Sprite SPE30 Wireless Bluetooth Earphone User Manual
SPRITE (Group) LIMITED Wireless Bluetooth Earphone
Sprite >
User Manual
User Manual
Safety Caution
Use headphones while driving, please observe the
national and regional regulation Please put all the
equipment and accessories out contact with the child
or pet, which may cause suffocation and serious
consequences
Please don't using the product in too high or too low
temperature environment
(Below -10 degree centigrade or Above 45 degree
centigrade)
Extreme temperatures can cause deformations,
reduce the charging capacity of the
device, and shorten the service life .
Do not use wet equipment, liquid can cause severe
damage to equipment.Please do not use wet hand
operating equipment, equipment damage caused by
water does not make the warranty scope.
If you use high volume for a long time, you may
damage your hearing and suggest using the lowest
volume of the phone
Product Image
TWS Function Process
1.Power On：Long Press MFB button around 1.5
second,Red and blue light alternate flashing and
accompanied "turn on" prompt tone
2.Power Off：Long press MFB button around 3
second,Red flashes and a prompt "turn off" prompt.
3.Pairing ：Long press MFB button of L and R 1.5
seconds respectively, and then double-click on one
of the headphones MFB button (set it to host). Two
earbuds will automatic interconnection, after two
earbuds on interconnection vice earpieces from two
alternating red and blue flashing into a headsets
flashing blue lights, the other one headset flashing in
red and blue.
4.Connect with Phone：Open phone “setting ---
Bluetooth --- click “TS007” , After earphone
connected ,indicator will turned into a blue light
flashing with a "connected" prompt.
5.Music play/pause：Press R or L could Play or
pause music playing .
6.Answer Call：
Press MFB button when call coming .
7.Hang up Call：Press MFB button when on call .
8. Recent Call number redial：When the phone is
connected to a bluetooth headset, Double-click the
FMB button once
9.Refuse Calling：Double-click the FMB button when
call coming .
10.Cancel Calling：Short press MFB button when in
the dialing state
11.Low Battery Clarm ：
When the headset power is
less than 20%, it flashes a red light for 5 seconds and
has a "low charge prompt" in 5 minutes.
12.Low electricity shutdown：When the headset is
lower than normal, the ear automatically shuts down,
the red light flashing and the "turn off" prompt.
13.Automatic Connection：
After earphone and Phone connected ,close
Bluetooth ,then open again ,earphone will connect
with phone automatic .
Wireless Bluetooth Earphone
Bluetooth earbuds single using
1.
Single open Pairing mode：Long Press MFB
button around 1.5 second,Red and blue light
alternate flashing and accompanied "turn on" prompt
tone
2.Pairing ：Long press MFB button 1.5 seconds ,
then red and blue flashing into a headsets flashing
blue lights .
5.Music play/pause：Press MFB button Play or
pause music playing .
6.Answer Call：Press MFB button when call coming .
7.Hang up Call：Press MFB button when on call .
8. Recent Call number redial：When the phone is
connected to a bluetooth headset, Double-click the
FMB button once
9.Refuse Calling：Double-click the FMB button whe
n
call coming .
10.Cancel Calling：Short press MFB button when i
n
the dialing state
11.Low Battery Clarm ：When the headset power i
s
less than 20%, it flashes a red light for 5 seconds an
d
has a "low charge prompt" in 5 minutes.
12.Low electricity shutdown：When the headset i
s
lower than normal, the ear automatically shuts down,
the red light flashing and the "turn off" prompt.
Charging for Earphone
Put L、R into Charging case，will start charging when
case closed .
1.When the charging headsets light is red.A full
charge, headsets light is put out. 100% Power“●●●●”
75% Power“●●●” 50% Power“●●” 25% Power“●”
.
Bluetooth Version：V4.1
Support：A hands-free headset, bluetooth audio
transmission
Bluetooth Distance：10M
Level：Class 2
Working frequency：2.402~2.48GHz
Charging voltage：5V
Battery capacity ：50mAh
Charging time ：1.5 hours
Playing time：2 hours
Standby time ：110 hours
Music Playing :2 hours
Emergency power source
parameters
1. Dual USB Port
2. Input ：5V~1 A
3. Output：5V~1 A
4. Charging case battery capacity ：400mAh
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment. This device complies with Part
15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
