Introducing the Sony SXRD Projection TV
- Presenting the Sony SXRD Projection TV
- Enjoying Your SXRD Projection TV
Setting Up the SXRD Projection TV
Using the Remote Control
Using the Features
Using the Memory Stick Viewer
Using i.LINK
Using the Menus
Other Information
Index

Printed on 100% recycled paper.

SXRD

2-584-141-12(1)

Owner’s Record

The model and serial numbers are located at the rear of

the SXRD projection TV, below the Sony logo, on the

sticker, and also on the TV box (white label). Record

these numbers in the spaces provided below. Refer to

them whenever you call upon your Sony dealer regarding

this product.

Model No.

Serial No.

Contacting Sony

If, after reading the following instructions, you have

additional questions related to the use of your Sony TV,

Please call one of the following numbers.

Customers in the continental United States contact the

QUALIA Call Center at:

1-877-782-5423

Customers in Canada contact the Customer Relations

Center at:

1-877-899-SONY (7669)

SXRD

2-584-141-12(1)

WARNING

To prevent fire or shock hazard, do not

expose the SXRD projection TV to rain

or moisture.

This symbol is intended to alert the user to the

presence of uninsulated “dangerous voltage”

within the product’s enclosure that may be of

sufficient magnitude to constitute a risk of

electric shock to persons.

This symbol is intended to alert the user to the

presence of important operating and

maintenance (servicing) instructions in the

literature accompanying the appliance.

CAUTION

To prevent electric shock, do not use this polarized AC

plug with an extension cord, receptacle or other outlet

unless the blades can be fully inserted to prevent blade

exposure.

CAUTION

When using TV games, computers, and similar products

with your projection TV, keep the brightness and contrast

functions at low settings. If a fixed (non-moving) pattern

is left on the screen for long periods of time at a high

brightness or contrast setting, the image can be

permanently imprinted onto the screen. Continuously

watching the same program can cause the imprint of

station logos onto the TV screen. These types of imprints

are not covered by your warranty because they are the

result of misuse.

Note on Caption Vision

This television receiver provides display of television

closed captioning in accordance with §15.119 of the FCC

rules.

Note to CATV system installer

This reminder is provided to call the CATV system

installer’s attention to Article 820-40 of the NEC that

provides guidelines for proper grounding and, in

particular, specifies that the cable ground shall be

connected to the grounding system of the building, as

close to the point of cable entry as practical.

Use of this television receiver for other than private

viewing of programs broadcast on UHF, VHF,

transmitted by cable companies or satellite for the use of

the general public may require authorization from the

broadcaster/cable company and/or program owner.

NOTIFICATION

This equipment has been tested and found to comply with

the limits for a Class B digital device pursuant to Part 15

of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a

residential installation. This equipment generates, uses,

and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions,

may cause harmful interference with radio

communications. However, there is no guarantee that

interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio

or television reception, which can be determined by

turning the equipment off and on, the user is encouraged

to try to correct the interference by one or more of the

following measures:

❑Reorient or relocate the receiving antennas.

❑Increase the separation between the equipment and

receiver.

❑Connect the equipment into an outlet on a circuit

different from that to which the receiver is

connected.

❑Consult the dealer or an experienced radio/TV

technician for help.

This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions: (1)

This device may not cause harmful interference; and (2)

this device must accept any interference received,

including interference that may cause undesired

operation.

For customers in Canada

This Class B digital apparatus complies with Canadian

ICES-003.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

ATTENTION

RISQUE DE CHOC ELECTRIQUE,

NE PAS OUVRIR

PRECAUCION

RIESGO DE CHOQUE ELECTRICO

CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

NO ABRIR

You are cautioned that any changes or

modifications not expressly approved in

this manual could void your warranty and

your authority to operate this equipment.

SXRD

2-584-141-12(1)

Safety

❑Operate the SXRD projection TV only on 120 V

AC.

❑The plug is designed, for safety purposes, to fit into

the wall outlet only one way. If you are unable to

insert the plug fully into the outlet, contact your

dealer.

❑If any liquid or solid object should fall inside the

cabinet, unplug the SXRD projection TV

immediately and have it checked by qualified

service personnel before operating it further.

❑If you will not be using the SXRD projection TV for

several days, disconnect the power by pulling the

plug itself. Never pull on the cord.

❑For details concerning safety precautions, see

“Important Safeguards” on page 5.

Installing

❑To prevent internal heat buildup, do not block the

ventilation slots.

❑Do not install the SXRD projection TV in a hot or

humid place, or in a place subject to excessive dust

or mechanical vibration.

❑Avoid operating the SXRD projection TV at

temperature below 41°F (5°C).

❑If the SXRD projection TV is transported directly

from a cold to a warm location, or if the room

temperature changes suddenly, the picture may be

blurred or show poor color. In this case, please wait

a few hours to let the moisture evaporate before

turning on the SXRD projection TV.

❑To obtain the best picture, do not expose the screen

to direct illumination or direct sunlight. It is

recommended to use spot lighting directed down

from the ceiling or to cover the windows that face

the screen with opaque drapery. It is desirable to

install the SXRD projection TV in a room where the

floor and walls are not of a reflective material.

Note

This digital television is capable of receiving analog

basic, digital basic and digital premium cable television

programming by direct connection to a cable system

providing such programming. A security card provided

by your cable operator is required to view encrypted

digital programming. Certain advanced and interactive

digital cable services such as video-on-demand, a cable

operator’s enhanced program guide and data-enhanced

television services may require the use of a set-top box.

For more information call your local cable operator.

This television also includes a QAM demodulator which

should allow you to receive unscrambled digital cable

television programming via subscription service to a

cable service provider. Availability of digital cable

television programming in your area depends on the type

of programming and signal provided by your cable

service provider.

Trademark Information

CableCARD™ is a trademark of Cable Television

Laboratories, Inc.

TruSurround, SRS and the ( )® symbol are trademarks

of SRS Labs, Inc. TruSurround technology is

incorporated under license from SRS Labs, Inc.

BBE and BBE Symbol are trademarks of BBE Sound,

Inc. and are licensed by BBE Sound, Inc. under U.S.

Patent No. 4,638,258 and 4,482,866.

Manufactured under license from

Dolby Laboratories. Dolby and the

double-D symbol are trademarks of

Dolby Laboratories.

This TV incorporates High-Definition

Multimedia Interface (HDMI™)

technology. HDMI, the HDMI logo and High-Definition

Multimedia Interface are trademarks or registered

trademarks of HDMI Licensing LLC.

WEGA, Steady Sound, Digital Reality Creation,

CineMotion, BN Smoother, Memory Stick, Memory

Stick Duo, Memory Stick PRO, Memory Stick PRO Duo,

MagicGate, MID and Twin View are trademarks of Sony

Corporation. i.LINK is a trademark of Sony Corporation

and used only to designate that a product contains an

IEEE 1394 connector. All products with an i.LINK

connector may not communicate with each other.

Caution

This projection TV for use only with Sony stand SU-

SX10. Use with other stand models is capable of resulting

in instability causing possible injury.

SXRD

2-584-141-12(1)

Important

Safeguards

Before using your SXRD projection TV, please read these

instructions completely, and keep this manual for future

reference.

Carefully observe and comply with all warnings, cautions

and instructions placed on the set or described in the

operating instructions or service manual.

WARNING

To guard against injury, the following basic safety

precautions should be observed in the installation, use

and servicing of the set.

Use

Power Sources

This set should be operated only from

the type of power source indicated on

the serial/model plate.

If you are not sure of the type of

electrical power supplied to your home,

consult your dealer or local power company. For those

sets designed to operate from battery power, refer to the

operating instructions.

Grounding or Polarization

This set is equipped with a polarized AC power cord plug

(a plug having one blade wider than the other), or with a

three-wire grounding type plug (a plug having a third pin

for grounding). Follow the instructions below:

For the set with a polarized AC power cord

plug

This plug will fit into the power outlet

only one way. This is a safety feature.

If you are unable to insert the plug

fully into the outlet, try reversing the

plug.

If the plug still fails to fit, contact your electrician to have

a suitable outlet installed. Do not defeat the safety

purpose of the polarized plug by forcing it in.

For the set with a three-wire grounding type

AC plug

This plug will only fit into a grounding-

type power outlet. This is a safety

feature. If you are unable to insert the

plug into the outlet, contact your

electrician to have a suitable outlet

installed. Do not defeat the safety purpose of the

grounding plug.

Overloading

Do not overload wall outlets, extension

cords or convenience receptacles

beyond their capacity, since this can

result in fire or electric shock.

Always turn the set off when it is not

being used. When the set is left

unattended and unused for long

periods of time, unplug it from the

wall outlet as a precaution against the

possibility of an internal malfunction that could create a

fire hazard.

If a snapping or popping sound from a TV

set is continuous or frequent while the TV

is operating, unplug the TV and consult

your dealer or service technician. It is

normal for some TV sets to make

occasional snapping or popping sounds,

particularly when being turned on or off.

Object and Liquid Entry

Never push objects of any kind into the

set through the cabinet slots as they may

touch dangerous voltage points or short

out parts that could result in a fire or

electric shock. Never spill liquid of any

kind on the set.

Attachments

Do not use attachments not

recommended by the manufacturer, as

they may cause hazards.

Cleaning

❑Clean the cabinet of the SXRD

projection TV with a dry soft cloth.

To remove dust from the screen,

wipe it gently with a soft cloth.

Stubborn stains may be removed

with a cloth slightly dampened with solution of mild

soap and warm water. Never use strong solvents

such as thinner or benzine for cleaning. If the picture

becomes dark after using the SXRD projection TV

for a long period of time, it may be necessary to

clean the inside of the SXRD projection TV. Consult

qualified service personnel.

❑Unplug the AC power cord when cleaning this unit.

If not, it may result in electric shock.

❑Clean the rear cover area of the SXRD projection

TV regularly. Dust in the rear cover area may cause

a problem with the cooling system of the SXRD

projection TV set.

SXRD

2-584-141-12(1)

On contamination on the screen surface

The screen surface has a special coating to reduce

reflections. To prevent screen damage, clean the screen as

follows:

❑Clean the screen with a soft cloth, such as the

supplied cleaning cloth or a glass cleaning cloth.

❑To remove hard contamination, use the supplied

cleaning cloth or a glass cleaning cloth moistened

with a solution of mild detergent and water.

❑Do not use any type of abrasive pad, alkaline

cleaner, acid cleaner, scouring powder, chemical

cloth, or solvent such as alcohol, benzene or thinner,

as these may scratch the screen's coating.

Installation

Water and Moisture

Do not use power-line operated sets

near water — for example, near a

bathtub, washbowl, kitchen sink, or

laundry tub, in a wet basement, or

near a swimming pool, etc.

Accessories

Do not place the set on an unstable

cart, stand, table or shelf. The set may

fall, causing serious injury to a child or

an adult and serious damage to the set.

Use only a cart or stand recommended

by the manufacturer for the specific

model of SXRD projection TV. An appliance and cart

combination should be moved with care. Quick stops,

excessive force, and uneven surfaces may cause the

appliance and cart combination to overturn.

Ventilation

The slots and openings in the cabinet and in the back or

bottom are provided for necessary ventilation. To ensure

reliable operation of the set, and to protect it from

overheating, these slots and openings must never be

blocked or covered.

❑Never cover the slots and openings

with a cloth or other materials.

❑Never block the slots and openings

by placing the set on a bed, sofa, rug

or other similar surface.

❑Never place the set in a confined

space, such as a bookcase or built-in

cabinet, unless proper ventilation is

provided.

❑Do not place the set near or over a

radiator or heat register, or where it is

exposed to direct sunlight.

❑Leave some space around the unit.

When installing the unit against a wall,

keep it at least 4 inches (10 cm) away from the wall.

Otherwise, adequate air circulation may be blocked,

causing overheating that may result in fire or

damage to the unit.

Power-Cord Protection

Do not allow anything to rest on or roll

over the power cord, and do not place the

set where the power cord is subject to

wear or abuse.

Antennas

Outdoor Antenna Grounding

If an outdoor antenna is installed, follow the precautions

below. An outdoor antenna system should not be located

in the vicinity of overhead power lines or other electric

light or power circuits, or where it can come in contact

with such power lines or circuits.

POWER

STD/DUO

Allow this

much

space.

11 7/8 inches (30 cm)

4 inches

(10 cm)

4 inches

(10 cm)

Never install the unit as follows:

Air circulation is blocked.

less than

4 inches

(10 cm)

SXRD

2-584-141-12(1)

WHEN INSTALLING AN OUTDOOR ANTENNA

SYSTEM, EXTREME CARE SHOULD BE TAKEN TO

KEEP FROM CONTACTING SUCH POWER LINES

OR CIRCUITS AS CONTACT WITH THEM IS

ALMOST INVARIABLY FATAL.

Be sure the antenna system is grounded so as to provide

some protection against voltage surges and built-up static

charges.

Section 810 of the National Electrical Code (NEC) in

USA and Section 54 of the Canadian Electrical Code in

Canada provides information with respect to proper

grounding of the mast and supporting structure,

grounding of the lead-in wire to an antenna discharge

unit, size of grounding conductors, location of antenna

discharge unit, connection to grounding electrodes, and

requirements for the grounding electrode.

Antenna Grounding According to the NEC

Refer to section 54-300 of Canadian Electrical Code for

Antenna Grounding.

Lightning

For added protection for this television receiver during a

lightning storm, or when it is left unattended and unused

for long periods of time, unplug it from the wall outlet

and disconnect the antenna. This will prevent damage to

the receiver due to lightning and power-line surges.

Service

Damage Requiring Service

Do not attempt to service the set by yourself

since opening the cabinet may expose you to

dangerous voltage or other hazards.

Unplug the set from the wall outlet and refer

servicing to qualified service personnel under the

following conditions:

❑When the power cord or

plug is damaged or frayed.

❑If liquid has been spilled into the

set.

❑If the set has been exposed to rain

or water.

❑If the set has been subject to

excessive shock by being dropped,

or the cabinet has been damaged.

❑If the set does not operate normally

when following the operating

instructions. Adjust only those

controls that are specified in the

operating instructions. Improper

adjustment of other controls may

result in damage and will often

require extensive work by a

qualified technician to restore the set to normal

operation.

❑When the set exhibits a distinct change in

performance, it indicates a need for service.

Replacement Parts

When replacement parts are required, be sure the service

technician certifies in writing that he has used

replacement parts specified by the manufacturer that have

the same characteristics as the original parts.

Unauthorized substitutions may result in fire, electric

shock or other hazards.

Safety Check

Upon completion of any service or repairs

to the set, ask the service technician to

perform routine safety checks (as specified

by the manufacturer) to determine that the

set is in safe operating condition, and to so

certify. When the set reaches the end of its

useful life, ask a qualified service

technician to dispose of the set.

For Safety

Be careful when moving

the SXRD projection TV

When you place the SXRD

projection TV in position, be careful

not to drop it on your foot or fingers.

Watch your footing while installing the SXRD projection

TV.

Antenna lead-in wire

Ground clamps

Antenna lead-in wire

(NEC Section 810-20)

Grounding conductors

(NEC section 810-21)

Power service grounding

electrode system (NEC Art

250 Part H)

Ground clamp

Electrical

service

equipment

NEC: National

Electrical Code

POWER

STD/DUO

SXRD

2-584-141-12(1)

Carry the SXRD projection TV in

the specified manner

If you carry the SXRD projection TV in a

manner other than the specified manner

and without the specified number of

persons, it may drop and a serious injury

may be caused. Be sure to follow the instructions

mentioned below.

❑Carry the SXRD projection TV with the specified

number of persons (see page 30).

❑Detach the speakers before carrying the SXRD

projection TV.

❑Hold the SXRD projection TV tightly when carrying

it.

❑Before carrying the SXRD projection TV,

disconnect any accessories or cables.

About the SXRD projection TV

Although the SXRD projection TV is made with high-

precision technology, black dots may appear or bright

points of light (red, blue, or green) may appear constantly

on the SXRD screen. This is a structural property of the

SXRD panel and is not a defect.

Installation

❑If direct sunlight or other strong illumination shines

on the screen, part of the screen may appear white

due to reflections from behind the screen. This is a

structural property of the SXRD projection TV.

Do not expose the screen to direct illumination or

direct sunlight.

❑The picture quality may be affected by your viewing

position. Sit at least 8 ft. (approx. 2.4~2.5 m) away

from your SXRD projection TV, and within 76º of

the vertical and 130º of the horizontal viewing area.

If you sit too close to the TV, you may experience

eye strain. For the best picture quality, install your

SXRD projection TV according to “Recommended

Viewing Area” on page 32.

❑When installing your SXRD projection TV against a

wall, keep it at least 4 inches (10 cm) from the wall.

❑Avoid installing the SXRD projection TV near a

heater, etc.

Projection lamp

❑Your SXRD projection TV uses a projection lamp as

its light source. It is time to replace the lamp with a

new one (not supplied) when:

• the lamp replacement indicator on the front panel

blinks in red,

• screen images become dark,

• no image appears on the display after prolonged

use.

❑In rare instances, the bulb may pop inside the lamp

unit, but the lamp unit is designed to contain all of

broken glass pieces inside the lamp unit. (See

“Replacing the Lamp” on page 20.)

Cooling fan

❑This SXRD projection TV uses a cooling fan. You

may hear the noise of fan running, depending on the

placement of your SXRD projection TV. The noise

may be more noticeable during the night or when the

background noise level is low.

❑When the temperature of the SXRD projection TV

rises, the cooling fan runs faster.

❑Although the SXRD projection TV is switched to

standby mode, the cooling fan continues to run for a

few minutes.

❑When the lamp eventually burns out, you may hear

a noticeable pop sound. This is normal and is

inherent in this type of lamp.

SXRD

2-584-141-12(1)

Important Safety Instructions

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation slots. Install in

accordance with the manufacturer’s instructions.

8) Do not install near any heat sources such as radiators,

heat registers, stoves, or other apparatus (including

amplifiers) that produce heat.

9) Do not defeat the safety purpose of the polarized or

grounding-type plug. A polarized plug has two

blades with one wider than the other. A grounding

type plug has two blades and a third grounding prong.

The wide blade or the third prong are provided for

your safety. If the provided plug does not fit into

your outlet, consult an electrician for replacement of

the obsolete outlet.

10) Protect the power cord from being walked on or

pinched particularly at plugs, convenience

receptacles, and the point where they exit from the

apparatus.

11) Only use attachments/accessories specified by the

manufacturer.

12) Use only with the cart, stand, tripod,

bracket, or table specified by the

manufacturer, or sold with the apparatus.

When a cart is used, use caution when

moving the cart/apparatus combination

to avoid injury from tip-over.

13) Unplug this apparatus during lightning storms or

when unused for long periods of time.

14) Refer all servicing to qualified service personnel.

Servicing is required when the apparatus has been

damaged in any way, such as power-supply cord or

plug is damaged, liquid has been spilled or objects

have fallen into the apparatus, the apparatus has been

exposed to rain or moisture, does not operate

normally, or has been dropped.

15) Apparatus shall not be exposed to dripping or

splashing and no objects filled with liquids, such as

vases, shall be placed on the apparatus.

SXRD

2-584-141-12(1)

Contents

Introducing the Sony

SXRD Projection TV

Presenting the Sony SXRD Projection TV............13

Package Contents...........................................13

Using This Manual.........................................13

Features..........................................................14

Enjoying Your SXRD Projection TV ....................16

Notes on the SXRD Projection TV................17

Cleaning the Screen Surface ..........................17

Attaching the Speakers ..................................18

Replacing the Lamp.......................................20

Setting Up the SXRD Projection TV

Overview................................................................25

SXRD Projection TV Front Panel and

Connectors .....................................................26

Front Panel.....................................................26

Front and Rear Panel Connectors ..................27

Installing the SXRD Projection TV.......................30

Carrying Your SXRD Projection TV.............30

Take Precaution during the Installation .........31

To Prevent the SXRD Projection TV

from Falling ...................................................31

When Installing Your SXRD Projection TV

Against a Wall ...............................................31

Recommended Viewing Area........................32

Connecting the Power Cord...........................33

Basic Connections: Connecting a Cable

or Antenna......................................................34

Cable or Antenna ...........................................35

Cable and Antenna.........................................36

Cable Box and Antenna .................................37

Cable Box ......................................................38

Connecting Optional Equipment ...........................39

Making Video Connections ...........................40

About Using S VIDEO ..................................40

VCR and Cable ..............................................41

VCR and Cable Box ......................................42

Two VCRs for Tape Editing..........................44

Satellite Receiver ...........................................45

Satellite Receiver with a VCR and Cable......46

DVD Player with Component

Video Connectors ..........................................48

DVD Player with

S VIDEO and Audio Connectors...................49

Camcorder......................................................50

Audio Receiver ..............................................51

Digital Cable Box ..........................................52

Digital Satellite Receiver...............................53

Digital Satellite Receiver with an HDMI

Connector.......................................................54

Connecting a Device with an Optical IN

Connector.......................................................56

Using the CONTROL S Feature............................57

Using CableCARD ................................................58

About Using CableCARD .............................58

Activating CableCARD Service....................58

Removing the CableCARD ...........................59

Setting Up the SXRD Projection TV

Channel List...................................................60

Using Initial Setup .........................................60

Using the Remote Control

Overview................................................................61

Inserting Batteries into the Remote Control ..........61

Button Descriptions ...............................................62

Programming the Remote Control.........................64

Manufacturer’s Codes............................................65

Using Other Equipment with Your SXRD

Projection TV Remote Control......................66

Operating a VCR ...........................................66

Operating a Satellite Receiver .......................66

Operating a Cable Box...................................67

Operating a DVD Player................................67

Operating an MDP

(Laserdisc Player) ..........................................67

Using the Features

Overview................................................................69

Watching TV .........................................................69

Using the Program Guide ......................................70

Displaying the Program Guide ......................70

Using the Guide Menu...................................71

Using the Program Options Menu .................71

Using Wide Screen Mode......................................72

Changing the Wide Screen Mode for 4:3

Source (Standard definition source) ..............72

Changing the Wide Screen Mode for 16:9

Source (High definition source).....................73

SXRD

2-584-141-12(1)

Using Twin View...................................................74

Displaying Twin Pictures...............................74

Activating the Picture ....................................74

Changing the Picture Size..............................76

Using Favorite Channels........................................77

Using the Channel Menu ...............................77

Using the Favorite Channels Guide ...............78

Using the Freeze Function .....................................79

Using the Memory Stick Viewer

About Memory Stick .............................................81

Features..........................................................81

Memory Stick Compatibility .........................82

Memory Stick Functionality ..........................82

File Compatibility..........................................83

Trademark Information..................................83

Inserting and Removing a Memory Stick ..............84

Inserting a Memory Stick ..............................84

Inserting the Memory Stick Duo ...................85

Removing a Memory Stick ............................86

Using the Memory Stick Index..............................87

Using the Memory Stick Index......................88

Viewing Photos......................................................89

Photo Controls ...............................................89

Photo Menu Bar Options ...............................90

Using Zoom and Pan......................................91

Using Rotate ..................................................91

Playing Movies ......................................................92

Movie Controls ..............................................92

Movie Menu Bar Options ..............................93

Memory Stick Index Menu Bar Options................94

Slide Show Menu Options .............................94

Folder Menu Options .....................................95

Memory Stick Menu ......................................95

Notes on Using Memory Stick Media ...................96

About DCF File Names .................................96

Memory Stick Precautions.............................97

Using i.LINK

About i.LINK.........................................................99

Using i.LINK Cables .....................................99

Connecting i.LINK Devices ........................100

Selecting an i.LINK Device.................................102

Using the i.LINK Control Panel ..........................103

i.LINK Setup........................................................105

Using the Menus

Overview..............................................................107

Using the Video Menu.........................................108

Selecting Video Options ..............................108

Using the Audio Menu.........................................112

Selecting Audio Options..............................112

Using the Screen Menu........................................114

Selecting Screen Options.............................114

Using the Channel Menu .....................................116

Selecting Channel Options ..........................116

Using the Parent Menu ........................................118

Selecting Parent Options..............................118

Viewing Blocked Programs.........................119

Selecting Custom Rating Options................120

Using the Setup Menu .........................................122

Selecting Setup Options...............................122

Programming Caption Vision ......................124

Using the Applications Menu ..............................125

Selecting Applications Options ...................125

Other Information

Overview..............................................................127

Glossary ...............................................................128

Contacting Sony...................................................129

Troubleshooting...................................................129

Twin View ...................................................129

Remote Control............................................130

CableCARD.................................................130

Memory Stick ..............................................131

Video............................................................133

Audio ...........................................................134

Channels ......................................................134

General.........................................................135

Flashing Indicators on the Front of the TV .........137

Specifications.......................................................138

Optional Accessories ...........................................140

Index

Index....................................................................141

Introducing the Sony SXRD Projection TV

SXRD

2-584-141-12(1)

Introducing the Sony

SXRD Projection TV

Presenting the Sony SXRD Projection TV

Thank you for purchasing the Sony SXRD projection TV.

This manual is for model KDS-70Q006.

Package Contents Along with your new SXRD projection TV, the packing box contains a

remote control, two AA (R6) batteries, a cleaning cloth, etc. For more

information, see page 139. These items are all you need to set up and use the

TV.

Using This Manual We recommend that you carefully review the contents of the following five

sections in the order shown to ensure that you fully understand the operation

of your new SXRD projection TV.

1Setting Up the SXRD Projection TV

This section guides you through your initial setup. It shows you how to

install your SXRD projection TV, to connect your new components and

to connect the antenna and cable.

2Using the Remote Control

This section shows you how to begin using your new SXRD projection

TV. It also shows you how to use your remote control functions.

3Using the Features

This section provides information on using the Program Guide, Wide

Screen Mode, Twin View, Favorite Channels and Freeze Function.

4Using the Memory Stick Viewer

This section shows you how to use the Memory Stick Viewer to view

files that are stored on Memory Stick media, such as photographs and

movies.

5Using i.LINK

This section explains how to use the i.LINK feature.

6Using the Menus

This section teaches you how to access on-screen menus and adjust your

SXRD projection TV settings.

Instructions in this manual are written for the remote control. Similar

controls are also found on the SXRD projection TV console.

Introducing the Sony SXRD Projection TV

SXRD

2-584-141-12(1)

Features Some of the features that you will enjoy with your new SXRD projection TV

include:

❑WEGA Engine™: Delivers superb picture quality from any video

source by minimizing the signal deterioration caused by digital-to-

analog conversion and stabilizing the signal processing. This engine

features unique Sony technology, including:

●The first step in the digital processing system, Composite

Component Processor (CCP-X), which enhances input signal-to-

noise ratio by chroma decoder digital processing.

●DRC (Digital Reality Creation®) MultiFunction 2 circuitry:

Enables the digital mapping of any NTSC source (DVD, VHS,

DBS, Cable, etc.), to create a picture that is precise and finer in

detail, rivaling high definition resolution. Incoming HD signals

(1080i) are also bitmapped, utilizing Sony’s proprietary algorithm

to provide a crisp and clear picture.

●IFP (Image Format Processor): The Digital Texture Enhancer

function of this chip provides the optimal contrast by utilizing a

wide dynamic range. This chip also reduces signal noise, by using

an improved motion vector algorithm, while maintaining image

sharpness.

❑Integrated HDTV: You can watch digital television programs and

enjoy the improved audio/video quality offered by these programs.

❑SXRD: SXRD is a Silicon X-tal Reflective Display technology which

delivers high-level resolution, greater contrast ratio, faster response

speed and film-like reproduction compared to other conventional

devices.

❑S-master Full Digital Amplifier: Delivers superb clear dialog and

reproduces the original sound quality while minimizing any sound

fragmentation or jitter noise.

❑Cinema Black Pro: Using the improved optical unit technology,

Cinema Black Pro enables you to view images with the deeper contrast.

❑BN Smoother™: Reduces the block noise caused by digital video

encoding and decoding process.

❑CineMotion®: Using the reverse 3-2 pull down technology, the

CineMotion feature provides smoother picture movement when playing

back movies or other video sources on film.

❑Twin View®: Twin View allows you to watch two programs side by side

with the ability to zoom in on one picture and listen to the program in

the selected window. You can watch pictures from two different sources

(1080i, 720p, 480p or 480i) simultaneously.

Introducing the Sony SXRD Projection TV

SXRD

2-584-141-12(1)

❑Memory Stick Viewer: Allows you to view digital photos (JPEG) and

movies (MPEG1) from Memory Stick media on your SXRD projection

TV screen.

❑Parental Control: V-Chip technology allows parents to block

unsuitable programming from younger viewers.

❑CableCARD™ slot: Provides cable subscribers with access to digitally

encrypted cable channels — without the need for a set-top box — that

will enable you to receive not only standard definition but also high

definition television. The CableCARD, which is provided by your cable

TV company, is inserted into the TV’s rear panel CableCARD slot.

After the service is activated with your cable TV company, the card

replaces the need for a separate set-top box. (Check with your cable TV

company about CableCARD service details, limitations, pricing, and

availability. For more information about CableCARD in this manual,

see page 58.)

❑Component Video Inputs: Offers the best video quality for DVD

(480p, 480i) and digital set-top box (1080i, 720p, 480p, 480i)

connections.

❑S VIDEO Inputs: Provides a high-quality image from connected

equipment.

❑Favorite Channel Preview: Allows you to preview up to sixteen

favorite channels without leaving the current channel.

❑Wide Screen Mode: Allows you to watch 4:3 normal broadcasts in

wide screen mode (16:9 aspect ratio).

❑Steady Sound®: Equalizes volume levels so there is consistent output

between programs and commercials.

❑HDMI (High-Definition Multimedia Interface): Provides an

uncompressed, all-digital audio/video interface between this TV and

any HDMI-equipped audio/video component, such as a set-top box,

DVD player, and A/V receiver. HDMI supports enhanced, or high-

definition video, plus two-channel digital audio.

❑i.LINK: Provides a secure digital interface to other digital home

entertainment devices. i.LINK allows for the secure transfer of

your SXRD projection TV.

Introducing the Sony SXRD Projection TV

SXRD

2-584-141-12(1)

Enjoying Your SXRD Projection TV

Indicators

The indicators show the current status of your SXRD projection TV.

Screen

To minimize reflection, the screen’s surface has a special coating. Read the

instructions “Cleaning the Screen Surface” on page 17 carefully before

cleaning. Inappropriate cleaning methods could damage the screen’s finish.

Detachable speakers (left/right)

The left and right speakers output audio signal. The speakers are packed

separately in the packing box. For details on how to attach the speakers to

the TV, see page 18.

Projection lamp

Your SXRD projection TV uses a projection lamp as its light source. The

projection lamp is located under the Front Panel Cover as noted in the

diagram above. Note the following:

❑The SXRD projection TV cools down its projection lamp when the

power is turned off. It takes up to two minutes for the picture to come

back after the TV is turned on again. The POWER/STANDBY LED

blinks in green while the picture is coming up.

❑When the projection lamp wears out, the screen goes dark. Replace the

lamp with a new Sony XL-5000 replacement lamp (not supplied).

✍After replacing the lamp, be sure to attach the lamp cover securely;

otherwise, your SXRD projection TV will not turn on. For details on lamp

replacement, see “Replacing the Lamp” on page 20.

✍The light emitted from the lamp is quite bright when your SXRD

projection TV is in use. To avoid eye discomfort or injury, do not look

into the housing when the power is on.

✍The projection lamp is a consumable product that wears out after use for

a certain period of time. When the lamp wears out, replace it with a new

one so that you can enjoy the original quality of the SXRD picture again.

POWER

STD/DUO

Screen

Projection lamp under the panel

Indicators

Right

speaker

Left

speaker

Introducing the Sony SXRD Projection TV

SXRD

2-584-141-12(1)

Notes on the SXRD

Projection TV

To enjoy clear pictures

❑Prevent sunlight or other light sources from shining directly onto the

screen.

❑The screen surface is easily scratched. Do not rub, touch, or tap it with a

sharp or abrasive object (see “Cleaning the Screen Surface” below).

On moisture condensation

❑If your SXRD projection TV is moved directly from a cold to a warm

location, is placed in a humid room, or if the room temperature changes

suddenly, the picture may blur or show poor color. This is caused by

moisture condensation on the lenses inside. If this happens, leave the

power on to help the moisture evaporate. When the condensation has

evaporated, the picture of your SXRD projection TV will return to

normal.

When not using the SXRD Projection TV for a long period of time

❑Turn off the main power on the front of your SXRD projection TV

before going to sleep or going out. Unplug the AC power cord from the

outlet if you anticipate not using the SXRD projection TV for more than

a week.

When turning off the power

❑The fan will continue to operate for about two minutes. Allow several

minutes before unplugging from the outlet or switching the breaker off.

Before carrying the SXRD Projection TV

❑Before carrying, unplug the power cord and disconnect all cables.

See page 30 for instructions on how to carry your SXRD projection TV.

❑Be sure to first remove the speakers before moving your SXRD

projection TV.

Cleaning the Screen

Surface

To remove dust from the front of the screen, wipe with the supplied cleaning

cloth.

✍Do not use any type of abrasive pad, alkaline cleaner, scouring powder,

window cleaners or solvent such as alcohol or benzene. Using these

types of products may damage the screen.

✍To clean the screen, use the supplied cleaning cloth lightly moistened

with a mild detergent and water solution. Use gentle pressure when

cleaning.

✍The supplied cleaning cloth is washable with warm water and a mild

detergent solution, and can be used repeatedly.

✍To remove the static from the screen, use the supplied anti-static brush.

All the dust and static will be removed. Use gentle pressure when

brushing.

Introducing the Sony SXRD Projection TV

SXRD

2-584-141-12(1)

Attaching the

Speakers

Your SXRD projection TV comes with detachable speakers. You can enjoy

the TV with or without the included speakers. The speakers are packed

separately in the packing box.

To attach the speakers to your SXRD projection TV, follow the steps below:

1Hold the left speaker upright. Insert the metal hook located on the top of

the speaker into the slot on the rear of the TV (upper right-hand corner)

and slowly move the speaker closer to the TV.

2Locate the black pin near the center of the speaker's attachment tab and

the matching hole on the rear of the TV. Insert the pin into the hole until

it locks into place.

✍Do not carry the SXRD projection TV with the speakers attached. If you

need to move the TV, do so before attaching the speakers.

Slot

Rear of SXRD

projection TV

Metal hook

Screw

Left speaker

Black pin

Rear of SXRD

projection TV

Screw

Left speaker

Hole

Introducing the Sony SXRD Projection TV

SXRD

2-584-141-12(1)

3Insert the four screws pre-attached to the speaker into the screw holes on

the rear of the TV, turn the screws clockwise, and tighten them to secure

the speaker to the TV.

4Repeat steps 1 through 4 with the right speaker.

✍The speakers can be detached if required. If you use a multi-channel

surround speaker system and there is not sufficient space to install the

display unit, we recommend using the speakers detached.

✍To prevent damage to the speaker housing or terminals, do not use

excessive force when attaching or detaching the speakers.

✍Be sure to first remove the speakers before moving the TV.

✍To remove dust from the transparent portions of the speakers, wipe

them with a clean, soft cloth.

✍Do not connect the detached speakers to other audio equipment.

✍Place the supplied slot covers to all four corners at the rear of the TV (as

shown in the following illustration) if you decide not to attach the

speakers. Avoid accidental swallowing of the slot covers by children.

Black pin

Rear of SXRD projection TV

Bottom slot

Top slot

Rear of SXRD

projection TV

Introducing the Sony SXRD Projection TV

SXRD

2-584-141-12(1)

Replacing the Lamp The projection lamp, which illuminates the picture, has a limited life.

If the screen becomes dark, the color looks unusual, or the LAMP indicator

on the front of the SXRD projection TV flashes, it is time to replace the lamp

with a new one (not supplied).

❑Use a Sony XL-5000 replacement lamp (not supplied) for replacement.

Use of any other lamp may damage the SXRD projection TV.

❑Do not remove the lamp for any purpose other than replacement. Doing

so may cause injury or fire.

❑Before replacing the lamp, turn the power off on the main unit. Wait

several minutes, then unplug the power cord. (The cooling fan will

continue to operate for about two minutes after turning the power off.)

❑Allow the lamp to cool down completely before removing it. The

surface of the lamp remains extremely hot for at least 30 minutes after

the power has been turned off.

❑Do not put flammable materials and metal objects inside the lamp

receptacle of the SXRD projection TV after removing the lamp. Doing

so may cause fire or electrical shock.

❑To avoid being burned, do not touch the lamp receptacle once the lamp

has been removed.

❑Mount the new lamp securely. Failure to do so may cause a fire or the

screen to go dark.

❑Do not touch the glass of the new lamp with your fingers.

The used lamp

For customers in the United States:

This product contains mercury. Disposal of this product may be regulated if

sold in the United States. For disposal or recycling information, please

contact your local authorities or the Electronics Industries Alliance

(http://www.eiae.org).

❑Do not leave the used lamp near flammable materials or within the reach

of children.

❑Do not pour water onto the used lamp or put any object inside the lamp.

Doing so may cause the lamp to burst.

✍Avoid touching the front glass of a new lamp as this may reduce picture

quality or lamp life.

WARNING

Electric appliances can cause fire or high temperature, resulting in injury

or death. Be sure to follow the instructions below.

Introducing the Sony SXRD Projection TV

SXRD

2-584-141-12(1)

1Turn off the power on the main unit. Wait several minutes, then unplug

the power cord.

(The cooling fan will continue to operate for about two minutes after

turning the power off.)

2Wait at least 30 minutes after unplugging the power cord to allow the

lamp to cool down before replacing it.

Take the new lamp out of the box.

3Put both hands underneath the Front Panel Cover and locate the screw

on each side of the cover.

Loosen the screws by turning them counterclockwise and remove the

cover.

✍Don’t shake the lamp. Vibration can damage the lamp or shorten its

life.

✍Avoid touching the front glass of a new lamp or the glass of the

lamp receptacle. This may reduce picture quality or lamp life.

✍Hold beneath both sides of the cover, and pull forward to release it.

POWER

STD/DUO

(Continued)

Introducing the Sony SXRD Projection TV

SXRD

2-584-141-12(1)

4Pull out the lamp.

Loosen the screw on the lamp cover with a coin or similar object and

slide the knob to the left. Put fingers on the right edge of the cover and

pull it forward to remove the cover.

Loosen the two screws that hold the lamp using the hex key supplied

with the lamp, then pull out the lamp.

5Attach the new lamp.

Making sure the front glass of the new lamp is facing the left side of the

lamp slot, place the lamp and tighten the screws.

✍The lamp is very hot immediately after use. Never touch the front

glass of the lamp or the surrounding parts.

✍After it has cooled, place the used lamp into the empty box of the

replacement lamp. Never put the used lamp into a plastic bag while

the lamp is hot.

✍Remove the dust inside the lamp slot with a vacuum cleaner, after

pulling out the lamp.

Pull forward

with fingers

Introducing the Sony SXRD Projection TV

SXRD

2-584-141-12(1)

Making sure the black pin on the back of the lamp cover goes into the

hole on the TV, put the cover back on. Slide the knob to the right until v

matches V, and then tighten the screw.

6Reattach the Front Panel Cover securely and tighten the two screws

underneath the cover.

✍If the lamp cover screw is inserted incorrectly, the lamp may not

operate properly. In such a case, remove the screw, insert it

correctly and then tighten the screw completely.

✍If the lamp cover is not reattached securely, the self-diagnostic

function may be triggered and the POWER/STANDBY indicator

flashes three times (see page 137).

✍Consult your Sony dealer for a Sony XL-5000 replacement lamp.

✍Take great care when replacing the lamp or plugging in/unplugging

the connecting cords. Rough handling may cause the SXRD

projection TV to fall, damaging the TV, the TV stand and/or the floor.

The pin is on the back of the

lamp cover. Gently push the

cover until the pin locks into

place.

POWER

STD/DUO

Press firmly.

Setting Up the SXRD Projection TV

SXRD

2-584-141-12(1)

Setting Up the SXRD Projection TV

Overview

This chapter includes illustrated instructions for setting up your SXRD

projection TV.

Topic Page(s)

SXRD Projection TV Front Panel and Connectors 26

Installing the SXRD Projection TV 30

Basic Connections: Connecting a Cable or Antenna 34

Connecting Optional Equipment

Making Video Connections

About Using S VIDEO

VCR and Cable

VCR and Cable Box

Two VCRs for Tape Editing

Satellite Receiver

Satellite Receiver with a VCR and Cable

DVD Player with Component Video Connectors

DVD Player with S VIDEO and Audio Connectors

Camcorder

Audio Receiver

Digital Cable Box

Digital Satellite Receiver

Digital Satellite Receiver with an HDMI Connector

Connecting a Device with an Optical IN Connector 56

Using the Control S Feature 57

Using CableCARD 58

Setting Up the SXRD Projection TV Channel List 60

Setting Up the SXRD Projection TV

SXRD

2-584-141-12(1)

SXRD Projection TV Front Panel and Connectors

Front Panel

Item Description

1LAMP LED Lights up in red when the lamp for the light source has

burned out. For details, see “Replacing the Lamp” on

page 20.

2i.LINK STANDBY

LED

When lit in red, indicates that i.LINK Standby is on. For

details, see page 123.

3Memory Stick

indicator

When lit, indicates that the Memory Stick is being read.

(Do not remove the Memory Stick when the indicator is

lit.)

4Memory Stick slot For inserting Memory Stick media to view on your SXRD

projection TV. For details, See “Inserting and Removing a

Memory Stick” on page 84.

5 TIMER LED When lit, indicates one of the timers is set. When the

timer is set, this LED will remain lit even if the TV set is

turned off. For details, see page 125.

6(IR) Infrared

Receiver

Receives IR signals from the remote control.

7POWER/

STANDBY LED

Blinks and then lights up in green when the TV set is

turned on. When in standby mode, the LED lights up in

red. The LED does not light up when the AC power cord

is not connected to the outlet. If the red LED blinks

continuously, this may indicate the display unit needs

servicing (see “Contacting Sony” on page 129). When the

red LED blinks only three times, the lamp cover is not

attached securely (see page 23).

POWER

STD/DUO

POWER/STANDBY

STANDBY

POWER

LAMP

TIMER

STD / DUO

CHANNEL

VOLUME

TV / VIDEO

21 583 4 67

Setting Up the SXRD Projection TV

SXRD

2-584-141-12(1)

Front and Rear

Panel Connectors

8POWER Press to turn on/off the SXRD projection TV.

9CHANNEL +/– Press to scan through channels.

q; VOLUME +/– Press to adjust the volume.

qa TV/VIDEO Press to select between the TV’s tuner and other video

equipment inputs.

Item Description

Connection Description

1i.LINK

(3 inputs)

Connects to the i.LINK jack on your i.LINK-compatible

portable device. Provides a secure digital connection

between your SXRD projection TV and i.LINK-

compatible portable device, such as a digital video

camcorder.

2S VIDEO

(Front and rear)

Connects to the S VIDEO OUT jack of your VCR,

camcorder, or other S VIDEO-equipped video component.

Provides better picture quality than the VHF/UHF jacks or

the Video IN jack.

3VIDEO/

L(MONO)-AUDIO-R

(Front and rear)

Connects to the audio and video OUT jacks on your VCR

or other video component. A third video input (VIDEO 2)

is located on the front panel of the SXRD projection TV.

POWER

STD/DUO

S VIDEO VIDEO

VIDEO 2 INPUT

L (MONO) - AUDIO -R

OPEN

i.LINK S400

TS/DV/MICROMV/HDV

21 3

Front Panel of SXRD projection TV

Push up to open

the front panel.

(Continued)

zThe CHANNEL +

button and VOLUME +

button have a tactile

dot. Use the tactile as

a reference when

operating the TV.

Setting Up the SXRD Projection TV

SXRD

2-584-141-12(1)

4HD/DVD IN (1080i/

720p/480p/480i)

Connects to your DVD player’s or digital set-top box’s

component video (Y, PB, PR) and audio (L/R) jacks.

5AUDIO OUT

(VAR/FIX) L/R

Connects to the left and right audio inputs of your audio or

video component.

✍AUDIO OUT jacks are operable only when the TV’s

Speaker is set to Off. For details, see page 113.

6AC IN Connects the supplied power cord.

7CONTROL S

IN/OUT

To control other Sony equipment with the SXRD

projection TV's remote control, connect the CONTROL S

IN jack of the equipment to the CONTROL S OUT jack on

the SXRD projection TV with the CONTROL S cable.

To control the SXRD projection TV with the remote

control of another Sony product, connect the CONTROL S

OUT jack of the equipment to the CONTROL S IN jack on

the SXRD projection TV with the CONTROL S cable.

Connection Description

AUDIO

OUT

(VAR/FIX)

1 3

qz 5 6

4qs

0 9 Rear of SXRD projection TV

Setting Up the SXRD Projection TV

SXRD

2-584-141-12(1)

*Manufactured under license from Dolby Laboratories.

“Dolby” and the double-D symbol are trademarks of Dolby Laboratories.

Connection Description

8HDMI

(VIDEO 6 IN and

VIDEO 7 IN)

HDMI (High-Definition Multimedia Interface) provides an

uncompressed, all-digital audio/video interface between

this TV and any HDMI-equipped audio/video component,

such as a set-top box, DVD player, and A/V receiver.

HDMI supports enhanced, or high-definition video, plus

two-channel digital audio. You can also connect a DVI-

equipped device to your SXRD projection TV by using an

HDMI-DVI cable.

9DIGITAL AUDIO

(OPTICAL) OUT

(PCM/DOLBY*

DIGITAL)

Connects to the optical audio input of a digital audio

component that is PCM/Dolby digital compatible.

0CableCARD slot CableCARD provides cable subscribers with access to

secure, digitally encrypted cable channels -- without the

need for a set-top box -- that will enable you to receive not

only standard definition but also high definition television.

For more information, see page 58.

qa CABLE Connects to your cable signal. This CABLE input jack, in

conjunction with the VHF/UHF input jack, lets you set up

your SXRD projection TV to switch between scrambled

channels (coming through a cable box) and unscrambled

cable channels. For details, see page 37.

qs VHF/UHF Connects to your VHF/UHF antenna or cable box output

jack.

Setting Up the SXRD Projection TV

SXRD

2-584-141-12(1)

Installing the SXRD Projection TV

Carrying Your SXRD

Projection TV

Carrying the SXRD projection TV requires at least four people. Do not hold

by the pedestal or the Front Panel Cover of the SXRD projection TV. Doing

so may cause these parts to break off.

As shown in the illustration below, two persons hold the TV by its sides and

the other two by its rear panel. Each person holding the side should use both

hands to grasp the bottom corners of the panel. The other two should place

their hands on the top edge of the TV and the lower part of the rear panel.

✍Be sure to first remove the speakers before moving the TV.

✍Make sure the screws underneath the Front Panel Cover are securely

tightened before moving the TV (see Step 6 on page 23).

To carry the TV, hold it by

the top and bottom of the

panel.

Setting Up the SXRD Projection TV

SXRD

2-584-141-12(1)

Take Precaution

during the

Installation

To ensure the safety of children and the SXRD projection TV, keep children

away from the TV during installation. Climbing on or pushing the SXRD

projection TV or its stand may cause it to fall.

To Prevent the SXRD

Projection TV from

Falling

As a protective measure, secure the SXRD projection TV as follows.

Using the SXRD projection TV stand with support belts

❑Sony strongly recommends using the TV stand designed for your SXRD

projection TV, model SU-SX10 (not supplied).

When Installing Your

SXRD Projection TV

Against a Wall

Keep your SXRD projection TV at least 4 inches (10 cm) away from the wall

to provide proper ventilation.

Setting Up the SXRD Projection TV

SXRD

2-584-141-12(1)

Recommended

Viewing Area

Your viewing position may affect the picture quality.

For the best picture quality, install your SXRD projection TV within the

areas shown below.

Horizontal Viewing Area

Vertical Viewing Area

POWER

STD/DUO

˚65˚

min. 6.6 ft. (approx. 2.0 m

min. 8 ft. (approx. 2.4~2.5 m)

65˚

POWER

STD/DUO

38˚

min. 8 ft. (approx. 2.4~2.5 m)

Setting Up the SXRD Projection TV

SXRD

2-584-141-12(1)

Connecting the

Power Cord

1Connect the AC power cord (supplied) to the AC IN connector of the

TV.

2Connect the other end of the power cord to a wall outlet.

✍Complete other connections before connecting the power cord.

✍Be sure to use the supplied AC power cord.

✍When connecting optional components, do not connect the AC power

cord to a wall outlet until you have completed making all connections.

✍Do not use damaged or deformed cables.

AC IN

AC power cord

Setting Up the SXRD Projection TV

SXRD

2-584-141-12(1)

Basic Connections: Connecting a Cable or Antenna

The way in which you connect your SXRD projection TV will vary,

depending on how your home receives a signal (cable, cable box, antenna)

and whether or not you plan to connect a VCR.

If you are connecting a VCR

❑See the connections described on pages 41 and 43.

If You Are Connecting See Page

Cable or Antenna

❏No cable box or VCR

Cable and Antenna

❏No cable box or VCR

Cable Box and Antenna

❏Cable box unscrambles only some channels (usually

premium channels)

❏No VCR

Cable Box

❏Cable box unscrambles all channels

❏No VCR

Setting Up the SXRD Projection TV

SXRD

2-584-141-12(1)

Cable or Antenna For best results, use one of the following connections if you are

connecting a cable or an antenna and you:

❑Do not need a cable box to unscramble channels. (If you have a cable

box, see pages 37 and 38.)

❑Do not intend to connect a VCR. (If you have a VCR, see pages 41 and

42.)

The connection you choose depends on the cable type you have in your

home, as described below.

75-ohm coaxial cable (usually found in newer homes)

Cable Type Connect As Shown

VHF Only or

combined

VHF/UHF

Cable

300-ohm twin lead cable (usually found in older homes)

Cable Type Connect As Shown

VHF Only or

UHF Only or

combined

VHF/UHF

75-ohm coaxial and 300-ohm twin lead cable (found in some homes)

Cable Type Connect As Shown

VHF and UHF

75-ohm coaxial

cable Rear of SXRD

Projection TV

VHF/UHF

75-ohm coaxial

cable

CABLE

Rear of SXRD

Projection TV

Rear of SXRD Projection TV

Antenna connector

(not supplied)

300-ohm twin lead cable

VHF/UHF

Rear of SXRD

Projection TV

75-ohm coaxial cable

VHF/UHF

U/V mixer

(not supplied)

300-ohm twin lead cable

Setting Up the SXRD Projection TV

SXRD

2-584-141-12(1)

Cable and Antenna For best results, use this connection if you:

❑Have a cable and an antenna.

(This is convenient if you are using a separate rooftop antenna to receive

additional channels that are not provided by your cable TV company.)

❑Do not have a cable box or VCR. (If you have a cable box, see pages 37

and 38. If you have a VCR, see pages 41 and 42.)

Notes on Using This Connection

Antenna and CATV cable

Cable Type Connect As Shown

Cable TV

(CATV) and

Antenna

To Do This ... Do This ...

Switch the SXRD projection

TV’s input between the cable

and antenna

Press ANT to switch back and forth between the

SXRD projection TV’s VHF/UHF and CABLE

inputs.

✍For optimum picture quality, a 75-ohm coaxial cable antenna connection

is highly recommended. Radio waves and other interference can easily

affect a 300-ohm twin lead cable, resulting in signal deterioration. If you

use a 300-ohm twin lead cable, keep it as far away as possible from the

SXRD projection TV.

✍Do not use an indoor antenna, which is especially susceptible to radio

noise.

Antenna cable CATV cable

Setting Up the SXRD Projection TV

SXRD

2-584-141-12(1)

Cable Box and

Antenna

For best results, use this connection if:

❑Your cable company scrambles some channels, such as premium

channels (which requires you to use a cable box), but does not scramble

all channels.

❑You do not have a VCR. (If you have a VCR, see pages 41 and 42.)

With this connection you can:

❑Use the SXRD projection TV’s remote control to change channels

coming through the cable box to the SXRD projection TV’s cable input.

(You must first program the remote control for your specific cable box;

see “Programming the Remote Control” on page 64.)

❑Use the SXRD projection TV’s remote control to change channels

coming directly into the SXRD projection TV’s VHF/UHF input jack.

Notes on Using This Connection

Before connecting a cable

box, see “Using

CableCARD” on page 58.

✍This connection will allow you to take advantage of dual picture features

such as Twin View, Freeze, etc.

IN OUT

CABLE

VHF/UHF

CATV cable

Rear of SXRD projection TV

Cable box

Antenna Cable

Coaxial

cable

To Do This ... Do This ...

Use the cable box Tune the SXRD projection TV to the channel the cable box is set to

(usually channel 3 or 4) and then use the cable box to switch

channels.

Set up the SXRD projection TV remote control

to operate the cable box

Program the remote control. See “Programming the Remote

Control” on page 64.

Activate the remote control to operate the cable

box

Press FUNCTION repeatedly until the SAT/CABLE indicator lights

up.

Prevent the accidental switching of TV channels When using the cable box, the SXRD projection TV must stay on the

channel the cable box is set to (usually channel 3 or 4). You can use

the SXRD projection TV’s Channel Fix feature to lock in a specific

channel. For details, see “Using the Channel Menu” on page 116.

Switch the SXRD projection TV’s input between

the cable box and cable

Press ANT to switch back and forth between the SXRD projection

TV’s VHF/UHF (scrambled channels) and CABLE (unscrambled)

inputs.

Setting Up the SXRD Projection TV

SXRD

2-584-141-12(1)

Cable Box For best results, use this connection if:

❑Your cable company scrambles all channels, which requires you to use a

cable box.

❑You do not have a VCR. (If you have a VCR, see pages 41 and 42.)

With this connection you can:

❑Use the SXRD projection TV’s remote control to change channels

coming through the cable box to the SXRD projection TV’s VHF/UHF

jack. (You must first program the remote control for your specific cable

box.)

To connect the cable box

1Connect the CATV cable to the cable box’s input jack.

2Use a coaxial cable to connect the cable box’s output jack to the SXRD

projection TV’s VHF/UHF jack.

3Run Auto Program, as described in “Setting Up the SXRD Projection

TV Channel List” on page 60.

Notes on Using This Connection

Before connecting a cable

box, see “Using

CableCARD” on page 58.

✍With this connection, all channels come into the SXRD projection TV

through your cable box and only one unscrambled signal is sent to the

SXRD projection TV, so you cannot use the dual picture features. If

some of your channels are scrambled, but others are not, consider using

the “Cable Box and Antenna” connection on page 37 instead.

VHF/UH

CATV cable Coaxial cable

Rear of SXRD projection TV

Cable box

OUT

To do this... Do This ...

Use the cable box Tune the SXRD projection TV to the channel the cable box is set to

(usually channel 3 or 4) and then use the cable box to switch

channels.

Set up the SXRD projection TV remote control

to operate the cable box

Program the remote control. See “Programming the Remote

Control” on page 64.

Activate the remote control to operate the cable

box

Press FUNCTION repeatedly until the SAT/CABLE indicator

lights up.

Prevent the accidental switching of TV channels When using the cable box, the SXRD projection TV must stay on the

channel the cable box is set to (usually channel 3 or 4). You can use

the SXRD projection TV’s Channel Fix feature to lock in a specific

channel. For details, see “Using the Channel Menu” on page 116.

Setting Up the SXRD Projection TV

SXRD

2-584-141-12(1)

Connecting Optional Equipment

Use the directions in this section to connect the following optional

equipment:

If You Are Connecting See Page

Making Video Connections 40

About Using S VIDEO 40

VCR and Cable 41

VCR and Cable Box 42

Two VCRs for Tape Editing 44

Satellite Receiver 45

Satellite Receiver with a VCR and Cable 46

DVD Player with Component Video Connectors 48

DVD Player with S VIDEO and Audio Connectors 49

Camcorder 50

Audio Receiver 51

Digital Cable Box 52

Digital Satellite Receiver 53

Digital Satellite Receiver with an HDMI Connector 54

Connecting a Device with an Optical IN Connector 56

Using the CONTROL S Feature 57

Using CableCARD 58

Setting Up the SXRD Projection TV

SXRD

2-584-141-12(1)

Making Video

Connections

Your TV includes several types of video inputs. When connecting your TV,

use the inputs that are available on your components that provide the best

video performance, as described below.

About Using

SVIDEO

If the optional equipment you are connecting has an S VIDEO jack

(shown at left), you can use an S VIDEO cable for improved picture

quality (compared to an A/V cable). Because S VIDEO carries only

the video signal, you also need to connect audio cables for sound, as

shown below.

Example of an S VIDEO Connection

Best Video

Performance

Connector Type

HDMI (High-Definition

Multimedia Interface)

Component video

S VIDEO

Composite video

RF/Coaxial

Cables are often

color-coded to connectors.

Connect red to red,

white to white, etc.

Rear of SXRD projection TV

S VIDEO cable

Equipment with S VIDEO

Audio cable

Setting Up the SXRD Projection TV

SXRD

2-584-141-12(1)

VCR and Cable Use this hookup if:

❑You have cable TV that does not require a cable box.

Disconnect all power sources before making any connections.

1Connect the CATV cable to the single (input) jack of the splitter.

2Using a coaxial cable, connect one of the output jack of the splitter to

the SXRD projection TV’s CABLE jack.

3Using a coaxial cable, connect the splitter's other output jack to the

VCR's input jack.

4Using A/V and S VIDEO cables, connect the VCR’s AUDIO and

S VIDEO OUT jacks to the SXRD projection TV’s AUDIO and S

VIDEO IN jacks.

Coaxial cable

Rear of SXRD projection TV

VIDEO

AUDIO-L

AUDIO-R

VCR

A/V cable

S VIDEO

S VIDEO cable

Cables are often

color-coded to connectors.

Connect red to red,

white to white, etc.

Coaxial cable

CATV

Cable

Splitter

✍If your VCR is not equipped with S VIDEO, use a VIDEO cable (yellow)

instead of the S VIDEO cable.

Setting Up the SXRD Projection TV

SXRD

2-584-141-12(1)

VCR and Cable Box Use this hookup if:

❑Your cable TV company scrambles some channels, but not all of them

(pay channels vs. regular cable channels) and you need to use a cable

box.

❑You want to enjoy the Twin View feature.

With this setup you can:

❑Use the SXRD projection TV’s remote control to change channels on

your cable box when the signal is scrambled. To program your Sony

remote control to operate your cable box, see “Programming the

Remote Control” on page 64.

❑Use the SXRD projection TV’s remote control to change channels on

your SXRD projection TV when the signal is not scrambled. Your

SXRD projection TV’s tuner provides a better signal than the cable box.

❑Use the Twin View feature. (When all channels are routed through your

cable box, only one signal is sent to the SXRD projection TV, so you

cannot use the Twin View feature.)

Disconnect all power sources before making any connections.

1Connect the CATV cable to the single (input) jack of the splitter.

2Using a coaxial cable, connect one of the splitter’s two output jacks to

the SXRD projection TV’s CABLE jack.

3Using a coaxial cable, connect the splitter’s other output jack to the

cable box’s input jack.

4Using a coaxial cable, connect the cable box’s output jack to the VCR’s

RF input jack.

5Using an A/V cable, connect the cable box’s A/V output jacks to the

SXRD projection TV’s A/V input jacks.

6Using an A/V and S VIDEO cables, connect the VCR’s AUDIO and S

VIDEO OUT jacks to the SXRD projection TV’s AUDIO and S VIDEO

IN input jacks.

7Run Auto Program, as described in “Setting Up the SXRD Projection

TV Channel List” on page 60.

Before connecting a cable

box, see “Using

CableCARD” on page 58.

✍To view scrambled channels, tune the SXRD projection TV to the channel

the cable box is set to (usually channel 3 or 4) and then use the cable

box to switch channels.

Setting Up the SXRD Projection TV

SXRD

2-584-141-12(1)

Cable box

VCR

Rear of SXRD projection TV

A/V cable

Coaxial

cable

VIDEO

AUDIO-L

AUDIO-R

CATV

cable

Coaxial

cable

Splitter

Cables are often

color-coded to connectors.

Connect red to red,

white to white, etc.

If you are connecting a

digital cable box, you will

need a special bi-

directional splitter

designed to work with

your cable box.

Coaxial cable

A/V cable

S VIDEO

cable

✍If your VCR is not equipped with S VIDEO, use a VIDEO cable (yellow)

instead of the S VIDEO cable.

Setting Up the SXRD Projection TV

SXRD

2-584-141-12(1)

Two VCRs for Tape

Editing If you connect two VCRs, you can record from one VCR to the other while

using your SXRD projection TV to monitor what is being recorded.

Disconnect all power sources before making any connections.

1Using A/V cables, connect the playback VCR’s AUDIO and VIDEO

OUT jacks to the recording VCR’s AUDIO and VIDEO IN jacks.

2Using A/V cables, connect the recording VCR’s AUDIO and VIDEO

OUT jacks to the SXRD projection TV’s AUDIO and VIDEO IN jacks.

Using

S VIDEO jacks?

See page 40.

Rear of SXRD projection TV

VCR (playback) VCR (recording)

A/V cable

AUDIO-R

AUDIO-L

VIDEO

A/V cable

Cables are often

color-coded to connectors.

Connect red to red,

white to white, etc.

✍To perform tape editing, set the SXRD projection TV to the video input

intended for playback by pressing TV/VIDEO on the remote control.

✍You may need to change the video input on your VCR. See your VCR’s

operating manual for instructions.

✍If your VCRs have S VIDEO jacks: For best picture quality, use an

S VIDEO connection instead of the yellow video cable on your combined

A/V cable.

Using an S VIDEO cable, connect the playback VCR’s S VIDEO OUT jack

to the recording VCR’s S VIDEO IN jack. S VIDEO does not provide

audio, so audio cables must be connected to provide sound.

✍You cannot record signals from equipment connected to the Y, PB, PR

input.

Setting Up the SXRD Projection TV

SXRD

2-584-141-12(1)

Satellite Receiver Disconnect all power sources before making any connections.

1Connect the satellite antenna cable to the satellite receiver’s

SATELLITE IN jack.

2Using A/V and S VIDEO cables, connect the satellite receiver’s AUDIO

and S VIDEO OUT jacks to the SXRD projection TV’s AUDIO and S

VIDEO IN jacks.

✍If your satellite receiver is not equipped with S VIDEO, use a VIDEO cable

(yellow) instead of the S VIDEO cable.

Satellite receiver

A/V cable

Rear of SXRD projection TV

VIDEO

AUDIO-L

AUDIO-R

Satellite

antenna

cable

S VIDEO

S VIDEO cable

Cables are often

color-coded to connectors.

Connect red to red,

white to white, etc.

Setting Up the SXRD Projection TV

SXRD

2-584-141-12(1)

Satellite Receiver

with a VCR and

Cable

Disconnect all power sources before making any connections.

1Connect the CATV cable to the single (input) jack of the splitter.

2Using a coaxial cable, connect one of the splitter’s two output jacks to

the SXRD projection TV’s CABLE jack.

3Using a coaxial cable, connect the splitter’s other output jack to the

VCR’s VHF/UHF IN jack.

4Connect the satellite antenna cable to the satellite receiver’s

SATELLITE IN jack.

5Using A/V and S VIDEO cables, connect the satellite receiver’s AUDIO

and S VIDEO OUT jacks to the VCR’s AUDIO and S VIDEO IN jacks.

6Using A/V and S VIDEO cables, connect the VCR’s AUDIO and S

VIDEO OUT jacks to the SXRD projection TV’s AUDIO and S VIDEO

IN jacks.

7Run Auto Program, as described in “Setting Up the SXRD Projection

TV Channel List” on page 60.

Setting Up the SXRD Projection TV

SXRD

2-584-141-12(1)

Rear of SXRD projection TV

S VIDEO AUDIO-R

AUDIO-L

VIDEO

Satellite receiver

VCR

S VIDEO cable A/V cable

A/V cable

Satellite

antenna

cable

S VIDEO cable

Cables are often

color-coded to connectors.

Connect red to red,

white to white, etc.

CATV cable

Splitter

Coaxial cable

Coaxial

cable

✍Be sure your VCR’s video input is set correctly. See your VCR’s operating

manual for instructions.

✍If your VCR or satellite receiver is not equipped with S VIDEO, use a

VIDEO cable (yellow) instead of the S VIDEO cable.

Setting Up the SXRD Projection TV

SXRD

2-584-141-12(1)

DVD Player with

Component

Video Connectors

Use this hookup if:

❑Your DVD player has component (Y, PB, PR) jacks.

Disconnect all power sources before making any connections.

1Using a component video cable, connect the DVD player’s Y, PB and PR

jacks to the SXRD projection TV’s Y, PB and PR jacks. Use the HD/

DVD IN 4 or 5 input.

2Using an audio cable, connect the DVD player’s AUDIO OUT jacks to

the SXRD projection TV’s AUDIO IN jacks. Be sure to use the same

row of inputs that you used for the video connection (HD/DVD IN 4 or

5).

✍The Y, PB and PR jacks on your DVD player are sometimes labeled Y,

CB and CR, or Y, B-Y and R-Y. If so, connect the cables to like colors.

Component video cable

Rear of SXRD projection TV

Audio cable

DVD player

AUDIO-R

AUDIO-L

Cables are often

color-coded to connectors.

Connect red to red,

white to white, etc.

✍To take advantage of the Wide Mode feature, set the DVD player’s

aspect ratio to 16:9. For details, refer to the operating instructions

supplied with your DVD player.

Setting Up the SXRD Projection TV

SXRD

2-584-141-12(1)

DVD Player with

S VIDEO and Audio

Connectors

Use this hookup if:

❑Your DVD player does not have component (Y, PB, PR) jacks.

Disconnect all power sources before making any connections.

1Using an audio cable, connect the DVD player’s AUDIO OUT jacks to

the SXRD projection TV’s AUDIO IN jacks.

2Using a S VIDEO cable, connect the DVD player’s S VIDEO jack to the

SXRD projection TV’s S VIDEO jack.

Cables are often

color-coded to connectors.

Connect red to red,

white to white, etc.

DVD player

Rear of SXRD projection TV

A/V cable

S VIDEO

cable

S VIDEO

AUDIO-R

AUDIO-L

VIDEO

✍If your DVD player is not equipped with S VIDEO, use a VIDEO cable

(yellow) instead of the S VIDEO cable.

✍To watch the DVD player, press TV/VIDEO repeatedly to select the

DVD input (VIDEO 1 in the illustration). If you have a non-Sony DVD

player, and want to set up the TV remote control to operate the DVD

player you must program the remote control. See “Programming the

Remote Control” on page 64.

✍To control DVD functions with the TV remote control, see “Operating

a DVD Player” on page 67.

✍To label video inputs to easily identify equipment connected to the

TV, see the instructions for setting up Video Labels on page 123.

Setting Up the SXRD Projection TV

SXRD

2-584-141-12(1)

Camcorder Disconnect all power sources before making any connections.

For easy connection of the camcorder, the SXRD projection TV has front

audio and video inputs (shown below). However, if you prefer, you can also

connect the camcorder to the SXRD projection TV’s rear AUDIO and S

VIDEO IN jacks.

Using A/V and S VIDEO cables, connect the camcorder’s audio and

S VIDEO OUT jacks to the SXRD projection TV’s AUDIO and S VIDEO

IN jacks.

✍If your camcorder is equipped with an i.LINK jack, you can connect it

using i.LINK instead of the A/V inputs. See “Using i.LINK” on page 99.

✍If you have a mono camcorder, connect its left audio output to the SXRD

projection TV’s AUDIO L (MONO) jack.

✍If your camcorder is not equipped with S VIDEO, use a VIDEO cable

(yellow) instead of the S VIDEO cable.

S VIDEO VIDEO

L (MONO) - AUDIO -R

TS/DV/MICROMV/HDV

i.LINK S400 VIDEO 2 INPUT

VIDEO

To A/V output

AUDIO-L

AUDIO-R

S VIDEO

A/V cable

S VIDEO cable

Front of SXRD projection TV

Cables are often

color-coded to connectors.

Connect red to red,

white to white, etc.

To S VIDEO

output

Camcorder

Setting Up the SXRD Projection TV

SXRD

2-584-141-12(1)

Audio Receiver For improved sound quality, you may want to play the TV’s audio through

your stereo system (see page 113).

Disconnect all power sources before making any connections.

Using an audio cable, connect the SXRD projection TV’s AUDIO OUT

(VAR/FIX) jacks to the audio receiver’s audio LINE IN jacks.

✍AUDIO OUT jacks are operable only when the TV’s Speaker is set to Off.

For details, see page 113.

OUT

(

VAR/FIX

)

Rear of SXRD projection TV

AUDIO-L AUDIO-R

Audio cable

Line

input

Cables are often

color-coded to connectors.

Connect red to red,

white to white, etc.

Audio receiver

Setting Up the SXRD Projection TV

SXRD

2-584-141-12(1)

Digital Cable Box Disconnect all power sources before making any connections.

1Using a component video cable, connect the digital cable box’s Y, PB

and PR jacks to the SXRD projection TV’s Y, PB and PR jacks. Use the

HD/DVD IN 4 or 5 input.

2Using an audio cable, connect the digital cable box’s AUDIO OUT

jacks to the SXRD projection TV’s AUDIO IN jacks.

✍Component video (Y, PB, PR) connection is necessary to view 480p,

720p, and 1080i formats. Note that this TV displays all format types of

picture in a resolution of 1920 dots x 1080 lines.

✍The Y, PB and PR jacks do not provide audio, so audio cables must be

connected to provide sound.

AUDIO

OUT

(VAR/FIX)

Rear of SXRD projection TV

AUDIO-L

AUDIO-R

Audio cable

Component video cable

Digital cable box

Cables are often

color-coded to connectors.

Connect red to red,

white to white, etc.

Setting Up the SXRD Projection TV

SXRD

2-584-141-12(1)

Digital Satellite

Receiver

Disconnect all power sources before making any connections.

1Using a component video cable, connect the digital satellite receiver’s

Y, P B and PR jacks to the SXRD projection TV’s Y, PB and PR jacks. Use

the HD/DVD IN 4 or 5 input.

2Using an audio cable, connect the digital satellite receiver’s AUDIO

OUT jacks to the SXRD projection TV’s AUDIO IN jacks.

✍Component video (Y, PB, PR) connection is necessary to view 480p,

720p, and 1080i formats. Note that this TV displays all format types of

picture in a resolution of 1920 dots x 1080 lines.

✍The Y, PB and PR jacks do not provide audio, so audio cables must be

connected to provide sound.

AUDIO

OUT

(VAR/FIX)

Rear of SXRD projection TV

AUDIO-L

AUDIO-R

Audio cable

Component video cable

Digital satellite receiver

Cables are often

color-coded to connectors.

Connect red to red,

white to white, etc.

Setting Up the SXRD Projection TV

SXRD

2-584-141-12(1)

Digital Satellite

Receiver with an

HDMI Connector

Use this hookup if:

❑Your digital satellite receiver has a High-Definition Multimedia

Interface (HDMI).

Disconnect all power sources before making any connections:

Using an HDMI cable (not supplied), connect the digital satellite receiver’s

HDMI OUT jack to the SXRD projection TV’s HDMI IN jack.

Use the HDMI IN 6 or 7 input.

The HDMI jack

provides both video

and audio signals, so it

is not necessary to

connect an audio

cable.

Rear of SXRD projection TV

HDMI cable

Digital satellite receiver

Setting Up the SXRD Projection TV

SXRD

2-584-141-12(1)

When connecting to the Digital Satellite Receiver’s DVI-HDTV connector

If you are connecting to a digital satellite receiver with DVI-HDTV output,

you can connect to the SXRD projection TV’s HDMI IN jack by using an

HDMI-DVI cable.

1Using an HDMI-DVI cable, connect the digital satellite receiver’s DVI-

HDTV OUT jack to the SXRD projection TV’s HDMI IN jack.

Use the HDMI IN 6 input.

2Using an audio cable, connect the digital satellite receiver’s AUDIO

OUT jacks to the SXRD projection TV’s AUDIO IN jacks.

✍The DVI-HDTV VIDEO jack does not provide audio, so audio cables must

be connected to provide sound when an HDMI-DVI cable is used.

✍Use only the HDMI IN 6 input for this connection. If the HDMI IN 7 input

is used for this connection, the AUDIO IN jacks in HDMI IN 6 become

unavailable.

Rear of SXRD projection TV

HDMI-DVI cable

Audio cable

Digital satellite receiver

AUDIO-R

AUDIO-L

Cables are often

color-coded to connectors.

Connect red to red,

white to white, etc.

Setting Up the SXRD Projection TV

SXRD

2-584-141-12(1)

Connecting a Device with an Optical IN Connector

You can use the SXRD projection TV's DIGITAL AUDIO (OPTICAL) OUT

jack to connect a digital audio device that is PCM/Dolby digital compatible,

such as an audio amplifier.

Using an optical audio cable, connect the device's OPTICAL IN jack to the

SXRD projection TV's DIGITAL AUDIO (OPTICAL) OUT jack.

AUDIO

OUT

(VAR/FIX)

OPTICAL

LINE

OUT

L AUDIO R

LINE

Optical audio cable

Rear of SXRD projection TV

Audio amplifier

The DIGITAL AUDIO

(OPTICAL) OUT jack is

available only when a

digital TV channel is

received.

✍You should also connect the TV’s analog audio output jacks to the

amplifier’s analog audio input jacks so that the amplifier can output

audio for analog channels. For details, see page 51.

Setting Up the SXRD Projection TV

SXRD

2-584-141-12(1)

Using the CONTROL S Feature

CONTROL S allows you to control your SXRD projection TV system and

other Sony equipment with one remote control. In addition to allowing you

to control multiple devices with one remote control, the CONTROL S

feature allows you to always point your remote control at your SXRD

projection TV, instead of having to point it at the other equipment, which

might be hidden or out of direct line of sight.

AUDIO

OUT

(VAR/FIX)

Rear of SXRD projection TV

Setting Up the SXRD Projection TV

SXRD

2-584-141-12(1)

Using CableCARD

CableCARD provides cable subscribers with access to digitally encrypted

cable channels — without the need for a set-top box — that will enable you

to receive not only standard definition but also high definition television. The

CableCARD, which is provided by your cable TV company, is inserted into

the TV’s rear panel CableCARD slot. After the service is activated with your

cable TV company, the card replaces the need for a separate set-top box.

Activating

CableCARD Service

Before you can use CableCARD service, you need to insert the CableCARD

(supplied by your cable TV company) and activate the service, as described

below:

1Insert the CableCARD into the TV’s CableCARD slot.

About Using CableCARD

If you are planning to use a separate cable box for digital cable TV services, you may be able to receive

programming using this TV with the CableCARD instead — except in the following circumstances:

❑Your cable TV company does not provide CableCARD service in your viewing area.

❑You want to access your cable TV company’s interactive or advanced features (such as video-on-

demand or, in some cases, pay-per-view). At this time, these services require a bidirectional link,

which are only available through the use of a separate set-top box. CableCARD is currently a

unidirectional device only, and cannot provide these advanced services.

Check with your cable TV company for CableCARD service details, limitations, pricing, and

availability, all of which are determined by your cable TV company — not Sony.

✍CAUTION: Inserting the CableCARD incorrectly may result in permanent

damage to the card and the TV.

Setting Up the SXRD Projection TV

SXRD

2-584-141-12(1)

2Gently push the card into the slot until it locks into place.

3After 1-2 minutes, the CableCARD setup screen is automatically

displayed. This screen includes information your cable TV company

will request before they can activate your service.

4Follow the displayed instructions: Phone your cable TV company. A

representative will guide you through the activation process.

5After your CableCARD is activated, your cable TV company will

download the service information, including the channel list, to the

CableCARD. After the CableCARD has acquired channels from your

cable TV company, the TV tunes to the lowest available channel.

Removing the

CableCARD

In the event you want to cancel your service, contact your cable TV

company.

1Push the eject button on the TV’s CableCARD slot to release the card.

2Pull the CableCARD straight out of the slot to remove it.

To install a different CableCARD, follow the instructions in “Activating

CableCARD Service” on page 58.

You can also access

information about your

CableCARD in the

Applications Menu (see

page 126).

✍Once the CableCARD is removed, your TV will no longer decrypt digital

cable TV programming services that require CableCARD.

Eject button

Setting Up the SXRD Projection TV

SXRD

2-584-141-12(1)

Setting Up the SXRD Projection TV Channel List

After you finish connecting the TV, you need to run the Initial Setup feature,

which automatically creates a list of available analog and digital channels.

The Initial Setup screen appears when you turn on your TV for the first time

after hooking it up. If you want to refresh the list of available channels

because there has been a change in your cable/satellite service or

connections, you can do so by selecting the Auto Program option in the

Channel menu (see page 116).

Using Initial Setup To run Initial Setup the first time you turn on your TV

1Press POWER to turn on the TV.

The Initial Setup screen appears.

2Press V or v to select the on-screen display language. Then press .

The message “Start auto program now?” appears.

3Press V or v to select “Yes”, then press .

Initial Setup automatically creates a list of receivable channels. When

finished, the lowest numbered channel is displayed.

To run Auto Program again at a later time

❑Use the Auto Program feature as described on page 116.

To add individual digital channels

❑Use the Digital Channel feature as described on page 116.

✍The Initial Setup feature does not apply for installations that use a

cable box for all channel selection.

✍Auto Program may take more than 50 minutes to complete. A

progress bar is displayed while the channel list is being created.

If you are using a

CableCARD, Auto

Program is disabled for

the CABLE input.

SXRD

2-584-141-12(1)

Using the Remote Control

Overview

The table on the next page describes the buttons on the remote control.

Inserting Batteries into the Remote Control

Insert two size AA (R6) batteries (supplied) by matching the e and E on

the batteries to the diagram inside the battery compartment.

✍To avoid possible damage from battery leakage, remove the batteries if

you anticipate the remote control will not be used for an extended period.

✍Handle the remote control with care. Avoid dropping it, getting it wet, or

placing it in direct sunlight, near a heater, or in high humidity.

✍Your remote control can be programmed to operate most video

equipment. (See “Programming the Remote Control” on page 64.)

Coin Lock

Using the Remote Control

SXRD

2-584-141-12(1)

Button Descriptions

Button Description

1MUTING Press to mute the sound. Press again or press VOL + to restore

the sound.

2FUNCTION Press repeatedly until the indicator of the equipment (TV,

SAT/CABLE, DVD/VCR, i.LINK) that you want to operate

lights up.

3Press repeatedly to step through the available audio effect

modes: Dolby Virtual, TruSurround, Simulated, Off.

For details, see “Selecting Audio Options” on page 112.

4SLEEP Press repeatedly until the TV displays the time in minutes (15,

30, 45, 60 or 90) that you want the SXRD projection TV to

remain on before shutting off. To cancel Sleep Timer, press

SLEEP repeatedly until Sleep Off appears.

5GUIDE Press to display the digital program guide.

While FUNCTION is switched on SAT/CABLE, press to

display the program guide of your satellite program provider.

6Use with 0-9 and ENTER buttons to select digital channels

(for example, 2.1). For details on selecting digital channels,

see page 69.

7PICTURE Press repeatedly to step through the available video picture

modes: Vivid, Standard, Pro. Also available in the Video

menu. For details, see “Selecting Video Options” on page 108.

8WIDE Press to step through the wide screen modes: Wide Zoom,

Normal, Full and Zoom. For details, see “Using Wide Screen

Mode” on page 72.

9V/v/B/b

X/x/m/M

When the menu is displayed, move the on-screen cursor.

X: Pause

x: Stop

m: Fast-Reverse

M: Fast-Forward

q; H: Playback

: When the menu is displayed, select the item.

(Twin View)

Press to turn on/off Twin View. For details, see “Using Twin

View” on page 74.

qs ANT

INDEX

Press to change between the VHF/UHF input and the CABLE

input.

While FUNCTION is switched on SAT/CABLE, press to

display index of your satellite program provider.

qd VOL +/– Press to adjust the volume.

qf POWER

buttons

(Green)

Press to turn on and off the SXRD projection TV and other

audio/video equipment you have programmed into the remote

control. For instructions, see “Programming the Remote

Control” on page 64.

zThe 5 button and CH+

button have a tactile dot.

Use the tactile as a

reference when operating

the TV.

Using the Remote Control

SXRD

2-584-141-12(1)

Using the Remote Control

qg REC

RESET

Record

Press when in a menu to reset the settings to the factory

defaults.

qh TV/VIDEO Press to

cycle through the video equipment connected to your

SXRD projection TV

’s video inputs:

VIDEO 1

VIDEO 2

VIDEO 3

VIDEO 4

VIDEO 5

VIDEO 6

and

VIDEO 7

qj DISPLAY Press once to display the current time and channel label (if set)

and channel number. Press again to turn Display off. See page

126 for details on setting the time.

qk JUMP Press to jump back and forth between two channels. The

SXRD projection TV alternates between the current channel

and the last channel that was selected.

ql 0 – 9 and

ENTER

Press 0 - 9 to select a channel, the channel changes after 3

seconds. Press ENTER to select immediately.

w; FAVORITES Press to display the Favorite Channels list. For details, see

“Using Favorite Channels” on page 77.

wa FREEZE Press to freeze the window picture. Press again to restore the

picture.

ws i.LINK Press to display the i.LINK Control Panel. For information on

using the i.LINK Control Panel, see page 103. Also available

in the Applications Menu (page 125).

MEMORY

STICK

Press to display the Memory Stick Menu.

For details, see “Using the Memory Stick Viewer” on page 81.

wf MENU Press to display the SXRD projection TV on-screen menu.

Press again to exit from the menu.

wg CH +/– Press to scan through channels. To scan quickly through the

channels, press and hold down CH+ or CH–.

wh EXIT Press to exit the on-screen menu or display and return to

normal viewing.

Button Description

Using the Remote Control

SXRD

2-584-141-12(1)

Programming the Remote Control

The remote control is preset to operate Sony brand video equipment.

If you have video equipment other than Sony brand that you want to control

with the SXRD projection TV’s remote control, use the following procedure

to program the remote control.

1Turn to the list of “Manufacturer’s Codes” on page 65, and find the

three-digit code number for the manufacturer of your equipment. (If

more than one code number is listed, use the number listed first.)

2Press FUNCTION repeatedly until the DVD/VCR, SAT/CABLE or

i.LINK indicator lights up.

3Press SAT/CABLE for five seconds until the indicator of the selected

input flashes.

4While the desired indicator is flashing, enter the three-digit

manufacturer’s code number.

5Press ENTER.

6To check if the code number works, aim the SXRD projection TV’s

remote control at the equipment and press SAT/CABLE that

corresponds with that equipment. If it responds, you are done. If not, try

using another code listed for that manufacturer.

Function Equipment Programmable Code

Number

DVD/VCR Sony DVD player 751

SAT/CABLE Sony Satellite Receiver 801

i.LINK Sony DVD player (i.LINK) 901

✍The equipment must have infrared (IR) remote capability in order to be

used with the remote control.

✍You must do step 5 within 10 seconds of step 4, or you must redo

steps 4 through 5.

✍If more than one code number is listed, try entering them one by one

until you come to the correct code for your equipment.

✍If you enter a new code number, the code number you previously entered

at that setting is erased.

✍In some cases, you may not be able to operate your equipment with the

supplied remote control. In such cases, use the equipment’s own remote

control unit.

✍Whenever you remove the batteries to replace them, the code numbers

may revert to the factory setting and must be reset.

Using the Remote Control

SXRD

2-584-141-12(1)

Using the Remote Control

Manufacturer’s Codes

VCRs

Laserdisc Players

DVD Players

Cable Boxes

Satellite Receivers

* If an Aiwa VCR does not work even

though you enter the code for Aiwa,

enter the code for Sony instead.

Manufacturer Code

Sony 301, 302, 303

Admiral

(M. Ward)

327

Aiwa* 338, 344

Audio Dynamic 314, 337

Broksonic 319, 317

Canon 309, 308

Citizen 332

Craig 302, 332

Criterion 315

Curtis Mathes 304, 338, 309

Daewoo 341, 312, 309

DBX 314, 336, 337

Dimensia 304

Emerson 319, 320, 316,

317, 318, 341

Fisher 330, 335

Funai 338

General Electric 329, 304, 309

Go Video 322, 339, 340

Goldstar 332

Hitachi 306, 304, 305,

338

Instant Replay 309, 308

JC Penney 309, 305, 304,

330, 314, 336,

337

JVC 314, 336, 337,

345, 346, 347

Kenwood 314, 336, 332,

337

LG 332

LXI (Sears) 332, 305, 330,

335, 338

Magnavox 308, 309, 310

Marantz 314, 336, 337

Marta 332

Memorex 309, 335

Minolta 305, 304

Mitsubishi/

MGA

323, 324, 325,

326

Multitech 325, 338, 321

NEC 314, 336, 337

Olympic 309, 308

Optimus 327

Orion 317

Manufacturer Code

Panasonic 308, 309, 306,

307

Pentax 305, 304

Philco 308, 309

Philips 308, 309, 310

Pioneer 308

Quasar 308, 309, 306

RCA/

PROSCAN

304, 305, 308,

309, 311, 312,

313, 310, 329

Realistic 309, 330, 328,

335, 324, 338

Sansui 314

Samsung 322, 313, 321

Sanyo 330, 335

Scott 312, 313, 321,

335, 323, 324,

325, 326

Sharp 327, 328

Signature 2000

(M. Ward)

338, 327

SV2000 338

Sylvania 308, 309, 338,

310

Symphonic 338

Tashiro 332

Tatung 314, 336, 337

Teac 314, 336, 338,

337

Technics 309, 308

Toshiba 312, 311

Wards 327, 328, 335,

331, 332

Yamaha 314, 330, 336,

337

Zenith 331

Manufacturer Code

Sony 701

Panasonic 704, 710

Pioneer 702

Function Code

Sony 751

Sony (i.LINK) 901

General Electric 755

Hitachi 758

JVC 756

Magnavox 757

Mitsubishi 761

Oritron 759

Panasonic 753

Philips 757

Pioneer 752

RCA/PROSCAN 755

Samsung 758

Toshiba 754

Zenith 760

Manufacturer Code

Sony 230

Hamlin/Regal 222, 223, 224,

225, 226

Jerrold/G. I./

Motorola

201, 202, 203,

204, 205, 206,

207, 208, 218

Oak 227, 228, 229

Panasonic 219, 220, 221

Pioneer 214, 215

Scientific Atlanta 209, 210, 211

Tocom 216, 217

Zenith 212, 213

Manufacturer Code

Sony 801

Dish Network 810

Echostar 810

General Electric 802

Hitachi 805

Hughes 804

Mitsubishi 809

Panasonic 803

RCA/

PROSCAN

802, 808

Toshiba 806, 807

Using the Remote Control

SXRD

2-584-141-12(1)

Using Other Equipment with Your SXRD Projection TV Remote

Control

To operate other connected equipment with your SXRD projection TV

remote control, first turn to page 65 and program the necessary code. For

operating video equipment, press TV/VIDEO repeatedly until you see the

video input on the screen for your connected equipment. Remote control

operation tips are provided below.

Operating a VCR

Operating a Satellite

Receiver

To Do This ... Press

Activate the remote control to

operate the VCR

FUNCTION repeatedly until the DVD/VCR

indicator lights up.

Turn on/off SAT/CABLE

Change channels CH +/–

Record z REC

Play

Stop x

Fast forward M

Rewind the tape m

Pause X

Search the picture forward or

backward

M or m during playback

(release to resume normal playback)

To Do This ... Press

Activate the remote control to

operate the satellite receiver

FUNCTION repeatedly until the SAT/CABLE

indicator lights up.

Turn on/off SAT/CABLE

Select a channel 0-9, ENTER

Change channels CH +/–

Back to previous channel JUMP

Display channel number DISPLAY

Display SAT Index INDEX

Display SAT Guide GUIDE

Display SAT Menu MENU

Move highlight (cursor) V v B b

Select item

Using the Remote Control

SXRD

2-584-141-12(1)

Using the Remote Control

Operating a Cable

Box

Operating a DVD

Player

Operating an MDP

(Laserdisc Player)

To Do This ... Press

Activate the remote control to

operate the cable box

FUNCTION repeatedly until the SAT/CABLE

indicator lights up.

Turn on/off SAT/CABLE

Select a channel 0-9, ENTER

Change channels CH +/–

Back to previous channel JUMP

To Do This ... Press

Activate the remote control to

operate the DVD

FUNCTION repeatedly until the DVD/VCR

indicator lights up.

Turn on/off SAT/CABLE

Play

Stop x

Pause X

Step through different

tracks of the disc

M to step forward or m to step backward

Step through different chapters

of a video disc

CH+ to step forward or CH– to step backward

To Do This ... Press

Activate the remote control to

operate the MDP

FUNCTION repeatedly until the indicator of the

position you programmed for the MDP player lights

up.

Turn on/off SAT/CABLE

Play

Stop x

Pause X

Search the picture forward or

backward

M or m during playback

(release to resume normal playback)

Search a chapter forward or

backward

CH +/–

Using the Features

SXRD

2-584-141-12(1)

Using the Features

Overview

This chapter describes how to use the features of your TV.

Watching TV

Topic Page

Watching TV 69

Using the Program Guide 70

Using Wide Screen Mode 72

Using Twin View 74

Using Favorite Channels 77

Using the Freeze Function 79

To Do This ... Do This ...

Activate the remote control to

operate the TV

Press FUNCTION repeatedly until the TV

indicator lights up.

Turn on/off the TV Press POWER.

Tune directly to a channel To tune to analog channels, press 0-9 and then

ENTER.

For digital subchannels, press 0-9,,

press 0-9 again, and then ENTER.

For example, to select subchannel 21.13, press

2+1+ +1+3, and then press ENTER.

You can also select channels using the

program guide. See page 70 for details.

Adjust the volume Press VOL +/–.

Mute the sound Press MUTING (press again or VOL + to

restore the sound).

Alternate back and forth between

two channels

Press JUMP.

The SXRD projection TV alternates between

the current channel and the last channel that

was selected.

Display the current channel

number (and other information)

Press DISPLAY once to display the channel

number, current time, and channel label (if

set). Press DISPLAY again to turn Display off.

Switch the TV’s input to the VCR,

DVD player, or other connected

equipment

Press TV/VIDEO repeatedly to cycle through

the video equipment connected to the TV’s

video inputs.

Change video and audio options,

customize the TV’s setup, set

parental controls, and more

Press MENU to display the Menu. For details,

see “Using the Menus” on page 107.

Switch the TV’s input between

sources connected to the TV’s

VHF/UHF and CABLE inputs

Press ANT to alternate between sources

connected to the TV’s VHF/UHF and CABLE

inputs.

For a complete list of all

the functions of the

remote control, see

pages 61-67.

Using the Features

SXRD

2-584-141-12(1)

Using the Program Guide

Displaying the

Program Guide

This SXRD projection TV is equipped to show program information if it is

available from the station. The program guide lets you review program

information and select both analog and digital channels.

To display the program guide:

1Tune your SXRD projection TV to a channel by using the 0-9,,

and ENTER buttons.

2Press GUIDE on the SXRD projection TV’s remote control. The

program guide will appear with the currently selected program showing

in the background.

✍Program information in the guide is provided by the broadcasters. As a

result, it may sometimes include only the channel number, without a

program title or description.

Make Way for Ducks!

Series follows the aquatic misadventures of Henry and Riley, two

wayward ducks on a unique mission.

Time remaining: 1:26

FAM

TV-G

1 ABC

10 DISC

23.1

FAM

36 TLC

65 HIST

68 SHOW

C23.1

Channel number,

call letters, etc.

Program title and

description,

program

duration, time

remaining, rating

information,

closed-caption

availability, etc.

Selectable

channel list.

Using the Features

SXRD

2-584-141-12(1)

Using the Guide

The Program Guide menu allows you to select channels from a dropdown

list. The Guide provides information about the current program being shown

on each channel.

Using the Program

Options Menu

The Program Options menu allows you to customize the program settings on

the currently tuned channel.

✍Subchannels are additional channels of programming broadcast

simultaneously. For example, channel 4 might include three subchannels

(4.1, 4.2, 4.3) that are showing programs at the same time.

Main

Video 1

Video 2

Video 3

Make Way for Ducks!

Series follows the aquatic misadventures of Henry and Riley, two

wayward ducks on a unique mission.

Time remaining: 1:26

TV-G

Alternate Video

Alternate Audio

FAM

C23.1

1 ABC

10 DISC

23.1

FAM

36 TLC

65 HIST

68 SHOW

Option Description

Alternate

Video

(when

available)

Each program has a main video stream (the video that you see when

the channel is first tuned), and may have alternate video streams. This

option allows you to switch among these alternate video streams.

Alternate

Audio

(when

available)

Each program has a main audio stream (the audio you hear when the

channel is first tuned), and may have alternate audio streams. This

option allows you to switch among these alternate audio streams (e.g.,

for different languages).

Using the Features

SXRD

2-584-141-12(1)

Using Wide Screen Mode

Wide screen mode lets you watch 4:3 normal broadcasts in several wide

screen modes (16:9 aspect ratio).

❑Press WIDE repeatedly to toggle through the following screen mode

settings.

Changing the Wide Screen Mode for 4:3 Source (Standard definition source)

You can also access the

screen mode settings in

the Screen menu. For

details, see page 114.

Example Description

Wide Zoom enlarges the center portion of

the picture. The left and right edges of the

picture are stretched to fill the 16:9 screen.

Normal displays the 4:3 picture in its

original size. Side bars are shown to fill the

16:9 screen.

Full stretches the 4:3 picture horizontally,

to fill the 16:9 screen.

Zoom enlarges the 4:3 picture to fill the

16:9 screen. Zoom is useful for watching

Letterbox movies.

✍When you change channels or inputs, the Wide Mode settings revert

to the 4:3 Default setting in the Screen Menu. To retain the current

Wide Mode setting as channels and inputs are changed, set 4:3

Default to Off. For details, see page 115.

original source

Wide Zoom

Normal

Full

Zoom

Using the Features

SXRD

2-584-141-12(1)

Changing the Wide Screen Mode for 16:9 Source (High definition source)

Example Description

Wide Zoom enlarges the center portion of the picture. The left and right edges of

the picture are stretched to fill the 16:9 screen.

Full displays the picture at its original size.

Zoom enlarges the picture proportionately, both vertically and horizontally.

✍When the TV receives a 720p or 1080i signal, Normal cannot be selected.

✍When TV receives a 720p or 1080i signal that is 4:3 aspect ratio picture

(upconverted to 16:9) with a black bar at each side, Full returns the picture to

its original size.

original source

(Upconverted 4:3)(Upconverted 4:3) (Native 16:9)

Wide Zoom

Full

Zoom

Using the Features

SXRD

2-584-141-12(1)

Using Twin View

Twin View lets you see two pictures from two sources — from an antenna,

VCR, DVD, etc. — on the screen at the same time. You hear the sound from

only one of the sources at a time, but you can choose which source’s sound is

selected. You can also change the relative size of each of the pictures.

Displaying Twin

Pictures

To display Twin View

1Make sure your SXRD projection TV is tuned to

a working channel.

2Press .

A second picture appears. The active picture is highlighted.

To cancel Twin View and watch the active picture

❑Press again (or press ).

Activating the


You can use B or b buttons to activate the left and right pictures while using

Twin View.

To activate the right picture To activate the left picture

❑Press b.Press B.

FOX

C8.1

Video 1

DVD

FOX

C8.1

Video 1

DVD

C8.1

FOX

Video 1

DVD

Using the Features

SXRD

2-584-141-12(1)

Functions Available in the Active (Highlighted) Window

Factors Affecting Twin View

❑If you use a cable box to view all channels, the same channel appears in

both windows because the cable box unscrambles and sends only one

channel at a time. (To view the picture in dual picture features such as

Twin View, Freeze, etc., see “Cable Box and Antenna” on page 37.)

❑If you use a cable box and other video equipment, you can view the

cable box output in one window and view a different source (such as a

VCR or DVD player) in the second window by using the TV/VIDEO

button.

❑Digital TV channels, as well as any sources connected to the HD/DVD

IN 4-5, and HDMI IN 6-7 inputs display in the left window, but not the

right.

❑If you are viewing a 4:3 source and a 16:9 enhanced source (such as a

DVD) side by side, the 4:3 source appears larger.

❑Twin View does not display channels that are blocked by parental

settings (see page 118).

To Do This ... Do This ...

Tune to a channel To tune to analog channels, press 0-9 and then

ENTER.

For digital subchannels, press 0-9,,

press 0-9 again, and then ENTER.

For example, to select subchannel 21.13, press

2+1++1+3, and then press ENTER.

Adjust the volume Press VOL +/–.

Mute the sound Press MUTING (press again or press VOL +

to restore the sound).

Switch the TV’s input between

sources connected to the TV’s

VHF/UHF and CABLE inputs

Press ANT.

Switch the TV’s input between

sources connected to the TV’s A/V

inputs

Press TV/VIDEO.

Change the picture size Press V or v. (For details, see “Changing the

Picture Size” on page 76.)

Using the Features

SXRD

2-584-141-12(1)

Changing the

Picture Size

The zoom feature lets you change the size of the left and right pictures.

To enlarge the left

picture (reduce the

right)

1Press B to

activate the left

picture (if not

already

activated).

2Press V to

enlarge the

picture and v to

reduce the

picture.

To enlarge the right

picture (reduce the

left)

1Press b to

activate the right

picture (if not

already

activated).

2Press V to enlarge

the picture and v

to reduce the

picture.

✍When you adjust the picture sizes in Twin View, the SXRD projection TV

memorizes the change. The next time you use the Twin View function,

the memorized sizes appear.

Using the Features

SXRD

2-584-141-12(1)

Using Favorite Channels

The Favorite Channels feature lets you select programs from a list of up to

16 favorite channels that you specify. You can create a list using the Favorite

Channels option in the Channel Menu, or by using the Add to Favorites

feature in the Favorite Channels guide.

Using the Channel

1Press MENU to display the Menu.

2Press V or v to highlight the Channel icon and press .

3Press to select Favorite Channels.

4Use the 0-9 and ENTER buttons to enter the channel number that you

want to assign to the Favorite Channel number. A preview of the

highlighted channel appears in the upper right of the screen.

Press to select that channel as a Favorite Channel.

5To add more channels to your favorites list, repeat step 4.

To clear a Favorite Channel, press V or v to highlight the channel you

want to clear. Press RESET.

6Press MENU to exit the Menu.

✍Digital channels do not display in the preview window.

✍To enter digital channel numbers in step 4, use the 0-9, , 0-9 and

ENTER buttons.

For details on using the

Channel Menu, see

page 116.

Using the Features

SXRD

2-584-141-12(1)

Using the Favorite

Channels Guide

1Press FAVORITES.

The Favorite Channels list appears.

2Press V or v to highlight the channel you want to watch. A preview of

the highlighted Favorite Channel appears.

To add the current channel to the list of Favorite Channels, highlight

Add to Favorites and press .

3Press to select the channel you want to watch.

To change your Favorite Channels list or delete a channel from the list,

highlight Edit Favorites and press .

✍Digital channels do not display in the preview window.

Add to Favorites

Favorite Channels

1 8.14 PBS

2 15.8 NBC

3 27 HGTV

4 45.12 TNT

5 98 CNN

6 112.3 ESPN

7 120 NICK

Preview of

highlighted

Favorite

Channel

Favorite

Channels

Using the Features

SXRD

2-584-141-12(1)

Using the Freeze Function

The FREEZE button allows you to temporarily capture a program’s picture.

You can use this feature to write down information such as phone numbers,

recipes, etc.

To use the Freeze function

1When the program information you want to capture is displayed on the

screen, press FREEZE.

2The SXRD projection TV switches to Twin View and displays the

“frozen” picture on the right, while the current program continues on the

left.

3To cancel and return to normal viewing, press FREEZE again (or just

turn to another channel).

✍The Freeze feature is not available if you are using Favorite Channels (see

page 77) or Twin View (see page 74).

Current

program

in progress

Frozen


Call 555-1234

Using the Memory Stick Viewer

SXRD

2-584-141-12(1)

Using the Memory Stick Viewer

About Memory Stick

Memory Stick (sold separately) is a new, compact, portable, and versatile

Integrated Circuit recording medium with a data capacity that exceeds that

of a floppy disk. Memory Stick is specially designed for sharing digital data

among Memory Stick compatible products such as digital cameras and

digital video cameras. Because it is removable, Memory Stick can also be

used for external data storage.

The Memory Stick Viewer on your SXRD projection TV allows you to view

files that are stored on Memory Stick media. You can view:

❑Digital photos (JPEG files)

❑Movies (MPEG1 files)

You can also play slide show background music using MP3 files stored on

your Memory Stick.

For more information about handling Memory Stick media, see “Notes on

Using Memory Stick Media” on page 96.

Features With the Memory Stick Viewer, you can:

❑View photo (JPEG) and movie (MPEG1) files in a thumbnail index or

Slide Show

❑Set customized Slide Show options, including transitions and

background audio

❑Pan, zoom, and rotate photos

❑Mark photos and set quantities of prints to be output when the Memory

Stick is inserted into your photo printer (not supplied)

❑Lock (protect) or delete files on the Memory Stick

Using the Memory Stick Viewer

SXRD

2-584-141-12(1)

Memory Stick

Compatibility

This television is compatible with the following Sony brand Memory Stick

media types:

❑Memory Stick Media

❑Memory Stick Duo and PRO Duo Media (can be used without the

Memory Stick adaptor)

❑Memory Stick Media with Memory Select Function

❑Memory Stick PRO Media

About Memory Stick PRO Media

Memory Stick PRO media features vary by and are dependent upon the

design of host hardware devices. Memory Stick PRO in this SXRD

projection TV has been tested to support up to 1 GB media capacity and does

not support high-speed transfer, MagicGate copyright protection technology,

or access control security features.

Memory Stick

Functionality

Sony cannot guarantee or assure the Memory Stick functionality on this

television in the following cases:

❑You are using non-Sony brand Memory Stick media.

❑You are using video or audio clips that have been processed on a

computer.

❑You are using files that were obtained from the Internet or from a printed

film processing center.

❑The Memory Stick has been formatted on a personal computer.

Sony recommends that you back up all data stored on Memory Stick media

to avoid potential data loss. In the above two cases, in order to avoid

potential data corruption that may occur, be sure to back up data prior to use

with the TV’s Memory Stick Viewer. Sony cannot accept responsibility in

the event that data recorded to Memory Stick media is lost or damaged. For

certain non-Sony brand Memory Stick media, you can view images, but you

cannot rotate, delete or protect/unprotect images on the television. An error

message will occur if you attempt any of these operations. This is a result of

the unique file directory structure on these particular flash memory media

and is not a malfunction of the television.

✍The Memory Stick slot on your TV has been designed to accommodate standard

and compact versions of Memory Stick. It is not necessary to use an adaptor for

Memory Stick Duo and Memory Stick PRO Duo. If you use an adaptor, it may

damage the adaptor and Memory Stick slot.

Using the Memory Stick Viewer

SXRD

2-584-141-12(1)

File Compatibility The Memory Stick Viewer is compatible with JPEG images taken with Sony

digital still cameras and MPEG1* movies taken with Sony digital cameras

and camcorders. To be viewable in the Memory Stick Viewer, files must

have the following file name extensions:

Trademark

Information

Memory Stick, Memory Stick Duo, Memory Stick PRO, Memory Stick PRO

Duo, and MagicGate are trademarks of Sony Corporation.

File Type Supported File Name Extensions

JPEG .jpg

.jpeg

MPEG1 .mpg

.mpeg

* Some variations of MPEG1 movies may not play back correctly.

Using the Memory Stick Viewer

SXRD

2-584-141-12(1)

Inserting and Removing a Memory Stick

If you are using a Memory Stick Duo and PRO Duo, see “Inserting the

Memory Stick Duo” on page 85.

Inserting a Memory

Stick

Locate the Memory Stick slot and insert the Memory Stick into the Memory

Stick slot as illustrated below. When inserted properly, it should slide in with

little resistance and click into place.

To remove the Memory Stick, see “Removing a Memory Stick” on page 86.

✍Be sure to insert the Memory Stick in the correct direction. Forcing the

Memory Stick in the wrong way may damage it.

✍Insert only Memory Stick media into the Memory Stick slot. Attempting

to insert other objects into the Memory Stick slot may damage the SXRD

projection TV.

POWER

STD / DUO

Using the Memory Stick Viewer

SXRD

2-584-141-12(1)

Inserting the

Memory Stick Duo

Memory Stick Duo is a new, compact version of the standard-sized Memory

Stick recording medium.

Insert the Memory Stick Duo as shown below.

To remove the Memory Stick Duo, see “Removing a Memory Stick” on

page 86.

✍CAUTION: The Memory Stick slot on your TV has been designed to

accommodate standard and compact versions of Memory Stick. It is not

necessary to use an adaptor for Memory Stick Duo and Memory Stick

PRO Duo. If you use an adaptor, it may damage the adaptor and Memory

Stick slot.

✍CAUTION: Inserting the Memory Stick Duo incorrectly may result in

permanent damage to the Memory Stick Duo and the SXRD projection

TV.

STD / DUO

Using the Memory Stick Viewer

SXRD

2-584-141-12(1)

Removing a Memory

Stick

1Check that the Memory Stick indicator is off. (When the light is on, this

indicates that the SXRD projection TV is reading data from the Memory

Stick.)

2Push the Memory Stick gently into the Memory Stick slot, and then

release it. The Memory Stick media is ejected.

3Pull the Memory Stick completely out of the slot.

✍Removing the Memory Stick while a file is being accessed (when the

Memory Stick indicator on the SXRD projection TV’s front panel is lit)

may damage the Memory Stick or its contents.

✍When removing the Memory Stick, do not attempt to pull it from its slot

without first pushing it in to release it.

✍To protect small children from injury by Memory Stick media, remove all

Memory Stick media from the SXRD projection TV’s Memory Stick slot

and store in a safe location when not in use.

STD / DUOSTD / DUO STD / DUO

Using the Memory Stick Viewer

SXRD

2-584-141-12(1)

Using the Memory Stick Index

Turn on the SXRD projection TV and insert a Memory Stick that contains

the photo or movie files you want to view. To insert a Memory Stick, see

“Inserting a Memory Stick” on page 84.

The Memory Stick Index appears, which displays thumbnail images of the

files stored on the Memory Stick.

About the Lock and Movie Icons on the Thumbnail Images

✍If the Memory Stick Index does not appear, press on the remote

control.

Summer 2004 / DSC0001

Jul 30, 2004 12:59PM 640x480

Slide Show Contents Memory Stick

1 of 25

Thumbnails of photos and

movies

Memory Stick menu bar

Information about the highlighted

photo or movie

Highlighted thumbnail

Indicates the thumbnail is a movie (MPEG1) file instead of a photo (JPEG)

file.

Indicates the thumbnail is locked. Locked files cannot be changed or deleted.

For details, see “Protect“ on page 90 and 93.

Indicates that the photo is marked to be printed.

Indicates that the photo has an associated voice memo.

Using the Memory Stick Viewer

SXRD

2-584-141-12(1)

Using the Memory

Stick Index

The following describes how to use the Memory Stick Index.

To Do This ... Do This ...

Move the highlight to

a photo, voice memo

( ), or movie ( )

thumbnail

Press V v B b.

Display the

highlighted photo,

voice memo, or movie

file full screen

Press . For details, see “Viewing Photos” on page

89 and “Playing Movies” on page 92.

Display the next page

of thumbnails

1Press v to select V.

2Press v to display the next page of thumbnails.

Display the previous

or next page of

thumbnails

1Press v to select V.

2Press B to select .

3To go to the previous page, press V.

To go to the next page, press v.

Use the Memory Stick

Menu bar to access

additional options

1Press v to select V.

2Press B or b to select Slide Show, Contents, or

Memory Stick.

3Press V or v to select the option you want to change.

For details on these options, see “Memory Stick Index

Menu Bar Options” on page 94.

Move the highlight

from the Memory

Stick Menu bar back

to the thumbnails

1Press B or b to select V.

2Press V to return to the currently displayed

thumbnails, or v to display the next page of

thumbnails.

Exit Memory Stick

Viewer

Press on the remote control.

Using the Memory Stick Viewer

SXRD

2-584-141-12(1)

Viewing Photos

When you select a photo from the Memory Stick Index (described on

page 87), it displays as shown below, with the following controls.

Photo Controls

Summer 2004 / DSC00012

Jul 30, 2004 12:59PM 640x480 12 of 25

Slide ShowIndex View File

Photo menu bar

Information about

selected photo

Selected photo

Previous/next buttons

✍JPEGs captured using a digital video camera may appear to display

motion in full screen. This is a result of the way digital video cameras

record still images, and is not a result of a malfunction with the SXRD

projection TV.

To Do This ... Do This ...

Display the next or

previous file on the

Memory Stick

Press V or v to highlight the (Previous/Next)

button. Then press B to go to the previous file, or b to

go to the next file.

Hide the Photo menu bar,

displaying only the photo

With the highlight in the Photo menu bar, press v.

Display the hidden Photo

menu bar

Press V.

Play the JPEG voice memo

( files only)

Highlight B (Play) and then press . To pause the

voice memo, highlight X (Pause) and then press .

Display the Memory Stick

Index again

Press B or b to highlight Index in the Photo menu bar

and press .

For details on the Memory Stick Index, see page 88.

Access additional options

in the Photo menu bar

See “Photo Menu Bar Options” on page 90.

Exit Memory Stick Viewer Press on the remote control.

When the menu is

hidden, press B or b to

go to the previous or

next photo.

Using the Memory Stick Viewer

SXRD

2-584-141-12(1)

Photo Menu Bar

Options

The Photo menu bar lets you access additional photo viewing options.

To access the Photo menu bar

1Press B or b to select Index, Slide Show, View, or File.

2Use V v B b to select the desired option.

Option Description

Index Displays the Memory Stick Index, with the highlight on the

currently displayed photo’s thumbnail. For details, see “Using the

Memory Stick Index” on page 87.

Slide Show Displays the Slide Show menu. For details, see “Slide Show Menu

Options” on page 94.

View Rotate Allows you to rotate the photo in 90 degree

increments clockwise or counterclockwise. For

details, see “Using Rotate” on page 91.

Zoom/Pan Allows you to magnify and pan across the photo.

For details, see “Using Zoom and Pan” on page 91.

File Protect Allows you to protect the JPEG file from any

changes. When a JPEG file is protected, it cannot

be rotated or deleted. Select On or Off.

Quantity

Allows you to indicate the number of prints to make

of the specific photo when the Memory Stick is

inserted into a compatible photo printer (not

supplied).

Delete Deletes the JPEG file from the Memory Stick.You

cannot delete a JPEG file that has been protected

(or if the Memory Stick is locked).

JPEG files that are

protected are indicated

by the Lock icon.

The Print Quantity

feature is also known

as DPOF (Digital Print

Order Format).

Using the Memory Stick Viewer

SXRD

2-584-141-12(1)

Using Zoom and

Pan

To Zoom and Pan a photo

1In the Photo menu bar, press B or b to highlight View.

2Press V or v to highlight Zoom/Pan and press .

3Specify the zoom center point by using V v B b; then press to set

the center.

The Zoom and Pan controls are displayed.

Using Rotate To Rotate a photo

1In the Photo menu bar, press B or b to highlight View.

2Press V or v to highlight Rotate.

3To rotate clockwise, press V or v to highlight Clockwise and press .

To rotate counterclockwise, press V or v to highlight Counterclockwise

and press .

The photo is rotated 90 degrees each time you press .

To Do This ... Do This ...

Zoom in (increase magnification)

or out (decrease magnification)

Press B or b to highlight Zoom and press . Then press V to zoom in or v to

zoom out.

To stop using Zoom, press .

Pan (left, right, up, down) (You can use Pan only when the photo is magnified using Zoom.)

Press B or b to highlight Pan and press . Then press B b V v to pan

around the photo.

To stop using Pan, press .

Exit the Zoom/Pan controls Press B or b to highlight Exit and press .

Exit Memory Stick Viewer Press on the remote control.

You cannot rotate a

photo that has been

protected. see “Protect”

on page 90.

Using the Memory Stick Viewer

SXRD

2-584-141-12(1)

Playing Movies

When you select a movie from the Memory Stick Index (described on

page 87), it displays as shown below, with the following controls.

Movie Controls

Information about

selected movie

Selected movie

Enlarge button

Movie menu bar

Previous/next buttons

Play/pause button

✍MPEG movies recorded in VX Fine mode with Sony digital cameras cannot be

played back with the Memory Stick Viewer.

To Do This ... Do This ...

Enlarge the movie window Press V or v to highlight Enlarge, and then

press . To display the movie controls again,

press .

Play the movie with the

movie controls displayed

Press V or v to highlight B (play) and then

press .

Pause the movie While the movie is playing, the B button changes to

the X (pause) button.

Press V or v to highlight X (Pause) and then

press .

Display the previous or next

file on the Memory Stick

Press V or v to highlight the (Previous/Next)

button. Then press B to go to the previous file, or b to

go to the next file.

Hide the Movie menu bar,

displaying only the movie

With the highlight in the Movie menu bar, press v.

Display the hidden Movie

menu bar

Press V.

Access additional options in

the Movie menu bar

See “Movie Menu Bar Options” on page 93.

Exit Memory Stick Viewer Press on the remote control.

The quality of the movie

when enlarged

depends on the

resolution of the

MPEG1 file. See your

camera’s instruction

manual for details.

Using the Memory Stick Viewer

SXRD

2-584-141-12(1)

Movie Menu Bar

Options

To access the Movie menu bar

1Use V or v to highlight Index in the Movie menu bar.

2Press B or b to select Index, Slide Show, or File.

3Press V or v to select the desired option.

Option Description

Index Displays the Memory Stick Index, with the highlight on the thumbnail

of the currently displayed movie.

Slide

Show

Displays the Slide Show menu. For details, see “Slide Show Menu

Options” on page 94.

File Protect

Allows you to protect the MPEG1 file from any

changes. When an MPEG1 file is protected, it

cannot be deleted. Select On or Off.

Delete Deletes the MPEG1 file from the Memory

Stick.You cannot delete an MPEG1 file that has

been protected (or if the Memory Stick is locked).

MPEG1 files that are

protected are indicated

by the Lock icon.

Using the Memory Stick Viewer

SXRD

2-584-141-12(1)

Memory Stick Index Menu Bar Options

Slide Show Menu

Options

The Slide Show menu includes the following options:

Option Description

Start Starts the Slide Show.

Music Allows you to select background audio to play during the Slide

Show.

Off No additional background audio is played during

the Slide Show. Audio that is associated with the

JPEG or MPEG1 files will play.

Play Memory

Stick

Plays all MP3 files on the Memory Stick. The

Piano MP3 file is not played.

Piano

(Built-in

music)

Plays the MP3 file stored in the SXRD projection

TV’s internal memory.

(List of MP3

Files)

Displays a list of all MP3 files found at the top level

(root) of the Memory Stick. To show additional

MP3 files stored in other folders on the Memory

Stick, select Complete List.

Complete

List

Displays a list of all available MP3 files. The list is

sorted in alphabetical order, grouped by folder.

Transition

Effect

Allows you to select an effect to be used when advancing to the next

file in the Slide Show.

Slide

Advance

Allows you to specify when to advance to the next slide.

Fast Slide advances after about 3 seconds.

Medium Slide advances after about 6 seconds.

Slow Slide advances after about 12 seconds.

Manual

advance

Slide advances only after you press B or b.

File

Information

Determines whether file information is displayed. Select On or Off.

Repeat On Slide Show continuously loops.

Off Slide Show plays once through all files and ends.

The Slide Show menu

is the same whether

you select it from the

Memory Stick Index

(page 87), Photo

(page 89), or Movie

(page 92) menus.

When you select

Complete List, it may

take a moment to

display the list of all

MP3 files.

Some JPEG files may

take longer to display

than others, which may

make it seem longer

than the interval you

selected for Slide

Advance.

Using the Memory Stick Viewer

SXRD

2-584-141-12(1)

Folder Menu

Options

The Folder menu includes the following options:

Memory Stick Menu The Memory Stick menu displays the current status of the Memory Stick,

including total capacity, used capacity, and free capacity.

Option Description

Select

Folder

Allows you to select different folders to view in the Memory Stick

Viewer.

Digital Camera

Folders

Selects all folders within the directories

defined by the DCF rules used by Sony digital

cameras (see page 96). JPEG and MPEG1

files in those directories are recognized even if

they do not conform to the DCF file naming

rules.

Select a Folder Allows you to access individual folders on the

Memory Stick.

File Order Allows you to change the order in which the Memory Stick files are

displayed.

Date Order Displays files in chronological order by

modification date.

Date Order

Reverse

Displays files in reverse chronological order

by modification date.

Alphabetical Displays files in alphabetical order by

filename.

Filter Allows you to selectively display specific file types within the

selected folder.

Show Photos and

Movies

Displays all readable files.

Show Photos

Only

Displays only photo (JPEG) files.

Show Movies

Only

Displays only movie (MPEG1) files.

Show All Print

Marks

Displays all files marked with the Print Mark

feature, regardless of the currently selected

folder. For details, see “Print Quantity” on

page 90.

The Rotate and Protect

functions do not

change the file’s

modification date.

Using the Memory Stick Viewer

SXRD

2-584-141-12(1)

Notes on Using Memory Stick Media

About DCF File

Names

Most Sony brand digital still and video cameras automatically record still

photo and movie files using DCF compliant directory and file names.

If you selected the Digital Camera Folders option, as described on page 95,

you might want to have your digital camera’s instruction manual handy in

order to check how files and directories are organized for your specific

model of digital camera.

DCF stands for “Design Rules for Camera File Systems,” which are

specifications established by the Japan Electronics and Information

Technology Industries Association (JEITA: formerly JEIDA).

Using the Memory Stick Viewer

SXRD

2-584-141-12(1)

Memory Stick

Precautions

When using Memory Stick media, follow these precautions:

❑To avoid permanent damage to still image data, do not turn off the

SXRD projection TV or remove Memory Stick media from the insertion

slot while data is being read (as indicated by the Memory Stick indicator

light being on).

❑Avoid touching the terminal of Memory Stick media or bringing it into

contact with a metal object.

❑Do not drop, bend, or submit Memory Stick media to external shock.

❑Do not disassemble or modify Memory Stick media.

❑Avoid getting liquid on Memory Stick media.

❑Apply labels only within the designated label area.

❑To avoid permanent damage to still image data, do not use or store

Memory Stick media in a location subject to:

●High temperature (such as near a heater or inside a hot car)

●High humidity

●Direct sunlight

●Corrosive substances

●Magnetic fields

●Excessive dust

●Static electricity or electric noise

●Electric surges

❑Store and carry Memory Stick media in its original case to ensure

protection of stored data.

❑Save a backup of stored data.

❑When using the Memory Stick Duo, insert it without using the Memory

Stick Duo adaptor. For details, see page 85.

Label Area

Using i.LINK

SXRD

2-584-141-12(1)

Using i.LINK

About i.LINK

This SXRD projection TV is equipped with i.LINK, which provides a secure

digital interface to other digital home entertainment devices, such as digital

VCRs, digital camcorders, set-top boxes, and other devices that also are

equipped with i.LINK. i.LINK allows for the secure transfer of copyright-

protected digital content between these devices and your digital television.

i.LINK is a trademark of Sony Corporation and used only to designate that a

product contains an IEEE 1394 connector.

All products with an i.LINK connector may not communicate with each

other.

Using i.LINK Cables This SXRD projection TV has three S400 i.LINK terminals (one in the front

panel, and two in the back panel). You can use the following i.LINK cables

with this SXRD projection TV:

✍Do not use cables other than the ones listed above.

Sony Model Length

VMC-IL4415 1.5 meters

VMC-IL4435 3.5 meters

4-pin i.LINK cable

Using i.LINK

100

SXRD

2-584-141-12(1)

Connecting i.LINK

Devices

To connect a digital i.LINK device (using only a digital signal)

1Using an i.LINK cable (see page 99), connect the device’s i.LINK jack

to either of the SXRD projection TV’s i.LINK jacks.

To connect an i.LINK device that supports an EIA-775A connection

1Using an i.LINK cable (see page 99), connect the device’s i.LINK jack

to either of the SXRD projection TV’s i.LINK jacks.

2Using an A/V cable, connect the i.LINK device's A/V output jacks to

the SXRD projection TV's VIDEO 3 A/V input jacks.

✍Before connecting this unit to i.LINK-compatible equipment, read the

instruction manual of the i.LINK device to be connected.

✍Only one i.LINK cable should connect the SXRD projection TV and any

given i.LINK device.

Rear of the SXRD projection TV

A/V cable

i.LINK cable

i.LINK-equipped device

VIDEO

AUDIO-R

AUDIO-L

Cables are often color-

coded to connectors.

Connect red to red,

white to white.

Using i.LINK

101

Using i.LINK

SXRD

2-584-141-12(1)

Notes on Using This Connection

Notes on Connecting i.LINK Devices

To connect two or more i.LINK devices, use i.LINK cables to connect them

as shown below.

You can connect up to 63 i.LINK devices. However, the maximum number

of cables in any serial route is 16.

Do not connect i.LINK devices in a way that creates a loop.

Connecting non-compatible devices, such as PCs or PC peripherals, may

result in malfunctions.

To Do This ... Do This ...

Set up a digital i.LINK

device

For digital i.LINK devices (devices that require only the

i.LINK connection), no setup is necessary. The SXRD

projection TV automatically recognizes the device as soon

as the connection is made.

Set up an i.LINK

device that supports an

EIA-775A analog

connection

1Connect analog A/V cables to the VIDEO 3 input (see

page 100).

2Use the i.LINK Control Panel to activate the analog

connection to your i.LINK device (see page 105).

A B C D E

i.LINK i.LINK i.LINK i.LINK

A B C D

F G

i.LINK i.LINK i.LINK i.LINK

i.LINK i.LINK

A B C

i.LINK i.LINK

i.LINK

Using i.LINK

102

SXRD

2-584-141-12(1)

Selecting an i.LINK Device

Before an i.LINK device can be viewed, it must first be selected via the

i.LINK Device List.

1Connect the i.LINK device that you wish to operate.

2Press i.LINK on the remote control.

The SXRD projection TV (DTV), along with all devices connected by

i.LINK to the SXRD projection TV, appear on the i.LINK Device List.

Devices that are not supported by the SXRD projection TV appear on

the Device List as “Other Device,” but cannot be controlled using the

SXRD projection TV's remote control or on-screen i.LINK Control

Panel. For these devices, use the remote control supplied with the

device.

3Press V or v to navigate among the i.LINK-connected devices.

4Press to select the desired device and display the device's i.LINK

Control Panel. Use the i.LINK Control Panel to operate the selected

device. For details, see page 103.

✍For instructions on connecting i.LINK devices, see page 100.

✍i.LINK devices can be connected to one another and to the SXRD

projection TV while the SXRD projection TV is powered on. The Device

List will automatically update to include the newly-connected device. See

page 100 for more information on connecting i.LINK devices.

Digital VCR

Status:

Viewing.

i.LINK Device List

Sony DTV

DTV

Using i.LINK

103

Using i.LINK

SXRD

2-584-141-12(1)

Using the i.LINK Control Panel

After you select an i.LINK device using the Device List, the SXRD

projection TV displays the i.LINK Control Panel, which allows you to use

the SXRD projection TV's remote to control the selected i.LINK device.

1If the i.LINK Control Panel is not already displayed, press i.LINK on the

remote control.

2Press V v B b on the remote control to navigate through the options

available in the i.LINK Control Panel.

3Press to select a desired option.

4Press EXIT to exit the Control Panel and view the i.LINK device full-

screen.

The i.LINK Control Panel displays the signal from the SXRD projection TV

to the left on screen (if available), and the signal from the currently selected

device to the right on screen.

✍If i.LINK is pressed while the SXRD projection TV is displaying an analog

or digital channel (not the i.LINK device), then the Device List will

appear. Select the desired device from the list and press to display

the Control Panel.

✍To exit i.LINK mode, select DTV from the Device List or press CH+/–.

Setup

Exit i.LINK

i.LINK

Control Panel

Power

Swap Audio

Full Screen

Status: Playing. 00:00:31

Back to Device List

VICTOR HM-DH35000

52.3

The DTV window appears only if the

i.LINK menus were entered while

watching a digital TV channel

(Continued)

Using i.LINK

104

SXRD

2-584-141-12(1)

To Do This ... Do This ...

Go to the Device List Press V v B b to highlight Back to Device List and press .

Change the audio being played from the

SXRD projection TV to the current

selected device, and vice versa

Press V v B b to highlight Swap Audio and press . An icon appears next

to the window that currently has sound.

Play a recording from the selected

i.LINK camcorder or digital VCR

Press V v B b to highlight and press .

Fast-forward or rewind a recording from

the selected i.LINK camcorder or digital

VCR

Press V v B b to highlight or and press .

Record from SXRD projection TV to

the selected i.LINK digital VCR

If the (record) button is available, press V v B b to highlight

and press .

Stop a recording from the selected

i.LINK digital VCR

Press V v B b to highlight and press .

Turn the selected device power on and

off

Press V v B b to highlight Power and press .

Setup the selected device Press V v B b to highlight Setup and press . For more details on Setup,

see page 105.

Notes About Controlling i.LINK Devices

❑You can control the functions of the selected i.LINK device by using the equivalent buttons on the

SXRD projection TV's remote control. To program the remote control to operate i.LINK devices, see

“Programming the Remote Control” on page 64.

❑Some options on the i.LINK Control Panel may not be available, depending on the device being

controlled.

❑Only i.LINK-equipped digital camcorders and digital VCRs can be controlled directly through the

i.LINK Control Panel.

❑Not all functions are supported for all i.LINK devices.

❑If you are using a digital VCR, turn off any Auto LINC functionality of the VCR. For details, see the

digital VCR’s user manual.

Using i.LINK

105

Using i.LINK

SXRD

2-584-141-12(1)

i.LINK Setup

You can use the i.LINK Control Panel to access digital setup options, some

of which are also available through the Digital Program Guide (described on

page 71).

To set up the selected device:

Press V v B b to highlight Setup and press .

The following options are displayed:

Option Description

Alternate Video

(when available)

Each program has a main video stream (the video that you see

when the channel is first tuned), and may have alternate video

streams. This option allows you to switch among these alternate

video streams.

Alternate Audio

(when available)

Each program has a main audio stream (the audio that you hear

when the channel is first tuned), and may have alternate audio

streams. This option allows you to switch among these alternate

audio streams (e.g., for different languages).

Analog Video The TV is able to accept an analog signal from a selected set-top

box. The set-top box must be EIA-775A compliant and must be

connected to the TV’s VIDEO 3 input. To associate the device

with the TV's analog VIDEO 3 input, press V or v to select

Analog Video and press . All EIA-775A-compliant devices

will be shown in the list. Select the desired device from the list

and press .

Alternate Video

Alternate Audio

Analog Video

i.LINK Control Panel

Power

Swap Audio

Full Screen

Sony DV-VCR

888.888

Setup

Back to Device List

Notes on i.LINK

❑The SXRD projection TV can act as an i.LINK repeater, so that i.LINK signals are be relayed to

another device even when the TV is powered off. To enable this feature, set the i.LINK Standby option

to On using the Setup Menu as described on page 123.

❑Parental Control settings apply to the signal from a selected device. For more details, see page 118.

107

Using the Menus

SXRD

2-584-141-12(1)

Using the Menus

Overview

Opening and choosing a menu

1Press MENU to display the menu screen.

2Press V or v to highlight the desired menu icon and press to select it.

3Use the arrow button to scroll through the features.

4See the specific menu page for instructions on moving through the

menu.

To end a menu session

❑Press MENU again.

To end one menu session and move to another

❑Press B to return to the menu icons.

Press the arrow buttons to choose the next menu icon and press to

select it.

The Menu gives you access to the following features:

Menu Icon Description Page

The Video Menu allows you to make adjustments to your

picture settings. It also allows you to customize the Picture

Mode based on the type of program you are viewing, select

Advanced Video options, and more.

108

The Audio Menu offers enhanced audio options such as

listening to second audio programming (SAP) or

customizing the Effect of the sound on your TV.

112

The Screen Menu allows you to make Wide Mode

adjustments and make changes to the screen’s vertical

center and size. The newly added Overscan feature lets you

fix the overscan problem.

114

The Channel Menu allows you to set up a Favorite

Channels list, run the Auto Program function, label

channels, and more.

116

The Parent Menu lets you control the viewing of programs

based on their ratings.

118

The Setup Menu provides options for setting up your

system, including selecting closed caption modes, labeling

video inputs, selecting the language of the on-screen

menus, and more.

122

The Applications Menu lets you display the Memory Stick

Viewer and the i.LINK Control Panel, set on/off Timers,

access CableCARD and diagnostics information, and more.

125

Press MENU to enter

and exit Menus.

Using the Menus

108

SXRD

2-584-141-12(1)

Using the Video Menu

To select the Video menu

1Press MENU.

2Press V or v to highlight the

Video icon and press

3Use the arrow buttons to scroll

through the features.

4Press to select a feature.

5Use the arrow buttons to make the desired adjustments.

6Press to select/set.

7Press MENU to exit the menu screen.

To restore the factory default settings for the Video settings:

❑Press RESET on the remote control when in the Video menu.

Selecting Video

Options

The Video menu includes the following options.

Antenna

Video

Picture Mode Pro

Picture Max

Brightness 31

Color 31

Hue 0

Sharpness 31

Color Temp. Cool

Noise Reduction

Off

Direct Mode

Off

Option Description

Picture Mode

Customized


viewing

Vivid Select for enhanced picture contrast and sharpness.

Standard Select for standard picture settings. Recommended for

home entertainment.

Pro Select to display a picture with minimum

enhancements.

✍You can alter the Video menu settings (Picture, Brightness,

Color, etc.) for each Mode and each video input.

✍You can set up a Picture Mode (Vivid, Standard or Pro)

independently for each Video input (Video 1- Video 7,

including the Antenna input). Your Picture Mode settings

are automatically saved after each selection. This allows

you to customize the Mode setting for each type of signal

source.

Picture Adjust to increase picture contrast and deepen the color or decrease

picture contrast and soften the color.

Brightness Adjust to brighten or darken the picture.

Color Adjust to increase or decrease color intensity.

Hue Adjust to increase or decrease the green tones.

Sharpness Adjust to sharpen or soften the picture.

To quickly and easily

change from one

Picture Mode to

another, use PICTURE

on the remote control.

Using the Menus

109

Using the Menus

SXRD

2-584-141-12(1)

Color Temp.

White

intensity

adjustment

Choose from three color temperatures:

Cool Select to give the white colors a blue tint.

Neutral Select to give the white colors a neutral tint.

Warm Select to give the white colors a red tint.

Noise

Reduction

Select to reduce the noise level of connected equipment. This also

reduces the noise level to and signal from the VHF/UHF jack. Select

from High, Medium, Low and Off.

Direct Mode On Select for a natural, soft picture.

Off Select to turn off the Direct Mode.

Game Mode On Select to optimize the lipsync when playing games.

Off Select to turn off the Game Mode.

Option Description

Direct Mode is not

available when watching

480p or 720p sources.

(Continued)

Using the Menus

110

SXRD

2-584-141-12(1)

Advanced

Video

Select Program to choose among the options described below.

DRC Mode Creates a high-resolution picture with 4 x density, for

high quality sources (i.e., DVD player, satellite

receiver).

Mode 1 Recommended for moving pictures.

Mode 2 Recommended for still images and

text.

CineMotion Provides an optimized display by

automatically detecting film content

and applying a reverse 3-2 pulldown

process. Moving pictures will appear

clearer and more natural-looking.

✍DRC Mode is not available when watching 480p, 720p and

1080i sources, when using multi-picture functions (Twin

View, Freeze or Memory Stick), or when Direct Mode is set

to On or Game Mode is set to On.

DRC

Palette

Allows you to customize the level of detail (Reality)

and smoothness (Clarity) for up to three input sources.

For example, you can create one Custom setting to

optimize your cable input's picture, and create another

to optimize your DVD player's picture. You can switch

among the three Custom settings.

1Press the arrow buttons to highlight Custom 1,

Custom 2, or Custom 3 and then press .

The DRC palette appears.

2Press the arrow buttons to adjust the position of

the marker (z). As you move the z higher along

the Reality axis, the picture becomes more

detailed. As you move the z to the right along the

Clarity axis, the picture becomes smoother.

3To save the setting, press .

To return the Custom options to the default factory

settings, press the RESET button.

✍DRC Palette is not available when watching 480p, 720p

and 1080i sources, when using multi-picture functions

(Twin View, Freeze or Memory Stick), or when Direct Mode

is set to On or Game Mode is set to On.

Option Description

Custom 1

Press

Reality

(25)

Clarity

(1)

to exit

Using the Menus

111

Using the Menus

SXRD

2-584-141-12(1)

Smoother

Select to reduce noise caused by digital video

encoding and decoding process. It is especially

effective for watching a DVD or digital TV picture.

Select from High, Medium, Low and Off.

✍BN Smoother may not be able to correct image quality

from some connected equipment.

✍BN Smoother is not available when watching 480p, 720p,

and 1080i sources, or when using multi-picture functions

(Twin View, Freeze or Memory Stick).

Cinema

Black Pro

Emphasizes the black color.

On Select to enhance the black by

emphasizing the contrast.

Off Normal contrast.

Color

Space

Use to select the range of color reproduction from

Normal or Wide.

Color

Corrector

Select to make the colors more vivid. Select from

High, Low, and Off.

DTE Select to enhance the texture of the picture. Select

from High, Medium, Low, and Off.

Clear White Select to emphasize the white colors. Select from On

or Off.

Detail

Enhancer

Select to sharpen picture definition. Select from High,

Medium, Low, and Off.

Black

Corrector

Select to enhance the black colors to give the picture

strong contrast. Select from High, Medium, Low, and

Off.

Gamma

Corrector

Select to adjust the balance between bright and dark

areas of the picture. Select from High, Medium, Low,

and Off.

White

Balance

Select to fine-adjust the white color intensity by

changing the red, green and blue levels. Select Adjust

to choose among the R-Gain, G-Gain, B-Gain, R-

Bias, G-Bias, and B-Bias options. To restore the

factory default setting of White Balance, select Initial

set.

Option Description

BN Smoother may not

be effective for some

connected equipment.

Using the Menus

112

SXRD

2-584-141-12(1)

Using the Audio Menu

To select the Audio menu

1Press MENU.

2Press V or v to highlight the

Audio icon and press

3Use the arrow buttons to scroll

through the options.

4Press to select an option.

5Use the arrow buttons to scroll through the settings.

6Press to select the desired setting.

7Press MENU to exit the menu screen.

To restore the factory default settings for Treble, Bass and Balance

❑Press RESET on the remote control when in the Audio menu.

Selecting Audio

Options

The Audio menu includes the following options:

Antenna

Audio

Sound Mode Dynamic

Treble 31

Bass 31

Woofer Level Max

Balance 0

Steady Sound Off

Effect Off

MTS Mono

Audio Out Variable

Option Description

Sound

Mode

Customized

audio

settings

Dynamic Select to enhance treble and bass.

Clear Voice Suitable for spoken dialogue.

Custom Flat setting. Also allows you to customize the

settings.

✍Treble and Bass are not available when Dynamic or Clear

Voice is selected in Sound Mode.

Treble Adjust to increase or decrease higher-pitched sounds.

Bass Adjust to increase or decrease lower-pitched sounds

Woofer

Level

Adjust to decrease or increase woofer sound level.

Balance Adjust to emphasize left or right speaker volume.

Steady

Sound

Auto Select to stabilize the volume across all programs

and commercials.

Off Select to turn off Steady Sound.

✍Steady Sound is not available when Effect is set to Dolby

Virtual, TruSurround or Simulated.

Effect Dolby Virtual Select for surround sound (for Dolby surround

encoded programs only).

Dolby Virtual and

TruSurround attempt to

create the same

surround effect

produced by a

multichannel system

using the left and right

speakers.

Using the Menus

113

Using the Menus

SXRD

2-584-141-12(1)

TruSurround Select for surround sound (for stereo programs

only).

Simulated Adds a surround-like effect to mono programs.

Off Normal stereo or mono reception.

MTS

Enjoy stereo,

bilingual and

mono

programs

Stereo Select for stereo reception when viewing a program

broadcast in stereo.

Auto SAP Select to automatically switch to second audio

programs when a signal is received. (If no SAP

signal is present, the SXRD projection TV remains

in Stereo mode.)

Mono Select for mono reception. (Use to reduce noise

during weak stereo broadcasts.)

✍MTS is available only for analog programs.

Audio Out This option can be set only when the Speaker option is set to Off.

Easy control

of volume

adjustments

Var iable The SXRD projection TV’s speakers are turned off,

but the audio output from your audio system can

still be controlled by the SXRD projection TV’s

remote control.

Fixed The SXRD projection TV’s speakers are turned off

and the audio output of the SXRD projection TV is

fixed. Use your audio receiver’s volume control to

adjust the volume (and other settings) through your

audio system.

Speaker On Select to turn on the SXRD projection TV

speakers.

Off Select to turn off the SXRD projection TV speakers

and listen to the TV’s sound only through your

external audio system speakers.

✍When the speakers are not connected, Speaker is

automatically set to Off.

Option Description

Using the Menus

114

SXRD

2-584-141-12(1)

Using the Screen Menu

To select the Screen menu

1Press MENU.

2Press V or v to highlight the

Screen icon and press

3Use the arrow buttons to scroll

through the features.

4Press to select a feature.

5Use the arrow buttons to scroll through the options.

6Press to select the desired option.

7Press MENU to exit the menu screen.

Selecting Screen

Options

The Screen menu includes the following options:

Antenna

Screen

Wide Mode Full

Game Picture

4:3 Default Off

Overscan Normal

Vertical Center

Vertical Size

Option Description

Wide Mode

Select a screen

mode to use for

4:3 sources.

Wide Zoom Select to enlarge the 4:3 picture, to fill the 16:9

screen, keeping the original image as much as

possible.

Normal Select to return the 4:3 picture to its original

size and aspect ratio.

✍Normal is not available when watching 720p or 1080i

sources.

Full Select to enlarge the 4:3 picture horizontally

only, to fill the wide screen.

Zoom Select to enlarge the 4:3 picture horizontally

and vertically to an equal aspect ratio that fills

the wide screen.

✍To change from one Wide Mode setting to another, use WIDE on the

remote control (see page 72).

Game Picture Adjust Allows you to move the position of the picture

left and right in the window. (This feature also

allows you to adjust the picture from any

connected equipment.) Select while watching

the picture to be adjusted. The SXRD

projection TV stores the position in memory

for each input.

Press B or b to and press to choose a

correction between +10 and –10.

Wide Mode is

unavailable while using

Twin View (page 74),

Freeze (page 79) or

Memory Stick

(page 81).

Using the Menus

115

Using the Menus

SXRD

2-584-141-12(1)

4:3 Default

Select the default

screen mode to

use for 4:3

sources.

Wide Zoom Select to enlarge the 4:3 picture, to fill the 16:9

screen, keeping the original image as much as

possible.

Normal Select to return the 4:3 picture to normal

mode.

Full Select to enlarge the 4:3 picture horizontally

only, to fill the wide screen.

Zoom Select to enlarge the 4:3 picture horizontally

and vertically to an equal aspect ratio that fills

the wide screen.

Off Select to continue using the current screen

mode setting when the channel or input is

changed.

Overscan Normal Select to display the picture within the normal

viewing area of the screen.

+1 or +2 Select to reduce the size of the picture to show

the overscan (i.e. the portion of the picture

outside of the normal viewing area).

Vertical Center Adjust Allows you to move the position of the picture

up and down in the window. (Available only in

Wide Zoom and Zoom modes.)

Press V or v and press to choose a

correction between +10 and –10.

Vertical Size Adjust Allows you to adjust the vertical size of the

picture. (Available only in Wide Zoom and

Zoom modes.)

Press V or v and press to choose a

correction between +10 and –10.

Option Description

If 4:3 Default is set to

anything but Off, the

Wide Mode setting

changes only for the

current channel. When

you change channels

(or inputs), Wide Mode

is automatically

replaced with the 4:3

Default setting. To

retain the current Wide

Mode setting as

channels and inputs

are changed, set 4:3

Default to Off.

Using the Menus

116

SXRD

2-584-141-12(1)

Using the Channel Menu

To select the Channel menu

1Press MENU.

2Press V or v to highlight the

Channel icon and press

3Use the arrow buttons to scroll

through the features.

4Press to select a feature.

5Use the arrow buttons to scroll through the options.

6Press to select the desired option.

7Press MENU to exit the menu screen.

Selecting Channel

Options

The Channel menu includes the following options:

Antenna

Channel

Channel Fix Off

Digital Channels

Auto Program

Show/Hide Channels

Label Channels

Favorite Channels

Option Description

Favorite

Channels

Lets you set up a list of your favorite channels. For details, see

“Using Favorite Channels” on page 77.

Channel Fix

Useful when you

have a cable box

or satellite

receiver connected

Off Turns off Channel Fix.

2-6 “Fix” your SXRD projection TV’s channel

setting to one channel (2-6) and use the cable

box, VCR or satellite receiver to change

channels. Select one of these settings if you

have connected the device to the VHF/UHF

jack.

C2–C6 “Fix” your TV’s channel setting to C2–C6

(CABLE input) and use the cable box or

satellite receiver to change channels.

Video 1, 4 Use when connecting a cable box. TV output

should be connected through the cable box.

Digital Channels Add Select to add digital channels.

Auto Program Start Automatically sets up the channel list on the TV

for all receivable channels for the current input

(VHF/UHF or CABLE).

✍Auto Program may take more than 50 minutes to

complete. A progress bar will display the approximate

progress of the Auto Program and Digital Channels/

Add sequences.

Using the Menus

117

Using the Menus

SXRD

2-584-141-12(1)

Show/Hide

Channels

Allows you to show or hide channels that appear in the Program

Guide (see page 70) and when you use the CH+/- buttons to

channel surf. Channels that are set to Hidden do not appear in

the Program Guide or when you use the CH+/- buttons.

1Press V or v to highlight the channel that you want to show

or hide.

To move between the Major and Digital subchannel lists,

press B or b.

2To change a channel’s setting to Shown or Hidden, press

3To show or hide more channels, repeat steps 1 and 2.

✍If you select to hide or show a major digital channel, all the sub-channels

are automatically hidden or shown. To show or hide an individual sub-

channel within a digital channel, you must individually select that sub-

channel to show or hide.

✍If you hide all sub-channels of a major digital channel, that major digital

channel is automatically set to Hidden.

Label Channels Allows you to assign labels (such as station call letters) to

channel numbers.

1Press V v to scroll through the channel numbers. Then

press to select the channel number that you want to

assign a label.

2Press V v to scroll through the label characters (A-Z, 0-9,

etc.). Then press to select the highlighted character.

Repeat to add characters to the label.

3Press B to return to the Channel menu, or press MENU to

exit the menus.

Option Description

Channels that you set

to hide can only be

accessed with the 0-9

buttons.

Using the Menus

118

SXRD

2-584-141-12(1)

Using the Parent Menu

The Parent menu allows you to set up the SXRD projection TV to block

programs according to their content and rating levels.

To select the Parent menu

1Press MENU.

2Press V or v to highlight the

Parent icon and press

3Use the 0-9 buttons on the

remote control to enter a four-

digit password.

4If this is the first time you are creating this password, confirm the

password by entering it again. (The Parent menu options appear.)

5Press V v B b to change settings. Press to select the changed

setting.

6Press MENU to exit the menu screen.

Selecting Parent

Options

The Parent menu includes the following options:

✍You need your password for any future access into the Parent menu. If

you lose your password, see “Lost password” on page 135.

Antenna

Parental Lock

Password

Option Description

Parental Lock

Turn ratings on/off and

select a rating system

Off Turn Parental Lock off. No programs are

blocked from viewing.

Child Maximum ratings permitted are:

US: TV-Y, TV-G, G

Canada: C, G, TV-Y

Yo u t h Maximum ratings permitted are:

US: TV-PG, PG

Canada: C8+, PG, 8 ans+, TV-PG

Y. Adult Maximum ratings permitted are:

US: TV-14, PG-13

Canada: 14+, 13 ans+, TV-14

Custom Select to set ratings manually.

US: See page 120 for details.

Canada: See page 121 for details.

Using the Menus

119

Using the Menus

SXRD

2-584-141-12(1)

To deactivate the parental control feature

❑Set Parental Lock to OFF when in the Parent menu.

To change the password

1In the Parent menu, use the arrow buttons to highlight Change

Password, and press to select it.

2Enter a new four-digit password using the 0-9 buttons.

3Confirm the new password by entering it again.

4Press MENU to exit the menu screen.

Viewing Blocked

Programs

You can view a blocked program by entering the password.

1Press ENTER when tuned to a blocked program.

2Enter your password using the 0-9 buttons.

Parental control will be canceled temporarily until you turn your SXRD

projection TV off.

Change Password Select to change your password.

Select Country U.S.A. Select to use USA ratings (see page 120).

Canada Select to use Canadian ratings (see page 121).

Option Description

If you are not familiar

with the Parental

Guideline rating

system, you should

select Child, Yo u t h , or

Y. A d u l t to help simplify

the rating selection. To

set more restrictive

ratings, select Custom.

For descriptions of

Child, Yo u t h , and

Y. A d u l t ratings, see

page 118.

Using the Menus

120

SXRD

2-584-141-12(1)

Selecting Custom

Rating Options

US custom rating options

If you selected U.S.A. as the country of residence on page 119, the Custom

Rating menu includes the following options. (If you selected Canada, see

page 121.)

Option Description

Movie Rating G All children and general audiences.

PG Parental guidance suggested.

PG-13 Parental guidance for children under 13.

RRestricted viewing, parental guidance is suggested

for children under 17.

NC-17

and X

No one 17 and under.

TV Rating

Block programs

by their rating,

content or both

Age-Based Options

TV-Y All children.

TV-Y7 Directed to children age 7 and older.

TV-G General audience.

TV-PG Parental guidance suggested.

TV-14 Parents strongly cautioned.

TV-MA Mature audience only.

Content-Based Options

FV Fantasy violence.

DSuggestive dialog.

LStrong language.

SSexual situations.

VViolence.

Unrated

Block programs

or movies that are

broadcast without

a rating

Allow Allows programs and movies that are broadcast

without a rating.

Block Blocks all programs and movies that are broadcast

without a rating.

✍The content ratings will increase depending on the level of the age-based rating.

For example, a program with a TV-PG V (Violence) rating may contain

moderate violence, while a TV-14 V (Violence) rating may contain more intense

violence.

To ensure maximum

blocking capability, the

age-based ratings

should be blocked.

If you select Block, be

aware that the

following programs

may be blocked: news,

sports, weather,

emergency broadcasts,

political programs,

public service

announcements, and

religious programs.

Using the Menus

121

Using the Menus

SXRD

2-584-141-12(1)

Canadian custom rating options

If you selected Canada as the country of residence on page 119, the Custom

Rating menu includes the following options. (If you selected U.S.A., see

page 120.)

Option Description

English Rating C All children.

C8+ Children 8 years and older.

GGeneral programming.

PG Parental guidance.

14+ Viewers 14 and older.

18+ Adult programming.

French Rating G General programming.

8 ans+ Not recommended for ages under 8.

13 ans+ Not recommended for ages under 13.

16 ans+ Not recommended for ages under 16.

18 ans+ Programming restricted to adults.

U.S.A. Rating See “TV Rating” on page 120 for details.

Using the Menus

122

SXRD

2-584-141-12(1)

Using the Setup Menu

To select the Setup menu

1Press MENU.

2Press V or v to highlight the

Setup icon and press .

3Use the arrow buttons to scroll

through the features.

4Press to select a feature.

5Use the arrow buttons to scroll

through the options.

6Press to select the desired option.

7Press MENU to exit the menu screen.

Selecting Setup

Options

The Setup menu includes the following options:

Antenna

Setup

Caption Vision Off

Info Banner On

Label Video Inputs

Language English

i.LINK Standby Off

Menu Color Gray

High Altitude Off

Illuminated Yes

Power Saving Standard

Option Description

Caption Vision Allows you to select from four closed caption modes (for

programs that are broadcast with closed captioning).

Program Allows you to set basic and advanced Caption

Vision options. See “Programming Caption

Vision” on page 124.

On Caption Vision is turned on.

Off Caption Vision is turned off.

Info Banner Set to On or Off. When on, displays the program name, time

remaining and other information (if the broadcaster offers this

service). Displays when the channel is changed or the

DISPLAY button is pressed.

Using the Menus

123

Using the Menus

SXRD

2-584-141-12(1)

Label Video

Inputs

Allows you to label the audio/video equipment you have

connected to the SXRD projection TV so you can identify them

when using TV/VIDEO. When in this menu:

1Press V or v to highlight an input to label, then press

to select it.

2Use the arrow buttons to scroll through the labels.

3Press to select the equipment you connected to

each of the input jacks on the back of your SXRD

projection TV.

Select Skip if you do not have any equipment

connected to a particular input.

Video 1-3 VHS, DVD, Receiver, Satellite, Cable Box,

8mm, DTV, Game, LD, Beta, Skip

Video 4-7 DVD, Satellite, Cable Box, DTV, HD, Game,

PVR, Skip

✍If you select Skip, your SXRD projection TV skips the

selected connection when you press TV/VIDEO.

Language Select to display all on-screen menus in your language of

choice: English, Español, Français.

i.LINK Standby On Allows the i.LINK signal to pass through to

connected i.LINK devices even when the TV

is turned off. The front panel i.LINK Standby

LED shows red. The TV uses more standby

power than when this option is set to Off.

Off Does not allow the i.LINK signal to pass

through to connected i.LINK devices when the

TV is turned off. The TV uses less standby

power than when this option is set to On.

Menu Color Enables you to select a specific color for the on-screen menus

from Gray, Red, Green, Indigo, and Purple.

High Altitude On Select to use the SXRD projection TV at an

altitude of 5,000 feet (1,500 m) or higher.

Off Select to use the SXRD projection TV at

normal altitude.

Illuminated Allows you to illuminate the Sony logo on the front panel of the

TV.

Ye s Illuminates the Sony logo while the power is

turned on.

No Illuminates the Sony logo when you switch the

power on or off.

Option Description

If a CableCARD is

inserted, the i.LINK

Standby Off setting uses

the same amount of power

as the i.LINK Standby On

setting.

(Continued)

Using the Menus

124

SXRD

2-584-141-12(1)

Programming

Caption Vision

If you selected the Program option under Caption Vision (see page 122), you

can change the following settings:

Power Saving Standard Select to view picture without the benefit of

Power Saving.

Reduced Select to view picture with reduced power

consumption. The picture becomes darker, but

also enhances the black level.

Option Description

Basic Allows you to select basic analog (EIA-608) closed caption options.

CC1, CC2,

CC3, CC4

Displays a printed version of the dialog or sound

effects of a program. (Should be set to CC1 for most

programs.)

Text 1 ,

Text 2 ,

Text 3 , Tex t4

Displays network/station information presented using

either half or the whole screen (if available). For

closed captioning, set to CC1.

Advanced Allows you to select advanced digital (EIA-708) closed caption

options. Select from the available options.

Digital CC Allows you to set digital closed captioning to Basic (digital EIA-608)

or Advanced (digital EIA-708).

Advanced

Settings

Allows you to make additional settings for digital (EIA-708) closed

caption options. Select from As Broadcast, Small Text, Large Text

and Custom.

Custom... Allows you to customize the following settings:

Character Size Small, Standard,

Large

Character Style Style 1-7

Character Color Color 1-8

Edge Color Color 1-8

Edge Type None, Raised,

Outline, Left

Shadow, Right

Shadow

Background Color None, Color 1-8

Window Color None, Color 1-8

✍Color options can also be set to Solid or

Translucent.

Using the Menus

125

Using the Menus

SXRD

2-584-141-12(1)

Using the Applications Menu

To select the Applications menu

1Press MENU.

2Press V or v to highlight the

Applications icon and press .

3Use the arrow buttons to scroll through

the features.

4Press to select a feature.

5Use the arrow buttons to scroll through the options.

6Press to select the desired option.

7Press MENU to exit the menu screen.

Selecting

Applications

Options

Antenna

Applications

Memory Stick

i.LINK

Clock/Timers

Diagnostics

CableCARD

Option Description Displays...

Memory Stick Start Displays the Memory Stick Viewer.

For details, see page 88.

i.LINK Start Displays the i.LINK Device List. For

details, see page 102.

Clock/Timers Select to set the clock and to program your SXRD projection

TV to turn on and off at two scheduled viewing times.

Sleep Allows you to select the amount of

time (15 minutes, 30 minutes, 45

minutes, 60 minutes, 90 minutes or

Off) that you want the SXRD

projection TV to remain on before

shutting off automatically.

Timer 1

Timer 2

You can use the Timers to program the

SXRD projection TV to turn on and

off and tune to a specific channel at

two scheduled viewing times.

You can also use the

MEMORY STICK and

i.LINK buttons on the

remote control or front

panel.

(Continued)

Using the Menus

126

SXRD

2-584-141-12(1)

Timer 1 and Timer 2 cannot be set until you set the Current

Time.

1Press V or v to highlight Timer 1 or Timer 2. To set the

timer, press b.

✍To go directly to programming Timer 1 or 2, press

instead of pressing b.

2Press V or v to highlight one of the following options, then

press .

Program Select to set the Timer by day, time,

duration, and channel.

Off Select to turn off the Timer. (Your

previous settings are saved.)

3If you selected Program in step 2, press V and v to set the

day(s), hour, minute, duration, and channel number. Press

or press b to confirm each setting and move to the

next setting.

Press B to go back to the previous setting.

4Press MENU to exit the menu screen. An LED on the front

panel will light, indicating the Timer has been set.

Current Time You can set the current time.

1Press to select Current Time.

2Press V and v to set the current time (day, hour, minute,

and AM/PM). Press (or press b) to confirm each

setting and move to the next setting. Press B to go back the

previous setting.

3Press MENU to exit the menu screen.

✍When the AC power cord is unplugged, the Clock/Timers settings will be

reset. Set the clock or timer again.

Diagnostics Display diagnostics information about the TV. This can be

useful in providing information to an authorized technician or

repair person.

CableCARD This list of selectable CableCARD options will vary, depending

on your cable service provider.

Option Description Displays...

127

SXRD

2-584-141-12(1)

Other Information

Overview

This chapter includes the following topics:

Topic Page

Glossary 128

Contacting Sony 129

Troubleshooting 129

Flashing Indicators on the Front of the TV 137

Specifications 138

Optional Accessories 140

Index 141

Other Information

128

SXRD

2-584-141-12(1)

Glossary

analog signal A signaling method that uses continuous changes in the amplitude or frequency of an

electronic transmission to convey information.

aspect ratio Refers to the ratio between the width and height of the screen. This SXRD projection

TV has a 16:9 (widescreen) aspect ratio, as opposed to a 4:3 aspect ratio.

CableCARD The PCMIA shaped card provided by your cable TV company which descrambles the

digitally encrypted cable channels. You should check with your local cable TV

company about CableCARD service.

component video Component video is sent through three cables: two color shade (chrominance) signals

and one brightness (luminance) signal. Component video achieves greater color

accuracy than composite video or S VIDEO by splitting chrominance into two

separate portions.

composite video Composite video is sent through a single cable. Composite video combines the color

shade (chrominance) and brightness (luminance) information into one video signal.

digital television (DTV) A new technology for transmitting and receiving broadcast television signals. DTV

provides higher resolution and improved sound quality over analog television.

HDMI (High-Definition

Multimedia Interface)

Provides an uncompressed, all-digital audio/video interface between this TV and any

HDMI-equipped audio/video component, such as a set-top box, DVD player, and

A/V receiver. HDMI supports enhanced, or high-definition video, plus two-channel

digital audio.

National Television

System Committee

(NTSC)

A unit of the Federal Communications Commission, Washington, DC, that

establishes television standards in the United States, such as NTSC Color, the

standard used in this SXRD projection TV.

RF Radio Frequency. That part of the frequency spectrum that is used to transmit TV and

radio signals.

S VIDEO S VIDEO requires a single cable, which carries the brightness (luminance) and color

(chrominance) signals of the picture separately. S VIDEO provides better resolution

than composite video, which carries the signals together.

VHF/UHF VHF (Very High Frequency) is the part of the frequency spectrum from 30 to 300

megahertz. UHF (Ultra High Frequency) is the part of the frequency spectrum from

300 to 3,000 megahertz.

480i Provides 480 lines of resolution. Displays images using interlaced scanning, which

first transmits all the odd lines on the SXRD projection TV screen and then the even

lines.

480p Provides 480 lines of resolution. Displays images using progressive scanning, which

transmits each line from top to bottom.

720p Provides 720 lines of resolution. Displays images using progressive scanning, which

transmits each line from top to bottom.

1080i Provides 1080 lines of resolution. Displays images using interlaced scanning, which

first transmits all the odd lines on the SXRD projection TV screen and then the even

lines. 1080i is one of the formats used by HDTV (High Definition TV).

4:3 aspect ratio 16:9 aspect ratio

Other Information

129

Other Information

SXRD

2-584-141-12(1)

Contacting Sony

If, after reading these operating instructions, you have additional questions

related to the use of your Sony television, please call our QUALIA Call

Center at 1-877-782-5423 (US residents only) or Customer Relations Center

at 1-877-899-SONY (7669) (Canadian residents only).

Before calling Sony customer support, please write down the model and

serial numbers of your TV. You’ll find this information on the front cover of

this manual.

Troubleshooting

Twin View

Problem Possible Remedies

I cannot get Twin View to work ❏If you are using a cable box to unscramble all channels (as shown on page 38),

you cannot use the Twin View feature. This is because the cable box can

unscramble only one channel at a time.

❏You can use Twin View to view a signal from a different source that is connected

to the SXRD projection TV’s A/V jacks (such as a VCR or DVD player) in the

second window by pressing TV/VIDEO while in Twin View.

❏Sources connected to the CABLE, VIDEO 4, VIDEO 5, VIDEO 6 and VIDEO 7

inputs, as well as digital source display only in the left Twin View window.

There is no Twin View window,

or it is just static

❏Be sure the Twin View window is set to a video input or channel that has a signal

airing.

❏You might be tuned to a video input with nothing connected to it. Try cycling

through the video inputs by pressing TV/VIDEO.

Twin View cannot display

anything but TV channels

❏Try cycling through the video inputs by pressing TV/VIDEO. Check that the

Label Video Inputs option is not set to Skip. (See the Setup menu on page 123.)

Twin View displays the same

program in both windows

❏Both Twin View windows might be set to the same channel. Try changing

channels in either window.

Other Information

130

SXRD

2-584-141-12(1)

Remote Control

CableCARD

Problem Possible Remedies

Remote control does not

operate

❏The batteries could be weak. Replace the batteries.

❏Check the orientation of the batteries.

❏Press FUNCTION repeatedly until the TV indicator lights up. You may have

inadvertently pressed FUNCTION, which changes the remote control to SAT or

CABLE mode.

❏Make sure this unit’s power cord is connected securely to the wall outlet.

❏Locate the unit at least 3-4 feet away from fluorescent lights.

❏If the "High Temperature Warning!" message appears, turn off the TV and wait

until the TV's projection lamp cools down (approximately 5 minutes). If the

remote control still does not work, make sure to dust the ventilation slots on the

rear of the TV and the cooling fan to provide adequate ventilation around the TV.

Cannot change channels with

the remote control

❏If you are using the SXRD projection TV to change channels, first press

FUNCTION repeatedly until the TV indicator lights up.

❏If you are using another device to change channels, be sure you have not

inadvertently switched your SXRD projection TV from the channel 3 or 4 setting.

Use the Channel Fix option to “Fix” the channel based on the hookup you used

(see page 116).

❏If you are using another device to change channels, be sure to press FUNCTION

for that device. For example, if you are using your cable box to change channels,

be sure to press FUNCTION repeatedly until the SAT/CABLE indicator lights up.

Remote control does not

operate non-Sony video

equipment

❏If you replaced the batteries to the remote recently, the code numbers for the video

equipment may need to be reset.

❏There may be more than one code for the equipment that you are attempting to

operate.

❏There is a possibility that some non-Sony equipment cannot be operated by your

Sony SXRD projection TV remote. You may need to use the equipment’s original

remote control.

Problem Possible Remedies

Problems using CableCARD or

CableCARD services

❏Check that the CableCARD is inserted properly (see pages 58-59).

❏The CableCARD must be activated by your local cable TV provider before you can

receive digital cable TV services. See the activation instructions on pages 58-59.

❏Check the Diagnostics and CableCARD menu options (see page 126). (This can

be useful in providing information to an authorized technician or repair person.)

❏Contact your cable TV provider.

Other Information

131

Other Information

SXRD

2-584-141-12(1)

Memory Stick

Problem Possible Remedies

Image does not display/Cannot

see all files

❏Some variations of MPEG1 movies may not play back correctly.

❏Make sure the image file is a JPEG (.jpg, .jpeg) file or an MPEG1 (.mpg, .mpeg)

file.

❏Make sure the Memory Stick is inserted properly (see page 84).

❏Check the Filter option setting (see page 95).

❏Check the Select Folder setting (see page 95) and ensure that files are either in

DCF directories if Digital Camera Folders is selected (see page 95), or in the

currently selected folder if Select a Folder is selected (see page 95).

❏The maximum number of files the Memory Stick Viewer can display is 2,000 files

total, including all JPEG, MPEG1, and MP3 files.

JPEG image displays

undesirable motion or flicker in

full screen

❏JPEGs captured using a digital video camera may appear to display motion in full

screen. This is a result of the way digital video cameras record still images, and is

not a result of a malfunction with the SXRD projection TV.

Rotation not saved after

Memory Stick is ejected or

Memory Stick Viewer is closed

❏The Memory Stick might be locked. Unlock the Memory Stick and try rotating the

image again.

❏The file might not have information (EXIF data) that is usually generated when a

digital camera records a photo. In this case, it is not possible to save the rotation.

❏There might be insufficient space on the Memory Stick to save the rotated file. Try

deleting one or more files and rotating the image again.

Cannot show (or hide) file

information in full screen or

Slide Show

❏Set the File Information option to On or Off (see page 94).

Cannot see menu ❏Press V to display the menu again.

Cannot hear audio while

using Memory Stick

❏Check the SXRD projection TV’s volume or Speaker (see page 113) settings.

❏To hear JPEG voice memo, select the Digital Camera Folders option and set the

Filter option to Show All Print Marks.

❏Check that the Music option is not set to Off (see page 94).

Not all MP3 files on Memory

Stick are included when the

Music /Complete List option is

selected (page 94)

❏The Memory Stick Viewer can display a maximum of 2,000 files total, including

all JPEG, MPEG1, and MP3 files.

❏Make sure that the file is named with the file extension (.mp3).

MP3 files on the Memory Stick

are not listed

❏Only MP3 files that are named with the file extension (.mp3) are displayed in the

list.

Music files are playing in wrong

order

❏MP3 files are played in alphabetical order, according to the folder in which they

are stored. If you want to change the playlist order, rename your files

alphabetically in the order in which you want them to play or create a MP3 playlist

(.m3u file) on a PC.

Cannot see MP3 list to play

music

❏MP3 files on your Memory Stick only can be played as background music during a

Slide Show (see page 94).

MPEG1 movie does not

play back correctly

❏Some variations of MPEG1 movies may not be compatible with the Memory Stick

Viewer.

❏MPEG movies recorded in VX Fine mode with Sony digital cameras cannot be

played back with the Memory Stick Viewer.

(Continued)

Other Information

132

SXRD

2-584-141-12(1)

MPEG1 quality is poor when

enlarged (page 92)

❏The quality of the movie when enlarged depends on the resolution of the MPEG1

file. See your camera’s instruction manual for details.

Error message is displayed ❏No Memory Stick There is no Memory Stick in the slot.

❏Memory Stick is

Locked

The lock mechanism on the Memory Stick is engaged.

❏Memory Stick Error The Memory Stick in the slot might be damaged; try a

different Memory Stick.

❏Format Error The Memory Stick may have been formatted using a PC

or other device that is not compatible with cameras.

Error icon is displayed The file is not a valid MPEG1 or JPEG format, or it is a

progressive JPEG (which is not supported).

The thumbnail is not DCF-compatible.

The file is a JPEG or an MPEG1, but the thumbnail is

unreadable.

The file is unreadable.

Problem Possible Remedies

Other Information

133

Other Information

SXRD

2-584-141-12(1)

Video

Problem Possible Remedies

No picture (screen not lit), no

sound

❏If your SXRD projection TV does not turn on, and a red light keeps flashing, your

SXRD projection TV may need service. Call your local Sony Service Center.

❏Make sure the power cord is plugged in.

❏Press POWER on the front of the SXRD projection TV.

❏Press TV/VIDEO to cycle through the connected video sources.

❏Try another channel; it could be station trouble.

Dark, poor or no picture

(screen lit), good sound

❏Adjust the Picture option in the Video menu (see page 108).

❏Adjust the Brightness option in the Video menu (see page 108).

❏Check the antenna/cable connections.

No color/dark picture/color is

not correct

❏Adjust the Color option in the Video menu (see page 108).

Only snow and noise appear on

the screen

❏Check the antenna/cable connections.

❏Try another channel; it could be station trouble.

❏Press ANT to change the input mode (see page 62).

Dotted lines or stripes ❏Adjust the antenna.

❏Move the SXRD projection TV away from noise sources such as cars, neon signs,

or hair dryers.

Double images ❏Using a highly directional outdoor antenna or a cable may solve the problem.

“Black box” on screen ❏You have selected a text option in the Setup menu and no text is available. (See

page 122 to reset Setup selections.) To turn off this feature, set the Caption

Vision option to Off. If you were trying to select closed captioning, select CC1

instead of Tex t 1 - 4.

Black bands appear at the top

and bottom of the screen

❏Some wide-screen programs are filmed in aspect ratios that are greater than 16:9

(this is especially common with theatrical releases). Your SXRD projection TV

will show these programs with black bands at the top and bottom of the screen.

For more details, check the documentation that came with your DVD (or contact

your program provider).

Certain programs on DVD or

other digital sources display a

loss of detail, especially during

fast-motion or dark scenes

❏The compression used by certain digital broadcasts and DVDs may cause your

SXRD projection TV’s screen to display less detail than usual, or cause artifacts

(small blocks or dots, pixelations) to appear on your screen. This is due to your

SXRD projection TV’s large screen and ability to show very fine detail, and is

normal for certain digitally recorded programs. Adjust the reality/clarity in the

DRC Palette menu (see page 110) to optimize the picture while viewing these

sources.

"Iris Unit error" appears while

Cinema Black Pro is set to On

❏The Iris Control may have a problem. Call your local Sony Service Center.

Other Information

134

SXRD

2-584-141-12(1)

Audio

Channels

Problem Possible Remedies

Good picture, no sound ❏Press MUTING so that Muting disappears from the screen (see page 62).

❏Make sure the Speaker option is set to On in the Audio menu (see page 113).

❏Make sure the MTS option is set to Stereo or Mono (see page 113).

❏Make sure the speakers are connected correctly (see page 18).

❏When the HDMI IN input is in use, surround sound, such as AC-3 and DTS,

cannot be input. Change the sound setting for the external input device to Linear

PCM.

Audio noise ❏Communication problems may occur if infrared communication equipment (e.g.,

infrared cordless headphones) is used near the SXRD projection TV. Please use

headphones other than infrared cordless headphones. Also, if you use infrared

communication equipment other than infrared cordless headphones, move the

infrared transceiver away from the SXRD projection TV until the noise is

eliminated, or move the transmitter and receiver of the infrared communication

equipment closer together.

Cannot gain enough volume

when using a cable box

❏Increase the volume of the cable box using the cable box’s remote control. Then

press FUNCTION repeatedly until the SXRD projection TV indicator lights up

and adjust the SXRD projection TV’s volume.

Sound seems weak or

insufficient

❏The SXRD projection TV’s audio might be set to Auto SAP or Mono, when it

might be better set to Stereo. In the Audio menu (see page 113), set the MTS

setting to Stereo. If already set to Stereo, switch to Mono (which may reduce

background noise during weak stereo broadcasts).

Cannot raise the volume on

external speakers

❏If the Speaker option is set to Off and the Audio Out option is set to Fixed (in

order to output the sound to your audio system), use your audio receiver to adjust

the sound (see page 113). Or, to use the SXRD projection TV remote control, set

the Audio Out option to Variable.

❏To turn on the SXRD projection TV speakers, set the Speaker option to On (see

page 113).

Cannot switch from Off to On

in the Speaker option

❏Make sure the speakers are connected correctly (see page 18).

Problem Possible Remedies

Cannot receive upper channels

(UHF) when using an antenna

❏Press ANT to select the VHF/UHF input (see page 62).

❏Use Auto Program in the Channel menu to add receivable channels that are not

presently in the SXRD projection TV’s memory (see page 116).

TV is fixed to one channel ❏Use Auto Program in the Channel menu to add receivable channels that are not

presently in the SXRD projection TV’s memory (see page 116).

❏Check your Channel Fix settings (see page 116).

Cannot receive any channels

when using cable TV

❏Use Auto Program in the Channel menu to add receivable channels that are not

presently in the SXRD projection TV’s memory (see page 116).

❏Press ANT to select the CABLE input (see page 62).

Other Information

135

Other Information

SXRD

2-584-141-12(1)

General

Cannot receive or select

channels

❏Use Auto Program in the Channel menu to add receivable channels that are not

presently in SXRD projection TV memory (see page 116).

Some digital cable channels are

not being displayed

❏Certain cable companies have limitations on the broadcast of digital cable

channels. Check with your cable company for more information.

❏The digital cable channel may be set to Hidden in the Digital Setup menu (see

page 117).

Problem Possible Remedies

How to reset TV to factory

settings

❏Turn on the TV. While holding down the RESET button on the remote control,

press the POWER button on the TV. (The TV will turn itself off, then back on

again.) Release the RESET button.

How to restore Video settings

to factory settings

❏Press RESET on the remote control while in the Video menu (see page 108).

How to restore Audio settings

to factory settings

❏Press RESET on the remote control while in the Audio menu (see page 112).

Cannot cycle through the other

video equipment connected to

the SXRD projection TV

❏Be sure the Label Video Inputs option is not set to Skip (see page 123).

Cannot operate Menu ❏If a menu option appears in gray, this indicates that the menu option is not

available.

Lost password ❏In the password screen (see page 118), enter the following master password:

4357. The master password clears your previous password; it cannot be used to

temporarily unblock channels.

❏The i.LINK STANDBY LED blinks in red when the signal from an i.LINK device

is being shown.

TIMER LED on front panel is

lit

❏The LED (see page 26 or 137) blinks when the TV is turned on, then shuts off

when the picture is displayed. If the red LED blinks continuously, this may

indicate the TV needs service. When lit, indicates that the timer is set (see page 26

or 137). When the timer is set, this LED will remain lit even when the TV is

turned off.

POWER/STANDBY LED

blinks in red

❏If the LED blinks three times, the lamp cover may not be attached securely (see

page 23).

LAMP LED blinks in red ❏Replace the lamp (see page 20).

The replacement lamp does not

light up

❏The screw of the lamp cover may be slanted. Take out the screw, insert it straight

into the screw hole, and then tighten it completely (see page 20).

Digital cable box does not work ❏If you are connecting a VCR and digital cable box using a splitter, as described on

page 42, you must use a special bi-directional splitter that is designed to work

with your digital cable box. Contact your cable provider for details.

Cannot record digital channels

to VCR

❏Only analog channels can be recorded to your VCR.

(Continued)

Other Information

136

SXRD

2-584-141-12(1)

TV cabinet creaks ❏When the TV is in use, there is a natural rise in temperature, causing the cabinet to

expand or contract and may be accompanied by a slight creaking noise. This is not

a malfunction.

A slight creaking noise occurs

from the bottom part of the TV

❏Cinema Black Pro applies a mechanical iris system. When Cinema Black Pro

is turned On/Off, a natural creaking noise occurs due to the basic structure of the

optical unit. The creaking sound is an inherent nature of this system and is not a

defect.

The cooling fan is loud ❏If the SXRD projection TV is used at high altitudes and High Altitude is set to

On, the cooling fan runs faster and its sound becomes louder. If the TV is not

used at high altitudes, set High Altitude to Off (see page 123).

The signal from a selected

i.LINK device is not being

displayed

❏If you have several i.LINK devices connected and operating at once, the TV may

not be able to display the signal from the selected device. Turn the other i.LINK

devices off, and reselect the desired i.LINK device.

❏If you are using a digital VCR, turn off any Auto LINC functionality of the VCR.

For details, see the digital VCR’s user manual.

The TV does not turn on ❏The SXRD projection TV cools down its projection lamp when the power is

turned off. It takes up to two minutes for the picture to come back after the TV is

turned on again. Wait for a while until the picture comes back.

Problem Possible Remedies

Other Information

137

Other Information

SXRD

2-584-141-12(1)

Flashing Indicators on the Front of the TV

The POWER/STANDBY (green or red) and/or LAMP (red) indicators light

or flash if there is a problem with or change in the condition of the SXRD

projection TV.

The POWER/STANDBY (green) indicator flashes.

❑The lamp for the light source is ready to turn on.

The POWER/STANDBY (red) indicator flashes three times.

❑The lamp cover is not attached securely. When you secure the lamp

cover, the POWER/STANDBY indicator flashes in red and the SXRD

projection TV enters the standby mode (see page 26).

The LAMP indicator flashes.

❑The lamp for the light source has burned out.

Replace it with a new one (see page 20).

If the SXRD projection TV does not function properly after correcting the

problems, contact qualified Sony personnel.

POWER

STD/DUO

POWER/STANDBY

STANDBY

POWER

LAMP

TIMER

STD / DUO

Other Information

138

SXRD

2-584-141-12(1)

Specifications

Projection System 3 SXRD Panel, 1 lens projection system

SXRD Panel 0.78 inch SXRD panel 6,220,800 pixels (2,073,600 x 3)

Projection Lens High Performance, large diameter hybrid lens F2.4

Antenna 75 ohm external terminal for VHF/UHF

Lamp UHP lamp, 200W, XL-5000

Television System NTSC American TV Standard

ATSC (8VSB terrestrial) ATSC compliant 8VSB

QAM on cable ANSI/SCTE 07 2000

Screen Size (measured diagonally) 70 inches

Channel Coverage Terrestrial (analog) 2-69

Cable TV (analog) 1-125

Terrestrial (digital) 2-69

Cable TV (digital) 1-135

Power Requirements 120V, 60 Hz

Inputs/Outputs

HDMI IN 2 total Video: 1080i, 720p, 480p, 480i

Audio: Two channel linear PCM 32, 44.1 and

48 kHz, 16, 20 and 24 bit

✍Not compatible with compressed sound,

such as AC-3 and DTS.

Video (IN) 3 total (1 on front panel) 1 Vp-p, 75 ohms unbalanced, sync negative

S Video (IN) 3 total (1 on front panel) Y: 1 Vp-p, 75 ohms unbalanced, sync

negative

C: 0.286 Vp-p (Burst signal), 75 ohms

Audio (IN) 6 total (1 on front panel) 500 mVrms (100% modulation)

Impedance: 47 kilohms

Component Video Input 2 (Y, PB, PR) Y: 1.0 Vp-p, 75 ohms unbalanced, sync

negative

PB: 0.7 Vp-p, 75 ohms

PR: 0.7 Vp-p, 75 ohms

CONTROL S (IN) 1 Mini jack

CONTROL S (OUT) 1 Mini jack

AUDIO (VAR/FIX) OUT 1 500 mVrms at the maximum volume setting

(Variable)

500 mVrms (Fixed)

Impedance (output): 2 kilohms

✍AUDIO OUT jacks are operable only

when the TV’s Speaker is set to Off. For

details, see page 113.

i.LINK 3 total (1 on front panel) 4-pin S400 i.LINK terminal

RF Inputs 2

Digital Audio Optical Output

(PCM/Dolby Digital)

1 Optical Rectangular (1)

Other Information

139

Other Information

SXRD

2-584-141-12(1)

Design and specifications are subject to change without notice.

CableCARD Slot PCMCIA Type I/II

Speaker Output 25 W (L), 25 W (R), 50 W (Woofer)

Dimensions (W × H × D) 1,907 × 1,195 × 627 mm

Mass Approx. 124kg

Power Consumption

In Use 330 W

In Standby 0.5 W

In i.LINK/CableCARD Standby Less than 30 W

Supplied Accessories

Remote Control RM-Y914

AA (R6) Batteries 2 supplied for remote control

Cleaning Cloth 1

AC Power Cord 1

Anti-Static Cleaning Brush 1

Slot Covers 4

Owner’s Guide 1

Quick Setup Guide 1

Warranty 1

Product Registration Card 1

Other Information

140

SXRD

2-584-141-12(1)

Optional Accessories

❑HDMI cable

❑Component video cable

❑S VIDEO cable

❑A/V cable

❑Audio cable

❑Optical cable

❑Control S cable : RK-G69

❑TV Stand : SU-SX10

❑Lamp : XL-5000

❑i.LINK cables: VMC-IL4415 (4-pin to 4-pin, 1.5 meters); VMC-IL4435 (4-pin to 4-pin, 3.5 meters)

141

SXRD

2-584-141-12(1)

Index

Numerics

0 – 9 buttons 63, 69

4:3 Default settings 115

AC IN 28, 33

Advanced Video 110

Alternate Audio 71, 105

Alternate Video 71, 105

ANT button 62, 69

Antenna, connecting 35, 36

Applications Menu 125

Audio Menu 107, 112

Audio Out 113

AUDIO OUT jack 28

Audio receiver, connecting 51

Auto Program (channel setup) 60,

116

Auto SAP 113

Balance, adjusting 112

Bass, adjusting 112

Batteries, inserting in remote 61

Black Corrector 111

BN Smoother 111

Brightness, adjusting 108

Cable

connecting 35

with VCR, connecting 41

Cable box

connecting with VCR 42

using with TV remote control

CABLE jack 29

CableCARD 58, 126

CableCARD slot 29

Camcorder, connecting 50

Caption Vision 122, 124

CH +/– button 63

Change Password 119

CHANNEL +/– 27

Channel Fix 116

Channel Menu 107, 116

Channels

adding 77–78

Auto Program 116

creating labels 117

deleting 77–78

setting up 60

Cinema Black Pro 111

Cleaning Cloth 139

Clear Voice 112

Clear White 111

Clock/Timers 125

Closed caption modes 107, 122

Color Corrector 111

Color Space 111

Color Temperature, adjusting 109

Color, adjusting 108

Connecting

Audio receiver 51

Cable and antenna 36

Cable box 37–38

Cable or antenna 35

Camcorder 50

DVD player 48

Satellite receiver 45–47

VCR 41–44, 46

CONTROL S 57

CONTROL S IN/OUT jack 28

Detail Enhancer 111

Detachable speakers 16, 18-19

Diagnostics 126

DIGITAL AUDIO (OPTICAL)

OUT jack 29

Digital CC 124

Digital Channels 116

Digital Reality Creation 14

Direct Mode 109

DISPLAY button 63, 69

Dolby Virtual 112

DRC Mode 110

DRC Palette 110

DTE 111

DVD player

using with TV remote control

with A/V connectors,

connecting 49

with component video

connectors,

connecting 48

Dynamic 112

Effect 112

English Rating 121

ENTER button 63, 69

Error messages, Memory Stick

131

EXIT button 63

Favorite Channels

setting up 116

using 77

FAVORITES button 63

Features 14

File 90, 93

File Information 94

File Order 95

Filter 95

FREEZE button 63

Freeze, using 79

French Rating 121

Front Panel 26–27

FUNCTION button 62

Game Mode 109

Game Picture 114

Gamma Corrector 111

GUIDE button 62, 70

HD/DVD IN jacks 28

(Continued)

142

SXRD

2-584-141-12(1)

HDMI 29

High Altitude 123

Hue, adjusting 108

i.LINK 27, 99–105

i.LINK button 63

i.LINK Standby 123

i.LINK STANDBY LED 26

Illuminated 123

Index 90, 93

INDEX button 62

Info Banner 122

Installation of the Projection TV

30–33

JUMP button 63, 69

Label Channels 117

Label Video Inputs 123

LAMP LED 26

Lamp, replacing 20–23

Language, setting 123

MDP, using with TV remote

control 67

Memory Stick 125

button 63

Duo 85

features 81

Index 87

indicator (LED) 26

insertion slot 26

panning photos 91

photo options 90

playing movies 92

precautions 97

removing 86

rotating photos 91

slide show options 94

troubleshooting 131

viewing photos 89

zooming photos 91

MENU button 63, 69

Menu Color 123

Menus

Applications 107, 125

Audio 107, 112

Channel 107, 116

Parent 107, 118

Screen 107, 114

Setup 107, 122

Video 107, 108

Movie Rating 120

MTS 113

Music 94

MUTING button 62, 69

Noise Reduction 109

Overscan 115

Parent Menu 107, 118

Parental control, described 14

Parental Lock 118

PICTURE button 62

Picture contrast, adjusting 108

Picture Mode

Pro 108

Standard 108

Vivid 108

POWER button 26

POWER buttons (GREEN) 62

Power Saving 124

POWER/STANDBY indicator

26, 137

Problems, troubleshooting 129–

136

Program Guide menu 70–71

Program Options menu 71

Ratings

setting 120

viewing blocked programs 119

Rear panel 27–29

REC button 63

Remote control

button descriptions 62–63

inserting batteries 61

programming 64

Repeat 94

RESET button 63

Resetting

Audio options 112

Video options 108

S VIDEO jack 27

SAT/CABLE power button 62

Satellite receiver

connecting 45

using with TV remote control

Screen Menu 107, 114

Select Country 119

Select Folder 95

Setup Menu 122

Sharpness, adjusting 108

Show/Hide Channels 117

Simulated 113

SLEEP button 62

Slide Advance 94

Slide Show 90, 93

Sound Mode 112

Speaker 113

Specifications 138–139

Steady Sound

adjusting 112

Subchannels 71

Timer

set current time 126

setting 125

TIMER indicator 26, 137

Transition Effect 94

Treble, adjusting 112

Troubleshooting 129–136

TruSurround 113

TV Rating 120

TV/VIDEO button 27, 63, 69

Twin View

activating a picture 74

button 62

described 14

enlarging pictures 76

picture size, adjusting 76

143

SXRD

2-584-141-12(1)

using 74

Zoom feature 76

U.S.A. Rating 121

Unrated 120

VCR

using with TV remote control

with cable box, connecting 42

with cable, connecting 41

with satellite receiver and cable,

connecting 46

Vertical Center 115

Vertical Size 115

VHF/UHF jack 29

Video inputs, labeling 123

VIDEO L(MONO)-AUDIO-R

Video Menu 107, 108

Viewing area, recommended 32

VOL +/– button 62, 69

VOLUME +/– 27

White Balance 111

WIDE button 62

Wide Mode 114

Wide Screen Mode 72

Woofer Level 112

Printed on 100% recycled paper.
