WPEA-252NI
Specifications
Standard IEEE 802.11abgn
Chipset solution AR9592-AR1B
Radio stream 2T2R
Antenna Type / con. 2 U.FL connectors
Bus Interface PCI Express
Form Factor Mini-PCIe
Data Rate
802.11b: 11, 5.5,2,1Mbps
802.11g: 54, 48, 36, 24, 18, 12, 9, 6Mbps
802.11a: 54, 48, 36, 24, 18, 12, 9, 6 Mbps
802.11n: MCS 0 to 15 for HT20MHz
MCS 0 to 15 for HT40MHz
Media Access Control CSMA/CA with ACK
Spreading /Modulation
Techniques
802.11a: OFDM (BPSK, QPSK, 16-QAM, 64-QAM)
802.11b: DSSS (DBPSK, DQPSK, CCK)
802.11g: OFDM (BPSK,QPSK,16-QAM,64-QAM)
802.11n: OFDM (BPSK,QPSK,16-QAM,64-QAM)
Frequency Range 2.4GHz: 11b/g/n: 2.400 ~ 2.4835GHz
5GHz: 11a/n: 5.150GHz ~ 5.825GHz
Transmit Output Power
(Tolerance: +/-2dBm)
802.11a: 14dBm ± 2dBm@54Mbps
802.11b: 19dBm ± 2dBm@11Mbps
802.11g: 16dBm ± 2dBm@54Mbps
802.11gn HT20: 18dBm ± 2dBm@MCS0
802.11gn HT20: 15dBm ± 2dBm@MCS7
802.11gn HT40: 17dBm ± 2dBm@MCS0
802.11gn HT40: 14dBm ± 2dBm@MCS7
802.11an HT20: 18dBm ± 2dBm@MCS0
802.11an HT20: 12dBm ± 2dBm@MCS7
802.11an HT40: 17dBm ± 2dBm@MCS0
802.11an HT40: 11dBm ± 2dBm@MCS7
Receiver Sensitivity
(Tolerance: +/-2dBm)
802.11a: -72dBm ± 2dBm@54Mbps
802.11b: -90dBm ± 2dBm@11Mbps
802.11g: -73dBm ± 2dBm@54Mbps
802.11gn HT20: -84dBm ± 2dBm@MCS0
802.11gn HT20: -69dBm ± 2dBm@MCS7
1
802.11gn HT40: -82dBm ± 2dBm@MCS0
802.11gn HT40: -65dBm ± 2dBm@MCS7
802.11an HT20: -89dBm ± 2dBm@MCS0
802.11an HT20: -69dBm ± 2dBm@MCS7
802.11an HT40: -85dBm ± 2dBm@MCS0
802.11an HT40: -67dBm ± 2dBm@MCS7
Operating Voltage 3.3 V ±10% I/O supply voltage
Power Consumption
TX Mode: 1050mA
RX Mode: 300mA
Associated Idle: 50mA
Temperature Range -40~+85°C (Operating)
Humidity
(non-condensing) 10~85 % (Operating), 5~90 % (Storing)
Security WEP / WPA / WPA2, 802.1x
OS supported Windows XP/Vista/Win7/Win8, Linux
2
Federal Communication Commission Interference Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate this equipment.
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
Operations in the 5.15-5.25GHz band are restricted to indoor usage only.
Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
This device is intended only for OEM integrators under the following conditions:
1) The antenna must be installed such that 20 cm is maintained between the antenna and users,
and
2) The transmitter module may not be co-located with any other transmitter or antenna.
3
As long as 2 conditions above are met, further transmitter test will not be required. However, the
OEM integrator is still responsible for testing their end-product for any additional compliance
requirements required with this module installed
IMPORTANT NOTE: In the event that these conditions can not be met (for example certain
laptop configurations or co-location with another transmitter), then the FCC authorization is no
longer considered valid and the FCC ID can not be used on the final product. In these
circumstances, the OEM integrator will be responsible for re-evaluating the end product
(including the transmitter) and obtaining a separate FCC authorization.
End Product Labeling
This transmitter module is authorized only for use in device where the antenna may be installed
such that 20 cm may be maintained between the antenna and users. The final end product must be
labeled in a visible area with the following: “Contains FCC ID: RYK-WPEA252NI”. The
grantee's FCC ID can be used only when all FCC compliance requirements are met.
Manual Information To the End User
The OEM integrator has to be aware not to provide information to the end user regarding how to
install or remove this RF module in the user’s manual of the end product which integrates this
module.
The end user manual shall include all required regulatory information/warning as show in this
manual.
