For customers who purchased this product in
the USA
Please register this product on line at
http://www.sony.com/productregistration.
Proper registration will enable us to send you
periodic mailings about new products, services,
and other important announcements.
Registering your product will also allow us to
contact you in the unlikely event that the
product needs adjustment or modification.
Thank you.
WARNING
To reduce the risk of fire or electric shock,
do not expose this apparatus to rain or
moisture.
To reduce the risk of fire, do not cover the
ventilation of the apparatus with newspapers,
tablecloths, curtains, etc. And do not place
lighted candles on the apparatus.
To reduce the risk of fire or electric shock, do
not expose this apparatus to dripping or
splashing, and do not place objects filled with
liquids, such as vases, on the apparatus.
Do not install the appliance in a confined space,
such as a bookcase or built-in cabinet.
Do not expose the batteries (battery pack or
batteries installed) to excessive heat such as
sunshine, fire or the like for a long time.
As the main plug is used to disconnect the unit
from the mains, connect the unit to an easily
accessible AC outlet. Should you notice an
abnormality in the unit, disconnect the main
plug from the AC outlet immediately.
The unit is not disconnected from the AC
power source (mains) as long as it is connected
to the wall outlet, even if the unit itself has been
turned off.
You are cautioned that any changes or
modifications not expressly approved in this
manual could void your authority to operate
this equipment.
The nameplate and important information
concerning safety are located on the bottom
exterior.
CAUTION
Danger of explosion if battery is incorrectly
replaced. Replace only with the same type.
NOTE
This equipment has been tested and found to
comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment
generates, uses and can radiate radio frequency
energy and, if not installed and used in
accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference to
radio or television reception, which can be
determined by turning the equipment off and
on, the user is encouraged to try to correct the
interference by one or more of the following
measures:
— Reorient or relocate the receiving antenna.
— Increase the separation between the equipment
and receiver.
— Connect the equipment into an outlet on a
circuit different from that to which the receiver
is connected.
— Consult the dealer or an experienced radio/TV
technician for help.
WARNING
Replace the battery for the clock backup with
a Sony CR2032 lithium battery. Use of
another battery may present a risk of fire or
explosion.
Battery may explode if mistreated. Do not
recharge, disassemble or dispose of in fire.
Dispose of the used battery promptly. Keep
away from children.
Important Safety
Instructions
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings.
Install in accordance with the
manufacturer’s instructions.
8) Do not install near any heat sources such as
radiators, heat registers, stoves, or other
apparatus (including amplifiers) that
produce heat.
9) Do not defeat the safety purpose of the
polarized or grounding-type plug. A
polarized plug has two blades with one
wider than the other. A grounding type plug
has two blades and a third grounding prong.
The wide blade or the third prong are
provided for your safety. If the provided
plug does not fit into your outlet, consult an
electrician for replacement of the obsolete
outlet.
10) Protect the power cord from being walked
on or pinched particularly at plugs,
convenience receptacles, and the point
where they exit from the apparatus.
11) Only use attachments/accessories specified
by the manufacturer.
12) Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination to
avoid injury from tip-over.
13) Unplug this apparatus during lightning
storms or when unused for long periods of
time.
14) Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way,
such as power-supply cord or plug is
damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does
not operate normally, or has been dropped.
For the state of california, USA only
Perchlorate Material –special handling may
apply, See www.dtsc.ca.gov/hazardouswaste/
perchlorate
Perchlorate Material: Lithium battery contains
perchlorate
Features
Dual alarm FM/AM synthesized clock radio
Nature Sounds (Sea Waves, Birds, Rain,
Brook, Under the Sea)
Room temperature display (Fahrenheit /
Centigrade) 5°F – 122°F (–15°C – 50°C)
Built-in audio cable for Digital Music Player
10 Station Presets (5 FM/5 AM)
Various types of alarms - radio, buzzer and
Nature Sounds (5)
Automatic time set: when you plug the clock
in for the first time, the current time will be
shown in the display
Automatic Daylight Saving Time Set/Summer
time adjustment
100-year calendar and DATE/TIME ZONE
button to display year, month, and date
Brightness Control (High/Low/Off)
No Power No Problem alarm system to keep
the clock and the alarm operating during a
power interruption with a CR2032 battery
installed
Extendable Snooze system - Snooze time can
be set from 10 to 60 minutes
Progressive Alarm Speed (buzzer only)
Precautions
Play the unit on the power source specified in
“Specifications.”
To disconnect the power cord (mains lead),
pull it out by the plug, not the cord.
Since a strong magnet is used for the speaker,
keep personal credit cards using magnetic
coding or spring-wound watches away from
the unit to prevent possible damage from the
magnet.
Do not leave the unit in a location near a heat
source such as a radiator or airduct, or in a
place subject to direct sunlight, excessive
dust, mechanical vibration, or shock.
Allow adequate air circulation to prevent
internal heat build-up. Do not place the unit
on a thick pile surface (rug, a blanket, etc.),
or near materials that might block the
ventilation holes (such as a curtain, etc.).
Should any solid object or liquid fall into the
unit, unplug the unit and have it checked by
qualified personnel before operating it any
further.
To clean the casing, use a soft cloth
dampened with a mild detergent solution.
Never touch the wire of the external FM
antenna during a thunderstorm.
Furthermore, immediately disconnect the
main plug from the wall outlet.
NOTES ON THE LITHIUM BATTERY
Wipe the battery with a dry cloth to assure a
good contact.
Be sure to observe the correct polarity when
installing the battery.
Do not hold the battery with metallic
tweezers, otherwise a short-circuit may
occur.
If you have any questions or problems
concerning your unit, consult your nearest
Sony dealer.
Troubleshooting
Should any problem persist after you have
made the following checks, consult your nearest
Sony dealer.
The clock flashes “AM 12:00” due to a
power interruption.
The battery is low. Replace the battery.
Remove the old battery and install a new one.
The alarm settings do not sound at the
preset alarm time.
Check that alarm “” or alarm “” is
properly set/displayed.
The alarm settings are activated but there
is no sound at the preset alarm time.
Check the alarm volume setting.
When daylight saving time begins, the
clock does not switch to daylight saving
time automatically.
Make sure the clock is set correctly.
Press and hold DISPLAY/CLOCK and
SNOOZE / BRIGHTNESS simultaneously for
at least 2 seconds to activate the Automatic
DST function.
4-180-722-31(1) About the backup
battery
To maintain accurate time, this unit includes an
internal CR2032 battery as a backup power
source in the event of a power interruption.
Knowing when to replace
the battery
When the battery becomes weak, “” will
appear in the display.
If a power interruption occurs while the battery
is weak, the current time and alarm will be
erased.
Replace the battery with a Sony CR2032 lithium
battery. Use of another battery may cause a fire
or explosion.
Note
If “AM 12:00” flashes in the display when the
unit is connected to an AC outlet for the first
time, the battery may be weak. In this case,
consult your Sony dealer.
Installing and replacing the
backup battery
1 Keep the AC power cord connected to
the AC outlet, remove the screw that
secures the battery compartment at the
bottom of the unit using a screwdriver,
and pull the battery compartment
marked PULL OPEN. (See fig. -)
2 Insert a new battery in the battery
holder with the side facing up.
To remove the battery from the battery
compartment, push it out from the side
marked PUSH. (See fig. -)
3 Insert the battery compartment back
into the unit and secure it with the
screw. (See fig. -)
4 To turn “” off in the display, press
RADIO BAND, AUDIO IN, or
NATURE SOUND / PRESET after
replacing the battery.
Notes
When you replace the battery, do not
disconnect the AC power cord from AC
outlet.
Otherwise, the 100-year calendar, current
time, alarm, and station presets will be
erased.
If the clock is erased while you are replacing
the battery, set the clock again. (See “Setting
the clock”)
CR2032
Specifications
Time display
12-hour system
Radio section
Frequency range
Band Frequency Channel step
FM 87.5 MHz – 108 MHz 0.1 MHz
AM 530 kHz – 1,710 kHz 10 kHz
General
Speaker
Approx. 3.6 cm (1 7/16 inches) dia., 8 Ω
Input
Built-in audio cable with stereo mini plug
(ø 3.5 mm)
Power output
0.7 W (at 10% harmonic distortion)
Power requirements
120 V AC, 60 Hz
For clock back up: 3V DC, one CR2032 battery
Nature Sounds
Sea Waves, Birds, Rain, Brook, Under the Sea
Temperature range
5 °F – 122 °F (–15 °C – 50 °C)
Temperature resolution
1 °F (1 °C)
Dimensions
Approx. 217 mm × 67 mm × 62 mm (w/h/d)
(8 5/8 inches × 2 3/4 inches × 2 1/2 inches) not
including projecting parts and controls
Mass
Approx. 675 g (1 lb 7.63 oz) including power
supply unit and CR2032 battery
Supplied accessories
AM loop antenna (1)
Design and specifications are subject to change
without notice.
Connecting the
antenna
To connect the AM loop
antenna
The shape and the length of the antenna is
designed to receive AM signals. Do not
dismantle or roll up the antenna.
1 Remove only the loop part from the
plastic stand.
2 Set up the AM loop antenna.
3 Connect the cords to the AM antenna
terminals.
Cord (A) or cord (B) can be connected to
either terminal.
Insert the cord while
pushing down the
terminal clamp.
4 Make sure the AM loop antenna is
connected firmly by pulling softly.
Adjusting the AM loop antenna
Find a place and an orientation that provides
good reception.
Do not place the AM loop antenna near the
unit or other AV equipment, as noise may
result.
Tip
Adjust the direction of the AM loop antenna for
best AM broadcast sound.
©2010 Sony Corporation Printed in China
FM/AM Clock Radio
ICF-C717PJ
Operating Instructions
Dream Machine is a trademark of Sony Corporation.
No Power No Problem is a trademark of Sony Corporation.
Setting the time zone
and the clock for the
first time
This unit is preset to current EST (Eastern
Standard Time) at the factory, and is powered
by a backup battery. All you need to do the first
time is just plug it in and select your time zone.
1 Plug in the unit.
“year” (about 4 seconds) “month and
date” (about 4 seconds) “current EST
(Eastern Standard Time)” appears in the
display in turn.
2 Press and hold DATE/TIME ZONE for
at least 2 seconds.
Area number “2” flashes in the display.
3 Press TIME SET + or – repeatedly to
select the time zone as follows:
Area number Time zone
1 Atlantic Standard Time
2
(default setting)
Eastern Standard Time
3 Central Standard Time
4 Mountain Standard Time
5 Pacific Standard Time
6 Yukon Standard Time
7 Hawaiian Standard Time
4 Press DATE/TIME ZONE to set.
Notes
Though the clock is correctly set at the
factory, discrepancies may arise during
transport or storage. If necessary, set the
clock to the correct time by referring to
“Setting the clock.”
While setting the time zone, you must
perform each step within 65 seconds, or the
time zone setting mode will be canceled.
When daylight saving time
(summer time) begins
This model automatically adjusts for daylight
saving time (summer time).
“ ” is displayed from the beginning of daylight
saving time (summer time), and disappears at
the end of daylight saving time (summer time)
automatically.
Daylight saving time (summer time) begins
at: 2:00 AM on the second Sunday of March.
Standard time begins at: 2:00 AM on the first
Sunday of November.
To cancel Automatic DST/Summer
Time adjustment during daylight
saving time (summer time)
Automatic DST/Summer Time adjustment can
be canceled.
Press and hold DISPLAY/CLOCK and
SNOOZE / BRIGHTNESS at the same time for
at least 2 seconds while the clock is displayed.
“ ” and “OFF” appear in the display to show that
Automatic DST/Summer Time adjustment has
been canceled. The display returns to the clock.
Notes
Daylight saving time (summer time) is
subject to variations in circumstances and
laws of each country/region. Customers
living in a country/region without daylight
saving time (summer time) from 2:00 AM on
the second Sunday of March to 2:00 AM on
the first Sunday of November must cancel
Automatic DST/Summer Time adjustment
before using the unit.
To activate Automatic DST/Summer Time
adjustment again, press and hold DISPLAY/
CLOCK and SNOOZE / BRIGHTNESS at the
same time for at least 2 seconds.
“ ” and “On” appear in the display to show
that Automatic DST/Summer Time
adjustment has been activated. The display
returns to the clock.
This unit includes a preinstalled Sony Lithium battery (CR2032) as back-up power source for the clock, which is preset
to EST (Eastern Standard Time) at the factory. And this battery is considered part of the product.
Setting the clock
1 Plug in the unit.
2 Press and hold DISPLAY/CLOCK for at
least 2 seconds.
The year starts to flash in the display.
3 Press TIME SET + or – repeatedly to
set the year.
4 Press DISPLAY/CLOCK.
5 Repeat steps 3 and 4 to set the month,
day, hour and minute, and then press
DISPLAY/CLOCK.
The seconds advance from zero.
Notes
While setting the clock, you must perform
each step within 65 seconds, or the clock
setting mode will be canceled.
When pressing any of the rear buttons, hold
the unit firmly to prevent slippage.
To display the year and date
Press DATE/TIME ZONE once for the year, and
press again for the date.
After a while, the display will change back to
the current time automatically.
Using the Projector
function
The Projector function allows you to display
the clock and alarm on a nearby wall, up to a
distance of 2 metres away.
Pressing the PROJECTION ROTATE button
repeatedly changes the angle of rotation at
which the clock and alarm appear.
How to use
1 Plug in the unit.
2 Select the location and height.
3 Press the PROJECTION ON/OFF
button.
4 To adjust the focus, turn PROJECTION
FOCUS.
5 To press the PROJECTION ROTATE
button repeatedly changes the angle of
rotation at which the clock and alarm
appear. (See fig. )
Notes
The Projector function cannot be used unless
the clock has been set.
Do not stare into the lens directly.
Certain walls may not display the projection
properly.
The projector can be rotated 90° left or right
from the upward position, and clicks when
returned to the upward position.
If the projector unit is rotated beyond
limited, it may be damaged.
The projector will automatically turn off after
10 hours.
Setting the brightness
of the display
Three levels of brightness are available by
pressing SNOOZE / BRIGHTNESS.
Note
When the alarm is sounding, the brightness
function cannot be used.
Playing the radio
Manual tuning
1 Press RADIO BAND to turn on the
radio and select the AM or FM band.
2 Press TUNING + or – to tune in to a
desired frequency.
3 Adjust the volume using VOL + or –.
Tuning in to a station
The unit automatically scans AM or FM
stations.
1 Press RADIO BAND to turn on the
radio to select the AM or FM band.
2 Press and hold TUNING + or –.
+ : scans upward through the frequency
bands.
– : scans downwards through the frequency
bands.
Scanning starts from the currently-tuned
frequency. When a station is received,
scanning stops.
3 Adjust the volume using VOL + or –.
Preset tuning
You can preset 5 stations for FM and 5 stations
for AM.
Presetting a station
1 Follow steps 1 and 2 in “Manual
tuning” to tune the frequency you wish
to preset.
2 Hold down the desired NATURE
SOUND / PRESET 1 to 5 button until
you hear two beeps.
Example: The following display appears
when you preset FM 105.7 MHz to preset
number 3 for FM.
The display shows the frequency for a few
seconds and then changes back to the
current time.
To change the preset station, tune in to the
desired station and hold down the NATURE
SOUND / PRESET 1 to 5 button until you
hear two beeps.
To preset another station, repeat these steps.
Note
If you try to store another station with the same
preset number, the previously stored station
will be replaced.
Tuning in to a preset station
1 Press RADIO BAND to turn on the
radio and select the AM or FM band.
2 Press NATURE SOUND / PRESET 1 to
5 where the desired station is stored.
3 Adjust the volume using VOL + or –.
Improving the
reception
FM: Extend the FM wire antenna fully to
increase reception sensitivity.
AM: Connect the supplied AM loop antenna to
the unit. Rotate the antenna horizontally
for optimum reception.
Note on radio reception
Keep digital music players or mobile phones
away from the AM loop antenna or the FM
antenna, as this may lead to reception
interference.
Selecting a Nature
Sound
This unit includes 5 types of Nature Sounds:
(Sea Waves, Birds, Rain, Brook, and Under the
Sea.)
You can choose any one of these by pressing the
corresponding button.
Icons Sound type
Sea Waves
Birds
Rain
Brook
Under the Sea
Note
When other functions are in use, Nature
Sounds are not available.
Setting the alarm
The dual alarm function allows you to set two
alarm programs (ALARM ON/OFF A and
ALARM ON/OFF B).
The alarm time can be set for each program
and the alarm sound is selectable from
“NATURE SOUND,” “RADIO,” or “BUZZER.”
Notes
Before setting the alarm, make sure to set the
clock. (See “Setting the clock”)
The factory setting alarm time is “PM 12:00.”
To set the radio alarm, first preset your
favorite station. (See “Presetting a station”)
While setting the alarm, you must perform
each step within 65 seconds, or the alarm
setting mode will be canceled.
To set the alarm
1 Press and hold ALARM ON/OFF A or
B for a few seconds.
2 Press TIME SET + or – to set the
desired hour, and press ALARM ON/
OFF A or B.
3 Press TIME SET + or – to set the
desired minute, and press ALARM ON/
OFF A or B.
4 Press TIME SET + or – to set the
desired alarm period (“WEEKDAY,”
“WEEKEND,” or everyday*), and press
ALARM ON/OFF A or B.
* In the case of everyday, both
“WEEKDAY” and “WEEKEND” are
displayed.
5 Press TIME SET + or – to set the
desired alarm mode (“NATURE
SOUND,” “RADIO,” or “BUZZER”),
and press ALARM ON/OFF A or B.
You can choose one of 3 settings: “NATURE
SOUND,” “RADIO,” or “BUZZER.” Set the
alarm mode as follows:
– NATURE SOUND: see “ Setting the
Nature Sound alarm.”
– RADIO: see “ Setting the radio alarm.”
– BUZZER: see “ Setting the buzzer
alarm.”
Setting the Nature Sound alarm
1 Perform steps 1 to 5 in “To set the
alarm.”
2 Press TIME SET + or – to select
“NATURE SOUND” alarm mode, and
press ALARM ON/OFF A or B.
“NATURE SOUND” appears in the display.
3 Press TIME SET + or – to select the
NATURE SOUND / PRESET 1 to 5,
and press ALARM ON/OFF A or B.
4 Press TIME SET + or – to adjust the
volume, and press ALARM ON/OFF A
or B.
The setting is entered.
5 Press ALARM ON/OFF A or B. “” or
“” appears in the display after about
4 seconds.
Nature Sounds will sound at the set time.
Setting the radio alarm
1 Perform steps 1 to 5 in “To set the
alarm.”
2 Press TIME SET + or – to select
“RADIO” alarm mode, and press
ALARM ON/OFF A or B.
“RADIO” appears in the display.
3 Press TIME SET + or – to select the
AM band, FM band or the last station,
and press ALARM ON/OFF A or B.
If you select the last station, jump to step 5.
4 Press TIME SET + or – to select the
station, and press ALARM ON/OFF A
or B.
5 Press TIME SET + or – to adjust the
volume, and press ALARM ON/OFF A
or B.
The setting is entered.
6 Press ALARM ON/OFF A or B. “” or
“” appears in the display after about
4 seconds.
The radio will turn on at the set time.
Setting the Buzzer alarm
1 Perform steps 1 to 5 in “To set the
alarm.”
2 Press TIME SET + or – to select
“BUZZER” alarm mode, and press
ALARM ON/OFF A or B.
The setting is entered.
3 Press ALARM ON/OFF A or B. “” or
“” appears in the display after about
4 seconds.
The buzzer will sound at the set time.
When the alarm setting is completed, the alarm
time setting is displayed.
When both ALARM “” and ALARM “” are
turned on, you can switch the ALARM A and
ALARM B display by pressing DISPLAY/
CLOCK.
Notes
When you use the radio alarm, the timed
alarm sounds with the last broadcasting
station tuned to before the power went off.
When you set the radio alarm, select the
desired broadcasting station before turning
the power off.
The ALARM “” (or “”) indicator flashes
in the display when the alarm sounds.
If a second alarm sounds during a first (or
the SNOOZE function is active), the second
alarm takes priority.
The alarm function works as usual on the
first and last day of daylight saving time
(summer time) while Automatic DST/
Summer Time adjustment is set. As a result,
if the alarm is set to a time skipped when
daylight saving time (summer time) begins in
March: the alarm is skipped. If the alarm is
set to a time skipped when daylight saving
time (summer time) ends in November: the
alarm sounds twice.
If the same alarm time is set for both alarms
(ALARM A and B), ALARM A takes priority.
To confirm an alarm time setting
Turn off the ALARM ON/OFF “” or “”
indicator in the display, and press the ALARM
ON/OFF A or B button again.
You can confirm the alarm time by pressing
TIME SET + or – after the alarm time is set.
To change an alarm setting
There are two ways to set the alarm:
To change all alarm settings
Set the alarm again.
To change an alarm time only
When the alarm is set (ALARM “” or
ALARM “” appears), this function is
available.
Press and hold TIME SET + for at least 2
seconds to move the alarm time forwards. Press
and hold TIME SET – for at least 2 seconds to
move the alarm time back. When you release
the button, the changed time will be displayed
for about 2 seconds. To further change the
alarm time, press TIME SET + or – within these
2 seconds, otherwise the setting change will be
fixed as displayed.
To doze for a few more minutes
Press SNOOZE / BRIGHTNESS.
The sound turns off but will automatically
come on again after about 10 minutes.
You can change the snooze time by pressing
SNOOZE / BRIGHTNESS repeatedly within
4 seconds.
The maximum snooze time is 60 minutes.
To stop the alarm
Press OFF ALARM RESET to turn off the
alarm.
The alarm will sound again at the same time
the next day (if the setting is not changed).
To deactivate the alarm
Press ALARM ON/OFF A or B to turn off the
ALARM “” or “” indicator in the display.
Note on the alarm in the event of a power
interruption
In the event of a power interruption, the alarm
will work until the internal battery is worn out.
However, certain functions may be affected as
follows:
The backlight will not light up.
If the alarm mode is set to NATURE SOUND
or RADIO, it will change to BUZZER
automatically.
If a power interruption occurs while the
alarm is sounding, the alarm will stop.
If OFF ALARM RESET is not pressed, the
alarm will sound for about 5 minutes.
If “” appears in the display, the alarm will
not sound in the event of power interruption.
Replace the battery if “” appears.
The snooze function will not work.
During a power interruption, the alarm will
sound at the set time only once.
Setting the sleep
timer
You can fall asleep to “NATURE SOUND,”
“RADIO,” or “AUDIO IN” using the built-in
sleep timer that turns off “NATURE SOUND,”
“RADIO,” or “AUDIO IN” automatically after a
preset duration.
1 Press SLEEP while the unit is turned
on.
“SLEEP” appears and the sleep time flashes
in the display.
2 Press SLEEP to set the sleep timer
duration.
Each time you press SLEEP, the duration
(in minutes) changes as follows:
The display returns to clock mode (and the
sleep timer starts) approximately 4 seconds
after the duration is set and the SLEEP
button is released.
Note
Even if the sleep timer is set, it cannot turn off
the power of optional components connected to
the AUDIO IN jack of this player.
To turn off the unit before the preset
time
Press OFF ALARM RESET.
To change the sleep timer setting
You can press SLEEP repeatedly to select the
desired sleep timer setting even after the sleep
timer has been activated.
To deactivate the sleep timer
Press SLEEP repeatedly to set the sleep timer to
“OFF” in step 2.
Using the
temperature function
This unit includes an external temperature
sensor, allowing you to monitor ambient
temperature.
The temperature is displayed in Fahrenheit or
Centigrade.
To switch between Fahrenheit and Centigrade,
press and hold the SNOOZE / BRIGHTNESS
and DATE/TIME ZONE buttons for more than
2 seconds.
Notes
In the example, the display shows Fahrenheit;
however, Centigrade can also be displayed.
Do not use in water.
Do not forcefully pull on the external
temperature sensor. Improper use of the
external temperature sensor may cause a
malfunction.
Do not place the temperature sensor near the
floor, a heat source such as a radiator or
airduct, or in a place subject to direct
sunlight.
The display temperature and actual
temperature may differ depending on the
usage environment.
The operating temperature range is 5 °F
(–15 °C) to 122 °F (50 °C).
If the temperature is lower than 5 °F (–15 °C)
or higher than 122 °F (50 °C), the “Lo” or
“Hi” indicator appears.
When plugging in the unit or recovering
from a power interruption, the temperature
display of this unit will flash “--”.
The temperature will be displayed after 20
seconds.
Connecting external
component
(See fig. )
To listen to sound
1 Connect the built-in audio cable with
the stereo mini plug on the bottom of
the unit to the line output jack or
headphones jack on the optional
component (e.g., portable music
player).
2 Press AUDIO IN.
“AUDIO IN” appears in the display.
3 Play the optional component
connected to the unit’s built-in audio
cable.
4 Adjust the volume using VOL + or –
and the connected component’s
volume.
To return to the radio
Press RADIO BAND.
The frequency is shown in the display.
To stop listening
Press OFF ALARM RESET, and stop playback
on the connected unit.
To turn off the sound from the
optional component
Press OFF ALARM RESET, and then turn off
the optional component.
Notes
Refer also to the connected component’s
manual.
Connect the audio cable firmly to prevent a
malfunction.
Keep digital music players away from the
speaker.
If you increase the volume too much, loud
sound may occur when switching to the
radio.
Confirm the volume setting of the external
component before removing the AUDIO IN
cable. High volume may damage your
hearing, particularly if using headphones
with the external component.
AUDIO IN cannot be set for the alarm
sound.
When you listen to the radio with external
component connected, turn off the connected
component to prevent noise. If noise occurs,
even when the component is turned off,
disconnect and place the external component
away from the unit.
Built-in audio
cable
The built-in audio cable can
be inserted in the slot of the
unit.
To the headphones
jack or line output
jack
The VOL + button has a tactile dot.
FM wire antenna
Temperature
sensor
AC power cord
Built-in audio
cable
