TCM-
150
Standard Cassette Voice Recorder
Key Features
One Button Recording
Large Playback Speaker for Improved Sound
Led Battery Level Indicator
Built
-
In Microphone
Up to 25 Hour
Battery Life
1
Key Technologies
One Button Recording
For simplified, quick play/record operation.
25 Hour
Battery Life
Is made possible by advanced technology which extends battery power
beyond previous limits.
1
LED Battery Level Indicator
Provides visible indication of battery power remaining.
Clear Voice
™
Recording System
Improves and enhances voice quality during record and
playback.
Large Playback Speaker for Improved Sound Large speaker allows better sound quality during
playback.
Built
-In Microphone For extra convenience, eliminates the need for an external microphone.
Automatic Shut
-Off at End of Tape Pops up buttons to conserve battery power, reduces
mechanical wear, and alerts you that the end of the tape has been reached.
One Touch Record from Playback For simplified quick play/record operation.
Sony
-
Matic
®
Automatic Recording Level Control
Uses advanced circuitry to ensure correct
recording level.
L/R Monaural Earphone Jack provide sound in both ears when using an optional stereo headset
Cue And Review Function
Provides sound during fast forward and rewind modes to help find
specific passages.
Pause Switch
Temporarily halts recording or playback without leaving that mode, and resumes at
the flick of a button.
Stop/Pause Release Function Automatically turns off the pause switch whenever the stop button is
pressed, to prevent loss of recording.
Power Requirements
2 "AA" Batteries
Sony Electronics Inc.
•
16530 Via Esprillo
•
San Diego, CA 92127
•
1.800.222.7669
•
www.sony.com
Last Updated: 05/21/2010
TCM-
150
Standard Cassette Voice Recorder
Please visit the Dealer Source for current
information at www.sony.com/dealersource
Specifications
General
Type of Use: Portable Voice Recorder
Recording Media: Standard Audio Cassette
Recording and Playback Times: up to 90
minutes
Audio
Recording System: 2
-
Track, 1
-
Channel
Standard Cassette
Microphone: Built
-
in
Frequency Range: 250
-
6300Hz
Tape Speed: 4.8cm/s
Features
Audio
Recording Features: Clear Voice™
Sound
System, One
-
Touch Record, Sony
-
Matic
®
Automatic Recording Level
Convenience
Automatic Shut
-
off:
Yes
Convenience
Search Features:
Cue and Review
Hardware
Display: N/A
Power
Output Power: 250mW
Power Requirements: N/A
Battery Type: "AA" x 2
Battery Life (Approx): Rec/Play: 25 Hours
w/Sony Alkaline Batteries (optional)
Speaker
Type: Built
-
in
Speaker Dimensions: 2" (50mm) diameter
Inputs and Outputs
Microphone Input: N/A
DC
-
In:
N/A
Headphone Output(s): 1 (Mini)
Dimensions
Weight: 6 oz (169 g)
Measurements: W 3 3/8" x H 4 1/2" x D 1
3/8" (86.9 x 116.3 x 36.5mm)
Color:
Silver
UPC Code:
027242607712
1. Battery life will vary based upon usage conditions.
©2006 Sony Electronics Inc.
Features and specifications are subject to change without notice. Non
-
metric weights and measures are approximate.
Reproduction in whole or in part without written permission is prohibited.
All rights reserved. Sony, Clear Voice, Sony
-
Matic, and like.no.other are
trademarks of Sony.
