Suzhou Sate Auto Electronic TSB40 Tire Pressure Monitoring System Sensor User Manual
Suzhou Sate Auto Electronic Co., Ltd Tire Pressure Monitoring System Sensor
User manual
TSB40 User manual
1. General Description
Tire pressure sensor is composed of RF chip, battery, antenna and Rf
matching network. It is applied to monitor tire pressure, temperature and
acceleration and the tire data is transmitted via center frequency 433.92MHz.
2. Operation Functions
Transmitter ID Programming:transmitter ID can be progranmmed for easy
replacement
Alarm Record Inquity:automatically record the 10 alarm records
Standard Pressure Programming: standard pressure for each tire can be
programmed on monitor
3. Product Features
Powerful functions including low pressure alarms in 3 levels,fast leak alarm
and standard pressure setting etc.
Monitor connects to continuous power to ensure full-time monitoring
Design of the whole system matches the rtuck perfectly
Simple operation for function programming and inquiry
4. Installing structure
5. Installation requirements
4.
valve
cap
3.
nut
2.
cushion
1.
Valve
rod
TPMS
Sensor
FCC ID: TTETSB40
User manual
moment:3.8N.m(±0.3N)
Tires must do dynamic balance testing and adjusting.
