Sunwe Electronic Technology IAHP86 Bluetooth Headphone User Manual
HongKong Sunwe Electronic Technology Limited Bluetooth Headphone
User manual
FCC WARNINGS
compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
ADDITIONAL WARNINGS AND PRECAUTIONS
• To avoid hearing damage, make sure that the volume on your music player is turned down before
connecting your headphones. After placing headphones in/on your ears, gradually turn up the volume
until you reach a comfortable listening level.
• Lithium batteries, like all rechargeable batteries, are recyclable and should be recycled or disposed
of according to state and local guidelines. They should never be disposed of in normal household
waste, and they should never be incinerated, as they might explode. Contact your local government for
disposal or recycling practices in your area.
• WARNING: This product may contain chemicals known to the State of California to cause birth defects,
or other reproductive harm (California Prop 65). Wash hands after handling.
• This product meets and complies with all Federal regulations.
Orientation
Wireless Noise Canceling Headphones
User’s Guide for Model IAHP86B v1547-01
Includes
• Micro-USB to USB charging cable
• 3.5mm audio cable
• Hard carrying case
Features
• Supports Bluetooth
• Wireless range: 33 feet
• Built-in microphone
• Micro-USB port for battery recharge
• Aux in (3.5mm audio input)
• Folding adjustable headband
• On-ear controls
• DC battery power: built-in
rechargeable lithium ion battery
• Battery life: approx. 8 hours
Noise Canceling
Indicator Light
Noise Canceling
ON/OFF
RIGHT EARCUP CONTROLS
Power/Pair/Play/Pause/Speakerphone
Press and hold for 4 sec. to turn the unit on and begin pairing.
Press and hold to turn OFF.
Volume +/-
Press to adjust volume level.
Aux In
Bluetooth
LED Indicator
Mic
Micro-USB
Charging Port
LEFT EARCUP CONTROLS
This device complies with Part 15 of the FCC rules. Operation is subjected to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Charging the Battery
Requires a Micro-USB to USB cable (included).
1. Using a Micro-USB to USB cable (included), connect the larger USB plug
to the USB port of a powered on computer or USB power adaptor (not
included).
2. Connect the smaller Micro-USB plug into the Micro-USB port on the unit.
The unit will now charge.
Aux In
Aux In mode will function even if the headphones are not powered ON.
To conserve battery power, keep them powered OFF when using Aux In.
Requires a 3.5mm audio cable (included).
1. Connect a 3.5mm audio cable to the Aux In on the unit and the
audio output on an audio device.
2. Use the controls on the connected device to select and play audio.
Noise Canceling
The Noise Canceling feature will electronically mute background noise. It can be
used with the Bluetooth or Aux In modes to enhance the quality of any music or
audio that is playing through the headphones.
Noise Canceling mode will function even if the headphones are not powered ON.
To conserve battery power, it is recommended to power the headphones OFF if
you want to use the Noise Canceling feature without playing audio.
Bluetooth Wireless Audio
Pairing to a Device and Playing Audio
After initial pairing, the unit will stay paired unless unpaired manually by the user,
or erased due to a reset of the device. If your device should become unpaired or
you it is unable to connect, repeat the steps listed here.
1. Press and hold the Power/Pair button on the unit for approximately
4 seconds to power the unit on and begin pairing. The pairing indicator
will begin red and blue.
When pairing, remain within 3 feet of the unit.
2. Using the controls on your Bluetooth device, select the IAHP86 in your
Bluetooth settings/device menu. If your device requests a password, enter
the default password 0 0 0 0 .
and connecting Bluetooth devices.
3. When successfully paired, the pairing indicator will start blue and
an audible chime will sound through the unit. Audio played through the
connected Bluetooth device will now be heard through the headphones.
4. Use the controls on the connected device to select and begin playing audio.
5. To play or pause audio, use the controls on the connected Bluetooth device,
or press the Play/Pause button on the headphones.
Using the Speakerphone
1. When a call is received, a ringtone will sound through the unit.
2. Press the
button to accept the call, or accept the call using the
controls on the connected phone.
3. The incoming call received through the device will now be heard through
the headphones.
4. To end the call, press the
button or end the call using the controls on
the connected device.
STATUS INDICATOR
Power On Flashing blue light
Charging Solid red light
Charging Complete Solid blue light
Pairing Flashing red and blue lights
Pairing Complete Flashing blue light
