Quick Start Guide
Spectralink 87-Series Handsets
Corporate Sync
If supported in your facility, your PIVOT supports over-the-air
synchronization with corporate contacts, email and calendars.
Contact your system administrator for details on how to set
this up on your device.
Barcode Reader (8753 only)
The barcode reader is activated by an application that utilizes the
scanned barcode as data. Both 1D and 2D types of barcodes can
be scanned. Open the application that requires a barcode scan
and hold the device in a horizontal position and press the scan
button. The data is entered in the text fi eld.
Spectralink SAFE
If available in your facility, the Spectralink SAFE application
receives and can respond to signs of distress. As programmed
by your administrator, the device may send an alarm if it senses
running, becomes unusually tilted, or is still for a period of time.
Any of these conditions might indicate that the user is in trouble
and needs help. The Spectralink SAFE application can also
enable a Panic button that will place an emergency call
when pressed.
Applications in Webview
Applications that have been specifi cally developed for your facility
are opened by tapping a shortcut widget in the Application box.
Battery Pack
The Battery Pack can be removed and charged in the Quad
Charger which is especially designed for shift use. The battery
itself clips into a carrier and does not need to be removed from
the carrier before charging it in the Quad Charger.
Always start every shift with a fully charged battery.
Removal: Slide the carrier latch towards the phone body to
remove the Battery Pack.
remove the Battery Pack.
Latch
Slide this way
Push-to-Talk
If activated in your facility, the PTT feature allows your PIVOT
to operate in a group broadcast mode, where a single handset
can transmit to multiple listeners, like a two-way radio.
Replacement: To replace the Battery Pack, slip the tabs at the
top of the carrier into the corresponding slots at the top of the
battery cavity. Gently press the bottom of the Battery Pack until
it snaps into place. The Battery Pack should snap into position
with minimal pressure.
Tabs
Press here
Index fi nger is pressing
the scan button.
![](/img.php?id=2183818&img=bg2.png)
720-0002-100 Revision A
Contact Information
Spectralink Corporation
US Location European Location
800-775-5330 +45 7560 2850
2560 55th Street Spectralink Europe ApS
Boulder, CO 80301 Langmarksvej 34
info@spectralink.com 8700 Horsens
infodk@spectralink.com
Copyright Notice
© 2014 Spectralink Corporation All rights reserved. SpectralinkTM, the Spectra-
link logo and the names and marks associated with Spectralink’s products are
trademarks and/or service marks of Spectralink Corporation and are common
law marks in the United States and various other countries. All other trademarks
are property of their respective owners. No portion hereof may be reproduced or
transmitted in any form or by any means, for any purpose other than the recipient’s
personal use, without the express written permission of Spectralink.
All rights reserved under the International and pan-American copyright Conven-
tions. No part of this manual, or the software described herein, may be reproduced
or transmitted in any form or by any means, or translated into another language or
format, in whole or in part, without the express written permission of Spectralink
Corporation.
Do not remove (or allow any third party to remove) any product identifi cation, copy-
right or other notices.
Notice
Spectralink Corporation has prepared this document for use by Spectralink per-
sonnel and customers. The drawings and specifi cations contained herein are the
property of Spectralink and shall be neither reproduced in whole or in part without
the prior written approval of Spectralink, nor be implied to grant any license to
make, use, or sell equipment manufactured in accordance herewith.
Spectralink reserves the right to make changes in specifi cations and other infor-
mation contained in this document without prior notice, and the reader should in
all cases consult Spectralink to determine whether any such changes have been
made.
NO REPRESENTATION OR OTHER AFFIRMATION OF FACT CONTAINED
IN THIS DOCUMENT INCLUDING BUT NOT LIMITED TO STATEMENTS RE-
GARDING CAPACITY, RESPONSE-TIME PERFORMANCE, SUITABILITY FOR
USE, OR PERFORMANCE OF PRODUCTS DESCRIBED HEREIN SHALL BE
DEEMED TO BE A WARRANTY BY SPECTRALINK FOR ANY PURPOSE, OR
GIVE RISE TO ANY LIABILITY OF SPECTRALINK WHATSOEVER.
Welcome to PIVOT by Spectralink
Your PIVOT handset combines the familiarity of an Android
smartphone with the advanced functionality and durability
needed for a workplace environment. It is a WorkSmart device.
Contact your system administrator for information about what
capabilities are confi gured for your facility.
The unique spine design permits a comfortable grip no matter
the size of one’s hand. In this document we have demonstrated
two different grips. It may take some getting used to, but as you
use your PIVOT, you will fi nd that it gives superior performance
in every functional area.
Spectralink applications are translated into French, German,
Spanish and Italian but we have retained the long list of
languages offered by Android. If you select a different
language, labels associated with specialized applications
may appear in English.
Instructions for using standard Android features are readily
available online. Specialized Spectralink applications follow
these same usage guidelines. Use this document as a starting
place to explore PIVOT and learn a new way of working smart.
The complete PIVOT by Spectralink User Guide is available
online at http://support.spectralink.com.
Carrying Accessories
• Two clips styles are available: Both the clothespin-style and
button-style easily attach to a belt or other fi rm edge.
• Cross-body lanyard hugs the body for secure carrying
and quick access.
• Silicone bumper protects your PIVOT without interfering
with use.
Dialer
PIVOT’s Dialer easily makes calls by free dialing, through
selecting recent calls or contacts from the People application
or by selecting contacts from a corporate directory if enabled
in your facility.
Power
Proximity and
light sensors
Microphone
Volume up
Volume down
Push-to-talk
Reboot LED
(Bottom) USB port (Bottom) Headset jack
(Top) Panic button
(if enabled)
Speaker
Battery Pack latch
Battery Pack
Scan window
(8753 only)
(All 4 corners)
Lanyard through-holes
Scan button
(8753 only)
Rear speaker
Charging with the USB Cable
Charge PIVOT fully before using it. An all-night charge is best.
Caution
The phone must be ON to be charged. Ensure your phone is turned
on when charging it. It will not charge when it is turned off.
