Video Splitter User Manual
Welcome to use series products:
User Manual
Factory: ISO9002 Certificate
Production:CCC CE ertificate
1* Product Introduction:
VGA splitter(video splitter) is the equipment to distribute 1 video signal to
multiple VGA output equipments synchronously, to ensure different displays
show the same image. The euipment with additional power adapter, which can
blow up and dispoze the output signals, in order to ensure and improve the
signal output plus. Advantages: high bandwidth, resolution and reliability, As
well as the long-distance signal transmission, the max long-distance can reach
65 meters. it could be used in: securities business, computer exhibition hall,
public broadcasting and education & training center etc.
2* Safety guide:
In order to make sure the correct use of the device and the security of the
operator, please do as following:
1) The power supply of the device is USB Provide.
2) Do not put the device in the place where is too hot or too cold.
3) The power of the device will heat when working. So keep the working
environment in good ventilation in order not to damage the machine with
high temperature.
4) The non-professional should not take apart the machine or repair it without
permission in order to avoid accident or aggravating damage extent of the
device.
5) Do not spill any chemical product or liquid on the device or near it.
3* Trouble shooting
1) When no output signal, please check:
A: Whether the power wire is plugged into the device.
B: Whether the connection wire is well.
C: Whether there is input signal.
2) If the power light is off, the power supply maybe wrong.
3) If the output image is interfered, the device may not be grounded properly.
4) If the output image is not clear, please check whether the connection wire
has problem.
4* Specification
Type CV- 1215
Bandwidth 150MHz
Product Type 1 into 2
Connector type INPUT HD15M OUTPUT HD15F
Min input voltage 0.5Vp-p
Max input voltage 1.0Vp-p
signal
I/O impedance 75Ω
Optimal Resolution 1280*1024
Max Resolution 1920*1080
Horizontal
frequency 30-120KHz
Video
Vertical frequency 40-120Hz
Dimension (mm) 66*5*61.4*24.2
pertine
nce Power Is USB Provide (5V 500mA)
House Plastic
NOTE:
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
ency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However,
there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
-- Reorient or relocate the receiving antenna
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:(1)this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference
that may cause undesired operation.
The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modifications to this equipment. Such modifications could void the
user's authority to operate the equipment.
