FD Trinitron®– Unprecedented image performance,
featuring the finest aperture grille pitch available
(0.22mm) and flattest Trinitron®display ever, gives
demanding CAD and graphic professionals the edge
F Series
•Tightest Aperture Grille Pitch Available – 0.22mm aperture grille pitch across the entire screen
•Bright Picture, Sharp Images – Sony’s new HiDensity™Electron Gun with Enhanced Elliptical Correction
System™technology
•Digital Multiscan®Technology – Supports the broadest range of PC and Mac®display resolutions
•Stable, Consistent Color And Images – Sony’s GeoLockPlus™circuitry provides improved color and
brightness uniformity
•Easy To Navigate On-Screen Display – DisplayMouse™control allows for quick, smooth adjustments of the
digital controls
•Instant Sizing And Centering Of Image – Active Signal Correction (ASC™) circuitry provides easy image adjustment
at the touch of a single button
•Generalized Timing Formula (GTF) - Insures compatibility with varying video standards, reduces set-up time and
maximizes the performance of the display system
•Reduced Depth Design – Smart cable design allows for overall shorter depth of display on desktop
•Comprehensive Digital OSD – Six languages with features such as image zoom, color and temperature adjustment,
control lock, landing correction and information screen
•Dual Input Control – 15 pin mini D-sub and 5 BNC connector options
•USB Compatibility – Self-powered USB hub built into base with one upstream and four downstream ports
Multiscan®Computer Displays with FD Trinitron
GDM-F500 and GDM-F400
GDM-F500 Sony FD Trinitron Computer Display
CRT: 21" FD Trinitron (19.8" Viewable Image Size)
Horizontal Scan Range: 30-121kHz
Vertical Scan Range: 48-160Hz
Maximum Resolution: 1800 x 1440 @ 80Hz
Dimensions (WxHxD): 19.8" x 20.0" x 19.1"
Weight: 70.5 lbs
GDM-F400 Sony FD Trinitron Computer Display
CRT: 19" FD Trinitron (18" Viewable Image Size)
Horizontal Scan Range: 30-107kHz
Vertical Scan Range: 48-120Hz
Maximum Resolution: 1600 x 1200 @ 85Hz
Dimensions (WxHxD): 17.5" x 18.7" x 17.9"
Weight: 60.6 lbs
S
pecifications
Dimensions (WxHxD)
GDM-F500: 19.8" x 20.0" x 19.1"
GDM-F400: 17.5" x 18.7" x 17.9"
Weight
GDM-F500: 70.5 lbs
GDM-F400: 60.6 lbs
Operating Temperature
50°F-104°F (10°C-40°C)
Operating Humidity
10%-80% (Non-Condensing)
Regulation Compliance
Safety: UL 1950
CSA 22.2 No. 950
EN60950 (TUV, GS mark)
Emission/EMI: FCC Class B
IC Class B
MPR II TUV (full compliance)
TCO 95
X-ray: DHHS
DNHW
PTB
Ergonomics: ZH1/618, ISO9241-3, 8
Designed for: Microsoft Windows®2000
Windows®98
Macintosh Compatible
Plug & Play: DDC-1, DDC-2B/A, DDC-CI
DMI Compliant
VESA: Generalized Timing Formula (GTF)
Front Panel Digital Controls
Power On/Off
Active Signal Correction (ASC™)
Reset
Brightness
Contrast
Input Switching Button
On-Screen Display (OSD)
Brightness/Contrast
H/V Size
H/V Centering
Zoom
Raster Rotation
Pincushion
Pin Balance
Keystone
Key Balance
Color Temperature
H/V Convergence: Top/Bottom
Landing Correction (4 Corners)
Moiré Cancellation
Manual Degauss
Power Save Delay
H/V OSD Position
Control Lock
Multi-Language Select (6 languages)
Supplied Accessories
Tilt Base/Wide Angle Swivel (±90°) Stand
Video Signal Cable (15 pin mini D-sub)
AC Power Cord
Macintosh Adapter
Windows 95/98 inf. Diskette
USB Cable
Limited Warranty
3 Years - Parts, Labor and CRT
CRT
GDM-F500: 21" FD Trinitron®
GDM-F400: 19" FD Trintron®
Viewable Image Size
GDM-F500: 19.8"
GDM-F400: 18"
Aperture Grille Pitch
0.22mm
Screen Treatment
Anti-Reflective Coating
Electron Gun
HiDensity™ Electron Gun with Enhanced Elliptical
Correction System™ technology
Horizontal Scan Range
GDM-F500: 30-121kHz
GDM-F400: 30-107kHz
Vertical Scan Range
GDM-F500: 48-160Hz
GDM-F400: 48-120Hz
Maximum Resolution
GDM-F500: 1800 x 1440 @ 80Hz
GDM-F400: 1600 x 1200 @ 85Hz
Preset Resolutions (27 modes)
640 x 480 @ 60Hz VGA Graphics
640 x 480 @ 85Hz VESA
800 x 600 @ 85Hz VESA
832 x 624 @ 75Hz Macintosh®16"
1024 x 768 @ 75Hz Macintosh®19"
1024 x 768 @ 85Hz VESA
1152 x 864 @ 75Hz VESA
1152 x 870 @ 75Hz Macintosh 2-page
1280 x 1024 @ 75/85Hz VESA
1600 x 1200 @ 75/85Hz VESA
1800 x 1350 @ 85Hz Sony (GDM-F500 only)
1800 x 1440 @ 80Hz Sony (GDM-F500 only)
and others
Color Temperature Presets
5000 Kelvin
6500 Kelvin
9300 Kelvin
3 User-Adjustable Settings (Bias/Gain Control)
Signal Inputs
Analog RGB
0.7Vp-p, 75ohm Termination
External Sync Signals
Separate/Composite 1-5Vp-p, polarity-free
TTL Sync on Green: 0.3Vp-p, negative
Input Connectors
15 pin mini D-sub and 5 BNC connectors
Power Requirements
100-240V AC; 50-60Hz
Power Management
International Energy Star, NUTEK and VESA
DPMS Compliant
GDM-F500
Operation: 140 watts (maximum)
Suspend: 8 watts (maximum)
Active Off: 1 watt (maximum)
Power Off: <1 watt
GDM-F400
Operation: 160 watts (maximum)
Suspend: 10 watts (maximum)
Active Off: 3 watts (maximum)
Power Off: <1 watt
F Series
Multiscan®Computer Displays with FD Trinitron®
GDM-F500 and GDM-F400
Sony Electronics Inc.
Information Technologies Marketing Division
3300 Zanker Road, San Jose, California 95134
For more information: 1.800.352.SONY
Web address: http://www.sony.com/displays
Computer Interface: The computer industry lacks standards, and therefore, there are a multitude of varying software packages and add-on hardware options. This display is not manufactured to any specific software, and
Sony does not and cannot make any warranty or representation with respect to the performance of this product with any particular software packages and/or non-Sony add-on hardware option except those mentioned in this
document. Sony hereby disclaims any representations or warranty that this product is compatible with any combination of non-Sony products you may choose to connect. While Sony representatives or Sony authorized
dealers may be able to assist you and may make recommendations, they are NOT authorized to vary or waive this disclaimer. Purchasers must determine for themselves the suitability and compatibility of the hardware and
software in each and every particular instance.
©1999 Sony Electronics Inc. All rights reserved. Reproduction in whole or in part without written permission is prohibited. Sony, the Sony logo, displays by sony, Multiscan, Trinitron, FD Trinitron, Digital Multiscan, HiDensity
Electron Gun, GeoLock Plus, DisplayMouse, ASC and Enhanced Elliptical Correction System are trademarks of Sony. Microsoft, the Windows Logo and Windows 2000 are registered trademarks of Microsoft Corporation. Macintosh
and Mac are trademarks of Apple Inc. Features and specifications are subject to change without notice. Non-metric weights and measurements are approximate.
This monitor is Energy Star Compliant when used with a computer equipped with VESA Display Power Management Signaling (DPMS). As an International Energy Star Partner, Sony Corporation has determined that this
product meets the International Energy Star Program for energy efficiency. The Energy Star emblem does not represent EPA endorsement of any product or service.
D174
Printed in U.S.A. 01/99
The Multiscan®FD Trinitron®displays offer the very
latest in advanced CRT display technology from
Sony: the FD Trinitron CRT. These virtually flat CRTs
minimize geometric distortion and reduce reflective
glare that may cause eyestrain. Designed with the
demanding CAD and graphic professionals in
mind, the Multiscan F Series sets a new level of
image performance, ease of use and reliability. The
stunning images produced by this display are a
result of Sony’s new HiDensity™Electron Gun with
Enhanced Elliptical Correction System™technology.
The tight 0.22mm aperature grille pitch delivers
sharp, detailed color images consistently across
the entire screen – especially in the corners. Digital
Multiscan®and Active Signal Correction (ASC™)
technologies allow for easy set-up, regardless of
the input signal or resolution. And with broad hori-
zontal scan rates available, resolutions as high as
1800 x 1440 @ 80Hz (F500) are possible. Our
unique DisplayMouse™control is easy-to-use and
allows for precise manual adjustment of the image
to fit individual user preference. Sony left nothing
to the imagination with this display, including
GeoLock Plus™circuitry. This feature will automati-
cally sense and neutralize electromagnetic fields
that can cause image or color distortion, which is
commonly noticeable on large screen displays. The
F Series is designed for Windows 2000 and
Windows 98, is Macintosh compatible and meets
or exceeds all of the industry safety standards,
including TCO 95 compliance.
