SCF418 Chassis Series
USER’S MANUAL
1.0
SUPER ®
SCF418BC-R1K62BP SCF418IF-R1K62BP
SCF418IL-R1K62BP
![](asset-2.png)
SCF418 Chassis Manual
ii
Manual Revision 1.0
Release Date: April 11, 2013
The information in this User’s Manual has been carefully reviewed and is believed to be accurate.
The vendor assumes no responsibility for any inaccuracies that may be contained in this document,
makes no commitment to update or to keep current the information in this manual, or to notify any
person or organization of the updates. Please Note: For the most up-to-date version of this
manual, please see our web site at www.supermicro.com.
Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product
described in this manual at any time and without notice. This product, including software and
documentation, is the property of Supermicro and/or its licensors, and is supplied only under a
license. Any use or reproduction of this product is not allowed, except as expressly permitted by
the terms of said license.
IN NO EVENT WILL SUPERMICRO BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,
SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO
USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES. IN PARTICULAR, SUPERMICRO SHALL NOT HAVE LIABILITY FOR ANY
HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE PRODUCT, INCLUDING THE
COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING OR RECOVERING SUCH
HARDWARE, SOFTWARE, OR DATA.
Any disputes arising between manufacturer and customer shall be governed by the laws of Santa
Clara County in the State of California, USA. The State of California, County of Santa Clara shall
be the exclusive venue for the resolution of any such disputes. Super Micro's total liability for all
claims will not exceed the price paid for the hardware product.
California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate
warning applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate
Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”
WARNING: Handling of lead solder materials used in this
product may expose you to lead, a chemical known to
the State of California to cause birth defects and other
reproductive harm.
Unless you request and receive written permission from Super Micro Computer, Inc., you may not
copy any part of this document.
Information in this document is subject to change without notice. Other products and companies
referred to herein are trademarks or registered trademarks of their respective companies or mark
holders.
Copyright © 2013 by Super Micro Computer, Inc.
All rights reserved.
Printed in the United States of America
![](asset-3.png)
iii
Preface
Preface
About This Manual
This manual is written for professional system integrators and PC technicians. It
provides information for the installation and use of the SCF418 4U chassis. Instal-
lation and maintenance should be performed by experienced technicians only.
The FatTwin™ is the latest addition to Supermicro's evolving line of Twin Architecture
SuperServer® solutions. The 4U FatTwin greatly expands computer and storage
capacities beyond Supermicro's existing 2U Twin2™ and 1U Twin™ SuperServer®
systems to achieve increased performance with lower power consumption. By virtue
of its shared components, the FatTwin improves cost-effectiveness and reliability,
while its modular architecture makes it exible to congure and easy to maintain.
The FatTwin is available in high-density hot-plug eight node congurations with a
choice of memory capacities, hard disk drives, power supplies, front or rear I/O, PCI
and networking options and more. Its high-efciency, highly effective shared cool-
ing architecture allows the FatTwin to operate in high-temperature, free-air cooled
environments up to 47°C, providing considerable cost savings and improved TCO.
Versatile congurations allow the FatTwin to be optimized for many different environ-
ments including Data Center, Cloud Computing, and HPC; Engineering, Research,
and GPU projects; File and Storage Server deployments; and General Server and
Enterprise Server applications.
This document lists compatible parts available when this document was published.
Always refer to the our web site for updates on supported parts and congurations
![](asset-4.png)
SCF418 Chassis Manual
iv
Manual Organization
Chapter 1 Introduction
Chapter 1 describes components included with this chassis, and the main features
of the SCF418 chassis. This chapter also includes contact information.
Chapter 2 System Safety
This chapter lists warnings, precautions, and system safety. You should thoroughly
familiarize yourself with this chapter for a general overview of safety precautions
that should be followed before installing and servicing this chassis.
Chapter 3 Chassis Components
Refer here for details on this chassis model including the fans, bays, airow shields,
and other components.
Chapter 4 System Interface
See this chapter for details on the system interface, which includes the functions
and information provided by the control panel on the chassis as well as other LEDs
located throughout the system.
Chapter 5 Chassis Setup and Maintenance
Follow the procedures given in this chapter when installing or removing components,
or reconguring your chassis.
Chapter 6 Rack Installation
Refer to this chapter for detailed information on chassis rack installation. You should
follow the procedures given in this chapter when installing, removing or reconguring
your chassis into a rack environment.
Appendices
The appendices list compatible cables, power supply specications, and compatible
backplanes. Not all compatible backplanes are listed. Refer to our Web site for the
latest compatible backplane information.
![](asset-5.png)
v
Preface
Appendix A Power Supply Specications
Appendix B SAS-F418-B6 Backplane Specications
Appendix C SAS-F418-B2R Backplane Specications
![](asset-6.png)
SCF418 Chassis Manual
vi
Table of Contents
Preface
About This Manual .............................................................................................iii
Manual Organization ..........................................................................................iv
Chapter 1 Introduction
1-1 Overview ......................................................................................................... 1-1
1-2 Shipping List .................................................................................................... 1-1
Part Numbers .................................................................................................. 1-1
1-3 Contacting Supermicro .................................................................................... 1-2
1-4 Returning Merchandise for Service................................................................. 1-3
Chapter 2 Standardized Warning Statements for AC Systems
2-1 About Standardized Warning Statements ....................................................... 2-1
Warning Denition ........................................................................................... 2-1
Installation Instructions .................................................................................... 2-4
Circuit Breaker ................................................................................................ 2-5
Power Disconnection Warning ........................................................................ 2-6
Equipment Installation ..................................................................................... 2-8
Restricted Area ................................................................................................ 2-9
Battery Handling ............................................................................................ 2-10
Redundant Power Supplies .......................................................................... 2-12
Backplane Voltage ........................................................................................ 2-13
Comply with Local and National Electrical Codes ........................................ 2-14
Product Disposal ........................................................................................... 2-15
Hot Swap Fan Warning ................................................................................. 2-16
Power Cable and AC Adapter ...................................................................... 2-18
Chapter 3 Chassis Components
3-1 Overview ......................................................................................................... 3-1
3-2 Components .................................................................................................... 3-1
3-3 Where to get Replacement Components ........................................................ 3-2
Chapter 4 System Interface
4-1 Overview ......................................................................................................... 4-1
4-2 Control Panel Buttons ..................................................................................... 4-2
4-3 Control Panel LEDs ........................................................................................ 4-2
4-4 Drive Carrier LEDs .......................................................................................... 4-3
![](asset-7.png)
vii
Preface
Chapter 5 Chassis Setup and Maintenance
5-1 Overview ......................................................................................................... 5-1
5-2 Installation Procedures .................................................................................... 5-1
5-3 Removing Power Cords .................................................................................. 5-2
5-4 Node Locations ............................................................................................... 5-2
5-5 Removing Nodes from the Chassis ................................................................ 5-3
5-6 Removing the Cover from the Node ............................................................... 5-3
5-7 Node Congurations ....................................................................................... 5-4
Overview of the Node ..................................................................................... 5-4
SCF418BC-R1K62BP Node Layout ................................................................ 5-4
SCF418IF-R1K62BP Node Layout ................................................................. 5-5
SCF418IL-R1K62BP Node Layout .................................................................. 5-5
5-8 Nodes and Associated Hard Drives ................................................................ 5-6
5-9 Installing and Removing Hard Drives ............................................................. 5-8
Installing and Removing 2.5" Hard Drives ...................................................... 5-8
Installing and Removing 3.5" Fixed Hard Drives ...........................................5-11
5-10 Removing and Installing the Backplane ........................................................ 5-13
Removing the Backplane .............................................................................. 5-13
Installing the Backplane ................................................................................ 5-15
5-11 Installing the Motherboard ........................................................................... 5-16
Compatible Motherboards ............................................................................. 5-16
Permanent and Optional Standoffs ............................................................... 5-16
5-12 Installing Expansion Cards ........................................................................... 5-18
SCF418 PCIE Slot Congurations ................................................................ 5-18
Installing Rear Low-prole Expansion Cards ................................................ 5-19
Assembling the PCIE Slot Bracket Assembly .......................................... 5-20
Installing the PCIE Slot Bracket Assembly Into the Node ....................... 5-21
Installing Rear Micro LP Cards ..................................................................... 5-22
Installing the Micro LP Assembly Into the Node ...................................... 5-22
Installing Front Low-prole Expansion Cards ............................................... 5-23
Assembling the PCIE Slot Bracket Assembly .......................................... 5-24
5-13 Installing Air Shrouds .................................................................................... 5-26
Air Shrouds ................................................................................................... 5-26
5-14 Removing and Installing System Fans ......................................................... 5-27
Removing and Installing Internal System Fans ............................................ 5-27
Removing and Installing External System Fans ........................................... 5-28
5-15 Replacing the Power Supplies ..................................................................... 5-29
Power Supply Replacement .......................................................................... 5-29
![](asset-8.png)
SCF418 Chassis Manual
viii
Chapter 6 Rack Installation
6-1 Overview ......................................................................................................... 6-1
6-2 Unpacking the System .................................................................................... 6-1
6-3 Preparing for Setup ......................................................................................... 6-1
Choosing a Setup Location ............................................................................. 6-1
6-4 Warnings and Precautions .............................................................................. 6-2
Rack Precautions ............................................................................................ 6-2
General Server Precautions ............................................................................ 6-2
Rack Mounting Considerations ....................................................................... 6-3
Ambient Operating Temperature ................................................................ 6-3
Reduced Airow ......................................................................................... 6-3
Mechanical Loading ................................................................................... 6-3
Circuit Overloading ..................................................................................... 6-3
Reliable Ground ......................................................................................... 6-3
6-5 Rack Mounting Instructions ............................................................................. 6-4
Identifying the Sections of the Rack Rails ...................................................... 6-4
Adjusting the Rails .......................................................................................... 6-4
Installing the Rails on a Rack ......................................................................... 6-5
Chassis Installation ......................................................................................... 6-6
Appendix A SCF418 Power Supply Specications
Appendix B BPN-SAS-F418-B6 Backplane Specications
Appendix C BPN-SAS-F418B2R Backplane Specications
![](asset-9.png)
1-1
Chapter 1: Introduction
Chapter 1
Introduction
1-1 Overview
Supermicro's SCF418 "Fat Twin" chassis is designed to optimize performance per
Watt and per dollar with up to eight independent hot-pluggable DP computing nodes,
efciently organized into a 4U form factor. Each node provides hot-swappable and/
or xed hard drives for RAID 5 data protection, and is contained in a convenient
module to facilitate easy system upgrades, installation and maintenance. See be-
low for the hard drive conguration of your particular SCF418 chassis model. The
SCF418 chassis is equipped with high-efciency optional 1 + 1 Platinum Level
redundant power supplies (95%), on each side, for a total of four power supplies,
with a power-efcient server board and optimized cooling subsystems. The Fat Twin
is the best choice for HPC, datacenter and cost-effective blade-type applications.
1-2 Shipping List
Part Numbers
Please visit the Supermicro web site for the latest shipping lists and part numbers
for your particular chassis model at http://www.supermicro.com/products/nfo/Fat-
Twin.cfm
SCF418 Chassis
Model CPU Nodes HDD I/O Slots Power
Supply
SCF418BC-R1K62BP DP/UP 8x
48x 2.5" SAS/
SATA (8x per
node)
8x mirco LP total
(1x micro LP per
node)
8x LP total
(1x LP per node)
4x
1620W
SCF418IF-R1K62BP DP/UP 8x
16x xed 3.5"
SAS/SATA
(2x per node)
16x LP total
(2x LP per node)
4x
1620W
SCF418IL-R1K62BP DP/UP 8x
16x xed 3.5"
SAS/SATA
(2x per node)
8x LP total
(1x LP per node)
4x
1620W
![](asset-a.png)
SCF418 Chassis Manual
1-2
1-3 Contacting Supermicro
Headquarters
Address: Super Micro Computer, Inc.
980 Rock Ave.
San Jose, CA 95131 U.S.A.
Tel: +1 (408) 503-8000
Fax: +1 (408) 503-8008
Email: marketing@supermicro.com (General Information)
support@supermicro.com (Technical Support)
Web Site: www.supermicro.com
Europe
Address: Super Micro Computer B.V.
Het Sterrenbeeld 28, 5215 ML
's-Hertogenbosch, The Netherlands
Tel: +31 (0) 73-6400390
Fax: +31 (0) 73-6416525
Email: sales@supermicro.nl (General Information)
support@supermicro.nl (Technical Support)
rma@supermicro.nl (Customer Support)
Asia-Pacic
Address: Super Micro Computer, Inc.
4F, No. 232-1, Liancheng Rd
Chung-Ho Dist., New Taipei City 235
Taiwan
Tel: +886-(2) 8226-3990
Fax: +886-(2) 8226-3991
Web Site: www.supermicro.com.tw
Technical Support:
Email: support@supermicro.com.tw
Tel: +886-(2)-8226-3990
![](asset-b.png)
1-3
Chapter 1: Introduction
1-4 Returning Merchandise for Service
A receipt or copy of your invoice marked with the date of purchase is required be-
fore any warranty service will be rendered. You can obtain service by calling your
vendor for a Returned Merchandise Authorization (RMA) number. When returning
to the manufacturer, the RMA number should be prominently displayed on the
outside of the shipping carton, and mailed prepaid or hand-carried. Shipping and
handling charges will be applied for all orders that must be mailed when service
is complete.
For faster service, RMA authorizations may be requested online (http://www.
supermicro.com/support/rma/).
Whenever possible, repack the chassis in the original Supermicro carton, using the
original packaging material. If these are no longer available, be sure to pack the
chassis securely, using packaging material to surround the chassis so that it does
not shift within the carton and become damaged during shipping.
This warranty only covers normal consumer use and does not cover damages in-
curred in shipping or from failure due to the alteration, misuse, abuse or improper
maintenance of products.
During the warranty period, contact your distributor rst for any product problems.
![](asset-c.png)
2-1
Chapter 2: Warning Statements for AC Systems
Chapter 2
Standardized Warning Statements for AC Systems
2-1 About Standardized Warning Statements
The following statements are industry standard warnings, provided to warn the user
of situations which have the potential for bodily injury. Should you have questions
or experience difficulty, contact Supermicro's Technical Support department
for assistance. Only certied technicians should attempt to install or congure
components.
Read this appendix in its entirety before installing or conguring components in the
Supermicro chassis.
These warnings may also be found on our web site at http://www.supermicro.com/
about/policies/safety_information.cfm.
Warning!
This warning symbol means danger. You are in a situation that could cause bodily
injury. Before you work on any equipment, be aware of the hazards involved with
electrical circuitry and be familiar with standard practices for preventing accidents.
Warning Denition
警告の定義
この警告サインは危 険を意 味します。
人身事故につながる可能性がありますので、いずれの機器でも動作させる前に、
電気回路に含まれる危険性に注意して、標準的な事故防止策に精通して下さい。
此警告符号代表危险。
您正处于可能受到严重伤害的工作环境中。在您使用设备开始工作之前,必须充分
意识到触电的危险,并熟练掌握防止事故发生的标准工作程序。请根据每项警告结
尾的声明号码找到此设备的安全性警告说明的翻译文本。
此警告符號代表危險。
您正處於可能身體可能會受損傷的工作環境中。在您使用任何設備之前,請注意觸
電的危險,並且要熟悉預防事故發生的標準工作程序。請依照每一注意事項後的號
碼找到相關的翻譯說明內容。
![](asset-d.png)
2-2
SUPERSERVER "servername" User's Manual
Warnung
WICHTIGE SICHERHEITSHINWEISE
Dieses Warnsymbol bedeutet Gefahr. Sie benden sich in einer Situation, die zu
Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den
Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung
vor Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung angegebenen
Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten
Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.
BEWAHREN SIE DIESE HINWEISE GUT AUF.
INSTRUCCIONES IMPORTANTES DE SEGURIDAD
Este símbolo de aviso indica peligro. Existe riesgo para su integridad física. Antes
de manipular cualquier equipo, considere los riesgos de la corriente eléctrica y
familiarícese con los procedimientos estándar de prevención de accidentes. Al
nal de cada advertencia encontrará el número que le ayudará a encontrar el texto
traducido en el apartado de traducciones que acompaña a este dispositivo.
GUARDE ESTAS INSTRUCCIONES.
IMPORTANTES INFORMATIONS DE SÉCURITÉ
Ce symbole d'avertissement indique un danger. Vous vous trouvez dans une
situation pouvant entraîner des blessures ou des dommages corporels. Avant
de travailler sur un équipement, soyez conscient des dangers liés aux circuits
électriques et familiarisez-vous avec les procédures couramment utilisées pour
éviter les accidents. Pour prendre connaissance des traductions des avertissements
gurant dans les consignes de sécurité traduites qui accompagnent cet appareil,
référez-vous au numéro de l'instruction situé à la n de chaque avertissement.
CONSERVEZ CES INFORMATIONS.
ןונקת תורהצהאהרהז
ןה תואבה תורהצהא ינפמ שמתשמה תא ריהזהל תנמ לע ,היישעתה ינקת יפ לע תורהז הלבח
ה וא תולאש שיו הדימב .תירשפא תיזיפי ,יהשלכ היעבב תולקתרוציל שי הכימת תקלחמ םע רשק
רידגהל וא ןיקתהל םיאשר דבלב םיכמסומ םיאנכט .ורקימרפוס לש תינכט תאה .םיביכר
אורקל שי .ורקימרפוס יזראמב םיביכרה תרדגה וא תנקתה ינפל ואולמב חפסנה תא
![](asset-e.png)
2-3
Warning Statements for AC Systems
안전을 위한 주의사항
경고!
이 경고 기호는 위험이 있음을 알려 줍니다. 작업자의 신체에 부상을 야기 할 수
있는 상태에 있게 됩니다. 모든 장비에 대한 작업을 수행하기 전에 전기회로와
관련된 위험요소들을 확인하시고 사전에 사고를 방지할 수 있도록 표준
작업절차를 준수해 주시기 바랍니다.
해당 번역문을 찾기 위해 각 경고의 마지막 부분에 제공된 경고문 번호를
참조하십시오
BELANGRIJKE VEILIGHEIDSINSTRUCTIES
Dit waarschuwings symbool betekent gevaar. U verkeert in een situatie die
lichamelijk letsel kan veroorzaken. Voordat u aan enige apparatuur gaat werken,
dient u zich bewust te zijn van de bij een elektrische installatie betrokken risico's
en dient u op de hoogte te zijn van de standaard procedures om ongelukken te
voorkomen. Gebruik de nummers aan het eind van elke waarschuwing om deze te
herleiden naar de desbetreffende locatie.
BEWAAR DEZE INSTRUCTIES
![](asset-f.png)
2-4
SUPERSERVER "servername" User's Manual
Installation Instructions
Warning!
Read the installation instructions before connecting the system to the power source.
Warnung
Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen
lesen.
¡Advertencia!
Lea las instrucciones de instalación antes de conectar el sistema a la red de
alimentación.
Attention
Avant de brancher le système sur la source d'alimentation, consulter les directives
d'installation.
設置手順書
システムを電源に接続する前に、設置手順書をお読み下さい。
אורקל שי רוקמל תכרעמה רוביח ינפל הנקתה תוארוה תאחתמ.
시스템을 전원에 연결하기 전에 설치 안내를 읽어주십시오.
Waarschuwing
Raadpleeg de installatie-instructies voordat u het systeem op de voedingsbron
aansluit.
警告
将此系统连接电源前,请先阅读安装说明。
警告
將系統與電源連接前,請先閱讀安裝說明。
![](asset-10.png)
2-5
Chapter 2: Warning Statements for AC Systems
Circuit Breaker
Warning!
This product relies on the building's installation for short-circuit (overcurrent)
protection. Ensure that the protective device is rated not greater than: 250 V, 20 A.
サーキット・ブレーカー
この製品は、短絡(過電流)保護装置がある建物での設置を前提としています。
保護装置の定格が250 V、20 Aを超えないことを確認下さい。
Warnung
Dieses Produkt ist darauf angewiesen, dass im Gebäude ein Kurzschluss-
bzw. Überstromschutz installiert ist. Stellen Sie sicher, dass der Nennwert der
Schutzvorrichtung nicht mehr als: 250 V, 20 A beträgt.
¡Advertencia!
Este equipo utiliza el sistema de protección contra cortocircuitos (o sobrecorrientes)
del edicio. Asegúrese de que el dispositivo de protección no sea superior a: 250
V, 20 A.
Attention
Pour ce qui est de la protection contre les courts-circuits (surtension), ce produit
dépend de l'installation électrique du local. Vériez que le courant nominal du
dispositif de protection n'est pas supérieur à :250 V, 20 A.
לע ךמתסמ הז רצומנגהה תעינמל םינבמב תנקתומה יכ אדוול שי .ילמשח רצק
רצקה ינפמ ןגמה רישכמה ילמשחהמ רתוי אל אוה-250 V, 20 A
20A, 250V :
警告
此产品的短路(过载电流)保护由建筑物的供电系统提供,确保短路保护设备的额定电
流不大于250V,20A。
警告
此產品的短路(過載電流)保護由建築物的供電系統提供,確保短路保護設備的額定電
流不大於250V,20A。
![](asset-11.png)
2-6
SUPERSERVER "servername" User's Manual
Power Disconnection Warning
電源切断の警告
システムコンポーネントの取り付けまたは取り外しのために、シャーシー内部にアクセス
するには、
システムの電源はすべてのソースから切断され、電源コードは電源モジュールから取り
外す必要があります。
警告
在你打开机箱并安装或移除内部器件前,必须将系统完全断电,并移除电源线。
警告
在您打開機殼安裝或移除內部元件前,必須將系統完全斷電,並移除電源線。
Warnung
Das System muss von allen Quellen der Energie und vom Netzanschlusskabel
getrennt sein, das von den Spg.Versorgungsteilmodulen entfernt wird, bevor es
auf den Chassisinnenraum zurückgreift, um Systemsbestandteile anzubringen oder
zu entfernen.
Warning!
The system must be disconnected from all sources of power and the power cord
removed from the power supply module(s) before accessing the chassis interior to
install or remove system components.
경고!
이 제품은 전원의 단락(과전류)방지에 대해서 전적으로 건물의 관련 설비에
의존합니다. 보호장치의 정격이 반드시 250V(볼트), 20A(암페어)를 초과하지
않도록 해야 합니다.
Waarschuwing
Dit product is afhankelijk van de kortsluitbeveiliging (overspanning) van
uw electrische installatie. Controleer of het beveiligde aparaat niet groter
gedimensioneerd is dan 220V, 20A.
![](asset-12.png)
2-7
Chapter 2: Warning Statements for AC Systems
¡Advertencia!
El sistema debe ser disconnected de todas las fuentes de energía y del cable
eléctrico quitado de los módulos de fuente de alimentación antes de tener acceso
el interior del chasis para instalar o para quitar componentes de sistema.
Attention
Le système doit être débranché de toutes les sources de puissance ainsi que de
son cordon d'alimentation secteur avant d'accéder à l'intérieur du chassis pour
installer ou enlever des composants de systéme.
ילמשח קותינ ינפמ הרהזא
!הרהזא
למשחה תורוקמ לכמ תכרעמה תא קתנל שי ריסהל שיו קפסהמ ילמשחה לבכ תא
נקתה ךרוצל זראמה לש ימינפה קלחל השיג ינפלת רסה ואת .םיביכר
경고!
시스템에 부품들을 장착하거나 제거하기 위해서는 섀시 내부에 접근하기 전에
반드시 전원 공급장치로부터 연결되어있는 모든 전원과 전기코드를 분리해주어야
합니다.
Waarschuwing
Voordat u toegang neemt tot het binnenwerk van de behuizing voor het installeren
of verwijderen van systeem onderdelen, dient u alle spanningsbronnen en alle
stroomkabels aangesloten op de voeding(en) van de behuizing te verwijderen
![](asset-13.png)
2-8
SUPERSERVER "servername" User's Manual
Equipment Installation
機器の設置
トレーニングを受け認定された人だけがこの装置の設置、交換、またはサービスを許可
されています。
Warning!
Only trained and qualied personnel should be allowed to install, replace, or service
this equipment.
Warnung
Das Installieren, Ersetzen oder Bedienen dieser Ausrüstung sollte nur geschultem,
qualiziertem Personal gestattet werden.
¡Advertencia!
Solamente el personal calicado debe instalar, reemplazar o utilizar este equipo.
Attention
Il est vivement recommandé de confier l'installation, le remplacement et la
maintenance de ces équipements à des personnels qualiés et expérimentés.
!הרהזא
שר דבלב ךמסומ תווצתא ףילחהל ,ןיקתהל יא .דויצה רובע תוריש תתל וא דויצה
경고!
훈련을 받고 공인된 기술자만이 이 장비의 설치, 교체 또는 서비스를 수행할 수
있습니다.
警告
只有经过培训且具有资格的人员才能进行此设备的安装、更换和维修。
警告
只有經過受訓且具資格人員才可安裝、更換與維修此設備。
![](asset-14.png)
2-9
Chapter 2: Warning Statements for AC Systems
アクセス制限区域
このユニットは、アクセス制限区域に設置されることを想定しています。
アクセス制限区域は、特別なツール、鍵と錠前、その他のセキュリティの手段を用いての
み出入りが可能です。
Warning!
This unit is intended for installation in restricted access areas. A restricted access
area can be accessed only through the use of a special tool, lock and key, or other
means of security. (This warning does not apply to workstations).
Restricted Area
Waarschuwing
Deze apparatuur mag alleen worden geïnstalleerd, vervangen of hersteld door
geschoold en gekwaliceerd personeel.
Warnung
Diese Einheit ist zur Installation in Bereichen mit beschränktem Zutritt vorgesehen.
Der Zutritt zu derartigen Bereichen ist nur mit einem Spezialwerkzeug, Schloss und
Schlüssel oder einer sonstigen Sicherheitsvorkehrung möglich.
¡Advertencia!
Esta unidad ha sido diseñada para instalación en áreas de acceso restringido.
Sólo puede obtenerse acceso a una de estas áreas mediante la utilización de una
herramienta especial, cerradura con llave u otro medio de seguridad.
Attention
Cet appareil doit être installée dans des zones d'accès réservés. L'accès à une
zone d'accès réservé n'est possible qu'en utilisant un outil spécial, un mécanisme
de verrouillage et une clé, ou tout autre moyen de sécurité.
警告
此部件应安装在限制进出的场所,限制进出的场所指只能通过使用特殊工具、锁和
钥匙或其它安全手段进出的场所。
警告
此裝置僅限安裝於進出管制區域,進出管制區域係指僅能以特殊工具、鎖頭及鑰匙
或其他安全方式才能進入的區域。
![](asset-15.png)
2-10
SUPERSERVER "servername" User's Manual
Battery Handling
Warning!
There is the danger of explosion if the battery is replaced incorrectly. Replace the
battery only with the same or equivalent type recommended by the manufacturer.
Dispose of used batteries according to the manufacturer's instructions
תלבגומ השיג םע רוזא
!הרהזא
תרזעב תנתינ השיגה .השיג תלבגה םהב שיש םירוזאב הדיחיה תא ןיקתהל שי
.)'דכו לוענמ ,חתפמ( דבלב החטבא ילכ
.
경고!
이 장치는 접근이 제한된 구역에 설치하도록 되어있습니다. 특수도구, 잠금 장치 및
키, 또는 기타 보안 수단을 통해서만 접근 제한 구역에 들어갈 수 있습니다.
Waarschuwing
Dit apparaat is bedoeld voor installatie in gebieden met een beperkte toegang.
Toegang tot dergelijke gebieden kunnen alleen verkregen worden door gebruik te
maken van speciaal gereedschap, slot en sleutel of andere veiligheidsmaatregelen.
電池の取り扱い
電池交換が正しく行われなかった場合、破裂の危険性があります。 交換する電池はメー
カーが推奨する型、または同等のものを使用下さい。 使用済電池は製造元の指示に従
って処分して下さい。
警告
电池更换不当会有爆炸危险。请只使用同类电池或制造商推荐的功能相当的电池更
换原有电池。请按制造商的说明处理废旧电池。
警告
電池更換不當會有爆炸危險。請使用製造商建議之相同或功能相當的電池更換原有
電池。請按照製造商的說明指示處理廢棄舊電池。
![](asset-16.png)
2-11
Chapter 2: Warning Statements for AC Systems
Warnung
Bei Einsetzen einer falschen Batterie besteht Explosionsgefahr. Ersetzen Sie die
Batterie nur durch den gleichen oder vom Hersteller empfohlenen Batterietyp.
Entsorgen Sie die benutzten Batterien nach den Anweisungen des Herstellers.
Attention
Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer
que par une pile de type semblable ou équivalent, recommandée par le fabricant.
Jeter les piles usagées conformément aux instructions du fabricant.
¡Advertencia!
Existe peligro de explosión si la batería se reemplaza de manera incorrecta.
Reemplazar la batería exclusivamente con el mismo tipo o el equivalente
recomendado por el fabricante. Desechar las baterías gastadas según las
instrucciones del fabricante.
!הרהזא
תנכס תמייקץוציפ .הניקת אל ךרדב הפלחוהו הדימב הללוסה לש ףילחהל שי
גוסב הללוסה תא מ םאותה תרבחלמומ ןרציתצ.
תוללוסה קוליס תושמושמה עצבל שי .ןרציה תוארוה יפל
경고!
배터리가 올바르게 교체되지 않으면 폭발의 위험이 있습니다. 기존 배터리와
동일하거나 제조사에서 권장하는 동등한 종류의 배터리로만 교체해야 합니다.
제조사의 안내에 따라 사용된 배터리를 처리하여 주십시오.
Waarschuwing
Er is ontplofngsgevaar indien de batterij verkeerd vervangen wordt. Vervang de
batterij slechts met hetzelfde of een equivalent type die door de fabrikant aanbevolen
wordt. Gebruikte batterijen dienen overeenkomstig fabrieksvoorschriften afgevoerd
te worden.
![](asset-17.png)
2-12
SUPERSERVER "servername" User's Manual
Warnung
Dieses Gerät kann mehr als eine Stromzufuhr haben. Um sicherzustellen, dass
der Einheit kein trom zugeführt wird, müssen alle Verbindungen entfernt werden.
¡Advertencia!
Puede que esta unidad tenga más de una conexión para fuentes de alimentación.
Para cortar por completo el suministro de energía, deben desconectarse todas las
conexiones.
Attention
Cette unité peut avoir plus d'une connexion d'alimentation. Pour supprimer toute
tension et tout courant électrique de l'unité, toutes les connexions d'alimentation
doivent être débranchées.
Redundant Power Supplies
Warning!
This unit might have more than one power supply connection. All connections must
be removed to de-energize the unit.
冗長電源装置
このユニットは複数の電源装置が接続されている場合があります。
ユニットの電源を切るためには、すべての接続を取り外さなければなりません。
דחא קפסמ רתוי םייק םא
!הרהזא
.קפס לש דחא רוביחמ רתוי שי הדחיל תא ריסהל שי
ןקורל תנמ לע םירוביחה לכ
חיה תאי.הד
警告
此部件连接的电源可能不止一个,必须将所有电源断开才能停止给该部件供电。
警告
此裝置連接的電源可能不只一個,必須切斷所有電源才能停止對該裝置的供電。
![](asset-18.png)
2-13
Chapter 2: Warning Statements for AC Systems
Backplane Voltage
バックプレーンの電圧
システムの稼働中は危険な電圧または電力が、バックプレーン上にかかっています。
修理する際には注意ください。
警告
当系统正在进行时,背板上有很危险的电压或能量,进行维修时务必小心。
警告
當系統正在進行時,背板上有危險的電壓或能量,進行維修時務必小心。
Warnung
Wenn das System in Betrieb ist, treten auf der Rückwandplatine gefährliche
Spannungen oder Energien auf. Vorsicht bei der Wartung.
¡Advertencia!
Cuando el sistema está en funcionamiento, el voltaje del plano trasero es peligroso.
Tenga cuidado cuando lo revise.
Attention
Lorsque le système est en fonctionnement, des tensions électriques circulent sur
le fond de panier. Prendre des précautions lors de la maintenance.
Warning!
Hazardous voltage or energy is present on the backplane when the system is
operating. Use caution when servicing.
.
경고!
이 장치에는 한 개 이상의 전원 공급 단자가 연결되어 있을 수 있습니다. 이 장치에
전원을 차단하기 위해서는 모든 연결 단자를 제거해야만 합니다.
Waarschuwing
Deze eenheid kan meer dan één stroomtoevoeraansluiting bevatten. Alle
aansluitingen dienen verwijderd te worden om het apparaat stroomloos te maken.
![](asset-19.png)
2-14
SUPERSERVER "servername" User's Manual
Comply with Local and National Electrical Codes
Warning!
Installation of the equipment must comply with local and national electrical codes.
地方および国の電気規格に準拠
機器の取り付けはその地方および国の電気規格に準拠する必要があります。
Warnung
Die Installation der Geräte muss den Sicherheitsstandards entsprechen.
¡Advertencia!
La instalacion del equipo debe cumplir con las normas de electricidad locales y
nacionales.
경고!
시스템이 동작 중일 때 후면판 (Backplane)에는 위험한 전압이나 에너지가 발생
합니다. 서비스 작업 시 주의하십시오.
Waarschuwing
Een gevaarlijke spanning of energie is aanwezig op de backplane wanneer het
systeem in gebruik is. Voorzichtigheid is geboden tijdens het onderhoud.
ירוחאה לנפב חתמ
זא!הרה
ךלהמב רהזיהל שי .תכרעמה לועפת ןמזב ירוחאה לנפב חתמ תנכס תמייק
.הדובעה
警告
设备安装必须符合本地与本国电气法规。
警告
設備安裝必須符合本地與本國電氣法規。
![](asset-1a.png)
2-15
Chapter 2: Warning Statements for AC Systems
Product Disposal
Warning!
Ultimate disposal of this product should be handled according to all national laws
and regulations.
יצראה למשחה יקוח םואית
!הרהזא
תנקתה םייצראהו םיימוקמה למשחה יקוחל תמאות תויהל תבייח דויצה.
Attention
L'équipement doit être installé conformément aux normes électriques nationales
et locales.
경고!
현 지역 및 국가의 전기 규정에 따라 장비를 설치해야 합니다.
Waarschuwing
Bij installatie van de apparatuur moet worden voldaan aan de lokale en nationale
elektriciteitsvoorschriften.
製品の廃棄
この製品を廃棄処分する場合、国の関係する全ての法律・条例に従い処理する必要が
あります。
警告
本产品的废弃处理应根据所有国家的法律和规章进行。
警告
本產品的廢棄處理應根據所有國家的法律和規章進行。
Warnung
Die Entsorgung dieses Produkts sollte gemäß allen Bestimmungen und Gesetzen
des Landes erfolgen.
![](asset-1b.png)
2-16
SUPERSERVER "servername" User's Manual
Waarschuwing
De uiteindelijke verwijdering van dit product dient te geschieden in overeenstemming
met alle nationale wetten en reglementen.
¡Advertencia!
Al deshacerse por completo de este producto debe seguir todas las leyes y
reglamentos nacionales.
Attention
La mise au rebut ou le recyclage de ce produit sont généralement soumis à des
lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de
l'organisme compétent.
Warning!
The fans might still be turning when you remove the fan assembly from the chassis.
Keep ngers, screwdrivers, and other objects away from the openings in the fan
assembly's housing.
Hot Swap Fan Warning
רצומה קוליס
!הרהזא
ו תויחנהל םאתהב תויהל בייח הז רצומ לש יפוס קוליס.הנידמה יקוח
ファン・ホットス ワップ の 警 告
シャーシから冷却ファン装置を取り外した際、ファンがまだ回転している可能性がありま
す。 ファンの開口部に、指、ドライバー、およびその他のものを近づけないで下さい。
警告
当您从机架移除风扇装置,风扇可能仍在转动。小心不要将手指、螺丝起子和其他
物品太靠近风扇
경고!
이 제품은 해당 국가의 관련 법규 및 규정에 따라 폐기되어야 합니다.
![](asset-1c.png)
2-17
Chapter 2: Warning Statements for AC Systems
Warnung
Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis
genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände
von den Öffnungen des Lüftergehäuses entfernt.
¡Advertencia!
Los ventiladores podran dar vuelta cuando usted quite ell montaje del ventilador
del chasis. Mandtenga los dedos, los destornilladores y todos los objetos lejos de
las aberturas del ventilador
Attention
Il est possible que les ventilateurs soient toujours en rotation lorsque vous retirerez
le bloc ventilateur du châssis. Prenez garde à ce que doigts, tournevis et autres
objets soient éloignés du logement du bloc ventilateur.
!הרהזא
יקלח תא םיריסמ רשאכ שי .םידבוע ןיידע םיררוואמהו ןכתי ,זראמהמ ררוואמה
קיחרהללררוואמה ךותב םיחתפהמ םינוש הדובע ילכו תועבצאה תא חוטב קחרמ
.
경고!
섀시로부터 팬 조립품을 제거할 때 팬은 여전히 회전하고 있을 수 있습니다. 팬
조림품 외관의 열려있는 부분들로부터 손가락 및 스크류드라이버, 다른 물체들이
가까이 하지 않도록 배치해 주십시오.
Waarschuwing
Het is mogelijk dat de ventilator nog draait tijdens het verwijderen van het
ventilatorsamenstel uit het chassis. Houd uw vingers, schroevendraaiers
en eventuele andere voorwerpen uit de buurt van de openingen in de
ventilatorbehuizing.
警告
當您從機架移除風扇裝置,風扇可能仍在轉動。小心不要將手指、螺絲起子和其他
物品太靠近風扇。
![](asset-1d.png)
2-18
SUPERSERVER "servername" User's Manual
Warning!
When installing the product, use the provided or designated connection cables,
power cables and AC adaptors. Using any other cables and adaptors could cause
a malfunction or a re. Electrical Appliance and Material Safety Law prohibits the
use of UL or CSA -certied cables (that have UL/CSA shown on the code) for any
other electrical devices than products designated by Supermicro only.
Power Cable and AC Adapter
Warnung
Bei der Installation des Produkts, die zur Verfügung gestellten oder benannt
Anschlusskabel, Stromkabel und Netzteile. Verwendung anderer Kabel und Adapter
kann zu einer Fehlfunktion oder ein Brand entstehen. Elektrische Geräte und
Material Safety Law verbietet die Verwendung von UL-oder CSA-zertizierte Kabel,
UL oder CSA auf der Code für alle anderen elektrischen Geräte als Produkte von
Supermicro nur bezeichnet gezeigt haben.
¡Advertencia!
Al instalar el producto, utilice los cables de conexión previstos o designados, los
cables y adaptadores de CA. La utilización de otros cables y adaptadores podría
ocasionar un mal funcionamiento o un incendio. Aparatos Eléctricos y la Ley de
Seguridad del Material prohíbe el uso de UL o CSA cables certicados que tienen
UL o CSA se muestra en el código de otros dispositivos eléctricos que los productos
designados por Supermicro solamente.
電源コードとACアダプター
製品を設置する場合、提供または指定された接続ケーブル、電源コードとACアダプター
を使用下さい。 他のケーブルやアダプタを使用すると故障や火災の原因になることがあ
ります。 電気用品安全法は、ULまたはCSA認定のケーブル(UL/CSEマークがコードに表
記)を Supermicroが指定する製品以外に使用することを禁止しています。
警告
安装此产品时,请使用本身提供的或指定的连接线,电源线和电源适配器.使用其它线
材或适配器可能会引起故障或火灾。除了Supermicro所指定的产品,电气用品和材
料安全法律规定禁止使用未经UL或CSA认证的线材。(线材上会显示UL/CSA符号)。
警告
安裝此產品時,請使用本身提供的或指定的連接線,電源線和電源適配器.使用其它線
材或適配器可能會引起故障或火災。除了Supermicro所指定的產品,電氣用品和材
料安全法律規定禁止使用未經UL或CSA認證的線材。(線材上會顯示UL/CSA符號)。
![](asset-1e.png)
2-19
Chapter 2: Warning Statements for AC Systems
Attention
Lors de l'installation du produit, utilisez les bables de connection fournis ou désigné.
L'utilisation d'autres cables et adaptateurs peut provoquer un dysfonctionnement
ou un incendie. Appareils électroménagers et de loi sur la sécurité Matériel interdit
l'utilisation de UL ou CSA câbles certiés qui ont UL ou CSA indiqué sur le code
pour tous les autres appareils électriques que les produits désignés par Supermicro
seulement.
אתמו םיילמשחמ יAC
!הרהזא
םימאתמו םיקפס ,םילבכב שמתשהל שי ,רצומה תא םיניקתמ רשאכAC רשא
וא הלקתל םורגל לוכי רחא םאתמ וא לבכ לכב שומיש .ךכ םשל וקפוסו ודעונ
טב יקוחו למשח ירישכמב שומיש יקוח יפ לע .ילמשח רצק רוסיא םייק ,תוחי
ב םיכמסומה םילבכב שמתשהל-
UL ב וא- CSA לש דוק םהילע עיפומ ראשכ(
UL/CSA) רחא ילמשח רצומ לכ רובע.דבלב ורקימקרפוס ידי לע ןיוצ אלש
. .
UL CSA
Supermicro
(UL/CSA )
경고!
제품을 설치할 때에는 제공되거나 지정된 연결케이블과 전원케이블, AC어댑터를
사용해야 합니다. 그 밖의 다른 케이블들이나 어댑터들은 고장 또는 화재의 원인이
될 수 있습니다. 전기용품안전법 (Electrical Appliance and Material Safety
Law)은 슈퍼마이크로에서 지정한 제품들 외에는 그 밖의 다른 전기 장치들을
위한 UL또는 CSA에서 인증한 케이블(전선 위에 UL/CSA가 표시)들의 사용을
금지합니다.
Waarschuwing
Bij het installeren van het product, gebruik de meegeleverde of aangewezen kabels,
stroomkabels en adapters. Het gebruik van andere kabels en adapters kan leiden
tot een storing of een brand. Elektrisch apparaat en veiligheidsinformatiebladen wet
verbiedt het gebruik van UL of CSA gecerticeerde kabels die UL of CSA die op
de code voor andere elektrische apparaten dan de producten die door Supermicro
alleen.
![](asset-1f.png)
2-20
SUPERSERVER "servername" User's Manual
Notes
![](asset-20.png)
3-1
Chapter 3: Chassis Components
Chapter 3
Chassis Components
3-1 Overview
This chapter describes the most common components included with your chassis.
Some components listed may not be included or compatible with your particular
chassis model. For more information, see the installation instructions detailed later
in this manual.
3-2 Components
Chassis
The SCF418 chassis is available in a variety of congurations. For more information,
visit our Web site at: http://www.supermicro.com.
Backplane
Some SCF418 chassis models come equipped with a SAS-F418-B6 backplane. For
more information regarding compatible backplanes, visit the Supermicro web site
at http://www.supermicro.com.
Fans
The SCF418 chassis supports system fans. System fans for the SCF418 chassis are
powered from the motherboards or the backplane. When one of the motherboard
nodes is removed, another motherboard will continue to operate the fans.
Mounting Rails
The SCF418 includes a set of rails, and can be placed in a rack for secure stor-
age and use. To setup your rack, follow the step-by-step instructions included in
this manual.
Power Supply
Each SCF418 chassis model includes a high-efciency 94%+ Plus Platinum Level
power supply, rated at 1620 Watts. In the unlikely event your power supply fails,
replacement is simple and can be accomplished without tools.
![](asset-21.png)
SCF418 Chassis Manual
3-2
Air Shroud
The SCF418 chassis requires air shrouds for each node to direct the airow where
cooling is needed. The air shroud will differ for different motherboards. If using a
motherboard which is not the default in the chassis, refer to the optional parts in
the Appendix of this manual, or the Supermicro web site at www.supermicro.com
to puchase the proper air shroud.
3-3 Where to get Replacement Components
Although not frequently, you may need replacement parts for your system. To
ensure the highest level of professional service and technical support, we strongly
recommend purchasing exclusively from our Supermicro Authorized Distributors/
System Integrators/Resellers. A list of Supermicro Authorized Distributors/System
Integrators/Reseller can be found at: http://www.supermicro.com. Click the Where
to Buy link.
![](asset-22.png)
4-1
Chapter 4: System Interface
Chapter 4
System Interface
4-1 Overview
There are several LEDs on the control panel and on the drive carriers to keep you
constantly informed of the overall status of the system. SCF418 models with rear I/O
(left image below) include four control panels on the handles of the chassis which
control each of the nodes. SCF418 chassis with front I/O (right image below) have
a power button LED and a UID indicator, with additional LED indicators directly on
the motherboard.
This chapter explains the meanings of all LED indicators and the appropriate re-
sponse you may need to take.
Figure 4-1: Chassis Control Panel
Front I/O ChassisRear I/O Chassis
![](asset-23.png)
SCF418 Chassis Manual
4-2
4-2 Control Panel Buttons
•Power: The main power button on each of the four control panels is
used to apply or remove power from the power supply to each of the
four systems in the chassis. Turning off system power with this but-
ton removes the main power, but keeps standby power supplied to the
system. Therefore, you must unplug system before servicing. The poer
button has a built-in LED which will turn green when the power is on.
•UID: When used with a UID compatible motherboard, the UID indicator is used
to turn on or off the blue light function of the LED. This is built into the front
side of the UID button and at the rear end of each motherboard node, for those
motherboards which support it. Once the blue light is activated, the unit can be
easily located in very large racks and server banks.
4-3 Control Panel LEDs
The four control panels are located on the front handle of the SCF418 chassis.
Each control panel has two additional LEDs. These LEDs provide you with critical
information related to different parts of the system. This section explains what each
LED indicates when illuminated and any corrective action you may need to take.
•Informational LED:
Continuously on and blue: UID function has been activated.
Flashing red: Fan failure.
Continuously on and red: Overheat condition. This may be caused by cables
obstructing the airow in the system or the ambient room temperature being
too warm. Check the routing of the cables and make sure all fans are present
and operating normally. You should also check to make sure that the chassis
covers are installed. Finally, verify that the heatsinks are installed properly.
This LED will remain ashing or on as long as the overheat or fan failure
condition exists.
![](asset-24.png)
4-3
Chapter 4: System Interface
•NIC: Indicates network activity on either LAN1 or LAN2 when ashing.
4-4 Drive Carrier LEDs
The SCF418 chassis uses SAS/SATA drives.
SAS/SATA Drives
Each SAS/SATA drive carrier has two LEDs.
•Blue: Each Serial ATA drive carrier has a blue LED. When illuminated, this blue
LED (on the front of the SATA drive carrier) indicates drive activity. A connection
to the SATA backplane enables this LED to blink on and off when that particular
drive is being accessed.
•Red: The red LED illuminates to indicate a SAS/SATA drive failure. If one of
the SAS/SATA drives fail, you should be notied by your system management
software.
SCSI Drives
This chassis does not support SCSI drives.
![](asset-25.png)
SCF418 Chassis Manual
4-4
Notes
![](asset-26.png)
5-1
Chapter 5: Chassis Setup and Maintenance
Chapter 5
Chassis Setup and Maintenance
5-1 Overview
This chapter covers the steps required to install components and perform mainte-
nance on the chassis. The only tool you will need to install components and perform
maintenance is a Phillips head screwdriver.
Read the safety warnings and installation instructions in Chapter 2 Standardized
Warning Statements for AC Systems before performing setup or maintenance
procedures.
5-2 Removing Power Cords
Before performing any setup or maintenance on the chassis, use the following
procedure to ensure that power has been removed disconnected from the system.
Removing the Power Cord
1. Use the operating system to power down the system, following the on-screen
prompts.
2. After the system has completely shut-down, carefully grasp the head of the
power cord and gently pull it out of the back of the power supply.
3. If your system has dual redundant power supplies, remove the cords from
both power supplies.
4. Disconnect the cord from the power strip or wall outlet.
![](asset-27.png)
SCF418 Chassis Manual
5-2
5-3 Node Locations
The SCF418 chassis contains eight individual motherboards in separate nodes. The
nodes are available in a variety of congurations with 2.5" hard drives, 3.5" hard
drives or both. See the following page for your specic SCF418 model to determine
the hard drive conguration in your chassis nodes.
Figure 5-1: Node Locations in the SCF418 Chassis
(Your chassis may differ slightly from the one shown in this illustration)
Node 4
Node 8
Node 3 Node 7
Node 6
Node 5
Node 2
Node 1
![](asset-28.png)
5-3
Chapter 5: Chassis Setup and Maintenance
5-4 Removing Nodes from the Chassis
Each of the eight individual nodes may be removed from the chassis. Note that
when a node is removed from the chassis, the hard drives located in the node will
shut-down.
Removing a Node
1. Power down the system and remove the power cords from the rear of the
node as described in Section 5-2.
2. Grasp the node by the handles on either side of the front of the node.
3. Carefully pull the node forward and out of the chassis.
5-5 Removing the Cover from the Node
Removing the Node Cover
1. Remove the power cord from the node as described in Section 5-2 and re-
move the node from the chassis as described in Section 5-4.
2. Remove the two screws on either side of the rear of the node.
3. Lift the cover up and off the node.
Figure 5-2: Removing the Node Cover
(Your node may differ slightly from the one shown in this illustration)
![](asset-29.png)
SCF418 Chassis Manual
5-4
Figure 5-3: Front and Rear of the Node
(Your node may differ from the one shown in this illustration)
Figure 5-4 SCF418BC-R1K62BP Node
5-6 Node Congurations
Overview of the Node
SCF418BC-R1K62BP
Front of Node Rear of Node
Six 2.5" hot-swappable hard drives One Micro LP expansion card
One low-prole expansion card
Front of
the Node Rear of
the Node
SCF418BC-R1K62BP Node Layout
![](asset-2a.png)
5-5
Chapter 5: Chassis Setup and Maintenance
Figure 5-5: SCF418IFL-R1K62BP Node
Figure 5-6: SCF418IL-R1K62BP Node
SCF418IF-R1K62BP
Front of Node Rear of Node
Two low-prole expansion cards Two xed 3.5" hard drives
SCF418IL-R1K62BP
Front of Node Rear of Node
One low-prole expansion card Two xed 3.5" hard drives
10
SCF418IF-R1K62BP Node Layout
SCF418IL-R1K62BP Node Layout
![](asset-2b.png)
SCF418 Chassis Manual
5-6
Figure 5-7: Hard Drives and the Corresponding Motherboards
Node 4 Node: 8
Node 3 Node: 7
Node 6
Node 5
Node 2
Node 1
5-7 Nodes and Associated Hard Drives
The SCF418 chassis contains eight individual motherboards in separate 1U nodes.
Each node controls the hard drives contained within that node. Note that if a node
is pulled out of the chassis, the hard drives associated with that node will power
down as well. Refer to the charts below and on the following pages for your specic
chassis conguration
SCF418BC-R1K62BP
Node 4
Controls six 2.5" HDDs, D1-D6
Node 8
Controls six 2.5" HDDs, H1-H6
Node 3
Controls six 2.5" HDDs, C1-C6
Node 7
Controls six 2.5" HDDs, G1-G6
Node 2
Controls six 2.5" HDDs, B1-B6
Node 6
Controls six 2.5" HDDs, F1-F6
Node 1
Controls six 2.5" HDDs, A1-A6
Node 5
Controls six 2.5" HDDs, E1-E6
![](asset-2c.png)
5-7
Chapter 5: Chassis Setup and Maintenance
SCF418IL-R1K62BP
Node 4
Controls two xed 3.5" HDDs D1-D2
Node 8
Controls two xed 3.5" HDDs H1-H2
Node 3
Controls two xed 3.5" HDDs C1-C2
Node 7
Controls two xed 3.5" HDDs G1-G2
Node 2
Controls two xed 3.5" HDDs B1-B2
Node 6
Controls two xed 3.5" HDDs, F1-F2
Node 1
Controls two xed 3.5" HDDs A1-A2
Node 5
Controls two xed 3.5" HDDs E1-E2
SCF418IF-R1K62BP
Node 4
Controls two xed 3.5" HDDs D1-D2
Node 8
Controls two xed 3.5" HDDs H1-H2
Node 3
Controls two xed 3.5" HDDs C1-C2
Node 7
Controls two xed 3.5" HDDs G1-G2
Node 2
Controls two xed 3.5" HDDs B1-B2
Node 6
Controls two xed 3.5" HDDs, F1-F2
Node 1
Controls two xed 3.5" HDDs A1-A2
Node 5
Controls two xed 3.5" HDDs E1-E2
![](asset-2d.png)
SCF418 Chassis Manual
5-8
Removing 2.5" Hard Drive Carriers from the Node
1. Press the release button on the drive carrier. This extends the drive bay
handle.
2. Use the handle to pull the drive carrier out of the chassis.
Figure 5-8: Removing a 2.5" Hard Drive Carrier
(Your node may differ slightly from the one shown in this illustration)
1
2
5-8 Installing and Removing Hard Drives
Note that if a node is pulled out of the chassis, the hard drives associated with
that node will power down as well. 2.5" hard drives are hot-swappable and may be
removed from the node without removing the node from the chassis or powering
down the system.
Only enterprise level hard drives are recommended for use in Supermicro chassis.
Installing and Removing 2.5" Hard Drives
![](asset-2e.png)
5-9
Chapter 5: Chassis Setup and Maintenance
The 2.5" hard drives are mounted in the drive carrier to simplify their installation
and removal from the chassis. These carriers also help promote proper airow for
the drive bays.
Figure 5-9: 2.5" Hard Drive Carrier
Installing a 2.5" Drive into the Hard Drive Carrier
1. Remove the two screws holding the drive to the carrier.
2. Remove the drive from the carrier.
Warning: Except for short periods of time while swapping hard drives, do not oper-
ate the server with the hard drives bays empty.
Figure 5-10: Removing the Dummy Drive from the 2.5" Drive Carrier
Drive Carrier
Dummy Drive
1
1
1
1
1
1
![](asset-2f.png)
SCF418 Chassis Manual
5-10
3. Install a new drive into the carrier with the printed circuit board side facing
down so that the mounting holes align with those in the carrier.
4. Secure the hard drive by tightening all four screws.
5. Use the open handle to replace the drive carrier into the chassis. Make sure
to close the drive carrier handle.
2.5" Drive Carrier
SAS or SATA
Hard Drive
Install Screws From
Beneath the Drive
Carrier
Figure 5-11: Installing a 2.5" Hard Drive in the Drive Carrier
4
![](asset-30.png)
5-11
Chapter 5: Chassis Setup and Maintenance
Figure 5-13: Installing a 3.5" Hard Drive in the Drive Carrier
Figure 5-12: Removing a 3.5" Fixed Hard Drive from the Node
Installing and Removing 3.5" Fixed Hard Drives
Removing 3.5" Fixed Hard Drives from the Node
1. Power down the system and remove the power cords from the rear of the
power supplies as described in Section 5-2. Remove the node from the
chassis as described in Section 5-4 and remove the cover from the node as
described in Section 5-5.
2. Remove the screw securing the 3.5" hard drive tray to the oor of the chassis.
3. Lift the hard drive and tray up and out of the chassis.
4. Remove the screws securing the hard drive to the tray and set them aside for
later use.
5. Lift the hard drive up and out of the tray.
1
3
1
5
![](asset-31.png)
SCF418 Chassis Manual
5-12
Figure 5-14: Installing a 3.5" Fixed Hard Drive in the Node
6. Install a replacement drive into the hard drive tray and secure it to the tray
with the screws previously set aside.
7. Secure the hard drive tray to the oor of the node with the screw previously
set aside.
8. Replace the node cover, return the node to its bay in the chassis, plug the
power cord into the rear of the power supply and power up the system.
1
7
![](asset-32.png)
5-13
Chapter 5: Chassis Setup and Maintenance
Figure 5-15: Removing the Screws at the Top of the Backplane
(Your node may differ slightly from the one shown in this illustration)
5-9 Removing and Installing the Backplane
The SCF418 chassis backplane is located behind the hard drives and in front of
the front system fans in each node. Although backplane failure rarely occurs, in the
event of a backplane failure, follow the instructions below.
Removing the Backplane
Removing the Backplane from the Chassis
1. Power down the system and remove the power cords from the rear of the
power supplies as described in Section 5-2. Remove the node from the
chassis as described in Section 5-4 and remove the cover from the node as
described in Section 5-5.
2. Remove the node cover and air shroud.
1
4
![](asset-33.png)
SCF418 Chassis Manual
5-14
3. Remove the four screws securing the backplane to the node.
4. Lift the backplane up and out of the node.
1
5
Figure 5-16: Removing the Backplane from the Node
(Your node may differ slightly from the one shown in this illustration)
![](asset-34.png)
5-15
Chapter 5: Chassis Setup and Maintenance
1
2
1
3
Figure 5-17: Installing the Backplane
(Your node may differ slightly from the one shown in this illustration)
Installing the Backplane
Installing the Backplane into the Chassis
1. Ensure that all of the hard drive carriers have been removed from the bays in
the front of the node (See 5-8 Installing and Removing Hard Drives).
2. Ease the backplane forward, against the front of the chassis.
3. Align the mounting holes in the backplane with the holes in the chassis. Re-
place the four screws at the top of the backplane
4. Reconnect all cables and return the hard drive trays to their bays in the front
of the node.
![](asset-35.png)
SCF418 Chassis Manual
5-16
5-10 Installing the Motherboard
Compatible Motherboards
For the most up-to-date information on compatible motherboards and other parts,
visit the Supermicro Web site at www.supermicro.com.
Permanent and Optional Standoffs
Standoffs prevent short circuits by creating space between the motherboard and the
oor of the node. The SCF418 chassis includes permanent standoffs in locations
used by most motherboards. These standoffs use the rounded Phillips head screws
included in the SCF418 accessories packaging.
Some motherboards require additional screws for heatsinks, general components
and/or non-standard security. Optional standoffs are used for these mother-
boards.
To use an optional standoff, compare the mounting holes in the motherboard with
those in the oor of the node. Then place a screw through the bottom the node and
secure the screw with a hexagonal nut (rounded side up).
Depending upon the conguration of the motherboard being used, it is also possible
that some of the optional standoffs which are pre-installed in the chassis, may need
to be removed. Add or remove standoffs as needed.
![](asset-36.png)
5-17
Chapter 5: Chassis Setup and Maintenance
Installing the Motherboard
1. Review the documentation that came with your motherboard. Become familiar
with component placement, requirements, cautions, and cable connections.
2. Remove the node from the chassis as described in Section 5-2, remove the
node from the chassis as described in Section 5-4 and remove the cover from
the node as described in Section 5-5.
3. Compare the holes in the motherboard to those in the node. Add or remove
standoffs as necessary.
4. Lay the motherboard in the node, aligning the standoffs with the motherboard.
5. Secure the motherboard to the oor of the node tray using the rounded, Phil-
lips head screws included for this purpose. Do not exceed eight pounds of
torque when tightening down the motherboard.
6. Install the expansion card associated with the motherboard if the chassis is a
hot-swappable version. Refer to the next section for instructions on installing
the expansion card
7. Secure the CPU(s), heatsinks, and other components to the motherboard as
described in the motherboard documentation. Do not exceed eight pounds of
torque when tightening down the motherboard.
8. Connect the cables between the motherboard, backplane, chassis, front
panel, and power supply, as needed. The fans may be temporarily removed
to allow access to the backplane ports.
9. Replace the expansion card bracket and secure the bracket with a screw.
Figure 5-18: Installing the Motherboard in the Node Tray
(Your node may differ slightly from the one shown in this illustration)
![](asset-37.png)
SCF418 Chassis Manual
5-18
SCF418BC-R1K62BP
Front of Node Rear of Node
Eight 2.5" hot-swappable hard drives One Micro LP expansion card
One low-prole expansion card
SCF418IL-R1K62BP
Front of Node Rear of Node
One low-prole expansion card Two xed 3.5" hard drives
SCF418IF-R1K62BP
Front of Node Rear of Node
Two low-prole expansion cards Two xed 3.5" hard drives
5-11 Installing Expansion Cards
SCF418 PCIE Slot Congurations
Some SCF418 chassis models support one or more expansion cards in each
node, Refer to the tables below to determine the PCIE slot conguration for your
particular chassis.
![](asset-38.png)
5-19
Chapter 5: Chassis Setup and Maintenance
0.15
PCIE Slot Clip
PCIE Slot Shield
Figure 5-19: I/O Shield Conguration
Installing Rear Low-prole Expansion Cards
The following instructions are for chassis nodes in which the expansion cards are
mounted in the rear of the node.
![](asset-39.png)
SCF418 Chassis Manual
5-20
Figure 5-20: Assembling the PCIE Slot Bracket and Cards
Assembling the PCIE Slot Bracket Assembly
Each node supports one expansion card. This expansion card must be plugged into
a riser card, which in turn plugs into the motherboard.
Assembling the PCIE Slot Bracket Assembly
1. Remove the node from the chassis as described in Section 5-2, remove the
node from the chassis as described in Section 5-4 and remove the cover from
the node as described in Section 5-5.
2. Open the PCIE slot clip and remove the PCIE slot shield. (See the illustration
on the previous page)
3. Remove the three mounting screws securing the PCIE slot bracket to the
node.
4. Lift the PCIE slot bracket out of the node.
5. Insert the expansion card into the riser card.
6. Secure the riser card to the PCIE slot bracket using the two screws included
in the accessory box.
7. Insert the expansion card bracket into the PCIE slot bracket
8. Secure the expansion card bracket ot the PCIE slot bracket using two screws
as illustrated.
Riser Card
PCIE Slot
Bracket
Expansion
Card Bracket
Expansion
Card
Card
Mounting
Screws
![](asset-3a.png)
5-21
Chapter 5: Chassis Setup and Maintenance
Riser Card
Bracket
Mounting
Screw
Bracket
Mounting
Screws
PCIE Slot
Bracket
Expansion
Card
Installing the PCIE Slot Bracket Assembly Into the Node
Installing the PCIE Slot Bracket Assembly
1. Remove the PCIE slot cover and assemble the PCIE slot bracket assembly
as described on the previous page.
2. Simultaneously place the expansion card into the rear window of the node
and plug the riser card into the slot on the motherboard.
3. Secure the PCIE slot bracket assembly to the node with three bracket mount-
ing screws.
Figure 5-21: Installing the PCIE Slot Bracket Assembly
(Your node may differ slightly from the one shown in this illustration)
![](asset-3b.png)
SCF418 Chassis Manual
5-22
Figure 5-22: Installing the Micro LP Card
(Your node may differ slightly from the one shown in this illustration)
Installing the Micro LP Assembly Into the Node
Installing the Micro LP Card Assembly
1. Remove the screw securing the slot cover to the chassis and set the screw
aside for later use.
2. Simultaneously place the Micro LP card into the rear window of the node and
plug the card into the slot on the motherboard.
3. Secure the Micro LP assembly to the node with two bracket mounting screws.
Installing Rear Micro LP Cards
![](asset-3c.png)
5-23
Chapter 5: Chassis Setup and Maintenance
PCIE Slot Clip PCIE Slot
Shield
Figure 5-23: PCIE Slot Conguration
(Your chassis and nodes may differ from those shown in this illustration)
Installing Front Low-prole Expansion Cards
The following instructions are for chassis nodes in which the expansion cards are
mounted in the front of the node.
![](asset-3d.png)
SCF418 Chassis Manual
5-24
Figure 5-24: Assembling the PCIE Slot Bracket and Riser Card
Assembling the PCIE Slot Bracket Assembly
Each node supports one expansion card. This expansion card must be plugged into
a riser card, which in turn plugs into the motherboard.
Assembling the PCIE Slot Bracket Assembly
1. Remove the node from the chassis as described in Section 5-2, remove the
node from the chassis as described in Section 5-4 and remove the cover from
the node as described in Section 5-5.
2. Open the PCIE slot clip and remove the PCIE slot shield. (See the illustration
on the previous page)
3. Remove the three mounting screws securing the PCIE slot bracket to the
node.
4. Lift the PCIE slot bracket out of the node.
Riser Card
PCIE Slot
Bracket
Card
Mounting
Screws
![](asset-3e.png)
5-25
Chapter 5: Chassis Setup and Maintenance
Figure 5-25: Installing the Riser Card and Bracket
(Your node may differ slightly from the one shown in this illustration)
Figure 5-26: Installing the Expansion Card
(Your node may differ slightly from the one shown in this illustration)
Bracket
Mounting
Screws
6. Insert the riser card into the appropriate slot on the motherboard.
7. Simultaneously insert the expansion card into the riser card, while sliding the
expansion card bracket into the open PCIE slot.
8. Secure the expansion card bracket ot the PCIE slot bracket using two screws
as illustrated.
5. Secure the riser card to the PCIE slot bracket using the two screws included
in the accessory box.
10
![](asset-3f.png)
SCF418 Chassis Manual
5-26
Figure 5-27: Installing the Air Shroud
(Your node may differ from those shown in this illustration)
5-12 Installing Air Shrouds
Air Shrouds
Air shrouds concentrate airow to maximize fan efciency. The SCF418 and
SCF418L chassis require an air shroud in each node.
Installing an Air Shroud
1. Power down the system and remove the power cords from the rear of the
power supplies as described in Section 5-2. Remove the node from the
chassis as described in Section 5-4 and remove the cover from the node as
described in Section 5-5.
2. Make sure that the motherboard and all components are properly installed in
each node.
3. Place the air shroud over the motherboard, as illustrated below. The air
shroud sits behind the system fans and goes over the top of the motherboard
and its components.
4. Repeat the procedure for the remaining three nodes.
1
3
1
3
![](asset-40.png)
5-27
Chapter 5: Chassis Setup and Maintenance
5-13 Removing and Installing System Fans
Removing and Installing Internal System Fans
Removing Internal System Fans
1. Power down the system and remove the power cords from the rear of the
power supplies as described in Section 5-2. Remove the node from the
chassis as described in Section 5-4 and remove the cover from the node as
described in Section 5-5.
2. Disconnect the wiring to all three fans.
3. Remove the four screws securing the fan tray to the oor of the node and set
them aside for future use.
4. Lift the fan tray up and out of the node.
5. Push upward on the underside of the failed fan to remove it from the fan tray.
Installing Internal System Fans
1. Insert the replacement fan into the fan tray, making certain that the fan is fac-
ing in the same direction as the other fans in the fan tray.
2. Place the fan tray in the node.
3. Secure the fan tray to the oor of the node with the four screws previously set
aside.
4. Reconnect the wiring to the fans.
Figure 5-28:
Removing the Fan Tray
Figure 5-29:
Removing the Fan from the Fan Tray
(Your node may differ slightly from the one shown in this illustration)
![](asset-41.png)
SCF418 Chassis Manual
5-28
Removing and Installing External System Fans
Figure 5-30: Installing the External Fan
(Your node may differ slightly from the one shown in this illustration)
Removing a Rear Exhaust Fan
1. Determine which node contains the failed fan and power down the node with
the operating system.
2. Remove the power cord from the rear of the node as described on page 5-2.
3. Press the release tab on the bottom of the fan and pull it away from rear of
the node.
Installing a Rear Exhaust Fan
1. Press the release tab on the bottom of the fan and insert it into the open fan
bay.
2. Push the fan into the bay until it clicks into the locked position.
![](asset-42.png)
5-29
Chapter 5: Chassis Setup and Maintenance
The SCF418 chassis includes redundant 1620W power supplies. These power sup-
plies are auto-switching capable. This enables the power supplies to automatically
sense and operate at a 100v to 240v input voltage. An amber light will be illuminated
on the power supply when the power is off. An illuminated green light indicates that
the power supply is operating.
Power Supply Replacement
The SCF418 chassis utilizes redundant power supplies. In the unlikely event that
the power supply unit needs to be replaced, one power supply can be removed,
without powering down the system. Replacement units can be ordered directly from
Supermicro (See the contact information in the Preface of this manual).
Changing the Power Supply
1. Disconnect the AC power cord on the back of the failed power supply.
2. Press the release tab on the back of the power supply and pull the power
supply out using the handle provided.
3. Push the replacement power supply module into the power bay until it clicks
into the locked position.
4. Plug the AC power cord back into the module and power up the node.
5-14 Replacing the Power Supplies
Release Tab
Figure 5-31: Changing the SCF418 and SCF418L Chassis Power Supplies
(Your node may differ slightly from the one shown in this illustration)
![](asset-43.png)
SCF418 Chassis Manual
5-30
Notes
![](asset-44.png)
6-1
Chapter 6: Rack Installation
Chapter 6
Rack Installation
6-1 Overview
This chapter provides a quick setup to install the SCF418 chassis into a rack. Fol-
lowing these steps in the order given should enable you to have the system installed
within a minimal amount of time.
6-2 Unpacking the System
You should inspect the box which the chassis was shipped in and note if it was
damaged in any way. If the chassis itself shows damage, you should le a damage
claim with the carrier who delivered it.
Decide on a suitable location for the rack unit that will hold your chassis. It should
be situated in a clean, dust-free area that is well ventilated. Avoid areas where
heat, electrical noise and electromagnetic elds are generated. The system needs
to be placed near a grounded power outlet. Be sure to read the Rack and Server
Precautions in the next section.
6-3 Preparing for Setup
The box your chassis was shipped in should include two sets of rail assemblies and
the mounting screws needed for installing the system into the rack. Also included
is an optional square hole to round hole converter bracket, for use in racks with
round mounting holes. Please read this section in its entirety before you begin the
installation procedure outlined in the sections that follow.
Choosing a Setup Location
•Leave enough clearance in front of the rack to enable you to open the front
door completely (~25 inches).
•Leave approximately 30 inches of clearance in the back of the rack to allow for
sufcient airow and ease in servicing.
•This product is for installation only in a Restricted Access Location (dedicated
equipment rooms, service closets and the like).
![](asset-45.png)
SCF418 Chassis Manual
6-2
6-4 Warnings and Precautions
Rack Precautions
•Ensure that the leveling jacks on the bottom of the rack are fully extended to
the oor with the full weight of the rack resting on them.
•In single rack installations, stabilizers should be attached to the rack.
•In multiple rack installations, the racks should be coupled together.
•Always make sure that the rack is stable before extending a component from
the rack.
•You should extend only one component at a time - extending two or more si-
multaneously may cause the rack to become unstable.
General Server Precautions
•Review the electrical and general safety precautions that came with the com-
ponents you are adding to your chassis.
•Determine the placement of each component in the rack before you install the
rails.
•Install the heaviest server components on the bottom of the rack rst, and then
work upwards.
•Use a regulating uninterruptible power supply (UPS) to protect the server from
power surges, voltage spikes and to keep your system operating in case of a
power failure.
•Allow the hot-plug hard drives and power supply modules to cool before touch-
ing them.
•Always keep the rack's front door and all panels and components on the servers
closed when not servicing to maintain proper cooling.
Warning: do not pick up the server by the front handles. They are designed
to pull the system from a rack only.
![](asset-46.png)
6-3
Chapter 6: Rack Installation
Rack Mounting Considerations
Ambient Operating Temperature
If installed in a closed or multi-unit rack assembly, the ambient operating tempera-
ture of the rack environment may be greater than the ambient temperature of the
room. Therefore, consideration should be given to installing the equipment in an
environment compatible with the manufacturer’s maximum rated ambient tempera-
ture (TMRA).
Reduced Airow
Equipment should be mounted into a rack so that the amount of airow required
for safe operation is not compromised.
Mechanical Loading
Equipment should be mounted into a rack so that a hazardous condition does not
arise due to uneven mechanical loading.
Circuit Overloading
Consideration should be given to the connection of the equipment to the power
supply circuitry and the effect that any possible overloading of circuits might have
on overcurrent protection and power supply wiring. Appropriate consideration of
equipment nameplate ratings should be used when addressing this concern.
Reliable Ground
A reliable ground must be maintained at all times. To ensure this, the rack itself
should be grounded. Particular attention should be given to power supply connec-
tions other than the direct connections to the branch circuit (i.e. the use of power
strips, etc.).
To prevent bodily injury when mounting or servicing this unit in a rack, you
must take special precautions to ensure that the system remains stable.
The following guidelines are provided to ensure your safety:
•This unit should be mounted at the bottom of the rack if it is the only unit in
the rack.
•When mounting this unit in a partially lled rack, load the rack from the bottom
to the top with the heaviest component at the bottom of the rack.
•If the rack is provided with stabilizing devices, install the stabilizers before
mounting or servicing the unit in the rack.
![](asset-47.png)
SCF418 Chassis Manual
6-4
6-5 Rack Mounting Instructions
This section provides information on installing the chassis into a rack unit with the
rails provided. There are a variety of rack units on the market, which may mean
that the assembly procedure will differ slightly from the instructions provided. You
should also refer to the installation instructions that came with the rack unit you are
using. NOTE: This rail will t a rack between 28.5" and 33.5" deep. The SCF418
is not designed for installation into a Telco post-style rack unit.
Identifying the Sections of the Rack Rails
The chassis package includes two rail assemblies in the rack mounting kit. Each
assembly consists of two sections: A front section that secures to the front post of
the rack and a rear section that can be adjusted in length and secures to the rear
post of the rack. These assemblies are specically designed for the left and right
side of the chassis.
Adjusting the Rails
Each rail assembly has an adjusting screw. loosening this screw allows you to adjust
the length of the rail to t a variety of rack sizes.
Figure 6-1: Identifying the Outer Rail and Inner Rails
(Left Rail Assembly Shown)
Rear
Section
This Side Faces
Outward
Adjusting
Screw
Front Section
![](asset-48.png)
6-5
Chapter 6: Rack Installation
Figure 6-3: Attaching the Rails to a Rack
Note: gures are for illustrative purposes only. Always install servers into racks
from the bottom up.
Installing the Rails on a Rack
Installing the Rails
1. Adjust the length of both rails as described on the previous page.
2. Hang the hooks of the front of the outer rail onto the slots on the front of the
rack. Secure the front of the outer rail to the rack with two screws.
3. Pull out the rear of the inner rail, adjusting the length until it ts within the
posts of the rack.
4. Hang the hooks of the rear portion of the inner rail onto the slots on the rear
of the rack. Secure the rear of the outer rail to the rear of the rack with two
screws.
5. Repeat steps 1-4 for the remaining rail.
![](asset-49.png)
SCF418 Chassis Manual
6-6
Figure 6-4: Installing into a Rack
Stability hazard. The rack stabilizing mechanism must be in place, or the
rack must be bolted to the oor before you slide the unit out for servicing.
Failure to stabilize the rack can cause the rack to tip over.
Note: gures are for illustrative purposes only. Always install servers into racks
from the bottom up.
Chassis Installation
Installing the Chassis into a Rack
1. Conrm that the rails are correctly installed on the rack.
2. Align the bottom of the chassis with the bottom of the rails.
3. Insert the chassis into the rails, keeping the pressure even on both sides,
pushing the chassis into the rack until it clicks into the locked position.
4. Secure the chassis handles to the front of the rack.
![](asset-4a.png)
A-1
Appendix A: Power Supply Specications
Appendix A
SCF418 Power Supply Specications
This appendix lists power supply specications for your chassis system.
SCF418BC-R1K620BP
1620W
MFR Part # PWS-1K62P-1R
AC Voltage 100 - 240V, 50 - 60Hz, 7.5 Amp max
+5V 18 Amp
+5V standby 3 Amp
+12V 49 Amp
-12V 0.5 Amp
+3.3V 15 Amp
![](asset-4b.png)
SCF418 Chassis Manual
A-2
Notes
![](asset-4c.png)
B-1
Appendix C: BPN-SAS-F418B6 Backplane Specications
Appendix B
BPN-SAS-F418-B6 Backplane Specications
To avoid personal injury and property damage, carefully follow all the safety steps
listed below when accessing your system or handling the components.
B-1 ESD Safety Guidelines
Electrostatic Discharge (ESD) can damage electronic com ponents. To prevent dam-
age to your system, it is important to handle it very carefully. The following measures
are generally sufcient to protect your equipment from ESD.
•Use a grounded wrist strap designed to prevent static discharge.
•Touch a grounded metal object before removing a component from the antistatic
bag.
•Handle the backplane by its edges only; do not touch its components, peripheral
chips, memory modules or gold contacts.
•When handling chips or modules, avoid touching their pins.
•Put the card and peripherals back into their antistatic bags when not in use.
B-2 General Safety Guidelines
•Always disconnect power cables before installing or removing any components
from the computer, including the backplane.
•Disconnect the power cable before installing or removing any cables from the
backplane.
•Make sure that the backplane is securely and properly installed on the mother-
board to prevent damage to the system due to power shortage.
![](asset-4d.png)
B-2
SCF418 Chassis Manual
B-3 An Important Note to Users
All images and layouts shown in this user's guide are based upon the latest PCB
revision available at the time of publishing. The card you have received may or may
not look exactly the same as the graphics shown in this manual.
B-4 Introduction to the BPN-SAS-F418-B6 Backplane
The BPN-SAS-F418-B6 backplane has been designed to utilize the most up-to-date
technology available, providing your system with reliable, high-quality performance.
This manual reects BPN-SAS-F418-B6 Revision 1.01, the most current release
available at the time of publication. Always refer to the Supermicro web site at
http://www.supermicro.com for the latest updates, compatible parts and supported
congurations.
![](asset-4e.png)
B-3
Appendix B: BPN-SAS-F418-B2R
B-5 Front Connectors
Figure B-1: Front Connectors
1. Main Power Connector (4-Pin): JP10
2. Main Power Connector (4-pin): JP13
3. Sideband Connector #1 (SB#1): JP52
4. Sideband Connector #2 (SB#2): JP54
5. Upgrade Connector: JP46
6. ATMEL Chip
7
77
7
7
7
1
2
4
3
1
2
4 3
1
2
5
6
1
2
7
8
12
7
8
44
34
12
22
23
33
+
+
+
+
+
+
BAR CODE
DESIGNED IN USA
+5V
GND
+12V
+12V
GND
+5V
REV 1.01
BPN-SAS-F418-B6
J7
J8
J12
J9
J10
J11
JP10
JP13
Y2
JP46
JP52
JP54
MH4 MH1 MH2 MH3
C5
C48
C6
C47
C45
C44
C18
A
#5
SB#1
SB#2
UPGRADE
#3
#4
#2
#1
#0
1
7
438
9
5
6
2
10
11
12
7. SATA Connector #0: J7
8. SATA Connector #1: J8
9. SATA Connector #2: J9
10. SATA Connector #3: J10
11. SATA Connector #4: J11
12. SATA Connector #5: J12
![](asset-4f.png)
B-4
SCF418 Chassis Manual
5 Upgrade Connector
The upgrade connector, designated JP46 is a
rmware upgrade port.
Backplane
Main Power
4-Pin Connector
Pin# Denition
1 and 2 Ground
3+5V
4+12V
B-6 Front Connector and Pin Denitions
1 - 2 Backplane Main Power Connectors
The 4-pin connectors, designated JP10 and
JP13 provide power to the backplane. See
the table on the right for pin denitions.
6 ATMEL Chip
The ATMEL chip is an enclosure manage-
ment chip used in the BPN-SAS-F418-B6
backplane.
3 - 4 Sideband Connectors
For SES-2 to work properly, an 8-pin sideband
cable must be connected to JP52 and JP54.
See the table to the right for pin denitions.
Sideband Connector
Pin # Denition Pin # Denition
2 Backplane
Addressing
(SB5)
1 Controller
ID (SB6)
4 Reset (SB4) 3 GND (SB2)
6 GND (SB3) 5 SDA (SB1)
8 Backplane
ID (SB7)
7 SCL (SB0)
10 No Connec-
tion
9 No Connec-
tion
7 - 11 SATA Connectors #0 - #5
SATA connectors #0 - #5 are used to connect
the SATA cables. The six ports are designated
#0 - #5 and are compatible with both SAS and
SATA drives.
![](asset-50.png)
B-5
Appendix B: BPN-SAS-F418-B2R
1
3
12
13 24
25
36
37
48
A
C
A
C
A
C
A
C
A
C
AC
A
C
A
C
A
C
A
C
A
C
A
C
22
213327
8
7
9
22
2133
27
8
7
9
22
21
33
27
87
22
213327
87
9
22
21
33
27
8
7
9
22
3327
87
9
D13
D6
D5 D37
D29
D23 D107
D40
D24
D22
D12
D102
J35
J21 J2
J15J13
J1
FAIL5 ACT5
FAIL4 ACT4
FAIL3 ACT3
FAIL2 ACT2
FAIL1 ACT1
SAS #5 SAS #4
SAS #3
SAS #2
SAS #1
FAIL0 ACT0
SAS #0
B-7 Rear Connectors and LED Indicators
Rear SAS/SATA Connectors and LED Indicators
Ports SAS/SATA Drive
Number
Rear
Connectors
Failure LED
Indicator
Activity LED
Indicator
SAS#0 SAS/SATA HDD #0 J1 D5 D12
SAS#1 SAS/SATA HDD #1 J13 D23 D22
SAS#2 SAS/SATA HDD #2 J21 D37 D40
SAS#3 SAS/SATA HDD #3 J35 D107 D102
SAS#4 SAS/SATA HDD #4 J2 D6 D13
SAS#5 SAS/SATA HDD #5 J15 D29 D24
SAS #0
SAS #1
SAS #2
SAS #3
SAS #4
SAS #5
D29
D107
D23
D6
D37
D5
D24
D102
D22
D13
D40
D12
Figure C-B: Rear Connectors and LED Indicators
![](asset-51.png)
B-6
SCF418 Chassis Manual
Notes
![](asset-52.png)
C-1
Appendix C: BPN-SAS-F418-B2R Backplane Specications
Appendix C
BPN-SAS-F418B2R Backplane Specications
To avoid personal injury and property damage, carefully follow all the safety steps
listed below when accessing your system or handling the components.
C-1 ESD Safety Guidelines
Electrostatic Discharge (ESD) can damage electronic com ponents. To prevent dam-
age to your system, it is important to handle it very carefully. The following measures
are generally sufcient to protect your equipment from ESD.
•Use a grounded wrist strap designed to prevent static discharge.
•Touch a grounded metal object before removing a component from the antistatic
bag.
•Handle the backplane by its edges only; do not touch its components, peripheral
chips, memory modules or gold contacts.
•When handling chips or modules, avoid touching their pins.
•Put the card and peripherals back into their antistatic bags when not in use.
C-2 General Safety Guidelines
•Always disconnect power cables before installing or removing any components
from the computer, including the backplane.
•Disconnect the power cable before installing or removing any cables from the
backplane.
•Make sure that the backplane is securely and properly installed on the mother-
board to prevent damage to the system due to power shortage.
![](asset-53.png)
C-2
SCF418 Chassi Manual
C-3 An Important Note to Users
All images and layouts shown in this user's guide are based upon the latest PCB
Revision available at the time of publishing. The card you have received may or
may not look exactly the same as the graphics shown in this manual.
C-4 Introduction to the BPN-SAS-F418-B2R Backplane
The BPN-SAS-F418-B2R backplane has been designed to utilize the most up-
to-date technology available, providing your system with reliable, high-quality
performance.
This manual reects BPN-SAS-F418-B2R Revision 1.01, the most current release
available at the time of publication. Always refer to the Supermicro web site at
http://www.supermicro.com for the latest updates, compatible parts and supported
congurations.
![](asset-54.png)
C-3
Appendix C: BPN-SAS-F418B2R Backplane Specications
+
+
1
2
3 4
7
7
DESIGNED IN USA
5V12V
#0
#1
REV 1.01
BPN-SAS-F418-B2R
MH2
MH1
C45
JP10
J6
J5
c-5 Front Connectors
Figure C-1: Front Connectors
1. Main Power Connector (4-pin): JP10
2. SAS Port #0: J5
3. SAS Port #1: J6
1
3
2
![](asset-55.png)
C-4
SCF418 Chassis Manual
Backplane
Main Power
4-Pin Connector
Pin# Denition
1 and 2 Ground
3+5V
4+12V
C-6 Front Connector and Pin Denitions
1 Backplane Main Power Connector
The 4-pin connector, designated JP10 pro-
vides power to the backplane. See the table
on the right for pin denitions.
2 - 3 SATA Connectors
The SATA connectors #0 - #1 are used to
connect the SATA cables. The two ports are
designated SAS #0 - SAS #1 and are compat-
ible with both SAS and SATA drives.
![](asset-56.png)
C-5
Appendix C: BPN-SAS-F418B2R Backplane Specications
BAR CODE
22
21
33
27
8
7
9
22
21
33
27
8
7
9
A
C
A
C
J1
J2
D12
D13
ACT#0
ACT#1
SAS#1
SAS#0
C-7 Rear Connectors and LED Indicators
Rear SAS/SATA Connectors and LED Indicators
Ports SAS/SATA
Drive Number Rear Connectors Activity LED Indicator
SAS#0 SAS/SATA
HDD #0
J1 D12
SAS#1 SAS/SATA
HDD #1
J2 D13
SAS #0
SAS #1
D13
D12
Figure C-2: Rear Connectors and LED Indicators
![](asset-57.png)
C-6
SCF418 Chassis Manual
Disclaimer (cont.)
The products sold by Supermicro are not intended for and will not be used in life sup-
port systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices,
aircraft/emergency communication devices or other critical systems whose failure to per-
form be reasonably expected to result in signicant injury or loss of life or catastrophic
property damage. Accordingly, Supermicro disclaims any and all liability, and should
buyer use or sell such products for use in such ultra-hazardous applications, it does so
entirely at its own risk. Furthermore, buyer agrees to fully indemnify, defend and hold
Supermicro harmless for and against any and all claims, demands, actions, litigation,
and proceedings of any kind arising out of or related to such ultra-hazardous use or
sale.
