Suzhou Sate Auto Electronic TSB23-RE Tire Pressure Monitoring System Sensor User Manual
Suzhou Sate Auto Electronic Co., Ltd Tire Pressure Monitoring System Sensor
User Manual
TPMS Sensor Installation Instruction
1. General Description
Tire pressure sensor is composed of RF chip, battery, antenna and Rf
matching network. It is applied to monitor tire pressure, temperature and
acceleration and the tire data is transmitted via center frequency 433.92MHz.
2. Operation Functions
Transmitter ID Programming:transmitter ID can be progranmmed for easy
replacement
Alarm Record Inquity:automatically record the 10 alarm records
Standard Pressure Programming: standard pressure for each tire can be
programmed on monitor
3. Product Features
Powerful functions including low pressure alarms in 3 levels,fast leak alarm
and standard pressure setting etc.
Monitor connects to continuous power to ensure full-time monitoring
Design of the whole system matches the rtuck perfectly
Simple operation for function programming and inquiry
4. Installing structure
5. Installation requirements
valve
cap
nut
cushion
Valve
rod
TPMS
Sensor
TPMS Sensor Installation Instruction
moment:3.8N.m(±0.3N)
Tires must do dynamic balance testing and adjusting.
Federal Communications Commission (FCC) Interference
Statement
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generate, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may
cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by
the party responsible for compliance could void the user’s authority to
operate this equipment.
RF exposure warning
This equipment complies with FCC radiation exposure limits set forth
for an uncontrolled environment.
This equipment must not be collocated or operating in conjunction with
any other antenna or transmitter.
