User Manual
ON/OFF
Forward
Stop
Reverse
Hold down the red button
and speak close to the mic
Mic
One "9 volt" and 4 "AA"
batteries required
(Not included)
FOR AGES 5 AND UP
INSTALLING BATTERIES
Note: Any batteries purchased for use in this toy may pose a
hazard to children, please check safety notice supplied with
batteries before use.
Warning: Dispose of batteries promptly and properly; do not
bury or burn them.
CAUTIONS:
• Batteries to be installed by adults only.
• Use only fresh batteries of the required size and
recommended type.
• Do not mix old and new batteries, different types of batteries
(standard, alkaline, or rechargeable), or rechargeable batteries
of different capacities.
IN THE CONTROLLER
Use a Phillips head screw driver to remove the battery
compartment cover located on the back of the controller.
Insert one "9V" alkaline battery in the correct position as marked
in compartment. Replace cover and screw.
IN THE SPIDER
You need four AA batteries to power your Spider.
1. Slide OFF/ON on the bottom of the Spider to OFF.
2. Remove screw on battery case door with Phillips screw driver
and insert 4 AA batteries as shown (follow +/- inside case and
insert).
3. Retighten battery door.
RADIO CONTROL DRIVING
1. Slide ON/OFF to ON. The top button on the driver's suit lights.
2. Fully extend the antenna on the transmitter and slide OFF/ON
on the transmitter to ON. The indicator on the transmitter
lights.
3. Use the transmitter's control levers to move and steer the
Spider.
4. When you finish driving the Spider, slide OFF/ON on the
Spider and the transmitter to OFF.
SPIDER FUNCTION CONTROLS
1. Turn on the spider and transmitter.
2. Use the transmitter’s control levers to steer your spider.
• To go forward, push both levers forward.
• To reverse, pull both levers back.
• To turn left or right, push the opposite lever forward. For
example, to turn left, push the right lever forward.
• To spin left or right, push the opposite lever forward and pull
the other lever back.
3. Turn off the spider and transmitter when you finish playing.
FCC Warning: Changes or modifications to this unit not
expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of
the following measures:
❑
Reorient or relocate the receiving antenna.
❑
Increase the separation between the equipment and receiver.
❑
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
❑
Consult the dealer or an experienced radio/TV technician
for help.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
CHOKING HAZARD-
Small parts
Not for children under 3 years
ITEM 6863
Size: 297mm x 210mm (A4 Size)
Color: Black Color Only
Full
Function Radio Control
Item/Art# 6863
All Rights World-wide Reserved
SUPERTOYS U.S.A. INC.
2145 JACQUELINE AVE, BELLMORE, N.Y. 11710
Tel: 212-242-6180 Fax: 1-516-781-6860
CAUTION: NOT SUITABLE FOR CHILDREN
UNDER 36 MONTHS DUE TO SMALL PARTS
MADE IN CHINA
1- Check batteries frequently.
2- Always replace with fresh alkaline batteries.
3- Check battery terminals for contact.
4- Always turn switch off when not in use.
5- Run on smooth level surfaces.
Helpful hints for maintenance
and performance.
41
1.5
VOLT
D
1.5
VOLT
C
1.5
V
AA
9
VOLT
GA 13
The eyes light when
you switch on
your Spider
