SpotCell QuickStart

potCell
S
Quick Installation Guide
www.spotwave.com
Spotwave Wireless Inc. 1 Hines Road, Ottawa ON K2K 3C7 Canada
780-00004-01-IST
© 2002 Spotwave Wireless Inc. All rights reserved. Printed in Canada
Spotwave and SpotCell are trademarks of Spotwave Wireless Inc. Patents pending.
If required, more detailed information on installing
SpotCell can be found in the enclosed User Manual. 2. Location
The DU can be mounted anywhere your cell
phone works. This may be on a rooftop (typical
rural set-up), on the side of a building, or inside
a building (typical downtown set-up). The CU
will be mounted inside the building where your
cell phone does not work.(The illustration at
the right depicts a typical installation.)
To start the installation, place the DU and CU
in the general areas where they are to be located.
Do not physically mount them at this time.
Maximum separation between the DU and CU,
and back-to-back positioning are optimal when
both are mounted indoors.
For quick installation of SpotCell:
For your safety beware of power lines and ensure that
appropriate safety measures are maintained at all times
during the installation of the SpotCell 100 equipment.
Contact with high-voltage power lines could result in
death or serious injury.
,
WARNING
6. Installation: DU
Again rotate the DU. When the LED turns green, stop the
rotation. This is the direction the DU must face when
mounted.
10. Final Checklist
1.Properly ground the DU via the grounding bolt.
2.Ensure that there is a drip loop on the cable connecting
to the DU.
3.Firmly affix the cable to the building where it runs
between the DU and CU.
Rotate 360°
3. Installation
Connect the DU and CU with the wrench and cable provided.
Back of DU
Cable connector
Cable connector
Grounding bolt
LED
7. Installation: DU
Now mount the DU. Typical installations are pictured below .
Wall Mount Pipe Mount with Hose Clamp
4. Installation
Set the switch on the bottom of the CU to “1” (install).
Connect the power supply to the CU, then plug the adapter
into the AC outlet.
8. Installation: CU
Move the switch on the bottom of the CU to “2” (active).
Hold the CU in the location to be mounted. The LCD on
the bottom of the CU indicates coverage by the number of
bars; more bars indicate better coverage.
Switch: install mode
position
DU
(outward-facing unit) CU
(indoor unit)
1. Parts List
• Mounting kit• Donor Unit (DU)
• Coverage Unit (CU)
• Cable (80'/25 m)
• Power supply
1
2
CHxxx
In Service
5. Installation: DU
In the location where the DU is to be mounted, rotate the
unit in a complete circle. The LED on the back will turn red
or green during the rotation.
9. Installation: CU
Mount the CU from a wall or ceiling, close to the centre of
the area requiring coverage.
Rotate 360°
Mounting bracket
