Go beyond what you’ve seen before with remarkable 4K¹ HDR
clarity, color and contrast. Scenes are more detailed, more
natural and more real with 4K HDR Processor X1, and life’s
brilliance is revealed with extra smooth and vibrant colors. And
with Android TV, nd all the entertainment you want.
Bullets
• The dramatic contrast, color and detail of 4K HDR
• Take even non-HDR content to the next level with the new 4K HDR Processor X1
• Enjoy smooth and vibrant colors with TRILUMINOS™ Display and 4K HDR Super Bit Mapping
• Android™ TV with Google Home compatibility gives you a genius TV
• Lifelike motion with Motionow™ XR technology
• Improved contrast with enhanced brightness and black levels
• 4K X-Reality PRO provides lifelike detail and clarity
• Live TV streaming, no annual contract with PlayStation™ Vue
• Just say what you want with Voice Search
• Send entertainment from your smartphone to your TV with Google Cast™³
Features
Uncover the detail with 4K HDR
High Dynamic Range (HDR) will change the way you look at TV. Combined with 4K Ultra HD resolution¹, HDR video content
delivers exceptional detail, color and contrast, with a far wider range of brightness than other video formats. The result is
the most lifelike picture TVs have ever been able to create, with brilliant highlights and ne detail.
Take non-HDR content to the next level
Our newly developed 4K HDR Processor X1 outperforms our original 4K Processor X1 with more real-time image processing
power. It takes even non-HDR content to near 4K HDR quality¹. Object-based HDR Remaster technology can detect,
analyze and optimize each object in the picture individually to adjust the overall contrast for a more natural and realistic
picture on screen.
Vibrant colors, smooth gradations
Colors are as rich and vivid as nature’s own thanks to the TRILUMINOS™ Display with more shades of red, green and blue
than ever before. You’ll enjoy vibrant, authentic images that evoke the emotion in every scene. And, 4K HDR Super Bit
Mapping reveals thousands of shades and gradations of light, for sunsets as bright and clear as real life.
A genius TV, a smarter home
Find all the entertainment you can dream of, faster than ever. From movies and TV shows to thousands of apps, Sony’s
Android™ TV brings you everything in an instant³. Cast your favorite apps with Google Cast, and Voice Search helps you
nd the entertainment you want. And with Google Home compatibility, simply voice-control your TV and ask it to do
things, like play your favorite YouTube videos.
Improved contrast.
Thanks to Dynamic Contrast Enhancer, experience more life, more texture and more energy in every scene with brighter
highlights, deeper blacks, and more natural tonal gradation.
XBR-65X850E
65” class (64.5” diag) 4K HDR Ultra HD TV
Audio
Bass/Treble/Balance Balance
DSEE/DSEE-HX DSEE
Speaker Conguration 2ch, Full Range (25 x 90
mm) x 2
Speaker Position Down Firing
Speaker Type Bass Reex
Audio Features
Advanced Auto
Volume Yes
Alternate Audio
(Digital) Yes
ARC Output Format
Two channel linear
PCM: 48kHz 16bits, Dolby
Digital, Dolby Digital
Plus, DTS
Audio Out Fixed / Variable
Auto Surround Yes
Clear Audio+ Yes
Clear Phase Yes
Dolby audio format
support
Dolby Digital, Dolby
Digital Plus, Dolby Pulse
DTS audio format
support DTS Digital Surround
HDMI Audio Return
Channel(ARC) Yes
HDMI input Audio
format
5.1 channel linear PCM:
32, 44.1, 48, 88.2, 96,
176.4, 192kHz, 16, 20,
24bits, Dolby Digital,
Dolby Digital Plus, DTS
Headphone/Speaker
Link Yes
Simulated Surround
Sound S-Force Front Surround
S-Master S-Master Digital Amplier
Sound Modes Standard, Dialog,
Cinema, Music, Sports
Convenience Features
Application Store Yes (Google Play Store)
Auto Picture Mode Yes
Auto Shut-o Yes
Channel Block (with
password) Analog & Digital
Google Cast™ Yes
HDMI-CEC Yes
i-Manual Yes
Multiple Language
Display English, Spanish, French
On/O Timer Yes
On-Screen Clock Yes
Parental Control Yes
Show/Hide Channels Yes (Digital & Analog)
Sleep Timer Yes
Text Input Language
BUL / CAT / HRV / CES /
DAN / DUT / ENG / EST
/ FIN / FRA / GER / GRK
/ HUN / ITA / LAV / LIT /
NOR / POL / POR / RON
/ RUS / SLK / SLV / SPA /
SWE / TUR / UKR / THA /
VIE / ARA / FAS / JPN
USB drive format
support
Yes (Supported File
System: FAT16/ FAT32/
exFAT/ NTFS)
USB playback codecs MPEG1:MPEG1/
MPEG2PS:MPEG2/
Voice Search Yes
Customizing Capability
RS-232C Control Yes
Design Features
Cable Management Yes
Frame color Black
Illumination LED Yes
Stand Design Dark Silver U Slate
Display Features
Backlight dimming
type Frame Dimming
Backlight Type Edge LED
Display type LCD
Display
Aspect Ratio 16:9
Redening realism
The dierence is clear. You’ll see lifelike detail and stunning clarity, no matter what you're watching. 4K X-Reality PRO™
upscales images to near 4K clarity¹. See the details appear in buildings and trees as scenes become clearer, smoother
and more natural.
Motionow™ keeps the action smooth
TV that keeps up with real life. Sony’s refresh rate technology (Motionow™ XR 960) builds upon the native 120Hz panel to
allow fast moving action sequences in sports and movies to be seen with lifelike clarity.
Live TV, no annual contract
PlayStation™ Vue now available on Android TV. Enjoy live TV streaming with no annual contract and no surprise fees.
Experience premium content, including sports, news and more, from your favorite networks.
Just say what you want
Spend less time browsing, and more time watching. Voice search on Android TV™ provides you with the power of Google
search in 42 languages, allowing you to nd content across dierent services without the hassle of time-consuming text
entry³
Send to a bigger, better screen with Google Cast™
Send movies and music from your smartphone to your TV with Google Cast™. Use your phone as a remote control³
Your favorite apps, on your TV
Enjoy a huge range of apps from Google Play™, including YouTube™, Netix, Amazon Video, Hulu, Pandora and more.
Also, play your favorite Android games on the big screen³.
A masterpiece of design
Keep wires out of sight, thanks to a hidden cable panel structure, for a clean look.
Specications
Display Resolution QFHD
Display resolution (H x
V, pixels) 3840x2160
Screen Size (cm,
measured diagonally) 163.9 cm
Screen Size (inch,
measured diagonally) 65" (64.5")
Viewing Angle (Right/
Le) 178(89/89) degree
Viewing Angle (Up/
Down) 178(89/89) degree
Energy Saving & Eciency
Dynamic Backlight
Control Yes
Power Saving Modes Yes
General Features
Closed Captions (CC) Analog
Digital
Demo Mode Yes
Hotel Mode Menu Yes
Inputs and Outputs
4K 60P High-Quality
formats
Up to 18Gbps:4K
60p 4:4:4(8bit),
4:2:2(8,10,12bit),
4:2:0(8,10bit) HDR
included for HDMI 2/3
AC Power Input AC Adapter
Analog Audio Input(s)
(Total)
2 (1 Side Analog
Conversion / Rear Hybrid
w/Component)
Audio / Headphone
Output(s)
1 (Side/Hybrid w/HP and
Subwoofer Out)
Bluetooth prole
support
Version 4.1/ HID/HOGP/
SPP/A2DP(via rmware
update)/AVRCP(via
rmware update)
Component Video (Y/
Pb/Pr) Input(s)
1 (Rear Hybrid w/
Composite)
Composite Video
Input(s)
2 (1 Side Analog
Conversion / 1 Rear
Hybrid w/Component)
Digital Audio Output(s) 1 (rear)
Ethernet Connection(s) 1 (Side)
HDCP HDCP2.2 (for
HDMI1/2/3/4)
HDMI inputs total 4 (3 Side/1 Rear)
HDMI PC Input Format
640 x 480@60Hz
800 x 600@60Hz
1024 x 768@60Hz
1280 x 1024@60Hz
1600 x 900@60Hz
1152 x 864@75Hz
1680 x 1050@60Hz
1920 x 1080@60Hz
HDMI Signal
4096 x 2160p (24, 60Hz),
3840 x 2160p (24, 30,
60Hz), 1080p (30, 60Hz),
1080/24p, 1080i (60Hz),
720p (30, 60Hz), 720/24p,
480p, 480i
Headphone Output(s) 1 (Rear / Hybrid w/Audio
Out and Subwoofer Out)
RF Connection Input(s) 1 (side)
RS-232C Input(s) 1 (Rear/Mini Jack)
Subwoofer Out 1 (Side / Hybrid w/HP
and Audio Out)
USB Port(s) 3 (side)
Network Features
Codec for Home
Network
MPEG1: MPEG1/
MPEG2PS: MPEG2/
MPEG2TS (HDV,AVCHD):
MPEG2, AVC/MP4(XAVC
S): AVC, MPEG4, HEVC/
AVI: Xvid, MotinJpeg/ASF
(WMV): VC1/MOV: AVC,
MPEG4, MotionJpeg/
MKV: Xvid, AVC, MPEG4,
VP8.HEVC/WEBM:
VP8/3GPP: MPEG4, AVC/
MP3/ASF (WMA)/ LPCM/
WAV/ MP4AAC/ FLAC/
JPEG
Electronic Program
Guide (EPG) Yes
Featured (Content
Bar) Yes
Home Network Feature Home Network Client /
Home Network Renderer
Internet Browser Opera (not pre-Installed)
Live Football Mode Yes
Other Network
Features
Content Bar: Yes
Genre Categories
(Content Bar): Yes
(depend on countries)
Related Info: Yes (US /
Canada / MX(STB))
Photo Sharing Plus /
Photo Share Yes
Screen
mirroring(Miracast™) Yes
Social Viewing Yes
Trending on Twitter Yes (only US)
TV SideView™ Yes
Wi-Fi Certied Yes
Wi-Fi Direct Yes
Wi-Fi Frequency 2.4GHz /5GHz
Wi-Fi Standard a/b/g/n/ac
Wireless LAN Integrated
Power
Annual Power
Consumption 158 kWh/Year
Power Consumption
(in Operation) 174W
Power Consumption
(in Standby) 0.5W
Power Requirements
(frequency)
60Hz for UL cUL 50/60Hz
for other
Power Requirements
(voltage)
AC 120V for UL cUL
AC 110-240V for other
Regulation and Standards Compliance
VESA® Hole Pitch 11 7/8 x 11 7/8 inch (300
x 300 mm)
VESA® Hole Spacing
Compatible Yes
Sensing Features
LightSensor™
Technology Yes
Service and Warranty Information
Limited Warranty Term 12 months
TV System
Channel Coverage
(Analog)
VHF: 2-13/UHF: 14-69/
CATV: 1-135
Color Space sRGB/
Color System NTSC
Number of Tuners
(Terrestrial/Cable) 1 (Digital / Analog)
On-board Storage
(GB) 16GB
OS Android 6.0,
Marshmallow
Tuner Channel
Coverage (Digital
Cable)
CATV: 1-135
Tuner Channel
Coverage (Digital
Terrestrial)
VHF: 2-13/UHF: 14-69
TV System (Analog) M
TV System (Digital
Cable) Clear QAM
TV System (Digital
Terrestrial) ATSC
Video Features
Video Signal (analog) 1080p (60) / 1080i (60) /
720p (60) / 480p /480i
24p True Cinema Yes
4:3 Default Yes
4K Processor X1
Auto Wide Yes
Blinking Type Frame Blinking
HDR (High Dynamic
Range) compatiblity Yes
Live Color™
Technology Yes
Mastered in 4K Yes
Motionow™ XR
Technology Motionow XR
Panel Refresh Rate
(Native Hertz) 120Hz
PhotoTV HD Yes
1. 3,840 x 2,160 pixels.
2. Compared to standard LED HDTVs.
3. Broadband speed of at least 2.5 Mbps recommended for SD services, 10 Mbps for HD streaming or 4K downloads, 20 Mbps for 4K Ultra HD streaming. Wireless connectivity requires
802.11 home network (802.11n recommended). Network services, content, and the operating system and soware of this Product may be subject to individual terms and conditions and
changed, interrupted or discontinued at any time and may require fees, registration and credit card information.
4. Requires compatible devices connected to the same network. Google Cast requires mobile devices with Android 2.3 or higher, or iOS 6.0 or higher and Chromecast application.
Google Play using Android TV Remote Control application requires Android 4.0 or higher; not available for iOS. Voice Search is available using the included remote control, Android TV
Remote Control application with Android 4.0 or higher, or using Sony’s TV SideView application available for Android 4.0.3 or higher or iOS 7.0 or higher.
5. Requires HDR compatible content from supported streaming services, such as Netix, Ultra and Amazon Video.
6. Service not available in all areas. See www.psvue.com for details. Sony Entertainment Network Account is required. Network services, content, and the operating system and soware
of this Product may be subject to individual terms and conditions and changed, interrupted or discontinued at any time and may require fees, registration and credit card information.
7. Google Home device (sold separately) compatible with Sony TV’s powered by Android TV. Requires compatible devices connected to the same wireless home network. Download
the Google Home app from the iPhone App Store or Google Play. Subject to third party app terms and conditions. User must link compatible devices in order to control operation. Once
download is complete, the Google Home feature may be connected to the Sony device to access the voice control function.
© 2017 Sony Electronics Inc. All rights reserved. Reproduction in whole or in part without written permission is prohibited.
SonyX-Reality, Motionow, TRILUMINOS, TV SideView, X-tended Dynamic Range and the Sony logo are trademarks of Sony Corporation. PlayStation Vue logo is a trademark of Sony
Interactive Entertainment Inc. HDMI is a trademark of HDMI Licensing LLC. Android, Android TV, Google Cast, Google Play, Google, YouTube and the Google logo are registered
trademarks of Google Inc., used with permission. All other trademarks are trademarks of their respective owners. Features and specications are subject to change without notice.
/Updated: August 15, 2017
Picture Modes
Vivid, Standard, Custom,
Cinema Pro, Cinema
Home, Sports, Animation,
Photo-Vivid, Photo-
Standard, Photo-Custom,
Game, Graphics
Video Processing 4K X-Reality PRO
Wide Mode
Wide / Normal / Full /
Zoombr Normal / Full1 /
Full2 for PC
Weights and Measurements
Dimensions (Approx.)
TV only: 57 1/4 x 33 1/8 x
1 3/4(15/32) inch (1454 x
840 x 44 (11.2) mm)
TV with stand: 57 1/4
x 35 3/4 x 10 1/2 inch
(1454 x 905 x 266 mm)
Stand Width: 20 1/8 inch
(509 mm)
AC Cable Length: 1500
mm
Weight (Approx.)
TV only: 46.3 lb (21 Kg)
TV with stand: 48.7 lb
(22.1 Kg)
Accessories
Supplied Accessories
Voice Remote Control
(RMF-TX300U)
Batteries (R03)
AC Power Cord Spec (US
2pin,Pig-tail, at blades
Polarity)
IR Blaster (1-849-161-12)
Operating Instructions
Quick Setup Guide /
Supplement CUE (GA)
Table Top Stand
(Separate, assemble
required)
