Sony TC KA3ES User Manual Dimensions Diagram TCKA3ESdiagram
User Manual: Sony TC-KA3ES Dimensions Diagram
Open the PDF directly: View PDF
.
Page Count: 1
1/4 inch = 1 inch Scale 4:1
TC-KA3ES
DESCRIPTION:
DIMENSIONS
(WHD):
WEIGHT:
POWER
REQUIREMENTS:
POWER
CONSUMPTION:
Contractor's
Notes:
FRONT VIEW
SIDE VIEW
CASSETTE
RECORDER/PLAYER 120
V
60
H
2 " 12 1/16" 2 "
16 7/8"
BACK VIEW
2 " 7 1/4" 2 "
12 3/4 "
14 1/8"
1/2" 1/2"
5 5/16"
9/16"
4 3/4"
AC Cord
3/8"
16 7/8" X 5 5/16" X 14
1"
0 1 2 8
ES
REMOTE
SENSOR
POWER
16lbs 12oz 30 W
a
LINE IN/OUT
L
R
