SparkLAN Communications WUBM273ACN 802.11ac/b/g/n USB module User Manual WUBM 273ACN

SparkLAN Communications, Inc. 802.11ac/b/g/n USB module WUBM 273ACN

Contents

WUBM-273ACN User Manual

WUBM-273 ACN
Standard
802.11ac/b/g/n
Chipset
Mac/BB/RF
MediaTek MT7612U
Host Interface
USB Type A or 12-pin wafer connector
Form Factor
USB Module
Data Rates
802.11a: 6~54Mbps / 802.11b: 1~11Mbps / 802.11g: 6~54Mbps
802.11n: MCS0 ~ MCS15 / 802.11ac: MCS0 ~ MCS9
Radio
Antenna
2 x U.FL connectors or printed antenna, 2T2R
Operating Frequency
ac/n ISM Band: 5.150GHz ~ 5.850GHz
b/g/n ISM Band: 2.400GHz ~ 2.4835GHz
*subject to local regulations
Modulation
802.11a: OFDM (BPSK, QPSK,16-QAM, 64-QAM)
802.11b: DSSS (DBPSK, DQPSK, CCK)
802.11g: OFDM (BPSK, QPSK,16-QAM, 64-QAM)
802.11n: OFDM (BPSK, QPSK,16-QAM, 64-QAM)
802.11ac: OFDM (BPSK, QPSK,16-QAM, 64-QAM, 256-QAM)
Output Power
802.11b: 15dBm ± 2dBm@11Mbps
802.11a: 12dBm ± 2dBm@54Mbps / 802.11g: 13dBm ± 2dBm@54Mbps
802.11gn (HT20): 12dBm ± 2dBm@MCS7 / 802.11gn (HT40): 12dBm ± 2dBm@MCS7
802.11an (HT20): 11dBm ± 2dBm@MCS7 / 802.11an (HT40): 11dBm ± 2dBm@MCS7
802.11ac (VHT80): 10dBm ± 2dBm@MCS9
Receive Sensitivity
802.11b: ≤ -76dBm@11Mbps
802.11a: ≤ -65dBm@54Mbps / 802.11g: ≤ -65dBm@54Mbps
802.11gn (HT20): ≤ -64dBm@MCS7 / 802.11gn (HT40): ≤ -61dBm@MCS7
802.11an (HT20): ≤ -64dBm@MCS7 / 802.11an (HT40): ≤ -61dBm@MCS7
802.11ac (VHT80): ≤ -51dBm@MCS9
Operating Voltage
DC 5V /0.9A
Environmental
Temperature Range
0 ~ 40°C (Operating) / -10 ~ 70°C (Storing)
Humidity
(Non-Condensing)
10% ~ 85% (Operating) / 5% ~ 90% (Storing)
Physical Specification
Dimensions
55mm x 25mm x 3.3mm (± 0.5mm)
Weight
≤ 7g
Software
Driver
Windows XP/ Vista, Win 7, Win 8, Linux , Android by request
Security
WEP, WPA, WPA2, 802.1x
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device
may not cause harmful interference and (2) this device must accept any interference received, including interference
that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 o
f the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residentia
l installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guar
antee that interference will not occur in a particular installation. If this equipment does cause harmful interference to r
adio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures: ‐Reorient or relocate the receiving antenna. ‐
Increase the separation between the equipment and receiver. ‐
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ‐
Consult the dealer or an experienced radio/TV technician for help.
You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could
void your authority to operate the equipment.
FCC RF Radiation Exposure Statement: 1. This Transmitter must not be co‐
located or operating in conjunction with any other antenna or transmitter. 2.
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipm
ent should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.
According to FCC 15.407(e), the device is intended to operate in the frequency band of 5.15GHz to 5.25GHz under all
conditions of normal operation. Normal operation of this device is restricted to indoor used only to reduce any potenti
al for harmful interference to co‐channel MSS operations.
Information to OEM integrator
The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove thi
s RF module in the user manual of the end product. The user manual which is provided by OEM integrators for end us
ers must include the following information in a prominent location.
1. To comply with IC RF exposure compliance requirements, the antenna used for this transmitter must be installed to
provide a separation distance of at least 20 cm from
all persons and must not be co-located or operating in conjunction with any other
antenna or transmitter, except in accordance with IC multi‐transmitter product transmitter product procedures.
2. Only those antennas with same type and lesser gain filed under this IC ID number can be used with this device.
3. The regulatory label on the final system must include the statement: “Contains IC ID: xxxx “.
4. The final system integrator must ensure there is no instruction provided in the user manual or customer documenta
tion indicating how to install or remove the transmitter module except such device has implemented two
ways authentication between module and the host system.
5. If the end product integrating this module is going to be operated in 5.15 ~5.25GHz frequency range, the warning
statement in the user manual of the end product should include the restriction of operating this device in indoor could
void the user’s authority to operate the equipment.
