FWD-
42PX2
Plasma Display
Shown with silver bezel and matching speakers (SS-SP42FW/S)
Key Features
High Definition Plasma: Brilliant image quality with
ability to display over 1 billion colors delivers hi-
contrast video and sharp text for any display
solution.
Progressive Scan Display: 1024 x 768 progressive
scan display maximizes video performance; ideal
for PC and HDTV content.
Multiple Input Connectivity: DVI-D (HDCP), HD-15
(RGB), HD-15 (YUV/Component), Composite Y/C
(S-Video) inputs provide hook-up flexibility.
Flexible Option Boards: Optional input boards to
match the exacting needs of the display
application.
High Resolution Video Display: This HD monitor is
able to display video resolutions up to 1080i.
Key Technologies
High Definition Plasma Brilliant image quality with ability to display over 1 billion colors delivers hi-contrast
video and sharp text for any display solution.
Multiple Input Connectivity
DVID (HDCP), HD
-
15 (RBG), HD
-15 (YUV/Component), Composite Y/C(S-
Video)
inputs provide hook-up flexibility.
Flexible Option Boards Optional input boards to match the exacting needs of the display application.
Network Management Card (BKM-FW32), Network Media Card (BKM-FW50), Internal TV Tuner (ICS-SP20)
Progressive Scan Display 1024 x 768 progressive scan display maximizes video performance; ideal for PC
and HDTV content.
High Resolution Video Display This HD monitor is able to display video resolutions up to 1080i.
Extra Long Panel Life Long panel life combined with low power consumption ensures years of energy-
efficient operation. Screen saver functions include auto-dimmer and on/off timer and help ensure maximum
panel life.
FWD-
42PX2
Plasma Display
Sony Electronics Inc. •
16530 Via Esprillo
• San Diego, CA 92127 • 1-800-222-7669 • www.sony.com
Last Updated: 04/27/2006
Shown with silver bezel (Speakers Optional)
Please visit the Dealer Network for current
information at www.sony.com/dn
Features
Video
Picture Modes: Custom (3), Vivid, Standard
Color Temperature:
Cool, Neutral, Warm
Panel Type: AC-
Type Plasma Display Panel
Screen or Display Technology: PlasmaPRO
Video Processing:
WEGA Engine
™
Technology
Convenience
Multiple Language Display:
English, French,
Spanish, Italian, German, Japanese, Dutch,
Swedish, Russian, Chinese
Picture and Picture: Yes
-
in
-
Picture: Yes
Specifications
General
Screen Size:
42.0"
Video
Horizontal Scan (KHz) for PC: N/A
Closed Caption Decoder: Yes
Contrast Ratio:
10000:1
Display Resolution:
1024 x 768
Image Retention Protection:
Auto Wide Mode,
Background, Multi
-
Mode Picture Orbit, Picture
Inversion, Power Save, Smart Fan Technology,
Timers, White Screen
Viewing Angle:
Horizontal: 178
°
,
Vertical: 178
°
Audio
Audio Power Output:
14W Total (7Wx2 Digital
AMP)
Convenience
Cable Management System: Yes
On Screen Controls: Yes
Wall/Arm Mount: Yes (capable)
Inputs and Outputs
Analog Audio Input(s):
1 (Side)
Analog Audio Output(s): Speakers (L/R)
Optional
Analog Video Input(s):
1 (Side)
DVI Connection Input(s):
1 DVI
-D (HDCP)
(Bottom)
PC Audio Input(s): 1 (per input)
PC Video Input(s):
1 (Bottom))
-
D
-
sub 15
Component Video (Y/Pb/Pr ) Input(s):
1 (Side)
Optional
Composite Video Input(s):
1 (Side)
Control
-
S Input(s):
1 (Bottom)
Control
-
S Output(s):
1 (Bottom)
RCA Audio Input(s): RCA (L/R)
RF Connection Input(s):
1 (optional)
RS232 Control:
1 (Bottom)
S
-
Video Input(s):
1 (Side)
S
-
Video Output(s):
1 (Side)
Video In (BNC):
1 (optional)
Power
Internal Power Supply: Yes
Power Consumption:
330 W (typ.)
Power Requirements:
AC 100 to 240 V, 50 / 60
Hz,
Regulation and Standard
Compliance
Emissions/Ergonomics: N/A
Energy Star
®
Compliant: N/A
Plug & Play:
N/A
Safety Regulations:
UL60950, CSA No.60950
(c-
UL), CE LVD (EN60950), Den
-an, FCC Class-
B, IC Class-B, VCCI Class-B, CE EMC
(EN55022 Class
-
B, EN55024, EN61000
-
3
-
2,
EN61000
-
3
-3), C-
Tick (AS/NZS 3548/95,
AS/NZS 4252.1), JEITA, KSA, PAI, CCC
Service and Warranty Information
Extended Warranty:
Optional Plans for up to 5
years on-
site service in most areas.
Limited Warranty: 2 years parts, 2 years labor,
1 year panel including on
-
site service in most
areas.
Dimensions
Weight:
66.1 lbs..
Measurements:
40.7" x 24.9" x 4.77" w/out
speakers; 48.2" x 24.9" x 4.77" w/ speakers
Operating Conditions
Colors:
1.07 billion
Luminance: 450cd/m²
Pixel Pitch:
0.90 x 0.676 mm
Screen Treatment:
Anti
-
Glare, Anti
-
Reflective
Vertical Refresh Range: N/A
Software
Operating System Compatibility: N/A
Hardware
Color Systems: NTSC, PAL, SECAM,
NTSC4.43, PAL60, PAL
-M, PAL-N
Mount Design:
Landscape, Portrait
Remote Control:
Multi
-
Function Remote
Supplied Accessories
DVID cable, HD
-
15 to Component (RCA) cable, AC
Power Cord, Remote Control, Operating
Instructions, AC Plug Holder (2), AA/R6 Size
Battery (2), Cable Holder (4)
Optional Accessories
Networking Boxes and Cards: NSP-
1 (Content,
Status, Control and Storage sent over IP), BKM
-
FW32 (Status and Control sent over IP and
connectivity to PJNet), BKM
-
FW50 (Network
Media Card designed as a simple,
dependable,low cost digital signage solution).
EBS-
N200D (Status, Control, Storage and
Streaming realtime Video sent over IP)
Tiltable Wall Mount PLP
-
91/D: Tiltable Wall Mount Kit
supporting Portait, Landscape and Tilt (up to 15
degrees). Also, allows room for EBS
accessories.
Stationary Wall Mount SFM1: Stationary Wall Mount
Kit supports Landscape mode.
Optional Speakers: SS
-SP42FW/S (Silver) and SS-
SP42FW/B (Black)
Table Top Stands: SPM
-TRI/E (Silver Base Stand),
SPM-TRI/C (Clear Acrylic Base Stand)
ICS-
SP20: Internal TV Tuner/smartplug perfect for
hospitality or home use
BKM-
FW11: Component/5 BNC input
BKM-
FW12: Component/RGB loop through.
Color:
Black (FWD
-
42PX2/B), Silver (FWD
-
42PX2/S)
©2006 Sony Electronics Inc.
Features and specifications are subject to change without notice. Non-
metric weights and measures are approximate.
Sony is a trademark of Sony. All other trademarks are property of their
respective owners.
