SparkLAN Communications WMIR278GN 11GN mini-PCI User Manual WMIR 278GN FCC IC
SparkLAN Communications, Inc. 11GN mini-PCI WMIR 278GN FCC IC
UserMan_RYK-WMIR278GN
User’s Guide
1
Wireless Network Card Series
User’s Guide
User’s Guide
2
Product Name 11Mbps/54Mbps/300Mbps
802.11b/g/n draft WLAN MIMO mini PCI card
Model Number WMIR-278GN
Host Interface Mini PCI type 3B
Chipset solution Ralink, RT3062 ( MAC/BBP/RF)
RF chain 2T2R for HT20, HT40
Guard interval ( GI ) Long/Short GI for both HT20 and HT40
Dimension 59.75mm*44.6mm*3.55mm
Weight 7g
Frequency Band 802.11b
ISM band 2.400 ~ 2.484GHz (subject to local regulations)
802.11g
ISM band 2.400 ~ 2.484GHz (subject to local regulations)
802.11n draft
ISM band
2422 – 2452MHz (channel BW=40MHz)
2400 – 2483.5MHz (channel BW=20MHz)
Number of Channel 802.11b
USA and Canada – 11
Most European countries – 13
Japan – 14
France – 4
802.11g
USA and Canada – 11
Most European countries – 13
Japan – 14
HT20
USA and Canada – 11
Most European countries – 13
WMIR-278GN
802.11b/g/n Mini-PCI Module
SPECIFICATION
User’s Guide
3
Japan – 13
HT40
USA and Canada – 3~9
Most European countries – 3~9
Operating Voltage 3.3V ± 5%
Spreading 802.11b
Direct Sequence Spread Spectrum (DSSS)
802.11g
Orthogonal Frequency Division Multiplexing (OFDM)
HT20
Orthogonal Frequency Division Multiplexing (OFDM)
Multiple-input/multiple-output (MIMO)
HT40
Orthogonal Frequency Division Multiplexing (OFDM)
Multiple-input/multiple-output (MIMO)
Modulation 802.11g
64 QAM, 16 QAM, QPSK, BPSK
802.11b
CCK, DQPSK, DBPSK
HT20, HT40
64 QAM, 16 QAM, QPSK, BPSK
Data Rate 802.11b
11, 5.5, 2, 1 Mbps per channel, auto fallback for extended range
802.11g
54, 48, 36, 24, 18, 12, 9, 6 Mbps per channel, auto fallback for extended
range
HT20
Refer to HT20 output power table
HT40
Refer to HT40 output power table
Antenna Two antenna connectors,
Two antenna port for TX/RX.
Transmitted power
802.11b
1Tx ~ 15 +/-1.5dBm@ch1~ch14
802.11g
1Tx ~ 14 +/-1.5dBm@ch1~ch14
HT20
please see the output power table for detail. tolerance: +/-1.5dBm
HT40
User’s Guide
4
please see the output power table for detail. tolerance: +/-1.5dBm
Receive Sensitivity
Nominal Temp Range:
802.11b (1Rx)
Typ. 1Mbps, -93dBm
Typ. 2Mbps, -93dBm
Typ. 5.5Mbps, -92dBm
Typ. 11Mbps, -90dBm
802.11g (2Rx)
Typ. 6Mbps, -93dBm
Typ. 9Mbps, -93dBm
Typ. 12Mbps, -92dBm
Typ. 18Mbps, -90dBm
Typ. 24Mbps, -87dBm
Typ. 36Mbps, -84dBm
Typ. 48Mbps, -80dBm
Typ. 54Mbps, -78dBm
HT20 (2Rx)
Typ. MCS=0, -93dBm
Typ. MCS=1, -91dBm
Typ. MCS=2, -88dBm
Typ. MCS=3, -86dBm
Typ. MCS=4. -83dBm
Typ. MCS=5, -79dBm
Typ. MCS=6, -77dBm
Typ. MCS=7, -75dBm
Typ. MCS=8, -91dBm
Typ. MCS=9, -88dBm
Typ. MCS=10, -86dBm
Typ. MCS=11, -83dBm
Typ. MCS=12, -80dBm
Typ. MCS=13, -75dBm
Typ. MCS=14, -74dBm
Typ. MCS=15, -72dBm
HT40 (2Rx)
Typ. MCS=0, -90dBm
Typ. MCS=1, -88dBm
Typ. MCS=2, -85dBm
Typ. MCS=3, -83dBm
Typ. MCS=4, -80dBm
User’s Guide
5
Typ. MCS=5, -76dBm
Typ. MCS=6, -74dBm
Typ. MCS=7, -72dBm
Typ. MCS=8, -88dBm
Typ. MCS=9, -85dBm
Typ. MCS=10, -83dBm
Typ. MCS=11, -80dBm
Typ. MCS=12, -77dBm
Typ. MCS=13, -72dBm
Typ. MCS=14, -71dBm
Typ. MCS=15, -69dBm
Power consumption
(Average)
802.11b
Continue TX : 470mA@3.3V
Continue RX : 250mA@3.3V
802.11g
Continue TX : 420mA@3.3V
Continue RX : 250mA@3.3V
HT20
Continue TX : 530mA@3.3V
Continue RX : 260mA@3.3V
HT40
Continue TX : 550mA@3.3V
Continue RX : 290mA@3.3V
LED indicator N/A
Supplied Driver Windows 2000/XP 32/Vista 32/Win7 32, please refer to software spec in
detail.
Standards IEEE 802.11b, IEEE 802.11g i3standard, Wi-Fi compliant ,EWC 802.11n
draft
Temperature Range 0 ~ 55°C (Operating); -20 ~ 80°C (Storing)
Humidity Operating Humidity 10% to 85% Non-Condensing
Storage Humidity 5% to 90% Non-Condensing
Network Protocol TCP/IP, IPX, NDIS4, and NDIS5x
Management Utility Monitor Internet Access Status via UI
System Requirements Laptop containing
miniPCI slot
64MB memory or greater
300MHz processor or greater
Microsoft Windows 2000/XP 32/Vista 32/Win7 32
User’s Guide
6
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance
20cm between the radiator & your body.
This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
The availability of some specific channels and/or operational frequency bands are
country dependent and are firmware programmed at the factory to match the intended
destination. The firmware setting is not accessible by the end user.
User’s Guide
7
This device is intended only for OEM integrators under the following conditions:
1) The antenna must be installed such that 20 cm is maintained between the antenna
and users, and
2) The transmitter module may not be co-located with any other transmitter or antenna,
3) For all products market in US, OEM has to limit the operation channels in CH1 to
CH11 for 2.4G band by supplied firmware programming tool. OEM shall not supply
any tool or info to the end-user regarding to Regulatory Domain change.
As long as 3 conditions above are met, further transmitter test will not be required.
However, the OEM integrator is still responsible for testing their end-product for any
additional compliance requirements required with this module installed.
IMPORTANT NOTE: In the event that these conditions can not be met (for example
certain laptop configurations or co-location with another transmitter), then the FCC
authorization is no longer considered valid and the FCC ID can not be used on the final
product. In these circumstances, the OEM integrator will be responsible for re-evaluating
the end product (including the transmitter) and obtaining a separate FCC authorization.
End Product Labeling
This transmitter module is authorized only for use in device where the antenna may be
installed such that 20 cm may be maintained between the antenna and users. The final
end product must be labeled in a visible area with the following: “Contains FCC ID:
RYK-WMIR278GN”.
Manual Information To the End User
The OEM integrator has to be aware not to provide information to the end user regarding
how to install or remove this RF module in the user’s manual of the end product which
integrates this module.
The end user manual shall include all required regulatory information/warning as show in
this manual.
User’s Guide
8
Canadian Regulatory Wireless Notice
This device complies with RSS-210 of the Industry Canada Rules. Operation is subject
to the following two conditions:
1) this device may not cause interference and
2) this device must accept any interference, including interference that may cause
undesired operation of the device
IMPORTANT NOTE:
Canada Radiation Exposure Statement:
This equipment complies with Canada radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator and your body.
