SparkLAN Communications WPEA128N 802.11abgn Mini PCIe module User Manual

SparkLAN Communications, Inc. 802.11abgn Mini PCIe module

User manual

WPEA-128N
PRODUCT SPECIFICATION
Standard
IEEE 802.11abgn
Chipset solution
Atheros AR9380-AL1A
Radio stream
3T3R
Antenna Type / con.
3 U.FL connectors
Bus Interface
PCI Express
Form Factor
Mini PCIe
Data Rate
IEEE 802.11b: 11, 5.5,2,1Mbps
IEEE 802.11g: 54, 48, 36, 24, 18, 12, 9, 6Mbps
IEEE 802.11a: 54, 48, 36, 24, 18, 12, 9, 6 Mbps
IEEE 802.11n: MCS 0 to 23 for HT20MHz
MCS 0 to 23 for HT40MHz
Media Access Control
CSMA/CA with ACK
Spreading /Modulation
Techniques
802.11a: OFDM (BPSK, QPSK, 16-QAM, 64-QAM)
802.11b: DSSS (DBPSK, DQPSK, CCK)
802.11g: OFDM (BPSK,QPSK,16-QAM,64-QAM)
802.11n: OFDM (BPSK,QPSK,16-QAM,64-QAM)
Frequency Range
2.4GHz: 11b/g/n: 2.400 ~ 2.4835GHz
5GHz: 11a/n: 5.180 ~ 5.825GHz
Transmit Output Power
(Tolerance: +/-2dBm)
802.11a: 12dBm ± 2dBm@54Mbps
802.11b: 17dBm ± 2dBm@11Mbps
802.11g: 16dBm ± 2dBm@54Mbps
802.11gn HT20: 16dBm ± 2dBm@MCS0
802.11gn HT20: 15dBm ± 2dBm@MCS7
802.11gn HT40: 15dBm ± 2dBm@MCS0
802.11gn HT40: 14dBm ± 2dBm@MCS7
802.11an HT20: 15dBm ± 2dBm@MCS0
802.11an HT20: 12dBm ± 2dBm@MCS7
802.11an HT40: 14dBm ± 2dBm@MCS0
802.11an HT40: 11dBm ± 2dBm@MCS7
Receiver Sensitivity
(Tolerance: +/-2dBm)
802.11a: -81dBm ≤ 2dBm@54Mbps
802.11b: -92dBm ≤ 2dBm@11Mbps
802.11g: -82dBm ≤ 2dBm@54Mbps
802.11gn HT20: -79dBm ≤ 2dBm@MCS7
802.11gn HT40: -76dBm ≤ 2dBm@MCS7
802.11an HT20: -78dBm ≤ 2dBm@MCS7
802.11an HT40: -74dBm ≤ 2dBm@MCS7
Operating Voltage
DC 3.3V +/- 5%
Power Consumption
TX Mode: 760mA(Max)
RX Mode: 220mA(Max),
Associated Idle: 190 mA
Temperature Range
0° ~ +50°C (Operating), -20°~+60°C (Storing)
Humidity (non-condensing)
10~90%(Operating), 5~90%(Storing)
Security
WEP / WPA / WPA2
OS supported
Windows XP/Vista/Win7/ Linux
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
IMPORTANT NOTE:
Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
Country Code selection feature to be disabled for products marketed to the US/CANADA
Operation of this device is restricted to indoor use only
This device is intended only for OEM integrators under the following conditions:
1) The antenna must be installed such that 20 cm is maintained between the antenna
and users, and
2) The transmitter module may not be co-located with any other transmitter or antenna,
3) For all products market in US, OEM has to limit the operation channels in CH1 to
CH11 for 2.4G band by supplied firmware programming tool. OEM shall not supply
any tool or info to the end-user regarding to Regulatory Domain change.
As long as 3 conditions above are met, further transmitter test will not be required. However,
the OEM integrator is still responsible for testing their end-product for any additional
compliance requirements required with this module installed
IMPORTANT NOTE
In the event that these conditions can not be met (for example certain laptop configurations or
co-location with another transmitter), then the FCC authorization is no longer considered valid
and the FCC ID can not be used on the final product. In these circumstances, the OEM
integrator will be responsible for re-evaluating the end product (including the transmitter) and
obtaining a separate FCC authorization.
End Product Labeling
This transmitter module is authorized only for use in device where the antenna may be
installed such that 20 cm may be maintained between the antenna and users. The final end
product must be labeled in a visible area with the following: “Contains FCC ID:
RYK-WPEA128N”.
Manual Information to the End User
The OEM integrator has to be aware not to provide information to the end user regarding how
to install or remove this RF module in the user’s manual of the end product which integrates
this module.
The end user manual shall include all required regulatory information/warning as show in this
manual.
Antenna Model
Antenna Type
Connector
2400~2483.5MHz
5725~5850MHz
GEC6200
Dipole
RP-SMA Plug
3dbi
5 dBi
RFA-25-T42-M32-N
Dipole
RP-SMA Plug
2.9 dBi
4.5dBi
