Spectrum MK2 Wireless Residential Door Locks User Manual Kevo 2 Kwikset ENG printable indd
Spectrum Brands, Inc. Wireless Residential Door Locks Kevo 2 Kwikset ENG printable indd
Spectrum >
Users Manual
1 / 11 © 2016 Spectrum Brands, Inc.
64452 / 02
ENGLISH 2nd Generation
Installation and
User Guide
Parts in the boxRequired tools
Additional tools
(depending on application)
Latch with
rectangular faceplate
Ruler
Phillips screwdriver
Hammer
Wood block
Latch screws Strike screws Mounting plate screws
03809 46780 49191 64109
Mounting plate SmartKey toolInterior assembly
Keys
Battery pack Interior cover Batteries
Interior assembly
screws
Interior cover
screws
Drive-in latch Strike Exterior assembly Adapter ring
A
G
NQR TUV
P
HJKLM
BCDE F
Note: Part numbers are printed on screw bags.
2 / 11 © 2016 Spectrum Brands, Inc.
If drilling a new door, use the supplied template and the complete
door drilling instructions available at www.kwikset.com/doorprep.
Note: Additional door preparation may be required for
doors with 11/2" (38 mm) holes. Consult the deadbolt
drilling instructions at www.kwikset.com/doorprep
or
Measure to conirm that the hole in the door
is either 21/8" (54 mm) or 11/2" (38 mm).
A
21/8"
54 mm
11/2"
38 mm
backset
Measure to conirm that the backset is
either 23/8" or 23/4" (60 or 70 mm).
23/8" or 23/4"
60 or 70 mm
B
Measure to conirm that the hole in
the door edge is 1" (25 mm).
C
1"
25 mm
13/4"
44 mm
Measure to conirm that the
door is 13/4" (44 mm) thick.
D
1Prepare the door and check dimensions
3 / 11 © 2016 Spectrum Brands, Inc.
A
A
N (2x)
A
A
B
B
B
B
Q (2x)
R (2x)
C
Longer screws, Q,
install closest to
the door jamb.
door frame
A B
C
D
Is the door edge chiseled?
Is the D-shaped hole centered in the door hole?
Which latch are you installing?Hold the latch in front of the door hole, with the latch
face lush against the door edge.
YES
YES
NO
NO
Use latch “A”. If the
latch bolt is not already
extended, extend the
latch bolt as shown.
No adjustment is required.
Proceed to next step.
D-shaped hole centered D-shaped hole NOT centered
Rotate latch face as
shown to extend latch.
“UP” is
on top
“UP” is
on top
wood
block
Use latch “B”. If the
latch bolt is not already
extended, extend the
latch bolt as shown.
Latch “A” Latch “B”
EInstall strike on the door frame.
Make sure the hole in the door frame is drilled a
minimum of 1" (25 mm) deep.
or
chiseled not
chiseled
or
or
Note: The longer screws, Q, (3" / 76 mm) must be used
to maintain highest security.
2Install the latch and strike
3Install the exterior assembly
Diameter is 21/8" (54 mm) Diameter is 11/2" (38 mm)
21/8"
54 mm
11/2"
38 mm
“E” is required for installation.
Install “E” on “D”.
“E” is not needed for
installation. Discard “E”.
Locate mounting plate (G).
Note: It is on the back of
the interior assembly.
or
What is the diameter of the hole in the door? Install exterior assembly and mounting plate.
A C
B
a
b
c
d
e
Cable goes underneath latch. Rotate torque blade to align
with D-shaped hole.
Route cable
through
center hole,
then push
cable into
bottom hole.
Keep parallel to
edge of door
Insert key and test latch. If
latch does not extend or retract
smoothly, adjust screws (T).
Remove key when inished
and make sure the latch
bolt is fully extended.
Tighten
screws evenly
D
G
G
F
T
D
E
E
T (2x)
4 / 11 © 2016 Spectrum Brands, Inc.
Locate mounting screws and keep them within reach.
T
KKHH
J
5 / 11 © 2016 Spectrum Brands, Inc.
a
a
b
b
d
c
c
Remove battery cover and battery pack from interior assembly.
Connect cable and install interior assembly.
A
B
Make sure
turnpiece is in the
vertical position.
Make sure
cable “clicks”
into place.
Tuck cable into
interior housing.
Secure with
screws.
bottom hole
Tip
Use lever if
you need to
remove cable.
Push turnpiece shaft
onto torque blade.
turnpiece
shaft
torque
blade
vertical
Remove
interior cover.
Remove
battery pack.
Do not install
batteries yet.
H
U (2x)
4Install the interior assembly
6 / 11 © 2016 Spectrum Brands, Inc.
5Perform the door handing process
A B
C D
status LED
This step will teach the lock the orientation of your door and is crucial for lock operation.
Install 4 AA batteries in the battery pack.
Ensure correct polarity. For best
results, use new, non-rechargeable
Alkaline batteries only.
IMPORTANT: Make sure the door is open. Insert the battery pack
while PRESSING AND HOLDING the Program button. Release the button
when the battery pack is all the way inside the lock interior.
IMPORTANT: The Status LED will lash red and green, and the lock will beep. Press
and release the Program button again. The latch bolt will retract and extend on its own.
Did the latch bolt bolt retract and extend on its own?
or
Door handing process was
successful! Proceed to next step
after latch bolt stops moving.
Remove battery pack, wait
15 seconds, then attempt
the process again.
YES NO
J
L (4x)
7 / 11 © 2016 Spectrum Brands, Inc.
Download the app and set up your smartphone
Download the Kevo app at kwikset.com/kevo/app or scan the QR code below. Follow the instructions inside the app to create an account, enroll
your irst smartphone and send eKeys to family and friends.
When using your phone to lock and unlock the door,
make sure the phone is on, Bluetooth is enabled, and
the Kevo app is running in the background.
You may hold the phone in your hand, pocket, bag or purse as long
as there is a clear line of sight between the lock and the phone.
First 10 Touches
Your irst 10 touches will teach your Kevo smart lock
about your entryway and the typical positions where
you might keep your phone during normal use.
Kevo may take longer to lock and unlock during this learning phase.
After the irst 10 touches Kevo has learned about your home's
environment and customized itself to the best performance.
See “Positioning Technology” on page 11 for more information.
A B
Locking the doorNormal use Unlocking the door
Touch the deadbolt rose.
The light ring will spin blue,
spin amber, then lash
amber, and you will hear one
beep. The door will lock.
Touch the deadbolt rose.
The light ring will spin blue,
spin green, then lash green,
and you will hear two beeps.
The door will unlock.
6
7
OPTIONAL: Re-key the lock
If desired, the lock may be re-keyed to work with your existing key.
See the supplied SmartKey Re-key instructions for more information.
Remove
security
screw.
Install
cover.
Install
cover.
Install
screws.
Install
screws.
aa
bb c
8 / 11 © 2016 Spectrum Brands, Inc.
8Install the interior cover
Important information about the interior cover:
If you want to keep the window locked: If you want to unlock the window (for quick access to back panel):
If the window
is unlocked,
it can slide
up for quick
access to
buttons while
the cover is
installed.
The window
on the interior
cover is locked
by default
to prevent
someone from
tampering with
the back panel.
The interior
cover will
be installed
over the
back panel
with three
screws.
The buttons
on the back
panel are
used to
program
Kevo.
© 2015 Spectrum Brands, Inc.
V (3x)
K
K
K
V (3x)
9 / 11 © 2016 Spectrum Brands, Inc.
AB
Reference Guide
Kevo at a Glance
1. Touch Kevo anywhere on the
metallic surface behind the
light ring to lock and unlock.
2. Insert your SmartKey tool here
when rekeying your lock to
work with your existing key.
3. Changes color to communicate
with you.
4. Insert your standard key here.
5. Only use to reset Kevo
to delete all eKeys and fobs.
See “System Reset” for more
information.
6. Where all the programming
features are located.
7. Use to enroll phones and fobs.
8. Engages with turnpiece when
interior cover is installed. When
the cover is removed, the
turnpiece shaft can be used
to manually lock and unlock
the door.
9. Use to reset calibration that
was learned during irst 10
touches to the deadbolt rose.
10. Use to enable and disable the
Status LED, Triple Touch Lock,
Audio, and Auto-Lock.
11. Communicates whether the
door is locked or unlocked and
lashes red for a low battery
alert. Can be turned on and o
by Switch #1.
Kevo-Compatible Devices
Smartphones and Smart Devices
A Kevo-compatible smartphone (or other
mobile internet-connected device or tablet)
must have Bluetooth Smart Ready/ Bluetooth
4.0 and an app speciic to the device must be
installed. Find out if your device is compatible
at www.kwikset.com/kevo/devices.
Kevo Fob
A Kevo Fob is a Bluetooth device that provides the
same touch-to-open convenience as a smartphone.
Up to eight fobs can be enrolled in a single Kevo lock. A
single fob can be enrolled in up to 25 di erent Kevo locks.
Note: You may choose to use only Kevo fobs, only
smartphones or a mix of both in your Kevo system.
Standard Key
Always make sure you have access to your standard key.
Switches Triple Touch Lock and Auto-Lock
Switch 1
Status LED
Door lock status LED blinks every 6
seconds. ON position is factory default.
Switch 2
Triple Touch Lock
See “Triple Touch Lock.”
OFF position is factory default.
Switch 3
Audio
Beeping sound is heard during
programming and normal operation.
ON position is factory default.
Switch 4
Auto-Lock
Automatically re-locks door 30
seconds after unlocking. OFF position
is factory default.
Triple Touch Lock allows you to lock the door from the outside
without the use of a smartphone or fob. You might use Triple
Touch Lock if you are using only a standard key in your system
but wish to lock the door by touch, if your smartphone or fob is
disabled, or if you have a visitor in your home that will leave and
lock the door behind them.
To lock the door with this feature, touch the deadbolt rose three
times, pausing briely between each touch. The light ring will spin
blue, spin amber, then lash amber, and you will hear one beep (if
switch #3 is on).
To enable Triple Touch Lock, set Switch #2 to the ON position.
Auto-Lock will automatically re-lock the door 30 seconds after
unlocking. To enable Auto-Lock, set Switch #4 to the ON position.
Both features are OFF by default.
CAUTION: With these feature enabled, it is possible to lock
yourself outside if you don’t have an enrolled smartphone,
Kevo fob or standard key with you.
1234
on o
1. Deadbolt rose 3. Light ring
2. SmartKey tool
access
5. Reset button
6. Back panel
7. Program button
8. Turnpiece shaft
4. Keyway
9. Positioning
Technology button
10. Switches
11. Status LED
System Reset
If you wish to perform a system reset, press and hold the Reset
button on the back panel for 10 seconds until the lock beeps and the
light ring lashes red.
WARNING: Resetting your Kevo system will restore your
lock to factory settings and delete all smartphones and fobs
from Kevo’s memory.
Phones: After a system reset, you will need to re-enroll and your
Owner phone. You will still be able to send eKeys at no charge to
anyone who previously had an active eKey at the time of reset.
Fobs: After a system reset, all fobs will need to be re-enrolled.
See the online Troubleshooting guide for instructions.
AB
10 / 11 © 2016 Spectrum Brands, Inc.
Light Ring Notiications
Red Light Ring Warnings
Status LED Notiications
Blue Spinning and Shutting
O : Kevo is unable to establish a
connection with your device, and it
will not lock or unlock. Make sure that
your Bluetooth and Bluetooth Sharing
(inside your phone’s privacy settings)
are enabled, and make sure you are
signed in to your Kevo app and that
it’s running in the background.
Magenta Flash: Your device is
outside of the activation range
that was established during your
irst 10 touches, and it will not
lock or unlock. See “Positioning
Technology” on page 11. When
locking and unlocking your door,
make sure there is a clear line of sight
between the lock and your device.
Teal Flash: Kevo was tapped while the
door was already opening or closing.
Red Flash: Kevo has detected an
unauthorized device within activation
range, and it will not lock or unlock.
An unauthorized phone is one with
the Kevo app installed that does not
have an eKey to your lock, and an
unauthorized fob is one that has not
been enrolled in your Kevo system.
Top Two LEDs are Solid Red: The AA batteries in
the Kevo interior are low and need to be replaced.
Bottom LED is Solid Red: The fob battery
(CR2025) is low and needs to be replaced.
See the online Troubleshooting Guide at
www.kwikset.com/kevo/support .
Side LEDs Flashing Red: The deadbolt has
jammed. Check your door for alignment and
make sure the latch bolt can operate smoothly.
Amber lash
Door is locked
Green lash
Door is unlocked.
Red lash
The 4 AA batteries in the Kevo interior are low and
need to be replaced.
11 / 11 © 2016 Spectrum Brands, Inc.
Important Safeguards
1. Read all instructions in their entirety.
2. Familiarize yourself with all warning
and caution statements.
3. Remind all family members of safety precautions.
4. Always have access to your lock’s standard key.
5. If using the Triple Touch Lock or Auto-
Lock features, make sure to have your
smartphone, fob or standard key with
you to prevent locking yourself out.
6. Familiarize yourself with all light
ring error notiications.
7. Replace low batteries immediately.
Preventing Inadvertent
Unlocking of Your Door
WARNING: Failure to follow these safeguards
could result in your lock opening inadvertently.
1. Avoid keeping and storing phones
and fobs unnecessarily close to the
lock when inside the home.
2. Restrict access to your Kevo lock’s back panel
and routinely check your settings to ensure they
have not been altered without your knowledge.
3. Protect the password to your Kevo
app and web portal accounts.
4. When sending an eKey, always double-check
that you are sending it to the correct recipient.
5. Protect and restrict access to your
smartphone so that your app settings cannot
be altered without your knowledge.
6. Enable the Kevo app’s security passcode
so that your app settings cannot be
altered without your knowledge.
7. When sending eKeys, be aware of the
di erence between an Admin user and
other users in the system: an Admin user
can send, disable and delete eKeys.
8. If your smartphone is lost or stolen, use the Kevo
web portal (www.mykevo.com) to disable it.
9. If a fob in your Kevo system is lost or stolen,
reset your lock to delete it from memory.
WARNING: This Manufacturer advises that
no lock can provide complete security by itself.
This lock may be defeated by forcible or technical
means, or evaded by entry elsewhere on the
property. No lock can substitute for caution,
awareness of your environment, and common
sense. Builder’s hardware is available in multiple
performance grades to suit the application. In
order to enhance security and reduce risk, you
should consult a qualiied locksmith or other
security professional.
CAUTION: As with any radio-based
technology, it should be noted that the accuracy
and reliability of the Kevo lock’s inside-outside
sensor cannot be guaranteed. Users should not
rely solely on the Kevo lock’s sensor for security
purposes and should always use caution. This
manufacturer assumes no responsibility for
incorrect results or damages resulting from the use
of the Kevo lock’s sensor.
Certain home conigurations may impede the Kevo
lock’s sensor more than others. Example: Your
home o ice is located next to your entryway, and
part of the o ice extends past the front door, jutting
into the front yard. If your device is being actively
used in that o ice extension, the Kevo lock’s sensor
could possibly detect the device as being outside of
your home while that device is in active use.
Need Help?
18003275625
18003275625
1800 623 118
0800 736 776
528141709475
56229382400
5713441460
+86 755298331111
+65 - 666 55 888 o ice • +65 - 8181 8989 mobile
+65 - 666 55 888 o ice • +65 - 8181 8989 mobile
www.kwikset.com/kevo/support
Advanced Features
Positioning Technology
The Kevo smart lock features a unique positioning technology that can
tell if your device is inside or outside your home to help prevent your
door from being unlocked by unauthorized users while your device is
inside.
For additional security, Kevo will also limit the activation range on the
outside. During the irst 10 touches, the Kevo smart lock will learn about
your entryway and the typical positions where you might keep your
phone during normal use.
Kevo may take longer to lock and unlock during this learning phase.
After the irst 10 touches, Kevo has learned about your home's
environment and customized itself to the best performance.
If you ind that the Kevo activation range is not ideal for your use, you
can reset what Kevo learned, and Kevo will learn your environment
again. Quickly press and release the Positioning Technology button on
the lock interior. Kevo will learn your environment again during the next
10 touches.
History Log
A history of the lock’s activity may be viewed through the Kevo app or
by logging into the web portal: www.mykevo.com.
Notiications
The Kevo app can send notiications when the door is locked and
unlocked by eKey holders. You can choose to receive the system’s
default notiications or set up custom notiications to monitor a speciic
user or time frame.
Dual Factor Authentication
Kevo features an optional, added-security passcode that you can enable
inside the app to be used in addition to the app’s password. Enabling the
passcode will require you to enter a 4-digit PIN whenever you access the
app, and it protects your Kevo account against unauthorized changes
when your phone is unlocked.
Kevo Plus
With Kevo Plus, you will be able to lock and unlock your home and check
whether your door is locked or unlocked when you are away from home.
You can upgrade to Kevo Plus inside the Kevo app.
Visit www.kwikset.com/kevo/kevo-plus for more information.
Connect Smart Products
Connect Kevo to select smart products. In the Kevo app, tap the gear
icon to connect to smart products (iOS only: select “Preferences”). Visit
www.kwikset.com/kevo/support for more information.
Conformité règlementaire
Ce produit est conforme aux normes établies par
les organismes de règlementation suivants :
• Federal Communications Commission (FCC)
• Industrie Canada
FCC
Cet appareil est conforme aux limites prescrites dans la
partie 15 des règlements de la Federal Communication
Commission (FCC) des États-Unis. Son utilisation est
subordonnée aux conditions suivantes : ( 1 ) l’appareil
ne doit pas causer d’interférence nuisibles, et ( 2 )
il doit accepter toute interférence, y compris celles
qui peuvent causer son mauvais fonctionnement.
Lors des tests eectués, cet appareil s’est révélé conforme
aux limites prescrites dans la partie 15 des règlements de la
Federal Communications Commission (FCC) des États-Unis
pour un appareil numérique de Classe B. Ces limites ont
été fixées pour protéger raisonnablement les installations
résidentielles contre les interférences nuisibles. L’appareil
produit, utilise et peut émettre des radiofréquences. S’il
n’est pas installé et utilisé de la façon prescrite, il peut
brouiller les communications radio. Il n’est pas garanti
qu’aucune interférence ne se produira. Si l’appareil brouille
la réception d’une radio ou d’un téléviseur (pour savoir
s’il est à l’origine du brouillage, il sut de l’éteindre et de
le rallumer), l’utilisateur est invité à tenter de corriger la
situation en prenant une ou plusieurs des mesures suivantes :
• réorienter ou déplacer l’antenne réceptrice;
• éloigner davantage l’appareil émetteur du récepteur;
• brancher l’appareil dans une prise reliée à un circuit
diérent de celui auquel le récepteur est relié;
• consulter le détaillant ou un technicien de
radiotélévision expérimenté pour obtenir de l’aide.
IMPORTANT! Les modifications qui n’ont pas été
expressément approuvées par le fabricant de l’appareil
peuvent annuler l’autorisation d’utiliser l’appareil.
Industrie Canada
Cet appareil est conforme aux normes d’Industrie Canada
exemptes de licence RSS. L’opération est sujette aux
deux conditions: ( 1 ) ce dispositif peut ne pas causer
l’interférence et ( 2 ) ce dispositif doit accepter n’importe
quelle interférence, y compris l’interférence qui peut
causer le fonctionnement non souhaité du dispositif.
Cumplimiento Normativo
Este producto cumple con las normas establecidas
por los siguientes organismos reguladores:
• Comisión Federal de Comunicaciones (FCC)
• Industry Canada
FCC
Este dispositivo cumple con la 15ª parte del reglamento
de la FCC. Su funcionamiento está sujeto a las siguientes
dos condiciones: ( 1 ) este dispositivo no deberá causar
ninguna interferencia dañina, y ( 2 ) este dispositivo deberá
aceptar cualquier interferencia recibida, incluyendo aquélla
que podría causar un funcionamiento no deseado.
Se realizaron pruebas a este equipo cuyos resultados
revelaron que cumple con los límites establecidos para un
dispositivo digital de la Clase B, conforme a la 15ª parte del
reglamento de la FCC. Estos límites han sido impuestos para
proporcionar protección razonable contra interferencias
dañinas en una instalación residencial. Este equipo genera,
utiliza y puede irradiar energía de radiofrecuencia y, si no se
instala y utiliza según lo que indican las instrucciones, podría
causar interferencia dañina en radiocomunicaciones. Sin
embargo, no hay garantía de que la interferencia no ocurrirá
en determinadas instalaciones. Si este equipo efectivamente
causa interferencia en la recepción de radio o televisión,
la cual puede determinarse encendiendo y apagando el
equipo, sugerimos al usuario que intente corregir dicha
interferencia tomando una o más de las siguientes medidas:
• Volver a orientar o ubicar la antena receptora.
• Incrementar la distancia entre el equipo y el recibidor.
• Conectar el equipo a una toma de corriente
en un circuito distinto del circuito en el
cual esté conectado el recibidor.
• Consultar con el distribuidor o un técnico de radio
y TV con experiencia para obtener su ayuda.
¡IMPORTANTE! Todo cambio o modificación no
aprobado expresamente por el fabricante podría
desautorizar al usuario para operar el equipo.
Industria de Canada
Este dispositivo cumple con las normas de la Industria de
Canada licencia-exenta RSS. Su funcionamiento está sujeto a
las siguientes dos condiciones: ( 1 ) este dispositivo no deberá
causar ninguna interferencia dañina, y ( 2 ) este dispositivo
deberá aceptar cualquier interferencia, incluyendo aquélla que
podría causar el funcionamiento no deseado del dispositivo.
Regulatory Compliance
This product complies with standards established
by the following regulatory bodies:
• Federal Communications Commission (FCC)
• Industry Canada
FCC
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
( 1 ) this device may not cause harmful interference, and
( 2 ) this device must accept any interference received,
including interference that may cause undesired operation.
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment
o and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between
the equipment and receiver.
• Connect the equipment into an outlet on a circuit
dierent from that to which the receiver is connected.
• Consult the dealer or an experienced
radio/TV technician for help.
IMPORTANT! Changes or modifications not expressly
approved by the manufacturer could void the
user’s authority to operate the equipment.
Industry Canada
This device complies with Industry Canada licence-exempt
RSS standard(s). Operation is subject to the following two
conditions:
( 1 ) this device may not cause interference, and ( 2 ) this
device must accept any interference, including interference
that may cause undesired operation of the device.
Terms and Conditions
Términos y condiciones
Termes et conditions
64436 / 01
Important Safeguards
1. Read all instructions in their entirety.
2. Familiarize yourself with all warning
and caution statements.
3. Remind all family members of safety precautions.
4. Always have access to your lock’s standard key.
5. If using the Triple Touch Lock feature, make
sure to have your smartphone, fob or standard
key with you to prevent locking yourself out.
6. Familiarize yourself with all light
ring error notifications.
7. Replace low batteries immediately.
Preventing Inadvertent
Unlocking of Your Door
WARNING: Failure to follow these safeguards
could result in your lock opening inadvertently.
1. Avoid keeping and storing phones and fobs
unnecessarily close to the lock when inside the home.
2. Restrict access to your Kevo lock’s back panel
and routinely check your settings to ensure they
have not been altered without your knowledge.
3. Protect the password to your Kevo
app and web portal accounts.
4. When sending an eKey, always double-check that
you are sending it to the correct recipient.
5. Protect and restrict access to your
smartphone so that your app settings cannot
be altered without your knowledge.
6. Enable the Kevo app’s security passcode
so that your app settings cannot be
altered without your knowledge.
7. When sending eKeys, be aware of the dierence
between an Admin user and other users in the system:
an Admin user can send, disable and delete eKeys.
8. If your smartphone is lost or stolen, use the Kevo
web portal (www.mykevo.com) to disable it.
9. If a fob in your Kevo system is lost or stolen,
reset your lock to delete it from memory.
CAUTION: As with any radio-based technology, it
should be noted that the accuracy and reliability
of the Kevo lock’s inside-outside sensor cannot
be guaranteed. Users should not rely solely on the
Kevo lock’s sensor for security purposes and should
always use caution. This manufacturer assumes
no responsibility for incorrect results or damages
resulting from the use of the Kevo lock’s sensor.
Certain home configurations may impede the Kevo
lock’s sensor more than others. Example: Your home
oce is located next to your entryway, and part
of the oce extends past the front door, jutting
into the front yard. If your device is being actively
used in that oce extension, the Kevo lock’s sensor
could possibly detect the device as being outside
of your home while that device is in active use.
WARNING: This Manufacturer advises that no lock
can provide complete security by itself. This lock
may be defeated by forcible or technical means,
or evaded by entry elsewhere on the property.
No lock can substitute for caution, awareness of
your environment, and common sense. Builder’s
hardware is available in multiple performance
grades to suit the application. In order to enhance
security and reduce risk, you should consult a
qualified locksmith or other security professional.
Medidas de protección importantes
1. Lea las instrucciones en su totalidad.
2. Familiarícese con todas las definiciones
de advertencia y precaución.
3. Recuerde a todos los integrantes de su
familia las precauciones de seguridad.
4. Siempre tenga acceso a la llave
estándar de su cerradura.
5. Si utiliza la función de cierre con tres toques,
verifique que lleve consigo el teléfono
inteligente, llavero transmisor o llave
estándar para evitar quedarse afuera.
6. Familiarícese con todas las notificaciones
de error que aparecen con anillo de luz.
7. Cambie las baterías gastadas de inmediato.
Impedir la apertura
involuntaria de la puerta
ADVERTENCIA: Si no se cumplen estas
medidas de protección, la cerradura
podría abrirse involuntariamente.
1. Evite mantener y guardar los teléfonos y
llaveros transmisores cerca de la cerradura
cuando esté en el interior de la casa.
2. Limite el acceso al panel posterior de la
cerradura Kevo y verifique en forma rutinaria
las configuraciones para comprobar que no
hayan sido alteradas sin su conocimiento.
3. Proteja las contraseñas de las cuentas
del portal web y aplicación Kevo.
4. Al enviar una llave electrónica, siempre
vuelva a comprobar que la está
enviando al destinatario correcto.
5. Proteja y limite el acceso a su teléfono inteligente
para que no se puedan alterar las configuraciones
de la aplicación sin su conocimiento.
6. Habilite el código de acceso de seguridad de la
aplicación Kevo para que no se puedan alterar las
configuraciones de la aplicación sin su conocimiento.
7. Al enviar llaves electrónicas, tenga en cuenta
la diferencia entre un usuario Admin y otros
usuarios del sistema: el usuario Admin puede
enviar, deshabilitar y eliminar llaves electrónicas.
8. Si pierde o roban su teléfono inteligente,
utilice el portal web (www.mykevo.com) para
deshabilitar el dispositivo inteligente.
9. Si pierde o roban su llavero transmisor, reinicie
la cerradura para eliminarla de la memoria.
PRECAUCIÓN: Al igual que con cualquier tecnología
de radio, se debe tener en cuenta que la precisión,
la confiabilidad o la utilidad del posicionamiento
de su dispositivo no se pueden garantizar con
ubicaciones derivadas del sensor correspondiente
a la cerradura Kevo; esta función se brinda solo por
propósitos de comodidad. Los usuarios no deben
confiar únicamente en el sensor de la cerradura
Kevo para propósitos de seguridad y siempre deben
tener precaución. Kwikset no asume responsabilidad
alguna por resultados incorrectos o daños producidos
por el uso del sensor de la cerradura Kevo.
Ciertas configuraciones domésticas pueden impedir
el funcionamiento del sensor de la cerradura Kevo
más que otras. Ejemplo: Su oficina está ubicada
junto al recibidor, y parte de la oficina se extiende
más allá de la puerta principal, proyectándose
hacia el patio principal. Si su dispositivo se utiliza
en forma activa en dicha extensión de la oficina, es
posible que el sensor de la cerradura Kevo detecte
el dispositivo en una ubicación externa al hogar
mientras dicho dispositivo se encuentra en uso activo.
ADVERTENCIA: Este Fabricante hace saber que no
hay cerrojos que puedan proporcionar completa
seguridad por sí mismos. Puede hacerse que
falle este cerrojo forzándolo o utilizando medios
técnicos, o puede evadirse entrando por otra parte
de la propiedad. No hay cerrojos que puedan
hacer de sustitutos para la precaución, el estar
al tanto del entorno, y el sentido común. Pueden
obtenerse piezas de ferretería de constructor con
diversos grados de rendimiento para ajustarse a
la aplicación. Para realzar la seguridad y reducir
los riesgos, debe consultar con un cerrajero
capacitado o otro profesional de seguridad.
Mesures de protection importantes
1. Lire toutes les instructions en entier.
2. Familiarisez-vous avec tous les
avertissements et mises en garde.
3. Rappelez les précautions de sécurité à
tous les membres de la famille.
4. Conservez un accès permanent à la
clé standard de votre serrure.
5. Lors de l’utilisation de la fonction trois touches de
la serrure, assurez-vous d’avoir avec vous votre
téléphone intelligent, porte-clés électronique
ou clé standard pour éviter que la porte ne
se verrouille alors que vous êtes dehors.
6. Familiarisez-vous avec tous les anneaux
lumineux de notification d’erreur.
7. Remplacez les piles faibles immédiatement.
Empêcher le déverrouillage
involontaire de votre porte
WARNING: Failure to follow these safeguards
could result in your lock opening inadvertently.
1. Évitez de garder ou entreposer des porte-clés
électroniques et téléphones excessivement près de la
serrure lorsque vous êtes à l’intérieur de la maison.
2. Restreignez l’accès au panneau arrière de
votre serrure Kevo et vérifiez régulièrement
vos réglages pour vous assurer qu’ils
n’ont pas été modifiés à votre insu.
3. Protégez les mots de passe de vos comptes
de portail Web et application Kevo.
4. Lors de l’envoi d’une eKey, revérifiez
systématiquement que vous êtes en train
de l’envoyer au bon destinataire.
5. Protégez et restreignez l’accès à votre téléphone
intelligent afin que les réglages de votre application
ne puissent être modifiés à votre insu.
6. Activez le code d’accès de sécurité de l’application
Kevo afin que les réglages de votre application
ne puissent être modifiés à votre insu.
7. Lors de l’envoi d’eKeys, tenez compte de la diérence
entre un utilisateur Administrateur et d’autres
utilisateurs du système ; un utilisateur Administrateur
peut envoyer, désactiver et supprimer des eKeys.
8. Si votre téléphone est perdu ou volé,
utilisez le portail Web (www.mykevo.com)
pour le supprimer ou le désactiver.
9. Si votre porte-clés électronique est perdu ou volé,
réinitialisez votre serrure pour l’eacer de la mémoire.
ATTENTION: Comme pour une technologie radio, il
est à noter que la précision, la fiabilité ou l’utilisabilité
du positionnement de votre appareil indiqué par
le capteur intérieur-extérieur de la serrure Kevo ne
peuvent être garanties; ces données sont fournies à
titre de commodité uniquement. Les utilisateurs ne
doivent pas se fier exclusivement aux capteurs de
la serrure Kevo à des fins de sécurité et ils doivent
toujours faire preuve de prudence. Le fabricant
se dégage de toute responsabilité en cas de
résultats incorrects ou de dommages découlant
de l’utilisation du capteur de la serrure Kevo.
Certaines configurations de maisons peuvent entraver
plus que d’autres le capteur de la serrure Kevo.
Exemple: Votre bureau à la maison est situé à côté
de votre entrée, et une partie du bureau s’étend
au-delà de la porte de la façade, s’avançant sur la
cour d’entrée. Si votre appareil est en train d’être
utilisé activement dans cette extension de bureau, le
capteur de la serrure Kevo pourrait éventuellement
détecter l’appareil comme étant à l’extérieur de votre
maison alors que cet appareil est en utilisation active.
AVERTISSEMENT: Le fabricant tient à vous aviser
qu’aucun verrou ne peut à lui seul orir une
sécurité complète. Ce verrou peut être mis hors
d’état par la force ou des moyens techniques ou
être évité par l’utilisation d’une autre entrée dans
la propriété. Aucun verrou ne peut remplacer la
surveillance de votre environnement et le bon
sens. Diérentes qualités de matériel d’installation
sont oertes pour diérentes applications. Afin
d’augmenter la sécurité et de réduire le risque,
vous devriez consulter un serrurier qualifié
ou un autre professionnel de la sécurité.
