Sunitec Enterprise BC005 Bluetooth Multipoint Speakerphone User Manual UM BC932 Sunitec v0 1 A4 EN

Sunitec Enterprise Co., Ltd. Bluetooth Multipoint Speakerphone UM BC932 Sunitec v0 1 A4 EN

User Manual

1. About Bluetooth Speakerphone
This versatile Bluetooth speakerphone is specially designed for user to
enjoy convenience and freedom of wireless communication. Dual capacity
of use on desk-top like a Conference Speakerphone and in-car like a
Hands-free car kit. Advanced built-in microphone with D.S.P. solution for
Echo Cancellation & Noise Suppression that gives you impeccable full
duplex sound quality.
2. About Bluetooth Technology
Bluetooth wireless technology is set to revolutionize the personal
connectivity by providing freedom from wired connections-enabling links
and connectivity between notebook/laptop, mobile phones, portable
handheld devices and other Bluetooth enabled devices within 10 meters.
Utilizing global sound & digital data 2.4GHz ISM transmission, it makes
global communication in the way you’ve never dreamed of!
3. Getting to Know Your Bluetooth Speakerphone
To use your Bluetooth speakerphone, please follow these simple steps:
(1) Charge your speakerphone. Prior to using the speakerphone, it is
recommended to charge the battery fully for the first time. Normal full
charge time is 3 hrs. (approx.)
(2) Place your speakerphone and a Bluetooth-enabled mobile phone
within 1 meter for pairing.
(3) Ensure your speakerphone and mobile phone is placed within 10
meters Bluetooth sensing distance. (Obstruction could cause shorter
sensing distance.)
(1) Speaker
(2) Microphone
(3) LED
(4) Charging Socket (5-pin USB)
(5) Mute Button
(6) MFB Button (Multi-Function Button)
(7) Volume Increase (V+)
(8) Volume Decrease (V-)
4. Appearance and Function
User Manual
1
2
5. Charging Your Bluetooth Speakerphone
The Bluetooth speakerphone comes with a rechargeable battery. Prior to
using the speakerphone, it is recommended to charge the battery fully for
the first time. Normal full charge time is 3 hrs. (approx.)
IMPORTANT:
(1) Charging indication will be delayed for a few minutes if the speakerphone
has not been used for a long time or the battery is drained.
(2) To prolong durability of battery, it’s recommended to charge the
speakerphone whenever low battery is encountered. When battery
becomes low, LED will flash red every 3 seconds. Under low battery
condition, if speakerphone is continuously used, it’ll decrease
durability of battery as well as standby time and cause longer charge
time than normal 3 hrs. Also, the speakerphone will power off.
(3) The red LED will flash on while charging and flash off when charging
is completed.
6. Turning ON/OFF the Speakerphone
Power On: When speakerphone is under off mode, press and hold the
“MFB” for 4 seconds until you hear a short beep. The blue LED will flash 5
times, and then the speakerphone will automatically connect to the last
connected mobile phone.
Power Off: Speakerphone is under standby mode, press and hold the
9. Disconnection between Speakerphone and Mobile Phone
When you need to connect your speakerphone with another Bluetooth-
enabled mobile phone, please follow the steps below to disconnect the
speakerphone with the pre-paired mobile phone.
(1) Power off the speakerphone.
(2) Select “Disconnecting on the Bluetooth device list of your mobile
phone to remove the connection.
Note: When losing the connection/link, the speakerphone will be
automatically power off in 10 minutes. The blue LED will flash twice in every
3 seconds when the speakerphone is not connected with mobile phone.
10. Using the Speakerphone
(1) Answering a Call
When receiving a phone call, short press the “MFB” button to answer
the call.
(2) Ending a Call
Short press the “MFB” button to end a call.
(3) Reject a Call
When you hear the ringing tone, press and hold the “MFB” button for
2 seconds to reject the call.
(4) Voice Dial
If your mobile phone is voice dialing enabled, under standby mode,
short press the MFB” button and say the voice tag after you hear a
beep.
Note: Please make sure to record voice tag into the mobile phone before
using voice dial function. Functionality varies depending on the mobile
phone models. Please refer to your mobile phone user guide for details.
(5) Last Number Re-Dialing
Under standby mode, short press the “MFB” button twice for last
number redials.
(6) Adjusting the Volume
During a call, press the “V+” or “V-” buttons repeatedly until you reach
the desired volume level.
(7) Mute & Un-Mute
a: Mute: During a call, short press the “MUTE” button to mute the
speakerphone. The red LED will flash on during mute mode.
b: Un-Mute: Short press the “MUTE” button during mute mode to un-
mute the speakerphone.
“MFB” button for 4 seconds until you hear a short beep. The red LED will
flash 5 times before power off.
7. Pairing
Prior to using the speakerphone for the first time, you must pair it with a
Bluetooth-enabled mobile phone. The steps below describe pairing
instructions for a typical Bluetooth-enabled mobile phone.
(1) Place the speakerphone and mobile phone no more than 1 meter apart.
(2) Ensure the speakerphone is under OFF mode.
(3) Press and hold the “MFB” button for 6 seconds until the LED flash red
and blue alternatively, it is now ready for pairing.
(4) Activate the Bluetooth function on your mobile phone and search fro
accessible Bluetooth device by referring to your mobile phone user
guide for details.
(5) Select “BT Speaker” from the list.
(6) Enter the pre-programmed code “0000 and press “OK” to pair the
speakerphone and the phone. When pairing is completed, the blue
and red LED stop flashing, the speakerphone is under the standby
mode with the blue LED flashes in every 3 seconds.
(7) Press “Return” to go back to your mobile phone’s main menu. Please
place the mobile phone and the speakerphone within 10 meters
sensing distance. You should now be able to make and receive calls
using your speakerphone.
Note: If the pairing cannot be completed within 2 minutes after the pairing
mode is activated, the speakerphone will power off automatically. Please
repeat steps above to pair the speakerphone and mobile phone again.
8. Connection/Link between Speakerphone and Mobile Phone
After pairing is completed, speakerphone is always under standby mode.
Before you place or answer a call, if the headset icon is not shown on
phone screen, please follow the steps below to activate the Bluetooth
connection/link through your mobile phone or speakerphone until the
headset icon is on the screen.
(1) On phone: Select the “BT Speaker” from the paired list on your phone
screen.
(2) On speakerphone: Short press MFB” and select “Accepton phone
screen to accept connection.
(8) Transferring Calls
a: Speakerphone to Mobile Phone: During a call, press both of “V+”
and “V-” buttons, and the call is routed to your mobile phone.
b: Mobile Phone to Speakerphone: Press both of “V+” and V-”
buttons to route the call to speakerphone.
(9) Hold the Call
During a call, press the “MFB button twice to hold the phone call.
Press “MFB” button twice again to resume conversation.
(10) Answer the Second Call
a: When receiving a second call, press “MFB” button twice to hold
the first call on line and answer the second call.
b: When receiving a second call, press “MFB” button once to end the
first call and answer the second call.
(11) Reject the Second Call
When receiving a second call, press and hold the MFB” button for 2
seconds to reject the second call.
(12) Switch Between 2 Phone Calls
a: When having 2 calls on the line, press “MFB” button twice to
switch between these 2 phone calls.
b: When having 2 calls on the line, press MFBbutton once to end
the first call and stay with the second call.
(13) Activate Multipoint Connection
The default setting of speakerphone’s multipoint function is off.
Please activate the multipoint function for connecting with 2 mobile
phones in the same time.
a: Multipoint On: Under standby mode, press and hold V+ button
for 3 seconds until you hear a beep. After turn on the multipoint
function, the speakerphone will automatically connect to the last 2
mobile phones that has been paired before.
b: Multipoint Off: Under standby mode, press and hold “V-” button for
3 seconds until you hear a beep. The speakerphone will turn off
the multipoint function and power off automatically. When power
on the speakerphone again, it will only connect to the last
connected Bluetooth device.
(14) Multipoint Connection/Link with 2 Mobile Phones
a: When power on the speakerphone, it will automatically search
and connect the last 2 mobile phones that have been connected
before.
b: Under standby mode, press and hold “V+” button for 3 seconds
until you hear a beep, then the speakerphone will automatically
connect the last 2 mobile phone that have been connected before.
(15) Using the Secondary Mobile Phone Through Speakerphone
When connected with 2 Bluetooth mobile phones, the first connected
one is primary phone that can use MFB” button for voice dial and
redial. The second connected phone is secondary phone that will use
“V+” button for voice dial and redial
a: Voice Dial: Press “V+” button once to activate the secondary
phone’s voice dialing function.
b: Re-Dialing: Press “V+” button twice to redial the last outgoing
number of secondary phone.
Note:
1. When the speakerphone is in Multipoint mode and connect with
only 1 mobile phone, it can also enter voice dial function by press
“V+” button once or make last outgoing number re-dialing by
press “V+” button twice.
2. The Multipoint speakerphone can be paired with 2 mobile phones
at the same time. When one of them receives an incoming call,
the other phone will be disconnected from speakerphone but
resume connection automatically after the first one has finished
the phone call.
11. Low Voltage Protection of Battery
When the voltage of battery decreased to 3.3V, the red LED will flash in
every 3 seconds, and the speakerphone will be power off automatically
when the voltage under 3.0V.
12. Restore to Default Setting
Please follow the steps below to reset the speakerphone to its original
setting and remove all the previous pairing and connection.
(1) Ensure the speakerphone is under standby mode.
(2) Press and hold both of “V+and V-” buttons for 10 seconds until the
blue and red LED flash 5 times, then the speakerphone will resume
standby mode. The speakerphone is now back to original setting, and
after power on the speakerphone again, it will enter pairing mode
automatically.
NOTES: If the speakerphone is connected with a mobile phone before
restore to default setting, it will enter pairing mode automatically after
restored to default. If the speakerphone is not connected with the mobile
phone before restore to default setting, it will be under standby mode after
restored to default setting.
13. LED Indication
3
4
5
6
7
MULTIPOINT
SPEAKERPHONE
Speakerphone Status LED Indication
Power Off Mode Off
Power On Blue LED flash 5 times rapidly
Power Off Red LED flash 5 times rapidly
Standby Mode Blue LED flash once every 3 seconds
Standby (Disconnect Blue LED flash twice every 3 seconds
Bluetooth device)
Standby-Low Voltage Red LED flash once every 3 seconds
Talk in progress Blue LED flash once every 6 seconds
Mute Red LED steady on
Pairing in progress The red and blue LED flash on alternatively
Chargubg in progress Red LED steady on
Charging completed Off
(1) (2)
(3)
(7)
Mu ltip oin t Sp eak erp ho ne
(6) (8)
(4)
(5)
BC932
(2)
(3) (8)(7) (6)(4)
(1) (5)
BC372
Mult ipo int S peak erpho ne
BC352
(1) (5)
(3) (8)(7) (6)(4)
(2)
Mult ipo int S peak erpho ne
BC332
(8)(7) (6)(3) (4)
(2)
(5)
(1)
Mult ipoi nt Spe akerp hone
(5)
(8)(7)
(1)
(6)
(2)
(3)
(4)
BC322
Mult ipo int S peak erpho ne
14. Product Specification
Bluetooth Compliance: Bluetooth V2.1+EDR
Operating Frequency Band: 2.4GHz ~ 2.48GHz unlicensed ISM band
Output Power: Class 2, up to 10 meters
Support Profiles: HSP and HFP Profiles
Support Multiple Paired Device: Memorize paired data of 8 Bluetooth phones
Stand-by Time: Up to 1000 hours/ 41 days
Talk Time: Up to 10-12 hours
Battery Charging Time: About 3 hours
Charger Voltage: DC5.0V, 400mA
Battery: 650mA, BL-5B (Rechargeable Lithium Battery)
FCC Warning:
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
Changes or modification not expressly approved by the party responsible for compliance
could void the users authority to operate the equipment.
FCC Radio Frequency Exposure Statement
This product has been evaluated under FCC Bulletin OET 65C and found compliant to the
requirement asset as set forth in CFR 47 section 2.1091 and 15.247 (i) addressing RF
exposure from radio frequency device. The radiated output power of this product is far below
the FCC radio frequency exposure limit.
* The clip on the back of equipment is used for vehicle and fix on the solar plate.

Navigation menu
