Introducing Your New BRAVIA®
Getting Started
Operating the TV
Using Features
Using the Menus
Other Information

4-458-509-12(1)

LCD TV

Operating Instructions

Introducing Your New

BRAVIA®

Getting Started

Operating the TV

Using Features

Using the Menus

Other Information

Sony Customer Support

U.S.A.: http://www.sony.com/tvsupport

Canada: http://www.sony.ca/support

United States

1.800.222.SONY

Canada

1.877.899.SONY

Please Do Not Return

the Product to the Store

KDL-46R453A / 46R450A / 40R471A / 40R450A / 32R421A / 32R400A

CAUTION

To prevent electric shock and blade exposure, do not use

this polarized AC plug with an extension cord, receptacle or

other outlet unless the blades can be fully inserted.

❑Operate the TV only on 110-240 V AC

(USA/Canada 120 V AC).

❑Avoid operating the TV at temperatures

below 41°F (5°C).

Licensing Information

MHL, Mobile High-Definition Link and the MHL Logo are

trademarks or registered trademarks of MHL Licensing, LLC.

HDMI, the HDMI logo, and High-Definition Multimedia

Interface are trademarks or registered trademarks of HDMI

Licensing, LLC in the United States and other countries.

Fergason Patent Properties, LLC:

U.S. Patent No. 5,717,422

U.S. Patent No. 6,816,141

Manufactured under license from Dolby Laboratories.

Blu-ray Disc is a trademark.

“BRAVIA” and , BRAVIA Sync, and are

trademarks or registered marks of Sony Corporation.

“PlayStation” is a registered trademark and “PS3” is a

trademark of Sony Computer Entertainment Inc.

Cleaning

When cleaning, be sure to unplug the power

cord to avoid any chance of electric shock.

• Wipe the LCD screen gently with a soft cloth.

• Stubborn stains may be removed with a

cloth slightly moistened with a solution of

mild soap and warm water.

• If using a chemically pretreated cloth, please

follow the instruction provided on the

package.

• Never use strong solvents such as a thinner,

alcohol or benzine for cleaning.

• See the supplied Safety Booklet for

additional information.

Your BRAVIA TV is ENERGY STAR® qualified

in the “Home” mode. It meets strict energy

efficiency guidelines set by the U.S.

Environmental Protection Agency and

Department of Energy.

ENERGY STAR is a joint program of these

government agencies, designed to promote energy efficient

products and practices. Changes to certain features,

settings, and functionalities of this TV (i.e. Picture/Sound,

Light Sensor, Power Savings, Picture Scene) can increase or

change the power consumption. The Auto and General

picture scenes are default settings optimized for the input

signal selected. Your BRAVIA TV is tested in these settings

for ENERGY STAR qualification. Depending upon such

changed settings, the power consumption may exceed the

limits required for the ENERGY STAR qualification in the

“Home” mode.

Owner’s Record

The model and serial numbers are located at the side

and rear of the TV. Record these numbers in the spaces

provided below. Refer to them whenever you call upon

your Sony dealer regarding this TV.

Model Name

Serial No.

The 32 class has a 31.5 inch viewable image size (measured diagonally).

Contents

Introducing Your New BRAVIA

Welcome to the World of BRAVIA® . . . . . . . .4

Experiencing Stunning HD with Your

BRAVIA . . . . . . . . . . . . . . . . . . . . . . . . . . .4

The Four Steps to a Stunning HD

Experience . . . . . . . . . . . . . . . . . . . . . . . . .5

TV Feature Highlights . . . . . . . . . . . . . . . . . . .5

Getting Started

Setting Up Your TV . . . . . . . . . . . . . . . . . . . . .7

Attaching the Table-Top Stand . . . . . . . . . . . .8

Locating Inputs and Outputs . . . . . . . . . . . . .10

Connecting the TV . . . . . . . . . . . . . . . . . . . .12

Connecting Other Equipment . . . . . . . . . . . .15

When Installing the TV Against a Wall or

Enclosed Area . . . . . . . . . . . . . . . . . . . . .16

Securing the TV . . . . . . . . . . . . . . . . . . . . . .17

Running Initial Setup. . . . . . . . . . . . . . . . . . .20

Operating the TV

Using the Remote Control. . . . . . . . . . . . . . .22

Remote Control Button Description . . . . . . .23

TV Controls and Indicators . . . . . . . . . . . . . .26

Using Features

BRAVIA Sync Control . . . . . . . . . . . . . . . . . .27

Using PIP Feature. . . . . . . . . . . . . . . . . . . . .28

Favorites . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Wide Mode . . . . . . . . . . . . . . . . . . . . . . . . . .30

Wide Mode with PC . . . . . . . . . . . . . . . . . . .31

Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31

Playing back Photo/Music/Video via USB. . .32

Photo Frame . . . . . . . . . . . . . . . . . . . . . . . . .33

Using the Menus

Navigating through TV Menus . . . . . . . . . . .35

Using the Picture Settings. . . . . . . . . . . . . . .37

Using the Sound Settings . . . . . . . . . . . . . . .39

Using the Screen Settings . . . . . . . . . . . . . .41

Using the Channel Settings . . . . . . . . . . . . .43

Using the Parental Lock Settings . . . . . . . . .44

Using the Setup Settings . . . . . . . . . . . . . . .47

Using the Eco Settings . . . . . . . . . . . . . . . . .52

Other Information

PC Input Signal Reference Chart for

HDMI IN . . . . . . . . . . . . . . . . . . . . . . . . . .53

Using a Wall-Mount Bracket . . . . . . . . . . . . .54

Troubleshooting . . . . . . . . . . . . . . . . . . . . . .56

Important Notices . . . . . . . . . . . . . . . . . . . . .62

Specifications . . . . . . . . . . . . . . . . . . . . . . . .63

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65

Customer Support

United States

http://www.sony.com/tvsupport

Canada

http://www.sony.ca/support

On-line Registration

United States

http://productregistration.sony.com

Canada

http://www.sony.ca/registration

Introducing Your New BRAVIA®

Welcome to the World of BRAVIA®

Thank you for choosing this Sony

BRAVIA

high-definition television. Use the

documentation listed below to get the most out of your TV.

Experiencing Stunning HD with Your

BRAVIA

The quality of the image you see on your BRAVIA

TV is only as good as the quality of the

signal it receives. To experience the stunning detail of your new

BRAVIA

TV, you need

access to HD programming. Your

BRAVIA

TV can receive and display HD programming

from:

• Over-the-air broadcasting via HD-quality antenna

• HD cable subscription

• HD satellite subscription

• Blu-ray Disc™ player or other HD compatible external equipment

Contact your cable, satellite or HD service provider for information on upgrading to HD

programming.

Safety Booklet

Contains precautionary

measures to keep you and

your TV safe. Read this

information prior to setting up

your TV.

Quick Setup Guide

Provides TV setup information with sample

connection diagrams.

Operating Instructions

Provides the most detailed

information to operate your

TV.

Introducing Your New BRAVIA®

The Four Steps to a Stunning HD

Experience

Set, Source, Sound, and Setup

Along with your BRAVIA TV set, a complete HD system requires a source of HD

programming, an HD sound system, and a proper connection setup. Refer to the Quick

Setup Guide, enclosed separately, for connecting optional equipment.

TV Feature Highlights

Your BRAVIA comes with many convenient features, such as:

➢ MHL (Mobile High-Definition Link) input: You can connect your MHL device

using an MHL cable (page 14).

➢ BRAVIA

SyncTM: Allows your BRAVIA TV to communicate with other Sony

equipment supporting the BRAVIA Sync Control function (page 27).

➢ Digital Media Accessibility: Use the Photo, Music, and Video icons to

access photo, music, and video files from Sony USB equipment (page 32).

➢ PIP (Picture in Picture): You can work on your PC and watch your favorite TV

program simultaneously (page 28).

➢ Favorites: Your favorite channels and inputs are at your finger tips for easy

access (page 29).

➢ Auto Wide Mode: Set your TV to automatically adjust the screen based on the

signal resolution (page 30).

➢ Input Selection: Allows you to easily switch between the connected equipment

(page 31).

You can enjoy crisp, clear images, smooth

movement, and high-impact visuals from 1080 HD

signals as shown here.

When you compare a high-definition signal to a

standard analog signal, you will notice a big

difference in picture quality. If black bars appear as

shown here, press WIDE on the remote control to fill

the screen.

(Continued)

➢ Scene Select: Allows you to easily adjust your TV to the most suitable picture

and sound settings based on the scenes for the best quality result for the

contents genre you are watching.

➢ Photo Frame: You can enjoy the large photo frame display with music (page

33).

➢ On Timer: Set timer to wake up TV automatically with preferred setting of input

and volume. You can also wake up with your favorite photo and music through

photo frame feature (page 49).

Getting Started

Setting Up Your TV

Some TV models are packaged with a detached Table-Top Stand so you can mount

your TV to a wall right away. If you are not mounting the TV to a wall, you will need to

attach the Table-Top Stand. You will need a Phillips screwdriver (not supplied) and the

supplied screws to complete the task. Look for the supplied Table-Top Stand instruction

leaflet.

Be sure to consider the following while setting up your TV:

• Disconnect all cables when carrying the TV.

• Carry the TV with the adequate number of people; larger size TVs require two or more people.

• Correct hand placement while carrying the TV is very important for safety and to avoid damage.

• Do not put stress on the LCD panel or the frame around the screen.

• Ensure your TV has adequate ventilation, see page 16.

• For best picture quality, do not expose the screen to direct illumination or sunlight.

• Avoid installing the TV in a room with reflective wall and floor materials.

• Avoid moving the TV from a cold area to a warm area. Sudden room temperature changes may

cause moisture condensation. This may cause the TV to show poor picture and/or poor color.

Should this occur, allow moisture to evaporate completely before powering the TV on.

KDL-46R453A/46R450A/

40R471A/40R450A

KDL-32R421A/

32R400A

Attaching the Table-Top Stand

• Refer to the supplied Table-Top Stand instruction leaflet for proper attachment.

• For best picture quality, do not expose the screen to direct illumination or sunlight.

1Place the TV with its screen facing down on a level and stable surface covered with

a thick and soft cloth.

2Fix the TV to the Table-Top Stand using the supplied screws.

Thick and soft cloth Screw (+PSW 5 x 16)

(Supplied)

* Be careful not to hit the Table-

Top Stand against the edge of

the surface when attaching it.

Getting Started

• Hold the Table-Top Stand with one hand to avoid it dropping when attaching.

• This TV is very heavy, so two people should place the TV onto thick and soft cloth.

• If using an electric screwdriver, set the tightening torque at approximately 1.5 N·m (15 kgf·cm).

• Be sure to securely tighten the supplied screws, otherwise the TV may fall down.

• Use an appropriate screwdriver to attach the screws tightly without damaging the screw head.

• Please ensure the AC power cord is away from the Table-Top Stand installation location when

you attach the Table-Top Stand.

• When detaching the Table-Top Stand, reverse the attaching procedure. Do not remove any

screws other than those used when attaching the Table-Top Stand. Do not power on the TV with

its LCD panel facing down to avoid uneven picture uniformity.

Locating Inputs and Outputs

Item Description

HDMI IN 1 (ARC)

HDMI IN 2/MHL

HDMI (High-Definition Multimedia Interface) provides an uncompressed,

all-digital audio/video interface between this TV and any HDMI-equipped

audio/video equipment, such as a set-top box, DVD player, and A/V

receiver. HDMI supports enhanced, or high-definition video, plus digital

audio.

You can also connect your MHL (Mobile High-Definition Link) device to

HDMI IN 2/MHL using an MHL cable. In addition, when you connect

BRAVIA Sync-compatible equipment, communication with the connected

device is supported.

If connecting a digital audio system that is compatible with Audio Return

Channel (ARC) technology, use HDMI IN 1 (ARC). If not, an additional

connection with DIGITAL AUDIO OUT (OPTICAL) is necessary.

2AUDIO OUT Connects to the audio input jacks of your analog audio equipment. You

can use these outputs to listen to your TV’s audio through your stereo

system.

3DIGITAL AUDIO

OUT (OPTICAL)

Connects to the optical audio input of digital audio equipment that is PCM/

Dolby*1 Digital compatible.

*1Manufactured under license from Dolby Laboratories.

• An HDMI or Component video (YPBPR) connection is required to view 480i, 480p, 720p, 1080i

and 1080p video formats. 1080/24p is available only with HDMI/MHL connection.

• Be sure to use only an authorized HDMI cable bearing the HDMI logo. We recommend that you

use a Sony HDMI cable (high speed type).

Side PanelRear Panel

Getting Started

4CABLE/

ANTENNA

RF input that connects to your Cable or VHF/UHF antenna.

5VIDEO IN/

COMPONENT

IN/R-AUDIO-L

(MONO)

This input port can be used as a composite video input (VIDEO) or as a

component video input (COMPONENT). For composite use, connect the

yellow jack to Y for video and use audio L (mono) and R for audio signal.

For component connection, use Y, PB, PR for video signals and also

connect the audio L (mono) and R for audio signal.

This TV can auto detect and switch between the VIDEO and COMPONENT

when VIDEO or COMPONENT is connected.

To set to auto detection, press HOME, select Settings, and then select the

Setup settings. Select the Video/Component Selection option in AV

Setup then set to Auto.

7USB Connects to USB equipment to access photo, music, and video files.

Item Description

Connecting the TV

Cable System or VHF/UHF Antenna System

You can enjoy high-definition and standard-definition digital programming (if available in

your area) along with standard-definition analog programming.

This TV is capable of receiving unscrambled digital programming for both cable (QAM

and 8VSB) and external VHF/UHF antenna (ATSC).

xCable or VHF/UHF (or VHF only)

• It is strongly recommended that you connect the CABLE/ANTENNA input using a 75-ohm

coaxial cable to receive optimum picture quality. A 300-ohm twin lead cable can easily be

affected by radio frequency interference, resulting in signal degradation.

Cable System and VHF/UHF Antenna System

Use an optional A-B RF switch (not supplied) to switch between the cable and over-the-

air antenna programming, as indicated below.

• Be sure to set the Signal Type setting to Cable or Antenna found under the Channel settings

for your input signal (page 43).

75-ohm coaxial cable Rear of TV

CABLE/ANTENNA

Cable

Antenna

A/B RF Switch

Rear of TV

CABLE/ANTENNA

Getting Started

HD Cable Box/HD Satellite Box

You can enjoy high-definition programming by subscribing to a high-definition cable

service or a high-definition satellite service. For the best possible picture, make sure you

connect this equipment to your TV via the HDMI or component video (with audio) input

located on the back of your TV.

xShown with HDMI Connection

xShown with Component Connection

Rear of TV

HDMI cable

HD cable box/

HD satellite box

CATV/Satellite

antenna cable

Rear of TV

CATV/Satellite

antenna cable

AUDIO-R (red)

AUDIO-L (white)

Component video cable

Audio cable

PR (red)

PB (blue)

Y (green)

HD cable box/

HD satellite box

(Continued)

MHL device

The MHL (Mobile High-Definition Link) enables the TV to communicate with connected

MHL-compatible device. When connecting MHL-compatible device, TV simultaneously

charges the connected device while playing photo/music/video from it. You can use the

TV remote control to control the connected MHL-compatible device.

• You can continue normal usage of the connected MHL-compatible device (such as receiving

calls) depending on its capability.

• Some remote control functions may not be available depending on features of the connected

MHL-compatible device. Refer to the device manual for details.

• This product is officially MHL-certified for guaranteed operation with other MHL-certified

devices. If you encounter any problems when using the MHL function, consult the device

manufacturer for support.

• If Auto Input Change(MHL) is set to On, the TV automatically switches to HDMI IN 2/MHL from

other input when MHL-compatible device is connected to HDMI IN 2/MHL jack. The availability

of Auto Input Change(MHL) depends on whether the MHL-compatible device can support this

feature.

• The TV can connect to the MHL-compatible device via its MHL 2 connection.

Side of TV

Use authorized MHL Cable with

MHL Logo (not supplied).

MHL device

Getting Started

Connecting Other Equipment

• Refer to the Quick Setup Guide (supplied) when connecting other equipment to your TV.

Blu-ray Disc Player/

“PS3”

DVD

player

Digital satellite

receiver

Analog audio equipment

(A/V Receiver/HomeTheater)

Digital

cable box

Audio

system

Digital audio equipment

(A/V Receiver/Home Theater)

Digital recorder

USB

CABLE/ANTENNA

MHL device

When Installing the TV Against a

Wall or Enclosed Area

Make sure that your TV has adequate ventilation. Allow enough space around the TV as

shown below. Avoid operating the TV at temperatures below 41 °F (5 °C).

• Inadequate ventilation can lead to overheating of the TV and may cause damage to your TV or

cause a fire.

(30 cm)

11 7/8 inches

(6 cm)

inches

4 inches

(10 cm)

4 inches

(10 cm)

23/8

Leave at least this much space around the set.

Installed with stand

inches

11 7/8

4 inches

(10 cm)

4 inches

(10 cm)

4 inches (10 cm)

(30 cm)

Installed on the wall

Leave at least

this much space

around the set.

Never install the TV set as follows:

Air circulation is blocked. Air circulation is blocked.

Wall Wall

Getting Started

Securing the TV

Sony strongly recommends taking measures to prevent the TV from toppling

over. Unsecured TVs may topple and result in property damage, serious bodily

injury or even death.

Preventing the TV from Toppling

❑Secure the TV to a wall and/or stand.

❑Do not allow children to play or climb on furniture and TV sets.

❑Avoid placing or hanging items on the TV.

❑Never install the TV on:

• slippery, unstable and/or uneven surfaces.

• furniture that can easily be used as steps, such as a chest of drawers.

❑Install the TV where it cannot be pulled, pushed, or knocked over.

❑Route all AC power cords and connecting cables so that they are not accessible to curious

children.

Recommended Measures to Secure the TV

Consider the following measures when securing your TV to a TV stand (not supplied).

1Secure the stand for the TV.

Make sure the TV stand can adequately support the weight of the TV. Use two angle

braces (not supplied) to secure the stand.

For each angle brace use the appropriate hardware to:

• attach one side of the angle brace to the wall stud.

• attach the other side to the TV stand.

Angle braces

Stand

(Continued)

2Secure the TV to the stand.

Use the optional hardware listed below (not supplied):

• M4 machine screw (screwed into the screw hole of the TV).

• A screw or similar (attach it to the TV stand).

• Rope or chain (strong enough to support the weight of the TV). Make sure that there is

no excess slack in the rope or chain.

An alternative way to secure the TV is with an optional Sony Support Belt Kit.

The Sony Support Belt Kit is available as an optional accessory, depending on your

TV model.

The length of the M4 machine screw differs depending on the rope or chain

diameter. Please refer to below illustration.

3Anchor the TV to the wall.

Anchor the TV to the wall by using bolts, wall anchor and chain (or rope).

Screw hole of

the TV

M4 machine

screw (not supplied)

Screw

(not supplied)

Rope or chain

(not supplied)

6-8 mm

Screw M4

Rope or chainTV

Wall-mount

holes

Anchor bolts

(not supplied)

Wall-anchor

(not supplied)

Rope or chain

(not supplied)

Getting Started

• Contact Sony Customer Support to obtain the optional Support Belt Kit by providing your TV

model name.

For United States call: 1-800-488-7669 or visit: http://www.sony.com/accessories

For Canada call: 1-877-899-7669

• Securing the TV to the stand without securing the TV and the stand to the wall provides minimum

protection against the TV toppling over. For further protection, be sure to follow the three

measures recommended.

Running Initial Setup

During initial setup, you will perform the following:

• Set the language for the On Screen Display (OSD) text

• Choose your viewing environment

• Scan for digital and analog channels

• Set the current date and time after Auto Program.

Complete your cable connections before beginning the Initial Setup. Refer to the Quick

Setup Guide (supplied) for sample connection diagrams.

2Use the remote control buttons described below to navigate through the Initial

Setup.

3Auto Program will scan for available channels from the signal source directly

connected to the TV’s CABLE/ANTENNA input. Follow the help text provided on the

screen to run the Auto Program.

4Set the current date and time.

1Turn on the TV.

The Initial Setup screen will appear.

V/v/B/b buttons:

Allow you to navigate and highlight options where applicable.

button:

Allows you to select the highlighted option and advance to the next screen.

Getting Started

• If you cancel the Auto Program, any channels you have selected are not registered. To rescan

for available channels, run Auto Program.

• Connect either your cable or antenna to the TV (you can connect both using an A-B RF switch

(not supplied)); for more details see page 12.

Operating the TV

Using the Remote Control

To Insert Batteries into the Remote Control

Insert two size AAA batteries (supplied) by matching e and E on the batteries to the

diagram inside the battery compartment of the remote control.

Guidelines to follow

Push to

open

• Point your remote control directly at the IR sensor

located on your TV.

• Make sure that no objects are blocking the path

between the remote control and the IR sensor on your

TV.

• Fluorescent lamps can interfere with your remote

control; try turning off the fluorescent lamps.

• If you are having problems with the remote control,

reinsert or replace your batteries and make sure that

they are correctly inserted.

Operating the TV

Remote Control Button Description

• The 5, N and CH + buttons have a tactile dot. Use them as a reference when operating the TV.

Button Description

1SYNC

Press to display the BRAVIA Sync Menu and then

select connected HDMI/MHL equipment from

Device Selection

2INPUT Press to display the list of External Inputs and TV

mode. Press repeatedly to toggle through the

inputs. See page 31.

3PIC OFF Press to turn picture off, and sound remains on.

40-9 Press 0-9 to select a channel.

5Use with 0-9 to select digital channels.

For example, to enter 2.1, press , ,

and .

6Colored

buttons

When the colored buttons are available, an

operation guide appears on the screen.

7SLEEP Press repeatedly until the TV displays the time in

minutes (Off/15/30/45/60/90/120) that you want

the TV to remain on before shutting off. To cancel

the sleep timer, press SLEEP repeatedly until Off

appears.

8V/v/B/bPress V/v/B/b to move focus/highlight. Press

to select/confirm an item.

9RETURN Press to go back to the previous screen or exit

from the screen when displaying menu items and

settings.

0HOME Press to display the menu with TV functions and

settings. See “Using the Menus” on page 35.

qa VOL +/– Press to adjust the volume.

(Continued)

Button Description

qs POWER Press to turn on and off the TV.

qd WIDE Press repeatedly to cycle through the available

Wide Mode settings. See page 30.

qf CC/

SUBTITLE

Press to cycle through the available settings for

Closed Captions (CC) : On, Off, and On when

Muting.

qg DISPLAY Press once to display the banner with channel/

program information you are watching. The

banner will time out in a few seconds or press

again to exit.

qh OPTIONS Press to display a list of convenient functions and

menu shortcuts. The options menu items vary

based on current input and content.

qj JUMP Press to jump back and forth between two

channels and external inputs. The TV alternates

between the current/last channel or external input

selected.

qk CH +/– Press to scan through channels. To scan quickly

through channels, press and hold down either CH

+/–.

ql MUTING Press to mute the sound. Press again or press

VOL + to restore the sound.

Operating the TV

Button Description

w; Equipment

Control

These buttons are used to control the equipment

connected to the TV by using the BRAVIA Sync

Control function (not available on all BRAVIA

Sync Control equipment). Some other buttons on

the remote control may also operate BRAVIA

SyncTM equipment.

m (fast reverse): Press to play a program in

fast rewind mode.

N (PLAY): Press to play a program at a normal

speed.

M (fast forward): Press to play a program in

fast forward mode.

(PREV): Press to replay the current program

from the previous chapter mark.

X (PAUSE): Press to pause playback.

x (STOP): Press to stop playback.

(NEXT): Press to advance forward to the

next chapter mark.

TV Controls and Indicators

• For more information about setting up the external inputs labels, see page 49.

• The 2 + button has a tactile dot. Use it as a reference when operating the TV.

• Make sure that the TV is completely switched off before unplugging the power cord.

Item Description

1(IR) Infrared

Receiver/

Light sensor

Receives IR signal from the remote control.

Senses room light level and adjusts the screen brightness accordingly. Do not

put anything over the sensor, doing so may affect its function.

2"/1 LED • Lights up in red when the TV is in standby mode.

• Lights up in green when the TV is turned on.

• Lights up in orange when the timer is set or the TV is in Photo Frame Mode.

Lights up in green when the Power Saving is set to Picture Off.

3"/1 (Power) Press to turn on and off the TV.

4– 2 +Press to adjust the volume, or select a channel/external input. When the

volume Up/Down screen is displayed by pressing 2 +/–, volume can be

adjusted. When the channel Up/Down screen is displayed by pressing CH/

INPUT, channels can be selected. When the input select screen is displayed

by pressing CH/INPUT, external input can be selected.

5CH/INPUT Switches between the channel Up/Down screen and input select screen.

6Speaker Outputs audio signal.

Using Features

BRAVIA Sync Control

With the BRAVIA Sync Control function,

BRAVIA Sync helps to communicate with

BRAVIA Sync-compatible equipment

using HDMI CEC (Consumer Electronics

Control). Use the following settings and

tips to help unify control of your

connected equipment.

1Press HOME and select Settings,

then select the Setup settings.

2Select the BRAVIA Sync Settings,

then highlight BRAVIA Sync Control,

and set to On.

xControlling BRAVIA Sync-

Compatible Equipment

To control the equipment by using the

remote control, press SYNC MENU and

select the desired equipment from Device

Selection.

xBD/DVD Player

• Automatically turns the BRAVIA Sync-

compatible equipment on and switches the

input to that equipment when you select it

from the Sync Menu.

• Automatically turns the TV on and switches

the input to the connected equipment when

the equipment starts to play.

• Automatically turns the connected

equipment off when you switch the TV to

standby mode.

xAV Amplifier

• Automatically turns the connected AV

amplifier on and switches the sound output

from the TV speaker to the audio system

when you turn the TV on.

• Automatically switches the sound output to

the AV amplifier by turning the AV amplifier

on when the TV is turned on.

• Automatically turns the connected AV

amplifier off when you switch the TV to

standby mode.

• Adjusts the volume (VOL +/-) and mutes the

sound (MUTING) of the connected AV

amplifier through the TV’s remote control.

xVideo Camera

• Automatically turns the TV on and switches

the input to the connected video camera

when the connected video camera is turned

on.

• Automatically turns the connected video

camera off when you switch the TV to

standby mode.

•BRAVIA Sync Control is only available for

the connected Sony equipment that has the

BRAVIA Sync or is compatible with BRAVIA

Sync Control.

•The BRAVIA Sync Control settings must be

set on both the TV and connected

equipment. For settings on the connected

equipment, refer to their instruction manuals.

• When specific Sony equipment compatible

with BRAVIA Sync Control is connected,

BRAVIA sync is automatically activated on

the equipment.

Using PIP Feature

PIP (picture in picture) displays a picture

from a connected PC in full screen, and a

TV program or other external input (see

below “To Enter PIP” table) in an inset

window. (Closed Captions (CC) is not

available with PIP mode.)

To Enter PIP

1Press OPTIONS while images from a

PC appear on the screen.

2Select PIP from the OPTIONS menu.

3The sub window will appear.

xTo Change Channels

You can change the channel of the sub

window by pressing CH +/– or entering

the channel number using the 0-9 numeric

and buttons.

xTo Exit from PIP

You can exit from PIP, using any of the

following methods:

xTo Swap Audio

You can swap audio between the main

and sub window.

1Press OPTIONS.

2Press V/v to highlight Audio Swap

and press .

3Press V/v to highlight the window to

be audible, then press .

PIP Supported Inputs

In main window In sub window

HDMI IN (PC timing) TV channel (CABLE/

ANTENNA), VIDEO

IN, COMPONENT IN

1Press OPTIONS, press V/v to highlight

Exit PIP, then press to exit to the full PC

screen.

2Press RETURN.

Main

Window

(PC)

Sub Window

(Location of the

Sub Window

can be moved

by pressing

V/v/B/b.)

Using Features

Favorites

Your favorite channels and external inputs

can be accessed by pressing the HOME

button once they are added to the list.

1Press HOME.

2Press V/v to select Favorites, then

press .

The favorites list appears.

3Press V/v to select a channel or input,

then press .

xTo add to Favorites

While tuned to the channel you want to

watch or viewing connected equipment,

press HOME and select Favorites to

display the list. Press the yellow button to

add to the list. Your newly added item will

be listed at the top of the list. When you

continue to add items beyond the 18th

item, the item listed at the bottom of the

list will be automatically removed from the

list.

xTo delete from Favorites

Select the item to delete, then press the

blue button.

xTo move items in Favorites

Select the item to move, then press the

red/green button.

• Favorite channels and external inputs can

also be added using the OPTIONS button

on the remote control.

•Your Favorites list will be cleared each time

you run the Auto Program.

Wide Mode

The Wide Mode feature allows you to

select the screen display of your

preference. Based on the original signal

source, you may see black bars around

the picture or just on the both sides of the

screen. Sometimes you will see the

picture filled the full screen. This is due to

the signals your TV receives.

You can manually select available Wide

Mode settings as you watch your TV by

pressing the WIDE button on your remote

control or you can set your TV to Auto

Wide.

xTo set Auto Wide

Press HOME and select Settings, then

select the Screen settings.

Select Auto Wide and set to On.

xTo change the Wide Screen Mode

Press WIDE repeatedly to cycle through

the available modes.

Normal is available with 480i or 480p

sources only.

4:3 Original source 16:9 Original source

Standard-

definition source

High-definition source

Wide Zoom Wide Zoom

Normal Normal

This mode is not

available.

Full Full

Zoom Zoom

4:3 Original source 16:9 Original source

Using Features

Wide Mode with PC

Wide Mode is also available for the PC

settings. When a PC is connected to the

TV and HDMI input is selected, you can

change the PC Screen settings.

xTo change the Wide Screen Mode for

PC Timing

Press WIDE repeatedly to cycle through

the available modes while in the HDMI

input (PC timing) mode.

Inputs

Press INPUT to display the Input menu

and toggle through the external inputs to

select your video signal for viewing

including the TV mode. The inputs list

consists of TV mode and other equipment

connected to the TV.

You can label your external inputs to

identify them easily.

xTo Manage on Input

Press HOME and select Settings, then

select the Setup settings. Select the

Manage Inputs option in AV Setup. Press

V/v to highlight the video input (HDMI 1-2,

Video, Component) to which you want to

assign a label; press to select the

input of your choice.

xTo Manage Label

Press B/b to highlight one of the

displayed labels that corresponds to your

connected equipment, then press .

xTo Manage Enable

1Press B/b to select enable column.

2Press V/v to select Auto, Always or

Off. The selected input will be listed

always.

Incoming PC signal

Normal

Full 1

Full 2

800 × 600

Playing back Photo/

Music/Video via USB

You can enjoy photo/music/video files

stored in a Sony digital still camera or

camcorder through a USB cable or USB

storage device on your TV.

1Connect a supported USB device to

the TV.

2Press HOME.

3Press V/v to select Photo, Music, or

Video, then press .

The file or folder list appears.

4Press V/v/B/b to select a file or folder,

then press .

When you select a folder, select a file,

then press .

Playback starts.

• If you connect the USB device when USB

Auto Start is set to On (page 47), the

thumbnail view of the last played Photo/

Music/Video appears automatically.

xNotes when playing back files

• While the TV is accessing the data on

the USB device, observe the following:

– Do not turn off the TV.

– Do not disconnect the USB cable.

– Do not remove the USB device.

The data on the USB device may be

damaged.

• Sony will not be held liable for any

damage to, or loss of, data on the

recording media due to a malfunction of

any connected devices or the TV.

• USB playback is supported for the

following photo file formats:

– JPEG (JPEG format files with the extension

“.jpg” and conforming to DCF 2.0 or Exif

2.21)

• USB playback is supported for the

following music file format:

– MP3 (files with the extension “.mp3” that

have not been copyrighted)

• USB playback is supported for the

following video file format:

– MPEG1, MPEG2 (files with the extension

“.mpg”)

• USB Auto Start shows photo files in the

newest digital still camera folder (DCF-

compliant, highest-numbered “DCIM”

folder).

• USB Auto Start may not work

automatically when some digital still

cameras are connected.

• The file name and folder name are only

supported in English.

• When you connect a Sony digital still

camera, set the camera’s USB

connection mode to “Auto” or “Mass

Storage.” For more information about

USB connection mode, refer to the

instructions supplied with your digital

camera.

Using Features

• Use a USB storage device that is

compliant with USB Mass Storage Class

standards.

• The file system on the USB device

supports FAT16, FAT32 and NTFS.

Photo Frame

You can enjoy looking at photos, listening

to music, or seeing the clock and

calendar, at the same time.

You can enter photo frame mode using

any of the following methods:

You can switch the frame, e.g. image and

clock, full screen image or full screen

clock.

For more details, see page 47.

xTo select photo

You can select photos from USB memory,

using any of the following methods:

1Press HOME, and then select Photo

Frame Mode.

2Press OPTIONS, when you are playing

back the photo/music files.

1Press HOME and select Settings, then

Setup > Photo Frame Settings > Image

Selection.

Press to select the file from thumbnail

view.

2In photo frame mode, press OPTIONS >

Image Selection. Press to select the

file from thumbnail view.

3Press HOME, and select Photo. When

playing back a photo, press OPTIONS >

Photo Frame Mode to launch Photo

Frame with the selected photo.

(Continued)

xTo select music

You can select music from USB memory,

using any of the following methods:

xTo select Display mode

You can change the photo frame display

by selecting Display Mode (page 47).

• Image and Clock

•Full Screen Image

• Full Screen Clock

xTo select Clock Display mode

There are five calendar display modes.

When the Display Mode setting is set to

Image and Clock, you can set to

Calendar, Analog Clock or Digital

Clock. When the Display Mode setting is

set to Full Screen Clock, you can set to

Calendar, Calendar and Clock or Clock.

For more details, see page 47:

•Calendar

• Analog Clock

• Digital Clock

• Calendar and Clock

•Clock

xDuration

To save power, photo frame mode will

shut down after 24 hours of TV with power

off automatically. After running photo

frame mode for 24 hours, not use this

mode for at least one hour, to avoid panel

burn-in.

Duration time can be set to Duration in

Photo Frame Settings. For more details,

see page 47.

To avoid panel burn-in, the position of the

photo, clock and calendar are switched

automatically every hour.

1Press HOME and select Settings, then

Setup > Photo Frame Settings > Music

Selection.

Press to select the file from thumbnail

view.

2In photo frame mode, press OPTIONS >

Music Selection.

Press to select the file from thumbnail

view.

3Press HOME, and select Music. When

playing back music, press OPTIONS >

Photo Frame Mode to launch Photo

Frame with the selected music.

Using the Menus

Navigating through TV Menus

The HOME button allows you to access a variety of TV settings and USB media files.

1Press on the remote control to display the

menu options.

2Press V/v/B/b to navigate on the menu or adjust the

settings.

3Press to select or confirm.

4Press to exit.

The Favorites feature provides quick access to your frequently used items,

such as preferred TV channels or external inputs (e.g. game console, DVD

player). For details, see page 29.

The Photo, Music, and Video icons organize your photo, music, and video

files from USB connected equipment. Be sure to select the correct icon when

accessing files. Refer to the feature section for more information on these

icons (page 32).

You can select Photo Frame Mode which enables you to enjoy photo, music

and clock. For details, see page 33.

Favorites


Music

Video

Photo Frame

Mode

(Continued)

The Settings icon contains all of the necessary configurations to customize

your TV settings. The options you can select may vary. Unavailable options

are grayed out or not displayed.

Picture: adjust the picture on your TV to fit your viewing preference.

Sound: customize your sound settings to suit your audio preference. You can

also change the settings to output the sound to your connected audio

equipment.

Screen: adjust the size and shape of the images you see on the screen.

Channel: navigate your favorite channels and inputs and select the signal type,

as well as autoprogram channels. You can also customize the channels you see

and the labels assigned to them.

Parental Lock: set the password and limit access to programming based on

rating levels. You can also block channels and inputs.

Setup: modify and customize a variety of general setting options.

Eco: changes the settings related to power consumption.

Settings

Using the Menus

Using the Picture Settings

Option Description

Picture Mode

Customized

picture viewing

Displays the options selected in the Scene Select settings. When Scene

Select is set to General, the first three options below can be selected.

Vivid Select for enhanced picture contrast and sharpness.

Standard Select for standard picture settings. Recommended for home

entertainment.

Custom Select to store your preferred settings.

Cinema For film-based content. Suitable in a theater-like environment.

Graphics Optimizes picture quality for viewing graphics.

Reset Resets the current Picture settings to their defaults, except Picture Mode.

Backlight Adjust to brighten or darken the backlight.

Picture Adjust to increase or decrease picture contrast.

Brightness Adjust to brighten or darken the picture.

Color Adjust to increase or decrease color intensity.

Hue Adjust to increase or decrease the green tones.

Sharpness Adjust to sharpen or soften the picture.

Color

Temperature

White adjustment

Cool Select to give the white colors a bluish tint.

Neutral Select to give the white colors a neutral tint.

Warm Select to give the white colors a reddish tint.

Noise Reduction Select to reduce the picture noise level. Select from Auto, High, Medium,

Low and Off.

MPEG Noise

Reduction

Select to reduce the picture noise in MPEG-compressed videos. This is

effective when viewing a DVD or digital broadcast. Select from High, Medium,

Low and Off.

CineMotion Provides improved picture movement and reduces picture blur and graininess

for film-based content. Select Auto to represent original film-based content as

is.

(Continued)

• Available Picture options, including options in Advanced Settings depend on Scene Select

and Picture Mode.

Advanced

Settings

Reset Resets the advanced settings to the default values.

Adv. Contrast

Enhancer

Automatically adjusts backlight and contrast to the most

suitable settings judging from the brightness of the screen.

This setting is especially effective for dark scenes, and will

increase the contrast distinction of the darker picture scenes.

Select from High, Medium, Low and Off.

Black

Corrector

Enhances black areas of the picture for stronger contrast.

Select from High, Medium, Low and Off.

Gamma Adjusts the balance between bright and dark areas of the

picture.

Clear White Emphasizes white colors. Select from High, Low and Off.

Live Color Makes colors more vivid. Select from High, Medium, Low

and Off.

LED Motion

Mode

Lights up the backlight adequately, reducing blur in movies,

but the brightness decreases.

Option Description

Using the Menus

Using the Sound Settings

Option Description

Sound Mode

Customized

sound listening

Sets a sound mode. Sound Mode includes options best suited for video and

photographs, respectively.

Standard Optimizes sound quality for general content.

Music Lets you experience dynamic and clear sound, like that of a

concert.

Cinema Optimizes surround sound for movies.

Game Broadens your game-playing experience with superb sound

quality.

Sports Reproduces realistic sound, like that in a stadium.

Reset Resets the current Sound settings to their defaults, except MTS Audio,

Alternate Audio and Speakers.

Equalizer Adjust allows you to select your frequency response curve. Select Reset to

reset the Equalizer settings to the default values.

Sound Booster Select On to enhance treble/bass and reproduces dynamic sound, or Off to

provide natural sound.

Clear Voice Select On for spoken dialog.

Steady Sound Select On to stabilize the volume across all programs and commercials.

Select Off to disable this function.

Balance Adjust to emphasize left or right speaker balance.

Volume Offset Adjust the volume level of the current input relative to other inputs.

MTS Audio

Enjoy stereo,

bilingual and

mono programs

Stereo Select for stereo reception when viewing a program

broadcast in stereo.

Auto SAP Select to automatically switch the TV to second audio

programs when a signal is received. If no SAP signal is

present, the TV remains in Stereo mode.

Mono Select for mono reception. Use to reduce noise during weak

stereo broadcasts.

Alternate Audio

Digital channels

only

Select among the available options to switch among the alternate audio

streams. The program you are tuned to may be broadcasted in a different

language in the alternate audio streams.

Speakers TV Speakers Select to use the TV speakers.

Audio System Select to use an external audio system for the TV sound. By

selecting this option you are disabling the TV speakers.

Audio Out Variable Adjusts the volume with the TV’s remote control, when using

an external audio system.

Fixed Adjusts the volume using the connected audio system’s

remote control.

(Continued)

•MTS Audio is only available for analog programs.

•Alternate Audio is only available if the program is broadcast with alternate audio streams.

• You can also access Sound Mode, MTS Audio and Alternate Audio by using the OPTIONS

button on the remote control.

Using the Menus

Using the Screen Settings

•Normal in the Wide Mode setting is not available when you are watching a 720p, 1080i or 1080p

source.

• If 4:3 Default is set to anything but Off, the Wide Mode setting changes only for the current

channel. When you change channels (or inputs), Wide Mode is automatically replaced with the

4:3 Default setting for 4:3 sources. To retain the current Wide Mode setting as channels and

inputs are changed, set 4:3 Default to Off.

•4:3 Default is not available if Auto Wide is set to Off.

Option Description

Wide Mode Wide Zoom Fills the screen with minimum distortion.

Normal Select to display 4:3 picture in original size when the original

source is 4:3.

Full Select to enlarge the picture horizontally to fill the screen when

the original source is 4:3 (Standard definition source). When the

original source is 16:9 (High-definition source), select this mode

to display the 16:9 picture in its original size.

Zoom Select to enlarge the original picture without distorting the aspect

ratio.

Auto Wide On Select On to automatically change Wide Mode setting based on

the content.

Off If frequent screen changes are disturbing to you, select Off.

Choose one of the Wide Mode options when this function is set

to Off.

4:3 Default

Select the default

Screen Mode to

use for 4:3

sources

Wide Zoom Enlarges the 4:3 picture to fill the 16:9 screen, displaying as

much of the original image as possible.

Normal Select to display the 4:3 picture in its original size.

Off Select to continue using the current Wide Mode setting when the

channel or input is changed.

Auto Display

Area

Select On to automatically adjust the picture to the most appropriate display

area.

Select Off to disable this function.

Display Area Full Pixel Displays pictures in their original size when parts of the picture

are cut off (available depending on the TV model).

+1 Displays pictures in their original size.

This option is only available for Digital TV and HDMI/MHL input

signals (non 1080i and 1080p video formats).

Normal Displays pictures in their recommended size.

-1 Enlarges the picture so that the edges are outside the visible

display area.

Horizontal

Center

Allows you to move the position of the picture left and right. (Available in Wide

Zoom and Zoom.)

(Continued)

• For the PC Input Signal Reference Chart, see page 53.

Option Description

Vertical Center Allows you to move the position of the picture up and down. (Available in Wide

Zoom and Zoom.)

PC Settings When a PC is connected to the TV, the PC settings screen appears instead of

the Screen settings.

You can also select the PIP feature which allows you to view two pictures

simultaneously from OPTIONS button (page 28).

Wide Mode Normal Select to display in the original image size.

Full 1 Select to enlarge the picture to fill the display area,

keeping its original aspect ratio.

Full 2 Select to enlarge the picture to fill the display area.

Reset Resets all PC settings to the default values.

Horizontal

Center

Allows you to move the position of the picture left and right.

Vertical

Center

Allows you to move the position of the picture up and down.

Using the Menus

Using the Channel Settings

• You should run Auto Program after changing the Signal Type setting.

• Running Auto Program will clear the Favorites list.

• Channels that you set to be hidden can be accessed by the 0-9 and buttons.

• You can set channels to be hidden that are automatically set in Auto Program.

Option Description

Signal Type Cable Select if you are receiving cable channels via Cable TV

provider.

Antenna Select if you are using an antenna.

Auto Program Automatically sets up the channel list on the TV for all receivable channels.

1Select Auto Program.

2Select OK to start Auto Program.

Add Digital

Channels

1Select Add Digital Channels.

2Select OK to add digital channels.

Show/Hide

Channels

Allows you to show or hide channels that appear when you use the CH +/–

buttons.

1Press V/v to scroll through the channels until you find the channel you

want to show or hide. Then press to select it.

2Press V/v to determine if the channel will be shown or hidden. Then press

to select it.

Edit Channel

Labels

Allows you to assign labels (such as station call letters) to channel numbers.

1Press V/v to scroll through the channel numbers. Then press to select

the channel number that you want to assign a label.

2Press V/v to scroll through the label characters (A-Z, 0-9, etc.). Press b to

move to the next character. Repeat the previous steps to add up to seven

characters to the label. When finished, press .

Analog Fine

Tune

Allows you to fine-tune the selected analog channel manually if you feel that a

slight tuning adjustment may improve picture quality. Select Auto to adjust to

the most appropriate analog channel.

Using the Parental Lock Settings

Option Description

Password The Parental Lock settings allow you to set up the TV to block programs

according to their content and rating levels. Use 0-9 on the remote control to

enter a four-digit password. The first time you create a password, confirm the

password by entering it again.

Change

Password

Select to change your password.

Country U.S.A. Select to use U.S.A. ratings (page 45).

Canada Select to use Canadian ratings (page 46).

Rating Off Turn Parental Lock off. No programs are blocked from

viewing.

Child Maximum ratings permitted are:

U.S.: TV-Y, TV-G, G

Canada: C, G, TV-Y

Youth Maximum ratings permitted are:

U.S.: TV-PG, PG

Canada: C8+, PG, 8 ans+, TV-PG

Young Adult Maximum ratings permitted are:

U.S.: TV-14, PG-13

Canada: 14+, 13 ans+, TV-14

Custom Select to set ratings manually.

U.S.: See page 45 for details.

Canada: See page 46 for details.

Downloadable

U.S. Rating

(Available only

in U.S.A.

where advanced

ratings exist)

Off Turn Downloadable U.S. Rating off. No programs that contain

downloadable ratings are blocked from viewing.

Custom Select to block programs based on downloadable ratings.

Clear All Select to clear the entire downloadable rating system.

Unrated

(Available only

when Country is

set to U.S.A.)

Allow Allows programs and movies that are broadcasted without a

rating.

Block Blocks all programs and movies that are broadcasted without

a rating.

Channel Block Allows you to block channels regardless of program ratings.

To View a Blocked Channel

Press when tuned to the blocked channel then enter the password.

External Input

Block

Allows you to block external inputs regardless of program ratings.

To View a Blocked External Input

Press when tuned to the blocked input then enter the password.

Using the Menus

• You need your password for any future access into the Parental Lock settings. If you lose your

password, see “Lost password” on page 61.

• Selecting Clear All will delete the current Downloadable U.S. Rating menu and the menu will

no longer be available until the TV is tuned to a channel that contains downloadable ratings.

• If you block unrated TV programs, be aware that the following types of programs may be

blocked: programs broadcasted from another country, emergency broadcasts, political

programs, sports, news, public service announcements, religious programs and weather.

US Models: Selecting Custom Parental Lock Rating Options

To select custom rating options for the U.S., select U.S.A. in the Country setting (page

44).

• To ensure maximum blocking capability, set the Age-Based Ratings.

Option Description

Movie Rating G All children and general audience.

PG Parental guidance suggested.

PG-13 Parental guidance for children under 13.

RRestricted viewing, parental guidance is suggested for

children under 17.

NC-17 and XNo one 17 or under allowed.

TV Rating

Block programs

by their rating,

content or both

Age-Based Ratings

TV-Y All children.

TV-Y7 Directed to children age 7 and older.

TV-G General audience.

TV-PG Parental guidance suggested.

TV-14 Parents strongly cautioned.

TV-MA Mature audience only.

Content-Based Ratings

FV Fantasy violence.

DSuggestive dialog.

LStrong language.

SSexual situations.

VViolence.

Canadian Models: Selecting Custom Parental Lock Rating

Options

To select custom rating options for Canada, select Canada in the Country setting (page

44).

Viewing Blocked Programs

You can view blocked programs by entering your password. Press when tuned to a

blocked program, then enter the password. This temporarily deactivates the parental

control feature. To reactivate the Parental Lock settings, turn off the TV. When the TV is

turned on again, your Parental Lock settings are reactivated.

Option Description

English Rating C All children.

C8+ Children 8 years and older.

GGeneral programming.

PG Parental guidance.

14+ Viewers 14 and older.

18+ Adult programming.

French Rating G General programming.

8 ans+ Not recommended for young children.

13 ans+ Not recommended for ages under 13.

16 ans+ Not recommended for ages under 16.

18 ans+ Programming restricted to adults.

U.S.A. Rating See “US Models” on page 45 for details.

Using the Menus

Using the Setup Settings

Option Description

Photo Frame

Settings

Display Mode Allows you to select the display mode. Select from Image and

Clock, Full Screen Image or Full Screen Clock. See page 34.

Clock Display Allows you to select the clock display. Select from Calendar,

Analog Clock, Digital Clock, Calendar and Clock or Clock.

Calendar and Clock and Clock can be displayed only when

Display Mode is Full Screen Clock.

Audio

Application

Music You can enjoy music with this function.

Off Turns off the music.


Selection

Select image.

Music

Selection

Select music.

Slideshow

Setting

Slideshow You can play a slideshow of photos.

Single View Displays one photo only.

Music

Playback

Setting

All Tracks Listen to all music tracks.

Single Track Set to listen to a single music track.

Duration Selects the time period (1 h, 2 h, 4 h or 24 h) after which the TV

automatically switches to standby mode.

First day of the

week

Set Sunday or Monday as the first day of the week on the

calendar.

USB Auto

Start

Select On to show the thumbnail view automatically when the TV is turned on and

a digital still camera or other device containing photo, music or video files is still

connected to the USB port then turned on.

(Continued)

• You can turn on Closed Captions (CC) options (On, Off or On when Muting) by pressing the

CC button on the remote control.

Closed

Captions

(CC)

Allows you to select from several closed caption modes (for programs that are

broadcast with closed captioning).

CC Display On Closed Captions (CC) is turned on.

Off Closed Captions (CC) is turned off.

On when

Muting

Closed Captions (CC) is turned on when the TV

is muted.

Analog CC Allows you to select basic analog (EIA-608) closed caption

options.

CC1, CC2,

CC3, CC4

Displays a printed version of the dialog or sound

effects of a program. (Should be set to CC1 for

most programs.)

Text1, Text2,

Text3, Text4

Displays network/station information presented

using either half or the whole screen (if available).

Digital CC When the digital closed caption service is available, select from

the Service 1-6 or CC1-4.

Digital CC

Options

Allows you to make additional settings for digital closed caption

options. Select As Broadcast or Custom. The Custom option is

available on the Digital CC setting.

Custom Allows you to customize the following settings:

Character

Size

Small, Standard, Large

Character

Style

Style 1-7

Character

Color

Color 1-8

Character

Opacity

Solid, Translucent

Edge Type None, Raised, Depressed,

Outline, Left Shadow,

Right Shadow

Edge Color Color 1-8

Background

Color

Color 1-8

Background

Opacity

Solid, Translucent

Audio

Description

Provides an audio description (narration) of visual information, when available.

Option Description

Using the Menus

• You can assign following labels for each input (except TV):

–, Cable, Satellite, VCR, DVD/BD, Home Theater, Game, Camcorder, Digital Camera, PC,

Edit

•“–” indicates that no labels are assigned.

• If you select Edit, you can edit video labels. Follow the same steps for Edit Channel Labels on

page 43.

Option Description

Info

Banner

Displays the information related to the input signal you are watching. Select Small

to display minimal channel and program title or select Large to display detailed

channel and program information along with the TV icon if you are viewing the TV.

Select Hidden to hide information about the TV channel or program. This

information will appear if it is available from the broadcaster.

Info Banner appears on the screen each time the channel and external inputs

are changed or when DISPLAY on the remote control is pressed.

Clock/Timers Sleep Timer Set the time in minutes (Off, 15, 30, 45, 60, 90, or 120) that you

would like the TV to remain on before shutting off automatically.

On Timer Turns on the TV from standby mode at a time you set, and tuned

to a TV channel or input of your preference. Before setting this

function, make sure you set the correct current Time.

Current Time You can set the current time manually. Select Date (Month/Day/

Year) to set the date, then select Time to set the time.

• This TV does not have a battery powered backup for the

clock. Therefore, if there is a power failure or if you disconnect

the power cord, be sure to reset the current date and time.

Initial Setup If you miss the Initial Setup when you first connect the TV or if you want to scan

all receivable channels, select Initial Setup. Follow the instructions on the screen.

Some settings such as Picture, Sound, and Parental Lock will not be affected

by this Initial Setup. If you wish to return your TV to factory settings, please see

the Troubleshooting section on page 56.

Language Select to display all on-screen settings in your language of choice: English,

Español, Français.

Startup Logo Select On to display the logo when the TV is turned on. Select Off to disable it.

AV Setup Manage Inputs Assigns a name to external equipment.

Select Auto to display names when the equipment is connected

and/or the signal of the equipment is ready to be shown, or

Always to display regardless of connection status or Off to

disable input (only for TV).

Video/

Component

Selection

Select Auto to have the TV detect and switch between the

Video or Component when Video or Component is connected.

(Continued)

Option Description

BRAVIA Sync

Settings

Communicates with equipment compatible with the BRAVIA Sync Control

function.

BRAVIA Sync

Control

Links the operations of the TV and the equipment.

For specific Sony equipment compatible with BRAVIA Sync

Control, this setting is applied automatically to the connected

equipment when set to On.

Device Auto

Power Off

Select On to have your connected equipment with BRAVIA

Sync Control function power off automatically when the TV is

turned off.

Select Off to disable this function. This feature is available when

BRAVIA Sync Control is On.

TV Auto Power

Select On to control your TV’s power on from your connected

equipment (except MHL-compatible device) with BRAVIA Sync

Control function. Select Off to disable this function. This feature

is available when BRAVIA Sync Control is On.

Auto Input

Change(MHL)

Select On to switch the TV input to the corresponding device

connected with an MHL cable.

BRAVIA Sync

Device List

Displays a list of equipment with BRAVIA Sync Control

function connected to the TV.

Device Control

Keys

Select button functions of the TV’s remote control to operate the

connected equipment.

None Deactivates the control by the TV’s remote

control.

Normal Enables basic operations, such as navigation

buttons (up, down, left or right, etc.).

Tuning Keys For basic operations and operation of channel-

related buttons, such as CH +/– or 0-9, etc. Useful

when you control a tuner or set-top box, etc; via

the remote control.

Menu Keys For basic operations and operation of the HOME/

OPTIONS buttons. Useful when you select menus

of a BD player, etc; via the remote control.

Tuning and

Menu Keys

For basic operations and operation of channel-

related buttons and HOME/OPTIONS buttons.

•Press OPTIONS while the equipment supporting BRAVIA Sync Control is

connected to display the Device Control options. The Device Control option

provides access to the Home (Menu), Options and Content List of your

connected equipment with your TV remote control.

• Some equipment with BRAVIA Sync Control does not support the Device

Control feature.

•BRAVIA Sync Settings must be setup on the connected equipment.


Adjustments

Lock

Select Lock so no adjustment can be made to items grayed out, except Picture

Mode and CineMotion.

Select Unlock to allow adjustment to any of the Picture settings.

Using the Menus

Product

Support

Contact Sony Sony contact information is available on this screen for your

convenience. TV specific information such as Model Name,

Serial Number, Software Version and downloadable ratings (if

available from the TV) are displayed here.

Signal

Diagnostics

Press to display the diagnostics information for the current

signal.

Option Description

Using the Eco Settings

Option Description

Reset Resets the current Eco settings to the default values.

Power Saving Select from Off, Low, High, Picture Off to adjust your TV’s power consumption.

By selecting the High option, you will reduce the power consumption more than

the other available settings.

While Picture Off is set, pressing VOL +/– or MUTING buttons will not disable this

function. Press other buttons to disable it.

Idle TV

Standby

Select to automatically power off the TV after 1 h, 2 h, or 4 h when no buttons are

pressed on the remote control or the TV. Select Off to disable this function.

Light Sensor Optimizes the picture settings according to the ambient lighting.

Auto Shut Off Select On to automatically power off the TV when no input signal is detected for a

certain period of time. Select Off to disable this function.

Other Information

PC Input Signal Reference Chart for

HDMI IN

After connecting the PC to the TV, set the output signal from the PC according to the

chart below.

xKDL-32R421A/32R400A

xKDL-46R453A/46R450A/40R471A/40R450A

* The 1080p timing when applied to the HDMI input will be treated as a video timing and not PC

timing. This affects Picture settings and Wide Mode settings. To view PC content set Wide

Mode to Full, and Display Area to Full Pixel.

• This TV’s HDMI input does not support Sync on Green or Composite Sync.

• Your PC must support one of the above PC input signals to display on the television.

• In plug and play, signals with a 60 Hz vertical frequency will be detected automatically. (PC

reboot may be necessary.)

Resolution

Horizontal

frequency (kHz)

Vertical

frequency (Hz)

Standard

Signals Horizontal

(Pixel)

×Vertical

(Line)

VGA 640 × 480 31.5 60 VGA

SVGA 800 × 600 37.9 60 VESA Guidelines

XGA 1,024 × 768 48.4 60 VESA Guidelines

WXGA 1,280 × 768 47.4 60 VESA

1,280 × 768 47.8 60 VESA

1,360 × 768 47.7 60 VESA

Resolution

Horizontal

frequency (kHz)

Vertical

frequency (Hz)

Standard

Signals Horizontal

(Pixel)

×Vertical

(Line)

VGA 640 × 480 31.5 60 VGA

SVGA 800 × 600 37.9 60 VESA Guidelines

XGA 1,024 × 768 48.4 60 VESA Guidelines

WXGA 1,280 × 768 47.4 60 VESA

1,280 × 768 47.8 60 VESA

1,360 × 768 47.7 60 VESA

SXGA 1,280 × 1,024 64.0 60 VESA

HDTV* 1,920 × 1,080 67.5 60 CEA-861*

Using a Wall-Mount Bracket

Your TV can be mounted on a wall using a Wall-Mount Bracket (not supplied) out of the

box as packaged. If the Table-Top Stand is attached to the TV, the TV may require

detaching the Table-Top Stand.

Prepare the TV for the Wall-Mount Bracket before making cable connections.

Sony does not supply the Wall-Mount Bracket or the installing service. For product

protection and safety reasons, Sony strongly recommends that installing of your

TV on the wall be performed by qualified professionals. Do not attempt to install it

yourself.

• Follow the instruction guide provided with the Wall-Mount Bracket for your model.

Sufficient expertise is required in installing this TV, especially to determine the strength

of the wall for withstanding the TV’s weight.

• The length of the screw for Wall-Mount Bracket differs depending on the mounting

hook thickness. Please see below illustration.

• Be sure to store the unused screws and Table-Top Stand in a safe place until you are

ready to attach the Table-Top Stand. Keep the screws away from small children.

• Read the supplied Safety Booklet for additional safety information.

KDL-40R471A/40R450A/32R421A/32R400A: 6.5~10 mm

KDL-46R453A/46R450A: 8~12 mm

Screw

KDL-40R471A/40R450A/32R421A/32R400A: M4

KDL-46R453A/46R450A: M6

Mounting Hook

Hook attachment on rear of TV set

Other Information

For KDL-46R453A/46R450A only

Secure the Attachment Parts to the rear of the TV using the supplied screws.

Screw (+PSW 6 × 16)

(not supplied)

Thick and soft cloth

Screw (+PSW 4 × 12)

(supplied)

Attachment parts for Wall-Mount

Bracket (supplied)

Mounting Hook

(not optional accessory)

Troubleshooting

Many of the poor pictures and poor sound conditions are related to improper connection

of the cables; refer to the Quick Setup Guide provided for connections.

If you have questions, service needs, or require technical assistance related to the use

of your Sony TV even after you read this operating instructions manual, contact the

following:

For US Support:

http://www.sony.com/tvsupport or call 1-800-222-SONY (7669)

For Canadian Support:

http://www.sony.ca/support or call 1-877-899-SONY (7669)

xThings to consider

• Check the input selection by pressing the INPUT button. You may be watching the

wrong input.

• If you cannot hear sound from the TV, you may have accidentally pressed the MUTING

button on your remote control; press the MUTING button again or press VOL + to

deactivate muting, or set Speakers to Audio System.

• If the remote control is not functioning properly, the batteries may be installed

incorrectly or may be low or an object or light may be interfering with the remote

control.

• To reset the TV to factory default settings:

1Turn on the TV.

2Press and hold down the V button on the remote, press the "/1 button on the TV set.

(The TV will turn itself off, then back on again.)

3Release the V button when the TV is turned on.

IMPORTANT: The factory reset will clear all of your customized settings including the

Parental Lock setting.

When the Password is lost or cannot be remembered, enter the master password: 4357.

This password clears your previous password and allows you to enter a new password.

Condition Explanation/Solution

No picture

No picture • Check the Power Saving settings (see page 52).

Cannot receive any

channels

• Make sure the power cord is connected securely.

• Turn on the power of the TV.

• Check cable/antenna connections.

• Make sure the Signal Type setting is correct for your TV signal

source.

Other Information

TV is locked to one

channel

•Perform Auto Program to add receivable channels that are not

present in the TV’s memory (see pages 20 and 43).

Cannot receive or select

channels

•Perform Auto Program to add receivable channels that are not

present in the TV’s memory (see pages 20 and 43).

• To receive or select cable channels, make sure that Signal Type

in the Channel settings is set to Cable (see page 43). To receive

or select UHF channels over an antenna, make sure Signal Type

is set to Antenna.

The TV turns off

automatically

• Check if Sleep Timer is activated (see page 49).

• Check Idle TV Standby in the Eco settings.

• Check Duration of Photo Frame Settings.

• Check Duration if TV is turned on by On Timer.

No picture from some

video sources

• Check the connection between the optional video equipment

and the TV.

•Press INPUT on the remote control (see page 31).

Poor picture

Picture quality not as

good as viewed at the

store

• Picture quality depends on the signal content. See Quick Setup

Guide (supplied) to display the best possible picture for that

signal.

Broadcast HD formats

have poor quality

• Content and signal quality are controlled by the signal provider.

Many HD channels and content are actually upscaled versions of

standard-definition broadcasts. The picture is affected by the

quality of the signal received, which varies between channel and

program.

Double images or ghosts • Check cable/antenna connections.

• Check the antenna location and direction.

Only snow and noise

appear on the screen

• Check if the antenna is broken or bent.

• Check if the antenna has reached the end of its serviceable life.

(3-5 years in normal use, 1-2 years at the seaside.)

Dotted lines or stripes • Keep the TV away from noise sources such as cars, motorcycles,

or hair-dryers.

• If using 300 ohm twin lead, move the excess lead away from the

TV or try using 75-ohm coaxial cable instead.

No color / Dark picture /

Color is not correct / The

picture is too bright

• Adjust the Picture Mode options in the Picture settings (see

page 37).

• If you set the Power Saving mode to Low or High, it will

enhance the black level.

Noisy picture • Make sure that the antenna is connected using a 75-ohm coaxial

cable (not supplied).

• Keep the antenna cable away from other connecting cords.

• To avoid TV interference, make sure to use an undamaged

antenna cable.

Condition Explanation/Solution

(Continued)

Blurry picture / Poor color • Transporting the TV from a cold to a warm location or a sudden

change in room temperature may cause moisture condensation,

resulting in a blurry picture or poor color. Turn off your TV and

wait a few hours before powering on again.

No sound / Noisy sound

No sound but good


• Check the volume control.

•Press MUTING or VOL + so that “Muting” disappears from the

screen (see pages 23 and 24).

•Set Speakers to TV Speakers in the Sound settings (see page

39). If it is set to Audio System, sound is not output from the TV’s

speakers regardless of the TV’s volume control.

• When using HDMI input with Super Audio CD or DVD-Audio,

DIGITAL AUDIO OUT (OPTICAL) may not provide an audio

signal.

• When tuned to a digital channel with Alternate Audio, the

broadcaster may not be broadcasting your preferred Alternate

Audio language. Press OPTIONS, highlight and select Alternate

Audio, and change the Alternate Audio language (see page

39).

Audio noise • Make sure that the antenna is connected using a 75-ohm coaxial

cable (not supplied).

• Keep the antenna cable away from other connecting cords.

• To avoid TV interference, make sure to use an undamaged

antenna cable.

No audio or low audio

with Home Theater

System

•Set Speakers to Audio System in the Sound settings (see page

39).

•Set Audio Out to Fixed in the Sound settings (see page 39).

No color / Irregular


• Verify that the Video/Component Selection (see page 49) is set

to the current input type in use. We suggest leaving this setting to

Auto.

BRAVIA Sync

Cannot find connected

BRAVIA Sync HDMI

device

• Make sure that the BRAVIA Sync Control is set up on both the

TV and the optional device compatible with BRAVIA Sync (see

page 27).

Second A/V receiver is

not listed on the BRAVIA

Sync Device List

• Only one A/V receiver may be used with the BRAVIA Sync and

BRAVIA Sync Control functions at one time (see page 50).

Condition Explanation/Solution

Other Information

PC connection

No picture / No signal • Confirm the PC is correctly connected to the TV with the HDMI

IN.

• Ensure the output signal from the PC is one of the formats listed

on page 53.

• Turn the PC off. Confirm the PC connection and restart the PC.

Plug-and-play will auto-detect the TV and correctly set up PC

timing.

• Verify the PC is not in standby or hibernation mode.

Poor Picture • Adjust the resolution (see page 53).

General

TV screen feels warm • Due to the thin profile of this television, the heat generated by the

LCD panel backlight and supporting electronics will be more

noticeable. This is normal operation and not a cause for concern.

One or more promotional

logo(s) appears (appear)

on the screen. (Demo

Mode)

•Press RETURN on the remote control to suspend Demo Mode.

Then, press HOME, select Settings and proceed with Initial

Setup in the Setup settings. Be sure to select Home on the

viewing environment (Location) step.

Wide Mode changes

automatically

• The current Wide Mode setting is automatically replaced with the

4:3 Default setting when you change the channel or video input,

if 4:3 Default in the Screen settings is set to other than Off. If you

want to lock in Wide Mode selected with WIDE on the remote

control, set 4:3 Default to Off in the Screen settings (see page

41).

• Check the Auto Wide option in the Screen settings (see page

41).

Suddenly the picture

gets smaller

• The picture gets smaller during the commercials due to the

method in which the provider broadcasts their content. When HD

content channels switch to SD content (commercials), the picture

may be small with a black border.

•Auto Wide will not expand the picture during these content

changes since the content information is regulated by the

channel signal provider. You can manually change the Wide

Mode if you prefer (see page 30). This setting will remain in

effect until you change the channel or input or manually change

the Wide Mode again.

“Black box” on screen • You have selected a text option and no text is available (see

page 48). To turn off this feature, set the CC Display option to

Off. If you were trying to select closed captioning, select CC1

instead of Text1-4.

Condition Explanation/Solution

(Continued)

Black bands appear at

the edges of the screen

• Some wide screen programs are filmed in aspect ratios that are

greater than 16:9 (this is especially common with theatrical

releases). Your TV will show these programs with black bands at

the top and bottom of the screen. For more details, check the

documentation that came with your DVD/Blu-ray (or contact your

program provider).

• Programs in 4:3 aspect ratio will have bands on left and right

sides of the screen.

• Programs broadcast in HD formats (720p and 1080i) with 4:3

content will commonly have black bands on the left and right

sides of the screen which are added by the broadcaster (see

image on left).

• Some cable and satellite set-top boxes can also control the size

of the picture. If you are using a set-top box, refer to the

manufacturer of the set-box for more information.

•Auto Wide will not expand the picture when the black bands on

the sides of the screen are added by the broadcaster. You can

manually change the Wide Mode to Wide Zoom, or Zoom to fill

the screen, which will remain in affect until you change the

channel or input or manually change the Wide Mode again.

Certain programs on

DVD or other digital

sources display a loss of

detail, especially during

fast-motion or dark

scenes

• This is due to the digital compression of the source content used

by certain digital broadcasts and DVDs which may cause your

TV’s screen to display less detail than usual, or cause artifacts

(small blocks or dots, pixelations) to appear on your screen.

These signal compressions are more visible and are dependent

on the clarity and resolution of the TV.

Remote control does not

operate

• To determine if the problem is with the remote control or not,

press a button on the TV.

• Check the polarity of the batteries or replace the batteries.

• Point the remote control at the remote control sensor located at

the front of the TV.

• Keep the remote control sensor area clear from obstacles.

• Fluorescent lamps can interfere with your remote control

operation; try turning off the fluorescent lamps.

Some digital cable

channels are not being

displayed

• Certain cable companies have limitations on the broadcast of

digital cable channels. Check with your cable company for more

information.

• The digital cable channel may be set to Hidden in the Show/

Hide Channels setting (see page 43).

Some photo, music, or

video files are not

displaying from my USB

equipment

• The accessible file or folder limit in a directory is 1,000 for USB

connected equipment. This limit includes non-supported files or

just folders. Files or folders are populated based on their time

stamps. Photo, music files or folders exceeding the limit will not

be displayed.

Photo images appear

small in the screen

• Set display size to expanded.

• Whether or not photo images can or cannot be displayed in full-

screen depends on the resolution or aspect ratio of the file.

Condition Explanation/Solution

Other Information

Photo images or folders

take time to display

• Depending on the image dimension, file size, and number of files

in a folder, some photo images or folders take time to display.

• The first time a camera is connected to the TV via USB cable, it

may take up to a couple of minutes for the photos to display.

Lost password • Select the Password settings on the Parental Lock settings,

then enter the following master password: 4357. This password

clears your previous password and allows you to enter a new

password (see page 44).

How to reset the TV to

factory settings

• Turn on the TV. While holding down V on the remote control,

press "/1 on the TV. (The TV will turn itself off, then back on

again.) Release V.

IMPORTANT: The reset will clear all of your customized settings

including the Parental Lock setting.

The TV surrounds

become warm

• When the TV is used for an extended period, the TV surrounds

become warm. You may feel hot when touching there by the

hand.

Condition Explanation/Solution

Important Notices

For Customers in Canada

This Class B digital apparatus complies with Canadian

ICES-003.

Pour les clients résidant au Canada

Cet appareil numérique de la classe B est conforme à la

norme NMB-003 du Canada.

FCC Related Information

This equipment has been tested and found to comply with

the limits for a Class B digital device, pursuant to Part 15 of

the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and

can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no

guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful

interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more

of the following measures:

❑Reorient or relocate the receiving antenna.

❑Increase the separation between the equipment and

receiver.

❑Connect the equipment into an outlet on a circuit

different from that to which the receiver is connected.

❑Consult the dealer or an experienced radio/TV

technician for help.

Note

This television includes a QAM demodulator which should

allow you to receive unscrambled digital cable television

programming via subscription service to a cable service

provider. Availability of digital cable television programming

in your area depends on the type of programming and signal

provided by your cable service provider.

Declaration of Conformity

Trade Name: SONY

Model: KDL-46R453A/KDL-46R450A/KDL-40R471A/

KDL-40R450A/KDL-32R421A/KDL-32R400A

Responsible Party: Sony Electronics Inc.

Address: 16530 Via Esprillo,

San Diego, CA 92127 U.S.A.

Telephone Number: 858-942-2230

This device complies with part 15 of the FCC rules.

Operation is subject to the following two conditions: (1)

This device may not cause harmful interference, and (2)

this device must accept any interference received,

including interference that may cause undesired

operation.

Pursuant to FCC regulations, you are cautioned that any

changes or modifications not expressly approved in this

manual could void your authority to operate this

equipment.

Other Information

Specifications

System

Television system NTSC: American TV standard

ATSC (8VSB terrestrial): ATSC compliant 8VSB

QAM on cable: ANSI/SCTE 07 2000 (Does not include CableCARD functionality)

Channel coverage Analog terrestrial: 2 - 69 / Digital terrestrial: 2 - 69

Analog Cable: 1 - 135 / Digital Cable: 1 - 135

Panel system LCD (Liquid Crystal Display) Panel, LED Backlight

Speaker output 8 W + 8 W

Input/Output jacks

CABLE/ANTENNA 75-ohm external terminal for RF inputs

VIDEO IN VIDEO: 1 Vp-p, 75 ohms unbalanced, sync negative

AUDIO: 500 mVrms (Typical) / Impedance: 47 kilohms

COMPONENT IN YPBPR (Component Video): Y: 1.0 Vp-p, 75 ohms unbalanced, sync negative / PB: 0.7 Vp-p,

75 ohms / PR: 0.7 Vp-p, 75 ohms / Signal format: 480i, 480p, 720p, 1080i, 1080p

AUDIO: 500 mVrms (Typical) / Impedance: 47 kilohms

HDMI IN 1(ARC)

HDMI IN 2/MHL

HDMI: Video: 480i, 480p, 720p, 1080i, 1080p, 1080/24p

MHL: Video: 480i, 480p, 720p, 720/30p, 1080i, 1080/30p, 1080/24p

Audio: Two channel linear PCM 32, 44.1 and 48 kHz, 16, 20 and 24bits, Dolby Digital

PC Input (see page 53)

AUDIO OUT 500 mVrms (typical)

DIGITAL AUDIO OUT

(OPTICAL)

PCM/Dolby Digital optical signal

USB Photo, Music and Video

Model name KDL-46R450A

KDL-46R453A

KDL-40R471A KDL-40R450A

Power and others

Power requirement 110-240 V AC, 50/60 Hz (U.S.A./Canada 120 V AC, 60 Hz)

Power consumption 109 W 89 W

in use

in standby Less than 0.2 W with 120 V AC and less than 0.3 W with 240 V AC

Screen size*

46 40

(measured diagonally)

(inches)

(cm) 116.8 101.6

Display resolution 1,920 dots (horizontal) × 1,080 lines (vertical)

Speaker/Full range (2) (mm)

(inches)

40 × 100

(1 5/8 × 4)

Dimensions* with stand (mm)

(inches)

1053 × 641 × 181

41 1/2 × 25 1/4 × 7 1/4

923 × 574 × 184

36 3/8 × 22 5/8 × 7 1/4

923 × 567 × 181

36 3/8 × 22 3/8 × 7 1/4

without stand (mm)

(inches)

1053 × 622 × 76

41 1/2 × 24 1/2 × 3

923 × 548 × 76

36 3/8 × 21 5/8 × 3

wall-mount hole pattern

(mm) 300 × 300 200 × 100

wall-mount screw size

(mm)

M6 (length: refer to diagram

on page 54) M4 (length: refer to diagram on page 54)

Mass* with stand (kg)

(lb.)

9.4

20.8

7.4

16.3

without stand (kg)

(lb.)

9.1

20.1

7.1

15.7

(Continued)

• Optional accessories availability depends on its stock.

• Design and specifications are subject to change without notice.

* Dimensions and mass are approximate values.

Supplied accessories Remote control RM-YD092 (1)/Size AAA batteries (2)/Operating Instructions (1)/Quick Setup

Guide (1)/Warranty Card (1)/Safety and Regulatory Booklet (1)/Software License (1)/Stand

installation guide (1)/Table-Top Stand (1 set)/Screw (4) (KDL-46R453A/46R450A), Screw (2)

(KDL-40R471A/40R450A)/Attachment Parts (2) (KDL-46R453A/46R450A only)

common to all models

Optional accessories Connecting cables / Support Belt Kit

Model name KDL-32R421A KDL-32R400A

Power and others

Power requirement 110-240 V AC, 50/60 Hz (U.S.A./Canada 120 V AC, 60 Hz)

Power consumption 60 W

in use

in standby Less than 0.3 W with 120 V AC and less than 0.4 W with 240 V AC

Screen size*

31.5 (32 class)

(measured diagonally)

(inches)

(cm) 80.0

Display resolution 1,366 dots (horizontal) × 768 lines (vertical)

Speaker/Full range (2) (mm)

(inches)

40 × 100

(1 5/8 × 4)

Dimensions* with stand (mm)

(inches)

731 × 466 × 171

28 7/8 × 18 3/8 × 6 3/4

731 × 461 × 163

28 7/8 × 18 1/4 × 6 1/2

without stand (mm)

(inches)

731 × 441 × 76

28 7/8 × 17 3/8 × 3

wall-mount hole pattern

(mm) 100 × 100

wall-mount screw size

(mm) M4 (length: refer to diagram on page 54)

Mass* with stand (kg)

(lb.)

5.0

11.1

without stand (kg)

(lb.)

4.8

10.6

Supplied accessories Remote control RM-YD092 (1)/Size AAA batteries (2)/Operating Instructions (1)/Quick Setup

Guide (1)/Warranty Card (1)/Safety and Regulatory Booklet (1)/Software License (1)/Stand

installation guide (1)/Table-Top Stand (1 set)/Screw (2)

common to all models

Optional accessories Connecting cables / Support Belt Kit

Model name KDL-46R450A

KDL-46R453A

KDL-40R471A KDL-40R450A

Other Information

Index

"/1 LED 26

0-9 buttons 23

4:3 Default 41

Add Digital Channels 43

Advanced Settings 38

Alternate Audio 39

Analog Fine Tune 43

Audio Description 48

AUDIO OUT 10

Audio Out 39

Auto Display Area 41

Auto Program 20, 43

Auto Shut Off 52

Auto Wide 41

AV Setup 49

Backlight 37

Balance 39

BRAVIA Sync Settings 50

Brightness 37

CABLE/ANTENNA 11

CC/SUBTITLE button 24

CH +/– button 24

CH/INPUT button 26

Change Password 44

Channel Block 44

CineMotion 37

Clear Voice 39

Clock/Timers 49

Closed Captions (CC) 48

Color 37

Color Temperature 37

Colored buttons 23

COMPONENT IN 11

Country 44

DIGITAL AUDIO OUT (OPTICAL)

Display Area 41

DISPLAY button 24

Downloadable U.S. Rating 44

Edit Channel Labels 43

English Rating 46

Equalizer 39

Equipment Control button 25

External Input Block 44

French Rating 46

HDMI IN 10

HOME button 23

Horizontal Center 41

Hue 37

Idle TV Standby 52

Info Banner 49

Infrared Receiver (IR) 26

Initial Setup 49

INPUT button 23

Installing the TV on a wall 54

JUMP button 24

Language 49

Light sensor 26, 52

Movie Rating 45

MPEG Noise Reduction 37

MTS Audio 39

Music 32

MUTING button 24

Noise Reduction 37

OPTIONS button 24

Password 44

PC Settings 42

Photo 32

Photo Frame 33

Photo Frame Settings 47

PIC OFF button 23

Picture 37

Picture Adjustments Lock 50

Picture Mode 37

PIP 28

Power ("/1) button 26

Power Saving 52

Product Support 51

Rating 44

Reset 37, 39, 52, 61

RETURN button 23

Scene Select 37

Settings

Channel 43

Eco 52

Parental Lock 44

Picture 37

Screen 41

Setup 47

Sound 39

Sharpness 37

Show/Hide Channels 43

Signal Type 43

SLEEP button 23

Sound Booster 39

Sound Mode 39

Speaker 26

Speakers 39

Startup Logo 49

Steady Sound 39

SYNC MENU button 23

Troubleshooting 56–61

TV Rating 45

U.S.A. Rating 46

Unrated 44

USB 11

USB Auto Start 47

Vertical Center 42

Video 32

VIDEO IN 11

Viewing Blocked Programs 46

VOL (2) +/– button 23, 26

Volume Offset 39

WIDE button 24

Wide Mode 41

4-458-509-12(1)

For Your Convenience

Online

Registration:

Be sure to register your TV.

United States

Canada

http://productregistration.sony.com

http://www.sony.ca/registration

Sony Bravia Lcd Tv Kdl 32R400A Users Manual 46R453A / 46R450A 40R471A 40R450A 32R421A

KDL-32R400A Operating Instructions KDL-R471A_R453A_R450A_R421A_R400A

KDL-40R450A Operating Instructions KDL-R471A_R453A_R450A_R421A_R400A

Sony Bravia LCD TV KDL-40R471A KDL-R471A_R450A_R421A_R400A

Navigation menu

Versions of this User Manual:

Views

Navigation
