Sony XS FB1330 User Manual Marketing Specifications XSFB1330 Mksp

User Manual: Sony XS-FB1330 Marketing Specifications

Open the PDF directly: View PDF PDF.
Page Count: 1

The perfect speaker upgrade for high-power handling and enhanced
bass. Sony FB car audio speakers deliver solid performance from
conventional size and nominal price.
© 2014 Sony Electronics Inc. All rights reserved. Reproduction in whole or in part without written permission is prohibited. Sony, MEGA BASS, and the Sony, MEGA BASS logos are trademarks
of Sony. All other trademarks are trademarks of their respective owners. Features and specications are subject to change without notice. Non-metric weights and measures are
approximate. Updated: May 31, 2016
• 3-way speaker system
• 5-1/4” Foamed-Mica Cellular Reinforced Woofers
• 1” Polyester Main Tweeter
• ¾” Piezo Super Tweeter for extended high-frequency
response
• Perfect compatibility with Sony MEX-N and CDG-G head
units
• Power Bass Response w/(60 – 24,000 Hz) Eective
Frequency Range
• 4 ohm Speaker Impedance
• 240 W Max Power Handling
• 35 W Rated Power Handling
Colors
Color Black and graphite
General
Magnet Ferrite
Material
Woofer: HOP+Aramid/Carbon ber
Tweeter: PEI
S-Tweeter: PEI
Power
Power Maximum
Capacity 240 Watts, Peak
Rated Power 35 Watts, Rated
Speaker
Frequency
Response 60 - 24,000 Hz
Impedance 4 ohm
Sensitivity 89+/-2 dB (1 W, 1 m)
Speaker
Dimensions
Woofer: 5 1/4 in. (13 cm)
Tweeter: 1 in. (2.5 cm)
S-Tweeter: 1/4 in. (0.6 cm)
Weights and Measurements
Depth (Approx.) 1 13/16 in. (4.5 cm)
Diameter
(Approx.) 5 1/4 in. (13 cm)
Weight (Approx.) 1 lb. 1 oz. per speaker (480 g)
Accessories
Supplied
Accessories
Parts for installation (1 Set)
User's Guide (1)
Speaker Design
The Sony® XS-GT1338F 5.25” speakers use a classic 3-way axial design. The woofer cone is constructed from HOP/Aramid
ber for smooth mid-range frequencies and the PEI tweeters delivers clear high frequncies.
Power Handling
The XS-GT1338F power handling is 230 Watts Max Power and 35 Watts Rated power.
XS-FB1330
FB - Car Audio Speakers
Specications
