Suunto 2458 Multipurpose sensor module User Manual Technical
Suunto Oy Multipurpose sensor module Technical
Suunto >
Users Manual
MOVESENSE
Manual
DRAFT 2017 -11-01
Movesense
Manual
i
CONTENTS
CONTENTS ......................................................................................................................... I
1 SAFETY .................................................................................................................... 1
1.1 Types of safety precautions .......................................................................... 1
1.2 Safety precautions ......................................................................................... 1
2 GETTING STARTED ................................................................................................. 2
3 CARE AND SUPPORT .............................................................................................. 3
3.1 Handling guidelines ....................................................................................... 3
3.2 Software updates ........................................................................................... 3
3.3 Battery ............................................................................................................ 3
4 REFERENCE ............................................................................................................ 4
4.1 Technical specifications ................................................................................ 4
4.2 Compliance ..................................................................................................... 4
4.3 Patent notice .................................................................................................. 6
4.4 Trademark ...................................................................................................... 6
4.5 Disposal of device.......................................................................................... 6
4.6 Copyright ........................................................................................................ 6
Movesense
Manual
1(7)
1 SAFETY
1.1 Types of safety precautions
WARNING: is used in connection with a procedure or situation that
may result in serious injury or death
CAUTION: is used in connection with a procedure or situation that will
result in damage to the device
NOTE: is used to emphasize important information
TIP: is used for extra tips on how to utilize the features and functions
of the device.
1.2 Safety precautions
WARNING: Only for recreational use.
WARNING: Always consult your doctor before beginning an exercise
program. Overexertion may cause serious injury.
CAUTION: Do not apply solvent of any kind to the product, as it may
damage the surface.
CAUTION: Do not apply insect repellent on the product, as it may
damage the surface.
CAUTION: Do not knock or drop the product, as it may get damaged.
NOTE: At Suunto we use advanced sensors and algorithms to
generate metrics that can help you in your activities and adventures. We
strive to be as accurate as possible. However, none of the data our products
and services collect is perfectly reliable, nor are the metrics they generate
absolutely precise. Calories, heart rate, location, movement detection, shot
recognition, physical stress indicators and other measurements may not
match the real world. Suunto products and services are intended for
recreational use only and are not meant for medical purposes of any kind.
Movesense
Manual
2(7)
2 GETTING STARTED
To start using the Movesense sensor with a heart rate belt:
1. Snap the sensor firmly into the belt connector.
2. Adjust the belt length as needed.
3. Moisten the belt electrode areas with water or electrode gel.
4. Put the belt on so that it fits snugly and the Suunto logo is facing up.
The belt turns on automatically when it detects a heartbeat.
TIP: Wear the belt against your bare skin for best results.
Pairing
You need to connect (pair) your Suunto Smart Sensor with compatible
BluetoothⓇ Smart or Smart Ready devices to view your heart rate. These
can be, for example, Suunto sports watches or mobile devices with sports
apps such as Sports Tracker.
Pairing procedures may vary, so refer to the instructions of your mobile
application or sports watch for guidance. When pairing, ensure you are at
least 10 m (33 ft) away from other Bluetooth devices.
You can pair the belt with multiple sports watches and apps, but only one
connection can be active at a time.
Movesense
Manual
3(7)
3 CARE AND SUPPORT
3.1 Handling guidelines
The Movesense sensor module be rinsed with fresh water after each use.
CAUTION: Do not pull the sensor module straight off the connector. This
may damage the belt connectors. Unsnap one side at a time.
CAUTION: Do not machine wash the sensor module. Machine washing
damages the module.
3.2 Software updates
The Movesense firmware can be updated over Bluetooth.
NOTE: Updating requires a data connection. Carrier data connection fees
may apply
3.3 Battery
The Movesense sensor uses a 3-Volt lithium cell (CR 2025).
To replace the battery:
1. Remove the sensor from the Movesense connector.
2. Open the battery cover.
3. Replace the battery.
4. Firmly close the battery cover.
Movesense
Manual
4(7)
4 REFERENCE
4.1 Technical specifications
Weight: 9.4 g/0.33 oz (battery included)
Diameter: 36.5 mm/1.44 in
Thickness: 8 mm/0.32 in
Operating temperature: -20° C to +60° C/-5° F to +140° F
Storage temperature: -30° C to +60° C/-22° F to +140° F
Water resistance: 30 m/98 ft (according to ISO 6425)
Battery type: CR2025
Battery life: ~ 500 hours
Transmission frequency: 2.4GHz (Bluetooth Smart).
Manufacturer
Suunto Oy
Tammiston kauppatie 7 A
FI-01510 Vantaa FINLAND
4.2 Compliance
4.2.1 EU Radio Directive
Hereby, Suunto Oy, declares that the radio equipment type OP174 is in
compliance with Directive 2014/53/EU. The full text of the EU declaration of
conformity is available at the following internet address:
www.suunto.com/EUconformity.
4.2.2 United States FCC
Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Class B device notice
NOTE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
Movesense
Manual
5(7)
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
RF exposure safety
Product OP174 is a radio transmitter and receiver.
It is designed not to exceed the emission limits for exposure to radio
frequency (RF) energy set by the Federal Communications Commission.
This transmitter must not be co-located or operating in conjunction with any
other antenna or transmitter.
4.2.3 Canada ISED
Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
Les changements ou modifications non expressément approuvés par la
partie responsable de la conformité pourraient annuler l'autorisation de
l'utilisateur d'utiliser l'équipement.
This device complies with Industry Canada’s licence-exempt RSSs.
Operation is subject to the following two conditions: (1) This device may not
cause interference; and (2) This device must accept any interference,
including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables
aux appareils radio exempts de licence. L'exploitation est autorisée aux
deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage,
et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique
subi, même si le brouillage est susceptible d'en compromettre le
fonctionnement.
RF exposure safety
The model is a radio transmitter and receiver.
Movesense
Manual
6(7)
It is designed not to exceed the emission limits for exposure to radio
frequency (RF) energy set by the ISED.
This transmitter must not be co-located or operating in conjunction with any
other antenna or transmitter.
Le modèle est un émetteur et un récepteur radio.
Il est conçu pour ne pas dépasser les limites d'émission pour l'exposition à
l'énergie radiofréquence (RF) établie par l'ISDE.
L’émetteur ne doit pas être colocalisé ni fonctionner conjointement avec à
autre antenneou autre émetteur.
CAN ICES-3 (B)/NMB-3(B)
This Class B digital apparatus complies with Canadian ICES-003
Cet appareil numérique de clase B est conforme à la norme Canadienne
ICES-003.
4.3 Patent notice
This product is protected by pending patent applications and their
corresponding national rights.
4.4 Trademark
Movesense, its logos, and other Suunto brand trademarks and made names
are registered or unregistered trademarks of Suunto Oy. All rights are
reserved.
4.5 Disposal of device
Please dispose of the device in an appropriate way, treating it as electronic
waste. Do not throw it in the garbage. If you wish, you may return the device
to your nearest Suunto representative.
4.6 Copyright
Copyright © Suunto Oy. All rights reserved. Suunto, Suunto product names,
their logos and other Suunto brand trademarks and names are registered or
unregistered trademarks of Suunto Oy. This document and its contents are
proprietary to Suunto Oy and are intended solely for the use of clients to
obtain knowledge and information regarding the operation of Suunto
products. Its contents shall not be used or distributed for any other purpose
Movesense
Manual
7(7)
and/or otherwise communicated, disclosed or reproduced without the prior
written consent of Suunto Oy. While we have taken great care to ensure that
information contained in this documentation is both comprehensive and
accurate, no warranty of accuracy is expressed or implied. This document
content is subject to change at any time without notice. The latest version of
this documentation can be downloaded at www.suunto.com.
