Southern Telecom A600 Mobile Phone User Manual A600
Southern Telecom Inc. Mobile Phone A600
User Manual
QUICK-START USER GUIDE ANDROID 6.0
A600,UW6009K
ANDROID SMARTPHONE
PRECAUTIONS
On the Road
Using a device while driving is illegal in many countries. Please refrain from using
your mobile while driving.
Near Sensitive Electronics or Medical Equipment
Don’t use your device near sensitive electronic equipment – particularly medical
devices such as pacemakers – as it could cause them to malfunction. It can also interfere
with the operation of fire detectors and other automatic-control equipment.
While Flying
Your device can cause interference with aircraft equipment. So it’s essential you
follow airline regulations. And if airline personnel ask you to switch off your device,
or disable its wireless functions, please do as they say.
At a Petrol Station
Don’t use your device at petrol stations. In fact, it’s always best to switch off
whenever you’re near fuels, chemicals or explosives.
Making Repairs
Never take your device apart. Please leave that to the professionals. Unauthorised
repairs could break the terms of your warranty. Don’t use your device if the antenna
is damaged, as it could cause injury.
Around Children
Keep your mobile out of children’s reach. It should never be used as a toy as this
is hazardous.
Near Explosives
Turn off your device in or near areas where explosive materials are used. Always obey
local laws and turn off your device when requested.
Emergency Calls
To make an emergency call your device must be turned on and in an area where there’s
network coverage. Dial the national emergency number 112/911 (or other emergency call
number) and press “Send”. Explain exactly where you are and don’t hang up until help
has arrived.
Working Temperature
The working temperature for the device is between 0 and 40 degree Celsius. Please don’t
use
the device outside the range. Using the device under too high or too low temperature
might cause problems.
At very high volume, prolonged listening to a mobile device can damage your hearing.
1 .Front camera
2. Speaker
3. Touchscreen
4. Volume button
5. Power button
6. Back button
7. Home button
8. Menu button
9. Micro USB and charging port
10. Earphone jack
1. PARTS AND BUTTONS OF THE DEVICE
11. Rear camera
12. Flash
13. Speaker
14. Microphone
The button moves back one step to the previous menu/page.
The button returns immediately to the main screen.
The button displays a menu of recently opened applications.
The button will launch the applications and settings menu.
Installing the micro-SIM Card and Battery
Switch off your phone before installing or replacing the battery or the micro-SIM card.
Insert your fingernail into the slot at the bottom left of the back cover, and slide
fingernail across bottom of back cover to lift it off.
2. TOUCH BUTTONS
3. GETTING STARTED
WARNING!
To avoid damage to the phone, do not use any other kind of SIM card, or any
non-standard micro-SIM card cut from a SIM card. You can get a standard
micro-SIM card from your service provider.
Insert the battery by aligning the metal contacts on the battery with the metal
contacts in the battery compartment. Gently push down on the battery until it
clicks into place.
Align the back cover with the back of the phone and press the cover back into
place. Ensure that all the tabs are secure and there are no gaps around the
cover.
The home screen will look similar to the picture below. To switch between
screens, simply slide your finger left or right across the display.
The home screen contains shortcuts to your most-used applications and
4. HOME SCREEN
widgets.
The status bar displays system information, such as current time,
wireless connectivity and battery charge status.
When you receive a notification you can quickly view it by following
the below instructions. Slide your finger from the top of the screen
down to the center to access Notification Panel to see your
notifications.
Drag the notification menu down to display the second fast access menu,
the menu will look similar to the below image.
5.QUICK NOTIFICATION PANEL
Through this menu, it is possible to modify the functions such as
brightness, auto rotation, Wi-Fi, Bluetooth and more.
The settings menu allows you to adjust Tablet cellphone System
Confguration.
To Change Settings:
1. Touch the “Settings” menu icon on the Application menu. The
Settings menu will open.
2. Touch a category title to view further options on the right side of
the screen.
• Wi-Fi – Connect to/disconnect from wireless networks, view
connection status
• Data usage – Enable/disable mobile data, view current usage, set
mobile data limit
(note: this function is available only on devices supplied with 3G card
functionality)
• Bluetooth – Connect or disconnect Bluetooth devices
• Display – Adjust display settings
• Smart Gesture settings – “ON” / “OFF”
• Audio Profiles – Adjust the different audio settings such as
ringtones
• Prompts and notifications – Adjust different notification settings
• Storage – View your phone’s internal and external storage settings
• Battery – View the status of your battery and make adjustments to
power consumption
• Apps – A list of all apps downloaded and running
6. SETTINGS MENU
• Delete applications – Select apps to delete
• Location services – Change approximate location detection, improve
search results, GPS satellites
• Security – Adjust phone’s security settings
• Accounts – Add or remove email and Google accounts such as Gmail,
Google
• Language and input Select language – add to the dictionary, edit
on-screen keyboard settings, vocal search, etc.
• Backup and reset – Backup and restore data, perform factory reset,
etc.
• Date and time – Set date, time zone, time, clock format etc.
• Accessibility – Set up large text, auto-rotate screen, speak password
etc.
• About Phone – Displays information about your phone
1. When phone is powered off insert a SIM card by removing the SIM cover
as illustrated above, insert your finger in the indent located near the
charging port and unclip the SIM cover, then insert the SIM card. Please
take note of the direction of insertion following the diagram on the
phone’s SIM port.
2. After inserting a SIM card, turn on the phone and wait a few minutes
for your phone to display Network information.
Inserting and Removing TF Card
NB: Please ensure when inserting an SD card your phone is powered “OFF”
1. Insert the TF card into the TF card slot located under the SIM card
cover as explained in the Inserting/Removing SIM card section. Gently
push TF card into slot until it clicks into place.
2. A prompt will be seen on the screen saying “Preparing SD card”.
Removing TF Card
7. INSERTING/REMOVING SIM CAEDS
1. Close all applications and documents which have been opened from the
TF card.
2. Select “Settings” and find “Storage” then click “Unmount SD
card”.
3. A prompt will be seen on the screen saying “SD card safe to remove”.
4. Gently press the TF card to remove and pull out the TF card.
Once your SIM cards are installed turn on your phone and wait a few
minutes for your phone to find a network.
Then select the Call icon. Here you can dial a number or select
a contact from your stored contacts list to call. You can also view
outgoing and incoming calls that have been made, as well as adding or
removing contacts.
8. MAKING AND RECEIVING CALLS
9. ANSWERING AND REJECTING CALLS
To answer a call – Slide your finger to the blue Call Answer key.
To reject a Call – Slide your finger to the Red Call End key.
The phone has a software keyboard which automatically displays when you
tap the place on screen where you want text or numbers to be entered,
then simply start typing.
Touchscreen
10. SOFTWARE KEYBOARD
The touchscreen responds to finger touch.
Note:
• Don’t place any object on the touchscreen for it may damage or
crush the screen.
Single Click: Single click one icon to choose the icon or option you
want.
Long Press: Press and hold an icon to delete or move an icon or app.
Drag: Press the icon and drag it to a different screen.
Note:
• Turn on your phone before connecting the phone to a PC by USB cable.
1. Use a USB cable to connect the phone with a computer. The phone will
automatically detect a USB connection.
2. A notification will pop up on the screen displaying USB connected,
select the desired USB operation.
3. The USB connection has been successful.
Wireless:
1. Select “Settings”.
2. Select “Wi-Fi” and slide OFF to ON status.
3. All detected wireless networks in the area will be listed. Click to
select desired wireless connection.
4. Enter network key if necessary.
11. HOW TO CONNECT TO A COMPUTER
12. CONNECTION TO INTERNET
5. Once connected to a wireless network, settings will be saved.
6. Wireless icon will appear on the taskbar when connected successfully.
Note:
• When the phone detects the same wireless network in the future, the
device will connect to he network automatically with the same password
record.
Please Note: Cell Data may be turned “OFF” as a factory setting, to
allow data to flow through your network provider please turn Cell Data
“ON” either from your quick drop down menu or in > Settings > Cell
Data, you will not be able to access the Internet when Cell Data is “OFF”
and not connected to Wi-Fi.
NB: Mobile Data charges apply when this setting is “ON” – Data will
be passed through your network provider.
Web Browsing
Connect to the Internet and launch the browser.
Type in the desired browsing URL.
13. MOBILE DATA AND INTERNET
Select “Settings”, select Bluetooth from “OFF” to “ON”.
Search for the device you would like to pair with and select “PAIR”.
You will see a message “Connected Successfully”.
Touch the icon to enter camera mode and the interface is shown
as follows:
14.BLUETOOTH
15. CAMERA
1. Touch the icon to take a photo.
2. Touch the icon to start camera recording.
3. Touch the icon on the top right to see the previous picture
and to delete, share or set it as a wallpaper. Click the return button
to exit camera interface.
4. Touch the icon to switch from front to back camera.
How to Close Applications
When an application is not responding you can manually shut the app down
in “Running Services” menu. This will ensure the system responds as
desired. Please shut down all idle applications to release memory and
get the system speed back to normal. To close the application, click
the icon on the shortcut bar to enter the system configuration
interface. Select the Application Running and the interface is
16.TROUBLE SHOOTING
Tap the application you want to close. A pop-up window will be displayed.
Tap “Stop” to close that application.
Power “OFF” / Restart / Reset the Phone
1. Press and hold the power button for 5 seconds and the device will
be powered down.
2. Press the reset button located under the power button with a sharp
object and the device will be forced to restart.
Restore Default Setting
If you want to reset the phone to factory settings and erase all
materials, please press Settings Backup and reset
Factory data reset.
WARNING:
actory Data Reset setting will delete ALL your data and system con guration as fi
well as any downloaded apps. Please use this function carefully.
FCC Warning:
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Any Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate
the equipment.
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more
of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
The SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue.
Device types A600, UW6009K (FCC ID: 2ABV4-A600) has also been tested
against this SAR limit. The highest reported SAR values for head,
body-worn accessory, and product specific (Hotspot) are 0.60 W/kg, 0.78
W/kg, and 0.81 W/kg respectively. The Max simultaneous SAR is 0.99W/kg.
This device was tested for typical body-worn operations with the back
of the handset kept 10mm from the body. To maintain compliance with FCC
RF exposure requirements, use accessories that maintain a 10mm
separation distance between the user's body and the back of the handset.
The use of belt clips, holsters and similar accessories should not
contain metallic components in its assembly. The use of accessories that
do not satisfy these requirements may not comply with FCC RF exposure
requirements, and should be avoided.
