User’s manual
Product: Spread Spectrum Spatial Multiplexing MIMO Wireless Module
Model: P23368
This radio module will not be sold to general public OEM integrators. This radio module
will be used and installed for Stryker product only. Therefore we will not supply the
User’s manual, the installation is official for Stryker.
FCC ID: SSH-SYNKTX
IC: 4919C-SYNKTX
Stryker will include the following Notice required by FCC/IC on the product and in the
User’s manual.
5900 Optical Court
San Jose, CA 95138
t: 408 754 2000 f: 408 754 2505
www.stryker.com
Endoscopy
Page 2 of 4
Compliance and Regulatory Information
FCC Rules, Part 15
This device complies with Part 15 of FCC Rules. Operation is subject to the following
two conditions:
This device may not cause harmful interference, and
This device must accept any interference, including interference that may cause
undesired operation of this device.
Modification Warning
The FCC / The Industry Canada regulations provide that changes or modifications not
expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
Industry Canadian
This device complies with Industry Canada license-exempt RSS standard(s). Operation
is subject to the following two conditions:
This device may not cause harmful interference, and
This device must accept any interference, including interference that may cause
undesired operation of this device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux
appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions
suivantes:
l'appareil ne doitpas produire de brouillage, et
l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même
si le brouillage est susceptible d'en compromettre le fonctionnement.
RF Exposure Statement
This equipment complies with FCC/IC radiation exposure limits set forth for an
uncontrolled environment and meets the FCC radio frequency (RF) Exposure
Guidelines and RSS-102 of the IC radiofrequency (RF) Exposure rules. This equipment
should be installed and operated keeping the radiator at least 20cm or more away from
person’s body.
Cet équipement est conforme aux limites d’exposition aux rayonnements énoncées
pour un environnement non contrôlé et respecte les règles les radioélectriques (RF) de
la FCC lignes directrices d'exposition dans et d’exposition aux fréquences
5900 Optical Court
San Jose, CA 95138
t: 408 754 2000 f: 408 754 2505
www.stryker.com
Endoscopy
Page 3 of 4
radioélectriques (RF) CNR-102 de l’IC. Cet équipement doitêtre installé et utilisé en
gardant une distance de 20 cm ou plus entre le dispositif rayonnant et le corps.
Federal Communication Interference Statement (United States only)
This equipment has been tested and found to comply with the limits for a class B digital
device, pursuant to Part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
Re-orient or relocate the receiving antenna
Increase the separation between the equipment and receiver
Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected
Consult the dealer or an experienced radio/TV technician for help
This device and its antenna(s) must not be co-located or operation in conjunction with
any other antenna or transmitter.
Canadian Depertment of Communications Industry Canada Notice (Canada only)
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
Under Industry Canada regulations, this radio transmitter may only operate using an
antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry
Canada. To reduce potential radio interference to other users, the antenna type and its
gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not
more than that necessary for successful communication.
Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut
fonctionner avec une antenned'un type et d'un gain maximal (ou inférieur) approuvé
pour l'émetteur par Industrie Canada. Dans le but de réduireles risques de brouillage
radioélectrique à l'intention des autres utilisateurs, il faut choisir le type d'antenne et
5900 Optical Court
San Jose, CA 95138
t: 408 754 2000 f: 408 754 2505
www.stryker.com
Endoscopy
Page 4 of 4
songain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse
pas l'intensité nécessaire àl'établissement d'une communication satisfaisante.
INFORMATION FOR OEM SYSTEM INTEGRATION
This radio transmitter 4919C-SYNKTX has been approved by Industry Canada to
operate with the antenna types listed below with the maximum permissible gain and
required antenna impedance for each antenna type indicated. Antenna types not
included in this list, having a gain greater than the maximum gain indicated for that type,
are strictly prohibited for use with this device.
Le présent émetteur radio 4919C-SYNKTX a été approuvé par Industrie Canada pour
fonctionner avec les types d'antenne énumérés ci-dessous et ayant un gain admissible
maximal et l'impédance requise pour chaque type d'antenne. Les types d'antenne non
inclus dans cette liste, ou dont le gain est supérieur au gain maximal indiqué, sont
strictement interdits pour l'exploitation de l'émetteur.
For product available in the USA/Canada market. Selection of other channels is not
possible.
This device is going to be operated in 5.15~5.25GHz frequency range, it is restricted in
indoor environment only.
Antenna information: Embedded inverted F Antenna: 1.9dBi
Frequency Tolerance：+/-20ppm
Manual and Product Labeling information To the End User
The end user manual shall include all required regulatory information/warning as shown
in this manual. The end user manual shall include the RF Exposure Warning statement
to advise end user that a minimum of 20cm needs to be kept between end user and the
antenna. And when this module is installed in the host product, you must include a
"Contains FCC ID: SSH-SYNKTX" and a “Contains IC: 4919C-SYNKTX” in the label of
the host product.
