User’s Guide
1
Wireless Network Card Series
User’s
Guide
User’s Guide
2
WMIR-269GN
802.11b/g/n Mini-PCI Module
Ralink RT2880, 2T2R
Chipset
CPU/
Mac/BB
Processor
Ralink RT2880
RF Chip Ralink RT2820
Memory
8Mbytes SDRAM
Host Interface
32-bit mini-PCI (Non-standard)
LED Indicator
Power / Activity
Radio
Antenna 3x I-pex Connectors (2T/2R)
[CON0:Tx0/Rx0, CON1:Tx1/Rx1, CON2:RX2]
Operating
Frequency 2.400 ~ 2.484GHz(Subject to Local Regulations)
IEEE 802.11b：(DSSS)
5.5/11 Mbps(CCK),
2 Mbps(DQPSK),
1 Mbps(DBPSK)
IEEE 802.11g：(OFDM/DSSS)
48/54 Mbps(QAM-64),
24/36 Mbps(QAM-16),
12/18 Mbps(QPSK),
6/9Mbps (BPSK)
Modulation
IEEE 802.11n：(OFDM/DSSS)
QAM-64, QAM-16,
QPSK, BPSK
Output
Powerv(peak
power)
11g: 24 dBm
11b: 21 dBm
11N HT20: 25 dBm
11N HT40: 24.5 dBm
802.11b:
-90dBm@1Mbps, ±2dB -88dBm@2Mbps, ±2dB
-86dBm@5.5Mbps , ±2dB
-83dBm@11Mbps, ±2dB
Receive
Sensitivity
802.11g:
-86dBm@6Mbps, ±2dB -84dBm@9Mbps, ±2dB
-82dBm@12Mbps , ±2dB -80dBm@18Mbps, ±2dB
-78dBm@24Mbps, ±2dB -75dBm@36Mbps, ±2dB
-72dBm@48Mbps , ±2dB -70dBm@54Mbps, ±2dB
Receive
Sensitivity
802.11n
MCS HT20 HT40
0 -85dBm, ±2dB -83dBm, ±2dB
1 -83dBm, ±2dB -81dBm, ±2dB
2 -81dBm, ±2dB -79dBm, ±2dB
3 -80dBm, ±2dB -76dBm, ±2dB
4 -78dBm, ±2dB -72dBm, ±2dB
5 -74dBm, ±2dB -69dBm, ±2dB
6 -71dBm, ±2dB -65dBm, ±2dB
7 -67dBm, ±2dB -62dBm, ±2dB
8 -85dBm, ±2dB -83dBm, ±2dB
9 -83dBm, ±2dB -81dBm, ±2dB
10 -80dBm, ±2dB -78dBm, ±2dB
11 -78dBm, ±2dB -75dBm, ±2dB
12 -75dBm, ±2dB -71dBm, ±2dB
13 -71dBm, ±2dB -69dBm, ±2dB
14 -68dBm, ±2dB -64dBm, ±2dB
15 -65dBm, ±2dB -61dBm, ±2dB
SPECIFICATION
Power
consumption TX: 950mA@2Tx(Max.) RX: 800mA@3Rx(Max.)
Operating
Voltage DC 3.3V ± 5% CPU Core
Voltage 1.2Vdc
Driver Linux
Environmental
Temperature Humidity
Operating 0 ~ 50°C 20% to 85% Non-Condensing
Storage -20 ~ 80°C 10% to 90% Non-Condensing
Physical Specification
Dimensions 59.6x61.5x4.8 mm
Weight 15g
User’s Guide
3
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance
20cm between the radiator & your body.
This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
The availability of some specific channels and/or operational frequency bands are
country dependent and are firmware programmed at the factory to match the intended
destination. The firmware setting is not accessible by the end user.
User’s Guide
4
This device is intended only for OEM integrators under the following conditions:
1) The antenna must be installed such that 20 cm is maintained between the antenna
and users, and
2) The transmitter module may not be co-located with any other transmitter or antenna,
3) For all products market in US, OEM has to limit the operation channels in CH1 to
CH11 for 2.4G band by supplied firmware programming tool. OEM shall not supply
any tool or info to the end-user regarding to Regulatory Domain change.
As long as 3 conditions above are met, further transmitter test will not be required.
However, the OEM integrator is still responsible for testing their end-product for any
additional compliance requirements required with this module installed.
IMPORTANT NOTE: In the event that these conditions can not be met (for example
certain laptop configurations or co-location with another transmitter), then the FCC
authorization is no longer considered valid and the FCC ID can not be used on the final
product. In these circumstances, the OEM integrator will be responsible for re-evaluating
the end product (including the transmitter) and obtaining a separate FCC authorization.
End Product Labeling
This transmitter module is authorized only for use in device where the antenna may be
installed such that 20 cm may be maintained between the antenna and users. The final
end product must be labeled in a visible area with the following: “Contains FCC ID:
RYK-WMIR269GN”.
Manual Information To the End User
The OEM integrator has to be aware not to provide information to the end user regarding
how to install or remove this RF module in the user’s manual of the end product which
integrates this module.
The end user manual shall include all required regulatory information/warning as show in
this manual.
User’s Guide
5
Canadian Regulatory Wireless Notice
This device complies with RSS-210 of the Industry Canada Rules. Operation is subject
to the following two conditions:
1) this device may not cause interference and
2) this device must accept any interference, including interference that may cause
undesired operation of the device
IMPORTANT NOTE:
Canada Radiation Exposure Statement:
This equipment complies with Canada radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator and your body.
