Swann Communications SWO-HUB01K SmartHub User Manual
Swann Communications Pty Ltd SmartHub
User Manual.pdf
Get Started in Four Easy Steps
At a Glance
Questions? Get more information regarding the setup and use of your
SwannOne products on the web at swannone.com, or simply email
us at support@swannone.com.
Thank you for choosing the SwannOne™ Smart Hub. Please take a moment to familiarize
yourself with the key areas of the hub.
Status light
Speaker &
Microphone
Ethernet
port
Storage
nook
USB port
Power port
WPS button
Reset button
USB port
Connect Power
Adapter
Connect Ethernet
Cable
Find
MAC ID
Register
Smart Hub
INPUT:5V 2A
This device compli es wit
h Part 15 of the FCC Rules. O peration is subjec t to the
follow ing two conditions : (1) this device may no t cause h armful inte rfere nce, and
(2) this d evice must accept an y interference rec eived , including i nterf erence that
may caus e undes ired operat ion
MAC ID:XX-XX-XX-
XX-XX-XX
FCC ID:VMISWO-H
UB01K
S/No:XXXXXMMYY
XXXXX
Model:SWO-HUB01
K
IC:XX123A-B123456
7890
Each USB:5V 500
mA
Designed in Australia Made in Chi na
MAC ID:XX-XX-X
-XX-XX-XXX
123 4
QSGSH130115E
The USB ports are ideal for charging most smartphones and portable USB devices.
EN
Smart Hub
Quick Start Guide
Read me first
© Swann Communications 2015
Operating temperature: -4C to 45C, 90% relative humidity
FCC Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This
device may not cause harmful interference, and (2) This device must accept any interference received, including
interference that may cause undesired operation.
Battery Safety Information
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED
BATTERIES ACCORDING TO THE INSTRUCTIONS.
SwannOne Warranty
Your SwannOne products are backed by a full 12 month guarantee from the date of purchase. In the unlikely event
of anything going wrong, you can have confidence that your purchase is protected. Refer to swannone.com for
terms and conditions.
Disposal and Recycling Information
Correct Disposal of this product. This marking indicated that this product should not be disposed with
other household wastes throughout the EU. To prevent possible harm to the environment or human
health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of
material resources. To return your used device, please use the return and collection systems or contact
the retailer where the product was purchased. They can take this product for environment safe recycling.
Intern et Ethernet
432
WPS
The Ethernet cable is only required for initial setup. Configure the Smart Hub to
connect to your Wi-Fi network directly during registration then go wireless.
Connect Ethernet Cable Connect Power Adapter Find MAC ID Register Smart Hub
Broadband Internet router
Ethernet cable
Power adapter
Ethernet port
Power port
Connect the Smart Hub directly to your broadband router with the
included Ethernet cable.
Plug the included power adapter into a power outlet and connect
it to the Smart Hub
There is an information label located on the bottom of the Smart Hub
containing all the little details about your hub including it’s MAC ID. You
will need the MAC ID during registration, so have it ready on hand. It
looks something like the example below.
MAC ID: __ __ – __ __ – __ __ – __ __ – __ __ – __ __
1 2 3 4
INP UT:5V 2A
This d evice c ompli es with P art 15 of t he FCC Ru les. Op erati on is sub ject to t he
fol lowin g two con ditio ns: (1) t his dev ice may n ot caus e harmf ul inte rfere nce, an d
(2) t his dev ice mus t accep t any int erfer ence re ceive d, incl uding i nterf erenc e that
may c ause un desir ed oper ation
MAC I D:XX- XX-XX -XX-X X-XX
FCC I D:VMI SWO-H UB01K
S/N o: XX XX XM MY YX XX XX
Mod el :S WO -H UB 01 K
IC: XX123A -B12 34 56 78 90
Eac h USB:5 V 500mA
Designed in Australia Made in Ch ina
INPUT:5V 2A
This device complies with Part 15 of the FCC Rules. Op
eration is subject to the
following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation
MAC ID:XX-XX-XX-XX-XX-XX
FCC ID:VMISWO-HUB01K
S/No:XXXXXMMYYXXXXX
Model:SWO-HUB01K
IC
:
XX123A
-
B1234567890
Each USB:5V 500mA
Designed in Australia Made in China
MAC ID:AB-CD-E -1 2 -3 4 -5 6F
Jot it down here!
Creating a SwannOne Account
Before you can register the Smart Hub, you will need to create a
SwannOne account. Your SwannOne account is what you use to control
and manage all your SwannOne devices and services from anywhere.
To sign up for a free account, go to home.swannone.com from your
PC, Mac, smartphone or tablet.
Installing the Smart Hub
Log in to your new SwannOne account at
home.swannone.com and then follow
the on-screen instructions to add the
Smart Hub to your SwannOne account.
If the Smart Hub is not connecting as expected, try performing a hard reset by using
a straightened paperclip to depress the Reset button while holding the WPS button
until the status light on the front of the Smart Hub goes off.
