Strength Master Fitness Tech BTDONGLE BT Dongle User Manual BT dongle Aug 04m
Strength Master Fitness Tech Co. Ltd BT Dongle BT dongle Aug 04m
User Manual
BT dongle user manual
1 Introduction
1 Introduction 1 Introduction
1 Introduction
1.1
1.11.1
1.1 BT dongle
BT dongle BT dongle
BT dongle
The BT 4.0 Low Energy Dongle is design for Bluetooth standard BLE electronic accessories via
Bluetooth connectivity. It is available in the 2.4GHz ISM band Class 2 Radio, compatible with Bluetooth
Core Specification Version 4.0 BLE and EDR. ISSC IS1677SM single chip solution combines
transceiver and baseband function to decrease the external components.
1.2
1.2 1.2
1.2 The features
The featuresThe features
The features
- Bluetooth EDR & BLE 4.0
- RF receiver
- GFSK typical -90dBm,
- π/4 PSK typical -90dBm,
- 8DPSK typical -83dBm
- BLE typical -92dBm
- Low power 3.3V RF operation
- RF transmitter output power Class 2
- Internal ROM and 4Mibts of flash
- I2C for external EEPROM and authentication chip (to enable functionality between your
appcessory and the iPod, iPhone and iPad)
- 1 LED driver
1.3 I
1.3 I1.3 I
1.3 Inst
nstnst
nstallation
allation allation
allation instruction
instructioninstruction
instruction
Step 1. Open the cover of console.
Step 2. Insert the dongle into specified port on the console.
Step 3. When the dongle is connected, it can be used.
1.4
1.4 1.4
1.4 FCC
FCCFCC
FCC
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
BT dongle user manual
T
will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or
more of the following measures:
-Reorient or relocate the receiving antenna
-Increase the separation between the equipment and receiver
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected
-Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
1.5
1.51.5
1.5 Further
Further Further
Further
Information
InformationInformation
Information
If you have
further
requirements
,
please feel free to E-mail us
at:
coordìnator@lìfespanfìtness.com
