Come home to a more immersive experience with 4K HDR
playback1, Dolby Atmos® 3D surround sound3 and access to
your favorite 4K HDR streaming services7. Built for optimum video
and audio performance, this universal Ultra HD player optimizes
playback on non-HDR TVs with HDR to SDR conversion, and plays
almost any disc or le format.
• Play 4K Ultra HD movies1 with High Dynamic
Range (HDR) support4
• Stream in 4K HDR1 and play almost any disc or le
format3
• 4K HDR to SDR conversion improves contrast and
color on non-HDR TVs
• Experience Dolby Atmos® 3D and DTS:X object-
based surround sound3
• Enjoy private viewing with wireless headphones
via Bluetooth®5
• Hear every detail with Hi-Res Audio
• Premium construction for optimum audio-visual
performance
• Don’t miss a sound with simultaneous HDMI and
Bluetooth® connectivity5
• Stream music to dierent rooms with wireless
multi-room listening6
Features
4K UHD Blu-ray4
Play 4K Ultra HD movies1 at 4x the resolution of full 1080p HD, letting you watch your favorite scenes with a level of detail
and clarity like never before.4
High Dynamic Range (HDR) support4
HDR allows for a greater range of color contrast and brightness, enhancing details from the original lm format.
Stream in 4K HDR and play most formats7
Go far beyond playing 4K Ultra HD Blu-ray discs. Stream in 4K HDR from your favorite streaming services7 andplay almost
any disc or le format, including most 4K Ultra HD video and Hi-Res Audio formats4. All you have to do is decide what to
enjoy next.
4K HDR to SDR conversion4
4K HDR to SDR (Standard Dynamic Range) conversion improves contrast and color for optimized playback and viewing
on non-HDR TVs.
Experience Dolby Atmos® and DTS:X® object-based surround sound3
With Dolby Atmos®3D and DTS:X object-based surround sound, you’ll feel like you’re inside the action as the sounds of
people, music and objects move all around you in three-dimensional space.3
Enjoy private viewing with wireless headphones5
Enjoy Bluetooth® audio connectivity5 so you can use your favorite wireless headphones for private viewing.
Hear every detail with Hi-Res Audio
Similar to the improved quality of going from HD video to 4K, High-Resolution Audio tracks are far higher quality than MP3s
and even CDs, letting you hear every breath, every drumbeat, every note.
Premium construction for optimum audio-visual performance
Our unique frame-and-beam chassis oers a rigid structure to eliminate micro-vibrations, as well as eective electrical
shielding, so all you experience is the highest sound and picture quality.
Don’t miss a sound with simultaneous HDMI and Bluetooth® connectivity5
UBP-X800/B
4K Ultra HD Blu-ray Disc™ Player
Bullets
Supported Media
Supported Media
CD (DTS-CD) Yes
DVD+R Yes
DVD+R Double Layer Yes
DVD+RW Yes
DVD Camcorder 8cm DVD 8cm DVD-R/ -RW
8cm DVD+RW
DVD-R Video
VR (w/o CPRM)
DVD-R Dual Layer Video
VR (w/o CPRM)
DVD-RW Video
VR (w/o CPRM)
DVD-Video Yes
External HDD (Read/Write/Copy/Move) Yes (Read)
File System FAT32 / exFAT / NTFS
SA-CD (SA-CD/CD) Playback Yes
Stereoscopic 3D (prole 5) Yes
Ultra HD Blu-ray Yes (DL/TL)
USB Memory Yes
Video CD Partially capable
BDAV BD-R Yes (ver.1.0, SL/DL)
BD-RE Yes (ver.2.0, SL/DL)
BDMV BD-R Yes (ver.2.0, SL/DL)
BD-RE Yes (ver.3.0, SL/DL)
Hybrid Disc
BD/CD Yes (select in set-up menu)
BD/DVD Yes (select in set-up menu)
HDDVD/DVD Yes (DVD part only)
Mixed Disc BDAV/BDMV Yes (BDMV)
Send audio via HDMI to a soundbar while sending it to a wireless speaker or headphones over Bluetooth®5 at the same
time. With simultaneous connectivity, you don’t have to miss a word or sound even if you step away from your TV.
Stream music to dierent rooms6
Listen to the same great song all around the house with multi-room listening. Now you can group selected Sony sound
bars and speakers together and stream music in multiple rooms.6
Specications
Music
AAC (.aac, .mka) Yes (BD, DVD, CD, USB), DLNA (.aac only)
AAC (.m4a) Yes (BD, DVD, CD, USB, DLNA)
AIFF (.ai, .aif) Yes (BD, DVD, CD, USB, DLNA)
ALAC (.m4a) Yes (BD, DVD, CD, USB, DLNA)
Dolby Digital (.ac3, .mka) Yes (BD, DVD, CD, USB)
DSD - DSDIFF/DSC (.d, .dsf) Yes (BD, DVD, CD, USB, DLNA)
FLAC (.ac, .a) Yes (BD, DVD, CD, USB, DLNA)
HE-AACv1/v2 Yes (BD, DVD, CD, USB, DLNA)
LPCM (.mka) Yes (BD, DVD, CD, USB)
LPCM (.wav) Yes (BD, DVD, CD, USB, DLNA)
Monkey's Audio Yes (BD, DVD, CD, USB, DLNA)
MP3 (.mka) Yes (BD, DVD, CD, USB)
MP3 (.mp3) Yes (BD, DVD, CD, USB, DLNA)
Vorbis Yes (BD, DVD, CD, USB, DLNA)
WMA10 Pro Yes (BD, DVD, CD, USB, DLNA)
WMA9 Standard (.wma) Yes (BD, DVD, CD, USB, DLNA)
BMP (.bmp) Yes (BD, DVD, CD, USB)
GIF (.gif) Yes (BD, DVD, CD, USB, DLNA)
JPEG (.jpg, .jpeg) Yes (BD, DVD, CD, USB, DLNA)
MPO MPF 3D (.mpo) Yes (BD, DVD, CD, USB)
PNG (.png) Yes (BD, DVD, CD, USB, DLNA)
WEBP Yes (BD, DVD, CD, USB)
Video
AVCHD Disc Format Folder Yes (BD, DVD, CD, USB, DLNA)
HEVC Yes (BD, DVD, CD, USB, DLNA)
Motion JPEG (.mov, .avi) Yes (BD, DVD, CD, USB, DLNA)
MPEG-1 Video/PS (.mpg .mpeg, .m2ts,
.mts) Yes (BD, DVD, CD, USB, DLNA)
MPEG-2 Video/PS, TS ( .mpg.mpeg,
.m2ts, .mts) Yes (BD, DVD, CD, USB, DLNA)
MPEG-4/AVC (.mov, 3gp, .3g2, .3gpp,
.3gpp2, .v) Yes (BD, DVD, CD, USB, DLNA)
MPEG-4 AVC (.mkv, .mp4, .m4v, .m2ts,
.mts) Yes (BD, DVD, CD, USB, DLNA)
VC1 (.m2ts, .mts, .mkv) Yes (BD, DVD, CD, USB)
VP Yes (BD, DVD, CD, USB, DLNA)
WMV9 (.wmv, .asf, .mkv) Yes (BD, DVD, CD, USB, DLNA)
XVID Yes (BD, DVD, CD, USB, DLNA)
BD-ROM
BD-Live (Prole2.0) Yes (Prole 2.0)
BD-ROM (SL/DL) Yes (SL/DL)
Bonus View (Prole1.1) Yes (Prole 1.1)
CD CD (CD-DA) Yes
CD-R/-RW Yes
3D
3D
BD-ROM Yes
Photo Yes
Streaming Yes
Video (from camcorder) Yes
Playback Features
Playback Features Instant Advance - (Capable)
Disc Playback Features
Repeat
All Yes
Chapter Yes
Title Ye s
Track Yes
Playback Control
Instant Replay - (Capable)
Play/Stop/Pause Yes
PREV/NEXT Yes
REV/FWD Yes
Slow Playback (FWD/REV) Yes (Slow REV do not support for UHD BD, BD3D and VCD )
STEP Playback (FWD/REV) Yes (Step REV do not support for UHD BD, BD3D and VCD )
Shue Yes
Convenience Features
Convenience Features
Auto Power O (Auto Stand-by) Yes
Bit Rate Indicator Yes (Video, Audio)
BRAVIA Sync Yes
DEMO mode - Tray Lock Yes
Easy Setup Yes
IPCC Yes
Multiple Language Display
English
Spanish
French
Portuguese
Parental Control Yes
Soware Keyboard
English
Norwegian
Finnish
Greek
Dutch
Portuguese
Swedish
Danish
Russian
Polish
French
German
Italian
Spanish
Super Quick Start Mode Yes
USB Keyboard Yes (101 only)
Child Lock Yes
Easy Setup Yes
2nd Display (Media Remote)
Device Yes (iPhone, Android, PC)
SongPal Yes
TV SideView Yes (Video & TV SideView)
Wireless Multi Room Yes
List with Thumbnail
BD/DVD/CD Photo Only
DLNA Photo Only (Uncertied)
HDD Photo Only
USB Photo Only
GUI
Customize on My Apps Yes
FAVORITE on Remote Yes
New UI Yes (2015 version)
Soware Keyboard
History Indication Yes
Style Qwerty
Qwertz
Video Features
Video Features
Deep Color Yes (12bit)
IP Content Noise Reduction Yes
Preset Picture mode Cinema tuned Yes (Direct / Brighter room / Theater Room / Auto / Custom1
/ Custom2)
Picture Parameter Adjustment(s)
24p True Cinema Yes
4K Upscale 60p (Disc/USB/Net/DLNA)
Brightness Yes
Color Yes
Contrast Yes
Hue Yes
IP Content Noise Reduction Yes
SDR converter Yes
Video
BD
HD (24Hz) (24p True Cinema) Yes
HD (60Hz) Yes
HD 24Hz to 60Hz conversion Yes
SD (60Hz) Yes
DVD
DVD 24p output Yes
NTSC/PAL (60Hz/50Hz) Yes (NTSC only)
TV Type Default Setting 16:9
Video Output - BD-ROM HDMI Yes (480i/ 480p/ 720p/ 1080i/ 1080p/ 2160p (60Hz))
Yes (1080p/ 2160p (24Hz))
Video Output - DVD R/RW BD R/RE non
copy protected HDMI Yes (480i/ 480p/ 720p/ 1080i/ 1080p/ 2160p (60Hz))
Video Output - DVD Upscaling HDMI Yes (720p/ 1080i/ 1080p/ 2160p)
Yes (1080p/ 2160p (60Hz))
Video Output - DVD - Video HDMI Yes (480i/ 480p/ 720p/ 1080i/ 1080p/ 2160p (60Hz))
Video Output - BD Upscaling HDMI Yes (4K (60Hz))
Video Output - Photo Upscaling HDMI Yes (4K)
Photo sRGB/ Adobe RGB/ sYCC Yes/ No (Unocial)/ Yes
Slide Show with Music CD Yes
USB Yes
General
General Features
Disc Drive Yes (Precision Drive HD)
Region Code (BD) A
Region Code (DVD) 1
Startup Screen Yes
TV System Default Setting 60Hz
Single/Changer Single
FW Update Network Ye s
USB Yes
Inputs and Outputs
Inputs and Outputs
Coaxial Audio Output(s) 1 (Rear)
Ethernet Connection(s) 1 (Rear)
HDMI Output(s) 2 (Rear)
USB Input(s) 1 (Front)
Audio Features
Audio Features
AV Sync Yes
Certied Hi-Res Audio Yes
Dolby Dolby Atomos / Dolby True HD decoding (7.1Ch)
DRC Yes
DSEE-HX Yes
dts DTS decoding (7.1ch)
LDAC Yes
Coaxial
Dolby Digital bit-stream out Yes
DTS bit-stream out Yes
DTS Neo 6 Yes
LPCM 2ch(-48kHz/-24bit(16bit for
encrypted content)) Out Yes
HDMI Audio Out
Dolby TrueHD bit-stream out Yes
DSD output Yes (2.8M)
DSD to LPCM conversion out Yes (2.8M/5.6M) (11.2M update)
DTS HD Master Audio bit-stream out Yes
LPCM 2ch out Yes (192kHz/96kHz/48kHz)
LPCM 6ch (5.1) out Yes (192kHz/96kHz/48kHz)
LPCM 8ch (7.1) out Yes (96kHz/48kHz)
Regulation and Standards
C/O on Kimeihan C/O on Kimeihan Yes (English)
Safety Approval Safety Approval UL/cUL
US Accesibility (Text to speech etc.) Yes
Remote Control
Standard Remote Yes
Network Features/SEN
Network Features/SEN Wake on LAN Yes (Super Quick Start Mode)
Home Share (DLNA)
Contents Throw Yes (Video, Audio, Photo)
DMP (Digital Media Player) Yes (Uncertied)(Video, Audio, Photo)
DMR (Dgital Media Renderer) Yes (Uncertied)(Video, Audio, Photo)
Wi-
Bluetooth TX Yes
Screen Mirroring Yes
Wi-Fi Built in Yes (2.4GHz, 5GHz)
Wi-Fi MIMO(Multi Input Muti Output) Yes
Entertainment DB (Gracenote etc.) Gracenote Yes (CD-DA Track info & Music Serch )
Network Streaming 3D Streaming Yes
4K streaming Yes
Network Streaming
Live Streaming Yes
Recommendation Yes
Subtitle Yes
Power
Power Power Consumption (in Operation) 15W
Power Consumption (in Standby) 0.35W
Accessories
Accessories Supplied Accessories
Instruction Manual (Full manual / Web manual, English)
Remote Control (RMT-VB310U)
Batteries (Type AAA x 2)
Customer Registration Card
Warranty Card
Weights and Measurements
Weights and Measurements
Dimensions (Approx.) Unit dimensions: 17 x 2 1/4 x 10 3/4 in (430 x 54 x 270 mm)
Carton dimensions: 19 x 3 3/4 x 14 in (480 x 95 x 355 mm)
Weight (Approx.) Unit only: 8 lbs 7 oz (3.8 kg)
Carton weight: 11 lbs 1 oz (5.0 kg)
1. 4K Ultra HD: 3840 x 2160 pixels
2. Interoperability and compatibility among Bluetooth® devices vary. LDAC supports several transmission rates according to your wireless environment. It allows you to enjoy
High-Resolution Audio content in exceptional sound quality near to High Resolution Audio, by transmitting at the maximum transfer rate: 990 kbps (approximately three times
more data than conventional Bluetooth® audio). LDAC provides an enhanced wireless listening experience for all your music, the way the artist truly intended.
3. Requires HDMI cable and Dolby Atmos® 3D and DTS:X capable source device. Not included.
4. 4K output requires a compatible 4K display and HDMI® cable, both not supplied.
5. Interoperability and compatibility among Bluetooth® devices vary.
6. Requires download of SongPal app for iPhone from the App Store or for Android from Google Play. User must link compatible devices in order to control operation. Subject to
app terms and conditions.
7. Network services, content, and the operating system and software of this Product may be subject to individual terms and conditions and changed, interrupted or discontinued
at any time and may require fees, registration and credit card information. Netflix streaming membership is required.
©2017 Sony Electronics, Inc. All rights reserved. Reproduction in whole or in part without written permission isprohibited. Sony, Blu-ray, LDAC and the Sony logo are
trademarks and or registered trademarks of Sony
Corporation. Dolby Atmos is a trademark of Dolby Laboratories Licensing Corporation. Bluetooth and the Bluetooth logo are trademarks of Bluetooth SIG, Inc. HDMI is a
trademark of HDMI Licensing LLC. DTS:X is a registered trademark of DTS, Inc. All other trademarks are trademarks of their respective owners. Features and specifications are
subject to change without notice

Navigation menu
