March 23, 2005

Side discharge tractor

13-2571-11

ESTATE

SD 12,5/96

The Stiga SD 12.5/96 is a good value tractor with a side ejector.

Manual transmission with 6 forward gears and one reverse. Briggs

& Stratton engine producing 12.5 hp.

It has a cutting width of 96 cm and manual connection of the cut-

ting deck. Large (50 cm ) wheels at the back provide good accessi-

bility.

SD 12,5/96 (13-2571-11)

MOTOR

Brand Briggs & Stratton

Power 12,5 hp

Cylinders 1

Speed 8km/h

Number of revolution 3000

FUEL

Type of fuel Petrol

Tank volume 5,8

Fuel gauge No

SPEED CONTROL

Type of transmission Transmatic

Number of gears 6

WHEELS

Wheel size 15x6 front; 20x8 rear

Bearings Plastic

Snow chains No

CUTTING SYSTEM

Cutting heights 6

Cutting width 96cm

Cutting height adjustment 31mm to 100mm

Length of blade 48cm

VIBRATIONS & SOUND LEVELS

Noise effect 100dB

CONTROLS

Electric starter Yes

Head light Yes

Hour meter No

Choke Yes

COLOUR & MATERIAL

Colour Yellow and grey

Material of chassis Metal

MEASURES & WEIGHT

Weight 150kg

Units on pallet 1

SEAT

Seat adjustable horizontally Manual

OTHER FACTS

CE-mark Yes

EAN bar code 7313321303327
