers may be damaged when a peak level section is

played.

Road safety

Do not use the monitor unit and headphones while

driving,cycling, or operating any motorized vehicle. It may

create a traffic hazard and is illegal in some areas. It can

also be potentially dangerous to play your headsets at high

volume while walking, especially at pedestrian crossings.

You should exercise extreme caution or discontinue use in

potentially hazardous situations.

• Do not install the monitor display where viewable by the

driver.

• Some states restrict the use of monitors and televisions in

vehicles. Where use is permitted, the units should not be

installed or operated so as to be viewable by the driver.

Precautions (continued)

Introductions

Precautions (continued)

On transportation

• When you transport this player, use the original carton

box and packing materials.

• Before you move this player, make sure to remove any

discs from the player.

On cleaning

Clean the cabinet, panel, and controls with a soft cloth

slightly moistened with a mild detergent solution. Do not

use any type of abrasive pad, scouring powder or solvent

such as alcohol or benzine.

On cleaning discs

Do not use a commercially available cleaning disc. It may

cause a malfunction.

If you have any questions or problems concerning your

player, please consult your nearest Sony dealer.

RECYCLING LITHIUM-ION BATTERIES

Lithium-Ion batteries are recyclable.You

con help preserve our environment by

returning your used rechargeable

batteries to the collection and recycling

location nearest you.

For more information regarding recycling of rechargeable bat-

teries, call to 1-800-822-8837, or visit http://www.rbrc.org/

Caution:

Do not handle damaged or leaking Lithium-Ion batteries.

Never expose the battery pack to temperature above 140

(60

C) such as in a car parked in the sun or under direct

sunlight.

RECYCLAGE DES ACCUMULATEURS

AUX IONS DE LITHIUM

Les accumulateurs aux de lithium sont

recyclables. Vous pouvez contribuer à

préserver l’environnement en rapportant les

piles usées dans un point de collection et

recyclage le plus proche.

Pour plus d’informations sur le recyclage des accumulateurs,

téléphonez le numéro gratuit 1-800-822-8837 (Etats-Units et

Canada uniquement), ou visitez http://www.rbrc.org/

Avertissement:

Ne pas utiliser des accumulateurs aux ions de lithium qui

sont endommagées ou qui fuient.

IMPORTANT NOTICE

Caution: This player is capable of holding a still video

image or on-screen display image on your television

screen indefinitely. If you leave the still video image or

on-screen display image displayed on your TV for an

extended period of time you risk permanent damage to

your television screen. Plasma Display Panel televisions

and projection televisions are especially susceptible to

this.

On handling discs

• To keep the disc clean, handle the disc by its edge. Do not

touch the surface.

• Do not stick paper or tape on the disc.

On storing discs

• Do not expose the disc to direct sunlight or heat sources

such as air ducts, or leave it in a car parked in direct sun-

light as the temperature may rise considerably inside the

car.

• After playing, store the disc in its case.

On cleaning discs

• Fingerprints or dust on a disc may cause deteriorated

image of sound quality. Leave the disc clean.

• Wipe the disc with a soft cloth from the center out.

• If the disc is very dirty, first wipe it with a damp cloth, then

wipe it again with a dry cloth.

• Do not use solvents such as benzine, thinner, commer-

cially, available cleaners, or anti-static spray intended for

vinyl LPs.

Notes about the Discs

About This Manual

• Instructions in this manual describe the controls on the

remote.You can also use the controls on the player if they

have the same or similar names as those on the remote.

• Some DVD video discs have functions that may not be

explained in this owner’s manual. Therefore, some instruc-

tions may differ from this owner’s manual, and there may

be extra instructions. In this case, follow the instructions dis-

played on the LCD screen or package.

• “ ”may appear on the LCD screen during operation.

This icon means the function explained in this owner’s

manual is not available on that specific DVD video disc.

Introductions

Table of Contents

Introductions

❏WARNING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

❏Welcome! . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

❏Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . .3

❏Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-9

❏About This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

❏Notes on Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

❏Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

❏Identification of Controls . . . . . . . . . . . . . . . . . . . . . . . . .12-17

Main Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12-13

Display Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15-17

❏Power Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18-20

AC Adaptor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Battery Pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19-21

Basic Operations

❏Playing a Disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21-26

Basic Playback

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21-23

Stopping Play

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

Resume Play

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

Screen Saver

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

Pause

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

Skipping Chapters and Tracks . . . . . . . . . . . . . . . . . . . . . . .25

To Scan at Fast Forward or Fast Reverse Playback . . . . . . .26

Playing in Slow-Motion

. . . . . . . . . . . . . . . . . . . . . . . . . . . .26

Operation Using GUI Menu Icons

❏General Information about GUI Menu Icons . . . . . . . . . . . . .27

❏Detailed Description of each GUI Menu Icon . . . . . . . . . .28-29

Advanced Operations

❏Using a Title Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

❏Using a DVD Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

❏Changing Subtitle Language . . . . . . . . . . . . . . . . . . . . . . . . .31

❏Changing Audio Soundtrack Language . . . . . . . . . . . . . . . . .32

❏Viewing from another Angle . . . . . . . . . . . . . . . . . . . . . . . . .33

❏Product a 3D Surround Effect . . . . . . . . . . . . . . . . . . . . . . . .34

❏Repeat Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35-36

❏Random Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37

❏Program Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38-39

❏Operation

with Audio CD and MP3 disc

. . . . . . . . . . . . . .40-42

❏

Operation with JPEG disc

. . . . . . . . . . . . . . . . . . . . . . . . .43-44

Initial Settings

❏Selection of Initial Settings . . . . . . . . . . . . . . . . . . . . . . . . . .45

❏Selecting Disc Language . . . . . . . . . . . . . . . . . . . . . . . . . . .46

❏Selecting Rating Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47

❏Selecting Area Code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48

❏Selecting TV Aspect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49

❏Selecting Menu Language . . . . . . . . . . . . . . . . . . . . . . . . . .50

❏Selecting Digital Audio Output . . . . . . . . . . . . . . . . . . . . .51-52

❏Others . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53

❏Table of Languages and their Code Numbers . . . . . . . . . . . .54

❏Area Code List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55-56

Connections

❏Connecting to a TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57

❏

Connecting to an amplifier equipped with a Dolby Digital decoder

. .58

❏Connecting to an amplifier equipped with a Dolby Pro Logic

Surround . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59

❏Connecting to an amplifier equipped with a DTS decoder . . .60

❏

Connecting to an amplifier equipped with a digital audio input . .

Reference

❏Disc Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62

❏Copyright Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63

❏Before Calling Service Personnel . . . . . . . . . . . . . . . . . . .64-66

❏Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67-68

Identification of Controls

Main Unit

BRIGHT

COLOR

LCD MODE

TOP MENU MENU

RETURN

PUSH

ENTER

DISPLAY

OPEN

1. LCD screen

2. Speaker

3. COLOR control slide (page 21)

4. BRIGHT control slide (page 21)

5. LCD MODE (page 22)

NORMAL → FULL → ZOOM → OFF

6. TOP MENU (page 30)

displays the title menu.

7. MENU (page 30)

displays menu programs.

8. B/V/v/b button, ENTER button

9. RETURN button

10. DISPLAY (page 27-29)

operation mode display.

11. OPEN button (page 21)

Push this button to open the Disc lid.

12. Disc Lid

NOTE:

Place a disc with the playback side down on the

spindle, and push gently on the center of the disc so

it goes into position.

Introductions

Identification of Controls (continued)

Main Unit

POWER /HOLD

VOLUME PHONES AUDIO VIDEO

DC IN 9.8V

S-VIDEO OUT

LINE SELECT

IN OUT

12 3456

7891011

12 13

1. Display Window

See details on next page.

POWER and HOLD switch

To turn off the power, you need to press the

POWER switch for at least one second. This is to

prevent the player from being accidentally turned

off.

HOLD switch

• The hold function locks the buttons on the DVD player so that

they will not work if accidentally touched.

• To enable, slide the HOLD switch on the left side of the DVD

player to the HOLD position.

• To disable, slide the switch back to its original position.

3. PREV/NEXT buttons (page 25)

4. PLAY button (page 21)

5. PAUSE button (page 25)

6. STOP button

7. VOLUME dial (page 21)

8. PHONES connector

9. AUDIO IN/OUT/ OPTICAL OUT connector

(page 57)

10. VIDEO IN/OUT connector (page 57)

11. LINE SELECT switch (page 57-61)

12. S-VIDEO OUT connector (page 57)

13. DC IN 9.8V connector (page 18)

Connect the AC adaptor.

Identification of Controls (continued)

Display Window

Disc type

Battery remaining indicator

Repeat mode

When playing back a DVD: Playing time of the

current title or current Title/ Chapter number

(Press PLAY button while playing disc. Title/

Chapter number appears for 2 seconds.)

When playing back a VIDEO CD with Playback

Control(PBC): Playing time of the current track.

When playing back a CD, or VIDEO CD(without

PBC): Playing time of the current track and cur-

rent track number.

When playing back a DATA CD(JPEG):

Current track number.

Playing status

NOTES:

• “MP3”and “CD”are displayed in the Display

Window when a Data-Disc is played.

• Data-Discs are discs that contain MP3 or

JPEG files.

Disc type Indication

1. DVD : DVD

2. CD (CDDA) : CD

3. VCD : VCD

4. Data-Disc : CD and MP3

Introductions

Identification of Controls (continued)

Inserting batteries into the remote

You can control the player using the supplied remote. Insert two size AA(R6) batteries (supplied) by matching

the and ends on the batteries to the markings inside the compartment. When using the remote, point at

the remote sensor on the player.

Insert the end first

NOTES:

• Do not leave the remote in an extremely hot or humid place.

• Do not drop any foreign object into the remote casing, particularly when replacing the batteries.

• Do not expose the remote sensor to direct light from the sun or lighting apparatus. Doing so may cause a malfunction.

• If you do not use the remote for an extended period of time, remove the batteries to avoid possible damage from battery

leakage and corrosion.

Identification of Controls (continued)

Remote Control

AUDIO

PREV NEXT

CLEAR

PLAY PAUSE STOP

SET UP

SCAN

TOP MENU

DISPLAY RETURN

SLOW

REPEAT

RANDOM

A-B

PROGRAM

ANGLE

123

654

DVD PORTABLE

ENTER

1. AUDIO button (page 32)

2. ANGLE button (page 33)

3. REPEAT button (page 35)

4. PROGRAM button (page 38-39)

5. RANDOM button (page 37)

6. A-B button (page 36)

7. PREV/NEXT button (page 25)

8. SCAN/SLOW button (page 26)

9. CLEAR button

10. PLAY button

11. * TOP MENU button (page 30)

12. DISPLAY button (page 27-29)

13. POWER button

14. NUMBER buttons

15. SET UP button (page 45)

Introductions

Identification of Controls (continued)

16. STOP button

17. MENU button

Use the MENU button to display the menu

screen included on a DVD disc.

To operate a menu screen, follow the

instructions in “Using a DVD Menu”(page 30).

18. PAUSE button

19. B/V/v/b button, ENTER button

(up, down, left, right) for use in highlighting a

selection on a GUI menu screen, TOP MENU

and MENU screen.

20. RETURN button

* TOP MENU button:

Use the TOP MENU button to display the title screen

included on DVD video discs. To operate a menu

screen, follow the instructions in “Using a Title Menu”

(page 30)

Power Connections

AC power Adaptor

VOLUME PHONES AUDIO VIDEO

DC IN 9.8V

S-VIDEO OUT

LINE SELECT

IN OUT

To DC IN 9.8V

AC power adaptor

(supplied)

AC Power cord

To AC outlet

Follow steps 1 to 3 to connect.

When disconnecting, reverse the order.

NOTES:

•When you disconnect the AC power cord, be sure to stop playback.

•Disconnecting the AC power cord during playback may cause a malfunction.

Power Connections (continued)

Introductions

Battery Pack

You can use the NP-FX700 rechargeable battery

pack (supplied) to enjoy the player when an AC out-

let is not available.

•Charge the battery pack before using it for the first

time.

AAttaching the battery pack (supplied)

1.Match the hooks of the battery pack into the holes

on the bottom of the player.

2.Press and slide the battery pack until the hooks

click.

NOTES:

•Do not detach the battery pack during playback.

•Be careful not to drop the battery pack.

ADetaching the battery pack

1.Press RELEASE switch

2.Slide the battery pack until the hooks click.

RELEASE Switch

Hooks

NOTE:

If you use the battery pack separately to the main

unit, use the safeguard to maintain the horizontal.

Power Connections (continued)

ACharging the battery pack

1. Attach the battery pack to the player.

2. Connect the AC power adaptor to the player and

the plug into an AC outlet.

3. During recharging, charge indicator is red.

If recharging is complete, charge indicator

changes to green color.

Confirm the battery charge on the unit’s display

window

•If using the AC adaptor, battery display does not

appear.

ARecharging and play times

* When Brightness control is set to “–”.

NOTES:

•Recharging times shown above depend on operating

conditions.

•As for the POWER ON, you cannot charge the

battery.

•Charge the battery at a temperature of +5°C (+41°F)

to +35°C (+95°F).

The charging time may vary, depending on the

surrounding temperature.

•If the surrounding temperature is higher than approxi-

mately 86°F (30°C), the player’s temperature will rise

and the battery may not begin to charge as soon as

you turn off the player. This is not a malfunction.

•The battery will begin to automatically charge as soon

as the surrounding temperature or the temperature of

the player drops.

VOLUME PHONES AUDIO VIDEO

DC IN 9.8V

S-VIDEO OUT

LINE SELECT

IN OUT

Battery Pack

Charge indicator

Player

AC adaptor cord insert

jack (DC IN 9.8V)

Recharging Play time

with player LCD On LCD Off

Approx. Approx. Approx.

2.6 hours 3 hours* 5 hours

Full Low Recharge

Playing a Disc

Basic Operation

- Prepare the power supply.

1.Open the outer cover and slide the POWER

switch to the left to turn unit on.

Power indicator lights and then the indicator will disap-

pear after 5 seconds.

Press OPEN to open the disc lid and insert a disc

with the side you want to play label up. Close the

disc lid by hand.

•If the disc is placed in upside down (and it is a single-

sided disc), “NO DISC”or “DISC ERROR”appears on

the LCD screen.

•If you insert an audio CD, the CD indicator lights up in

the display window.

•After playing back all of the chapters in the title, the

DVD player automatically stops and returns to the

menu screen.

3.Press PLAY to start play.

4.Adjust the volume.

NOTES:

•Place a disc with the playback side down on the

spindle, and push gently on the center of the disc

so it goes into position.

•

Confirm LCD MODE position by pressing LCD

MODE button.

•If no picture on the LCD, check that the LINE

SELECT switch is set to LINE Out mode.

Adjusting color intensity

•Use the COLOR control slide –/+ to adjust the color

shade.

– ; black and white

+ ; color

•Power consumption increases with the level of color.

Adjusting the brightness

Use the BRIGHT control slide –/+ to adjust the

brightness.

– ; dark

+ ; light

Basic Playback

DVD VCD CD

BRIGHT

COLOR

LCD MODE

Playing a Disc (continued)

AChanging the size of the picture

Use the LCD MODE button to change the picture mode. The mode is shown on the unit’s display window as

follows.

AThe picture mode and size

The picture shown on the LCD depends on the display mode and the size recorded on the disc.

NOTES:

•If you are not using the LCD on this unit, select OFF to conserve power.

•The LCD is turned off if you close the unit.

•Horizontal lines may appear in the picture when the mode is switched to ZOOM, but this is not an indication

of a malfunction.

Mode

Software

Wide-screen

Regular (4:3)

Regular (4:3),

Letterbox

NORMAL

Full screen

Screen with

blackbands on

the right and

left

The picture is

surrounded by

a black frame.

FULL

Full screen

The normal

mode screen is

horizontally

enlarged.

The normal

mode screen is

horizontally

enlarged.

ZOOM

Top and bottom

edges are cut

off.

Top and bottom

edges of the

full mode

screen are cut

off.

Full screen

OFF

DVD VCD CD

Playing a Disc (continued)

Basic Operation

AWhen a menu screen appears on the LCD

screen.

In case of interactive DVDs with control, a menu

screen appears on the LCD screen.

Press B/V/v/b and press ENTER, or press the

numeric button(s), to select the desired item.

Play of the selected item now begins.

•

For further information, also refer to the jacket or

case of the disc you are playing.

After operation

When the unit is not in use, remove the disc and press

POWER to turn off the DVD player.

NOTES:

•

When “”appears on the LCD screen while a

button is pressed, it means that this function is not

available on the disc you are playing.

•

Depending on the DVD disc, some operations may

be different or restricted. Refer to the jacket or

case of the disc you are playing.

Example of interactive

DVD On-Screen Menu

Video CD

This contains recordings of pictures and sound

whose quality is on a par with that of video tape.

This player also supports Video CDs with playback

control (Version 2.0).

What is playback control (PBC)?

If a Video CD has “playback control”written on its

disc or jacket, it means that particular scenes or

information can be selected for viewing interactive-

ly with the LCD monitor using the menu screen.

DVD VCD CD

Playing a Disc (continued)

AStopping Play

Press STOP during playback.

AResume Play

When play is stopped, the unit records the point

where STOP was pressed (RESUME function).

Press PLAY and play will resume from this point.

NOTES:

•

This operation works only with discs for which the

elapsed playing time appears in the display window dur-

ing stop.

•

When you press the STOP button, RESUME x(stop)

appears on the screen and the player enters the resume

mode. The current play information will appear on the

front panel display. Note that this information varies

according to the type of disc being played. For DATA

CDs, no information may be displayed depending upon

the condition of the disc. For Video CDs, the information

varies if PBC is ON or OFF.

•

The Resume function may not be available on some DVD

discs or Video CDs (version 2.0).

AScreen Saver

The screen saver is useful to prevent your display

from becoming damaged.

The screen saver picture appears when you leave

the DVD player in stop mode for about 15 minutes.

Automatic power off function

After the Screen Saver has been engaged

for about 15

minutes, the DVD player will automati-

cally turn itself off.

DVD VCD CD

Playing a Disc (continued)

Basic Operation

APause

Press PAUSE during playback.

•

DVD/Video CD

The player will be placed in the still picture mode.

•

The player will be placed in the pause mode.

ASkipping Chapters and Tracks

Skipping forward

Press NEXT during playback.

A chapter (DVD) or a track (CD/Video CD) is skipped

each time the button is pressed.

Skipping back

Press PREV during playback.

•

When the button is pressed once midway through

a chapter/track, the player returns to the start of

that chapter/track. When it is pressed again, a

chapter/track is skipped each time the button is

pressed.

For your reference:

•

When /is pressed during menu play of

video CDs equipped with PBC (Version 2.0), a

menu screen may sometimes be recalled.

DVD VCD CD

Playing a Disc (continued)

ATo Scan at Fast Forward or Fast Reverse

Playback

Press SCAN/SLOW or button during

playback.

[LCD screen]

•

The speed of advance (reverse) is relatively slow

at first. When the button is pressed again, the

speed becomes faster. (Each time the button is

pressed, the speed increases up to 4 steps (DVD)

or 3 steps (Video CD).)

•

The speed will be retained even after the button is

released.

To return to normal playback, press PLAY.

NOTE:

The DVD player does not play back sound during the

high speed reverse and forward playback of DVD

video discs.

However, the DVD player plays back sound during

fast forward or fast reverse playback of audio CDs.

Playing in Slow-Motion (DVD and Video CD only)

Press SCAN/SLOW or during Pause mode.

[LCD screen]

•

The speed of slow-motion is slow at first. When the

button is pressed again, the speed becomes

faster. (Each time the button is pressed, the speed

increase up to 4 steps.)

•

The speed will be retained even after the button is

released.

To return to normal playback, press PLAY.

NOTES:

•

The sound is muted during slow-motion playback.

•

Subtitles do not appear on the screen during slow

motion playback.

•

The reverse slow does not work with Audio and

Video CD.

DVD VCD CD

X2 FFX2 GG4 4

This unit features GUI*Menu Icons showing disc

information (title/chapter/track number, elapsed play-

ing time, audio/subtitle language, angle, and sound)

and player information (repeat play, play mode,

marker, etc.). Some icons only show the indicated

information. Other icons allow the settings to be

changed.

* GUI: Graphic User Interface

Common procedures

1.Press DISPLAY during playback.

Title function can be accessed from the stop

mode.

2.Press V/v to select the desired item.

The current selected item is indicated by a yellow

frame on its GUI menu icons.

3.Press B/bto select the desired setting.

•

When numbers are displayed (e.g. title number), the

numeric buttons can also be used for setting instead of

B/b.

•

For some functions, the setting will be registered

immediately; for others, ENTER must be pressed.

To clear the GUI Menu Icons, press DISPLAY

again.

Examples of GUI Menu Icons.

(The screens may differ depending on the disc contents.)

General information about GUI Menu lcons

Operation Using GUI Menu Icons

AUDIO

PREV NEXT

CLEAR

PLAY PAUSE STOP

SET UP

SCAN

TOP MENU

DISPLAY RETURN

SLOW

REPEAT

RANDOM

A-B

PROGRAM

ANGLE

123

654

DVD PORTABLE

ENTER

2, 3

1 /3

1 /12

0:20:09

1 ENG

5.1 CH

OFF

1 /1

NORM.

1 /3

NORM.

0:20:09

(DVD GUI) (Video CD GUI) (Video CD (Version 2.0))

PBC

NORM.

0:20:09

DVD VCD CD

Detailed Description of each GUI Menu Icon

You can view information about a disc and its operational status on the LCD screen.

Shows the current title number and total number of titles,

and skips to the desired title number.

Shows the current chapter number and total number of

chapters, and skips to the desired chapter number.

Shows the elapsed playing time, and

searches the point by the elapsed time directly.

Shows the current audio soundtrack language,

encoding method, and channel number, and

changes the setting.

Shows the current subtitles language, and

changes the setting.

Shows the current angle number and total number of

angles, and changes the angle number.

Shows the current sound mode, and

changes the setting.

1 /3

1 /12

0:20:09

1 ENG

5.1 CH

OFF

1 /1

NORM.

FUNCTION

(Press B/bto select desired item)

B/b, or Numeric

ENTER

B/b, or Numeric

ENTER

NEXT, PREV

Numeric

ENTER

B/b, AUDIO

B/b

B/b, ANGLE

B/b

Press DISPLAY during

playback. [LCD screen]

DVD GUI

SELECTION

METHOD

DVD

Detailed Description of each GUI Menu Icon (continued)

Operation Using GUI Menu Icons

B/b, or Numeric

ENTER

NEXT, PREV

B/b, AUDIO

B/b

Shows the current track number, total number of tracks and

PBC On mode, and skip to the desired track number.

Shows the elapsed playing time (Display only)

Shows the audio channel, and

changes the audio channel.

Shows the current sound mode, and

changes the setting.

1 /3

NORM.

0:20:09

FUNCTION

(Press B/bto select desired item) SELECTION

METHOD

NOTE:

Some DVD discs may not provide all of the above GUI menu icons.

Press DISPLAY during

playback. [LCD screen]

Video CD GUI

VCD

Using a Title/DVD Menu

Using a Title Menu

Some movie discs may contain two or more titles. If

the disc has a title menu recorded on it, the TOP

MENU button can be used to select the movie title.

(The details of operation differ depending on the disc

used.)

•Selecting a title may not be possible on

certain DVD discs.

1.Press TOP MENU.

A list of the titles on the disc is displayed.

Press TOP MENU again to resume play from the

scene when TOP MENU was first pressed.

•Resume play may not be possible on certain discs.

2.Press B/V/v/b and press ENTER or PLAY, or

press the numeric button(s), to select desired

title.

The selected title now starts playing.

Using a DVD Menu

Some DVDs have unique menu structures called

DVD menus. For example, DVDs programmed with

complex contents provide guide menus, and those

recorded with various languages provide menus for

audio and subtitle language. Although the DVD

menu’s contents and operation differ from disc to

disc, the following explains the basic operation when

this feature is used.

1.Press MENU during play.

The DVD menu available on the disc is now dis-

played.

Pressing MENU again resumes play from the

scene when MENU was first pressed.

•Resume play may not be possible on certain discs.

2.Press B/V/v/b and press ENTER, or press the

numeric button(s), to select desired item.

The selected item is now executed.

DVD

Changing Subtitle Language

Advanced Operations

It is possible to change the subtitle language to a dif-

ferent language from the one selected at the initial

settings. (See page 45 for further info.)

This operation works only with discs on which multi-

ple subtitle languages are recorded.

NOTES:

•

In some cases, the subtitle language is not

changed to the selected one immediately.

•

When a disc supporting the closed caption is

played, the subtitle and the closed caption may

overlap each other on the LCD screen. In this

case, turn the subtitle off.

•

When the desired language is not selected even

after pressing the button several times, it means

that the language is not available on the disc.

•

When the power is turned on or the disc is

removed, subtitles appear in the language select-

ed at the initial settings. If this language is not

recorded on the disc, the disc’s priority language

appears.

1.Press DISPLAY during playback.

2.Press V/v to select Subtitle item.

3.Press B/brepeatedly until the desired Subtitle

is selected.

Each time this button is pressed, the LCD screen

display changes.

TOP MENU

DISPLAY RETURN

DVD PORTABLE

ENTER

2, 3

OFF

1 ENG

DVD

Changing Audio Soundtrack Language

It is possible to change the audio soundtrack lan-

guage (or encoding method, channel number) to a

different language from the one selected at the initial

settings in case of DVD disc. (See page 45 for fur-

ther info.) This operation works only with discs on

which multiple audio soundtrack languages are

recorded. And it is possible to change the audio

channel in case of Video CD.

NOTES:

•

When the desired language is not selected even

after pressing the button several times, it means

that the language is not available on the disc.

•

When the power is turned on or the disc is

removed, the language heard is the one selected

at the initial settings. If this language is not record-

ed on the disc, only the available language on the

disc will be heard.

•

Some discs may not respond to Audio feature.

• DVD

1.Press AUDIO during play.

Number of the audio soundtrack language being

played back.

2.Press AUDIO repeatedly until the desired lan-

guage (or encoding method, channel number)

is selected.

• Audio and Video CD

1.Press AUDIO during play.

2.Press AUDIO repeatedly until the desired

sound is selected.

AUDIO

PREV NEXT

CLEAR SET UP

SCAN SLOW

REPEAT

RANDOM

A-B

PROGRAM

ANGLE

123

654

1, 2

1 ENG

5.1 CH

2 FRE

5.1 CH

LEFT

DVD VCD CD

Viewing from another Angle

Some DVDs may contain scenes which have been

shot simultaneously from a number of different

angles. For these discs, the same scene can be

viewed from each of these different angles using the

ANGLE button. (The recorded angles differ depend-

ing on the disc used.)

1.Press ANGLE during playback.

Number of angle

being played back.

2.Press ANGLE repeatedly until the desired

angle is selected.

For your reference

•

The ANGLE indicator will blink on the LCD screen

at scenes recorded at different angles to indicate

that angle switching is possible.

•

The angle number can be programmed beforehand;

the angle will be switched to the selected number

when the ANGLE indicator blinks.

NOTE:

This function only works for discs having scenes

recorded at different angles.

Advanced Operations

1 /3 2 /3 3 /3

1, 2

AUDIO

PREV NEXT

CLEAR

PLAY PAUSE STOP

SET UP

SCAN

TOP MENU

DISPLAY RETURN

SLOW

REPEAT

RANDOM

A-B

PROGRAM

ANGLE

123

654

ENTER

1 /1

1 /2

DVD

Product a 3D Surround Effect

This unit can produce a 3D Surround effect, using 3D

Surround Sound technology, which simulates multi-

channel audio playback from two conventional stereo

speakers instead of the five or more speakers nor-

mally required to listen to multi-channel audio from a

home theater. This feature works with DVD discs

encoded with Dolby Pro Logic and Dolby Digital

audio tracks.

NOTES:

•

This 3D Surround effect may not be available on

some DVD discs, such as those recorded with a

mono audio soundtrack.

•

Turn off the TV surround sound and other surround

effects when using this 3D surround effect.

•For best 3D Surround effect using only two speak-

ers, it is recommended that the two speakers be

positioned approximately 2 m to 2.5 m apart, and

that the listening position be 2 m to 2.5 m away

from the speakers.

3D Surround Effect works only when you

connect a PHONES connector or an AUDIO

IN/OUT.

1.Press DISPLAY during playback.

2.Press V/vto select SOUND item.

3.Press B/brepeatedly until the desired sound is

selected.

Each time this button is pressed, the LCD screen

display changes.

PREV NEXT

CLEAR

PLAY PAUSE STOP

SET UP

SCAN

TOP MENU

DISPLAY RETURN

SLOW

ENTER

2, 3

NORM.

SUR

DVD

Repeat Play

Advanced Operations

Repeating viewing (listening)

Press REPEAT during playback.

Each time this button is pressed, the LCD screen

changes as shown below and the disc will repeat a

chapter or title (DVD) or a track (Audio and Video CD).

• DVD

Cancel repeat mode

(normal play)

Repeat of chapter

being played

Repeat of title

being played

•Audio and Video CD

Cancel repeat mode

(normal play)

Repeat of track

being played

Repeat of entire

disc contents

To enjoy program repeat play (Video CD)

If REPEAT is pressed during program play, repeat

play is operated as below.

Cancel repeat mode

(Program play)

Repeat of the current

programmed track

Repeat of all

programs

To return to normal play

Press REPEAT several times until “OFF”is dis-

played.

OFF

TITLE

CHAPT

OFF

ALL

TRACK

OFF

ALL

TRACK

REPEAT

AUDIO

PREV NEXT

CLEAR

PLAY PAUSE STOP

SET UP

SCAN SLOW

REPEAT

RANDOM

A-B

PROGRAM

ANGLE

123

654

DVD VCD CD

Repeat Play (continued)

Repeating sections between two specific points

(A-B repeat)

NOTES:

•Repeat play works only with discs for which the

elapsed playing time appears in the display win-

dow during playback.

•Repeat play may not work correctly with some

DVDs and some Video CDs.

•A-B repeat play works only within a title DVD or a

track Video CD.

•Some subtitles recorded around point A or B may

fail to appear (DVD).

1.Press A-B during playback at the point where

repeat play is to start (A).

•You can select “OFF”at this step by pressing

CLEAR.

2.Press A-B during playback at the point where

repeat play is to be concluded (B).

Repeat play of the selection between points A and

B starts.

To return to normal playback

Press A-B once “OFF”is displayed.

1, 2

AUDIO

PREV NEXT

CLEAR

PLAY PAUSE STOP

SET UP

SCAN

TOP MENU

SLOW

REPEAT

RANDOM

A-B

PROGRAM

ANGLE

123

654

ENTER

A *

A–B

A B

A–B

OFF

DVD VCD CD

Random Play

Advanced Operations

Random play (Karaoke DVD, Video CD (PBC OFF))

NOTE:

This function only works with karaoke DVD and

Video CD. Random does not work with DVD movie

discs.

You can playback titles or tracks in random order.

(Random playback)

The DVD player automatically selects the titles on a

DVD video karaoke disc only and plays them back

randomly.

Press RANDOM during playback.

The DVD player automatically starts random play-

back and the RANDOM indicator in the display

window appears for 2 seconds.

RANDOM indicator also appears in the display

window when new track starts to play.

To return to normal play.

Press RANDOM again.

NOTES:

•

Random playback may not be possible on certain

discs.

•If you press the or button during random

playback, the DVD player goes to another track

randomly and starts playback.

DVD VCD

1, 2

AUDIO

PREV NEXT

CLEAR

PLAY PAUSE STOP

SET UP

SCAN

TOP MENU

DISPLAY RETURN

SLOW

REPEAT

RANDOM

A-B

PROGRAM

ANGLE

123

654

ENTER

Program Play

Programmed Playback with Audio

CD and MP3 disc

The Program function enables you to store your

favorite tracks from any disc in the player memory.

Program can contain 30 tracks.

1.Press PROGRAM during playback or in the

stop mode to enter the Program Edit mode.

The “”mark will appear to the right of the word

Program on the right side of the menu screen.

NOTE:

Press PROGRAM to exit the Program Edit mode;

the “”mark will disappear.

2.Select a track by using V/v, then press ENTER

to place the selected track on the Program list.

3.Repeat step 2 to place additional tracks on the

Program list.

Audio CD menu MP3 menu

4.Press b.

The programmed track you selected last is highlighted on

the program list.

5.Press V/vto select the track you want to start

playing.

Press TOP MENU to move to the next page.

Press MENU to move to the previous page.

6.Press

(PLAY) to start.

Playback begins in the order in which you programmed

the tracks and “PROG.”appears on the menu screen.

Playback stops after all of the tracks on the Program list

have played once.

7.To resume normal playback from programmed

playback, press PROGRAM and select a track

of CD (or MP3) list, then press ENTER.

“PROG.”indicator disappears on the menu screen and

starts normal playback.

Clear All

Program

0:02:43

TRACK 2

TRACK 3

TRACK 4

TRACK 5

TRACK 1

CD Player

TRACK 1

TRACK 2

TRACK 3

TRACK 4

TRACK 5

TRACK 6

TRACK 7

TRACK 8

ST NORM.

MP3

Clear All

Program

TRACK 1/104

0:04:25

TRACK 1.mp3

TRACK 2.mp3

TRACK 3.mp3

TRACK 4.mp3

TRACK 5.mp3

TRACK 2.mp3

TRACK 3.mp3

TRACK 4.mp3

TRACK 5.mp3

TRACK 1.mp3

TRACK 6.mp3

TRACK 7.mp3

TRACK 8.mp3

MP3

Advanced Operations

Program Play (continued)

Programmed Playback with Video CD

NOTE:

On a Video CD with PBC, you must set PBC to Off on

the setup menu to use the Program function.

1.Insert Video CD and close the tray.

2.Press PROGRAM while playback is stopped.

The VCD Program menu will appear.

NOTE:

Press RETURN or PROGRAM to exit the Program

menu.

3.Follow steps 2-6 of “Programmed Playback

with Audio CD and MP3 disc”on page 38.

4.To resume normal playback from programmed

playback, press PROGRAM during playback.

“No”indicator disappears in the display window.

Repeat Programmed Tracks



To repeat the track currently playing, press REPEAT.

The Repeat icon and “TRACK”appears on the menu

screen.

To repeat all tracks on the program list, press

REPEAT a second time.

The Repeat icon and “ALL”appears on the menu screen.



To cancel Repeat mode, press REPEAT a third time.

The Repeat icon and “OFF”appears on the menu screen.

Erasing a Track from Program List

1.Press PROGRAM during playback (Audio CD and

MP3 disc only) or in the stop mode to enter the

Program Edit mode.

The “”mark will appear.

2.Press bto move to the Program list.

3.Use V/vto select the track that you wish to erase

from the Program list.

4.Press CLEAR.

The track will be erased from the Program list.

Erasing the Complete Program List

1.Follow steps 1-2 of “Erasing a Track from Program

List”as above.

2.Use V/vto select “Clear All”, then press ENTER.

The complete Program for the disc will be erased.

The programs are also cleared when the disc is removed.

Clear All

VCD Player Program

TRACK 1

TRACK 2

TRACK 3

VCD CD

Operation with Audio CD and MP3 disc

The DVD Player can play MP3 formatted recordings

on CD-ROM, CD-R or CD-RW discs.

Before playing MP3 recordings, read the “Notes on

MP3 Recordings”on page 41.

1.Insert a disc and close the tray.

Audio CD; Audio CD menu appears on the LCD

screen go to step 4.

MP3 disc; The MP3-JPEG choice menu appears

on the LCD screen. Go to step 2

2.Press V/vto select the MP3 then press ENTER.

The MP3 menu appears on the LCD screen.

Press RETURN to move to the MP3-JPEG choice

menu.

3. Press V/vto select a folder, and ENTER.

A list of files in the folder appears.

4.Press V/vto select a track then press

(PLAY) or ENTER.

Playback starts.

During playback, the current track’s elapsed play-

ing time will appear on the display window and

menu.

Playback will stop at the end of the disc.

Press TOP MENU to move to the next page.

Press MENU to move to the previous page.

Audio CD menu MP3 menu

zz Hint

If you are in a file list and want to return to the Folder

list, use the

V/v

to highlight and press ENTER to

return to the previous menu screen.

5.To stop playback at any other time, press

x(STOP).

MP3

JPEG

Folder1

Folder2

Folder3

Folder4

Folder5

Folder6

Folder7

Folder8

Clear All

MP3

TRACK

0:00:00

Program

Clear All

CD Player

0:00:00

TRACK 1

TRACK 2

TRACK 3

TRACK 4

TRACK 5

TRACK 6

TRACK 7

TRACK 8

Program

ST NORM.

MP3

Clear All

TRACK 1/104

0:00:00

TRACK 1.mp3

TRACK 2.mp3

TRACK 3.mp3

TRACK 4.mp3

TRACK 5.mp3

TRACK 6.mp3

TRACK 7.mp3

TRACK 8.mp3

Program

MP3

Operation with Audio CD and MP3 disc (continued)

Advanced Operations

Notes on MP3 Recordings

About MP3

An MP3 file is audio data compressed by using

the MPEG1 audio layer-3 file-coding scheme. We

call files that have the “.mp3”file extension “MP3

files”.

The player can not read an MP3 file that has a file

extension other than “.mp3”.

MP3 disc compatibility with this player is

limited as follows:

1. Sampling Frequency / only at 44.1 kHz

2. Bit rate / within 32-320 kbps CBR (Constant Bit

Rate)

3. CD-R physical format should be “ISO 9660”

4. Discs created in the Packet Write format cannot

be played.

5. A single session disc requires MP3 files in the

first track. If there is no MP3 file in the 1st track, it

cannot playback MP3 files. If you wish to play-

back MP3 files, format all the data in the disc or

use a new one.

6. File names should be named using 8 letters or

less and must incorporate “.mp3”extension

e.g. “********.MP3”.

7. Do not use special letters such as “/ : * ? “ < > ”

etc.

8. Total number of files on the disc should be less

than 650.

This DVD player requires discs/recordings to meet

certain technical standards in order to achieve opti-

mal playback quality. Pre-recorded DVDs are auto-

matically set to these standards. There are many dif-

ferent types of recordable disc formats (including

CD-R containing MP3 files). That require certain pre-

existing conditions (see above) to insure compatible

playback.

9. VBR (Variable Bit Rate) is not supported

Pause

1.Press X(PAUSE) during playback.

2.To return to playback, press

(PLAY) or press

X(PAUSE) again.

Moving to another Track

Press .or >briefly during playback to go to

the next track or to return to the beginning of the

current track.

Press .twice briefly to step back to the previ-

ous track.

In case of audio CD, to go directly to any track,

enter the track number using the numbered but-

tons (0-9) during playback.

Operation with Audio CD and MP3 disc (continued)

Repeat Track/All/Off

1.To repeat the track currently playing, press

REPEAT.

The Repeat icon and “TRACK”appears on the menu

screen.

2.To repeat all tracks on a disc, press REPEAT a

second time.

The Repeat icon and “ALL”appears on the menu screen.

3.To cancel Repeat mode, press REPEAT a third

time.

The Repeat icon and “OFF”appears on the menu

screen.

1.Press mor Mduring playback.

The player will now go into SEARCH mode.

2.Press mor Mrepeatedly to select the required

speed: 1 m, 2 m, 3 m (backward) or

1 M, 2 M, 3 M(forward).

Search speed and direction are indicated on the menu

screen.

3.To exit SEARCH mode, press

(PLAY).

Random

1.Press RANDOM during playback or when playback

is stopped.

The unit automatically begins Random Playback

and RANDOM or “RAND.”appears on the display

window and menu screen.

2.To return to normal playback, press RANDOM

repeatedly until “RAND.”disappears on the menu

screen.

Surround (Audio CD only)

This unit can produce a Surround effect, which

simulates multi-channel audio playback from two

conventional stereo speakers, instead of the five or

more speakers normally required to listen to

multi-channel audio from a home theater system.

1.Press AUDIO or DISPLAY during playback.

2.Press B/b to select “NORM.”.

3.Press V/v to select “SUR.”.

To turn off the Surround effect, select “NORM.”.

Changing the Audio Channel

(Audio CD only)

Press AUDIO repeatedly during playback to hear a

different audio channel (ST, LEFT or RIGHT).

Operation with JPEG disc

Advanced Operations

This DVD Player can play discs with JPEG files.

Before playing JPEG recordings, read the notes on

JPEG Recordings on page 44.

1.Insert a disc and close the tray.

The MP3-JPEG choice menu appears on the LCD

screen.

2.Press V/vto select the JPEG then press

ENTER.

The JPEG menu appears on the LCD screen.

3. Press V/vto select a folder, and ENTER.

A list of files in the folder appears.

Press RETURN to move to the MP3-JPEG choice

menu.

zz Hint

If you are in a file list and want to return to the Folder

list, use the V/von the remote to highlight “”and

press ENTER to return to the

previous menu screen.

4.If you want to view a particular file, press V/v

to highlight a file and press ENTER or

(PLAY).

Viewing the file proceeding starts.

During viewing a file, press RETURN to move to

the previous menu (JPEG menu).

Press TOP MENU to move to the next page.

Press MENU to move to the previous page.

NOTE:

Press DISPLAY to appear the information of

current JPEG File. (The current number of file/

The total number of files, File size, File name)

zz Hint

There are three viewing Slide Speed options: Fast,

Normal, Slow, and Off. Press B/bto highlight the

Slide Speed then press V/vto select the option you

want to use, and press ENTER.

5.To stop viewing at any other time, press

x(STOP).

The JPEG menu appears.

JPEG

JPEG Viewer

Slide Speed

Off








1024 x 768

2/45

MP3

JPEG

2/45 1024 x 768


Folder1

Folder2

Folder3

Folder4

Folder5

Folder6

Folder7

Folder8

JPEG Viewer

Slide Speed

Off

Operation with JPEG disc (continued)

Moving to another File

Press .or >once during viewing a picture to

advance to the next file or to the previous file.

Still Picture

1.Press X(PAUSE) during slide show.

The player will now go into PAUSE mode.

2.To return to the slide show, press

(PLAY) or

press X(PAUSE) again.

To flip the picture

Press V/vduring showing a picture to flip the

picture horizontally or a vertically.

To rotate picture

Press B/bduring showing a picture to rotate the

picture clockwise or counter clockwise.

Notes on JPEG Recordings

Depending upon the size and number of the JPEG

files, it could take a long time for the DVD player to

read the disc’s contents. If you don’t see an on-

screen display after several minutes, some of the

files are too big — reduce the resolution of the

JPEG files to less than 2 mega pixels and burn

another disc.

Total number of files and folders on the disc should

be less than 650.

Some disc may be incompatible due to different

recording format or condition of disc.

Ensure that all the selected files have the “.jpg”

extensions when copying into the CD layout.

If the files have “.jpe”or “.jpeg”extensions, please

rename them as “.jpg”files.

File names without “.jpg”extension will not be able

to be read by this DVD player. Even though the

files are shown as JPEG image files in windows

explorer.

Selection of Initial Settings

Initial Settings

Once the initial settings have been completed, the

player can always be operated under the same con-

ditions (especially with DVD discs).

The settings will be retained in the memory until they

are changed, even if the power is switched off.

Selection of initial settings

1.Press SET UP in the stop or playback mode.

The SET UP menu is displayed.

2.Press V/vto select the desired item.

The screen will show the current setting for the

selected item, and the alternate setting(s).

• Disc Audio (see page 46.)

• Disc Subtitle (see page 46.)

• Disc Menu (see page 46.)

• Rating (see page 47.)

• Area Code (see page 48.)

• TV Aspect (see page 49.)

• Menu Language (see page 50.)

• Digital Audio Output (see pages 51-52.)

• Others (see page 53.)

3.Press band then V/vto select the desired set-

ting and press ENTER.

•Some items require additional steps. (See the respective

page.)

When the alternate setting is selected the screen

returns to the Initial Settings display.

To exit SET UP menu

Press SET UP, RETURN or PLAY.

PREV NEXT

CLEAR

PLAY PAUSE STOP

SET UP

SCAN

TOP MENU

DISPLAY RETURN

SLOW

654

ENTER

2, 3

Original

German

Chinese

Italian

Hungarian

Other — — — —

Polish

English

French

Spanish

Disc Subtitle

Disc Menu

Rating

Area Code

TV Aspect

Menu Language

Digital Audio Output

Others

Disc Audio

DVD

Selecting Disc Language

This is to select the audio soundtrack language, sub-

title language and the language used in title menus

or DVD menus which will always be used for every

disc to be played back.

When you play back a DVD video disc, the DVD

player automatically displays the pre-selected subti-

tle language if it is included on the disc.

1.At the SET UP menu screen, press V/vto

select “Disc Audio”and press b.

2.Press V/vto select the desired language and

then press ENTER.

Original :The original language of each disc will be

selected.

English : English will be selected.

Other : Another language can be selected. You

can input a 4-digit language code. (Refer

to the language codes on page 54. Press

CLEAR if an incorrect language code is

entered.)

The “Disc Subtitle”and “Disc Menu”are selected by

the same method.

NOTE:

If the language selected is not available on the disc,

the original language designated by each disc will be

selected.

PREV NEXT

CLEAR

PLAY PAUSE STOP

SET UP

SCAN

TOP MENU

DISPLAY RETURN

SLOW

654

ENTER

2, 3

Original

German

Chinese

Italian

Hungarian

Other — — — —

Polish

English

French

Spanish

Disc Subtitle

Disc Menu

Rating

Area Code

TV Aspect

Menu Language

Digital Audio Output

Others

Disc Audio

Original

German

Chinese

Italian

Hungarian

Other — — — —

Polish

English

French

Spanish

Disc Subtitle

Disc Menu

Rating

Area Code

TV Aspect

Menu Language

Digital Audio Output

Others

Disc Audio

DVD

Movies on DVDs may contain scenes not suitable for

children. Therefore, discs may contain Parental

Control information that applies to the complete disc

or to certain scenes on the disc. These scenes are

rated from 1 to 8, and alternatively, more suitable

scenes are available for selection on some discs.

Ratings are country-dependent. The Parental Control

feature allows you to prevent discs from being played

by your children or to have certain discs played with

alternative scenes.

Selecting rating level

1.Select “Rating”on the Setup menu using the

V/v.

2.While “Rating”is selected, press b.

3.When you have not entered a password yet.

Enter a 4-digit password using the numbered buttons to

create a personal 4-digit security password. then press

ENTER. Enter the 4-digit password again and press

ENTER to verify.

When you have already entered a password;

Enter a 4-digit password using the numbered but-

tons to confirm the personal 4-digit security pass-

word, then press ENTER.

If you make a mistake before pressing ENTER, press

CLEAR and enter 4-digit security password again.

4.Select a rating from 1 to 8 using the V/vbut-

tons. One (1) has the least playback restric-

tions. Eight (8) has the most playback restric-

tions.

Unlock: If you select Unlock, Parental Control is

not active. The disc will play in full.

Ratings 1 to 8: Some discs contain scenes not

suitable for children. If you set a rating for the

player, all disc scenes with the same rating or

lower will be played. Higher rated scenes will not

be played unless an alternative scene is avail-

able on the disc. The alternative must have the

same rating or a lower one. If no suitable alter-

native is found, playback will stop. You must

enter the 4-digit password or change the rating

level in order to play the disc.

5.Press ENTER to confirm your rating selection,

then press SET UP to exit the menu.

Selecting Rating Level

Initial Settings

Unlock

Change

Disc Subtitle

Disc Menu

Rating

Area Code

TV Aspect

Menu Language

Digital Audio Output

Others

Disc Audio

DVD

Selecting Area Code

Enter the code of a country/area whose standards

were used to rate the DVD video disc, referring to

the list (See “Area Code List”, page 55-56.).

1. Select Area Code using the V/von the setup

menu.

2. While Area Code is selected, press b.

3. Follow step 3 of “Rating”on previous page.

4. Select the first character using the V/v.

5. Shift the cursor using band select the

second character using V/v.

6. Press ENTER to confirm your country code

selection, then press SET UP to exit the menu.

NOTE:

Confirmation of the 4-digit password is necessary

when the code is changed

(see “Changing the 4-digit code”below.).

Changing the 4-digit code

1Follow Steps 1-2 as shown to the previous page

(Rating).

2Enter the old code, then press ENTER.

3Select Change using V/vthen press ENTER.

4Enter the new 4-digit code, then press ENTER.

5Enter exactly the same code a second time and

verify by pressing ENTER.

6Press SET UP to exit the menu.

If you forget your 4-digit code

If you forget your password, to clear the current

password, follow the procedure below.

1Press SET UP to display the setup menu.

2Use the Number buttons to enter the 6-digit num-

ber “210499”.

3Enter a new code as shown to the previous page

(Rating).

Code Set

U SDisc Subtitle

Disc Menu

Rating

Area Code

TV Aspect

Menu Language

Digital Audio Output

Others

Disc Audio

DVD

Selecting TV Aspect

Initial Settings

Select the appropriate screen type according to your TV

set; conventional size screen (4:3) or wide-screen (16:9).

1.At the SETUP menu screen, press V/vto select

“TV Aspect”and press b.

2.Press V/vto select the desired Aspect and

press ENTER.

4:3 Letterbox : The video material not formatted in

the Pan & Scan style is played back in the letter-

box style (black bands appear at top and bottom of

screen).

4:3 Panscan : Select when a conventional TV set is

connected. The video material formatted in the Pan

& Scan style is played back in that style (the left and

right edges are cut off).

16:9 Wide : Select when a wide-screen TV set is

connected. Played in “FULL”size. (Setting the wide-

screen TV to “FULL”mode is also necessary.)

* Each screen shows an example when the video

material for a wide-screen is played.

(This setting does not affect the video material for

conventional size.)

CLEAR

PLAY PAUSE STOP

SET UP

SCAN

TOP MENU

DISPLAY RETURN

SLOW

ENTER

4:3

16:9

Letterbox

Panscan

Wide

Disc Subtitle

Disc Menu

Rating

Area Code

TV Aspect

Menu Language

Digital Audio Output

Others

Disc Audio

4:3

16:9

Letterbox

Panscan

Wide

Disc Subtitle

Disc Menu

Rating

Area Code

TV Aspect

Menu Language

Digital Audio Output

Others

Disc Audio

16:9 Wide

4:3 Panscan

Cut Off

4:3 Letterbox

DVD

Selecting Menu Language

Selects language for SETUP menus and displays on

the TV.

1.At the SETUP menu screen, press V/vto select

“Menu Language”and press b.

2.Press V/vto select the desired Language and

press ENTER.

AUDIO

PREV NEXT

CLEAR

PLAY PAUSE STOP

SET UP

SCAN

TOP MENU

DISPLAY RETURN

SLOW

REPEAT

RANDOM

A-B

PROGRAM

ANGLE

123

654

DVD PORTABLE

ENTER

English

Spanish

French

Disc Subtitle

Disc Menu

Rating

Area Code

TV Aspect

Menu Language

Digital Audio Output

Others

Disc Audio

English

Spanish

French

Disc Subtitle

Disc Menu

Rating

Area Code

TV Aspect

Menu Language

Digital Audio Output

Others

Disc Audio

DVD

Selecting Digital Audio Output

Initial Settings

Each DVD disc has a variety of audio output options.

Set the player’s Digital Audio Output according to the

type of audio system you use.

1.At the SETUP menu screen, press V/vto select

“Digital Audio Output”and press b.

2.Press V/vto select the desired output and

press ENTER.

You can select Digital Audio Output or Sampling

Frequency item by pressing ENTER.

■

Digital Audio Output

DOLBY DIGITAL/PCM: Select “DOLBY

DIGITAL/PCM”if an active digital output is supplied

to a Dolby Digital decoder, (or an amplifier or other

equipment with Dolby Digital decoder).

Stream/PCM: Select “Stream/PCM”if an active

digital output is supplied to an amplifier or other

equipment with DTS decoder, Dolby Digital decoder

and MPEG decoder.

PCM: Select “PCM”if an active digital output is

supplied to an amplifier or other equipment with lin-

ear PCM only (or MD recorder or DAT deck).

DOLBY

DIGITAL /PCM

Stream/PCM

PCM

Sample Freq.

48 KHz

96KHz

Disc Subtitle

Disc Menu

Rating

Area Code

TV Aspect

Menu Language

Digital Audio Output

Others

Disc Audio

Playback

Disc

96 kHz

Linear PCM

DVD

DTS DVD

Dolby Digital

DVD

MPEG DVD

Audio CD/

Video CD

DTS Audio CD

Stream/PCM

PCM

DTS bit Stream

Dolby Digital

bit Stream

MPEG bit Stream

PCM

DTS bit Stream

OUTPUT

Dolby Digital/

PCM

DTS bit Stream

Dolby Digital

bit Stream

PCM

DTS bit Stream

PCM only

PCM

DTS bit Stream

PCM

DTS bit Stream

DVD

Selecting Digital Audio Output (continued)

■

Sampling Frequency

To change the Sample Frequency setting, first select

the desired digital audio output type as indicated on

page 51.

If your A/V receiver or surround processor is NOT

capable of handling 96kHz signals, select the 48kHz

option. When this choice is made, this unit will auto-

matically convert any 96kHz signals to a 48kHz out-

put so that your system is capable of decoding them.

If your A/V receiver or surround processor is capable

of handling 96kHz signals, select the 96kHz option.

When this choice is made, this unit will pass each

type of signal through without any further process-

ing.

NOTES:

•

When you are not using the player’s digital audio

output, don’t select any of the options.

•

If an active digital audio output signal is supplied

to a receiver or other equipment without a corre-

sponding digital decoding capability, a very loud

noise may be produced which could permanently

damage the speakers.

•

The DTS DVD disc sound is played back only

when the DVD player is connected to a receiver

with a DTS decoder.

DVD

Others

Initial Settings

The DRC, PBC settings can be changed.

1.At the SETUP menu screen, press V/vto select

“Others”and press b.

2.Press V/vto select the desired items and press

ENTER.

The setting of the selected item are changed

between On and Off.

■

DRC (Dynamic Range Compression) On/Off

On: Select this option to turn on the Dynamic

Range Compression circuitry so that the dia-

logue remains clear even at low volume lev-

els.

Off: Select this option to turn off the Dynamic

Range Compression and have the sound-

track presented exactly as it was created.

■

PBC On/Off

Set Playback Control (PBC) to On or Off

On: Video CDs with PBC are played back

according to the PBC.

Off: Video CDs with PBC are played back in the

same way Audio CDs.

About DRC (Dynamic Range Compression)

With the DVD format you have the opportunity to

hear a program’s soundtrack in the most accurate

and realistic presentation possible, thanks to the use

of digital audio technology. However, in certain

instances you may wish to slightly compress the

dynamic range of the audio output (the difference

between the loudest sounds and the

quietest ones) so that you may listen to a movie at a

lower volume without losing dialogue intelligibility.

NOTES:

•

The DRC function works only during playback of

Dolby Digital recorded discs.

•

The level of Dynamic Range Compression may dif-

fer depending on the DVD disc.

•

When playing karaoke, connect appropriate audio

equipment (such as an amplifier) to the DVD video

player.

DRC

PBC On

Disc Subtitle

Disc Menu

Rating

Area Code

TV Aspect

Menu Language

Digital Audio Output

Others

Disc Audio

DVD

Table of Languages and their Code Numbers

Enter the appropriate code number for the initial settings “Audio”, “Subtitle”and/or “Menu”(See page 46).

Code Language

6565 Afar

6566 Abkhazian

6570 Afrikaans

6577 Ameharic

6582 Arabic

6583 Assamese

6588 Aymara

6590 Azerbaijani

6665 Bashkir

6669 Byelorussian

6671 Bulgarian

6672 Bihari

6678 Bengali; Bangla

6679 Tibetan

6682 Breton

6765 Catalan

6779 Corsican

6783 Czech

6789 Welsh

6865 Danish

6869 German

6890 Bhutani

6976 Greek

6978 English

6979 Esperanto

6983 Spanish

6984 Estonian

6985 Basque

7065 Persian

7073 Finnish

7074 Fiji

Code Language

7079 Faroese

7082 French

7089 Frisian

7165 Irish

7168 Scots Gaelic

7176 Galician

7178 Guarani

7185 Gujarati

7265 Hausa

7273 Hindi

7282 Croatian

7285 Hungarian

7289 Armenian

7365 Interlingua

7378 Indonesian

7383 Icelandic

7384 Italian

7387 Hebrew

7465 Japanese

7473 Yiddish

7487 Javanese

7565 Georgian

7575 Kazakh

7576 Greenlandic

7577 Cambodian

7578 Kannada

7579 Korean

7583 Kashmiri

7585 Kurdish

7589 Kirghiz

7665 Latin

Code Language

7678 Lingala

7679 Laothian

7684 Lithuanian

7686 Latvian, Lettish

7771 Malagasy

7773 Maori

7775 Macedonian

7776 Malayalam

7778 Mongolian

7779 Moldavian

7782 Marathi

7783 Malay

7784 Maltese

7789 Burmese

7865 Nauru

7869 Nepali

7876 Dutch

7879 Norwegian

7982 Oriya

8065 Panjabi

8076 Polish

8083 Pashto, Pushto

8084 Portuguese

8185 Quechua

8277 Rhaeto-Romance

8279 Rumanian

8285 Russian

8365 Sanskrit

8368 Sindhi

8372 Serbo-Croatian

8373 Singhalese

Code Language

8375 Slovak

8376 Slovenian

8377 Samoan

8378 Shona

8379 Somali

8381 Albanian

8382 Serbian

8385 Sudanese

8386 Swedish

8387 Swahili

8465 Tamil

8469 Telugu

8471 Tajik

8472 Thai

8473 Tigrinya

8475 Turkmen

8476 Tagalog

8479 Tonga

8482 Turkish

8484 Tatar

8487 Twi

8575 Ukrainian

8582 Urdu

8590 Uzbek

8673 Vietnamese

8679 Volapük

8779 Wolof

8872 Xhosa

8979 Yoruba

9072 Chinese

9085 Zulu

DVD

Area Code List

Initial Settings

Enter the appropriate code number for the initial setting “Area Code”(See page 48).

Code Area

AD Andorra

AE United Arab Emirates

AF Afghanistan

AG Antigua and Barbuda

AI Anguilla

AL Albania

AM Armenia

AN Netherlands Antilles

AO Angola

AQ Antarctica

AR Argentina

AS American Samoa

AT Austria

AU Australia

AW Aruba

AZ Azerbaidjan

BA Bosnia-Herzegovina

BB Barbados

BD Bangladesh

BE Belgium

BF Burkina Faso

BG Bulgaria

BH Bahrain

BI Burundi

BJ Benin

BM Bermuda

BN Brunei Darussalam

BO Bolivia

BR Brazil

BS Bahamas

BT Bhutan

Code Area

BV Bouvet Island

BW Botswana

BY Belarus

BZ Belize

CA Canada

CC Cocos (Keeling) Islands

CF Central African Republic

CG Congo

CH Switzerland

CI Ivory Coast

CK Cook Islands

CL Chile

CM Cameroon

CN China

CO Colombia

CR Costa Rica

CS Former Czechoslovakia

CU Cuba

CV Cape Verde

CX Christmas Island

CY Cyprus

CZ Czech Republic

DE Germany

DJ Djibouti

DK Denmark

DM Dominica

DO Dominican Republic

DZ Algeria

EC Ecuador

EE Estonia

EG Egypt

Code Area

EH Western Sahara

ER Eritrea

ES Spain

ET Ethiopia

FI Finland

FJ Fiji

FK Falkland Islands

FM Micronesia

FO Faroe Islands

FR France

FX France (European Territory)

GA Gabon

GB Great Britain

GD Grenada

GE Georgia

GF French Guyana

GH Ghana

GI Gibraltar

GL Greenland

GM Gambia

GN Guinea

GP Guadeloupe (French)

GQ Equatorial Guinea

GR Greece

S. Georgia & S. Sandwich Isls.

GT Guatemala

GU Guam (USA)

GW Guinea Bissau

GY Guyana

HK Hong Kong

HM Heard and McDonald Islands

Code Area

HN Honduras

HR Croatia

HT Haiti

HU Hungary

ID Indonesia

IE Ireland

IL Israel

IN India

IO British Indian Ocean Territory

IQ Iraq

IR Iran

IS Iceland

IT Italy

JM Jamaica

JO Jordan

JP Japan

KE Kenya

KG Kyrgyzstan

KH Cambodia6

KI Kiribati

KM Comoros

Saint Kitts & Nevis Anguilla

KP North Korea

KR South Korea

KW Kuwait

KY Cayman Islands

KZ Kazakhstan

LA Laos

LB Lebanon

LC Saint Lucia

LI Liechtenstein

DVD

Area Code List (continued)

Code Area

LK Sri Lanka

LR Liberia

LS Lesotho

LT Lithuania

LU Luxembourg

LV Latvia

LY Libya

MA Morocco

MC Monaco

MD Moldavia

MG Madagascar

MH Marshall Islands

MK Macedonia

ML Mali

MM Myanmar

MN Mongolia

MO Macau

Northern Mariana Islands

MQ Martinique (French)

MR Mauritania

MS Montserrat

MT Malta

MU Mauritius

MV Maldives

MW Malawi

MX Mexico

MY Malaysia

MZ Mozambique

NA Namibia

NC New Caledonia (French)

NE Niger

Code Area

NF Norfolk Island

NG Nigeria

NI Nicaragua

NL Netherlands

NO Norway

NP Nepal

NR Nauru

NU Niue

NZ New Zealand

OM Oman

PA Panama

PE Peru

PF Polynesia (French)

PG Papua New Guinea

PH Philippines

PK Pakistan

PL Poland

Saint Pierre and Miquelon

PN Pitcairn Island

PR Puerto Rico

PT Portugal

PW Palau

PY Paraguay

QA Qatar

RE Reunion (French)

RO Romania

RU Russian Federation

RW Rwanda

SA Saudi Arabia

SB Solomon Islands

SC Seychelles

Code Area

SD Sudan

SE Sweden

SG Singapore

SH Saint Helena

SI Slovenia

Svalbard and Jan Mayen Islands

SK Slovak Republic

SL Sierra Leone

SM San Marino

SN Senegal

SO Somalia

SR Suriname

ST Saint Tome and Principe

SU Former USSR

SV El Salvador

SY Syria

SZ Swaziland

Turks and Caicos Islands

TD Chad

French Southern Territories

TG Togo

TH Thailand

TJ Tadjikistan

TK Tokelau

TM Turkmenistan

TN Tunisia

TO Tonga

TP East Timor

TR Turkey

TT Trinidad and Tobago

TV Tuvalu

Code Area

TW Taiwan

TZ Tanzania

UA Ukraine

UG Uganda

UK United Kingdom

USA Minor Outlying Islands

US United States

UY Uruguay

UZ Uzbekistan

VA Vatican City State

Saint Vincent & Grenadines

VE Venezuela

VG Virgin Islands (British)

VI Virgin Islands (USA)

VN Vietnam

VU Vanuatu

Wallis and Futuna Islands

WS Samoa

YE Yemen

YT Mayotte

YU Yugoslavia

ZA South Africa

ZM Zambia

ZR Zaire

ZW Zimbabwe

DVD

Connecting to a TV

NOTES:

•

Refer to the owner’s manual of your TV as well.

•

Before you connect the DVD player to your TV, be sure to turn off the power and unplug both units from the

wall outlet before making any connections.

•

Connect the DVD player to your TV directly. If you connect the DVD player to a VCR, the playback

picture will be distorted because DVD video discs are copy protected.

VOLUME PHONES AUDIO VIDEO

DC IN 9.8V

S-VIDEO OUT

LINE SELECT

IN OUT

VOLUME PHONES AUDIO VIDEO

DC IN 9.8V

S-VIDEO OUT

LINE SELECT

IN OUT

To audio/video input

To VIDEO IN/OUT

Audio/Video cable (Supplied)

To S-VIDEO OUT

To AUDIO IN/OUT

Right side of unit

To S-video input

TV or monitor with

audio/video inputs

You must set the LINE SELECT

switch to the "OUT" mode

If the TV has an S-video input, connect the DVD player

with the S-video cable. When using an S-video cable,

do not connect the yellow video cable.

Connections

Connecting to an amplifier equipped with a Dolby Digital decoder

VOLUME PHONES AUDIO VIDEO

DC IN 9.8V

S-VIDEO OUT

LINE SELECT

IN OUT

To AUDIO IN/OUT To digital audio input

(optical)

Optical cable (Not supplied)

Right side of unit

Amplifier equipped with a

Dolby Digital decoder

Front speaker

(left)

Rear speaker

(left surround)

Rear speaker

(right surround)

Front speaker

(right)

Sub woofer

Center

speaker

You must set the LINE SELECT

switch to the "Out" mode

To enjoy Dolby Digital sound from this DVD

player you need the following:

•DVD recorded in Dolby Digital

•6 channel receiver equipped with a Dolby Digital

decoder, or Dolby Digital processor and power

receiver

•5 speakers and 1 sub woofer

•Set the Digital Audio Output of this DVD player to

“Dolby Digital”from the SETUP menu

Manufactured under license from Dolby Laboratories.

“Dolby”, “Pro Logic”, and the double-D symbol are

trademarks of Dolby Laboratories.

Connecting to an amplifier equipped with a Dolby Pro Logic Surround

Connections

VOLUME PHONES AUDIO VIDEO

DC IN 9.8V

S-VIDEO OUT

LINE SELECT

IN OUT

Right side of unit

Amplifier equipped with a

Dolby Pro Logic Surround

(yellow)

No need to connect

when using an S-video cable

to connect to your TV.

Front speaker

(left)

Rear speaker

(left)

Rear speaker

(right)

Front speaker

(right)

Center

speaker

To analog

audio input

To VIDEO

IN/OUT

Audio/Video cable

(Supplied)

To AUDIO IN/OUT

You must set the LINE SELECT

switch to the "Out" mode

Dolby Pro Logic Surround

You can still enjoy the excitement of Surround Sound even if your A/V receiver does not offer Dolby Digital

decoding.

If your A/V receiver has a Dolby Pro Logic ll/ Pro Logic decoder, refer to the following connection diagram.

•

With a receiver equipped with Dolby Digital

Connect the equipment the same way as

described in “Connecting to an amplifier equipped

with a Dolby Digital decoder”on the previous

page. Refer to that receiver’s owner’s manual and

set the receiver so you can enjoy Dolby Pro Logic

Surround sound.

NOTE:

Be sure to set Digital Audio Output of this DVD

player to “PCM”from the SETUP menu when you

enjoy sounds of Dolby Pro Logic Surround using

this connection.

Connect one or two rear speak-

ers. The output sound from the

rear speakers will be monaural

even if you connect two rear

speakers.

Connecting to an amplifier equipped with a DTS decoder

VOLUME PHONES AUDIO VIDEO

DC IN 9.8V

S-VIDEO OUT

LINE SELECT

IN OUT

To AUDIO IN/OUT To digital audio input

(optical)

Optical cable (Not supplied)

Right side of unit

Amplifier equipped with a

DTS decoder

Front speaker

(left)

Rear speaker

(left surround)

Rear speaker

(right surround)

Front speaker

(right)

Sub woofer

Center

speaker

You must set the LINE SELECT

switch to the "Out" mode

Digital Theater System(DTS)

DTS is high quality surround technology used in theaters and now available for home use, on DVD video discs or audio CDs. If

you have a DTS decoder or processor, you can obtain the full benefit of 5.1 channel DTS encoded sound tracks on DVD video

discs or audio CDs.

“DTS”and “DTS Digital Out”are trademarks of Digital Theater Systems, Inc.

NOTE:

When you are connecting (via the OPTICAL OUT) an AV decoder that does not have the Dolby Digital, Digital

Theater System (DTS) or MPEG2 decoding, be sure to

set Digital Audio Output of this DVD player to “PCM”

from the SETUP menu. Otherwise, high volume sound may damage your hearing as well as the speakers.

Connecting to an amplifier equipped with a digital audio input

Connections

VOLUME PHONES AUDIO VIDEO

DC IN 9.8V

S-VIDEO OUT

LINE SELECT

IN OUT

To AUDIO IN/OUT To digital audio input

(optical)

Optical cable (Not supplied)

Right side of unit

Amplifier equipped with a

digital audio input

Front speaker

(left)

Front speaker

(right)

You must set the LINE SELECT

switch to the "Out" mode

2 Channel Digital Stereo

You can enjoy the dynamic sound of 2 Channel Digital Stereo by connecting this DVD player to a receiver

equipped with a digital audio input and speaker system (right and left front speakers).

NOTES:

For all connections

•

Connect the OPTICAL OUT of the player to the “OPTICAL”input of a Receiver or Processor.

•

Refer to the owner’s manual of your audio equipment as well.

•

Before you connect the DVD player to other equipment, be sure to turn off the power and unplug all of the

equipment from the wall outlet before making any connections.

•

The output sound of the DVD player has a wide dynamic range. Be sure to adjust the receiver’s volume to a

moderate listening level. Otherwise, the speakers may be damaged by a sudden high volume sound.

•

Turn off the receiver before you connect or disconnect the DVD player’s power cord. If you leave the receiv-

er power on, the speakers may be damaged.

Disc Requirements

Playable Discs

This DVD player can play back the following discs.

In addition, this unit can play a DVD-RW (Video Mode), DVD-R, DVD+RW and CD-R or CD-RW that con-

tains audio titles or MP3 or JPEG files.

You cannot playback discs other than those listed above.

(CVD, CD-ROM, CD-Extra, CD-G, and CD-i discs can not be played on this DVD player.)

Disc mark Contents

Audio+Video

(moving pictures)

Audio+Video

Audio

Disc size

12 cm

8 cm

12 cm

8 cm

12 cm

8 cm

Maximum playback time

Approx. 4 hours (single sided disc)

Approx. 8 hours (double sided disc)

Approx. 80 minutes (single sided disc)

Approx. 160 minutes (double sided disc)

74 minutes

20 minutes

74 minutes

20 minutes

DVD video

discs

Video CDs

Audio CDs

Reference

Region Management Information: This DVD Player is designed and manufactured to respond to the

Region Management Information that is recorded on a DVD disc. If the Region number described on the

DVD disc does not correspond to the Region number of this DVD player, this DVD player cannot play that

disc.

The Region number of this DVD player is 1.

You may not be able to play back some DVD video discs on this player if they were purchased from out-

side your geographic area or made for business purposes.

When you try to play back an unauthorized disc, “Check Regional Code”appears on the LCD screen.

It is forbidden by law to copy, broadcast, show, broadcast on cable, play in public, and rent copyrighted

material without permission.

DVD video discs are copy protected, and any recordings made from these discs will be distorted.

This product incorporates copyright protection technology that is protected by U.S. patents and other intel-

lectual property rights. Use of this copyright protection technology must be authorized by Macrovision, and

is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision.

Reverse engineering or disassembly is prohibited.

Note on Unauthorized Discs

Region Management Information

Note on Copyright

Before Calling Service Personnel

Check the following guide for the possible cause of a problem before contacting service.

Symptoms and Correction

Symptom

No power.

The power is on, but

the DVD player does

not work.

No picture on the

LCD or TV (including

video from another

unit).

Cause

•The power cord is disconnected.

•Hold switch is set to HOLD position.

•The battery is discharged.

•No disc is inserted.

•The video cable is not connected

securely.

•The AV LINE SELECT switch is not set

correctly.

•LCD mode is set to OFF.

•

Check that Brightness control is set to “–”.

•The TV is not set to receive DVD signal

output.

•The connected TV power is turned off.

Correction

•Plug the power cord into the wall out-

let securely.

•Release the hold mode.

•Recharge the battery.

•Insert a disc. (Check that the DVD or,

audio CD indicator in the display win-

dow is lit.)

•Connect the video cable into the jacks

securely.

•Set the LINE SELECT switch correct-

ly.

- While you are playing a disc, set the

LINE SELECT switch to Out mode.

- While you are viewing video from

other equipment, set the LINE

SELECT switch to In mode.

•Select a LCD mode other than OFF.

•Adjust the brightness.

•Select the appropriate video input

mode on the TV so the picture from

the DVD player appears on the LCD

screen.

•Turn on the TV.

Before Calling Service Personnel (continued)

Reference

Symptom

No sound.

The playback

picture is poor.

The DVD player does

not start playback.

Cause

•

The equipment connected with the audio

cable is not set to receive DVD signal

output.

•The audio cables are not connected

securely.

•The power of the equipment connected

with the audio cable is turned off.

•The Digital Audio Output is set to the

wrong position.

•The disc is dirty.

•No disc is inserted.

•An unplayable disc is inserted.

•The disc is placed upside down.

•The disc is not placed within the guide.

•A menu is on the LCD screen.

•The Rating level is set.

Correction

•Select the correct input mode of the

audio receiver so you can listen to the

sound from the DVD player.

•Connect the audio cable into the jacks

securely.

•Turn on the equipment connected with

the audio cable.

•Set the Digital Audio Output to the

correct position, then turn on the DVD

player again.

•Clean the disc.

•Insert a disc. (Check that the disc

indicator in the display window is lit.)

•

Insert a playable disc. (Check the disc

type, color system and Regional code.)

•

Place the disc with the playback side

down.

•Place the disc on the disc tray correct-

ly inside the guide.

•Press the SET UP button to turn off

the menu screen.

•Cancel the Rating function or change

the rating level.

Before Calling Service Personnel (continued)

Symptom

The LCD is dark.

No response when

buttons are

pressed.

The remote con-

trol does not

work properly.

Cause

•

Check that Brightness control is set to “–”.

•Some discs prohibit certain operations.

•Hold switch is set to HOLD position.

•The remote control is too far from the

DVD player.

•There is an obstacle in the path of the

remote control and the DVD player.

•The batteries in the remote control are

exhausted

Correction

•Adjust the brightness.

•“ ”may appear on the screen during

operation.

•Release the hold mode.

•Operate the remote control within about

23 ft (7 m).

•Remove the obstacle.

•Replace the batteries with new ones.

Specifications

Reference

[DVD player]

Power supply DC 9.8 V (AC adaptor terminal), DC 7.4 V (Battery)

Power consumption 12 W with battery

Weight 1.43 lbs (0.65 kg) (without battery pack)

External dimensions (W X D X H) 7 1/2 x 6 x 1 1/16 inches (189 x 150.3 x 26.1 mm)

Signal system NTSC

Laser

Semiconductor laser, wavelength 650 nm (DVD), 780 nm (CD)

Frequency range (audio) DVD linear sound: 48kHz sampling 4 Hz to 20 kHz

96kHz sampling 4 Hz to 44 kHz

Signal-to-noise ratio (audio) More than 95 dB

Dynamic range (audio) More than 95 dB

Harmonic distortion (audio) 0.08 %

Operating conditions Temperature: 41°F to 95°F, Operation status: Horizontal

Video input/output (VIDEO In/Out) 1.0 V (p-p), 75 Ω, negative sync., ø3.5mm mini jack x 1

S-video output (Y) 1.0 V (p-p), 75 Ω, negative sync., Mini DIN 4-pin x 1

Audio output (optical audio) Optical connector (ø3.5mm) x 1

Audio input/output 2.0 Vrms(1 KHz, 0 dB), ø3.5mm mini jack x 1

(AUDIO In/Out, analog audio)

Earphone terminal ø3.5mm stereo mini jack x 1

[Connectors]

Specifications (continued)

❋ Designs and specifications are subject to change without notice.

[Liquid Crystal

Display]

[Supplied

Accessories]

Panel size 7 inches (16:9)

Projection system TN color transmission

Driving system a-Si TFT active matrix

Resolution 234 x 480 (effective pixel rate: more than 99.99%)

•Audio/Video connecting cord .....................................................................1

•AC Adaptor (AC-FX100) ............................................................................1

•Power Cord ................................................................................................1

•Battery Pack (NP-FX100) ..........................................................................1

•Remote control (RMT-D163A)....................................................................1

•Size AA (R6) batteries ...............................................................................2

Sony Corporation Printed in Korea http://www.sony.net/

Sony Dps5032N Users Manual DPS5032N_SONY

DVP-FX700 Operating Instructions DVPFX700

User manual DVPFX700 Sony DVP-FX700 Portable DVD Player User Manuals and Instruction Guides

DPS5032N to the manual c1d67d5f-559a-4b18-b09c-0967a294f6b5

Navigation menu

Versions of this User Manual:

Views

Navigation
