925 SOLO
HEART RATE WATCH
SP6180IS01ROD.indd 1SP6180IS01ROD.indd 1 6/30/11 5:36 PM6/30/11 5:36 PM
925 Solo Heart Rate Watch
SETTING THE WATCH FUNCTIONS (cont.)
SETTING YOUR RESTING HEART RATE 17
SETTING THE COUNTDOWN TIMER 18
SETTING DUAL-TIME 19
OPERATING THE WATCH
PEDOMETER MODE 20
OPERATING THE CHRONOGRAPH 21
OPERATING THE COUNTDOWN TIMER 22
VIEWING THE EL BACKLIGHT SYSTEM 22
REPLACING THE WATCH BATTERY 23
BATTERY SAFETY INFORMATION 24
TROUBLE SHOOTING 25
RANGES & SPECIFICATIONS 26
WARRANTY 27
INTRODUCTION 1
HOW TO USE THIS MANUAL 1
WARNINGS & CAUTIONS 2
CARE & MAINTENANCE 3
WATCH FUNCTIONS 4
KEYS AND THEIR FUNCTIONS 5-6
ACQUIRING HEART RATE 7
MEASURING STRIDE LENGTH 7
POWER DOWN/RESET 8
HEART RATE LOCK 8
MAIN OPERATING MODES 9-10
SETTING THE WATCH FUNCTIONS
SETTING TIME & DATE 11
SETTING DAILY ALARM 12
FINDING YOUR TARGET HEART RATE ZONE 13
SETTING HEART RATE ZONES AND USER PROFILE 13-14
SETTING THE PEDOMETER 15
TARGET HEART RATE ZONE ALERT 16
TABLE OF CONTENTSTABLE OF CONTENTS
SP6180IS01ROD.indd 2-3SP6180IS01ROD.indd 2-3 6/30/11 5:36 PM6/30/11 5:36 PM
1 2
925 Solo Heart Rate Watch
WARNINGS & CAUTIONSINTRODUCTION
WARNING: Before starting any exercise program or performing any vigorous physical activity, we strongly
suggest you visit your doctor for a complete physical and to discuss your plans.
CAUTION: Your watch is designed to be water resistant to a static pressure of 3 ATM and can be worn while
showering and light swimming. However, we recommend that extensive use of the unit in the water be
avoided whenever possible. Care should be taken not to press any keys while the unit is submerged as this
can force moisture past the key seals and damage the unit.
CAUTION: Avoid exposing your watch to extreme conditions for a prolonged period of time.
CAUTION: Avoid rough usage or severe impacts to your watch.
DO NOT use hand cream as it will insulate the signal between the skin and sensor contacts.
DO NOT use the fingertips where the skin is dry and thick. For those with extremely dry skin, moisten fingers
and wrist with tap water or a conductive gel.
CLEAN the Back Cover occasionally by using a damp cloth. Then wipe dry to remove any residual grease.
CLEAN your skin and fingers with soap and water for a better signal transmission.
AVOID doing awkward motions during measurement. It may create inaccurate heart rate readings.
Congratulations on your purchase of a 925 Solo Heart Rate Watch. Please keep in mind your watch is a
sensitive technical instrument. With proper care and maintenance, it will last for many years. However,
improper care and handling can cause the various sensors to be damaged and to stop functioning.
HOW TO USE THIS MANUAL
Sportline Personal Fitness Monitors have many unique features and functions. Please read all sections of
this manual carefully and become fully familiar with the operation of the watch before using it in the field.
Proper setup and operation will greatly enhance the watch’s usefulness and your enjoyment.
The manual is divided into sections outlining each of the major functions of the watch. A drawing of the
watch screen that represents the starting point or other important screens for each operational process are
shown adjacent to the instructions for the process; important keys are shown indicating PRESS & HOLD and
PRESS.
The steps for the programming or operation are adjacent to the screen illustration. Key points and important
information are shown in highlighted blocks.
ACTIVATING THE WATCH FROM POWER DOWN MODE
PLEASE NOTE: Your watch was originally shipped in Power Down Mode to conserve battery life.
To deactivate Power Down mode: PRESS & HOLD ANY KEY for 5 seconds.
SP6180IS01ROD.indd Sec1:1-Sec1:2SP6180IS01ROD.indd Sec1:1-Sec1:2 6/30/11 5:36 PM6/30/11 5:36 PM
3 4
925 Solo Heart Rate Watch
TIME
• Time/Day/Date/Month
• 12- or 24-hour format
• Dual Time
• Daily Alarm
HEART RATE
• Finger-Touch
• Single user-selected HR Zone
• HR Zone Alert
• Average Heart Rate
PEDOMETER
• Steps
• Steps Goal
• Exercise Time
• Distance
• Calories
• 3 Sensitivity Levels
• Calorie Consumption
CHRONOGRAPH
• 1/100 second resolution
• 99 hours, 59 minutes, 59.99 seconds
TIMER
• 1-second resolution
• Range: 99 hours, 59 minutes, 59.99 seconds
OTHER
• EL Backlight System
WATCH FUNCTIONS
• NEVER attempt to disassemble or service your unit.
• DO NOT expose the unit to extreme heat, shocks, magnetic fields, electrical noise, strong vibration or
long-term exposure to direct sunlight.
• DO NOT drop or step on the watch.
• TO CLEAN THE UNIT: wipe with a lightly moistened cloth. Apply mild soap to the area if there are
stubborn stains or marks. Do not expose the unit to strong chemicals such as gasoline, cleaning solvents,
acetone, alcohol or insect repellents as they may damage the unit’s seal, case and/or finish.
• STORE the unit in a dry place when you are not using it.
CUSTOMER SUPPORT
If you have questions, comments or need assistance with your Sportline 925 Solo Heart Rate Watch, you
may contact Customer Support by calling 1-866-694-4575.
CARE & MAINTENANCE
SP6180IS01ROD.indd Sec1:3-Sec1:4SP6180IS01ROD.indd Sec1:3-Sec1:4 6/30/11 5:36 PM6/30/11 5:36 PM
5 6
925 Solo Heart Rate Watch
MODE KEY
• Scroll through operating modes
•
PRESS & HOLD: Enter/Exit the programming
sequence
• Set values being adjusted in programming
sequence
START/STOP KEY (S/S)
• Access Alarm in Time mode
• Turn Alarm ON or OFF in Alarm mode
• Start/Stop Countdown Timer
• Start/Stop Chronograph
• Increase setting values being adjusted in
programming sequence
RESET KEY (R)
•
PRESS & HOLD: Reset Chronograph or
Countdown Timer
• Decrease setting values being adjusted in
programming sequence
LIGHT KEY
• Activates (EL) backlight system
HEART RATE SENSOR
• Acquires Finger Touch Heart Rate
KEYS AND THEIR FUNCTIONSKEYS AND THEIR FUNCTIONS
MODE KEY
HEART RATE SENSOR
EL LIGHT KEY START/STOP KEY
(S/S)
RESET KEY
(R)
HEART RATE SENSOR
SP6180IS01ROD.indd Sec1:5-Sec1:6SP6180IS01ROD.indd Sec1:5-Sec1:6 6/30/11 5:36 PM6/30/11 5:36 PM
7 8
925 Solo Heart Rate Watch
ACQUIRING HEART RATE / MEASURING STRIDE LENGTH
ACQUIRING HEART RATE: FINGER TOUCH
Heart rate may be acquired from any operating mode (not in any Setting Sequence).
1. With the watch on your wrist, TOUCH & HOLD the HEART RATE SENSOR
(anywhere on the metal top plate of the watch) with your index finger.
NOTE: If Heart Rate Sensors are accidentally touched, the watch will automatically attempt to
acquire heart rate. If no heart rate is detected, watch will resume operating mode in approximately
10 seconds. This will not interfere with any timing functions in progress.
NOTE: You may exit Heart Rate mode at any time by Pressing the Mode, Start/Stop or Reset key.
2. Continue TOUCHING & HOLDING until heart rate displays.
3. Once Heart Rate is acquired, RELEASE THE SENSOR. Heart Rate will continue to display for a period of
approximately 10 seconds.
POWER DOWN/RESET
Power Down/Reset mode allows you to conserve battery life by deactivating the unit when the monitor is
not being used for long periods of time. To activate Power Down mode:
1. In Time mode, PRESS & HOLD the MODE, START/STOP & RESET keys for 5 seconds.
NOTE: Time/Date, User Profiles and Memory files will be reset to factory defaults.
2. To deactivate Power Save mode and resume normal operation, PRESS ANY KEY for 3 seconds.
HEART RATE LOCK
To deactivate finger Touch Heart Rate (when you don’t want to accidentally acquire heart rate):
1. In Time mode, PRESS & HOLD the START/STOP key. The lock icon ( ) will appear in the upper left of the
display.
2. To unlock, PRESS & HOLD the START/STOP key for 2 seconds in Time mode. The lock icon will disappear.
HOW TO MEASURE YOUR STRIDE LENGTH
1. Your stride is the distance between your back foot’s toe and your front foot’s toe (fig. 1). To find out what
your stride is, walk or run 10 steps and then measure the distance with a tape measure from the first
step’s toe to the 10th step’s toe (fig. 2). Divide your total distance by 10 to get your average stride length.
2. For a quick estimate, walk 3 steps, measure the distance, and divide by 3. The more steps you take, the
more accurate and realistic your stride will be. An average walking stride for a female is 2 feet (24 in), a
male is 2.5 feet (30 in).
POWER DOWN/RESET
START WALKING/RUNNINGFIGURE 2FIGURE 1 STRIDE DIVIDE TOTAL
DISTANCE BY 10
1 2 3 4 5 6 7 8 9 10
SP6180IS01ROD.indd Sec1:7-Sec1:8SP6180IS01ROD.indd Sec1:7-Sec1:8 6/30/11 5:36 PM6/30/11 5:36 PM
910
925 Solo Heart Rate Watch
MAIN OPERATING MODES
The Sportline 925 Solo Heart Rate Watch has 8 main operating modes: Time/Date, Pedometer, Heart Rate
Zone, Resting Heart Rate, Alarm/Chime, Chronograph, Countdown Timer and Dual Time. Scroll through
modes by PRESSING the MODE key. The watch also has 4 Pedometer sub modes (see following page).
You may acquire Heart Rate by TOUCHING & HOLDING the Heart Rate Sensor in any operating mode.
The Sportline 925 Solo Heart Rate Watch has 5 Pedometer sub modes. Scroll through Pedometer sub modes
by PRESSING the RESET key in Pedometer mode. You may acquire Heart Rate by TOUCHING & HOLDING the
Heart Rate Sensor in any operating mode.
MAIN OPERATING MODES
TIME/DATE PEDOMETER HEART RATE ZONE RESTING HEART RATE
ALARM/CHIME
PRESS
MODE
PRESS
MODE
PRESS
MODE
DUAL TIME COUNTDOWN TIMER CHRONOGRAPH
PRESS
MODE
PRESS
MODE
TIME/DATE
PRESS
RESET
PRESS
MODE
PRESS
RESET
PRESS
RESET
EXERCISE TIME/
CALORIES BURNED
DISTANCE
SPEEDAVERAGE
HEART RATE
STEPS/GOAL
SP6180IS01ROD.indd Sec1:9-Sec1:10SP6180IS01ROD.indd Sec1:9-Sec1:10 6/30/11 5:36 PM6/30/11 5:36 PM
11 12
925 Solo Heart Rate Watch
ADJUST: S/S or R ADJUST: S/S or R
SET: MODE SET: MODE
SETTING DAILY ALARM
The Sportline 925 Solo Heart Rate Watch is equipped with a Daily Alarm. To Set Alarm:
1. In Alarm Mode, PRESS & HOLD the MODE key to enter the Programming Sequence.
2. Adjust Hour by PRESSING the S/S or R key. Set by PRESSING the MODE key.
3. Adjust Minutes by PRESSING the S/S or R key. Set by PRESSING the MODE key.
4. PRESS & HOLD the MODE key to exit the Programming Sequence and return to
Operating mode.
5. Turn Alarm ON or OFF by PRESSING the START/STOP (S/S) key. Alarm icon ( )
will display in far right of screen when activated.
6. Turn Hourly Chime ON or OFF by PRESSING the RESET (R) key. Hourly Chime icon
( ) will display in far right of screen when Chime is activated.
SETTING TIME AND DATE
1. In Time mode, PRESS & HOLD the MODE key to enter the programming sequence.
The variable being adjusted will flash on and off.
2. Reset Seconds to zero (00) by PRESSING the START/STOP (S/S) or RESET (R) key.
Advance to Set Minutes by PRESSING the MODE key.
3. Adjust Minutes by PRESSING START/STOP (to increase) or RESET (to decrease). Set
Minutes and advance to Set Hour by PRESSING the MODE key.
4. Adjust Hour by PRESSING S/S or R. Set Hour and advance to Set Year by PRESSING
the MODE key.
5. Adjust Year by PRESSING S/S or R. Set by PRESSING the MODE key.
6. Adjust Month by PRESSING S/S or R. Set by PRESSING the MODE key.
7. Adjust Day by PRESSING S/S or R. Set by PRESSING the MODE key.
8. Adjust Month/Date display format by PRESSING S/S or R. Set Format by PRESSING
the MODE key.
9. Adjust 12/24-hour format by PRESSING S/S or R. Set Format by PRESSING
the MODE key.
10. Turn Key Beep ON or OFF by PRESSING S/S or R. Set by PRESSING the MODE key.
11. PRESS & HOLD the MODE key to exit the Programming Sequence.
SETTING THE WATCH FUNCTIONSSETTING THE WATCH FUNCTIONS
SP6180IS01ROD.indd Sec1:11-Sec1:12SP6180IS01ROD.indd Sec1:11-Sec1:12 6/30/11 5:36 PM6/30/11 5:36 PM
13 14
925 Solo Heart Rate Watch
SETTING THE WATCH FUNCTIONS
ADJUST: S/S or R
SET: MODE
SETTING HEART RATE TARGET ZONE AND USER PROFILE (cont.)
3. Adjust Lower Zone Limit (Lo in display) by PRESSING the START/STOP (S/S)
or RESET (R) key. Set Target Zone by PRESSING the MODE key.
4. Adjust Birth Year by PRESSING S/S or R key. Set by PRESSING the MODE key.
5. Adjust Birth Month by PRESSING S/S or R key. Set by PRESSING the MODE key.
6. Adjust Birth Day by PRESSING S/S or R key. Set by PRESSING the MODE key.
7. Adjust Gender (M = Male, F = Female) by PRESSING S/S or R key. Set by
PRESSING the MODE key.
8. Select Units (Imperial or Metric) by PRESSING S/S or R key. Set by PRESSING
the MODE key.
NOTE: This setting will effect Distance and Speed displays in Pedometer mode.
9. Adjust Weight by PRESSING S/S or R key. Set by PRESSING the MODE key.
10. Adjust Height by PRESSING S/S or R key. Set by PRESSING the MODE key.
11. Adjust Stride Length (see “Measuring Stride Length” page 7) by PRESSING S/S
or R key. Set by PRESSING the MODE key.
12. PRESS & HOLD the MODE key to exit the Programming Sequence and return to
Heart Rate Zone mode.
FINDING YOUR TARGET HEART RATE ZONE
Losing weight and managing to keep it off is a lot easier when you exercise in your target heart rate zone.
To get the most out of any exercise program, you should target 55% to 85% of your maximum heart rate
depending on your fitness level and objectives.
Fat Burning Zone: 55%–65% of maximum heart rate.
This zone is ideal for fitness beginners on a low to moderate intensity program. Exercising in this zone
reduces blood pressure and cholesterol and nearly all the calories burned are fats.
Cardio Zone: 65%–75% of maximum heart rate.
Reaching this zone requires more intense aerobic activity and is perfect for fitness enthusiasts working to
burn maximum calories from fat and carbohydrates.
Endurance Zone: 75%–85% of maximum heart rate.
Exercising in the Endurance Zone is generally recommended for athletes in training. Cardiovascular
strengthening, increased metabolism and elevated caloric burn are the primary benefits.
SETTING HEART RATE TARGET ZONE AND USER PROFILE
The Sportline 925 Solo Heart Rate Watch allows you to set a Target Heart Rate Zone for targeted exercise.
The watch automatically calculates your Maximum Heart Rate from your User Profile.
1. In Heart Rate Zone mode, PRESS & HOLD the MODE key to enter the Programming Sequence.
2. Adjust Upper Zone Limit (Hi in display) by PRESSING the START/STOP (S/S) or RESET (R) key.
Set by PRESSING the MODE key.
SETTING THE WATCH FUNCTIONS
SP6180IS01ROD.indd Sec1:13-Sec1:14SP6180IS01ROD.indd Sec1:13-Sec1:14 6/30/11 5:36 PM6/30/11 5:36 PM
15 16
925 Solo Heart Rate Watch
SETTING THE WATCH FUNCTIONSSETTING THE WATCH FUNCTIONS
TURN ON/OFF: S/S
HEART RATE TARGET ZONE ALERT
The Sportline 925 Solo Heart Rate Watch has an audible signal that alerts you when you
are above or below your Target Heart Rate Zone. This feature can be turned ON or OFF
from Heart Rate mode by PRESSING the START/STOP (S/S) key.
ADJUST: S/S or R
SET: MODE
SETTING THE PEDOMETER
The Sportline 925 Solo Heart Rate Watch allows you to set a walking goal and adjust
sensitivity to maximize your workout. By activating the Goal setting, the watch displays
an indicator bar to show the progress you have made on your desired step goal. To
test sensitivity setting, while wearing the watch and walking, watch as the steps are
recorded. If it seems that steps are being missed or over counted, adjust the sensitivity
1 (lowest) – 3 (highest). 2 is the default setting.
1. In Pedometer Mode, PRESS & HOLD the MODE key to enter the Programming
Sequence.
2. Turn the Goal indicator ON/OFF by PRESSING the S/S key. Set by PRESSING the
MODE key.
3. Adjust the number of steps for your goal by PRESSING the S/S or R key. Advance to
adjust the next digit by PRESSING the MODE key. Continue through all digits. Set by
PRESSING the MODE key.
4. Turn Average Heart Rate Beep ON/Off by PRESSING S/S. Set by PRESSING the MODE
key.
5. Adjust your sensitivity (1–3) by PRESSING the S/S or R key. Set by PRESSING the
MODE key.
6. PRESS & HOLD the MODE key to exit the Programming Sequence.
SP6180IS01ROD.indd Sec1:15-Sec1:16SP6180IS01ROD.indd Sec1:15-Sec1:16 6/30/11 5:36 PM6/30/11 5:36 PM
17 18
925 Solo Heart Rate Watch
ADJUST: S/S or R
SET: MODE
SETTING THE COUNTDOWN TIMER
The Sportline 925 Solo Heart Rate Watch is equipped with a 100-hour Countdown Timer.
To set Timer:
1. PRESS & HOLD the MODE key in Timer mode.
2. Adjust Seconds by PRESSING the START/STOP (S/S) or RESET (R) key. Set by
PRESSING the MODE key.
3. Adjust Minutes by PRESSING the S/S or R key. Set by PRESSING the MODE key.
4. Adjust Hours by PRESSING the S/S or R key. Set by PRESSING the MODE key.
5. PRESS & HOLD the MODE key to exit the Programming Sequence and return to
Timer mode.
SETTING THE WATCH FUNCTIONSSETTING THE WATCH FUNCTIONS
PRESS HR
SENSOR
RESTING HR SET
SETTING YOUR RESTING HEART RATE
Your Resting Heart Rate is a useful reference for tracking your fitness progress. As you
gain fitness, your Resting Heart Rate will lower.
NOTE: it is recommended to check your Resting Heart Rate just after waking in the morning. For best
results, check your Resting Heart Rate under consistent conditions.
1. In Resting Heart Rate mode, PRESS & HOLD the HEART RATE SENSORS until heart
rate is acquired.
2. An audible beep will sound. Your Resting Heart Rate will be displayed and recorded.
SP6180IS01ROD.indd Sec1:17-Sec1:18SP6180IS01ROD.indd Sec1:17-Sec1:18 6/30/11 5:36 PM6/30/11 5:36 PM
19 20
925 Solo Heart Rate Watch
SETTING THE WATCH FUNCTIONS
SET: MODE
PEDOMETER MODE
The Sportline 925 Solo Heart Rate Watch has 5 Pedometer sub modes. To access Pedometer mode, PRESS the
MODE key in Time/Date mode. Scroll through sub modes by PRESSING the RESET key in Pedometer mode.
You may acquire Heart Rate by PRESSING & HOLDING the HEART RATE SENSOR in any operating mode.
1. To START recording Pedometer information, PRESS the START/STOP (S/S) key. Pedometer icon ( ) will
flash in lower left of screen when Pedometer is activated.
NOTE: To prevent false counting, there is a 10 second delay built into the watch when you first begin walking. Steps are still being
recorded in the 10 second period and will be automatically added to the step count after 10 seconds.
2. To STOP recording, PRESS the S/S key for 2 seconds.
3. To RESET the Pedometer, in any Pedometer mode, PRESS & HOLD the R key (the pedometer must be stopped).
Note: for select models – When the pedometer is turned “OFF” the display will flash PEDO OFF to remind you to turn it on when you
are ready to begin counting steps again. After 1 hour of inactivity, the pedometer sensor will also be turned off, and the warning “PEDO
OFF” flashed, to conserve battery power. Simply press START/STOP to begin counting steps again.
ADJUST: S/S or R
SETTING DUAL-TIME
The Sportline 925 Solo Heart Rate Watch is equipped with a Dual-Time
setting. To set Dual-Time:
1. PRESS & HOLD the MODE key in Dual-Time mode.
2. Adjust Hour by PRESSING the STOP/START (S/S) or RESET (R) key.
Set by PRESSING the MODE key.
3. Adjust Minutes by PRESSING the S/S or R key. Set by PRESSING the MODE key.
4. PRESS & HOLD the MODE key to exit the Programming Sequence.
OPERATING THE WATCH
PRESS
RESET
PRESS
RESET
PRESS
RESET
EXERCISE TIME/
CALORIES BURNED
DISTANCE
SPEEDAVERAGE HEART RATE
STEPS/GOAL
SP6180IS01ROD.indd Sec1:19-Sec1:20SP6180IS01ROD.indd Sec1:19-Sec1:20 6/30/11 5:36 PM6/30/11 5:36 PM
21 22
925 Solo Heart Rate Watch
RESET: R RESET: R
START/STOP
TIMING: S/S
START/STOP
TIMING: S/S
OPERATING THE CHRONOGRAPH
The Sportline 925 Solo Heart Rate Watch is equipped with a 100-hour Chronograph.
To operate the Chronograph:
1. To START timing, PRESS the START/STOP (S/S) key.
2. To STOP timing, PRESS the S/S key.
3. To RESET the Chronograph, PRESS & HOLD the RESET (R) key.
OPERATING THE COUNTDOWN TIMER
The Sportline 925 Solo Heart Rate Watch is equipped with a 100-hour Countdown Timer.
To operate the Timer:
1. To START timing, PRESS the START/STOP (S/S) key.
2. To STOP timing, PRESS the S/S key.
3. To RESET the Timer, PRESS & HOLD the RESET (R) key.
VIEWING THE BACKLIGHT SYSTEM
The Sportline 925 Solo Heart Rate Watch is equipped with an electroluminescent
(EL) Backlight System for viewing the display in low light conditions. To operate the
Backlight System:
1. PRESS the EL key.
NOTE: excessive use of Backlight System may significantly reduce battery life.
OPERATING THE WATCHOPERATING THE WATCH
SP6180IS01ROD.indd Sec1:21-Sec1:22SP6180IS01ROD.indd Sec1:21-Sec1:22 6/30/11 5:36 PM6/30/11 5:36 PM
23 24
925 Solo Heart Rate Watch
The Sportline 925 Solo Heart Rate Watch uses a single CR2032 lithium battery (SP6180, SP5705).
Battery replacement will be required from time to time, and should occur when:
1. The display fades in part or completely
2. The heart rate function will not activate
3. Backlight System does not operate
To replace the battery of your Sportline 925 Solo Heart Rate Watch, we recommend you take it to a watch
repair service center or certified jeweler. This will ensure that the water resistance will be retained after
battery replacement.
REPLACING THE WATCH BATTERY
CAUTION – BATTERY SAFETY INFORMATION
• Non-rechargeable batteries are not to be recharged
• Rechargeable batteries must be removed before recharging
• Rechargeable batteries should only be recharged under adult supervision
• Do not mix alkaline, standard (carbon-zinc), or rechargeable (nickel-cadmium) batteries
• Exhausted batteries are to be removed
• Do not mix old and new batteries
• Do not dispose of batteries in fire; batteries may explode or leak
• Do not dispose of product in fire; batteries may explode or leak
• If this product will not be used for an extended period of time, remove the batteries from the product
• The supply terminals are not to be short-circuited
• Batteries are to be inserted with correct polarity
• Clean the battery contacts and also those of the product prior to battery installation
• As always, dispose of batteries in an eco-friendly manner
The purpose of the crossed-out wheelie bin symbol is to remind us that most electrical products, and batteries,
contain trace elements (including Mercury – Hg, Cadmium – Cd and Lead – Pb) which could be harmful to our
environment and therefore our health. We must all be careful to dispose of them responsibly in a specifically
designated way – either using a collection scheme or into the correctly labelled civic amenity (NOT into general
waste) – this will help your local authority to arrange to recycle or dispose of them in the appropriate manner.
BATTERY SAFETY INFORMATION
SP6180IS01ROD.indd Sec1:23-Sec1:24SP6180IS01ROD.indd Sec1:23-Sec1:24 6/30/11 5:36 PM6/30/11 5:36 PM
25 26
925 Solo Heart Rate Watch
TROUBLE SHOOTING RANGES & SPECIFICATIONS
POTENTIAL CAUSES FOR NO HEART RATE READING OR LONG RESPONSE TIME:
CAUSE: DRY SKIN
SOLUTION: Apply conductive gel thoroughly to fingers. Tap water may help if conductive gel is not available.
CAUSE: MUSCLE TREMORS CAUSED BY PRESSING ON SENSORS TOO HARD
SOLUTION: Decrease finger pressure on the Sensor Pads.
CAUSE: DEAD SKIN ON WRIST OR FINGER
SOLUTION: Rub off excessive dead skin with a towel
CAUSE: A THIN LAYER OF BODY GREASE INSULATES THE ECG SIGNAL PREVENTING WATCH
FROM DETECTING ECG HEART RATE
SOLUTION: Wipe wrist and the back of watch with a tissue or soft towel.
CAUSE: EXCESSIVE BODY HAIR
SOLUTION: Apply conductive gel to wrist.
CAUSE: LOW BATTERY
SOLUTION: Replace the battery in watch.
TIME
• AM, PM, hour, minute, second
• 12/24 hour format
• Calendar: month, date, day display with auto
leap year adjustment
ALARM
• Daily alarm
• Alarm duration: 30 seconds
CHRONOGRAPH
• Resolution: 1/100 second
• Measuring range: 99 hours, 59 minutes, 59.99
seconds
PEDOMETER
• Step Range: 0–999999
• Exercise Time: 99 hours, 59 minutes, 59.99
seconds
• Distance: 0–248.55 mi. (0–400 km)
• Calorie Range: 0–99999 kCal
• 3 sensitivity levels
TIMER
• 1-second resolution
• Range: 99 hours, 59 minutes, 59.99 seconds
HEART RATE
• Range: 43–200 beats per minute
• 1 User Programmable Heart Rate Target Zones
• Age setting range: 5–99 years
• Height setting range: 36–84 in.
(92–214 cm)
• Weight setting range: 0–440 lbs
(0–200 kg)
OTHER
• Electroluminescent (EL) backlight
• Water resistant up to 30 meters
• Battery: CR 2032
SP6180IS01ROD.indd Sec1:25-Sec1:26SP6180IS01ROD.indd Sec1:25-Sec1:26 6/30/11 5:36 PM6/30/11 5:36 PM
27 28
925 Solo Heart Rate Watch
WARRANTY
GUARANTEE CERTIFICATE – FOR PURCHASES MADE IN THE U.S.
If at any time within five (5) years from the purchase date of this product, it fails to perform properly because of defects in material or
manufacturing, return it prepaid to: EB SPORT GROUP, 585 Oak Ridge Road, Hazleton, PA 18202
Complete this Guarantee Certificate and enclose it (or a copy of it) with the product. (PLEASE PRINT CLEARLY)
NAME TEL
ADDRESS
CITY STATE ZIP
STORE PURCHASED FROM DATE OF PURCHASE
PROBLEM WITH PRODUCT PURCHASE PRICE
REPLACEMENT
This product has been carefully designed, manufactured and packaged. If any parts are missing or damaged, please contact us at the
address above and we will replace the unit at no charge. (Guarantee does not cover crystal or battery.)
©2011 Distributed by Sportline®, Hazleton, PA 18202
FOR PURCHASES MADE IN THE UK:
Should you experience problems with this item, please return it to the point of purchase. This will not affect your statutory rights.
Alternatively return it to the address shown below for a repair/replacement.
EB Brands UK, Berkeley Business Park, Wainwright Road, Worcester WR4 9FA
www.sportline.com
Distributed in the UK by EB Brands UK, Worcester WR4 9FA
SP6180IS01ROD.indd Sec1:27-Sec1:28SP6180IS01ROD.indd Sec1:27-Sec1:28 6/30/11 5:36 PM6/30/11 5:36 PM
925 SOLO
HEART RATE WATCH
www.sportline.com
Sportline® is a trademark of SPORTLINE, a division
of EB Sport Group, Yonkers, NY 10701
Distributed in the UK by
EB Brands UK, Worcester, WR4 9FA
All Rights Reserved. ©2011
SP6180IS01ROD
SP6180IS01ROD.indd Sec1:29SP6180IS01ROD.indd Sec1:29 6/30/11 5:36 PM6/30/11 5:36 PM
