DVP-NS75H

2-662-865-11(2)

2-662-865-11(2)

© 2006 Sony Corporation

DVP-NS75H

Operating Instructions

For customers in the U.S.A

Owner’s Record

The model and serial numbers are located at the rear of the unit.

Record the serial number in the space provided below. Refer to them

whenever you call upon your Sony dealer regarding this product.

Model No. DVP-NS75H

Serial No.______________

For Customers in Canada

If this product is not working properly, please call 1-877-602-2008 for

Peace of Mind Warranty Replacement service.

For other product related questions please contact our Customer

Information Service Centre at 1-877-899-7669 or write to us at:

Customer Information Service 115 Gordon Baker Road, Toronto,

Ontario, M2H 3R6

CD/DVD

Player

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US02WAR-CEK.fm

master page=left

2

DVP-NS75H

2-662-865-11(1)

WARNING

To reduce the risk of fire or

electric shock, do not expose

this apparatus to rain or

moisture.

To avoid electrical shock, do

not open the cabinet. Refer

servicing to qualified

personnel only.

The AC power cord must be

changed only at a qualified

service shop.

CAUTION

The use of optical instruments with

this product will increase eye

hazard. As the laser beam used in

this CD/DVD player is harmful to

eyes, do not attempt to disassemble

the cabinet.

Refer servicing to qualified

personnel only.

This symbol is

intended to alert the

user to the presence

of uninsulated

“dangerous voltage”

within the product’s enclosure that

may be of sufficient magnitude to

constitute a risk of electric shock to

persons. This symbol is

intended to alert the

user to the presence

of important

operating and

maintenance (servicing)

instructions in the literature

accompanying the appliance.

CAUTION

You are cautioned that any

changes or modifications not

expressly approved in this manual

could void your authority to

operate this equipment.

Note

This equipment has been tested

and found to comply with the

limits for a Class B digital device,

pursuant to Part 15 of the FCC

Rules. These limits are designed to

provide reasonable protection

against harmful interference in a

residential installation. This

equipment generates, uses, and can

radiate radio frequency energy

and, if not installed and used in

accordance with the instructions,

may cause harmful interference to

radio communications. However,

there is no guarantee that

interference will not occur in a

particular installation. If this

equipment does cause harmful

interference to radio or television

reception, which can be

determined by turning the

equipment off and on, the user is

encouraged to try to correct the

interference by one or more of the

following measures:

– Reorient or relocate the

receiving antenna.

– Increase the separation

between the equipment and

receiver.

– Connect the equipment into an

outlet on a circuit different

from that to which the receiver

is connected.

– Consult the dealer or an

experienced radio/TV

technician for help.

Notes About the

Discs

• To keep the disc clean, handle

the disc by its edge. Do not touch

the surface.

• Do not expose the disc to direct

sunlight or heat sources such as

hot air ducts, or leave it in a car

parked in direct sunlight as the

temperature may rise

considerably inside the car.

• After playing, store the disc in its

case.

• Clean the disc with a cleaning

cloth.

Wipe the disc from the center

out.

• Do not use solvents such as

benzine, thinner, commercially

available disc/lens cleaners, or

anti-static spray intended for

vinyl LPs.

• If you have printed the disc’s

label, dry the label before

playing.

3

DVP-NS75H

2-662-865-11(1)

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US02WAR-CEK.fm

master page=right

Important

Safeguards

For your protection, please read these safety

instructions completely before operating the appliance,

and keep this manual for future reference.

Carefully observe all warnings, precautions and

instructions on the appliance, or the one described in

the operating instructions and adhere to them.

Use Installation

Power sources

This set should be operated only

from the type of power source

indicated on the marking label. If

you are not sure of the type of

electrical power supplied to your

home, consult your dealer or local power company.

For those sets designed to operate from battery power,

or other sources, refer to the operating instructions.

Grounding or Polarization

This set is equipped with a polarized ac power cord

plug (a plug having one blade wider than the other), or

with a three-wire grounding type plug (a plug having a

third pin for grounding). Follow the instructions

below:

For the set with a polarized AC power

cord plug:

This plug will fit into the power

outlet only one way. This is a

safety feature. If you are unable to

insert the plug fully into the outlet, try reversing the

plug. If the plug should still fail to fit, contact your

electrician to have a suitable outlet installed. Do not

defeat the safety purpose of the polarized plug by

forcing it in.

For the set with a three-wire grounding

type AC plug:

This plug will only fit into a

grounding-type power outlet. This

is a safety feature. If you are

unable to insert the plug into the

outlet, contact your electrician to have a suitable outlet

installed. Do not defeat the safety purpose of the

grounding plug.

Overloading

Do not overload wall outlets,

extension cords or convenience

receptacles beyond their capacity,

since this can result in fire or

electric shock.

Object and Liquid Entry

Never push objects of any kind into

the set through openings as they

may touch dangerous voltage points

or short out parts that could result in

a fire or electric shock. Never spill

liquid of any kind on the set.

Attachments

Do not use attachments not

recommended by the manufacturer, as

they may cause hazards.

Cleaning

Unplug the set from the wall outlet

before cleaning or polishing it. Do

not use liquid cleaners or aerosol

cleaners. Use a cloth lightly

dampened with water for cleaning

the exterior of the set.

Water and Moisture

Do not use power-line operated sets

near water - for example, near a

bathtub, washbowl, kitchen sink, or

laundry tub, in a wet basement, or

near a swimming pool, etc.

Power-Cord Protection

Route the power cord so that it is

not likely to be walked on or

pinched by items placed upon or

against them, paying particular

attention to the plugs, receptacles, and the point where

the cord exits from the appliance.

Accessories

Do not place the set on an

unstable cart, stand, tripod,

bracket, or table. The set may

fall, causing serious injury to a

child or an adult, and serious damage to the set. Use

only a cart stand tripod, bracket, or table recommended

by the manufacturer.

An appliance and cart combination

should be moved with care. Quick

stops, excessive force, and uneven

surfaces may cause the appliance

and cart combination to overturn.

Ventilation

The slots and openings in the cabinet are provided for

necessary ventilation. To ensure reliable operation of

the set, and to protect it from overheating, these slots

and openings must never be blocked or covered.

• Never cover the slots and

openings with a cloth or

other materials.

• Never block the slots and

openings by placing the set

on a bed, sofa, rug or other

similar surface.

S3125A

,continued

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US02WAR-CEK.fm

master page=left

4

DVP-NS75H

2-662-865-11(1)

Antennas

Service

• Never place the set in a

confined space, such as a

bookcase, or built-in

cabinet, unless proper

ventilation is provided.

• Do not place the set near or

over a radiator or heat

register, or where it is

exposed to direct sunlight.

Outdoor antenna grounding

If an outdoor antenna or cable system is installed,

follow the precautions below.

An outdoor antenna system should not be located in the

vicinity of overhead power lines or other electric light

or power circuits, or where it can come in contact with

such power lines or circuits.

WHEN INSTALLING AN OUTDOOR ANTENNA

SYSTEM, EXTREME CARE SHOULD BE TAKEN

TO KEEP FROM CONTACTING SUCH POWER

LINES OR CIRCUITS AS CONTACT WITH THEM

IS ALMOST INVARIABLY FATAL.

Be sure the antenna system is grounded so as to provide

some protection against voltage surges and built-up static

charges. Section 810 of the National Electrical Code

provides information with respect to proper grounding of

the mast and supporting structure, grounding of the lead-in

wire to an antenna discharge unit, size of grounding

conductors, location of antenna-discharge unit, connection

to grounding electrodes, and requirements for the

grounding electrode.

Antenna Grounding According to the

National Electrical Code

Lightning

For added protection for this set during a lightning

storm, or when it is left unattended and unused for long

periods of time, unplug it from the wall outlet and

disconnect the antenna or cable system. This will

prevent damage to the set due to lightning and power-

line surges.

Antenna Lead in Wire

Ground Clamp

Antenna Discharge unit

(NEC Section 810-20)

Grounding Conductors

(NEC Section 810-21)

Ground Clamps

Power Service Grounding

Electrode System

(NEC Art 250 Part H)

Electric Service

Equipment

NEC-NATIONAL ELECTRICAL CODE

Damage Requiring Service

Unplug the set from the wall outlet and refer servicing

to qualified service personnel under the following

conditions:

• When the power cord or plug is

damaged or frayed.

• If liquid has been spilled or

objects have fallen into the

set.

• If the set has been exposed

to rain or water.

• If the set has been

subject to excessive

shock by being

dropped, or the cabinet

has been damaged.

• If the set does not operate

normally when following

the operating instructions.

Adjust only those controls

that are specified in the

operating instructions. Improper adjustment

of other controls may result in damage and

will often require extensive work by a

qualified technician to restore the set to normal

operation.

• When the set exhibits a distinct change in

performance - this indicates a need for service.

Servicing

Do not attempt to service the set

yourself as opening or removing

covers may expose you to

dangerous voltage or other

hazards.

Refer all servicing to qualified service personnel.

Replacement parts

When replacement parts are required, be sure the

service technician has used replacement parts specified

by the manufacturer that have the same characteristics

as the original parts.

Unauthorized substitutions may result in fire, electric

shock, or other hazards.

Safety Check

Upon completion of any service or

repairs to the set, ask the service

technician to perform routine

safety checks (as specified by the

manufacturer) to determine that

the set is in safe operating

condition.

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US03PRE1-CEK.fm

master page=right

5

DVP-NS75H

2-662-865-11(1)

Precautions

On safety

• To prevent fire or shock hazard, do not

place objects filled with liquids, such as

vases, on the apparatus.

• Should any solid object or liquid fall into

the cabinet, unplug the player and have it

checked by qualified personnel before

operating it any further.

On power sources

• The player is not disconnected from the AC

power source as long as it is connected to

the wall outlet, even if the player itself has

been turned off.

• If you are not going to use the player for a

long time, be sure to disconnect the player

from the wall outlet. To disconnect the AC

power cord, grasp the plug itself; never pull

the cord.

On placement

• Place the player in a location with adequate

ventilation to prevent heat build-up in the

player.

• Do not place the player on a soft surface

such as a rug.

• Do not place the player in a location near

heat sources, or in a place subject to direct

sunlight, excessive dust, or mechanical

shock.

• Do not install the player in an inclined

position. It is designed to be operated in a

horizontal position only.

• Keep the player and the discs away from

equipment with strong magnets, such as

microwave ovens, or large loudspeakers.

• Do not place heavy objects on the player.

On operation

• If the player is brought directly from a cold

to a warm location, or is placed in a very

damp room, moisture may condense on the

lenses inside the player. Should this occur,

the player may not operate properly. In this

case, remove the disc and leave the player

turned on for about half an hour until the

moisture evaporates.

• When you move the player, take out any

discs. If you don’t, the disc may be

damaged.

On adjusting volume

Do not turn up the volume while listening to

a section with very low level inputs or no

audio signals. If you do, the speakers may be

damaged when a peak level section is played.

On cleaning

Clean the cabinet, panel, and controls with a

soft cloth slightly moistened with a mild

detergent solution. Do not use any type of

abrasive pad, scouring powder or solvent

such as alcohol or benzine.

On cleaning discs, disc/lens cleaners

Do not use a commercially available

cleaning disc or disc/lens cleaner (wet or

spray type). These may cause the

apparatus to malfunction.

If you have any questions or problems

concerning your player, please consult your

nearest Sony dealer.

IMPORTANT NOTICE

Caution: This player is capable of holding a

still video image or on-screen display image

on your television screen indefinitely. If

you leave the still video image or on-screen

display image displayed on your TV for an

extended period of time you risk permanent

damage to your television screen. Plasma

display panel televisions and projection

televisions are susceptible to this.

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US01COV-CEKTOC.fm

master page=left

6

DVP-NS75H

2-662-865-11(1)

Table of Contents

WARNING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Notes About the Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Important Safeguards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

About This Manual. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

This Player Can Play the Following Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Index to Parts and Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Guide to the Control Menu Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Hookups. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Hooking Up the Player. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Step 1: Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Step 2: Inserting Batteries Into the Remote. . . . . . . . . . . . . . . . . . . . . . . . . . 16

Step 3: Connecting the Video Cords/HDMI Cords. . . . . . . . . . . . . . . . . . . . . 17

Step 4: Connecting the Audio Cords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Step 5: Connecting the Power Cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Step 6: Quick Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Playing Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Playing Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Resuming Playback From the Point Where You Stopped the Disc (Multi-disc

Resume) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Using the DVD’s Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Selecting “ORIGINAL” or “PLAY LIST” on a DVD-RW/DVD-R . . . . . . . . . . . 28

Playing VIDEO CDs With PBC Functions (PBC Playback) . . . . . . . . . . . . . . 29

Various Play Mode Functions (Program Play, Shuffle Play, Repeat Play,

A-B Repeat Play) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Searching for a Scene . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Searching for a Particular Point on a Disc (Search, Scan, Slow-motion Play,

Freeze Frame) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Searching for a Title/Chapter/Track/Scene, etc. . . . . . . . . . . . . . . . . . . . . . . 35

Searching by Scene (PICTURE NAVIGATION) . . . . . . . . . . . . . . . . . . . . . . 37

Viewing Information About the Disc . . . . . . . . . . . . . . . . . . . . . . . 38

Checking the Playing Time and Remaining Time . . . . . . . . . . . . . . . . . . . . . 38

Sound Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Changing the Sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

TV Virtual Surround Settings (TVS). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Enjoying Movies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Changing the Angles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Displaying the Subtitles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Adjusting the Playback Picture (CUSTOM PICTURE MODE). . . . . . . . . . . . 45

Sharpening the Picture (SHARPNESS). . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Adjusting the Picture Quality (BNR, MNR). . . . . . . . . . . . . . . . . . . . . . . . . . . 47

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US01COV-CEKTOC.fm

master page=right

DVP-NS75H

2-662-865-11(1)

7

Adjusting the Delay Between the Picture and Sound (AV SYNC) . . . . . . . . . 49

Enjoying MP3 Audio and JPEG Images . . . . . . . . . . . . . . . . . . . . . 50

About MP3 Audio Tracks and JPEG Image Files . . . . . . . . . . . . . . . . . . . . . 50

Playing MP3 Audio Tracks or JPEG Image Files. . . . . . . . . . . . . . . . . . . . . . 51

Enjoying JPEG Images as a Slide Show . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Using Various Additional Functions . . . . . . . . . . . . . . . . . . . . . . . 56

Locking Discs (CUSTOM PARENTAL CONTROL,

PARENTAL CONTROL) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Controlling Your TV with the Supplied Remote . . . . . . . . . . . . . . . . . . . . . . . 59

Settings and Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Using the Setup Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Setting the Display or Sound Track Language (LANGUAGE SETUP) . . . . . 62

Settings for the Display (SCREEN SETUP). . . . . . . . . . . . . . . . . . . . . . . . . . 63

Custom Settings (CUSTOM SETUP). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Settings for the Sound (AUDIO SETUP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Additional Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Self-diagnosis Function (When letters/numbers appear in the display). . . . . 72

Glossary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

Language Code List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Parental Control Area Code List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

About This Manual

• Instructions in this manual describe the controls on the remote. You can also use the

controls on the player if they have the same or similar names as those on the remote.

• “DVD” may be used as a general term for DVD VIDEOs, DVD+RWs/DVD+Rs (+VR

mode) and DVD-RWs/DVD-Rs (video mode).

• The meaning of the icons used in this manual is described below:

Icons Meaning

Functions available for DVD VIDEOs and DVD+RWs/DVD+Rs in +VR

mode or DVD-RWs/DVD-Rs in video mode

Functions available for DVD-RWs/DVD-Rs in VR (Video Recording) mode

Functions available for VIDEO CDs (including Super VCDs or CD-Rs/CD-

RWs in video CD format or Super VCD format)

Functions available for music CDs or CD-Rs/CD-RWs in music CD format

Functions available for DATA CDs (CD-ROMs/CD-Rs/CD-RWs

containing MP3* audio tracks, and JPEG image files)

Functions available for DATA DVDs (DVD-ROMs/DVD+RWs/DVD+Rs/

DVD-RWs/DVD-Rs containing MP3* audio tracks, and JPEG image files

)

*MP3 (MPEG-1 Audio Layer III) is a standard format defined by ISO (International Organization for

Standardization)/IEC (International Electrotechnical Commission) MPEG which compresses audio data.

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US04PRE2-CEK.fm

master page=left

8

DVP-NS75H

2-662-865-11(1)

This Player Can Play the

Following Discs

“DVD+RW,” “DVD-RW,” “DVD+R,”

“DVD-R,” “DVD VIDEO,” and “CD” logos

are trademarks.

Note about CDs/DVDs

The player can play CD-ROMs/CD-Rs/CD-

RWs recorded in the following formats:

– music CD format

– video CD format

– MP3 audio tracks and JPEG image files of

format conforming to ISO 9660* Level 1/

Level 2, or its extended format, Joliet

– KODAK Picture CD format

* A logical format of files and folders on CD-

ROMs, defined by ISO (International

Organization for Standardization).

The player can play DVD-ROMs/

DVD+RWs/DVD-RWs/DVD+Rs/DVD-Rs

recorded in the following format:

– MP3 audio tracks and JPEG image files of

format conforming to UDF (Universal Disk

Format).

Example of discs that the player

cannot play

The player cannot play the following discs:

• CD-ROMs/CD-Rs/CD-RWs other than

those recorded in the formats listed on this

page.

• CD-ROMs recorded in PHOTO CD format.

• Data part of CD-Extras.

• DVD Audio discs.

• HD layer on Super Audio CDs.

Also, the player cannot play the following

discs:

• A DVD VIDEO with a different region

code.

• A disc recorded in a color system other than

NTSC, such as PAL or SECAM (this player

conforms to the NTSC color system).

• A disc that has a non-standard shape (e.g.,

card, heart).

• A disc with paper or stickers on it.

• A disc that has the adhesive of cellophane

tape or a sticker still left on it.

Region code

Your player has a region code printed on the

back of the unit and only will play DVD

VIDEOs (playback only) labeled with

identical region codes. This system is used to

protect copyrights.

DVD VIDEOs labeled will also play on

this player.

If you try to play any other DVD VIDEO, the

message “Playback prohibited by area

limitations.” will appear on the TV screen.

Depending on the DVD VIDEO, there may

be no region code indication, even though

playing the DVD VIDEO is prohibited by

area restrictions.

Format of discs

DVD VIDEO

DVD-RW/-R

DVD+RW/+R

VIDEO CD/

Music CD

CD-RW/-R

ALL

DVP–XXXX

00V 00Hz

00W

NO.

0-000-000-00

XRegion code

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US04PRE2-CEK.fm

master page=right

9

DVP-NS75H

2-662-865-11(1)

Notes

• Notes about DVD+RWs/DVD+Rs, DVD-RWs/

DVD-Rs or CD-Rs/CD-RWs

Some DVD+RWs/DVD+Rs, DVD-RWs/DVD-

Rs, or CD-Rs/CD-RWs cannot be played on this

player due to the recording quality or physical

condition of the disc, or the characteristics of the

recording device and authoring software.

The disc will not play if it has not been correctly

finalized. For more information, refer to the

operating instructions for the recording device.

Note that some playback functions may not work

with some DVD+RWs/DVD+Rs, even if they

have been correctly finalized. In this case, view

the disc by normal playback. Also some DATA

CDs/DATA DVDs created in Packet Write

format cannot be played.

• Music discs encoded with copyright protection

technologies

This product is designed to playback discs that

conform to the Compact Disc (CD) standard.

Recently, various music discs encoded with

copyright protection technologies are marketed

by some record companies. Please be aware that

among those discs, there are some that do not

conform to the CD standard and may not be

playable by this product.

• Note on DualDiscs

A DualDisc is a two sided disc product which

mates DVD recorded material on one side with

digital audio material on the other side.

However, since the audio material side does not

conform to the Compact Disc (CD) standard,

playback on this product is not guaranteed.

Note on playback operations of

DVDs and VIDEO CDs

Some playback operations of DVDs and

VIDEO CDs may be intentionally set by

software producers. Since this player plays

DVDs and VIDEO CDs according to the disc

contents the software producers designed,

some playback features may not be available.

Also, refer to the instructions supplied with

the DVDs or VIDEO CDs.

Copyrights

This product incorporates copyright

protection technology that is protected by

U.S. patents and other intellectual property

rights. Use of this copyright protection

technology must be authorized by

Macrovision, and is intended for home and

other limited viewing uses only unless

otherwise authorized by Macrovision.

Reverse engineering or disassembly is

prohibited.

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US04PRE2-CEK.fm

master page=left

10

DVP-NS75H

2-662-865-11(1)

Index to Parts and Controls

For more information, see the pages indicated in parentheses.

Front panel

A[/1 (on/standby) button (25)

BDisc tray (25)

CFront panel display (11)

DHDMI* (High-Definition Multimedia

Interface) indicator (18, 63, 66, 73)

Lights up when the HDMI OUT jack is

correctly connected to a HDCP (High-

bandwidth Digital Content Protection)

compliant device with HDMI or DVI

(Digital Visual Interface) input.

EA (open/close) button (25)

FH (play) button (25)

Gx (stop) button (26)

H./> (previous/next) buttons (34)

IPROGRESSIVE button/indicator (20)

Lights up when the player outputs

progressive signals.

J (remote sensor) (16)

* This player is based on version 1.1 of High-

Definition Multimedia Interface Specifications.

This DVD player incorporates High-Definition

Multimedia Interface (HDMI™) technology.

HDMI, the HDMI logo and High-Definition

Multimedia Interface are trademarks or registered

trademarks of HDMI Licensing LLC.

Rear panel

AHDMI OUT (high-definition

multimedia interface out) jack (17)

BDIGITAL OUT (OPTICAL) jack (21)

CDIGITAL OUT (COAXIAL) jack (21)

DLINE OUT L/R (AUDIO) jacks (21)

ELINE OUT (VIDEO) jack (17)

FS VIDEO OUT jack (17)

GCOMPONENT VIDEO OUT (Y, PB,

PR) jacks (17)

VIDEO

LINE OUT

S VIDEO OUT

P

R

YP

B

COMPONENT VIDEO OUT

AUDIO

RL

COAXIAL

DIGITAL OUT

OPTICAL

HDMI OUT

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US04PRE2-CEK.fm

master page=right

11

DVP-NS75H

2-662-865-11(1)

Front panel display

When playing back a DVD VIDEO/DVD-VR mode disc

When playing back a VIDEO CD with Playback Control (PBC) (29)

When playing back a CD, DATA CD (MP3 audio)/DATA DVD (MP3 audio) or VIDEO CD

(without PBC)

* When playing DATA DVDs, the DVD indicator is displayed.

When playing VIDEO CDs (without PBC), the VCD indicator is displayed.

Current title/chapter or playing

time (38)

Disc type

Current audio signal (42)

Lights up when you can change the angle (44)

Lights up during

Repeat Play (32)

Playing status

Disc type

Current scene or playing time (38)

Playing status

Lights up during A-B Repeat Play (33)

Playing time (38)

Disc type*

Current track (38)

Lights up during

Repeat Play (32)

Lights up when playing MP3 audio tracks (50)

Playing status

,continued

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US04PRE2-CEK.fm

master page=left

12

DVP-NS75H

2-662-865-11(1)

Remote

ATV [/1 (on/standby) button (59)

BZ OPEN/CLOSE button (26)

CNumber buttons (28)

The number 5 button has a tactile dot.*

DCLEAR button (30)

ETOP MENU button (28)

FC/X/x/c buttons (28)

GO RETURN button (26)

H/ REPLAY/STEP/

ADVANCE/STEP buttons (26, 35)

I./> PREV/NEXT (previous/

next) buttons (26)

J m/M SCAN/SLOW

buttons (35)

KZOOM button (26, 53)

LSLOW PLAY/FAST PLAY buttons

(26)

MAUDIO button (41)

NSUBTITLE button (44)

O[/1 (on/standby) button (25)

PVOL (volume) +/– buttons (59)

The + button has a tactile dot.*

QTV/VIDEO button (59)

RPICTURE NAVI (picture navigation)

button (37, 53)

STIME/TEXT button (38)

TMENU button (28)

UENTER button (23)

VDISPLAY button (13)

WH PLAY button (25)

The H button has a tactile dot.*

Xx STOP button (26)

YX PAUSE button (26)

ZSUR (surround) button (42)

wj ANGLE button (44)

* Use the tactile dot as a reference when operating

the player.

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US04PRE2-CEK.fm

master page=right

13

DVP-NS75H

2-662-865-11(1)

Guide to the Control Menu Display

Use the Control Menu to select a function and to view related information. Press DISPLAY

repeatedly to turn on or change the Control Menu display as follows:

Control Menu display

The Control Menu display 1 and 2 will show different items depending on the disc type. For

details about each item, see the pages in parentheses.

Example: Control Menu display 1 when playing a DVD VIDEO.

*1Displays the scene number for VIDEO CDs

(PBC is on), track number for VIDEO CDs/

CDs, album number for DATA CDs/DATA

DVDs.

*2Displays the index number for VIDEO CDs,

MP3 audio track number or JPEG image file

number for DATA CDs/DATA DVDs.

*3Displays Super VCD as “SVCD.”

*4Displays the date for JPEG files.

To turn off the display

Press DISPLAY repeatedly.

Control Menu display 1

m

Control Menu display 2 (appears for certain discs only)

m

Control Menu display off

,

OFF

OFF

SET

ON

PLAY

1 8 ( 3 4 )

1 2 ( 2 7 )

T

1 : 3 2 : 5 5

DVD VIDEO

Quit:

PROGRAM ENTER DISPLAY

Currently playing chapter number*2

Playing time*4

Total number of chapters*2

Options

Current setting

Total number of titles*1

Playback status

(N Playback,

X Pause,

x Stop, etc.)

Function name of

selected Control

Menu item

Operation message

Selected item

Control Menu items Type of disc

being played*3

Currently playing title number*1

,continued

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US04PRE2-CEK.fm

master page=left

14

DVP-NS75H

2-662-865-11(1)

List of Control Menu items

Item Item Name, Function

TITLE (page 35)/SCENE (page 35)/TRACK (page 35)

Selects the title, scene or track to be played.

CHAPTER (page 35)/INDEX (page 35)

Selects the chapter or index to be played.

TRACK (page 35)

Selects the track to be played.

ORIGINAL/PLAY LIST (page 28)

Selects the type of titles (DVD-RW/DVD-R in VR mode) to be played, the ORIGINAL

one, or an edited PLAY LIST.

TIME/TEXT (page 35)

Checks the elapsed time and the remaining playback time.

Input the time code for picture and music searching.

Displays the DVD/CD text or the DATA CD/DATA DVD track/file name.

PROGRAM (page 30)

Selects the title, chapter or track to play in the order you want.

SHUFFLE (page 32)

Plays the title, chapter or track in random order.

REPEAT (page 32)

Plays the entire disc (all titles/all tracks/all albums) repeatedly or one title/chapter/track/

album repeatedly.

A-B REPEAT (page 33)

Specifies the parts you want to play repeatedly.

CUSTOM PICTURE MODE (page 45)

Adjusts the video signal from the player. You can select the picture quality that best suits

the program you are watching.

SHARPNESS (page 46)

Exaggerates the outline of the image to produce a sharper picture.

BNR (page 47)

Adjusts the picture quality by reducing the “block noise” or mosaic like patterns that

appear on your TV screen.

MNR (page 47)

Adjusts the picture quality by reducing the faint noise appearing around the outlines of

the images.

AV SYNC (page 49)

Adjust the delay between the picture and sound.

PARENTAL CONTROL (page 56)

Set to prohibit playback on this player.

SETUP (page 61)

QUICK Setup (page 23)

Use Quick Setup to choose the desired language of the on-screen display, the aspect ratio

of the TV and the audio output signal.

CUSTOM Setup

In addition to the Quick Setup setting, you can adjust various other settings.

RESET

Returns the settings in “SETUP” to the default setting.

ALBUM (page 50)

Selects the album that contains MP3 audio track and JPEG image file to be played.

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US04PRE2-CEK.fm

master page=right

15

DVP-NS75H

2-662-865-11(1)

zHint

The Control Menu icon indicator lights up in green

when you select any item

except “OFF” (“PROGRAM,” “SHUFFLE,”

“REPEAT,” “A-B REPEAT,” “CUSTOM

PICTURE MODE,” “SHARPNESS,” “BNR,”

“MNR” only). The “ORIGINAL/PLAY LIST”

indicator lights up in green when you select “PLAY

LIST” (default setting). The “AV SYNC” indicator

lights up in green when set to more than 0 ms.

FILE (page 35)

Selects the JPEG image file to be played.

DATE (page 53)

Displays the date the picture was taken by a digital camera.

INTERVAL (page 55)

Specifies the duration for which the slides are displayed on the screen.

EFFECT (page 55)

Selects the effects to be used for changing slides during a slide show.

MODE (MP3, JPEG) (page 54)

Selects the data type; MP3 audio track (AUDIO), JPEG image file (IMAGE) or both

(AUTO) to be played when playing a DATA CD or DATA DVD.

t

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US05GET-CEK.fm

master page=left

16

DVP-NS75H

2-662-865-11(1)

Hookups

Hooking Up the Player

Follow steps 1 to 6 to hook up and adjust the settings of the player.

Notes

• Plug cords securely to prevent unwanted noise.

• Refer to the instructions supplied with the components to be connected.

• You cannot connect this player to a TV that does not have a video input jack.

• Be sure to disconnect the power cord of each component before connecting.

Step 1: Unpacking

Check that you have the following items:

• Audio/Video cord (phono plug × 3 y phono plug × 3) (1)

• Remote commander (remote) (1)

• Size AA (R6) batteries (2)

Step 2: Inserting Batteries Into the Remote

You can control the player using the supplied remote. Insert two Size AA (R6) batteries by

matching the 3 and # ends on the batteries to the markings inside the compartment. When

using the remote, point it at the remote sensor on the player.

Notes

• Do not leave the remote in an extremely hot or humid place.

• Do not drop any foreign object into the remote casing, particularly when replacing the batteries.

• Do not expose the remote sensor to direct light from the sun or a lighting apparatus. Doing so may cause a

malfunction.

• If you do not use the remote for an extended period of time, remove the batteries to avoid possible damage

from battery leakage and corrosion.

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US05GET-CEK.fm

master page=right

17

Hookups

DVP-NS75H

2-662-865-11(1)

Step 3: Connecting the Video Cords/HDMI Cords

Connect this player to your TV monitor, projector or AV amplifier (receiver) using a video cord.

Select one of the patterns A through D, according to the input jack on your TV monitor,

projector or AV amplifier (receiver).

In order to view progressive signal (480p) pictures with a compatible TV, projector or monitor,

you must use pattern C. Select pattern D when connecting to a TV, projector or AV amplifier

(receiver) equipped with HDMI input.

COAXIAL

DIGITAL OUT

OPTICAL

A

VIDEO

AUDIO

INPUT

L

R

C

P

R

P

B

Y

COMPONENT

VIDEO IN

B

INPUT

S VIDEO

D

IN

P

R

YP

B

COMPONENT VIDEO OUT

AUDIO

RL

S VIDEO OUT

VIDEO

LINE OUT

HDMI OUT

Audio/video

cord

(supplied)

l : Signal flow

S VIDEO cord

(not supplied)

(yellow)

TV, projector or AV

amplifier (receiver)

CD/DVD player

TV, projector or AV

amplifier (receiver)

(green)

Component

video cord

(not supplied)

TV, projector or AV

amplifier (receiver)

(red)

(blue)

(yellow)

to LINE OUT (VIDEO)

to COMPONENT

VIDEO OUT

to S VIDEO OUT

(green)

(blue)

(red)

TV, projector or AV

amplifier (receiver)

HDMI cord

(not supplied)

to HDMI OUT

,continued

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US05GET-CEK.fm

master page=left

18

DVP-NS75H

2-662-865-11(1)

A If you are connecting to a video input jack

Connect the yellow plug of an audio/video cord (supplied) to the yellow (video) jack. You will

enjoy standard quality images.

With this connection, select “NORMAL (INTERLACE)” (default) by pressing the

PROGRESSIVE button on the front panel.

B If you are connecting to an S VIDEO input jack

Connect an S VIDEO cord (not supplied). You will enjoy high quality images.

With this connection, select “NORMAL (INTERLACE)” (default) by pressing the

PROGRESSIVE button on the front panel.

C If you are connecting to a monitor, projector or AV amplifier

(receiver) having component video input jacks (Y, PB, PR)

Connect the component via the COMPONENT VIDEO OUT jacks using a component video

cord (not supplied) or three video cords (not supplied) of the same kind and length. You will

enjoy accurate color reproduction and high quality images.

If your TV accepts progressive 480p format signals, use this connection and press the

PROGRESSIVE button on the front panel to output progressive signals. For details, see “Using

the PROGRESSIVE button” (page 20).

D If you are connecting to an HDMI/DVI input jack

Use a certified Sony HDMI cord (not supplied) to enjoy high quality digital picture and sound

through the HDMI OUT jack. When connecting to the HDMI OUT jack, carefully align the

HDMI connector with the jack. Do not bend and apply pressure to the HDMI cord.

To connect to a TV with DVI input

Use an HDMI-DVI converter cord (not supplied). The DVI jack will not accept any audio

signals, so you have to use another audio connection in addition to this connection (page 21).

Furthermore, you cannot connect the HDMI OUT jack to DVI jacks that are not HDCP

compliant (e.g., DVI jacks on PC displays).

Yellow

White (L)

Red (R)

Yellow

White (L)

Red (R)

Green

Blue

Red

Green

Blue

Red

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US05GET-CEK.fm

master page=right

19

Hookups

DVP-NS75H

2-662-865-11(1)

When connecting to a standard 4:3 screen TV

Depending on the disc, the image may not fit your TV screen. To change the aspect ratio, see

page 63.

Notes

• Do not connect a VCR, etc., between your TV and the player. If you pass the player signals via the VCR,

you may not receive a clear image on the TV screen. If your TV has only one audio/video input jack,

connect the player to this jack.

• If the picture appears too white when you are using A or B connection, set “BLACK LEVEL” in

“SCREEN SETUP” to “OFF” (page 64).

VCR

CD/DVD player TV

Connect

directly

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US05GET-CEK.fm

master page=left

20

DVP-NS75H

2-662-865-11(1)

Using the PROGRESSIVE button

By using the PROGRESSIVE button on the front panel, you can select the signal format in

which the player outputs video signals (Progressive or Interlace), and the conversion method for

progressive signals. The PROGRESSIVE indicator lights up when the player outputs

progressive signals.

Each time you press PROGRESSIVE, the display changes as follows:

PROGRESSIVE AUTO

m

PROGRESSIVE VIDEO

m

NORMAL (INTERLACE)

◆PROGRESSIVE AUTO

Select this setting when:

– your TV accepts progressive signals, and,

– the TV is connected to the COMPONENT VIDEO OUT jacks.

Normally select this under the above condition. This automatically detects the software type, and

selects the appropriate conversion method.

Note that the picture will not be clear or no picture will appear if you select these settings when

either of the above conditions is not met.

◆PROGRESSIVE VIDEO

Select this setting when:

– your TV accepts progressive signals, and,

– the TV is connected to the COMPONENT VIDEO OUT jacks, and,

– you want to fix the conversion method to PROGRESSIVE VIDEO for video-based software.

Select this if the image is not clear when you select PROGRESSIVE AUTO.

Note that the picture will not be clear or no picture will appear if you select these settings when

either of the above conditions is not met.

◆NORMAL (INTERLACE)

Select this setting when:

– your TV does not accept progressive signals, or,

– your TV is connected to jacks other than the COMPONENT VIDEO OUT jacks (LINE OUT

(VIDEO) or S VIDEO OUT).

You cannot select this setting while the HDMI indicator is lit.

About DVD software types and the conversion method

DVD software can be divided into two types: film-based software and video based software.

Video-based software is derived from TV, such as dramas and sit-coms, and displays images at

30 frames/60 fields per second. Film-based software is derived from film and displays images at

24 frames per second. Some DVD software contains both video and film.

In order for these images to appear natural on your screen when output in progressive format,

the progressive signals need to be converted to match the type of DVD software that you are

watching.

Note

When you play video-based software in progressive signal format, sections of some types of images may

appear unnatural due to the conversion process when output through the COMPONENT VIDEO OUT jacks.

Images from the S VIDEO OUT and LINE OUT (VIDEO) jacks are unaffected as they are output in the

normal (interlace) format.

,

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US05GET-CEK.fm

master page=right

21

Hookups

DVP-NS75H

2-662-865-11(1)

Step 4: Connecting the Audio Cords

Select one of the following patterns A or B, according to the input jack on your TV monitor,

projector or AV amplifier (receiver).

This will enable you to listen to sound.

zHint

For correct speaker location, see the operating instructions supplied with the connected components.

P

R

YP

B

COMPONENT VIDEO OUT

AUDIO

RL

S VIDEO OUT

VIDEO

LINE OUT

VIDEO

AUDIO

INPUT

L

R

B

A

COAXIAL

DIGITAL OUT

OPTICAL

AUDIO

RL

VIDEO

LINE OUT

HDMI OUT

HDMI OUT

COAXIAL

DIGITAL OUT

OPTICAL

AV amplifier (receiver)

with a decoder

(red)

TV, projector, or AV

amplifier (receiver)

Audio/video

cord (supplied)

: Signal flow

Coaxial digital cord

(not supplied)

to LINE OUT L/R (AUDIO)

Rear (L)

CD/DVD player

(white)

(yellow)*

(yellow)*

(white)

(red)

[Speakers]

Front (L)

[Speakers]

to coaxial or optical/

HDMI digital input

Rear (R)

Front (R)

Subwoofer

Center

* The yellow plug is used for video signals (page 17).

or

Optical digital cord

(not supplied)

Remove jack cap

before connecting

or

HDMI cord (not supplied)

to DIGITAL OUT (COAXIAL or OPTICAL)/HDMI OUT

,continued

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US05GET-CEK.fm

master page=left

22

DVP-NS75H

2-662-865-11(1)

A Connecting to audio L/R input

jacks

This connection will use your TV’s or stereo

amplifier’s (receiver’s) two speakers for

sound. Connect using the audio/video cord

(supplied).

• Surround effect (page 43)

TV: Dynamic Theater, Dynamic, Wide,

Night

Stereo amplifier (receiver): Standard, Night

B Connecting to a digital audio

input jack

If your AV amplifier (receiver) has a Dolby

Digital*1 or DTS*2 decoder and a digital

input jack, use this connection.

Connect using a coaxial or optical digital

cord/HDMI cord (not supplied).

• Surround effect

Dolby Digital (5.1ch), DTS (5.1ch)

*1 Manufactured under license from Dolby

Laboratories. “Dolby,” “Pro Logic,” and the

double-D symbol are trademarks of Dolby

Laboratories.

*2“DTS” and “DTS Digital Out” are trademarks of

Digital Theater Systems, Inc.

Notes

• After you have completed the connection, be sure

to set “DOLBY DIGITAL” to “DOLBY

DIGITAL” and “DTS” to “ON” in Quick Setup

(page 23).

• When you connect an amplifier (receiver) that

conforms to the 96 kHz sampling frequency, set

“48kHz/96kHz PCM” in “AUDIO SETUP” to

“96kHz/24bit” (page 68).

• The TVS effects of this player cannot be used

with this connection.

• When you connect the player to an AV amplifier

(receiver) using an HDMI cord, you will need to

do one of the following:

– Connect the AV amplifier (receiver) to the TV

with the HDMI cord.

– Connect the player to the TV with a video cord

other than HDMI cord (component video cord, S

VIDEO cord, or audio/video cord).

• When connecting to the HDMI OUT jack,

carefully align the HDMI connector with the jack.

Do not bend and apply pressure to the HDMI

cord.

Yellow

White (L)

Red (R)

Yellow

White (L)

Red (R)

Optical cord

HDMI cord

Coaxial cord

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US05GET-CEK.fm

master page=right

23

Hookups

DVP-NS75H

2-662-865-11(1)

Step 5: Connecting the Power Cord

Plug the player and TV power cords into an AC outlet.

Step 6: Quick Setup

Follow the steps below to make the minimum number of basic adjustments for using the player.

To skip an adjustment, press >. To return to the previous adjustment, press ..

1Turn on the TV.

2Press [/1.

3Switch the input selector on your

TV so that the signal from the

player appears on the TV screen.

“Press [ENTER] to run QUICK SETUP”

(press enter to run Quick Setup) appears

at the bottom of the screen. If this

message does not appear, select

“QUICK” (quick) under “SETUP”

(setup) in the Control Menu to run Quick

Setup (page 62).

4Press ENTER without inserting a

disc.

The Setup Display for selecting the

language used in the on-screen display

appears.

5Press X/x to select a language.

The player displays the menu and

subtitles in the selected language.

6Press ENTER.

The Setup Display for selecting the

aspect ratio of the TV to be connected

appears.

ENTE

R

LANGUAGE SETUP

OSD:

MENU:

AUDIO:

SUBTITLE: FRENCH

ENGLISH

ENGLISH

SPANISH

PORTUGUESE

SCREEN SETUP

TV TYPE: 16:9

4:3 PAN SCAN

4:3 LETTER BOX

ON

OFF

HDMI RESOLUTION:

SCREEN SAVER: JACKET PICTURE

BACKGROUND:

YC

B

C

R

/RGB (HDMI):

BLACK LEVEL:

BLACK LEVEL

(COMPONENT OUT)

:FULL

4:3 OUTPUT:

16:9

,continued

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US05GET-CEK.fm

master page=left

24

DVP-NS75H

2-662-865-11(1)

7Press X/x to select the setting that

matches your TV type.

◆If you have a 4:3 standard TV

• 4:3 LETTER BOX or 4:3 PAN SCAN

(page 63)

◆If you have a wide-screen TV or a 4:3

standard TV with a wide-screen mode

• 16:9 (page 63)

8Press ENTER.

The Setup Display for selecting the type

of jack used to connect your amplifier

(receiver) appears.

9Press X/x to select the type of jack

(if any) you are using to connect to

an amplifier (receiver), then press

ENTER.

If you did not connect an AV amplifier

(receiver), select “NO,” then go to step

13.

If you connected an AV amplifier

(receiver) using just an audio cord, select

“YES: LINE OUTPUT L/R (AUDIO),”

then go to step 13.

If you connected an AV amplifier

(receiver) using a digital coaxial or

optical/HDMI cord, select “YES:

DIGITAL OUTPUT.”

10Press X/x to select the type of

Dolby Digital signal you wish to

send to your amplifier (receiver).

If your AV amplifier (receiver) has a

Dolby Digital decoder, select “DOLBY

DIGITAL.” Otherwise, select “D-PCM.”

11Press ENTER.

“DTS” is selected.

12Press X/x to select whether or

not you wish to send a DTS signal

to your amplifier (receiver).

If your AV amplifier (receiver) has a

DTS decoder, select “ON.” Otherwise,

select “OFF.”

13Press ENTER.

Quick Setup is finished. All connections

and setup operations are complete.

Is this player connected to an amplifier

(receiver)? Select the type of jack you

are using.

LINE OUTPUT L/R(AUDIO)

DIGITAL OUTPUT

YES

NO

AUDIO SETUP

AUDIO ATT:

AUDIO DRC:

DIGITAL OUT:

DOLBY DIGITAL:

OFF

STANDARD

AUDIO FILTER: SHARP

ON

DOWNMIX: DOLBY SURROUND

D-PCM

D-PCM

48kHz/96kHz PCM:

DTS: DOLBY DIGITAL

AUDIO SETUP

AUDIO ATT:

AUDIO DRC:

DIGITAL OUT:

DOLBY DIGITAL:

OFF

STANDARD

AUDIO FILTER: SHARP

ON

DOWNMIX: DOLBY SURROUND

D-PCM

OFF

48kHz/96kHz PCM: ON

DTS: OFF

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US06PLY1-CEK.fm

master page=right

25

Playing Discs

DVP-NS75H

2-662-865-11(1)

Playing Discs

Playing Discs

Depending on the DVD or VIDEO CD, some

operations may be different or restricted.

Refer to the operating instructions supplied

with your disc.

1Turn on your TV.

2Press [/1.

The player turns on.

3Switch the input selector on your

TV so that the signal from the

player appears on the TV screen.

◆When using an amplifier (receiver)

Turn on the amplifier (receiver) and

select the appropriate channel so that you

can hear sound from the player.

4Press A on the player, and place a

disc on the disc tray.

5Press H.

The disc tray closes. The player starts

playback (continuous play). Adjust the

volume on the TV or the amplifier

(receiver).

Depending on the disc, a menu may

appear on the TV screen. For DVD

VIDEOs, see page 28. For VIDEO CDs,

see page 29.

To turn off the player

Press [/1. The player enters standby mode.

zHint

You can have the player turn off automatically

whenever you leave it in stop mode for more than

30 minutes. To turn this function on or off, set

“AUTO POWER OFF” in “CUSTOM SETUP” to

“ON” or “OFF” (page 65).

Notes on playing DTS sound tracks on a

DVD VIDEO

• DTS audio signals are output only through

the DIGITAL OUT (COAXIAL or

OPTICAL)/HDMI OUT jack.

• When you play a DVD VIDEO with DTS

sound tracks, set “DTS” to “ON” in

“AUDIO SETUP” (page 68).

• If you connect the player to audio

equipment without a DTS decoder, do not

set “DTS” to “ON” in “AUDIO SETUP”

(page 68). A loud noise may come out from

the speakers, affecting your ears or causing

the speakers to be damaged.

Note

Discs created on DVD recorders must be correctly

finalized before they can be played. For more

information about finalizing, refer to the operating

instructions supplied with the DVD recorder.

ENTER

RETURN

Playback side facing down

,continued

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US06PLY1-CEK.fm

master page=left

26

DVP-NS75H

2-662-865-11(1)

Additional operations

*1DVD VIDEOs/DVD-RWs/DVD-Rs only

*2DVD VIDEOs/DVD-RWs/DVD-Rs/

DVD+RWs/DVD+Rs only

*3Video and JPEG pictures only (except

BACKGROUND pictures). You can move the

enlarged picture using C/X/x/c. Depending

upon the contents of the disc, the zoom function

may be canceled automatically when the picture

is moved.

Note

You may not be able to use the Replay or Advance

function with some scenes.

Playback quickly or slowly with

sound

You can listen to dialog or sound while

playing the current scene quickly or slowly.

During playback, press FAST PLAY or

SLOW PLAY.

The speed changes when you press either

FAST PLAY or SLOW PLAY.

To return to normal playback

Press H.

Notes

• You can only use this function with DVDs/

VIDEO CDs/Super VCDs and DVD-RWs/DVD-

Rs in VR mode only.

• “Operation not possible” will appear when

maximum or minimum speed is reached.

• During Fast Play or Slow Play mode, you cannot

change the angle (page 44), subtitle (page 44), or

sound (page 41). The sound can only be changed

for VIDEO CDs/Super VCDs.

• Fast Play and Slow Play functions do not work

when playing DTS sound tracks.

• You cannot use Fast Play or Slow Play functions

when playing a still picture on DVD-RW/DVD-R

in VR mode.

Locking the disc tray (Child

Lock)

You can lock the disc tray to prevent children

from opening it.

When the player is in standby mode, press

ORETURN, ENTER and then [/1 on the

remote.

The player turns on and “LOCKED” appears

on the front panel display. The A and Z

buttons on the player or the remote do not

work while the Child Lock is set.

To unlock the disc tray

When the player is in standby mode, press

ORETURN, ENTER and then [/1 again.

Note

Even if you select “RESET” under “SETUP” in the

Control Menu (page 62), the disc tray remains

locked.

To Operation

Stop Press x

Pause Press X

Resume play after

pause Press X or H

Go to the next chapter,

track or scene in

continuous play mode

Press >

Go back to the

previous chapter,

track or scene in

continuous play mode

Press .

Stop play and remove

the disc Press Z

Replay the previous

scene*1Press

REPLAY during

playback

Briefly fast forward

the current scene*2Press

ADVANCE during

playback

Magnify the image*3Press ZOOM

repeatedly. Press

CLEAR to cancel.

CLEAR

REPLAY

ZOOM

SLOW PLAY FAST PLAY

ADVANCE

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US06PLY1-CEK.fm

master page=right

27

Playing Discs

DVP-NS75H

2-662-865-11(1)

Resuming Playback From

the Point Where You

Stopped the Disc (Multi-disc

Resume)

The player stores the point where you stopped

the disc for up to 6 discs and resumes

playback the next time you insert the same

disc. If you store a resume playback point for

the 7th disc, the resume playback point for the

first disc is deleted.

1While playing a disc, press x to

stop playback.

“RESUME” appears on the front panel

display.

2Press H.

The player starts playback from the point

where you stopped the disc in step 1.

zHint

To play from the beginning of the disc, press x

twice, then press H.

Notes

• “MULTI-DISC RESUME” in “CUSTOM

SETUP” must be set to “ON” (default) for this

function to work (page 65).

• The point where you stopped playing is cleared

when:

– you change the play mode.

– you change the settings on the Setup Display.

• For DVD-RWs/DVD-Rs in VR mode, CDs,

DATA CDs, and DATA DVDs the player

remembers the resume playback point for the

current disc.

The resume point is cleared when:

– you opened the disc tray.

– you disconnect the power cord.

– the player enters standby mode (DATA CD/

DATA DVD only).

• Resume Play does not work during Shuffle Play

and Program Play.

• This function may not work with some discs.

• If “MULTI-DISC RESUME” in “CUSTOM

SETUP” is set to “ON” and you playback a

recorded disc such as DVD-RW, the player may

playback other recorded discs from the same

resume point.

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US06PLY1-CEK.fm

master page=left

28

DVP-NS75H

2-662-865-11(1)

Using the DVD’s Menu

A DVD is divided into long sections of a

picture or a music feature called “titles.”

When you play a DVD which contains

several titles, you can select the title you want

using the TOP MENU button.

When you play DVDs that allow you to select

items such as language for the sound and

subtitles, select these items using the MENU

button.

1Press TOP MENU or MENU.

The disc’s menu appears on the TV

screen.

The contents of the menu vary from disc

to disc.

2Press C/X/x/c or the number

buttons to select the item you want

to play or change.

If you press the number buttons, the

following display appears.

Press the number buttons to select the

item you want.

3Press ENTER.

Selecting “ORIGINAL” or

“PLAY LIST” on a DVD-

RW/DVD-R

Some DVD-RWs/DVD-Rs in VR (Video

Recording) mode have two types of titles for

playback: originally recorded titles

(ORIGINAL) and titles that can be created on

recordable DVD players for editing (PLAY

LIST). You can select the type of title to be

played.

1Press DISPLAY when the player is

in stop mode.

The Control Menu appears.

2Press X/x to select

(ORIGINAL/PLAY LIST), then press

ENTER.

The options for “ORIGINAL/PLAY

LIST” appear.

3Press X/x to select a setting.

• PLAY LIST: plays the titles created

from “ORIGINAL” for editing.

• ORIGINAL: plays the titles originally

recorded.

4Press ENTER.

ENTER

MENUTOP MENU

Number

buttons

1

ENTER

DISPLAY

1 8 ( 3 4 )

1 2 ( 2 7 )

DVD-VR

PLAY LIST

PLAY LIST

ORIGINAL

T

1 : 3 2 : 5 5

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US06PLY1-CEK.fm

master page=right

29

Playing Discs

DVP-NS75H

2-662-865-11(1)

Playing VIDEO CDs With

PBC Functions (PBC Playback)

PBC (Playback Control) allows you to play

VIDEO CDs interactively by following the

menu on the TV screen.

1Start playing a VIDEO CD with PBC

functions.

The menu for your selection appears.

2Press the number buttons to select

the item number you want.

3Press ENTER.

4Follow the instructions in the

menu for interactive operations.

Refer to the instructions supplied with the

disc, as the operating procedure may

differ depending on the VIDEO CD.

To return to the menu

Press O RETURN.

zHint

To play without using PBC, press ./> or the

number buttons while the player is stopped to select

a track, then press H or ENTER.

“Play without PBC” appears on the TV screen and

the player starts continuous play. You cannot play

still pictures such as a menu.

To return to PBC playback, press x twice then

press H.

Note

Depending on the VIDEO CD, “Press ENTER” in

step 3 may appear as “Press SELECT” in the

instructions supplied with the disc. In this case,

press H.

ENTER

RETURN

Number

buttons

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US06PLY1-CEK.fm

master page=left

30

DVP-NS75H

2-662-865-11(1)

Various Play Mode

Functions (Program Play,

Shuffle Play, Repeat Play, A-B Repeat

Play)

You can set the following play modes:

• Program Play (page 30)

• Shuffle Play (page 32)

• Repeat Play (page 32)

• A-B Repeat Play (page 33)

Note

The play mode is canceled when:

– you open the disc tray.

– the player enters standby mode by pressing [/1.

Creating your own program

(Program Play)

You can play the contents of a disc in the

order you want by arranging the order of the

titles, chapters or tracks on the disc to create

your own program. You can program up to 99

titles, chapters and tracks.

1Press DISPLAY.

The Control Menu appears.

2Press X/x to select

(PROGRAM), then press ENTER.

The options for “PROGRAM” appear.

3Press X/x to select “SET t,” then

press ENTER.

4Press c.

The cursor moves to the title or track row

“T” (in this case, “01”).

CLEAR ENTER

DISPLAY

OFF

OFF

SET

ON

PLAY

1 8 ( 3 4 )

1 2 ( 2 7 )

T

1 : 3 2 : 5 5

DVD VIDEO

PROGRAM

1. TITLE

ALL CLEAR

2. TITLE – –

3. TITLE – –

4. TITLE – –

5. TITLE – –

6. TITLE – –

7. TITLE – –

T

– –

01

02

03

04

05

“TRACK” is displayed when you play

a VIDEO CD or CD.

Titles or tracks

recorded on a disc

PROGRAM

1. TITLE – –

ALL CLEAR

2. TITLE – –

3. TITLE – –

4. TITLE – –

5. TITLE – –

6. TITLE – –

7. TITLE – –

TC

ALL

01

02

03

04

05

06

– –

02

03

04

05

01

Chapters recorded on a disc

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US06PLY1-CEK.fm

master page=right

31

Playing Discs

DVP-NS75H

2-662-865-11(1)

5Select the title, chapter or track you

want to program.

◆When playing a DVD VIDEO

For example, select chapter “03” of title

“02.”

Press X/x to select “02” under “T,” then

press ENTER.

Next, press X/x to select “03” under “C,”

then press ENTER.

◆When playing a VIDEO CD or CD

For example, select track “02.”

Press X/x to select “02” under “T,” then

press ENTER.

6To program other titles, chapters or

tracks, repeat steps 4 to 5.

The programmed titles, chapters and

tracks are displayed in the selected order.

7Press H to start Program Play.

Program Play begins.

When the program ends, you can restart

the same program again by pressing H.

To return to normal play

Press CLEAR or select “OFF” in step 3. To

play the same program again, select “ON” in

step 3 and press ENTER.

To change or cancel a program

1Follow steps 1 to 3 of “Creating your own

program (Program Play).”

2Select the program number of the title,

chapter or track you want to change or

cancel using X/x and press c. If you

want to delete the title, chapter or track

from the program, press CLEAR.

3Follow step 5 for new programming. To

cancel a program, select “--” under “T,”

then press ENTER.

To cancel all of the titles, chapters or

tracks in the programmed order

1Follow steps 1 to 3 of “

Creating your own

program (Program Play).”

2Press X and select “ALL CLEAR.”

3Press ENTER.

zHint

You can perform Repeat Play or Shuffle Play of

programmed titles, chapters or tracks. During

Program Play, follow the steps of Repeat Play (page

32) or Shuffle Play (page 32).

Notes

• When you program tracks on a Super VCD, the

total playing time is not displayed.

• You cannot use this function with VIDEO CDs or

Super VCDs with PBC playback.

PROGRAM

1. TITLE – –

ALL CLEAR

2. TITLE – –

3. TITLE – –

4. TITLE – –

5. TITLE – –

6. TITLE – –

7. TITLE – –

C

ALL

03

04

05

06

T

– –

01

02

03

04

05

02

01

T

– –

01

02

03

04

05

PROGRAM

1. TITLE 0 2 – 0 3

ALL CLEAR

2. TITLE – –

3. TITLE – –

4. TITLE – –

5. TITLE – –

6. TITLE – –

7. TITLE – –

Selected title and chapter

PROGRAM

1. TRACK 0 2

ALL CLEAR

2. TRACK – –

3. TRACK – –

4. TRACK – –

5. TRACK – –

6. TRACK – –

7. TRACK – –

0:15:30

– –

01

02

03

04

05

T

Selected track

Total time of the programmed tracks

,continued

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US06PLY1-CEK.fm

master page=left

32

DVP-NS75H

2-662-865-11(1)

Playing in random order (Shuffle

Play)

You can have the player “shuffle” titles,

chapters or tracks. Subsequent “shuffling”

may produce a different playing order.

1Press DISPLAY during playback.

The Control Menu appears.

2Press X/x to select

(SHUFFLE), then press ENTER.

The options for “SHUFFLE” appear.

3Press X/x to select the item to be

shuffled.

◆When playing a DVD VIDEO

•TITLE

•CHAPTER

◆When playing a VIDEO CD or CD

•TRACK

◆When Program Play is activated

•ON: shuffles titles, chapters or tracks

selected in Program Play.

4Press ENTER.

Shuffle Play starts.

To return to normal play

Press CLEAR or select “OFF” in step 3.

zHints

• You can set Shuffle Play while the player is

stopped. After selecting the “SHUFFLE” option,

press H. Shuffle Play starts.

• Up to 200 chapters in a disc can be played in

random order when “CHAPTER” is selected.

Note

You cannot use this function with VIDEO CDs or

Super VCDs with PBC playback.

Playing repeatedly (Repeat Play)

You can play all of the titles or tracks on a

disc, or a single title, chapter or track

repeatedly.

You can use a combination of Shuffle or

Program Play modes.

1Press DISPLAY during playback.

The Control Menu appears.

2Press X/x to select

(REPEAT), then press ENTER.

The options for “REPEAT” appear.

3Press X/x to select the item to be

repeated.

◆When playing a DVD VIDEO

•DISC: repeats all of the titles.

•TITLE: repeats the current title on a

disc.

•CHAPTER: repeats the current

chapter.

◆When playing a DVD-VR mode disc

•DISC: repeats all the titles of the

selected type.

•TITLE: repeats the current title on a

disc.

•CHAPTER: repeats the current

chapter.

◆When playing a VIDEO CD or CD

•DISC: repeats all of the tracks.

•TRACK: repeats the current track.

◆When playing a DATA CD or DATA DVD

with MP3 audio tracks or JPEG image

files

•DISC: repeats all of the albums.

•ALBUM: repeats the current album.

•TRACK (MP3 audio tracks only):

repeats the current track.

◆When Program Play or Shuffle Play is

activated

•ON: repeats Program Play or Shuffle

Play.

PLAY

1 8 ( 3 4 )

1 2 ( 2 7 )

T

1 : 3 2 : 5 5

OFF

CHAPTER

TITLE

OFF

DVD VIDEO

DISC

TITLE

CHAPTER

OFF

1 8 ( 3 4 )

1 2 ( 2 7 )

T

1 : 3 2 : 5 5

DVD VIDEO

OFF

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US06PLY1-CEK.fm

master page=right

33

Playing Discs

DVP-NS75H

2-662-865-11(1)

4Press ENTER.

Repeat Play starts.

To return to normal play

Press CLEAR or select “OFF” in step 3.

zHint

You can set Repeat Play while the player is stopped.

After selecting the “REPEAT” option, press H.

Repeat Play starts.

Notes

• You cannot use this function with VIDEO CDs or

Super VCDs with PBC playback.

• When repeating a DATA CD/DATA DVD which

contains MP3 audio tracks and JPEG image files,

and their playing times are not the same, the sound

will not match the image.

• When “MODE (MP3, JPEG)” is set to “IMAGE

(JPEG)” (page 54), you cannot select “TRACK.”

Repeating a specific portion

(A-B Repeat Play)

You can play a specific portion of a title,

chapter or track repeatedly. (This function is

useful when you want to memorize lyrics,

etc.)

1Press DISPLAY during playback.

The Control Menu appears.

2Press X/x to select (A-B

REPEAT), then press ENTER.

The options for “A-B REPEAT”

appear.

3Press X/x to select “SET t,” then

press ENTER.

The “A-B REPEAT” setting bar appears.

4During playback, when you find the

starting point (point A) of the portion to

be played repeatedly, press ENTER.

The starting point (point A) is set.

5When you reach the ending point

(point B), press ENTER again.

The set points are displayed and the

player starts repeating this specific

portion.

To return to normal play

Press CLEAR or select “OFF” in step 3.

Notes

• When you set A-B Repeat Play, the settings for

Shuffle Play, Repeat Play and Program Play are

canceled.

• A-B Repeat Play does not work across multiple

titles.

• You may not set A-B Repeat Play for contents on

a DVD-RW/DVD-R (VR mode) that contains still

pictures.

PLAY

SET

OFF

OFF

1 8 ( 3 4 )

1 2 ( 2 7 )

T

1 : 3 2 : 5 5

DVD VIDEO

A 18 - 1:32:30 B

A 18 - 1:32:55 B 18 - 1:33:05

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US07PLY2-CEK.fm

master page=left

34

DVP-NS75H

2-662-865-11(2)

Searching for a Scene

Searching for a

Particular Point on a

Disc (Search, Scan, Slow-motion

Play, Freeze Frame)

You can quickly locate a particular point on a

disc by monitoring the picture or playing back

slowly.

Notes

• Depending on the disc, you may not be able to do

some of the operations described.

• For DATA CDs/DATA DVDs, you can search for

a particular point only on an MP3 audio track.

Locating a point quickly using

the PREV (previous)/NEXT (next)

buttons (Search)

You can search for the next or previous

chapter, track or scene using ./> on

the player.

During playback, press > or . once

briefly to go to the next or previous chapter/

track/scene. Or, press and hold > or .

to search forward or backwards and release

the button when you find the point you want

to return to normal playback. (Search)

Locating a point quickly by

playing a disc in fast forward or

fast reverse (Scan)

Press m or M while playing a

disc. When you find the point you want, press

H to return to normal speed. Each time you

press m or M during scan, the

scan speed changes. With each press the

indication changes as shown below. Actual

speeds may differ between discs.

Playback direction

Opposite direction

The “×2B”/ “×2b” playback speed is about

twice the normal speed.

The “3M”/“3m” playback speed is faster

than “2M”/“2m” and the “2M”/“2m”

playback speed is faster than “1M”/

“1m.”

STEP STEP

×2B t 1M t 2M t 3M

3M (DVD VIDEO/DVD-VR mode/

VIDEO CD only)

×2B (DVD VIDEO/CD only)

×2b t 1m t 2m t 3m

3m (DVD VIDEO/DVD-VR mode/

VIDEO CD only)

×2b (DVD VIDEO only)

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US07PLY2-CEK.fm

master page=right

35

Searching for a Scene

DVP-NS75H

2-662-865-11(2)

Watching frame by frame

(Slow-motion Play)

Press m or M when the player is

in pause mode. To return to normal speed,

press H.

Each time you press m or M

during Slow-motion Play, the playback speed

changes. Two speeds are available. With each

press the indication changes as follows:

Playback direction

2 y 1

Opposite direction (DVD/DVD-VR mode

only)

2 y 1

The “2 y”/“2 ” playback speed is slower

than “1 y”/“1 .”

Playing one frame at a time

(Freeze Frame)

When the player is in the pause mode, press

STEP to go to the next frame. Press

STEP to go to the preceding frame

(DVD/DVD-VR mode only). To return to

normal playback, press H.

Note

You cannot search for a still picture on a DVD-RW/

DVD-R in VR mode.

Searching for a Title/

Chapter/Track/Scene,

etc.

You can search a DVD by title or chapter, and

you can search a VIDEO CD/CD/DATA CD/

DATA DVD by track, index, file, or scene.

As titles and tracks are assigned unique

numbers on the disc, you can select the

desired one by entering its number. You can

also search for a scene using the time code.

1Press DISPLAY. (When playing a

DATA CD or DATA DVD with JPEG

image files, press twice.)

The Control Menu appears.

2Press X/x to select the search

method.

◆When playing a DVD VIDEO/DVD-VR

mode disc

TITLE

CHAPTER

TIME/TEXT

Select “TIME/TEXT” to search for a starting

point by inputting the time code.

ENTER

DISPLAY

CLEAR

Number

buttons

,continued

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US07PLY2-CEK.fm

master page=left

36

DVP-NS75H

2-662-865-11(2)

◆When playing a VIDEO CD or Super VCD

without PBC Playback

TRACK

INDEX

◆When playing a VIDEO CD or Super VCD

with PBC Playback

SCENE

◆When playing a CD

TRACK

◆When playing a DATA CD/DATA DVD

ALBUM

TRACK (MP3 audio tracks only)

FILE (JPEG image files only)

Example: when you select

CHAPTER

“** (**)” is selected (** refers to a number).

The number in parentheses indicates the total

number of titles, chapters, tracks, indexes,

scenes, albums or files.

3Press ENTER.

“** (**)” changes to “-- (**).”

4Press the number buttons to select

the title, chapter, track, index,

scene, etc., number you want to

search.

If you make a mistake

Cancel the number by pressing CLEAR,

then select another number.

5Press ENTER.

The player starts playback from the

selected number.

To search for a scene using the time code

(DVD VIDEO/DVD-VR mode only)

1In step 2, select TIME/TEXT.

“T **:**:**” (playing time of the current

title) is selected.

2Press ENTER.

“T **:**:**” changes to “T --:--:--.”

3Input the time code using the number

buttons, then press ENTER.

For example, to find the scene at 2 hours,

10 minutes and 20 seconds after the

beginning, just enter “2:10:20.”

zHints

• When the Control Menu display is turned off, you

can search for a chapter (DVD VIDEO/DVD-VR

mode) or track (CD/DATA CD/DATA DVD) by

pressing the number buttons and ENTER.

• You can display the first scene of titles, chapters

or tracks recorded on the disc on a screen divided

into 9 sections. You can start playback directly by

selecting one of the scenes. For details, see

“Searching by Scene (PICTURE

NAVIGATION)” (page 37).

Notes

• The title, chapter or track number displayed is the

same number recorded on the disc.

• You cannot search for a scene on a DVD+RW/

DVD+R using the time code.

PLAY

1 8 ( 3 4 )

1 2 ( 2 7 )

DVD VIDEO

T

1 : 3 2 : 5 5

Selected row

PLAY

DVD VIDEO

1 2 ( 2 7 )

T

1 : 3 2 : 5 5

( 3 4 )

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US07PLY2-CEK.fm

master page=right

37

Searching for a Scene

DVP-NS75H

2-662-865-11(2)

Searching by Scene

(PICTURE NAVIGATION)

You can divide the screen into 9 subscreens

and find the desired scene quickly.

1Press PICTURE NAVI during

playback.

The following display appears.

2Press PICTURE NAVI repeatedly to

select an item.

• CHAPTER VIEWER (DVD VIDEO

only): displays the first scene of each

chapter.

• TITLE VIEWER (DVD VIDEO only):

displays the first scene of each title.

• TRACK VIEWER (VIDEO CD/

Super VCD only): displays the first

scene of each track.

3Press ENTER.

The first scene of each chapter, title or

track appears as follows.

4Press C/X/x/c to select a chapter,

title or track, and press ENTER.

Playback starts from the selected scene.

To return to normal play during setting

Press O RETURN or DISPLAY.

zHint

If there are more than 9 chapters, titles or tracks, V

is displayed at the bottom right of the screen.

To display the additional chapters, titles or tracks,

select the bottom scenes and press x. To return to

the previous scene, select the top scenes and press

X.

Note

Depending on the disc, you may not be able to select

some items.

DISPLAY


NAVI

RETURN

ENTER

CHAPTER VIEWER

ENTER

1

4

7

2

5

8

3

6

9

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US08PLY3-CEK.fm

master page=left

38

DVP-NS75H

2-662-865-11(1)

Viewing Information About the

Disc

Checking the Playing

Time and Remaining

Time

You can check the playing time and

remaining time of the current title, chapter or

track. Also, you can check the DVD/CD text

or track name (MP3 audio) recorded on the

disc.

1Press TIME/TEXT during playback.

The following display appears.

2Press TIME/TEXT repeatedly to

change the time information.

The available time information depends

upon the type of disc you are playing.

◆When playing a DVD VIDEO or DVD-VR

mode disc

•T *:*:* (hours: minutes: seconds)

Playing time of the current title

•T–

*:*:*

Remaining time of the current title

•C *:*:*

Playing time of the current chapter

•C–

*:*:*

Remaining time of the current chapter

◆When playing a VIDEO CD or Super

VCD (with PBC functions)

•*:* (minutes: seconds)

Playing time of the current scene

◆When playing a VIDEO CD (without

PBC functions) or CD

•T *:* (minutes: seconds)

Playing time of the current track

•T–

*:*

Remaining time of the current track

•D *:*

Playing time of the current disc

•D–

*:*

Remaining time of the current disc

◆When playing a Super VCD (without

PBC functions)

•T

*:* (minutes: seconds)

Playing time of the current track

◆When playing a DATA CD (MP3 audio)

or DATA DVD (MP3 audio)

•T

*:* (minutes: seconds)

Playing time of the current track

TIME/TEXT

T 1:01:57

Time

information

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US08PLY3-CEK.fm

master page=right

39

Viewing Information About the Disc

DVP-NS75H

2-662-865-11(1)

Checking the play information of

the disc

To check the DVD/CD text

Press TIME/TEXT repeatedly in step 2 to

display text recorded on the DVD/CD.

The DVD/CD text appears only when text is

recorded in the disc. You cannot change the

text. If the disc does not contain text, “NO

TEXT” appears.

To check DATA CD (MP3 audio)/DATA DVD

(MP3 audio) album name, etc.

By pressing TIME/TEXT while playing MP3

audio tracks on a DATA CD/DATA DVD,

you can display the name of the album/track

and the audio bit rate (the amount of data per

second of the current audio track) on your TV

screen.

Checking the information on the

front panel display

You can view the time information and text

displayed on the TV screen also on the front

panel display. The information on the front

panel display changes as follows when you

change the time information on your TV

screen.

When playing a DVD VIDEO or DVD-VR

mode disc

BRAHMS SYMPHONY

T 17:30 128k

JAZZ

RIVER SIDE

Bit rate

Album name Track name

Playing time of the current title

Remaining time of the current title

Playing time of the current chapter

Remaining time of the current

chapter

Text

Current title and chapter number

(returns to top automatically)

,continued

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US08PLY3-CEK.fm

master page=left

40

DVP-NS75H

2-662-865-11(1)

When playing a DATA CD (MP3 audio)/

DATA DVD (MP3 audio)

When playing a VIDEO CD (without PBC

functions) or CD

zHints

• When playing VIDEO CDs without PBC

functions, the track number and the index number

are displayed after the text.

• When playing VIDEO CDs with PBC functions,

the scene number or the playing time are

displayed.

• Long text that does not fit in a single line will

scroll across the front panel display.

• You can also check the time information and text

using the Control Menu (page 13).

Notes

• Depending on the type of disc being played, the

DVD/CD text or track name may not be

displayed.

• The player can only display the first level of the

DVD/CD text, such as the disc name or title.

• Playing time of MP3 audio tracks may not be

displayed correctly.

• If you play a disc containing JPEG image files

only, “NO AUDIO DATA” appears when

“MODE (MP3, JPEG)” is set to “AUTO,”

“JPEG” appears when “MODE (MP3, JPEG)” is

set to “IMAGE (JPEG)” in the front panel display.

Playing time and number of the

current track

Track name

Current album and track number

(returns to top automatically)

Playing time and number of the

current track

Remaining time of the current

track

Remaining time of the disc

Text

Playing time of the disc

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US09ADV1-CEK.fm

master page=right

41

Sound Adjustments

DVP-NS75H

2-662-865-11(1)

Sound Adjustments

Changing the Sound

When playing a DVD VIDEO recorded in

multiple audio formats (PCM, Dolby Digital

or DTS), you can change the audio format. If

the DVD VIDEO is recorded with

multilingual tracks, you can also change the

language.

With CDs, DATA CDs, DATA DVDs or

VIDEO CDs, you can select the sound from

either the right or left channel and listen to the

sound of the selected channel through both

the right and left speakers. For example, when

playing a disc containing a song with the

vocals on the right channel and the

instruments on the left channel, you can hear

the instruments from both speakers by

selecting the left channel.

1Press AUDIO during playback.

The following display appears.

2Press AUDIO repeatedly to select

the desired audio signal.

◆When playing a DVD VIDEO

Depending on the DVD VIDEO, the

choice of language varies.

When 4 digits are displayed, they

indicate a language code. See “Language

Code List” on page 75 to see which

language the code represents. When the

same language is displayed two or more

times, the DVD VIDEO is recorded in

multiple audio formats.

◆When playing a DVD-VR mode disc

The types of sound tracks recorded on a

disc are displayed. The default setting is

underlined.

Example:

•1: MAIN

(main sound)

• 1: SUB (sub sound)

• 1: MAIN+SUB (main and sub sound)

◆When playing a VIDEO CD, CD or DATA

CD (MP3 audio)/DATA DVD (MP3 audio)

The default setting is underlined.

•STEREO

: the standard stereo sound

• 1/L: the sound of the left channel

(monaural)

• 2/R: the sound of the right channel

(monaural)

◆When playing a Super VCD

The default setting is underlined.

•1:STEREO

: the stereo sound of the

audio track 1

• 1:1/L: the sound of the left channel of

the audio track 1 (monaural)

• 1:2/R: the sound of the right channel of

the audio track 1 (monaural)

• 2:STEREO: the stereo sound of the

audio track 2

• 2:1/L: the sound of the left channel of

the audio track 2 (monaural)

• 2:2/R: the sound of the right channel of

the audio track 2 (monaural)

Notes

• While playing a Super VCD on which the audio

track 2 is not recorded, no sound will come out

when you select “2:STEREO,” “2:1/L,” or

“2:2/R.”

• When playing DVD-RW/DVD-R in VR mode: If

you connect to an AV amplifier (receiver) using

the DIGITAL OUT (COAXIAL or OPTICAL)/

HDMI OUT jack and want to switch between the

sound tracks, set “DOLBY DIGITAL” to “D-

PCM” in “AUDIO SETUP”.

AUDIO

1:

ENGLISH DOLBY DIGITAL 3/2.1

,continued

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US09ADV1-CEK.fm

master page=left

42

DVP-NS75H

2-662-865-11(1)

Checking the audio signal

format

You can check the audio signal format by

pressing AUDIO repeatedly during playback.

The format of the current audio signal (Dolby

Digital, DTS, PCM, etc.) appears as shown

below.

Example:

Dolby Digital 5.1 ch

Example:

Dolby Digital 3 ch

About audio signals

Audio signals recorded in a disc contain the

sound elements (channels) shown below.

Each channel is output from a separate

speaker.

• Front (L)

• Front (R)

•Center

• Rear (L)

• Rear (R)

• Rear (Monaural): This signal can be either

the Dolby Surround Sound processed

signals or the Dolby Digital sound’s

monaural rear audio signals.

• LFE (Low Frequency Effect) signal

Note

If “DTS” is set to “OFF” in “AUDIO SETUP”

(page 68) the DTS track selection option will not

appear on the screen even if the disc contains DTS

tracks.

TV Virtual Surround

Settings (TVS)

When you connect a stereo TV or 2 front

speakers, TVS (TV Virtual Surround) lets

you enjoy surround sound effects by using

sound imaging to create virtual rear speakers

from the sound of the front speakers (L: left,

R: right) without using actual rear speakers.

TVS was developed by Sony to produce

surround sound for home use using just a

stereo TV.

This only works when playing a multichannel

Dolby audio sound track. Furthermore, if the

player is set up to output the signal from the

DIGITAL OUT (OPTICAL or COAXIAL)/

HDMI OUT jack, the surround effect will

only be heard when “DOLBY DIGITAL” is

set to “D-PCM” in “AUDIO SETUP” (page

67).

1Press SUR during playback.

The following display appears.

2Press SUR repeatedly to select

one of the TVS sounds.

See the explanations given for each item

in the following section.

• TVS DYNAMIC THEATER

• TVS DYNAMIC

• TVS WIDE

• TVS NIGHT

• TVS STANDARD

1:

ENGLISH DOLBY DIGITAL

3 / 2 .1

Rear (L/R)

Front (L/R)

+ Center LFE (Low Frequency

Effect)

2:SPANISH DOLBY DIGITAL

2 / 1

Front (L/R) Rear

(Monaural) SUR

TVS DYNAMIC THEATER

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US09ADV1-CEK.fm

master page=right

43

Sound Adjustments

DVP-NS75H

2-662-865-11(1)

To cancel the setting

Select “OFF” in step 2.

◆TVS DYNAMIC THEATER

Creates one set of LARGE virtual rear

speakers and virtual subwoofer from the

sound of the front speakers (L, R) without

using actual rear speakers and subwoofer

(shown below).

This mode is effective when the distance

between the front L and R speakers is short,

such as with built-in speakers on a stereo TV.

◆TVS DYNAMIC

Creates one set of virtual rear speakers from

the sound of the front speakers (L, R) without

using actual rear speakers (shown below).

This mode is effective when the distance

between the front L and R speakers is short,

such as with built-in speakers on a stereo TV.

◆TVS WIDE

Creates five sets of virtual rear speakers from

the sound of the front speakers (L, R) without

using actual rear speakers (shown below).

This mode is effective when the distance

between the front L and R speakers is short,

such as with built-in speakers on a stereo TV.

◆TVS NIGHT

Large sounds, such as explosions, are

suppressed, but the quieter sounds are

unaffected. This feature is useful when you

want to hear the dialog and enjoy the

surround sound effects of “TVS WIDE” at

low volume.

◆TVS STANDARD

Creates three sets of virtual rear speakers

from the sound of the front speakers (L, R)

without using actual rear speakers (shown

below). Use this setting when you want to use

TVS with 2 separate speakers.

Notes

• When the playing signal does not contain a signal

for the rear speakers, the surround effects cannot

be heard.

• When you select one of the TVS modes, turn off

the surround setting of the connected TV or

amplifier (receiver).

• Make sure that your listening position is between

and at an equal distance from your speakers and

that the speakers are located in similar

surroundings.

• Not all discs will respond to the “TVS NIGHT”

function in the same way.

• If you use the DIGITAL OUT (OPTICAL or

COAXIAL)/HDMI OUT jack and set “DOLBY

DIGITAL” to “DOLBY DIGITAL,” and “DTS”

to “ON” in “AUDIO SETUP,” sound will come

from your speakers but it will not have the

SURROUND effect.

• The TVS effects do not work when using the Fast

Play or Slow Play functions, even though you can

change the TVS modes.

TV

Sub

woofer

TV

TV

L: Front speaker (left)

R: Front speaker (right)

: Virtual speaker

L R

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US10ADV2-CEK.fm

master page=left

44

DVP-NS75H

2-662-865-11(1)

Enjoying Movies

Changing the Angles

If various angles (multi-angles) for a scene

are recorded on the DVD VIDEO, “ ”

appears in the front panel display. This means

that you can change the viewing angle.

1Press ANGLE during playback.

The number of the angle appears on the

display.

2Press ANGLE repeatedly to select

an angle number.

The scene changes to the selected angle.

Note

Depending on the DVD VIDEO, you may not be

able to change the angles even if multi-angles are

recorded on the DVD VIDEO.

Displaying the Subtitles

If subtitles are recorded on the discs, you can

change the subtitles or turn them on and off

whenever you want while playing a DVD.

1Press SUBTITLE during playback.

The following display appears.

2Press SUBTITLE repeatedly to

select a setting.

◆When playing a DVD VIDEO

Select the language.

Depending on the DVD VIDEO, the

choice of language varies.

When 4 digits are displayed, they

indicate a language code. See “Language

Code List” on page 75 to see which

language the code represents.

◆When playing a DVD-VR mode disc

Select “ON.”

To turn off the subtitles

Select “OFF” in step 2.

Notes

• Depending on the DVD VIDEO, you may not be

able to change the subtitles even if multilingual

subtitles are recorded on it. You also may not be

able to turn them off.

• While playing a disc with subtitles, the subtitle

may disappear when you press FAST PLAY or

SLOW PLAY button.

ANGLE

2

SUBTITLE

1:ENGLISH

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US10ADV2-CEK.fm

master page=right

45

Enjoying Movies

DVP-NS75H

2-662-865-11(1)

Adjusting the Playback

Picture (CUSTOM PICTURE MODE)

You can adjust the video signal of the DVD,

VIDEO CD or DATA CD/DATA DVD in

JPEG format from the player to obtain the

picture quality you want. Choose the setting

that best suits the program you are watching.

When you select “MEMORY,” you can make

further adjustments to each element of the

picture (color, brightness, etc.).

1Press DISPLAY twice during

playback.

The Control Menu appears.

2Press X/x to select

(CUSTOM PICTURE MODE), then

press ENTER.

The options for “CUSTOM PICTURE

MODE” appear.

3Press X/x to select the setting you

want.

The default setting is underlined.

•

STANDARD:

displays a standard picture.

• DYNAMIC 1: produces a bold

dynamic picture by increasing the

picture contrast and the color intensity.

• DYNAMIC 2: produces a more

dynamic picture than DYNAMIC 1 by

further increasing the picture contrast

and color intensity.

• CINEMA 1: enhances details in dark

areas by increasing the black level.

• CINEMA 2: white colors become

brighter and black colors become richer

and the color contrast is increased.

• MEMORY: adjusts the picture in

greater detail.

4Press ENTER.

The selected setting takes effect.

zHint

When you watch a movie, “CINEMA 1” or

“CINEMA 2” is recommended.

Adjusting the picture items in

“MEMORY”

You can adjust each element of the picture

individually.

• PICTURE: changes the contrast

• BRIGHTNESS: changes the overall

brightness

• COLOR: makes the colors deeper or lighter

• HUE: changes the color balance

1In step 3 of “Adjusting the Playback

Picture,” select “MEMORY” and press

ENTER.

The “PICTURE” adjustment bar appears.

DISPLAY

RETURN

ENTER

DVD VIDEO

STANDARD

DYNAMIC 2

CINEMA 1

CINEMA 2

MEMORY

DYNAMIC 1

STANDARD


0

,continued

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US10ADV2-CEK.fm

master page=left

46

DVP-NS75H

2-662-865-11(1)

2Press C/c to adjust the picture

contrast.

To go to the next or previous picture item

without saving the current setting, press

X/x.

3Press ENTER.

The adjustment is saved and

“BRIGHTNESS” adjustment bar

appears.

4Repeat step 2 and 3 to adjust

“BRIGHTNESS,” “COLOR” and

“HUE.”

To turn off the display

Press O RETURN or DISPLAY.

Note

The “BRIGHTNESS” setting is not effective if you

connect the player via the LINE OUT (VIDEO) or

S VIDEO OUT jack and select “PROGRESSIVE

AUTO” or “PROGRESSIVE VIDEO” by using the

PROGRESSIVE button on the front panel.

Sharpening the Picture

(SHARPNESS)

You can enhance the outlines of images to

produce a sharper picture.

1Press DISPLAY twice during

playback.

The Control Menu appears.

2Press X/x to select

(SHARPNESS), then press ENTER.

The options for “SHARPNESS” appear.

3Press X/x to select a level.

• 1: enhances the outline.

• 2: enhances the outline more than 1.

4Press ENTER.

The selected setting takes effect.

ENTER

DISPLAY

DVD VIDEO

OFF

2

1

OFF

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US10ADV2-CEK.fm

master page=right

47

Enjoying Movies

DVP-NS75H

2-662-865-11(1)

To cancel the “SHARPNESS” setting

Select “OFF” in step 3.

Note

This setting is not effective if you connect the player

via the LINE OUT (VIDEO) or S VIDEO OUT jack

and select “PROGRESSIVE AUTO” or

“PROGRESSIVE VIDEO” by using the

PROGRESSIVE button on the front panel.

Adjusting the Picture

Quality (BNR, MNR)

You can adjust the picture quality by “BNR”

(Block Noise Reduction) or “MNR”

(Mosquito Noise Reduction)

Adjusting the BNR

The “BNR” function adjusts the picture

quality by reducing the “block noise” or

mosaic like patterns that appear on your TV

screen.

1Press DISPLAY twice during

playback.

The Control Menu appears.

2Press X/x to select (BNR),

then press ENTER.

The options for “BNR” appear.

ENTER

DISPLAY

OFF

ON

DVD VIDEO

OFF

,continued

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US10ADV2-CEK.fm

master page=left

48

DVP-NS75H

2-662-865-11(1)

3Press X/x to select the setting.

•OFF: To cancel the “BNR” effect.

•ON: To turn on the “BNR” effect.

4Press ENTER.

The disc plays with the setting you

selected.

To cancel the “BNR” setting

Select “OFF” in step 3.

To turn off the Control Menu

Press DISPLAY repeatedly until the Control

Menu is turned off.

Notes

• If the outlines of the images on your screen should

become blurred, set “BNR” to “OFF.”

• Depending on the disc or the scene being played,

there may be no “BNR” effect, or it may be hard

to discern.

Adjusting the MNR

The “MNR” function adjusts the picture

quality by reducing the faint noise appearing

around the outlines of the images.

The noise reduction effects are automatically

adjusted within each setting range according

to the video bit rate and other factors.

1Press DISPLAY twice during

playback.

The Control Menu appears.

2Press X/x to select

(MNR), then press ENTER.

The options for “MNR” appear.

3Press X/x to select the setting.

•OFF: To cancel the “MNR” effect.

•ON: To turn on the “MNR” effect.

4Press ENTER.

The disc plays with the setting you

selected.

To cancel the “MNR” setting

Select “OFF” in step 3.

To turn off the Control Menu

Press DISPLAY repeatedly until the Control

Menu is turned off.

Notes

• If the outlines of the images on your screen should

become blurred, set “MNR” to “OFF.”

• Depending on the disc or the scene being played,

there may be no “MNR” effect, or it may be hard

to discern.

OFF

ON

DVD VIDEO

OFF

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US10ADV2-CEK.fm

master page=right

49

Enjoying Movies

DVP-NS75H

2-662-865-11(1)

Adjusting the Delay

Between the Picture and

Sound (AV SYNC)

When the sound does not match the pictures

on the screen, you can adjust the delay

between the picture and sound.

1Press DISPLAY twice during

playback.

The Control Menu appears.

2Press X/x to select (AV

SYNC), then press ENTER.

The following display appears.

3Press x to select “SET c”, then

press ENTER.

The “AV SYNC” adjustment bar

appears.

4Press c repeatedly to adjust the

delay.

Each time you press C/c, the delay is

adjusted by 10 milliseconds.

5Press ENTER.

The selected setting takes effect.

To reset the “AV SYNC” setting

Press CLEAR in step 4.

Notes

• This function is not effective if you use the

DIGITAL OUT (OPTICAL or COAXIAL)

jack, and set “DOLBY DIGITAL” or

“DTS” in AUDIO SETUP to “DOLBY

DIGITAL” or “ON” respectively (page 67).

• This function is not effective if you connect

a Dolby Digital or DTS-compliant device

via the HDMI OUT jack, and set “DOLBY

DIGITAL” or “DTS” in AUDIO SETUP to

“DOLBY DIGITAL” or “ON” respectively

(page 67).

ENTER

DISPLAY

CLEAR

STOP

DVD VIDEO

0 ms

SET

AV SYNC 0ms

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US11PLA-CEK.fm

master page=left

50

DVP-NS75H

2-662-865-11(1)

Enjoying MP3 Audio and JPEG

Images

About MP3 Audio Tracks

and JPEG Image Files

MP3 is audio compression technology that

satisfies the ISO/IEC MPEG regulations.

JPEG is image compression technology.

You can play DATA CDs/DATA DVDs that

contain MP3 audio tracks or JPEG image

files.

DATA CDs/DATA DVDs that the

player can play

You can play back DATA CDs (CD-ROMs/

CD-Rs/CD-RWs) or DATA DVDs (DVD-

ROMs/DVD+RWs/DVD+Rs/DVD-RWs/

DVD-Rs) recorded in MP3 (MPEG-1 Audio

Layer III) and JPEG format.

However, this player only plays DATA CDs

whose logical format is ISO 9660 Level 1/

Level 2 or Joliet and DATA DVDs of

Universal Disk Format (UDF).

Refer to the instructions supplied with the

disc drives and the recording software (not

supplied) for details on the recording format.

Note

The player may not be able to play some DATA

CDs/DATA DVDs created in the Packet Write

format.

MP3 audio track or JPEG image

file that the player can play

The player can play the following tracks and

files:

– MP3 audio tracks with the extension

“.MP3.”

– JPEG image files with the extension

“.JPEG” or “.JPG.”

– JPEG image files that conform to the DCF*

image file format.

* “Design rule for Camera File system”: Image

standards for digital cameras regulated by JEITA

(Japan Electronics and Information Technology

Industries Association).

Notes

• The player will play any data with the extension

“.MP3,” “.JPG,” or “.JPEG,” even if they are not

in MP3 or JPEG format. Playing these data may

generate a loud noise which could damage your

speaker system.

• The player does not conform to audio tracks in

mp3PRO format.

• Some JPEG files cannot be played.

About playback order of albums,

tracks and files

Albums play in the following order:

◆Structure of disc contents

ROOT

Tree 1 Tree 2 Tree 3 Tree 4 Tree 5

Album Track or file

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US11PLA-CEK.fm

master page=right

51

Enjoying MP3 Audio and JPEG Images

DVP-NS75H

2-662-865-11(1)

When you insert a DATA CD/DATA DVD

and press H, the numbered tracks (or files)

are played sequentially, from 1 through 7.

Any sub-albums/tracks (or files) contained

within a currently selected album take

priority over the next album in the same tree.

(Example: C contains D so 4 is played

before 5.)

When you press MENU and the list of album

names appears (page 52), the album names

are arranged in the following order:

A t B t C t D t F t G. Albums

that do not contain tracks (or files) (such as

album E) do not appear in the list.

zHints

• If you add numbers (01, 02, 03, etc.) to the front

of the track/file names when you store the tracks

(or files) in a disc, the tracks and files will be

played in that order.

• Since a disc with many trees takes longer to start

playback, it is recommended that you create

albums with no more than two trees.

Notes

• Depending on the software you use to create the

DATA CD/DATA DVD, the playback order may

differ from the above illustration.

• The playback order above may not be applicable

if there are more than 200 albums and 300 tracks/

files in each album.

• The player can recognize up to 200 albums (the

player will count just albums, including albums

that do not contain MP3 audio tracks and JPEG

image files). The player will not play any albums

beyond the 200th album.

• Proceeding to the next or another album may take

some time.

Playing MP3 Audio

Tracks or JPEG Image

Files

You can play MP3 audio tracks and JPEG

image files on DATA CDs (CD-ROMs/CD-

Rs/CD-RWs) or DATA DVDs (DVD-ROMs/

DVD+RWs/DVD+Rs/DVD-RWs/DVD-Rs).

zHint

You can view the disc information while playing

MP3 audio tracks (page 38).

Notes

• DATA CDs recorded in KODAK Picture CD

format automatically start playing when inserted.

• If no MP3 audio track or JPEG image file is

recorded on the DATA CD/DATA DVD, “No

audio data” or “No image data” appears on the

screen.


NAVI

RETURN

ENTER

CLEAR

ZOOM

MENU

,continued

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US11PLA-CEK.fm

master page=left

52

DVP-NS75H

2-662-865-11(1)

Selecting an album

1Press MENU.

The list of albums on the disc appears.

When an album is being played, its title is

shaded.

2Press X/x to select the album you

want to play.

3Press H.

Playback starts from the selected album.

To select MP3 audio tracks, see

“Selecting an MP3 audio track”

(page 52).

To select JPEG image files, see

“Selecting a JPEG image file” (page 53).

To stop playback

Press x.

To go to the next or previous page

Press c or C.

To turn on or off the display

Press MENU repeatedly.

zHint

Of the selected album, you can select to play only

the MP3 audio tracks, JPEG image files or both, by

setting “MODE (MP3, JPEG)” (page 54).

Selecting an MP3 audio track

1After step 2 of “Selecting an album,”

press ENTER.

The list of tracks in the album appears.

2Press X/x to select a track and press

ENTER.

Playback starts from the selected track.

To stop playback

Press x.

To go to the next or previous page

Press c or C.

To return to the previous display

Press O RETURN.

To go to the next or previous MP3 audio

track

Press > or . during playback. You can

select the first track of the next album by

pressing > during playback of the last

track of the current album.

Note that you cannot return to the previous

album by using . and that you need to

select the previous album from the album list.

1 ( 3 0 )

ROCK BEST HIT

KARAOKE

JAZZ

R&B

MY FAVORITE SONGS

CLASSICAL

SALSA OF CUBA

BOSSANOVA

J A Z Z

1 ( 9 0 )

01SHE IS SPECIAL

02ALL YOU NEED IS ...

03SPICY LIFE

04HAPPY HOUR

05RIVER SIDE

06

5

07TAKE TIME,TAKE TIME

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US11PLA-CEK.fm

master page=right

53

Enjoying MP3 Audio and JPEG Images

DVP-NS75H

2-662-865-11(1)

Selecting a JPEG image file

1After step 2 of “Selecting an album,”

press PICTURE NAVI.

The image files in the album appear in 16

subscreens. A scroll box is displayed on

the right.

To display the additional image, select

the bottom images and press x. To return

to the previous image, select the top

images and press X.

2Press C/X/x/c to select the image you

want to view, and press ENTER.

The selected image appears.

Example

To go to the next or previous JPEG image

file

Press C or c during playback. You can select

the first file of the next album by pressing c

during playback of the last file of the current

album.

Note that you cannot return to the previous

album by using C and that you need to select

the previous album from the album list.

To rotate a JPEG image

Press X/x while viewing the image. Each

time you press X, the image rotates

counterclockwise by 90 degrees.

To return to normal view, press CLEAR.

Note that the view also returns to normal if

you press C/c to go to the next or previous

image.

Example: when X is pressed once.

To magnify a JPEG image (ZOOM)

Press ZOOM while viewing the image. You

can enlarge the image up to four times the

original size and scroll using C/X/x/c.

To return to normal view, press CLEAR.

◆When pressed once (x2)

The image enlarges twice the original size.

◆When pressed twice (x4)

The image enlarges four times the original

size.

To stop viewing the JPEG image

Press x.

zHints

• While viewing JPEG image files, you can set

options such as “INTERVAL” (page 55),

“EFFECT” (page 55) and “SHARPNESS”

(page 46).

• You can view JPEG images files without MP3

audio by setting “MODE (MP3, JPEG)” to

“IMAGE (JPEG)” (page 54).

• The date the picture was taken is displayed beside

“DATE” in the Control Menu (page 13). Note that

no date may appear depending on the digital

camera.

Note

PICTURE NAVI does not work if “AUDIO (MP3)”

is selected in “MODE (MP3, JPEG)” (page 54).

1234

5678

13 14 15 16

9101112

Rotating direction

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US11PLA-CEK.fm

master page=left

54

DVP-NS75H

2-662-865-11(1)

Enjoying JPEG Images as

a Slide Show

You can play JPEG image files on a DATA

CD or DATA DVD successively as a slide

show.

1Press MENU.

The list of albums on the DATA CD/

DATA DVD appears.

2Press X/x to select an album.

3Press H.

The JPEG images in the selected album

start playing as a slide show.

To stop playback

Press x.

Notes

• The slide show stops when X/x or ZOOM is

pressed.To resume the slide show, press H.

• This function does not work if “MODE (MP3,

JPEG)” is set to “AUDIO (MP3)” (page 54).

Viewing a slide show with sound

(MODE (MP3, JPEG))

When JPEG image files and MP3 audio

tracks are placed in the same album, you can

enjoy a slide show with sound.

1Press DISPLAY during stop mode.

The Control Menu appears.

2Press X/x to select (MODE

(MP3, JPEG)) and press ENTER.

The options for “MODE (MP3, JPEG)”

appear.

3Press X/x to select “AUTO” (default),

and press ENTER.

• AUTO: plays both the JPEG image files

and MP3 audio tracks in the same

album as a slide show.

• AUDIO (MP3): plays only MP3 audio

tracks continuously.

• IMAGE (JPEG): plays only JPEG

image files continuously.

4Press MENU.

The list of albums on the DATA CD/

DATA DVD appears.

5Press X/x to select the album that

contains both the MP3 audio tracks

and JPEG images you want to play.

6Press H.

A slide show starts with sound.

MENU

DISPLAY

ENTER

1 ( 3 0 )

ROCK BEST HIT

KARAOKE

JAZZ

R&B

MY FAVORITE SONGS

CLASSICAL

SALSA OF CUBA

BOSSANOVA

DATA CD

MP3

1 8 ( 3 4 )

1 2 ( 2 7 )

T

3 2 : 5 5

IMAGE (JPEG)

AUDIO (MP3)

AUTO

AUTO

1 ( 3 0 )

ROCK BEST HIT

KARAOKE

JAZZ

R&B

MY FAVORITE SONGS

CLASSICAL

SALSA OF CUBA

BOSSANOVA

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US11PLA-CEK.fm

master page=right

55

Enjoying MP3 Audio and JPEG Images

DVP-NS75H

2-662-865-11(1)

zHints

• To repeat both MP3 audio tracks and JPEG image

files in a single album, repeat the same MP3 audio

track or album when “MODE (MP3, JPEG)” is set

to “AUTO.” See “Playing repeatedly (Repeat

Play)” (page 32) to repeat the track or album.

• The player recognizes a maximum of 200 albums

regardless of the selected mode. Of each album,

the player recognizes up to 300 MP3 audio tracks

and 300 JPEG image files when “AUTO” is

selected, 600 MP3 audio tracks when “AUDIO

(MP3)” is selected, 600 JPEG image files when

“IMAGE (JPEG)” is selected.

Notes

• This function does not work if the MP3 audio

tracks and JPEG image files are not placed in the

same album.

• If playing time of JPEG image or MP3 audio is

longer than the other, the longer one continues

without sound or image.

• If you play large MP3 track data and JPEG image

data at the same time, the sound may skip. It is

recommended that you set the MP3 bit rate to 128

kbps or lower when creating the file. If the sound

still skips, then reduce the size of the JPEG file.

Setting the pace for a slide show

(INTERVAL)

You can set the time the slides are displayed

on the screen.

1Press DISPLAY twice while viewing a

JPEG image or when the player is in

stop mode.

The Control Menu appears.

2Press X/x to select

(INTERVAL), then press ENTER.

The options for “INTERVAL” appear.

3Press X/x to select a setting.

The default setting is underlined.

•NORMAL

: sets the duration to between

6 to 9 seconds.

• FAST: sets a duration shorter than

NORMAL.

• SLOW 1: sets a duration longer than

NORMAL.

• SLOW 2: sets a duration longer than

SLOW 1.

4Press ENTER.

Note

Some JPEG files, especially progressive JPEG files

or JPEG files of 3,000,000 pixels or more, may take

longer to display than others, which may make the

duration seem longer than the setting you selected.

Selecting the slides’ appearance

(EFFECT)

You can select the way the slides are

displayed during a slide show.

1Press DISPLAY twice while viewing a

JPEG image or when the player is in

stop mode.

2Press X/x to select (EFFECT),

then press ENTER.

The options for “EFFECT” appear.

3Press X/x to select a setting.

The default setting is underlined.

•MODE 1

: the image sweeps in from top

to bottom.

• MODE 2: the image sweeps in from left

to right.

• MODE 3: the image stretches out from

the center of the screen.

• MODE 4: the images randomly cycle

through the effects.

• MODE 5: the next image slides over the

previous image.

• OFF: turns off this function.

4Press ENTER.

1 0 / 2 9 / 2 0 0 6

1(

NORMAL

DATA CD

JPEG

NORMAL

INTERVAL

FAST

SLOW 1

SLOW 2

4)

3 ( 1 2)

1 0 / 2 9 / 2 0 0 6

1(

MODE 1

DATA CD

JPEG

MODE 1

MODE 2

MODE 3

MODE 4

MODE 5

OFF

4)

3 ( 1 2)

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US12ADV3-CEK.fm

master page=left

56

DVP-NS75H

2-662-865-11(1)

Using Various Additional

Functions

Locking Discs (CUSTOM

PARENTAL CONTROL, PARENTAL

CONTROL)

You can set two kinds of playback restrictions

for a disc.

• Custom Parental Control

You can set playback restrictions so that the

player will not play inappropriate discs.

• Parental Control

Playback of some DVD VIDEOs can be

limited according to a predetermined level

such as the age of the users. Scenes may be

blocked or replaced with different scenes.

The same password is used for both Parental

Control and Custom Parental Control.

Custom Parental Control

You can set the same Custom Parental

Control password for up to 40 discs. When

you set the 41st-disc, the first disc is canceled.

1Insert the disc you want to lock.

If the disc is playing, press x to stop

playback.

2Press DISPLAY while the player is in

stop mode.

The Control Menu appears.

3Press X/x to select

(PARENTAL CONTROL), then press

ENTER.

The options for “PARENTAL

CONTROL” appear.

4Press X/x to select “ON t,” then

press ENTER.

◆If you have not entered a password

The display for registering a new

password appears.

Enter a 4-digit password using the

number buttons, then press ENTER.

The display for confirming the password

appears.

◆When you have already registered a

password

The display for entering the password

appears.

5Enter or re-enter your 4-digit password

using the number buttons, then press

ENTER.

“Custom parental control is set.” appears

and then the screen returns to the Control

Menu.

ENTER

DISPLAY

Number

buttons

STOP

1 8 ( 3 4 )

1 2 ( 2 7 )

T

1 : 3 2 : 5 5

DVD VIDEO

OFF

PASSWORD

ON

PLAYER

PARENTAL CONTROL

Enter a new 4-digit password,

then press .

ENTER

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US12ADV3-CEK.fm

master page=right

57

Using Various Additional Functions

DVP-NS75H

2-662-865-11(1)

To turn off the Custom Parental Control

function

1Follow steps 1 to 3 of “Custom Parental

Control.”

2Press X/x to select “OFF t,” then press

ENTER.

3Enter your 4-digit password using the

number buttons, then press ENTER.

To play a disc for which Custom Parental

Control is set

1Insert the disc for which Custom Parental

Control is set.

The “CUSTOM PARENTAL

CONTROL” display appears.

2Enter your 4-digit password using the

number buttons, then press ENTER.

The player is ready for playback.

zHint

If you forget your password, enter the 6-digit

number “199703” using the number buttons when

the “CUSTOM PARENTAL CONTROL” display

asks you for your password, then press ENTER.

The display will ask you to enter a new 4-digit

password.

Parental Control (limited

playback)

Playback of some DVD VIDEOs can be

limited according to a predetermined level

such as the age of the users. The

“PARENTAL CONTROL” function allows

you to set a playback limitation level.

1Press DISPLAY while the player is in

stop mode.

The Control Menu appears.

2Press X/x to select

(PARENTAL CONTROL), then press

ENTER.

The options for “PARENTAL

CONTROL” appear.

3Press X/x to select “PLAYER t,”

then press ENTER.

◆If you have not entered a password

The display for registering a new

password appears.

Enter a 4-digit password using the

number buttons, then press ENTER.

The display for confirming the password

appears.

◆When you have already registered a

password

The display for entering the password

appears.

CUSTOM PARENTAL CONTROL

Custom parental control is already

set. To play, enter your password

and press

.

ENTER

STOP

1 8 ( 3 4 )

1 2 ( 2 7 )

T

1 : 3 2 : 5 5

DVD VIDEO

OFF

PASSWORD

ON

PLAYER

PARENTAL CONTROL

Enter a new 4-digit password,

then press .

ENTER

,continued

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US12ADV3-CEK.fm

master page=left

58

DVP-NS75H

2-662-865-11(1)

4Enter or re-enter your 4-digit password

using the number buttons, then press

ENTER.

The display for setting the playback

limitation level appears.

5Press X/x to select “STANDARD,”

then press ENTER.

The selection items for “STANDARD”

are displayed.

6Press X/x to select a geographic area

as the playback limitation level, then

press ENTER.

The area is selected.

When you select “OTHERS t,” select

and enter a standard code in the table on

page 75 using the number buttons.

7Press X/x to select “LEVEL,” then

press ENTER.

The selection items for “LEVEL” are

displayed.

8Select the level you want using X/x,

then press ENTER.

Parental Control setting is complete.

The lower the value, the stricter the

limitation.

To turn off the Parental Control function

Set “LEVEL” to “OFF” in step 8.

To play a disc for which Parental Control is

set

1Insert the disc and press H.

The display for entering your password

appears.

2Enter your 4-digit password using the

number buttons, then press ENTER.

The player starts playback.

zHint

If you forget your password, remove the disc and

repeat steps 1 to 3 of “Parental Control (limited

playback).” When you are asked to enter your

password, enter “199703” using the number

buttons, then press ENTER. The display will ask

you to enter a new 4-digit password. After you enter

a new 4-digit password, replace the disc in the

player and press H. When the display for entering

your password appears, enter your new password.

Notes

• When you play discs which do not have the

Parental Control function, playback cannot be

limited on this player.

• Depending on the disc, you may be asked to

change the parental control level while playing

the disc. In this case, enter your password, then

change the level. If the Resume Play mode is

canceled, the level returns to the previous level.

PARENTAL CONTROL

LEVEL: OFF

USA

STANDARD:

PARENTAL CONTROL

LEVEL: OFF

USA

STANDARD: USA

OTHERS

PARENTAL CONTROL

LEVEL: OFF

OFF

STANDARD:

8:

7:

6:

5:

NC17

R

PARENTAL CONTROL

LEVEL:

STANDARD: USA

4: PG13

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US12ADV3-CEK.fm

master page=right

59

Using Various Additional Functions

DVP-NS75H

2-662-865-11(1)

Changing the password

1Press DISPLAY while the player is in

stop mode.

The Control Menu appears.

2Press X/x to select

(PARENTAL CONTROL), then press

ENTER.

The options for “PARENTAL

CONTROL” appear.

3Press X/x to select “PASSWORD

t,” then press ENTER.

The display for entering the password

appears.

4Enter your 4-digit password using the

number buttons, then press ENTER.

5Enter a new 4-digit password using the

number buttons, then press ENTER.

6To confirm your password, re-enter it

using the number buttons, then press

ENTER.

If you make a mistake entering your

password

Press C before you press ENTER and input

the correct number.

Controlling Your TV with

the Supplied Remote

You can control the sound level, input source,

and power switch of your Sony TV with the

supplied remote.

You can control your TV using the buttons

below.

Note

Depending on the connected unit, you may not be

able to control your TV using all or some of the

buttons on the supplied remote.

By pressing You can

TV [/1Turn the TV on or off

VOL +/– Adjust the volume of the TV

TV/VIDEO Switch the TV’s input source

between the TV and other

input sources.

TV

VOL +/–

TV/VIDE

O

Number

buttons

,continued

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US12ADV3-CEK.fm

master page=left

60

DVP-NS75H

2-662-865-11(1)

Controlling other TVs with the

remote

You can control the sound level, input source,

and power switch of non-Sony TVs as well.

If your TV is listed in the table below, set the

appropriate manufacturer’s code.

1While holding down TV [/1, press the

number buttons to select your TV’s

manufacturer’s code (see the table

below).

2Release TV [/1.

Code numbers of controllable TVs

If more than one code number is listed, try

entering them one at a time until you find the

one that works with your TV.

Notes

• When you replace the batteries of the remote, the

code number you have set may be reset to the

default setting. Set the appropriate code number

again.

• Depending on the connected unit, you may not be

able to control your TV using all or some of the

buttons on the supplied remote.

Manufacturer Code number

Sony 01 (default)

Daewoo 04, 22

Hitachi 02, 04

JVC 09

LG/Goldstar 04

MGA/Mitsubishi 04, 13

Panasonic 19

Philips 21

RCA 04, 10

Samsung 04, 20

Sharp 18

Toshiba 07, 18

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US13ADV4-CEK.fm

master page=right

61

Settings and Adjustments

DVP-NS75H

2-662-865-11(1)

Settings and Adjustments

Using the Setup Display

By using the Setup Display, you can make

various adjustments to items such as picture

and sound. You can also set a language for the

subtitles and the Setup Display, among other

things.

For details on each Setup Display item, see

pages from 62 to 68.

Note

Playback settings stored in the disc take priority

over the Setup Display settings and not all of the

functions described may work.

1Press DISPLAY when the player is

in stop mode.

The Control Menu appears.

2Press X/x to select

(SETUP), then press ENTER.

The options for “SETUP” appear.

3Press X/x to select “CUSTOM,”

then press ENTER.

The Setup Display appears.

4Press X/x to select the setup item

from the displayed list:

“LANGUAGE SETUP,” “SCREEN

SETUP,” “CUSTOM SETUP” or

“AUDIO SETUP.” Then press

ENTER.

The Setup item is selected.

Example: “SCREEN SETUP”

5Press X/x to select an item, then

press ENTER.

The options for the selected item appear.

Example: “TV TYPE”

ENTER

DISPLAY

STOP

( 47 )

QUICK

CUSTOM

RESET

DVD VIDEO

QUICK

LANGUAGE SETUP

OSD:

MENU:

AUDIO:

SUBTITLE:

ENGLISH

ENGLISH

ORIGINAL

ENGLISH

SCREEN SETUP

TV TYPE:

HDMI RESOLUTION:

SCREEN SAVER:

16:9

AUTO

ON

YC

B

C

R

BLACK LEVEL:

BACKGROUND: JACKET PICTURE

BLACK LEVEL

(COMPONENT OUT)

:

4:3 OUTPUT:

ON

OFF

FULL

YC

B

C

R

/RGB (HDMI):

Selected item

Setup items

SCREEN SETUP

HDMI RESOLUTION:

TV TYPE:

SCREEN SAVER:

BACKGROUND:

16:9

4:3 PAN SCAN

4:3 LETTER BOX

BLACK LEVEL:

BLACK LEVEL

(COMPONENT OUT)

:

4:3 OUTPUT:

ON

OFF

FULL

16:9

JACKET PICTURE

YC

B

C

R

/RGB (HDMI):

Options

,continued

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US13ADV4-CEK.fm

master page=left

62

DVP-NS75H

2-662-865-11(1)

6Press X/x to select a setting, then

press ENTER.

The setting is selected and setup is

complete.

Example: “4:3 PAN SCAN”

To enter the Quick Setup mode

Select “QUICK” in step 3. Follow from step

5 of the Quick Setup explanation to make

basic adjustments (page 23).

To reset all of the “SETUP” settings

1Select “RESET” in step 3 and press

ENTER.

2Select “YES” using X/x.

You can also quit the process and return

to the Control Menu by selecting “NO”

here.

3Press ENTER.

All the settings explained on pages 62 to

68 return to the default settings. Do not

press [/1 while resetting the player,

which takes a few seconds to complete.

Setting the Display or

Sound Track Language

(LANGUAGE SETUP)

“LANGUAGE SETUP” allows you to set

various languages for the on-screen display or

sound track.

Select “LANGUAGE SETUP” in the Setup

Display. To use the display, see “Using the

Setup Display” (page 61).

◆OSD (On-Screen Display)

Switches the display language on the screen.

◆MENU (DVD VIDEO only)

You can select the desired language for the

disc’s menu.

◆AUDIO (DVD VIDEO only)

Switches the language of the sound track.

When you select “ORIGINAL,” the language

given priority in the disc is selected.

◆SUBTITLE (DVD VIDEO only)

Switches the language of the subtitle recorded

on the DVD VIDEO.

When you select “AUDIO FOLLOW,” the

language for the subtitles changes according

to the language you selected for the sound

track.

zHint

If you select “OTHERS t” in “MENU,”

“SUBTITLE,” or “AUDIO,” select and enter a

language code from “Language Code List” on

page 75 using the number buttons.

Note

If you select a language in “MENU,” “SUBTITLE”

or “AUDIO” that is not recorded on a DVD

VIDEO, one of the recorded languages will be

automatically selected.

Selected setting

SCREEN SETUP

TV TYPE:

SCREEN SAVER:

BACKGROUND:

4:3 PAN SCAN

ON

HDMI RESOLUTION: AUTO

JACKET PICTURE

BLACK LEVEL

(COMPONENT OUT)

:

OFF

BLACK LEVEL

:

ON

4:3 OUTPUT: FULL

YC

B

C

R

YC

B

C

R

/RGB (HDMI):

LANGUAGE SETUP

OSD:

MENU:

AUDIO:

SUBTITLE:

ENGLISH

ENGLISH

ORIGINAL

ENGLISH

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US13ADV4-CEK.fm

master page=right

63

Settings and Adjustments

DVP-NS75H

2-662-865-11(1)

Settings for the Display

(SCREEN SETUP)

Choose settings according to the TV to be

connected.

Select “SCREEN SETUP” in the Setup

Display. To use the display, see “Using the

Setup Display” (page 61).

The default settings are underlined.

◆TV TYPE

Selects the aspect ratio of the connected TV

(4:3 standard or wide).

Note

Depending on the DVD, “4:3 LETTER BOX” may

be selected automatically instead of “4:3 PAN

SCAN” or vice versa.

◆HDMI RESOLUTION

Selects the type of video signals output from

the HDMI OUT jack. When you select

AUTO (default), the player outputs video

signals of the highest resolution acceptable

for your TV. If the picture is not clear, natural

or to your satisfaction, try another option that

suits the disc and your TV/projector, etc. For

details, refer also to the instruction manual

supplied with the TV/projector, etc.

Notes

• Even when a setting other than “AUTO” is

selected and the connected TV cannot accept the

resolution, the player automatically adjusts the

video signals that are suitable for the TV.

• When the HDMI indicator on the front panel

lights up, images from the S VIDEO OUT and

LINE OUT (VIDEO) jacks are enlarged

vertically. (Except when 720×480p is selected).

◆YCBCR/RGB (HDMI)

Selects the type of HDMI signal output from

HDMI OUT jack.

Notes

• If the playback picture becomes distorted, set

“YCBCR” to “RGB.”

• If the HDMI OUT jack is connected to equipment

with a DVI jack, “RGB” signals will be

automatically output even when you select

“YCBCR”.

16:9 Select this when you connect a

wide-screen TV or a TV with a

wide mode function.

4:3

LETTER

BOX

Select this when you connect a

4:3 screen TV. Displays a wide

picture with bands on the upper

and lower portions of the

screen.

4:3

PAN SCAN Select this when you connect a

4:3 screen TV. Automatically

displays the wide picture on the

entire screen and cuts off the

portions that do not fit.

SCREEN SETUP

HDMI RESOLUTION:

SCREEN SAVER:

BACKGROUND:

AUTO

TV TYPE: 16:9

ON

JACKET PICTURE

BLACK LEVEL: ON

BLACK LEVEL (COMPONENT OUT):OFF

4:3 OUTPUT: FULL

YCBCR

YCBCR/RGB (HDMI):

16:9

4:3 PAN SCAN

4:3 LETTER BOX

AUTO Normally, select this.

1920×1080i Sends 1920×1080i video

signals.

1280×720p Sends 1280×720p video

signals.

720×480p Sends 720×480p video signals.

YCBCROutputs YCBCR signals.

RGB Outputs RGB signals.

,continued

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US13ADV4-CEK.fm

master page=left

64

DVP-NS75H

2-662-865-11(1)

◆SCREEN SAVER

The screen saver image appears when you

leave the player in pause or stop mode for 15

minutes, or when you play a CD or DATA

CD (MP3 audio)/DATA DVD (MP3 audio)

for more than 15 minutes. The screen saver

will help prevent your display device from

becoming damaged (ghosting). Press H to

turn off the screen saver.

◆BACKGROUND

Selects the background color or picture on the

TV screen when the player is in stop mode or

while playing a CD or DATA CD (MP3

audio)/DATA DVD (MP3 audio).

◆BLACK LEVEL

Selects the black level (setup level) for the

video signals output from the jacks other than

COMPONENT VIDEO OUT/HDMI OUT.

◆BLACK LEVEL (COMPONENT OUT)

Selects the black level (setup level) for the

video signals output from the COMPONENT

VIDEO OUT jacks. You cannot select this

when the player outputs progressive signals

(page 20).

◆4:3 OUTPUT

This setting is effective only when you set

“TV TYPE” in “SCREEN SETUP” to

“16:9.”

Adjust this to watch 4:3 aspect ratio

progressive signals. If you can change the

aspect ratio on your progressive format

(480p) compatible TV, change the setting on

your TV, not the player. Note that this setting

is effective only for HDMI connection or

progressive signals output from the

COMPONENT VIDEO OUT jacks.

ON Turns on the screen saver.

OFF Turns off the screen saver.

JACKET

PICTURE The jacket picture (still picture)

appears, but only when the

jacket picture is already

recorded on the disc (CD-

EXTRA, etc.). If the disc does

not contain a jacket picture, the

“GRAPHICS” picture appears.

GRAPHICS A preset picture stored in the

player appears.

BLUE The background color is blue.

BLACK The background color is black.

ON Sets the black level of the

output signal to the standard

level.

OFF Lowers the standard black

level. Use this when the picture

becomes too white.

OFF Sets the black level of the

output signal to the standard

level. Normally select this

position.

ON Raises the standard black level.

Use this setting when the

picture appears too dark.

FULL Select this when you can

change the aspect ratio on your

TV.

NORMAL Select this when you cannot

change the aspect ratio on your

TV. Shows a 16:9 aspect ratio

signal with black bands on left

and right sides of the image.

16:9 aspect ratio TV

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US13ADV4-CEK.fm

master page=right

65

Settings and Adjustments

DVP-NS75H

2-662-865-11(1)

Custom Settings (CUSTOM

SETUP)

Use this to set up playback related and other

settings.

Select “CUSTOM SETUP” in the Setup

Display. To use the display, see “Using the

Setup Display” (page 61).

The default settings are underlined.

◆AUTO POWER OFF

Switches the Auto Power Off setting on or

off.

◆AUTO PLAY

Switches the Auto Play setting on or off. This

function is useful when the player is

connected to a timer (not supplied).

◆DIMMER

Adjusts the lighting of the front panel display.

◆PAUSE MODE (DVD VIDEO/DVD-VR

mode only)

Selects the picture in pause mode.

◆TRACK SELECTION (DVD VIDEO only)

Gives the sound track which contains the

highest number of channels priority when you

play a DVD VIDEO on which multiple audio

formats (PCM, DTS, or Dolby Digital

format) are recorded.

Notes

• When you set the item to “AUTO,” the language

may change. The “TRACK SELECTION” setting

has higher priority than the “AUDIO” settings in

“LANGUAGE SETUP” (page 62).

• If you set “DTS” to “OFF” (page 68), the DTS

sound track is not played even if you set “TRACK

SELECTION” to “AUTO.”

• If PCM, DTS, and Dolby Digital sound tracks

have the same number of channels, the player

selects PCM, DTS, and Dolby Digital sound

tracks in this order.

◆MULTI-DISC RESUME (DVD VIDEO/

VIDEO CD only)

Switches the Multi-disc Resume setting on or

off. Resume playback can be stored in

memory for up to 6 different DVD VIDEOs/

VIDEO CDs (page 27).

Note

If you run Quick Setup, Multi-disc Resume settings

stored in memory may return to the default settings.

OFF Switches this function off.

ON The player enters standby mode

when left in stop mode for more

than 30 minutes.

OFF Switches this function off.

ON Automatically starts playback

when the player is turned on by

a timer (not supplied).

BRIGHT Makes the lighting bright.

DARK Makes the lighting dark.

AUTO

DARK Makes the lighting dark if you

do not operate the player or

remote for a short while.

CUSTOM SETUP

AUTO POWER OFF:

AUTO PLAY:

DIMMER:

OFF

OFF

BRIGHT

AUTO

PAUSE MODE:

AUTO

AUDIO (HDMI):

OFF

TRACK SELECTION: ON

MULTI-DISC RESUME:

AUTO The picture, including subjects

that move dynamically, is

output with no jitter. Normally

select this position.

FRAME The picture, including subjects

that do not move dynamically,

is output in high resolution.

OFF No priority given.

AUTO Priority given.

ON Stores the resume setting in

memory for up to 6 discs.

OFF Does not store the resume

setting in memory. Playback

restarts at the resume point only

for the current disc in the player.

,continued

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US13ADV4-CEK.fm

master page=left

66

DVP-NS75H

2-662-865-11(1)

◆AUDIO (HDMI)

Selects the type of audio signal output from

the HDMI OUT jack.

Note

A loud noise (or no sound) will be output if you

connect the player to a TV that is not compatible

with DOLBY DIGITAL/DTS signals and “AUTO”

is selected. In this case, select “PCM.”

Settings for the Sound

(AUDIO SETUP)

“AUDIO SETUP” allows you to set the sound

according to the playback and connection

conditions.

Select “AUDIO SETUP” in the Setup

Display. To use the display, see “Using the

Setup Display” (page 61).

The default settings are underlined.

◆AUDIO ATT (attenuation)

If the playback sound is distorted, set this

item to “ON.” The player reduces the audio

output level.

This function affects the output of the LINE

OUT L/R (AUDIO) jacks.

◆AUDIO DRC (Dynamic Range Control)

(DVD VIDEO/DVD-VR mode only)

Makes the sound clear when the volume is

turned down when playing a DVD that

conforms to “AUDIO DRC.”

This function affects the output from the

following jacks:

– LINE OUT L/R (AUDIO) jacks

– DIGITAL OUT (OPTICAL or COAXIAL)/

HDMI OUT jack only when “DOLBY

DIGITAL” is set to “D-PCM” (page 67).

AUTO Normally, select this. Outputs

audio signals according to the

“DIGITAL OUT” settings

(page 67).

PCM Converts Dolby Digital, or

96 kHz/24 bit PCM signals to

48 kHz/16 bit PCM.

OFF Normally, select this position.

ON Select this when the playback sound

from the speakers is distorted.

STANDARD Normally select this position.

TV MODE Makes low sounds clear even if

you turn the volume down.

WIDE

RANGE Gives you the feeling of being

at a live performance.

AUDIO SETUP

AUDIO ATT:

AUDIO DRC:

DIGITAL OUT:

OFF

STANDARD

AUDIO FILTER: SHARP

ON

DOWNMIX: DOLBY SURROUND

DOLBY DIGITAL:

DTS:

48kHz/96kHz PCM:

D-PCM

OFF

48kHz/16bit

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US13ADV4-CEK.fm

master page=right

67

Settings and Adjustments

DVP-NS75H

2-662-865-11(1)

◆AUDIO FILTER

Selects the digital filter to reduce noise above

22.05 kHz (Sampling frequency (Fs) of the

audio source is 44.1 kHz), 24 kHz (Fs is

48 kHz), or 48 kHz (Fs is above 96 kHz).

Note

There may be little effect by changing the digital

filter depending on the disc or playback

environment.

◆DOWNMIX (DVD VIDEO/DVD-VR mode

only)

Switches the method for mixing down to 2

channels when you play a DVD which has

rear sound elements (channels) or is recorded

in Dolby Digital format. For details on the

rear signal components, see “Checking the

audio signal format” (page 42). This function

affects the output of the following jacks:

– LINE OUT L/R (AUDIO) jacks

– DIGITAL OUT (OPTICAL or COAXIAL)/

HDMI OUT jack when “DOLBY

DIGITAL” is set to “D-PCM” (page 67).

◆DIGITAL OUT

Selects if audio signals are output via the

DIGITAL OUT (OPTICAL or COAXIAL)/

HDMI OUT jack.

Setting the digital output signal

Switches the method of outputting audio

signals when you connect a component such

as an amplifier (receiver) or MD deck with a

digital input jack.

For connection details, see page 21.

Select “DOLBY DIGITAL,” “DTS,” and

“48kHz/96kHz PCM” after setting

“DIGITAL OUT” to “ON.”

If you connect a component that is

incompatible with the selected audio signal, a

loud noise (or no sound) may be heard from

the speakers, risking damage to your ears or

speakers.

Notes

• The AV SYNC function (page 49) is not effective

if you use the DIGITAL OUT (OPTICAL or

COAXIAL) jack, and set “DOLBY DIGITAL” or

“DTS” to “DOLBY DIGITAL” or “ON”

respectively.

• The AV SYNC function (page 49) is not effective

if you connect a Dolby Digital or DTS-compliant

device via the HDMI OUT jack, and set “DOLBY

DIGITAL” or “DTS” to “DOLBY DIGITAL” or

“ON” respectively.

◆DOLBY DIGITAL (DVD VIDEO/DVD-VR

mode only)

Selects the type of Dolby Digital signal.

SHARP Provides a wide frequency range

and spatial feeling.

SLOW Provides smooth and warm

sound.

DOLBY

SUR-

ROUND

Normally, select this position.

Multi-channel audio signals are

output to 2 channels for enjoying

surround sounds.

NORMAL Multi-channel audio signals are

downmixed to 2 channels for use

with your stereo.

ON Normally select this position.

When you select “ON,” see

“Setting the digital output signal”

for further settings.

OFF The influence of the digital

circuit upon the analog circuit is

minimal. If you are using the

HDMI OUT jack, PCM sound

will be output depending on the

connected equipment.

If the signal is encrypted for

copyright protection purposes,

the signal is only output as

48 kHz/16 bit PCM.

D-PCM Select this when the player is

connected to an audio

component without a built-in

Dolby Digital decoder. You can

select whether the signals

conform to Dolby Surround

(Pro Logic) or not by making

adjustments to the

“DOWNMIX” item in

“AUDIO SETUP” (page 67).

,continued

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US13ADV4-CEK.fm

master page=left

68

DVP-NS75H

2-662-865-11(1)

Note

If the HDMI OUT jack is connected to equipment

not compatible with DOLBY DIGITAL signals, the

“D-PCM” signals will be automatically output even

when you select “DOLBY DIGITAL.”

◆DTS

Select the type of DTS audio signals.

Note

If the HDMI OUT jack is connected to equipment

not compatible with DTS signals, the “OFF” signals

will be automatically output even when you select

“ON.”

◆48kHz/96kHz PCM (DVD VIDEO only)

Selects the sampling frequency of the audio

signal.

Notes

• The analogue audio signals from the LINE OUT

L/R (AUDIO) jacks are not affected by this

setting and keep their original sampling frequency

level.

• If the HDMI OUT jack is connected to equipment

not compatible with 96 kHz/24 bit signals,

48 kHz/16 bit PCM will be automatically output

even when you select “96kHz/24bit.”

DOLBY

DIGITAL Select this when the player is

connected to an audio

component with a built-in

Dolby Digital decoder.

OFF Select this when the player is

connected to an audio

component without a built-in

DTS decoder.

ON Select this when the player is

connected to an audio

component with a built-in DTS

decoder.

48kHz/16bit The audio signals of DVD

VIDEOs are always converted

to 48kHz/16bit.

96kHz/24bit All types of signals including

96kHz/24bit are output in their

original format. However, if the

signal is encrypted for

copyright protection purposes,

the signal is only output as

48kHz/16bit.

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US14ADD-CEK.fm

master page=right

69

Additional Information

DVP-NS75H

2-662-865-11(1)

Additional Information

Troubleshooting

If you experience any of the following

difficulties while using the player, use this

troubleshooting guide to help remedy the

problem before requesting repairs. Should

any problem persist, consult your nearest

Sony dealer (For customers in the USA only).

Power

The power is not turned on.

,Check that the power cord is connected

securely.


There is no picture/picture noise appears.

,Re-connect the connecting cord securely.

,The connecting cords are damaged.

,Check the connection to your TV (page 17)

and switch the input selector on your TV so

that the signal from the player appears on

the TV screen.

,The disc is dirty or flawed.

,If the picture output from your player goes

through your VCR to get to your TV or if

you are connected to a combination TV/

VIDEO player, the copy-protection signal

applied to some DVD programs could affect

picture quality. If you still experience

problems even when you connect your

player directly to your TV, try connecting

your player to your TV’s S VIDEO input

(page 17).

,You have selected “PROGRESSIVE

AUTO” or “PROGRESSIVE VIDEO”

using the PROGRESSIVE button on the

front panel (the PROGRESSIVE indicator

lights up) even though your TV cannot

accept the progressive signal. In this case,

disconnect the HDMI cord from the player

and then select “NORMAL

(INTERLACE)” so that the

PROGRESSIVE indicator turns off.

,Even if your TV is compatible with

progressive format 480p signals, the image

may be affected when you set the player to

progressive format. In this case, select

“NORMAL (INTERLACE)” using the

PROGRESSIVE button on the front panel

so that the PROGRESSIVE indicator turns

off and the player is set to normal (interlace)

format.

,The player is connected to an input device

that is not HDCP compliant (the HDMI

indicator on the front panel does not light

up). See page 18.

,If the HDMI OUT jack is used for video

output, changing the “HDMI

RESOLUTION” setting in “SCREEN

SETUP” may solve the problem (page 63).

Connect the TV and the player using a video

jack other than the HDMI OUT, and switch

the TV’s input to the connected video input

so that you can see the on-screen displays.

Change the “HDMI RESOLUTION”

setting in “SCREEN SETUP,” and switch

the TV’s input back to HDMI. If the picture

still does not appear, repeat the steps and try

other options.

,If the signal from the LINE OUT (VIDEO)

or S VIDEO OUT jacks is distorted, change

the “HDMI RESOLUTION” setting in

“SCREEN SETUP” to “720 × 480p.”

There is no picture or the picture noise

appears when connected to the HDMI OUT

jack.

,Try the following: 1Turn the player off

and on again. 2Turn the connected

equipment off and on again. 3Disconnect

and then connect the HDMI cord again.

The picture does not fill the screen, even

though the aspect ratio is set in “TV TYPE”

under “SCREEN SETUP.”

,The aspect ratio of the disc is fixed on your

DVD.

Sound

There is no sound.

,Re-connect the connecting cord securely.

,The connecting cord is damaged.

,The player is connected to the wrong input

jack on the amplifier (receiver) (page 21).

,The amplifier (receiver) input is not

correctly set.

,The player is in pause mode or in Slow-

motion Play mode.

,The player is in fast forward or fast reverse

mode.

,If the audio signal does not come through

the DIGITAL OUT (OPTICAL or

COAXIAL)/HDMI OUT jack, check the

audio settings (page 67).

,While playing a Super VCD on which the

audio track 2 is not recorded, no sound will

come out when you select “2:STEREO,”

“2:1/L,” or “2:2/R.” ,continued

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US14ADD-CEK.fm

master page=left

70

DVP-NS75H

2-662-865-11(1)

,The equipment connected to the HDMI

OUT jack does not conform to the audio

signal format, in this case set

“AUDIO(HDMI)” in “CUSTOM SETUP”

to “PCM” (page 66).

No sound is output from the HDMI OUT

jack

,Try the following: 1Turn the player off

and on again. 2Turn the connected

equipment off and on again. 3Disconnect

and then connect the HDMI cord again.

,The HDMI OUT jack is connected to a DVI

device (DVI jacks do not accept audio

signals).

Sound distortion occurs.

,Set “AUDIO ATT” in “AUDIO SETUP” to

“ON” (page 66).

The sound volume is low.

,The sound volume is low on some DVDs.

The sound volume may improve if you set

“AUDIO DRC” in “AUDIO SETUP” to

“TV MODE” (page 66).

,Set “AUDIO ATT” in “AUDIO SETUP” to

“OFF” (page 66).

Operation

The remote does not function.

,The batteries in the remote are weak.

,There are obstacles between the remote and

the player.

,The distance between the remote and the

player is too far.

,The remote is not pointed at the remote

sensor on the player.

The disc does not play.

,The disc is turned over.

,Insert the disc with the playback side facing

down.

,The disc is skewed.

,The player cannot play certain discs

(page 8).

,The region code on the DVD does not match

the player.

,Moisture has condensed inside the player

(page 5)

.

,The player cannot play a recorded disc that

is not correctly finalized

(page 9)

.

The MP3 audio track cannot be played

(page 51).

,The DATA CD is not recorded in an MP3

format that conforms to ISO 9660 Level 1/

Level 2 or Joliet.

,The DATA DVD is not recorded in MP3

format that conforms to UDF (Universal

Disk Format).

,The MP3 audio track does not have the

extension “.MP3.”

,The data is not formatted in MP3 even

though it has the extension “.MP3.”

,The data is not MPEG-1 Audio Layer III

data.

,The player cannot play audio tracks in

mp3PRO format.

,“MODE (MP3, JPEG)” is set to “IMAGE

(JPEG)” (page 54).

The JPEG image file cannot be played

(page 51).

,The DATA CD is not recorded in a JPEG

format that conforms to ISO 9660 Level 1/

Level 2, or Joliet.

,The DATA DVD is not recorded in JPEG

format that conforms to UDF (Universal

Disk Format).

,The file has an extension other than

“.JPEG” or “.JPG.”

,The image is larger than 3072 (width) ×

2048 (height) in normal mode, or more than

3,300,000 pixels in progressive JPEG.

(Some progressive JPEG files cannot be

displayed even if the file size is within this

specified capacity.)

,The image does not fit the screen (the image

is reduced).

,“MODE (MP3, JPEG)” is set to “AUDIO

(MP3)” (page 54).

The MP3 audio tracks and JPEG image

files start playing simultaneously.

,“MODE (MP3, JPEG)” is set to “AUTO”

(page 54).

The album/track/file names are not

displayed correctly.

,The player can only display numbers and

alphabet. Other characters are displayed as

“*”.

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US14ADD-CEK.fm

master page=right

71

Additional Information

DVP-NS75H

2-662-865-11(1)

The disc does not start playing from the

beginning.

,Program Play, Shuffle Play, Repeat Play, or

A-B Repeat Play is selected (page 30).

,Resume play has taken effect (page 27).

The player starts playing the disc

automatically.

,The disc features an auto playback function.

,“AUTO PLAY” in “CUSTOM SETUP” is

set to “ON” (page 65).

Playback stops automatically.

,While playing discs with an auto pause

signal, the player stops playback at the auto

pause signal.

Some functions such as Stop, Search, Fast

Play, Slow Play, Slow-motion Play,

Repeat Play, Shuffle Play or Program Play

cannot be performed.

,Depending on the disc, you may not be able

to do some of the operations above. Refer to

the operating manual that comes with the

disc.

The language for the sound track cannot

be changed.

,Try using the DVD’s menu instead of the

direct selection button on the remote

(page 28).

,Multilingual tracks are not recorded on the

DVD being played.

,The DVD prohibits the changing of the

language for the sound track.

The subtitle language cannot be changed

or turned off.

,Try using the DVD’s menu instead of the

direct selection button on the remote

(page 28).

,Multilingual subtitles are not recorded on

the DVD being played.

,The DVD prohibits the changing of

subtitles.

The angles cannot be changed.

,Try using the DVD’s menu instead of the

direct selection button on the remote

(page 28).

,Multi-angles are not recorded on the DVD

being played.

,The angle can only be changed when the

“ ” indicator lights up on the front panel

display (page 11).

,The DVD prohibits changing of the angles.

The player does not operate properly.

,When static electricity, etc., causes the

player to operate abnormally, unplug the

player.

5 numbers or letters are displayed on the

screen and on the front panel display.

,The self-diagnosis function was activated.

(See the table on page 72.)

The disc tray does not open and “LOCKED”

appears on the front panel display.

,Child Lock is set (page 26).

The disc tray does not open and “TRAY

LOCKED” appears on the front panel

display.

,Contact your Sony dealer or local

authorized Sony service facility.

“Data error” appears on the TV screen

when playing a DATA CD/DATA DVD.

,The MP3 audio track/JPEG image file you

want to play is broken.

,The data is not MPEG-1 Audio Layer III

data.

,The JPEG image file format does not

conform to DCF (page 50).

,The JPEG image file has the extension

“.JPG” or “.JPEG,” but is not in JPEG

format.

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US14ADD-CEK.fm

master page=left

72

DVP-NS75H

2-662-865-11(1)

Self-diagnosis Function

(When letters/numbers appear in the

display)

When the self-diagnosis function is activated

to prevent the player from malfunctioning, a

five-character service number (e.g., C 13 50)

with a combination of a letter and four digits

appears on the screen and the front panel

display. In this case, check the following

table.

Glossary

Album (page 50, 52)

A unit in which to store JPEG image files or

MP3 audio tracks on a DATA CD/DATA

DVD. (“Album” is an exclusive definition for

this player.)

Chapter (page 13)

Sections of a picture or a music feature that

are smaller than titles. A title is composed of

several chapters. Depending on the disc, no

chapters may be recorded.

Dolby Digital (page 21, 67)

Digital audio compression technology

developed by Dolby Laboratories. This

technology conforms to multi-channel

surround sound. The rear channel is stereo

and there is a discrete subwoofer channel in

this format. Dolby Digital provides the same

discrete channels of high quality digital audio

found in “Dolby Digital” theater surround

sound systems. Good channel separation is

realized because all of the channel data is

recorded discretely and little deterioration is

realized because all channel data processing

is digital.

DTS (page 21, 68)

Digital audio compression technology that

Digital Theater Systems, Inc. developed. This

technology conforms to multi-channel

surround sound. The rear channel is stereo

and there is a discrete subwoofer channel in

this format. DTS provides the same discrete

channels of high quality digital audio.

Good channel separation is realized because

all of the channel data is recorded discretely

and little deterioration is realized because all

channel data processing is digital.

DVD VIDEO (page 7)

A disc that contains up to 8 hours of moving

pictures even though its diameter is the same

as a CD.

The data capacity of a single-layer and single-

sided DVD is 4.7 GB (Giga Byte), which is 7

times that of a CD. The data capacity of a

double-layer and single-sided DVD is 8.5

GB, a single-layer and double-sided DVD is

First three

characters of

the service

number

Cause and/or corrective

action

C 13 The disc is dirty or recorded

in a format that this player

cannot play (page 8).

,Clean the disc with a

cleaning cloth or check its

format (page 2).

C 31 The disc is not inserted

correctly.

,Re-insert the disc

correctly.

E XX

(xx is a number) To prevent a malfunction, the

player has performed the

self-diagnosis function.

,Contact your nearest

Sony dealer or local

authorized Sony service

facility and give the 5-

character service number.

Example: E 61 10

C:13:50

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US14ADD-CEK.fm

master page=right

73

Additional Information

DVP-NS75H

2-662-865-11(1)

9.4 GB, and double-layer and double-sided

DVD is 17 GB.

The picture data uses the MPEG 2 format, a

worldwide standard of digital compression

technology. The picture data is compressed to

about 1/40 (average) of its original size. The

DVD also uses a variable rate coding

technology that changes the data to be

allocated according to the status of the

picture. Audio information is recorded in a

multi-channel format, such as Dolby Digital,

allowing you to enjoy a more realistic audio

presence.

Furthermore, various advanced functions

such as the multi-angle, multilingual, and

Parental Control functions are provided with

the DVD.

DVD-RW (page 7)

A DVD-RW is a recordable and rewritable

disc that is the same size as a DVD VIDEO.

The DVD-RW has two different modes: VR

mode and Video mode. DVD-RWs created in

Video mode have the same format as a DVD

VIDEO, while discs created in VR (Video

Recording) mode allow the contents to be

programmed or edited.

DVD+RW (page 7)

A DVD+RW (plus RW) is a recordable and

rewritable disc. DVD+RWs use a recording

format that is comparable to the DVD VIDEO

format.

File (page 50, 53)

A JPEG image recorded on a DATA CD/

DATA DVD (“File” is an exclusive

definition for this player.) A single file

consist of a single image.

Film based software, Video based

software (page 20)

DVDs can be classified as Film based or

Video based software. Film based DVDs

contain the same images (24 frames per

second) that are shown at movie theaters.

Video based DVDs, such as television

dramas or sit-coms, displays images at 30

frames/60 fields per second.

HDMI (High-Definition Multimedia

Interface)

HDMI is an interface that supports both video

and audio on a single digital connection. The

HDMI connection carries standard to high

definition video signals and multi-channel

audio signals to AV components such as

HDMI equipped TVs, in digital form without

degradation.

Since the video signals are compatible with

the current DVI (Digital Visual Interface)

format, HDMI jacks can be connected to DVI

jacks by way of an HDMI-DVI converter

cord. The HDMI specification supports

HDCP (High-bandwidth Digital Contents

Protection), a copy protection technology that

incorporates coding technology for digital

video signals.

Normal (Interlace) format (page 20)

Normal (Interlace) format shows every other

line of an image as a single “field” and is the

standard method for displaying images on

television. The even number field shows the

even numbered lines of an image, and the odd

numbered field shows the odd numbered lines

of an image.

Progressive format (page 20)

Compared to the Interlace format that

alternately shows every other line of an image

(field) to create one frame, the Progressive

format shows the entire image at once as a

single frame. This means that while the

Interlace format can show 30 frames/60 fields

in one second, the Progressive format can

show 60 frames in one second. The overall

picture quality increases and still images,

text, and horizontal lines appear sharper. This

player is compatible with the 480 progressive

format.

Progressive JPEG

Progressive JPEGs are used mostly on the

internet. They are different from other JPEGs

in that they “fade in” gradually instead of

being drawn from top to bottom when

displayed on a browser. This lets you view the

image while it is being downloaded.

Title (page 11)

The longest section of a picture or music

feature on a DVD, movie, etc., in video

software, or the entire album in audio

software.

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US14ADD-CEK.fm

master page=left

74

DVP-NS75H

2-662-865-11(1)

Specifications

System

Laser: Semiconductor laser

Signal format system: NTSC

Audio characteristics

Frequency response: DVD VIDEO (PCM

96 kHz): 2 Hz to 44 kHz (±1.0 dB)/DVD

VIDEO (PCM 48 kHz): 2 Hz to 22 kHz

(±0.5 dB)/CD: 2 Hz to 20 kHz (±0.5 dB)

Signal-to-noise ratio (S/N ratio): 115 dB

(LINE OUT L/R (AUDIO) jacks only)

Harmonic distortion: 0.003 %

Dynamic range: DVD VIDEO: 103 dB/

CD: 99 dB

Wow and flutter: Less than detected value

(±0.001% W PEAK)

Outputs

(Jack name: Jack type/Output level/Load

impedance)

LINE OUT (AUDIO): Phono jack/2 Vrms/

10 kilohms

DIGITAL OUT (OPTICAL): Optical

output jack/–18 dBm (wave length

660 nm)

DIGITAL OUT (COAXIAL): Phono jack/

0.5 Vp-p/75 ohms

HDMI OUT: Type A (19 pin)

COMPONENT VIDEO OUT(Y, PB, PR):

Phono jack/Y: 1.0 Vp-p/PB, PR:

interlace*1 = 0.648 Vp-p, progressive or

interlace*2 = 0.7 Vp-p/75 ohms

*1BLACK LEVEL (COMPONENT OUT) is ON

*2BLACK LEVEL (COMPONENT OUT) is OFF

LINE OUT (VIDEO): Phono jack/1.0 Vp-p/

75 ohms

S VIDEO OUT: 4-pin mini DIN/Y:

1.0 Vp-p, C: 0.286 Vp-p/75 ohms

General

Power requirements:

120 V AC, 60 Hz

Power consumption: 12 W

Dimensions (approx.):

430 × 43 × 237 mm (width/height/depth)

incl. projecting parts

Mass (approx.): 1.92 kg

Operating temperature: 5°C to 35 °C

Operating humidity: 25 % to 80 %

Supplied accessories

See page 16.

Specifications and design are subject to

change without notice.

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US14ADD-CEK.fm

master page=right

75

Additional Information

DVP-NS75H

2-662-865-11(1)

Language Code List

For details, see pages 41, 44, 62.

The language spellings conform to the ISO 639: 1988 (E/F) standard.

Parental Control Area Code List

For details, see page 57.

Code Language Code Language Code Language Code Language

1027 Afar

1028 Abkhazian

1032 Afrikaans

1039 Amharic

1044 Arabic

1045 Assamese

1051 Aymara

1052 Azerbaijani

1053 Bashkir

1057 Byelorussian

1059 Bulgarian

1060 Bihari

1061 Bislama

1066 Bengali;

Bangla

1067 Tibetan

1070 Breton

1079 Catalan

1093 Corsican

1097 Czech

1103 Welsh

1105 Danish

1109 German

1130 Bhutani

1142 Greek

1144 English

1145 Esperanto

1149 Spanish

1150 Estonian

1151 Basque

1157 Persian

1165 Finnish

1166 Fiji

1171 Faroese

1174 French

1181 Frisian

1183 Irish

1186 Scots Gaelic

1194 Galician

1196 Guarani

1203 Gujarati

1209 Hausa

1217 Hindi

1226 Croatian

1229 Hungarian

1233 Armenian

1235 Interlingua

1239 Interlingue

1245 Inupiak

1248 Indonesian

1253 Icelandic

1254 Italian

1257 Hebrew

1261 Japanese

1269 Yiddish

1283 Javanese

1287 Georgian

1297 Kazakh

1298 Greenlandic

1299 Cambodian

1300 Kannada

1301 Korean

1305 Kashmiri

1307 Kurdish

1311 Kirghiz

1313 Latin

1326 Lingala

1327 Laothian

1332 Lithuanian

1334 Latvian;

Lettish

1345 Malagasy

1347 Maori

1349 Macedonian

1350 Malayalam

1352 Mongolian

1353 Moldavian

1356 Marathi

1357 Malay

1358 Maltese

1363 Burmese

1365 Nauru

1369 Nepali

1376 Dutch

1379 Norwegian

1393 Occitan

1403 (Afan)Oromo

1408 Oriya

1417 Punjabi

1428 Polish

1435 Pashto;

Pushto

1436 Portuguese

1463 Quechua

1481 Rhaeto-

Romance

1482 Kirundi

1483 Romanian

1489 Russian

1491 Kinyarwanda

1495 Sanskrit

1498 Sindhi

1501 Sangho

1502 Serbo-

Croatian

1503 Singhalese

1505 Slovak

1506 Slovenian

1507 Samoan

1508 Shona

1509 Somali

1511 Albanian

1512 Serbian

1513 Siswati

1514 Sesotho

1515 Sundanese

1516 Swedish

1517 Swahili

1521 Tamil

1525 Telugu

1527 Tajik

1528 Thai

1529 Tigrinya

1531 Turkmen

1532 Tagalog

1534 Setswana

1535 Tonga

1538 Turkish

1539 Tsonga

1540 Tatar

1543 Twi

1557 Ukrainian

1564 Urdu

1572 Uzbek

1581 Vietnamese

1587 Volapük

1613 Wolof

1632 Xhosa

1665 Yoruba

1684 Chinese

1697 Zulu

1703 Not specified

Code Area Code Area Code Area Code Area

2044 Argentina

2047 Australia

2046 Austria

2057 Belgium

2070 Brazil

2079 Canada

2090 Chile

2092 China

2115 Denmark

2165 Finland

2174 France

2109 Germany

2248 India

2238 Indonesia

2254 Italy

2276 Japan

2304 Korea

2363 Malaysia

2362 Mexico

2376 Netherlands

2390 New Zealand

2379 Norway

2427 Pakistan

2424 Philippines

2436 Portugal

2489 Russia

2501 Singapore

2149 Spain

2499 Sweden

2086 Switzerland

2528 Thailand

2184 United

Kingdom

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US01COVIX.fm

master page=left

76

DVP-NS75H

2-662-865-11(1)

Index

Numerics

16:9

63

4:3 LETTER BOX

63

4:3 PAN SCAN

63

48kHz/96kHz PCM

68

5.1 Channel Surround

22

A

A-B REPEAT

33

ADVANCE

26

ALBUM

36

Album

50, 72

ANGLE

44

AUDIO

41, 62

AUDIO ATT

66

AUDIO DRC

66

AUDIO FILTER

67

AUDIO SETUP

66

AUTO PLAY

65

AUTO POWER OFF

65

AV SYNC

49

B

BACKGROUND

64

Batteries

16

BLACK LEVEL

64

BLACK LEVEL

(COMPONENT OUT)

64

BNR

47

C

CD

8, 25

CHAPTER

35

Chapter

72

CHAPTER VIEWER

37

Checking the audio signal

format

42

Child Lock

26

Connecting

17

Continuous play

CD/VIDEO CD

25

DVD

25

Control Menu

13

CUSTOM

61

CUSTOM PARENTAL

CONTROL

56

CUSTOM PICTURE MODE

45

CUSTOM SETUP

65

D

DATA CD

7, 50

DATA DVD

7, 50

DATE

53

DIGITAL OUT

67

Digital output

67

DIMMER

65

Display

Control Menu Display

13

Front panel display

11

Setup Display

61

DOLBY DIGITAL

41, 67, 72

DOWNMIX

67

DTS

41, 68, 72

DVD

7, 25, 72

DVD+RW

7, 26, 73

DVD’s menu

28

DVD-RW

7, 28, 73

E

EFFECT

55

F

Fast forward

34

FAST PLAY

26

Fast reverse

34

FILE

36

File

73

Film based software

20, 73

Freeze Frame

35

Front panel display

11

H

Handling discs

2

HDMI

AUDIO (HDMI)

66

HDMI

73

HDMI RESOLUTION

63

Hooking up

16

I

INDEX

36

Interlace format

73

INTERVAL

55

J

JPEG

7, 50

L

LANGUAGE SETUP

62

Locating

a specific point by watching

the TV screen

34

M

MEMORY

45

MENU

62

MNR

48

MODE (MP3, JPEG)

54

MP3

7, 50

MULTI-DISC RESUME

27,

65

N

NORMAL (INTERLACE)

20

Normal (Interlace) format

73

O

On-screen display

Control Menu Display

13

Setup Display

61

ORIGINAL

28

ORIGINAL/PLAY LIST

28

OSD

62

P

PARENTAL CONTROL

56

PAUSE MODE

65

PBC Playback

29

PICTURE NAVIGATION

37,

53

PLAY LIST

28

PROGRAM

30

Program Play

30

PROGRESSIVE AUTO

20

Progressive format

73

PROGRESSIVE VIDEO

20

Q

QUICK

62

Quick Setup

23, 62

R

Remote

12, 16, 59

REPEAT

32

Repeat Play

32

REPLAY

26

RESET

62

S

Scan

34

SCENE

35

SCREEN SAVER

64

SCREEN SETUP

63

Searching

34

SETUP

61

Setup Display

61

SHARPNESS

46

SHUFFLE

32

Shuffle Play

32

Slide Show

54

SLOW PLAY

26

Slow-motion Play

35

Speakers

Hooking up

21

SUBTITLE

44, 62

Surround

42

T

TIME/TEXT

38

TITLE

35

Title

73

TITLE VIEWER

37

TOP MENU

28

TRACK

36

Track

11

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US01COVIX.fm

master page=right

77

DVP-NS75H

2-662-865-11(1)

Additional Information

TRACK SELECTION

65

TRACK VIEWER

37

Troubleshooting

69

TV TYPE

63

TVS (TV Virtual Surround)

42

U

Usable discs

8

V

Video based software

20, 73

VIDEO CD

7, 25

Z

ZOOM

26, 53

F:\SONY DVD\2662865112 DVP-

NS75H_US\SOURCE\DVP-

NS75H_US\01US15BCO-CEK.fm

master page=left

Sony Corporation Printed in Malaysia

Printed on 100% recycled paper using

VOC (Volatile Organic Compound)-free

vegetable oil based ink.

DVP-NS75H

2-662-865-11(2)
