Spirent Communications FLEX-WPEA 802.11ac/b/g/n Mini PCIe Module User Manual WPEA 352ACN manual0406x

Spirent Communications Inc 802.11ac/b/g/n Mini PCIe Module WPEA 352ACN manual0406x

Users Manual

WPEA-352ACN
PRODUCT INTRODUCTION
Standard
IEEE 802. 11ac/b/g/n
Chipset solution
QCA9880
Radio stream [Note1]
3T3R
Antenna Type / connector
3 U.FL connectors
Bus Interface
PCI Express
Form Factor
Mini-PCIe
Data Rate
802.11b: from 1Mbps to 11Mbps
802.11a/g: from 6Mbps to 54Mbps
802.11n: from 6.5Mbps to 450Mbps(MCS 0-23)
802.11ac: from 6.5Mbps to 1.3Gbps(MCS 0-9)
Spreading /Modulation
Techniques
802.11b: DSSS (DBPSK, DQPSK, CCK)
802.11a/g: OFDM (BPSK,QPSK,16-QAM,64-QAM)
802.11n: OFDM (BPSK,QPSK,16-QAM,64-QAM)
802.11ac: OFDM (BPSK,QPSK,16-QAM,64-QAM, 256-QAM)
Frequency Range[Note2]
2.4GHz: 11b/g/n: 2.400GHz ~ 2.4835GHz
5GHz: 11a/n: 5.150GHz ~ 5.850GHz
Transmit Output Power
(Tolerance: +/-2dBm)
802.11a: 15dBm@54Mbps
802.11b: 18dBm@11Mbps
802.11g: 15dBm@54Mbps
802.11gn HT20: 13dBm@MCS7
802.11gn HT40: 13dBm@MCS7
802.11an HT20: 13dBm@MCS7
802.11an HT40: 12dBm@MCS7
802.11ac VHT80: 10dBm@MCS9
Receiver Sensitivity
802.11a: <=-65dBm@54Mbps
802.11b: <=-76dBm@11Mbps
802.11g: <=-65dBm@54Mbps
802.11gn HT20: <=-64dBm@MCS7
802.11gn HT40: <=-61dBm@MCS7
802.11an HT20: <=-64dBm@MCS7
802.11an HT40: <=-61dBm@MCS7
802.11ac VHT80: <=-51dBm@MCS9
Operating Voltage
3.3 V
Power Consumption
TX Mode: TBD
RX Mode: TBD
Temperature Range
-20°C ~+65°C (Operating), -30°~+75°C (Storing)
Humidity (non-condensing)
10~85 % (Operating), 5~90 % (Storing) [Note3]
Security
WEP / WPA / WPA2, 802.1x
OS supported
Linux
Note:
1. For Radio stream with diversity or MIMO design, all RF connectors on the module must be
fitting
antennas in order to guarantee the module performance.
2. The frequency range is subject to local regulations.
3. The storing condition is only for product functionality, no included for parts appearance.
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
IMPORTANT NOTE:
Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated
with minimum distance 20cm between the radiator & your body.
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
Country Code selection feature to be disabled for products marketed to the US/CANADA
This device is intended only for OEM integrators under the following conditions:
1) The antenna must be installed such that 20 cm is maintained between the antenna
and users, and
2) The transmitter module may not be co-located with any other transmitter or antenna,
3) For all products market in US, OEM has to limit the operation channels in CH1 to
CH11 for 2.4G band by supplied firmware programming tool. OEM shall not supply
any tool or info to the end-user regarding to Regulatory Domain change.
As long as 3 conditions above are met, further transmitter test will not be required. However,
the OEM integrator is still responsible for testing their end-product for any additional
compliance requirements required with this module installed
IMPORTANT NOTE
In the event that these conditions can not be met (for example certain laptop configurations or
co-location with another transmitter), then the FCC authorization is no longer considered valid
and the FCC ID can not be used on the final product. In these circumstances, the OEM
integrator will be responsible for re-evaluating the end product (including the transmitter) and
obtaining a separate FCC authorization.
End Product Labeling
This transmitter module is authorized only for use in device where the antenna may be
installed such that 20 cm may be maintained between the antenna and users. The final end
product must be labeled in a visible area with the following: “Contains FCC ID:
WR2-FLEX-WPEA”.
Manual Information to the End User
The OEM integrator has to be aware not to provide information to the end user regarding how
to install or remove this RF module in the user’s manual of the end product which integrates
this module.
The end user manual shall include all required regulatory information/warning as show in this
manual.
Antenna&info.&
Antenna& &
Peak&gain&(&dBi&)&
Model/Brand&
Type& &
Connector&
5150~5250MHz&
5725~5850MHz&
Molex& & &
0479501001&
PCB&
UFL&
3.7dBi& &
3.7dBi& &
